Sharp CD G14000 User manual

2008îN Aprilåé 24ì˙ CD-G14000/17000/22000
CD-G22000
CD-G17000
CD-G14000
CD-G17000
CD-G22000
SISTEMA MINI COMPONENTE
MODEL
MODELO
Please refer to pages i to iii and E-1 to E-47.
Consulte las páginas i a iii y S-1 a S-47.
ENGLISH
ESPAÑOL
Please refer to pages i to iii and E-1 to E-47.
Consulte las páginas i a iii y S-1 a S-47.
ENGLISH
ESPAÑOL
Please
Consul
ENGLISH
ESPAÑOL
Please refer to pages i to iii and E-1 to E-47.
Consulte las páginas i a iii y S-1 a S-47.
ENGLISH
ESPAÑOL
MINI COMPONENT SYSTEM
CD-G14000/CD-G17000/
CD-G22000
OPERATION MANUAL
MANUAL DE MANEJO
MODEL
MODELO
SPEAKER SYSTEM
CP-G14000S/CP-G17000S/
The illustrations printed in this operation manual are for the model
CD-G14000
Las ilustraciones impresas en este manual de operaciones son para el
modelo CD-G14000
SISTEMA DE BOCINAS
CP-G22000S

i
Important Instruction
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
SPECIAL NOTES
NOTE
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
 Reorient or relocate the receiving aerial.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
 Consult the dealer or an experienced radio/TV technician for help.
WARNING
FCC Regulations state that any unauthorised changes or
modifications to this equipment not expressly approved by the
manufacturer could void the user's authority to operate this
equipment.
NOTE
It is the intent of Sharp that this product be used in full compliance
with the copyright laws of the United States and that prior permission
be obtained from copyright owners whenever necessary.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTSINSIDE. REFER SERVIC-
ING TO QUALIFIED SERVICE PERSONNEL.
Explanation of Graphical Symbols:
The lightning flash with arrowhead symbol,
withinanequilateral triangle, isintended to
alert the user to the presence of uninsulated
“dangerous voltage” withinthe product’sen-
closure that may be of sufficient magnitude
to constitute a risk of electric shock to per-
sons.
The exclamationpoint withinanequilateral
triangle isintended to alert the user to the
presence of important operating and main-
tenance (servicing) instructions inthe lit-
erature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
Caution - Use of any controls, adjustmentsor procedures
Thisproduct isclassified asa CLASS 1 LASER PRODUCT.
other than those specified herein may result in hazardous
radiation exposure.
Note to CATV system installer:
This reminder is provided to call the CATV system installer's
attention to Article 820-40 of the National Electrical Code that
provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of
cable entry as practical.
FOR YOUR RECORDS
For your assistance in reporting this unit in case of loss or theft,
please record below the model number and serial number which
are located on the rear of the unit.
Please retain this information.
Model number .......................................................
Serial number .......................................................
Date of purchase.......................................................
Place of purchase.......................................................
0202

ii
Important Instruction
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
IMPORTANT SAFETY INSTRUCTIONS
Electricity is used to perform many useful functions, but it can also
cause personal injuries and property damage if improperly handled.
This product has been engineered and manufactured with the
highest priority on safety. However, improper use can result in
electric shock and/or fire. In order to prevent potential danger, please
observe the following instructions when installing, operating and
cleaning the product. To ensure your safety and prolong the service
life of this product, please read the following precautions carefully
before use.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with
the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from
the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for
long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
Additional Safety Information
15) Power Sources - This product should be operated only from the
type of power source indicated on the marking label. If you are
not sure of the type of power supply to your home, consult your
product dealer or local power company. For product intended
to operate from battery power, or other sources, refer to the
operating instructions.
16) Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of
fire or electric shock.
17) Object and Liquid Entry - Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.

