Sharp UX-177 User manual

SERVICE MANUAL
No. 00ZUX177H/SME
FACSIMILE
MODEL UX-177
This document has been published to be used
for after-sales service only.
The contents are subject to change without notice.
SHARP CORPORATION
Parts marked with " " is important for maintaining the safety of the set. Be sure to replace these parts with specified ones for
maintaining the safety and performance of the set.
CHAPTER 1. GENERAL DESCRIPTION
[1] Specifications . . . . . . . . . . . . . . . . . . . . .1-1
[2] Operation Panel . . . . . . . . . . . . . . . . . . .1-2
[3] Transmittable Documents . . . . . . . . . . . .1-3
[4] Installation . . . . . . . . . . . . . . . . . . . . . . . .1-4
[5] Quick reference guide . . . . . . . . . . . . . . . 1-6
CHAPTER 2. ADJUSTMENTS
[1] Adjustments . . . . . . . . . . . . . . . . . . . . . . .2-1
[2] Diagnostics and service soft switch . . . . .2-2
[3] Troubleshooting . . . . . . . . . . . . . . . . . . .2-15
[4] Error code table . . . . . . . . . . . . . . . . . . .2-16
CHAPTER 3. MECHANISM BLOCKS
[1] General description . . . . . . . . . . . . . . . . . 3-1
[2] Disassembly and assembly
procedures . . . . . . . . . . . . . . . . . . . .3-6
CHAPTER 4. DIAGRAMS
[1] Block diagram . . . . . . . . . . . . . . . . . . . . .4-1
[2] Wiring diagram . . . . . . . . . . . . . . . . . . . .4-2
[3] Point-to-pointdiagram . . . . . . . . . . . . . . .4-3
CHAPTER 5. CIRCUIT DESCRIPTION
[1] Circuit description . . . . . . . . . . . . . . . . . .5-1
[2] Circuit description of control PWB . . . . . .5-2
[3] Circuit description of TEL/LIU PWB . . . . .5-8
[4] Circuit description of
power Supply PWB . . . . . . . . . . . .5-11
[5] Circuit description of CCD PWB . . . . . .5-12
CHAPTER 6. CIRCUIT SCHEMATICS AND
PARTS LAYOUT
[1] Control PWB circuit . . . . . . . . . . . . . . . . .6-1
[2] TEL/LIU PWB circuit . . . . . . . . . . . . . . . .6-8
[3] Power supply PWB circuit . . . . . . . . . . .6-13
[4] CCD PWB circuit . . . . . . . . . . . . . . . . . .6-15
[5] Operation panel PWB circuit . . . . . . . . .6-16
CHAPTER 7. OPERATION FLOWCHART
[1] Protocol . . . . . . . . . . . . . . . . . . . . . . . . . .7-1
[2] Power on sequence . . . . . . . . . . . . . . . . .7-2
CHAPTER 8. OTHERS
[1] Service tools . . . . . . . . . . . . . . . . . . . . . .8-1
[2] IC signal name . . . . . . . . . . . . . . . . . . . . .8-4
PARTS GUIDE
CONTENTS
UX-177H

(Danish) ADVARSEL !
Lithiumbatteri-Eksplosionsfare ved fejlagtig håndtering.
Udskiftning må kun ske med batteri af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandoren.
(English) Caution !
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the equipment manufacturer.
Discard used batteries according to manufacturer’s
instructions.
(Finnish) VAROITUS
Paristo voi räjähtää, jos se on virheellisesti asennettu.
Vaihda paristo ainoastaan laitevalmistajan suosittelemaan
tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden
mukaisesti.
(French) ATTENTION
Il y a danger d’explosion s’ il y a remplacement incorrect
de la batterie. Remplacer uniquement avec une batterie du
même type ou d’un type recommandé par le constructeur.
Mettre au rébut les batteries usagées conformément aux
instructions du fabricant.
(Swedish) VARNING
Explosionsfare vid felaktigt batteribyte.
Använd samma batterityp eller en ekvivalent
typ som rekommenderas av apparattillverkaren.
Kassera använt batteri enligt fabrikantens
instruktion.
(German) Achtung
Explosionsgefahr bei Verwendung inkorrekter Batterien.
Als Ersatzbatterien dürfen nur Batterien vom gleichen Typ oder
vom Hersteller empfohlene Batterien verwendet werden.
Entsorgung der gebrauchten Batterien nur nach den vom
Hersteller angegebenen Anweisungen.
CAUTION FOR BATTERY REPLACEMENT
UX-177H

CHAPTER 1. GENERAL DESCRIPTION
[1] Specifications
Applicable telephone line: Public switched telephone network
Compatibility: ITU-T (CCITT) G3 mode
Configuration: Half-duplex, desktop transceiver
Compression scheme: Modified Huffman and Sharp special
mode
Scanning method: Flat-bed, solid-state CCD
Resolution: Horizontal:
8 dot/mm
Vertical:
Standard
Fine/Halftone−7.7 lines/mm
Super fine−15.4 lines/mm
Recording system: Thermal recording
Display: 7 x 5 dots, 1 line by 16-digit display
Reception modes: FAX/TEL/TEL-FAX/A.M.
Modem speed: 9600 bps with automatic fallback to
7200, 4800, or 2400 bps
Transmission time* : Approx. 15 seconds
(Sharp special mode)
Effective recording width: 210 mm, max.
Input document size: Automatic feeding:
Width 148 to 216 mm
Length 128 to 297 mm
Manual feeding:
Width 148 to 216 mm
Length 128 to 1000 mm
Effective scanning width: 210 mm
Automatic document feeder: 20 sheets max.
Halftone (gray scale): 64 levels
Contrast control: Automatic/Dark selectable
Copy function: Standard
Telephone function: Standard
(cannot be used if power fails)
Noise emission: Less than 70 dBA
(Measured according to DIN 45635.)
Power requirements: 230 V AC, 50 Hz
Operating temperature: 5 to 35°C
Power consumption: Stand-by: 8 W
Maximum: 120 W
Dimensions: Width: 341 mm
Depth: 257 mm
Height: 123 mm
Weight: 2.9kg
* Based on ITU-T (CCITT) Test Chart #1 at standard resolution in
Sharp special mode, excluding time for protocol signals (i.e.,
ITU-T phase C time only).
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for procduct
improvement without prior notice. The performance specifications figures indicated are nominal values of production units. There may be some
deviation from these values in individual units.
UX-177H
1 – 1

