Sharp HT-SBW110 User manual

HT-SBW110
User manual
2.1 Soundbar Home Theatre System
EN

Trademarks
The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG,. Inc.
The terms HDMI, HDMI High-Denition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.
Dear Customer, thank you for having purchased this SHARP product. We would like to inform you that your warranty rights are in the European warranty
card. You can download them from www.sharpconsumer.eu or contact the retailer where you purchased your device. You can also obtain the copy of
the warranty rights via the electronic or conventional mail by submitting a request to [email protected].uk or calling
[phone] (UK) | [phone] (IE). Calls are charged at your normal telephone call rate.
Keep proof of purchase because it is necessary to apply warranty rights.
The telephone opening hours are:
Monday to Friday 8.30am to 6pm, Saturday 9am – 5pm.
Bank Holidays - 10am to 4pm
Closed Christmas and New Years day

Important safety instructions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Please, read these safety instructions and respect
the following warnings before the appliance is
operated:
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated“dangerous voltage”within the
product’s enclosure that may be of sucient magnitude as to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
In order to prevent re always
keep candles and other open
ames away from this product.
Warning:
• Always follow basic safety precautions when using this applience, espe-
cially when children are present.
• Children should be supervised to ensure that they do not play with the
appliance.
• Do not damage the power cord, or place any heavy objects on it, do not
strech it or bend it. Also do not use extension cables. Damage to the
power cord may result in re or electric shock.
• If the supply cord is damaged, it must be replaced by the manufacturer,
a service agent or similarly qualied person.
• Ensure that the unit is plugged into an AC 220-240V 50Hz power outlet.
Using higher voltage may cause the unit to malfunction or even catch
re.
• If the power plug does not t into your outlet, do not force the plug into
the electrical socket.
• To switch o the unit place it in to standby and unplug it from the mains
power supply.
• Do not disconnect or connect the power cord with wet hands. It may
cause an electric shock.
• Disconnect the power cord if it is not used for a long time.
• Ensure that the mains plug is always easily accessible.
• This product does not contain any parts that are serviceable by the
user. In case of a fault, contact the manufacturer or authorised service
department. Exposing the internal parts inside the device may endanger
your life. The manufacturers guarantee does not extend to faults caused
by repairs carried out by unauthorised third parties.
• Do not use this product immediately after unpacking. Wait until it warms
up to room temperature before using it.
• Ensure this product is used in moderate climates only (not in tropical/
subtropical climates).
• Place product on a at, stable surface that is not subject to vibrations.
• Ensure the product and its parts do not overhang the edge of the
supporting furniture.
• To reduce the risk of fire, electric shock or damage to this product, do
not expose it to direct sunlight, dust, rain and moisture. Never expose it
to dripping or splashing and do not place objects filled with liquids on
or near the product.
• Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
• Do not place the product where the humidity is high and ventilation is
poor.
• Ensure a minimum distance of 5 cm around the apparatus for sucient
ventilation. Do not block any ventilation openings of this and ensure
that they are not covered with items such as newspapers, table-cloths,
curtains, etc.
• NEVER let anyone, especially children, push anything into holes, slots
or any other openings in the unit’s casing as this could result in a fatal
electric shock.
• Storms are dangerous for all electric appliances. If the mains or aerial
wiring is struck by lightning, the appliance might get damaged, even if it
is turned o. You should disconnect all the cables and connectors of the
appliance before a storm.
Maintenance
• Unplug the power cable from the power source before cleaning the
appliance.
• Use a soft and clean rag to clean the outside of the unit. Never clean it
with chemicals or detergent.
Batteries
• Observe the correct polarity when inserting the
batteries.
• Do not expose batteries to high temperatures and
do not place them on locations where the tempera-
ture might increase quickly, e.g. near the re or on
the direct sunshine.
• Do not expose batteries to excessive radiant heat,
do not throw them into the re, do not disassemble
them and do not try to recharge un-rechargeable
batteries. They could leak or explode.
• Never use dierent batteries together or mix new and old ones.
• When the Remote Control is not to be used for a long time (more than a
month), remove the battery from the Remote Control to prevent it from
leaking.
• If the batteries leak, wipe away the leakage inside the battery compart-
ment and replace the batteries with new ones.
• Do not use any batteries other than those specied.
Do not ingest battery, chemical burn hazard
• If the battery is swallowed, it can cause severe internal burns in just
2 hours and lead to death. Keep new and used batteries away from
children. If the battery compartment does not close securely, stop
using the product and keep it away from children. If you think batteries
might have been swallowed or placed inside any part of the body, seek
immediate medical attention.
Disposal of this equipment and Batteries
• Do not dispose of this product or its batteries as unsorted
municipal waste. Return it to a designated collection point
for the recycling of WEEE in accordance with local law. By
doing so, you will help to conserve resources and protect
the environment.
• Most EU countries regulate the disposal of batteries by
law. Contact your retailer or local authorities for more
information.
• The symbol shown to the right appears on electrical equip-
ment and batteries (or their packaging) to remind users
of the disposal requirements. If "Hg" or 'Pb' appears below
the symbol, this means that the battery cantains traces of
mercury (Hg) or lead (Pb), respectively.
• Users are requested to use the locally provided return facilities for used
equipment and batteries.
CE Statement:
• Hereby, UMC Poland Sp. z o.o. declares that this audio device is in com-
pliance with the essential requirements and other relevant provisions of
RED Directive 2014/53/EU. The full text of the EU declaration of conform-
ity is available by following the link
https://www.sharpconsumer.eu/documents-of-conformity/
Cd
•
4