iii
Important Instruction
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
IMPORTANT SAFETY INSTRUCTIONS (continued)
ANTENNA LEAD IN WIRE
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
NEC - NATIONAL ELECTRICAL CODE
S2898A
ELECTRIC
SERV ICE
EQUIPMENT
GROUND
CLAMP
Example of antenna grounding as per
National Electrical Code, ANSI/NFPA 70
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
18) Damage Requiring Service - Unplug this product from the wall
outlet and refer servicing to qualified service personnel under
the following conditions :
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the
product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to its normal
operation,
e) If the product has been dropped or damaged in
any way, and
f) When the product exhibits a distinct change in
performance - this indicates a need for service.
19) Replacement Parts - When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics
as the original part. Unauthorized substitutions may result in
fire, electric shock, or other hazards.
20) Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
21) Wall or ceiling mounting - When mounting the product on a wall
or ceiling, be sure to install the product according to the method
recommended by the manufacturer.
22) Power Lines - An outside antenna system should not be located
in the vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or circuits.
When installing an outside antenna system, extreme care should
be taken to keep from touching such power lines or circuits as
contact with them might be fatal.
23) Outdoor Antenna Grounding - If an outside antenna or cable system
is connected to the product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges
and built-up static charges. Article810 of the National Electrical Code,
ANSI/NFPA 70, provides information with regards to proper grounding
of the mast and supporting structure, grounding of the lead-in wire to
an antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
24) Protective Attachment Plug - The product is equipped with an attachment
plug having overload protection. This is a safety feature. See Instruction
Manual for replacement or resetting of protective device. If replacement
of the plug is required, be sure the service technician has used a replace-
ment plug specified by the manufacturer that has the same overload
protection as the original plug.
25) Stand - Do not place the product on an unstable cart, stand, tripod or
table. Placing the product on an unstable base can cause the product to
fall, resulting in serious personal injuries as well as damage to the product.
Use only a cart, stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the product on a
wall, be sure to follow the manufacturer's intructions. Use only the mounting
hardware recommended by the manufacturer.

E-1
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
ENGLISH
Important Instruction
Introduction
Thank you for purchasing this SHARP product. To obtain the best
performance from this product, please read this manual carefully. It
will guide you in operating your SHARP product.
CD-G14000 and CP-G14000S
CD-G14000 Mini Component System consisting of CD-G14000
(main unit).
CP-G14000S Speaker System consisting of CP-G14000 (1 set of
front speaker) and 1 unit of CP-SW14000 (active subwoofer).
CD-G17000 and CP-G17000S
CD-G17000 Mini Component System consisting of CD-G17000
(main unit) and CP-G17000 (2 sets of front speakers).
CP-G17000S Speaker System consisting of 1 unit of CP-SW17000
(active subwoofer).
CD-G22000 and CP-G22000S
CD-G22000 Mini Component System consisting of CD-G22000
(main unit) and CP-G22000 (2 sets of front speakers).
CP-G22000S Speaker System consisting of 2 units of CP-SW22000
(active subwoofers).
Special notes
WARNINGS
 When the ON/STAND-BY button is set at STAND-BY position,
mains voltage is still present inside the unit. When the ON/
STAND-BY button is set at STAND-BY position, the unit may be
brought into operation by the timer mode or remote control.
 This unit contains no user serviceable parts. Never remove covers
unless qualified to do so. This unit contains dangerous voltages,
always remove mains plug from the socket before any service
operation and when not in use for a long period.
 To prevent fire or shock hazard, do not expose this appliance to
dripping or splashing. No objects filled with liquids, such as vases,
shall be placed on the apparatus.
Note:
Audio-visual material may consist of copyrighted works which must
not be recorded without the authority of the owner of the copyright.
Please refer to the relevant laws in your country.
CAUTION
 This product is classified as a CLASS 1 LASER product.
 Use of controls, adjustments or performance of procedures other
than those specified herein may result in hazardous radiation
exposure.
Supply of this product does not convey a license nor imply any right
to distribute content created with this product in revenue-generating
broadcast systems (terrestrial, satellite, cable and/or other distribu-
tion channels), revenue-generating streaming applications (via Inter-
net, intranets and/or other networks), other revenue-generating
content distribution systems (pay-audio or audio-on-demand appli-
cations and the like) or on revenue-generating physical media (com-
pact discs, digital versatile discs, semiconductor chips, hard drives,
memory cards and the like). An independent license for such use is
required. For details, please visit http://mp3licensing.com.
MPEG Layer-3 audio coding technology licensed from Fraunhofer
IIS and Thomson.