[2] Operation Panel
REDIAL key
Press this key to
automatically redial the
last number dialed.
SPEED DIAL key
Press this key to dial a
2-digit. Speed Dial number.
Display
This displays various
messages during operation
and programming.
RESOLUTION key
Press this key to adjust the
resolution and contrast
before sending or copying
a document.
FUNCTION key
Press this key to select
various special functions.
RECEPTION MODE key
Press this key to select
the mode of reception.
Number keys
Use these keys to dial
numbers, and enter
numbers and letters
during number/name
storing procedures.
SEARCH/R key
Press this key to search
for an automatic dialing
number, or, if you are on
a P.b.x. exension, press
this key to transfer or put
the other party on hold.
SPEAKER key
Press this key to dial a
number without picking
up the handset.
Rapid keys
Use these keys
to dial fax and voice
numbers automatically.
Rapid key 01 (indicated
by the blue logo) also
serves as an access key
when using the Mercury
Service. (Note that you
must attach the Rapid key
labels.)
COPY/HELP key
When a document is
in the feeder, press
this key to make a
copy. At any other
time, press this key
to print out the help
list, a quick reference
guide to the operation
fo your.
START key
Press this key to send or
receive a document.
STOP key
Press this key to stop
operations before
they are completed.
123
456
789
0
ABC
SPACE DEF
GHI JKL MNO
PQRS TUV
SYMBOLS
WXYZ
SPEED DIAL
REDIAL
SHIFT
DELETE
SEARCH/R
SPEAKER
01 02 03 04 05
06 07 08 09 10
11 12 13 14 15
16 17 18 19 20
COPY/HELP STOP
START
FUNCTION RESOLUTION
RECEPTION
MODE
VOLUME
UP
DOWN
UX-177
VOLUME key
Press these keys to adjust
the volume of the speaker
when the SPEAKER key
has been pressed, or the
volume of the ringer at all
other times.
UX-177H
1 – 2

[3] Transmittable Documents
1. Document Sizes
Normal size width 148 – 216 mm
length 128 – 297 mm
* With special sizes, only one sheet can be fed into the machine at
a time. Insert next page into feeder as current page is being
scanned.
2. Paper Thickness & Weight
Normal size
ADF 10
sheets Thickness 0.06–0.12 mm
Weight 52–104 g/m2
ADF 20
sheets Thickness 0.06–0.09 mm
Weight 52–74.3 g/m2
Special size Thickness 0.12–0.20 mm
Weight 52–157 g/m2
3. Document Types
•Normal paper
Documents handwritten in pencil (No. 2 lead or softer), fountain
pen, ball-point pen, or felt-tipped pen can be transmitted.
Documents of normal contrast duplicated by a copying machine
can also be transmitted.
•Diazo copy (blue print)
Diazo copy documents of a normal contrast may be transmitted.
•Carbon copy
A carbon copy may be transmitted if its contrast is normal.
4. Cautions on Transmitting Documents
•Documents written in yellow, greenish yellow, or light blue ink
cannot be transmitted.
•Ink, glue, and correcting fluid on documents must be dry before the
documents can be transmitted.
•All clips, staples and pins must be removed from documents be-
fore transmission.
•Patched (taped) documents should be copied first on a copier and
then the copies used for transmission.
•All documents should be fanned before insertion into the feeder to
prevent possible double feeds.
5. Automatic Document Feeder Capacity
Number of pages that can be placed into the feeder at anytime is as
follows:
Normal size: max. ADF 20 sheets
Special size: single sheet only (manual feed)
NOTES: •When you need to send or copy more pages than the
feeder limit, place additional pages in feeder when last
page in feeder is being scanned.
•Place additional pages carefully and gently in feeder.
If force is used, double-feeding or a document jam may
result.
6. Readable Width & Length
The readable width and length of a document are slightly smaller than
the actual document size.
Note that characters or graphics outside the effective document scan-
ning range will not be read.
•Readable width
210 mm, max.
•Readable length
This is the length of the document sent minus 4 mm from the top and
bottom edges.
(Min.)
(Max.)
A4 size
(Max.)
128mm 297mm
1000mm
148mm 216mm
[Normal size] 216mm [Special size]
Use document carrier sheet for smaller documents.
4mm
4mm
Readable length
Readable width
UX-177H
1 – 3