EN
Accessories
• 1x Remote control • 2x Wall Bracket
• 1x User manual • 1x Set of wall-mounting screws
• 1x power cord • 2 x AAA battery
Controls
1
321
1. Remote Control Sensor
2. LED Indicators
•Red indicator: In STANDBY mode.
•Green indicator: In AUX mode.
•Orange indicator: In Optical mode.
•Blue indicator: In Bluetooth mode.
••White indicator: In HDMI ARC mode.
3. Wall bracket screws
4. button
Switch the unit between ON and STANDBY mode.
5. button
Select the play function.
6. button
Select the Bluetooth mode. Press and hold to activate the pairing
function in Bluetooth mode or disconnect the existing paired
Bluetooth device.
7. +/- buttons
Increase/decrease the volume level.
Inputs/Outputs
1. AC~ Socket
Connect power cord.
2. SUBWOOFER OUT Socket
3. OPTICAL Socket
Opticial input jack.
4. SERVICE ONLY Socket
The USB socket is for service only. It is not designed to charge smart-
phones, tablets or similar devices.
5. AUX 1 Socket
Connect to an external audio device.
6. HMDI ARC Socket
Connect to a TV via HDMI cable.
4 5 6 7
1 32 4 5 61
EN

Remote control
1. – Switch the unit between ON and STANDBY mode.
2. – Select the Bluetooth mode.
Press and hold to activate the pairing function in Bluetooth mode or
disconnect the existing paired Bluetooth device.
3. – Select the play function.
4. VOL +/- – Increase/decrease the volume level.
5. / – Skip to previous/next track in Bluetooth mode.
6. – Play/pause/resume playback in Bluetooth mode.
7. – (MUTE) Mute or resume the sound.
8. BASS +/- – Adjust bass level.
9. TRE +/- – Adjust treble level.
10. EQ – Select a preset sound mode.
First time installation
Prepare the Remote Control
The provided Remote Control allows the unit to
be operated from a distance.
• Even if the Remote Control is operated within the eective range of 6m,
remote control operation may be impossible if there are any obstacles
between the unit and the remote control.
• If the Remote Control is operated near other products which generate
infrared rays, or if other remote control devices using infra-red rays are
used near the unit, it may operate incorrectly. Conversely, the other
products may operate incorrectly.
Replace the Remote Control Battery
1. Press and slide the back cover to open the battery compartment of the
remote control.
2. Insert two AAA size batteries (included). Make sure the (+) and (–) ends
of the batteries match the (+) and (–) ends indicated in the battery
compartment.
3. Close the battery compartment cover.
Placement and Mounting
AB
A: Normal Placement (place Soundbar on leveled surface in front of TV)
B: Wall Mounting
Wall Mounting
NOTE:
 Installation must be carried out by qualied personnel only. Incorrect
assembly can result in severe personal injury and property damage (if
you intend to install this product yourself, you must check for installa-
tions such as electrical wiring and plumbing that may be buried inside
the wall). It is the installer’s responsibility to verify that the wall will safely
support the total load of the unit and wall brackets.
 Additional tools (not included) are required for the installation.
 Do not overtighten screws.
 Keep this instruction manual for future reference.
 Use an electronic stud nder to check the wall type before drilling and
mounting.
764mm
12
6