E-2
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
Important Instruction
Special notes (continued)
Accessories
Please confirm that the following accessories are included.
Contents
Page
 General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 8
 Preparation for Use
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 16
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 - 17
Subwoofer control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 - 18
 Basic Operation
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 - 19
Setting the clock (Remote Control only) . . . . . . . . . . . . . 19 - 20
 CD or MP3/WMA disc Playback
Listening to a CD or MP3/WMA disc . . . . . . . . . . . . . . . . 20 - 23
Advanced CD or MP3/WMA disc playback . . . . . . . . . . . 24 - 26
MP3/WMA navigation (only for MP3/WMA files) . . . . . . . 27 - 30
 Radio
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 - 32
 Tape Playback
Listening to a cassette tape (TAPE 1 or TAPE 2) . . . . . . 33 - 34
 Tape Recording
Recording on a cassette tape . . . . . . . . . . . . . . . . . . . . . . 34 - 36
 Advanced Features
Timer and sleep operation (Remote Control only). . . . . . 37 - 40
Enhancing your system . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 - 42
 References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 - 44
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 - 47
Remote control 1 AM loop aerial 1 FM aerial 1
(CD-G14000/CD-G17000)
Subwoofer cable 1
(CD-G22000) Subwoofer
cable 2
(CD-G14000)
Wires for front speaker 2
(CD-G17000/CD-G22000)
Wires for front speaker 4
ENERGY STAR
®
Program Information
Productsthat have earned
the ENERGY STAR®are
designed to protect the
environment through
superior energy efficiency.
To comply with the ENERGY STAR®standardsmentioned above,
please cancel the demonstrationmode, asdescribed onpage 16.
ENERGY STAR®isa U.S. registered mark.
Red
Black

E-3
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
General Information
Precautions
 General
 Please ensure that the system is positioned in a well-ventilated
area and ensure that there is at least 10 cm (4") of free space
along the sides, top and back of the equipment.
 Do not place anything on top of the unit and subwoofer.
 Do not expose the system to moisture, to temperatures higher
than 60˚C (140˚F) or to extremely low temperatures.
 If your system does not work properly, disconnect the AC power
lead from the wall socket. Plug the AC power lead back in, and
then turn on your system.
 This unit should only be used within the range of 5˚C - 35˚C
(41˚F - 95˚F).
Warning:
The voltage used must be the same as that specified on this unit.
Using this product with a higher voltage other than that which is
specified is dangerous and may result in a fire or other type of
accident causing damage. SHARP will not be held responsible for
any damage resulting from use of this unit with a voltage other than
that which is specified.
 Volume control
The sound level at a given volume setting depends on speaker
efficiency, location and various other factors. It is advisable to avoid
exposure to high volume levels, which occurs whilst turning the unit
on with the volume control setting up high, or whilst continually
listening at high volumes. Excessive sound pressure from earphones
and headphones can cause hearing loss.
 Do not place active subwoofer system on
the same surface as main unit to prevent
sound interruption during playback.
 Use the unit on a firm, level surface free from
vibration.
 Keep the unit away from direct sunlight,
strong magnetic fields, excessive dust,
humidity and electronic/electrical
equipment (home computers,
facsimiles, etc.) which generate
electrical noise.
10 cm
(
4"
)
10 cm (4") 10 cm (4") 10 cm (4")
TIMER
POWER
ON/STAND-BY
CD
TUNER
(BAND)
4
3
1
5
4
5
3
2
1
PRESET
TUNING
PRESET
TUNING
VOL. VOL.
PHONES
RECORD/PLAYBACK
PLAYBACK(PLAY&STOP)
REMOTE
SENSOR
2
TAPE
(1 2)
OPEN/
CLOSE
c
AUDIO
IN
AUDIO
IN
Floor
 In case of an electrical storm, unplug the
system for safety.
 Hold the AC power plug by the head when
removing it from the wall socket, as pulling
the lead can damage internal wires.
 The AC power plug is used as a disconnect
device and shall always remain readily
operable.
 Do not remove the outer cover, as this
may result in electric shock. Refer
internal service to your local SHARP
service facility.

E-4
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
General Information
Controls and indicators
 Front panel
Reference page
1. Disc Trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2. Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3. Power On/Stand-by Button . . . . . . . . . . . . . . . . . . . 18, 37, 40
4. CD or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
8. Audio In Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9. CD Track Down or Fast Reverse, Tape 2 Rewind,
Tuner Preset Down, Time Down Button . . . . . . . . . 22, 32, 34
10. Tuning Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 27, 31
11. Tape 1 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 33
12. Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
13. Audio In Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
14. Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
15. Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
16. CD Play or Repeat, Tape Play Button . . . . . . . . . . . . . . 21, 25
17. Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . 21
18. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . 21
19. CD Track Up or Fast Forward, Tape 2 Fast Forward,
Tuner Preset Up, Time Up Button . . . . . . . . . . . . . . 22, 32, 34
20. Tuning Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27, 31
21. Tape 2 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 33
TIMER
POWER
ON/ STAND-BY
CD
TUNER
(BAND)
4
3
1
5
4
5
3
2
1
PRESET
TUNING
PRESET
TUNING
VOL. VOL .
PHONES
RECORD/PLAYBACK
PLAYBACK (PLAY & STOP)
REMOTE
SENSOR
2
TAPE
(1 2)
OPEN/
CLOSE
c
AUDIO
IN
AUDIO
IN