7. Use of Document Carrier Sheet
A document carrier sheet must be used for the following documents.
•Those with tears.
•Those smaller than size 148 mm (W) x 128 mm (L).
•Carbon-backed documents
NOTE: To transmit a carbon-backed document, insert a white sheet
of paper between the carbon back of the document and the
document carrier.
•Those containing an easily separable writing substance (e.g., trac-
ing paper written on with a soft, heavy lead pencil).
NOTES: •When using the document carrier, carefully read the in-
structions written on the back.
•If the document carrier is dirty, clean it with a soft, moist
cloth, and then dry it before using for transmission.
•Do not place more than one document in the carrier at a
time.
[4] Installation
1. Site selection
Take the following points into consideration when selecting a site for
this model.
ENVIRONMENT
•The machine must be installed on a level surface.
•Keep the machine away from air conditioners, heaters, direct sun-
light, and dust.
•Provide easy access to the front, back, and sides of the machine.
In particular, keep the area in front of the machine clear, or the
original document may jam as it comes out after scanning.
•The temperature should be between 5°and 35°C.
•The humidity should be between 30% and 85% (without conden-
sation).
ELECTRICITY
230V, 50Hz, grounded (3-prong) AC outlet is required.
Caution!
•Connection to a power source other than that specified will cause
damage to the equipment and is not covered under the warranty.
•If your area experiences a high incidence of lightning or power
surges, we recommend that you install a surge protector for the
power and telephone lines. Surge protectors can be purchased at
most telephone specialty stores.
If the machine is moved from a cold to a warm place...
If the machine is moved from a cold to a warm place, it is possible
that the reading glass may fog up, preventing proper scanning of
documents for transmission. To remove the fog, turn on the power
and wait approximately 2 hours before using the machine.
TELEPHONE JACK
A standard RJ-11C telephone jack must be located near the machine.
This is the telephone jack commonly used in most homes and offices.
•Plugging the fax machine into a jack which is not an RJ-11C jack
may result in damage to the machine or your telephone system. If
you do not know what kind of jack you have, or needed to have
one installed, contact the telephone company.
2. Assembly and connections
1 Connect the handset cord to the handset and the fax as shown.
•The ends of the handset cord are identical, so they will go into
either socket.
Place the handset on the handset rest.
2 Insert one end of the line cord into the socket on the back of the
machine marked TEL. LINE. Insert the other end into a wall tele-
phone socket.
•Be sure to plug the line cord into the TEL. LINE socket. Do
not plug it into the TEL. SET socket. (Note: The TEL. SET
socket is not available in some countries.)
Direction of insertion
Make print straight
across paper
E.G.
Place the document
carrier in the document
feeder with the clear film
side down
TEL.
SET TEL.
LINE
UX-177H
1 – 4

3 Plug the power cord into a 230V, 50Hz, grounded (3-prong) AC
outlet.
•Caution: The mains outlet (socket-outlet) shall be installed
near the equipment and shall be easily accessible.
•The fax does not have a power on/off switch, so the power is
turned on and off by simply plugging in or unplugging the power
cord.
4 Attach the received document support by inserting the ends into
the holes in the fax as shown below.
4. Loading the recording paper
1 Grasp the finger hold on the right side of the paper compartment
cover, and pull up to open the cover.
Remove the packing paper from the paper compartment.
•Caution! If you are replacing the paper, do not touch the metal
strip in the compartment. It may be hot if a document has just
been printed.
2 Unwrap the roll of fax paper and insert it in the compartment.
•Make sure the hubs on each side of the compartment fit into
the ends of the roll. The hub on the left side is mounted on a
spring to allow for insertion.
•Important: The roll must be placed so that the leading edge of
the paper feeds from over the top of the roll. (The paper is only
coated on one side for printing. If the roll is placed upside
down, the paper will come out blank after printing.)
Note: The paper roll provided is only a sample roll which is ap-
proximately 50 m long.
THERMAL PAPER: FO-40PRw
3 Pass the leading edge of the paper over the roller and through the
outlet in the paper compartment cover. Remove any slack.
4 Close the cover and then press the START key. A short length of
the fax paper will feed out. Grasp the paper by the edge and pull
upward to tear it off.
YES NO
START
UX-177H
1 – 5

FUNCTION key menu The following chart shows the layout of the functions and settings accessed by pressing the FUNCTION key. First press the FUNCTION key, the appropriate numeric key as shown, and then "#" or " " until the desired item appears. Instructions for making each setting appear in the display. If you have any difficulty, refer to the detailed instructions on the page shown below the setting.
[5] Quick reference guide Use this guide as a convenient reminder for operating the machine after you have read the detailed instructions for each procedure in the manual. Note:
•Steps which are optional are enclosed in a dotted frame:
1 – 6
UX-177H
Load document
START
RESOLUTION Lift handset
or press SPEAKER
Dial (press numeric keys)
START
Wait for reception tone Hang up
Load document RESOLUTION Load document RESOLUTION Load document RESOLUTION Load document RESOLUTION
START
START
Dial (press numeric keys)
SPEED DIAL
REDIAL
Press Rapid key
Wait for reception tone Enter Speed Dial number (press 2 numeric keys)
Normal Dialing Direct Keypad Dialing Rapid Key Dialing Speed Dialing Redialing
Transmitting documents
Normal Dialing Rapid Key Dialling Speed Dialing Redialing
Making voice calls
Lift handset or press SPEAKER
Dial (press numeric keys) Press Rapid key
Lift handset or press SPEAKER Lift handset or press SPEAKER
SPEED DIAL
REDIAL
Lift handset
Lift handset if you pressed SPEAKER Lift handset if you pressed SPEAKER
Lift handset if you press SPEAKER
Enter Speed Dial number (press 2 numeric keys)
Printing out lists Entering your name and FAX number Setting the date and time Storing Numbers For Automatic Dialing Setting User Switches
2
FUNCTION
or
3
FUNCTION
3
FUNCTION
3
FUNCTION FUNCTION
or
or
1 2
4
(Press until desired item appears) (Press until desired item appears)
ABC
SPACE DEF
GHI JKL MNO
PQRS TUV WXYZ
SYMBOLS
SPEED DIAL
REDIAL
DELETE
SHIFT
SEARCH/R
SPEAKER
123
456
789
0
Space Delete
Press this key to delete the letter highlighted by the cursor (if the cursor is to the right of the last letter entered, it will backspace and delete the last letter). Shift Press this key once to change case (press it again to change back).
Cursor left
Press this key to move the cursor to the left .
Cursor right
Press this key to move the cursor to the right .
Symbols Press either key repeatebly untill the desired symbol appears (see the symbol list below) .
Press this key twice to entera space.
To enter a letter or number, press the appropriate key repeatedly until the desired number/letter appears in the display (the number appears first, then the letters in the order shown abovethe key).
Letters and numbers

