Sharp RSP-ZA007WJN2 User manual

233
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
SPEAKER SYSTEMS
MODEL
RSP-ZA007WJN2
OUTLINE
SPEAKER SET
Speaker System for the PLASMA DISPLAY TV
[Appropriate Model]
This speaker system is for exclusive use with models PZ-43HV2/43HV2E/43HV2U

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
234
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual: electrical components having such features
are identified by "å" in the Replacement Parts Lists.
The use of a substitute replacement part which does not have the
same safety characteristics as the factory recommended replace-
ment parts shown in this service manual may create shock, fire or
other hazards.
"HOWTO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF.NO.
3. PART NO. 4. DESCRIPTION
5. CODE 6. QUANTITY
NOTES
•Parts marked by "NSP" are generally unavailable because they are
not in our Master Spare Parts List.
•The åmark found on some component parts indicates the
importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical
designation.
in USA: Contact your nearest SHARP Parts Distributor.
For location of SHARP Parts Distributor,
Please call Toll-Free; 1-800-BE-SHARP
in CANADA: Contact SHARP Electronics of Canada Limited
Phone [phone].
MARK ★: SPARE PARTS-DELIVERY SECTION
Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
CABINET APRTS LIST
RSP-ZA007WJN2 J Speaker Set (L, R) CS
NSP 1 9GJSNK2590 – Cabinet —
NSP 2 9GJSXB1447 – Baffle Assy —
3 9GJSWN1689 J Network Assy BC
NSP 4 9GJSAN3077 – Model Label —
5 9GJSBA1091 J Flanged Anchor Bolt AL
6 9GJSBN1002 J Serrated Flanged Nut AE
7—
8 9GJSEC1596 J Gasket(∗)AE
9 9GJSEC1587 J Gasket(∗)AE
10 9GJSEC1589 J Gasket(∗)AG
11 9GJSKX1077 J In-Put Terminal AT
NSP 12 9GJSME3291 – Stamped Serial Label —
NSP 9GJSRW1088 – –Serial Label —
NSP 13 9GJSMV2111 – Acoustic Absorbent —
14 9GJSNA1410 J Metal Rinforce AL
15 9GJA142CU6151F J Speaker(Woofer) BC
16 9GJFK26AP0269F J Speaker(Tweeter) BA
17 9GJAPZ30P080FMC J Screw(∗)AD
18 9GJBPZ30P160FZK J Screw(∗)AD
19 9GJBPZ40P080FMC J Screw(∗)AD
20 9GJBPZ40P160FMC J Screw(∗)AD
21 9GJSEC1605 J Gasket(∗)AL
22 9GJSEC1606 J Gasket(∗)AG
23 9GJSEC1607 J Gasket(∗)AL

235
654321
A
B
C
D
E
F
G
H
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
I N
Gray with White Line Gray with White Line
Gray with White Line
Gray Gray
Gray
1.8 µ F
1.0mH
Woofer
Tweeter
CABINET PARTS AND DIMENSIONS
SCHEMATIC DIAGRAM
Network Assy (9GJSWN1689)
(Unit : mm)
(631.4)
108
(108)
20
9
11
10
3
21
13
22
23
16
2
1
15
14
5
418
8
17
19
12
6
103.5
101
White Line
White Line
White Line

Mark Ref. No. Part No. ★Description Code Mark Ref. No. Part No. ★Description Code
236
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
PACKING PARTS LIST
9GJSEA1588 J Spacer Set AW
NSP 9GJSEC1608 –Spacer —
NSP 9GJSHC1785 –Sheet —
9GJSHC1783 J Protection Sheet AL
9GJSHD1051 J Spacer AN
9GJSHG2406 J Packing Case AT
9GJSME3280 J Side Pad Assy AW
9GJSHB1102 J Side Pad1 AL
9GJSHB1103 J Side Pad2 AL
9GJSHB1104 J Side Pad3 AL
NSP 9GJSME3292 –Stamped Serial Label —
NSP 9GJSRW1089 –Serial Number Label —
SUPPLIED ACCESSOPIES
9GJSEA1584 J Speaker Wire Set AS
9GJSDS1131 J Speaker Wire AN
9GJSDS1132 J Speaker Wire AN
NSP 9GJSHL1178 –Polyethylen Bag S1 —
NSP 9GJSEA1582 –Accsessories Assy —
9GJSEA1578 J Bracket Set AZ
9GJSHL1326 Polyethylen Bag S1 AD
9GJSNA1406 J Bracket AU
9GJSEA1579 J Bracket(R) Set AX
9GJSHL1326 Polyethylen Bag S1 AD
9GJSNA1407 J Bracket(R) AW
9GJSEA1580 J Bracket(L) Set AX
9GJSHL1328 J Polyethylen Bag S1 AD
9GJSNA1408 J Bracket(L) AW
NSP 9GJSEA1583 –Screw Set —
9GJCMZ50P120FZ J Screw AD
9GJSBA1160 J Bolt AG
9GJSEX1015 J Hexagon Lench AL
9GJSHL1326 J Polyethylen Bag S1 AD
9GJSHL1327 J Polyethylen Bag S1 AD
Two speaker cablesFour speaker brackets
Four screws for speaker bracket Four screws for speaker bracket
Hexagon wrench
Two speakers
Two spacers for speakers
Accessories

237
PZ-43HV2, PZ-43HV2E
PZ-43HV2U
Spacer
(9GJSHD1051)
Side Pad Assy (9GJSME3280)
Protection Shest S4 (PZ-43HV2E)
(9GJSHC1782)
Protection Shest S5 (PZ-43HV2/43HV5U)
(9GJSHC1783)
Spacer Set (PZ-43HV2/43HV2U)
(9GJSEA1588)
Paking Case
(9GJSHG2406)
Serial No.Label
(9GJSRW1089)
Accsessories Assy
(9GJSEA1582)
Spacer
(9GJSHD1051)
Side Pad Assy
(9GJSME3280)
Spaker Wire Set
(9GJSEA1584)
Speaker Set
PACKING OFTHE SET

PZ-43HV2, PZ-43HV2E
PZ-43HV2U
COPYRIGHT © 2003 BY SHARP CORPORATION
ALL RIGHTS RESERVED.
No part of this publication may be reproduced,
stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without
prior written permission of the publisher.
SHARP CORPORATION
AV Systems Group
Quality & Reliability Control Center
Yaita, Tochigi 329-2193, Japan
TQ1452-S
Mar. 2003 Printed in Japan
SY.KG
Design and Production Information
Design : Japan
Production : Japan