E-5
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
General Information
 Display
Reference page
1. Disc Number Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2. MP3/WMA Folder Indicator . . . . . . . . . . . . . . . . . . . . . . . . . 27
3. MP3/WMA Title Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4. MP3 Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5. WMA Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6. Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7. Timer Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8. Timer Recording Indicator . . . . . . . . . . . . . . . . . . . . . . . . . 38
9. Tape 2 Record Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
10. MP3/WMA Total Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
11. Daily Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
12. FM Stereo Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 31
13. FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . . 31
14. Tape Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
15. Memory Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 26, 30, 32
16. Extra Bass Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
17. Disc Repeat Play Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . 25
18. Disc Pause Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
19. Disc Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
 Rear panel (CD-G14000)
Reference page
1. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2. Subwoofer Pre-output Socket (Active Subwoofer). . . . . . 14
3. AC Power lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4. FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . 13
5. AM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6. AM Loop Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7. Front Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
75 OHMS
FM GND AM
ANTENNA
RATED SPEAKER IMPEDANCE : 6 OHMS MIN.
(CD-G14000)

E-6
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
General Information
Controls and indicators (continued)
 Rear panel (CD-G17000)
Reference page
1. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2. Subwoofer Pre-output Socket (Active Subwoofer) . . . . . . 14
3. AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4. FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . 13
5. AM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6. AM Loop Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7. Front Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8. Front Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
 Rear panel (CD-G22000)
Reference page
1. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2. Subwoofer Pre-output Sockets (Active Subwoofer) . . . . . 14
3. AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4. FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . 13
5. AM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6. AM Loop Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7. Front Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8. Front Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
75 OHMS
FM GND AM
ANTENNA
RATED SPEAKER IMPEDANCE : 12 OHMS MIN.
RATED SPEAKER IMPEDANCE : 12 OHMS MIN.
RIGHT LEFT
(CD-G17000)
75 OHMS
FM GND AM
ANTENNA
RATED SPEAKER IMPEDANCE : 12 OHMS MIN.
RATED SPEAKER IMPEDANCE : 12 OHMS MIN.
RIGHT LEFT
(CD-G22000)

E-7
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
General Information
 Front speaker
1. Woofer
2. Tweeter
3. Bass Reflex Duct
4. Speaker Terminals
Note:
The speaker grilles are not removable.
 Active subwoofer
Reference page
1. Subwoofer
2. Bass Reflex Duct
3. Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4. Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5. Crossover Frequency Control . . . . . . . . . . . . . . . . . . . . . . 17
6. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7. Subwoofer Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8. AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Note:
The subwoofer grilles are not removable.
1
3
4
2
1
3
2
4
5
6
7
8

E-8
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
General Information
Controls and indicators (continued)
 Remote control
Reference page
1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . 17
2. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . 21
3. Tuning Up, Cursor Up Button . . . . . . . . . . . . . . . . . . . . . . . 27
4. Disc Track Down or Fast Reverse, Tape 2 Rewind,
Tuner Preset Down, Time Down, Cursor Left Button
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19, 22, 27, 32, 33, 37
5. Clock/Timer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6. Character Input/Disc Direct Search Buttons . . . . . . . . . . . 24
7. Equaliser Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . 19
8. Extra Bass/Demo Button . . . . . . . . . . . . . . . . . . . . . . . . 18, 19
9. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
10. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
11. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
12. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
13. Audio In Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
14. Disc Track Up or Fast Forward, Tape 2 Fast Forward,
Tuner Preset Up, Time Up, Cursor Right Button
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19, 22, 27, 32, 33, 37
15. Tuning Down, Cursor Down Button . . . . . . . . . . . . . . . . . . 27
16. Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . 19
17. Clear/Dimmer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 18, 26
18. Disc Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
19. Disc Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
20. Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
21. Memory Button . . . . . . . . . . . . . . . . . . . . . . . . . . 19, 26, 32, 37
22. Disc Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
23. Disc Play or Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . 25
24. Tape Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33, 34
25. Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . . . 35
26. MP3/WMA Navigation Mode Select Button . . . . . . . . . . . . 27
27. Character Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
28. MP3/WMA Display Button . . . . . . . . . . . . . . . . . . . . . . . . . . 23
29. Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
1
2
5
7
8
3
4
6
10
11
9
12
13
14
16
15
21
23
22
17
19
18
25
24
20
26 27 2829