CHAPTER 2. ADJUSTMENTS
[1] Adjustments
General
Since the following adjustments and settings are provided for this
model, make adjustments and/or setup as necessary.
1. Adjustments
Adjustments of output voltage (FACTORY ONLY)
1. Install the power supply unit in the machine.
2. Set the recording paper and document.
3. When the document is loaded, power is supplied to the output
lines. Confirm that outputs are within the limits below.
Output voltage settings
Output Voltage limits
+5V 4.75V ∼5.25V
+24V 23.3V ∼24.7V
2. IC protectors
replacement
ICPs (IC Protectors) are installed to protect the motor driver circuit
and the plunger drive circuit. ICPs protect various ICs and electronic
circuits from an overcurrent condition.
The location of ICPs are shown below:
(1) FU1 (ICP-N20) is installed in order to protect IC’s from an over-
current generated in the motor drive circuit. If FU1 is open, replace
it with a new one.
3. Settings
(1) Dial mode selector
DIAL mode (Soft Switch No. SWB4 DATA No. 3)
POWER
SUPPLY
MJI MJ2
CNSP
CNLIUA
CNLIUB CNLIUB
CNLIUA
CNTH CNPN
CNPW CNMT
CNLED
CNCSW
CONTROLTEL/LIU
CNCCD
(step 1) Select "OPTION SETTING".
KEY : FUNCTION 4
DISPLAY: OPTION SETTING PRESS OR #
(step 2) Select "DIAL MODE".
KEY:
DISPLAY: DIAL MODE 1=TONE, 2=PULSE
(step 3) Select, using "1" or "2".
KEY: 1
DISPLAY: TONE SELECTED
KEY: 2
DISPLAY: PULSE SELECTED
(step 4) End, using the "STOP" key.
KEY:
Cursor
When initially registering,
the mode shows 1=TONE.
When registering again, the
mode which was registered
formerly is shown.
STOP
#### # # #
Connector
No. CNPW
Pin No.
1DG
2DG
3 +5V
4 VTH-ON
5MG
6MG
7 +24V
8 VTH
9 VTH
CNPS
CNLIUB
CNLIUA
CNTH
CNPW
CNPN
CNCCD
FU1
CNMT
CNCSW CNLEDCNCUT
UX-177H
2 – 1

[2] Diagnostics and service soft switch
2. Diagnostic items
ITEM
No. RAPID key Contents Function
1 01 Soft switch setting mode Display soft SW contents, and changes the setting.
2 02 ROM &RAM check mode Checks program ROM (128KByte) and work RAM (32KByte).
3 03 Aging mode Prints the check pattern at the speed of 1 sheet/5 minutes.
4 04 Panel check mode Displays the name of key depressed on the operation panel.
5 05 Check pattern mode Prints 2 sheets of check pattern.
6 06 Signal send mode Sends modem signals sequentially.
7 07 Memory clear mode Clears the backup memory contents to reset it to the initial state.
8 08 CCD adjust mode Used for CCD adjustment. Executes copy operation. When the STOP key is pressed, the unit goes
into the wait state. When the START key is pressed again, the unit starts operation again.
9 09 All black copy Performs all-dot printing (2m). (Check thermal head operation)
10 10 Auto feeder mode Feeds the original documents.
1. Operating procedure
(1) Entering the diagnostic mode
Press FUNC →9 →→8 →# →7 , and the following display will appear.
FVL0 After 2 sec: DIAG MODE
FVL0 Identical
Then press the START key. Select the desired item with the key or the # key or select with the rapid key. Enter the mode with the START
key.
(Diag•specifications)
FUNC DIAG MODE 9 8 7
START 01Soft switch setting mode
START 02ROM & RAM check mode
START 03Aging mode
START 04Panel check mode
START 05Check pattern mode
START 06Signal send mode
START 07Memory clear mode CCD adjust mode
All black copy
START
10 Auto feeder mode
START
09
START
START08
START
KEY
STOP
KEY +
+"Power ON"
Memory clear
(Work + Backup)
"Power ON" keep the STOP key pressed
while "WAIT A ...." is indicated.
Press the START key when "MEMORY CLEAR?" appears.
FVL0
If the dial mode cannot be set, repeat the dial mode operation, per-
forming the following operation.
After the power is turned on and "WAIT A MOMENT" is indicated,
press the STOP key.
UX-177H
2 – 2