EN
764mm
3
> 32mm
4mm
(5mm)
4
764mm
1. Remove the screws from the main unit.
2. Attach the wall brackets to the main unit with the screws removed from
the main unit.
3. Drill 2 parallel holes (Ø 4mm - 8mm each according to wall type) in the
wall. The distance between the holes should be 764 mm.
 Firmly x 1 dowel into each hole in the wall if necessary.
4. Leave a 5mm gap between the wall and the screw’s head. Lift the unit
with the attached wall brackets over the heads of the screws and slot
into place.
Connections
HDMI ARC input
The ARC (Audio Return Channel) function allows you to send audio
from your ARC- compliant TV to your sound bar through a single HDMI
connection. To enjoy the ARC function, please ensure your TV is both
HDMI-CEC and ARC compliant and set up accordingly. When correctly set
up, you can use your TV remote control to adjust the volume output (VOL
+/- and MUTE) of the sound bar.
 Connect the HDMI cable (not included) from unit's HDMI (ARC) socket to
the HDMI (ARC) socket on your ARC compliant TV. Then press the remote
control to select HDMI ARC.
TIPS:
• Your TV must support the HDMI-CEC and ARC function. HDMI-CEC and
ARC must be set to On.
• The setting method of HDMI-CEC and ARC may dier depending on
the TV. For details about ARC function, please refer to your TV owner’s
manual.
• Only HDMI cables of version 1.4 or higher can support the ARC function.
OPTICAL input
• Remove the protective cap of the OPTICAL socket, then connect an
OPTICAL cable (not included) to the TV’s OPTICAL OUT socket and the
OPTICAL socket on the unit.
TIP:
While in HDMI ARC/OPTICAL mode, if there’s no sound output from the
unit and the HDMI ARC/OPTICAL lights ashes quickly, you may need to
activate PCM signal output on your source device (eg. TV, DVD or Blu-ray
player).
AUX
A. Use a RCA to 3.5mm audio cable (not included) to connect the TV’s
audio output sockets to the AUX 1 socket on the unit.
B. Use a 3.5mm to 3.5mm audio cable (not included) to connect the TV’s
or external audio device headphone socket to the AUX 1 socket on
the unit.
TIP:
When you use the headphone output on the TV set, you will be able to
adjust the volume level directly using the TV remote control.
EN

Connect to Subwoofer
NOTE:
• For optimal sound, use the supplied Subwoofer only.
• Connect only speakers with impedance that is the same or higher than
the supplied speakers. Refer to the Specications section of this manual.
Connect to Power
• Before connecting the AC power cord, ensure you have completed all
other connections.
• Risk of product damage! Ensure that the power supply voltage corres-
ponds to the voltage printed on the back or the underside of the unit.
• Connect the mains cable to the AC~ Socket of the unit and then into a
mains socket.
Basic Operation
Standby/ON
• When you rst connect the unit to the main socket, the unit will be in
STANDBY mode. The POWER indicator will light up red.
• Press the button on the remote control to switch the main unit ON
or OFF.
• Disconnect the main plug from the main socket if you want to switch the
unit o completely.
If a TV or an external device (Only for AUX socket) is connected, the unit will
switch on automatically when the TV or the external device is switched on.
 When the unit has no input signal for over 15 minutes, it will automati-
cally switch to Standby mode.
Select Modes
Press the button on the unit repeatedly or press the AUX, BT
(Bluetooth), OPTICAL, HDMI ARC buttons on the remote control to select
the desired mode.
•Red indicator: In STANDBY mode.
•Green indicator: In AUX mode.
•Orange indicator: In Optical mode.
•Blue indicator: In Bluetooth mode.
••White indicator: In HDMI ARC mode.
Adjust the Volume
 Press the + / - buttons on the unit or press the VOL+ / VOL- buttons on
the remote control to adjust the volume.
 If you wish to turn the sound o, press the MUTE button on the remote
control. Press the MUTE button again or press the VOL+ / VOL- buttons
on the unit or on the remote control to resume normal listening.
 While adjusting the volume, the status indicator ashes quickly.
 While the volume level reaches its maximum level, if you press the VOL+
button again, the status indicator ashes once. While the volume level
reaches its minimum level, if you press the VOL- button again, the status
indicator ashes once.
Select Equaliser (EQ) Eect
• While playing, press the EQ button on the remote control to select
between preset equalisers: Movie (recommended for viewing movies),
Music (recommended for listening to music), NEWS (recommended for
listening to NEWS).
MOVIE - LED ash orange
MUSIC - LED ash blue
NEWS - LED ash green
AUX/OPTICAL/HDMI ARC
1. Ensure that the unit is connected to the TV or audio device.
2. While in ON mode, press the button on the unit repeatedly or press
the AUX, OPTICAL, HDMI ARC buttons on the remote control to select
the desired mode.
3. Operate your audio device directly for playback features.
4. Press the VOL +/– button to adjust the volume to your desired level.
TIP:
While in HDMI ARC/OPTICAL mode, if there’s no sound output from the
unit and the HDMI ARC/OPTICAL lights ashes quickly, you may need to
activate PCM signal output on your source device (eg. TV, DVD or Blu-ray
player).
Bluetooth Operation
Pair Bluetooth-enabled Devices
The rst time you connect your Bluetooth device to this player, you need to
pair your device to this player.
NOTE:
 The operational range between this player and a Bluetooth device is
approximately 8 meters (without any object between the Bluetooth
device and the unit).
 Before you connect a Bluetooth device to this unit, ensure you know the
device’s capabilities.
 Compatibility with all Bluetooth devices is not guaranteed.
 Any obstacle between this unit and a Bluetooth device can reduce the
operational range.
 If the signal strength is weak, your Bluetooth receiver may disconnect,
but it will re-enter pairing mode automatically.
1. While in ON mode, press the (Bluetooth) button on the remote control
or on the unit to select Bluetooth mode. The Blue indicator will light
ash.
2. Activate your Bluetooth device and select the search mode.“HT-
SBW110” will appear on your Bluetooth device list.
 If you cannot nd the unit, press and hold the button on the remote
control to be searchable. After the “Pairing”voice prompt and the Blue
indicator will ash rapidly.
3. Select “HT-SBW110”in the pairing list. After the “Paired” voice prompt,
the system is successfully connected and the Blue indicator will light
up solidly.
4. Begin playing music from the connected Bluetooth device.
To disconnect the Bluetooth function, you can:
 Switch to another function on the unit.
 Disable the Bluetooth function on your device.The device is successfully
disconnected from the unit after the “Disconnected” voice prompt.
 Press and hold the button on the remote control.
TIPS:
• Enter "0000" for the password if necessary.
• If no other Bluetooth device pairs with this player in 2 minutes, the
player will reconnect to the previous connection.
8

