1. STANDBY - Switch on the TV when in standby or vice versa.
2. SOURCE - To display the input/source menu.
3. NUMBER BUTTONS - 0-9 to select a TV channel directly.
4. MUTE - Mute the sound or vice versa.
5. GUIDE - Opens the 7 day TV guide (Digital TV mode).
6. MENU - Displays LIVE TV menu.
7. Google Assistant - Use your voice to access entertainment, control
smart devices, obtain answers on screen, and more.
8. INFO - Press once for programme information.
Press again to view detailed information
9. - Allows you to navigate the on-screen menus
and adjust settings to your preference.
10. BACK - Step back in the menu.
11. HOME - Displays the TVs Home Menu
12. EXIT - Exits all menus.
13. VOL (+/-) - Tilt to increase/decrease the sound level.
14. CH (+/-) - Tilt to switch to the next/previous channel in the
sequence.
15. NETFLIX - Access the YouTube App.
16. PRIME VIDEO - Access the Prime Video App.
17. YOUTUBE - Access the YouTube App.
18. FREEVIEW PLAY - Access the Freeview Play service. Only
availble in the UK.
19. AUDIO - Opens the audio track menu.
20. SUB - Turns on/o subtitles at the bottom of the screen.
21. TEXT - turns teletext on/o.
22. TV - Switches the TV to the last watched input.
23. - Play/Pause media.
24. - Play in fast rewind mode.
25. - Play in fast forward mode.
26. - Stop playback.
27. COLOUR BUTTONS - Execute corresponding function at
that time.
Using the remote control
What is included in the box
Online Manual
To launch the online manual, press the HOME button, select Apps from the Home menu, and select “E-instruction Manual”
from the apps list.
Accessories
Included with this TV are the following accessories
1 x Quick Start Guide 1 x Remote Control and 2 x AAA Batteries
1 x Stand installation pack1 x Safety Leaet
Microsoft PlayReady™
This product contains technology subject to certain intellectual property rights of Microsoft. Use or distribution of
this technology outside of this product is prohibited without the appropriate license(s) from Microsoft.
Content owners use Microsoft PlayReady™ content access technology to protect their intellectual property,
including copyrighted content. This device uses PlayReady technology to access PlayReady-protected content and/
or WMDRM-protected content. If the device fails to properly enforce restrictions on content usage, content owners
may require Microsoft to revoke the device’s ability to consume PlayReady-protected content. Revocation should not
aect unprotected content or content protected by other content access technologies. Content owners may require
you to upgrade PlayReady to access their content. If you decline an upgrade, you will not be able to access content
that requires the upgrade.
Additional Accessories
If you don’t have the RF cable shown below, then you can purchase one from www.umc-uk.co.uk/cables
If you are intending to connect your TV to an RF socket in order to receive Freeview, you will need this cable.
RF Cable
2
3
4 5
7
9
11
12
13 14
15 16
17 18
19 22
20 21
23 26
24 25
27
6 8
10
1
65FN2KA
65FN4KA
65FN6KA
65FN7KA
Quick Start Set Up Guide
For information on using the TV’s features, please refer to the Operating Instructions. (Available online to download.)
Model Numbers
Please save your box/packaging as you will need this in the event of warranty/service repair or support. We are
unable to carry out warranty/service if you are unable to package it correctly. The safest way to package your item
in the event of warranty/service repair is in it’s original box/packaging.
Freeview Play brings together live TV viewing with ‘‘catch up’’ TV services such as BBC iPlayer, ITV X, All 4 and My5. The Freeview
Play Explore app features a carousel of genres to select from when searching for programmes, such as sport, comedy, dramas and
soaps, etc. Content is made up from recommendations of the major broadcasters and oers an alternative means of searching.
Note that to use the full functionality of Freeview Play your set must be connected to the internet.
If you wish to use your Sky remote to operate the TV’s basic functions,
you will need a Sky remote control (Revision 9 or later) and you will need
to program it with the code 2134. If you wish to use your Sky Q remote to
operate the TV’s basic functions, you will need to program it with the code
4170.
Sky Remote Code
Register your manufacturers guarantee online within 14 days
of purchase at www.registertoday.co.uk/sharp and enter into a prize
draw to...
Quick & easy guide for setting up your TV
What is included in the box
Using the remote control
Setting up the TV for the rst time - including attaching the stand
Connecting other devices to the Television
Need help setting up or using your TV?
Please contact the UK & ROI Helpline*
Telephone UK 0330 024 0803 or ROI 01443 3323
Online support at: www.umc-uk.co.uk
Email support at: [email protected]
*Calls to 0330 numbers are charged at standard call rates and are included as
part of any bundled minutes with your phone provider. Hours are correct at time of this
document being published.
Please note these hours are subject to change periodically.
Calls to the ROI number are charged at the local call rate.
The helpline telephone opening hours are:
Monday - Friday: 8.30am – 6pm
For Saturdays and Bank Holidays, please refer to the website for our opening hours.