3. Diagnostic items description
3. 1. Soft switch setting mode
Used to change the soft switch settings.
The soft switch which is stored internally is set by using the keys.
The available soft switches are SW-A1 to SW-K1.
The content of soft switches is shown in page 2-5 to 2-13.
The contents are set to factory default settings.
3. 2. ROM & RAM check mode
ROM executes the sum check, and RAM executes the matching test.
The result will be notified with the number of short sounds of the
buzzer as well as by printing the ROM & RAM check list.
Number of short sounds of buzzer 0 →No error
1 →ROM error
2 →RAM error (32Kbyte)
3. 3. Aging mode
If any document is first present, copying will be executed sheet by
sheet. If no document is present, the check pattern will be printed
sheet by sheet. This operation will be executed at a rate of one sheet
per 5 minutes, and will be ended at a total of 10 sheets.
3. 4. Panel check mode
In this mode, whether each key operates properly or not is checked.
Press a key on the operation panel, and the corresponding key will be
displayed. In this mode, press the STOP key, and the list of the keys
pressed in this mode will be printed with the mode ended.
Whether all keys are pressed in this mode or not will be judged when
the list is printed, and the result will be printed.
3. 5. Check pattern mode
This mode is used to check the status of print head. Two sheets of
check pattern are printed. The following information of check pattern
is printed.
1 Vertical stripes (alternate white and black lines)Approx.35mm
2 Full black Approx. 70 mm
3 Full white Approx. 35 mm
3. 6. Signal send mode
This mode is used to send various signals to the line.
FAX signals are sent in the level set by the soft switch.
[1] No signal (CML signal turned on)
[2] 9600bps
[3] 7200bps
[4] 4800bps
[5] 2400bps
[6] 300bps (FLAG)
[7] 2100Hz (CED)
[8] 1100Hz (CNG)
[9] END
The signal can be checked by plugging the handset into the TEL line
connector on the rear of the machine.
3. 7. Memory clear mode
This mode is used to clear the backup memory and reset to the
default settings.
3. 8. CCD adjust mode
This mode is used to adjust the optical system. Since the copy is
function performed, set the original. To abort the copy operation,
press the STOP key. To restart press the START key. When the copy
is completed or when the STOP key is pressed in the interruption
state, exit from this mode occurs.
3. 9. All back copy
This mode is used to check the print head.
All-dot print is executed unconditionally until 2(m) is obtained except
when any trouble occurs (recording paper has run out, recording
paper jam, thermal protect).
3. 10. Auto feeder mode
In this mode, a document is inserted and discharged to check the
auto feed function.
After this mode is started, set a document, and the document feed
will be automatically tested.
1
2
3
UX-177H
2 – 3

4. How to make soft switch setting
To enter the soft switch mode, make the following key entries in
sequence.
Press FUNCTION 9 8 7 STARTSTART
Press FUNCTION key.
Press key.
Press key.
Bit1 - 8 are set.
Soft SW-A2 - SW-L2 are set.
S F T SW-A1 = 1 0 0 0 0 0 0 0
S F T SW-A1 = 1 0 0 0 0 0 0 0
S F T SW-A1 = 1 0 0 0 0 0 0 0
S F T SW-A1 = 1 0 0 0 0 0 0 0
S F T SW-A2 = 0 0 0 0 0 0 0 0
S F T SW-L2 = 0 0 0 0 0 0 0 0
Press key during setting.
To finish the settings halfway between
SW-A1 and SW-L2, press the STOP
key. In this case, the setting being done
to the SW No. on display will be nullified
while settings done to the preceding
SW Nos. remain in effect.
The soft switch mode is terminated.
S F T SW-A1 = 0 0 0 0 0 0 0 0
START
DATA No. 1 2 3 4 5 6 7 8
When the COPY key is pressed, the
contents of soft switches are printed.
UX-177H
2 – 4

5.Soft switch description
•Soft switch
SW
NO. DATA NO. ITEM Switch Setting and Function Initial setting Remarks
10
SW
|
A1
1 Protect from echo No Yes 0
2 Forced 4800bps reception Yes No 0
3 Footerprint Yes No 1
4 Length limitationofcopy/send/receive No limit Copy/Send: 1m Receive: 1.5m 0
5 CSI transmission No transmitted Transmitted 0
6 DIS receive acknowledgement during G3
transmission Twice NSF: Once DIS: Twice 0
7 Non modulated carrier for V29
transmissionmode Yes No 1
8 EOL detect timer 25s 13s 0
SW
|
A2
Modem speed 9600BPS 7200BPS 4800BPS 2400BPS
1 No. 1 0 0 0 0 0
2 No. 2 0 0 0 0 0
3 No. 3 0 1 1 0 0
4 No. 4 1 1 0 0 1
5 Sender’sinformationtransmit No Yes 0
6 H2 mode No Yes 0
7 Communication error treatment in RTN
sendingmode (reception) No communication error Communicationerror 1
8 CNGtransmission No Yes 0
SW
|
A3
1 CED tone signal interval 1000ms 750ms 500ms 75ms
2 No. 1 1 1 0 0 0
No. 2 1 0 1 0 1
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
A4
1 Signal transmission level Binaryinput 16 8 4 2 1 0
2 No.= 12345 1
30 1 0 1 1 (-11dBm) 0
4 1
5 1
6 Protocol monitor (error print) Printed at com. err Not printed 0
7 Protocolmonitor Yes No 0
8 Linemonitor Yes No 0
SW
|
A5
1 Digitalline equalization setting
(Reception) 7.2km 0km
2 No. 1 1 0 1
No. 2 1 0 1
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Error criterion 10 ~ 20% 5 ~ 10% 0
8 Anti junk fax check Yes No 0 OPTION
SW
|
A6
1 Auto gain control (MODEM) Enable Disable 1
2 End Buzzer Yes No 1
3 Disconnect the line when DIS is received
in Rx mode No Yes 1
4 Equalizer freeze control (MODEM) On Off 0
5 Equalizer freeze control 7200 bps only No Yes 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
UX-177H
2 – 5