•
EN
• The player will also be disconnected when your device is moved beyond
the operational range.
• If you want to reconnect your device to this player, place it within the
operational range.
• If the device is moved beyond the operational range, when it is brought
back, please check if the device is still connected to the player.
• If the connection is lost, follow the instructions above to pair your device
to the player again.
Listen to Music from Bluetooth Device
 If the connected Bluetooth device supports Advanced Audio Distri-
bution Prole (A2DP), you can listen to the music stored on the device
through the soundbar'.
 If the device also supports Audio Video Remote Control Prole (AVRCP),
you can use the soundbar's remote control to play music stored on the
device.
1. Pair your device with the player.
2. Play music via your device (if it supports A2DP).
3. Use supplied remote control to control play (if it supports AVRCP).
 To pause/resume play, press the button on the remote control.
 To skip to a track, press the / buttons on the remote control.
Troubleshooting
To keep the warranty valid, never try to repair the system yourself. If you
encounter problems when using this unit, review the following before
requesting service.
No power
Ensure that the AC cord is properly connected.
Ensure that there is power at the AC outlet.
Press standby button on the remote control or soundbar to turn the
soundbar on.
No sound
Increase the volume. Press Volume Up on the remote control or on the
right side of the soundbar.
Press MUTE on the remote control to ensure the soundbar is not muted.
Press source buttons to select a dierent input source.
When using either of the Digital input, if there is no audio:
 Try setting the TV output to PCM or
 Connect directly to your Blu-ray/other source, some TVs do not pass
through digital audio.
Your TV may be set to variable audio output. Conrm that the audio output
setting is set to FIXED or STANDARD, not VARIABLE. Consult your TV’s user
manual for more detailed information.
If using Bluetooth, ensure that the volume on your source device is turned
up and that the device is not muted.
Remote control does not work
Before you press any playback control button, rst select the correct
source.
Reduce the distance between the remote control and the unit.
Insert the battery with its polarities (+/-) aligned as indicated.
Replace the battery.
Aim the remote control directly at the sensor on the front of the unit.
I hear buzzing or humming
Ensure all cables and wires are securely connected.
Connect a dierent source device (TV, Blu-ray player, etc) to see if the
buzzing persists. If it does not, the problem may be with the original
device.
Connect your device to a dierent input on the soundbar.
I can’t nd the Bluetooth name of this unit on my Bluetooth device
Ensure the Bluetooth function is activated on your Bluetooth device.
Re-pair the unit with your Bluetooth device.
This is a 15 mins power o function, one of the ERPII standard
requirement for saving power
When the unit's external input signal level is too low, the unit will be
turned o automatically in 15 minutes. Please increase the volume level of
your external device.
EN

Technical specication
Model HT-SBW110
Sound Bar
Power Supply AC ~ 220-240V, 50/60Hz
Maximal Power Consumption 30 W
Nominal Power Consumption 10 W
StandBy Power Consumption <0.5W
Output Power 2 x 15 W (RMS) + 30 W (RMS) Subwoofer
Frequency Response 60Hz - 20KHz
Wired Subwoofer
Input Power 30 W (RMS)
Impedance 6 ohm
Bluetooth
Version V 4.2
Maximum power transmitted <20 dbm
Frequency bands 2402 MHz ~ 2480 MHz
Remote Control
Battery Type 2 x R03/AAA
800mm 62mm 150mm
62mm
220mm
320mm
1,3kg
KG
2,7kg
KG
10

www.sharpconsumer.eu
SAU/MAN/0110
UMC Poland sp. z o.o.
Ostaszewo 57B, 87-148 Łysomice,
Poland
Made in China