65FN2KA
65FN4KA
65FN6KA
65FN7KA
Energy Eciency Class (SDR) F
Power consumption (SDR) 100 W
Power Eciency Class (HDR) G
Power Consumption (HDR) 167 W
Screen resolution (pixels) 3840 x 2160
Screen Size (diagonal) 164 cm / 65 inches
RF 75 ohm Antenna • Analog • DVB • Satellite
Inputs 4 x HDMI, 2 x USB, 1x micro SD card reader,
1 x RJ45 LAN/Ethernet,
1x Mini Composite/CVBS + Audio input
Sound Outputs 1 x Digital Optical Audio output • 1 x 3.5mm Headphone
Speaker/ Amplier Watts (RMS) 2 x 10 / 2 x 8
Voltage and power consumption AC 220V ~ 240V; 50/60Hz
100/170/205W (home mode/standard/max)
(<0.5W in Standby)
Dimensions including stand (mm) 1450W x 881H x 273D
Net weight (Kgs) 18.6
Wall Mounting VESA 400 x 300 (mm)
The terms HDMI, HDMI High-Denition
Multimedia Interface, HDMI trade dress
and the HDMI Logos are trademarks
or registered trademarks of HDMI
Licensing Administrator, Inc.
Google, Google Play,
YouTube, Android TV and
other marks are trademarks
of Google LLC.
Manufactured under license
from Dolby Laboratories. Dolby,
Dolby Audio, and the double-D symbol
are trademarks of Dolby Laboratories
Licensing Corporation.
For DTS patents, see http://
patents.dts.com. Manufactured
under license from DTS, Inc.
(for companies headquartered
in the U.S./Japan/Taiwan) or
under license from DTS Licensing
Limited (for all other companies).
DTS, DTS:X, Virtual:X, and the
DTS:X logo are registered
trademarks or trademarks of DTS,
Inc. in the United States and other
countries. © 2021 DTS, Inc. ALL
RIGHTS RESERVED.
SHA/QSW/0294
SHA/QSW/0294

L
R
6 x
2
1
3
1 2
2
1
3
4
5
6
7
2
1
3
3
12
L
R
Terms and conditions apply. Online registration only.
Register your manufacturers
guarantee online within
14 days of purchase at
www.registertoday.co.uk/sharp
and enter into a prize draw to
win a Sharp Soundbar
4 x B
M (4x14)
2 x A
M (4x16)
5 x ST(4x25)
Connectivity
AEthernet/LAN Network connection
SAT IN
I
Satellite input
J
C
K
USB
D
USB 2.0 input x2
HDMI 4
L
HDMI input
E
M
HDMI 1
F
HDMI input (eARC)
TF Card in
N
TransFlash / micro SD Card input
HDMI 2
G
HDMI input
CI Card in Common Interface module
AV IN
H
Audio/Video input
Earphones Earphone output
Service Input Input is used only by
service centres
Digital Audio Digital Optical Audio Output
RF IN RF / TV aerial input
HDMI 3 HDMI input
B
M
I
J
K
L
H
(mini)
N
BCDEFG
A
(mini)
4 First time installation
When the set rst turns on, it will ask you to select your preferred on-screen
display language. This will change the language in which the menus and
associated information is displayed in.
Basic installation steps are shown below. These may vary slightly depending on your model. Due to Android software updates, the look and feel
of the TV start up procedure and subsequent menus can be subject to change.
Android Phone users
During the set-up process, you will be prompted to sign-in
to your Google account using your pre-installed “Google”
app. This set up process will depend upon which model TV
you are setting up. Please ensure you have your account
details to hand.
5 Pairing the remote 6 The Google Assistant
Using the Google Assistant with your voice
Remote controls with the Google Assistant have a Google Assistant dedicated button and a built-in
microphone. To use this feature with the Google Assistant remote control, follow the instructions as
below.
Before using the Google Assistant, you will need to pair the remote. Please follow step 5 of this guide to
pair your remote to enable the Google Assistant.
Press the button. The LED indicator on the remote control will illuminate.
Wait for the on-screen message from the Google Assistant, then speak into the microphone. A good rule
of thumb is to have the microphone positioned about 15-30 centimetres away from your mouth.
By speaking into the microphone, you can search for various content or control your connected smart
home devices. Speech examples may be displayed on the television screen depending on your model.
If during the rst time installation process the remote was not paired or skipped, then follow the process below
to pair your remote with the television.
Turn the set on.
Press the button on the remote control.
The pairing screen will appear on the TV.
Now press and hold the ”Left” and “Home” buttons on the remote simultaneously (highlighted).
The LED indicator on the remote control will start to ash.
Select the detected remote control shown on the screen and press OK.
Once paired the pairing screen will disappear.
This process will only need to be carried out if the remote is not paired. Once paired, when the button is
pressed it will open the Google Assistant screen on the set and activate voice functionality.
Connect the TV to your power socket.
If you wish to use the TV to receive Freeview/Saorview channels, connect the RF input from the TV to
your outdoor Digital TV aerial. If you do not wish to receive Freeview/Saorview, skip this step.
Connect to the internet. Ethernet provides the most stable connection. Insert the batteries supplied into the remote
controls and press the standby button to power
on the TV.
Wall Mounting the TV
Install the wall mounting bracket to the
television as advised by the bracket
manufacturer.
Press to navigate up
Press to conrm a selection
Press to navigate right
Press to navigate left
Press to navigate down
Microphone
+ LED
1 Fitting the stand
2 Connecting your set 3 Powering On the TV
Setting up the TV set for the rst time
Used for attaching the stand
to the TV set (g.2)
The TV panel must be facing downwards.
For the stand installation, there
is one type of screw provided as
shown below.
Note: To complete the stand
installation you will require a
cross head screw driver.
Remote Control:
Installing Batteries
6 x
Switch on the television by pressing the on/
o button on the bottom of the LED light.
LED Light
Place the TV set on a flat and clean surface
with the panel facing downwards to avoid
damage.
Ensure the stand feet match the orientation as
shown above.