SW
NO. DATA NO. ITEM Switch Setting and Function Initial
setting Remarks
10
SW
|
B1
1 Recall interval Binaryinput 8 4 2 1 0
2 No.=12341
30101 0
4(5 x 60 sec = 5 min) 1 OPTION
5 Recall times Binaryinput 8 4 2 1 0
6 No.=56780
70 0 1 0 (Twice) 1
8 0 OPTION
SW
|
B2
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
B3
1 PBX recall function (R key select) No Ope. No Ope. Earth Flash
2 No. 1 0 0 1 1 1
No. 2 0 1 0 1 1 OPTION
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Mercury line Yes No 1 OPTION
7 Reserved 0
8 Reserved 0
SW
|
B4
1 Reserved 0
2 Reserved 0
3 Dial mode Tone Pulse 1 OPTION
4 Pulse →Tone change function by key Enable Disable 1
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
B5
1 DTMF signal transmission level (Low) Binary input 16 8 4 2 1 1
2 No.= 12345 0
310100(0.5 x 20 = -10 dBm) 1
4 0
5 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
B6
1 DTMF signal transmission level (High) Binaryinput 16 8 4 2 1 1
2 No.= 12345 0
3 10010(0.5 x 18 = -9 dBm) 0
4 1
5 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
UX-177H
2 – 6

SW
NO. DATA NO. ITEM Switch Setting and Function Initial
setting Remarks
10
SW
|
C1
1 Readingslice (Binary) Factory
setting Light Dark Daker in
Dark mode
2 No. 1 0 1 0 1 0
No. 2 0 0 1 1 0
3 Reading slice (Half tone) Factory
setting Light Dark Daker in
Dark mode
4 No. 3 0 1 0 1 0
No. 4 0 0 1 1 0
5 Line density selection Fine Standard 0 OPTION
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
D1
1 Number of rings for auto receive Binary input 8 4 2 1 0
2 No.= 1234 1
30 0 0 1 (4 times) 0
4 0 OPTION
5 Automatic switching manual to auto
receivemode Reception after 5 rings Noreception 0
6 Reserved 0
7 Reserved 0
8 Ci detect frequency 20Hz or more as is PTT 0
SW
|
D2
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
E1
1 Automatic switching mode Tel/Fax auto switch Switch to fax 1
2 Pseudo ringing time at the phone/fax
automatic switching mode 15s 30s 60s 120s
3 No. 2 0 1 0 1 0
No. 3 0 0 1 1 0 OPTION
4 Number of CNG signal detection at the
phone/fax automatic switching mode Twice Once 0
5 CNG detect time at TEL/FAX mode 3s 5s 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
E2
1 Pseudo ringer sound output level to the
line Binaryinput 8 4 2 1 0
2 No.= 1234 1
30 1 0 1 -5dBm -5 = -10dBm 0
4(-5 ~ -20dBm setting) 1
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
F1
1 DTMF detection time 50ms 80ms 100ms 120ms
2 No. 1 0 0 1 1 0
No. 2 0 1 0 1 0
3Protection of remote reception (5 )
detect Yes No 0 OPTION
4 Remote reception with GE telephone Compatible Notcompatible 1
5 Remote operation code figures by
external tel (0 ~ 9) Binaryinput 8 4 2 1 0
6 No.= 5678 1
70101(5 ) 0
81 OPTION
UX-177H
2 – 7

SW
NO. DATA NO. ITEM Switch Setting and Function Initial
setting Remarks
10
SW
|
F2
1 CNG detection in STAND-BY mode Yes No 1 OPTION
2 Number of CNG detect (AM mode) 1pulse 2pulses 3pulses 4pulses
3 No. 2 0 0 1 1 0
No. 3 0 1 0 1 0
4 Number of CNG detect (STAND-BY
mode) 1pulse 2pulses 3pulses 4pulses
5 No. 4 0 0 1 1 0
No. 5 0 1 0 1 1
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
G1
1 Quiet detect time Binary input 8 4 2 1 0
2 No.= 1234 1
30 1 0 0 (4 sec) 0
4 0 OPTION
5 Quiet detect start timing Binary input 8 4 2 1 0
6 No.=56780
70 0 0 0 (Not wark) 0
8 0 OPTION
SW
|
G2
1 Off hook hold Binary input 128 64 32 16 8 4 2 1 0
2 No. = 1 2 3 4 5 6 7 8 0
3 0 0 0 0 0 0 0 0 0
4(0sec = No limit) 0
5 0
6 0
7 0
8 0 OPTION
SW
|
G3
1 OGM detect timer Not Work 100ms 200ms 300ms
2 No. 1 0 0 1 1 0
No. 2 0 1 0 1 1 Only for Irish
3 Reserved 0
4 Reserved 0
5 Section time of quiet detection 30s 40s 50S 60s
6 No. 5 0 0 1 1 0
No. 6 0 1 0 1 1
7 Reserved 0
8 Reserved 0
SW
|
H1
1 Busy tone detection ON/OFF time
(Lowerduration) 350ms 200ms 0
2 Busy tone detection ON/OFF time
(Upperduration) 650ms 900ms 0
3 Reserved 0
4 Busy tone continuous sound detect time 5s 10s 1
5 Reserved 0
6 Busy tone detect continuation sound
detect No Yes 0
7 Reserved 0
8 Busy tone detect intermittent sound
detect No Yes 0
SW
|
H2
1 Busy tone detection pulse number 2pulses 4pulses 6pulses 10pulses
2 No. 1 0 0 1 1 0
No. 2 0 1 0 1 1
3 Fax switching when A.M. full Yes No 0 OPTION
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
UX-177H
2 – 8

SW
NO. DATA NO. ITEM Switch Setting and Function Initial
setting Remarks
10
SW
|
I1
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 CPC signal detection Yes No 1
SW
|
I2
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 CPC detection time 70ms 40ms 20ms 4ms
7 No. 5 0 0 1 1 0
No. 6 0 1 0 1 1
8 Reserved 0
SW
|
I3
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
I4
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
I5
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
I6
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
I7
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
UX-177H
2 – 9

SW
NO. DATA NO. ITEM Switch Setting and Function Initial
setting Remarks
10
SW
|
J1
1 Reserved 0
2 Reserved 0
3 Sender’s phone number setting Cannot change Change allowed 0
4 Countrysetting Irish UK 0
5 Reserved 0
6 Summer time setting No Yes 1
7 Ringervolume Off Low Middle High
8 No. 7 0 0 1 1 1
No. 8 0 1 0 1 0 OPTION
SW
|
J2
1 Reserved 0
2 Reserved 0
3 Pollingkey Yes No 0 OPTION
4 Reserved 0
5 Reserved 0
6 Speakervolume No. 6 No. 7 No. 8
7 VERY LOW 0 0 0
8 LOW 0 0 1
MIDDLE 0 1 0 0
HIGH 0 1 1 1
VERY HIGH 1 0 0 0 OPTION
SW
|
J3
1 Reserved 0
2 Reserved 0
3 Communicationresults printout
(Transactionreport) Error/Timer Send only Always No print OPTION
4 No. 3 0 0 1 1 0
No. 4 0 1 0 1 1
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
K1
1 Entering DIAG mode by pressing
SPEED key Yes No 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
L1
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
L2
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
UX-177H
2 – 10

•Soft switch function description
SW-A1 No. 1 Protection from echo
Used to protect from echo in reception.
SW-A1 No. 2 Forced 4800 bps reception
When line conditions warrant that receptions take place at 4800 bps
repeatedly.
It may improve the success of receptions by setting at 4800 bps.
This improve the receiving document quality and reduces handshake
time due to fallback during training.
SW-A1 No. 3 Footer print
When set to "1", the date of reception, the sender machine No., and
the page No. are automatically recorded at the end of reception.
SW-A1 No. 4 Maximum copy, transmit, receive page length
Used to set the maximum page length.
To avoid possible paper jam, the page length is normally limited to 1
meter for copy or transmit, and 1.5 meters for receive.
It is possible to set it to "No limit" to transmit a long document, such
as a computer print form, etc. (In this case, the receiver must also be
set to no limit.)
SW-A1 No. 5 CSI transmission
(CSI TRANSMISSION) is a switch to set whether the machine sends
or does not send the signal (CSI signal) informing its own telephone
No. to the remote fax, machine when information is received. When
"nonsending" is set, the telephone No. is not output on the remote
transmitting machine if the remote transmitting machine has the func-
tion to display or print the telephone No. of receiving machine, using
this CSI signal.
SW-A1 No. 6 DIS receive acknowledgment during G3 transmis-
sion
Used to make a choice of whether reception of DIS (NSF) is acknowl-
edged after receiving two DISs (NSFs) or receiving one DIS (two
NSFs).
It may be useful for overseas communication to avoid an echo sup-
pression problem, if set to 1.
SW-A1 No. 7 Non-modulated carrier detection for V29 modem
Though transmission of a non-modulated carrier is not required for
transmission by the V29 modem according to the CCITT Recommen-
dation, it may be permitted to a send non-modulated carrier before
the image signal to avoid and echo suppression problem.
It may be useful for overseas communication to avoid an echo sup-
pression problem, if set to 1.
SW-A1 No. 8 EOL (End Of Line) detect timer
Used to make a choice of whether to use the 25-second or 13-second
timer for detection of EOL.
This is effective to override communication failures with some facsim-
ile models that have longer EOL detection.
SW-A2 No. 1 ~ No. 4 Modem speed
Used to set determine the initial modem speed. The default is 9600
bps.
It may be necessary to program it to a slower speed when frequent
line fallback is encountered, in order to save the time required for
fallback procedure.
SW-A2 No. 5 Sender’s information transmit
(SENDER’S INFORMATION TRANSMISSION) is a switch to set the
function to print the content of HEADER PRINT described in the
passcode list at the front end of receiver’s original when original is
sent to the remote machine.
If this switch is set to "NO", the HEADER PRINT is not output at the
receiving machine.
SW-A2 No. 6 H2 mode (SHARP special mode)
Used to determine reception of H2 mode (15 sec transmission mode).
When set to OFF, H2 mode reception is inhibited even though the
transmitting machine has H2 mode function.
SW-A2 No. 7 Communication error treatment (reception) in RTN
sending
Used to determine communication error treatment when RTN is sent
by occurrence of a received image error in G3 reception. When it is
set to "1", communication error is judged as no error.
SW-A2 No. 8 CNG transmission
When set to "0", this model allows CNG transmission by pressing the
Start key in the key pad dialing mode. When set to "1", CNG trans-
mission in the key pad dialing mode cannot be performed. In either
case, CNG transmission can be performed in the auto dial mode.
SW-A3 No. 1, No. 2 CED tone-signal interval
For international communication, the 2100Hz CED tone may act as
an echo suppression switch, causing a communication problem.
Though SW-A3 No. 1 and No. 2 are normally set to 0, it should be
changed this timer between the CED tone signal to eliminate the
communication problem caused by echo.
SW-A3 No. 3 ~ No. 8 Reserved
Set to "0".
SW-A4 No. 1 ~ No. 5 Signal transmission level
Used to control the signal transmission level in the range of-0dB to
-31dB.
The factory setting is at -8dB (MODEM output).
SW-A4 No. 6 Protocol monitor (Error print)
If set to "1", protocol is printed at communication error.
SW-A4 No. 7 Protocol monitor
Normally set to "0". If set to "1", communication can be checked, in
case of troubles, without using a G3 tester or other tools.
When communication FSK data transmission or reception is made,
the data is taken into the buffer. When communication is finished, the
data analyzed and printed out. When data is received with the line
monitor (SW4-No. 8) set to "1" the reception level is also printed out.
SW-A4 No. 8 Line monitor
Normally set to "0". If set to "1", the transmission speed and the
reception level are displayed on the LCD. Used for line tests.
SW-A5 No. 1, No. 2 Digital equalization setting (Reception)
Line equalization when reception is to be set according to the line
characteristics.
Setting should be made according to distance between the telephone
and the telephone company central switching station.
SW-A5 No. 3 ~ No. 6 Reserved
Set to "0".
SW-A5 No. 7 Error criterion
Used to select error criterion for sending back RTN when receiving
image data.
SW-A5 No. 8 Anti junk fax check
When use the Anti junk fax function, set to "1".
SW-A6 No. 1 Auto gain control (MODEM)
When this mode is enabled, If the reception signal level is under
31dBm. The modem itself controls the signal gain automatically.
TX RX
CED
DIS
T
UX-177H
2 – 11

SW-A6 No. 2 End buzzer
Setting this bit to 0 will disable the end buzzer (including the error
buzzer/on-hook buzzer).
SW-A6 No. 3 Disconnect the line when DIS is received in RX
mode
Bit1= 0: When DIS signal is received during RX mode, disconnect the
line immediately.
Bit1= 1: When DIS signal is received during RX mode, wait the next
signal.
SW-A6 No. 4 Equalization freeze control
This switch is used to perform reception operation by fixing the equal-
izer control of modem for the line which is always in unfavorable state
and picture cannot be received.
* Usually, the control is executed according to the state of line where
the equalizer setting is changed always.
SW-A6 No. 5 Equalization freeze 7200 bps only
Setting which specifies SW-A3 No. 6 control only in condition of 7200
bps modem speed.
SW-A6 No. 6 ~ No. 8 Reserved
Set to "0".
SW-B1 No. 1 ~ No. 4 Recall interval
Choice is made for a redial interval for speed and rapid dial calls.
Used a binary number to program this. If set to "0" accidentally, 1 will
be assumed.
SW-B1 No. 5 ~ No. 8 Recall times
Choice is made as to how many redials should be.
SW-B2 No. 1 ~ No. 8 Reserved
Set to "0".
SW-B3 No. 1, No. 2 PBX recall function (R key select)
Used to set the operation mode of PBX recall when the R key is
pressed.
Setting is mode according to the type of PBX.
No. 1 = 1, No. 2 = 1: Time break recall (=Flash) is performed.
The DPON on the LIU board is driven to initiate
recall.
No. 1 = 1, No. 2 = 0: Earth recall is performed.
The E-relay on the LIU board is driven to initiate
recall.
SW-B3 No. 3 ~ No. 5 Reserved
Set to "0".
SW-B3 No. 6 Mercury line
0: No
1: Yes
Default: 0
SW-B3 No. 7 ~ No. 8 Reserved
Set to "0".
SW-B4 No. 1, No. 2 Reserved
Set to "0".
SW-B4 No. 3 Dial mode
When using the pulse dial, set to "0". When using the tone dial, set to
"1".
SW-B4 No. 4 key Pulse dial →Tone dial
When setting to 1, the mode is changed by pressing the key from
the pulse dial mode to the tone dial mode.
SW-B4 No. 5 ~ No. 8 Reserved
Set to "0".
SW-B5 No. 1 ~ No. 5 DTMF signal transmission level of lower
frequency
The transmission level of DTMF signal is adjusted. (lower frequency)
00000: 0 dBm
↓
11111: -15.5 dBm (-0.5 dBm x 31)
SW-B5 No. 6 ~ No. 8 Reserved
Set to "0".
SW-B6 No. 1 ~ No. 5 DTMF signal transmission level of higher
frequency
The transmission level of DTMF signal is adjusted. (higher frequency)
00000: 0 dBm
↓
11111: -15.5 dBm (-0.5 dBm x 31)
SW-B6 No. 6 ~ No. 8 Reserved
Set to "0".
SW-C1 No. 1, No. 2 Reading slice (binary)
Used to determine the set value of reading density in standard/fine
mode. The standard setting is "00" (Factory setting is "00")
SW-C1 No. 3, No. 4 Reading slice (half tone)
Used to determine the set value of reading density in half tone mode.
The standard setting is "00" (Factory setting is "00")
SW-C1 No. 5 Line density selection
Used to set the transmission mode which is automatically selected
when the Resolution key is not pressed. In the copy mode, however,
the fine mode is automatically selected unless the Resolution key is
manually set to another mode.
SW-C1 No. 6 ~ No. 8 Reserved
Set to "0".
SW-D1 No. 1 ~ No. 4 Number of rings for auto answer mode
When the machine is set in the auto receive mode, the number of
rings before answering can be selected. It may be set from one to
four rings using a binary number. Since the facsimile telephone could
be used as an ordinary telephone if the handset is taken off the hook,
it should be programmed to the user’s choice. If the soft switch was
set to "1", direct connection is made to the facsimile.
If a facsimile calling beep was heard when the handset is taken off
the hook, press the START key and put the handset on the hook to
have the facsimile start receiving. If it was set to "0" accidentally,
receive ring is set to "1".
NOTE:If the machine is set to answer after a large number of rings, it
may not be able to receive faxes successfully.
If you have difficulty receiving faxes. reduce the number of
rings to a maximum of 6.
SW-D1 No. 5 Automatic switching from manual to auto receive
mode
This soft switch is used to select whether the machine should switch
to the auto receive mode after 5 rings in the manual receive mode or
remain in the same way as SW-D1 No. 1, No. 2, No. 3 and No. 4
"0"1"0"1" (5 rings (UK)) (3 rings (IR)).
SW-D1 No. 6, No. 7 Reserved
Set to "0".
SW-D1 No. 8 Ci detect frequency
Ring signal for auto reception is set.
When this switch is set to "0", PTT standards are set.
SW-D2 No. 1 ~ No. 8 Reserved
Set to "0".
UX-177H
2 – 12