E-9
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
Preparation for Use
System connections
75 OHMS
FM GND AM
ANTENNA
RATED SPEAKER IMPEDANCE : 6 OHMS MIN.
Subwoofer
connection
(see page 14)
FM
aerial
AM loop
aerial Front
speaker
(left)
Speaker connection
(see page 12)
Aerial connection (see page 12)
To wall socket (AC 120 V ~ 60 Hz)
To wall socket (AC 120 V ~ 60 Hz)
Make sure to unplug the AC power lead before making any connections.
Front
speaker
(right) Active subwoofer
AC power connection (see page 15)
(CD-G14000)

E-10
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
Preparation for Use
System connections (continued)
75 OHMS
FM GND AM
ANTENNA
RATEDSPEAKER IMPEDANCE : 12 OHMS MIN.
RATEDSPEAKER IMPEDANCE : 12 OHMS MIN.
RIGHT LEFT
Subwoofer
connection
(see page 14)
FM
aerial AM loop
aerial Front
speaker
(left)
Front
speaker
(left)
Speaker connection
(see page 12)
Aerial connection (see page 12)
To wall socket (AC 120 V ~ 60 Hz)
Front
speaker
(right)
Front
speaker
(right) Active subwoofer
To wall socket (AC 120 V ~ 60 Hz)
AC power connection (see page 15)
(CD-G17000)
Make sure to unplug the AC power lead before making any connections.

E-11
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
Preparation for Use
75 OHMS
FM GND AM
ANTENNA
RATEDSPEAKER IMPEDANCE : 12 OHMS MIN.
RATEDSPEAKER IMPEDANCE : 12 OHMS MIN.
RIGHT LEFT
Subwoofer
connection
(see page 14)
FM
aerial AM loop
aerial
Subwoofer
connection
(see page 14)
Speaker connection
(see page 12)
Aerial connection (see page 12)
To wall socket
To wall socket
Make sure to unplugthe AC power lead before makingany connections.
Front
speaker
(right)
Front
speaker
(right)
Front
speaker
(left)
Front
speaker
(left)
Active Subwoofer Active subwoofer
AC power connection (see page 15)
(CD-G22000)
To wall socket
(AC 120 V ~60 Hz) (AC 120 V ~60 Hz) (AC 120 V ~60 Hz)

E-12
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
Preparation for Use
System connections (continued)
 Aerial connection
Note:
Placing the aerial on the unit or near the AC power lead may cause
noise pickup. Place the aerial away from the unit for better reception.
Installing the AM loop aerial:
 Speaker connection
Front speakers:
Connect the black wire to the FRONT SPEAKERS (–) terminal, and
the red wire to the FRONT SPEAKERS (+) terminal.
Caution:
Supplied FM aerial:
Connect the FM aerial wire to the FM
75 OHMS socket and position the FM
aerial wire in the direction where the
strongest signal can be received.
Supplied AM loop aerial:
Connect the AM loop aerial to the AM
and GND terminals. Position the AM
loop aerial for optimum reception.
Place the AM loop aerial on
a shelf,
etc., or attach it to a stand or a wall with
screws (not supplied).
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
ANTENNA
FM
75 OHMS
AM
GND
AM loop
aerial
FM
aerial
Connect the speaker wires to the speakers first, then to the unit.
If you use other speakers with impedance lower
than that specified, the unit may be damaged.
Front speakers: 6 ohms (CP-G14000) and 12 ohms
(CP-G17000 and CP-G22000)
Do not mistake the right and the left channels. The
right speaker is the one on the right side when you
face the unit.
 Do not let the bare speaker wires touch each other.
Do not allow any objects to fall into or to be placed
in the bass reflex ducts.
Do not stand or sit on the speakers. You may be
injured.
Black
Red
Front speaker (right)
Front speaker (right) Front speaker (left)
Front speaker (left)
Incorrect
Incorrect

E-13
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
Preparation for Use
Placing the speaker system
To enjoy the surround effect, we recommend that you place each
speaker as shown to the below.
External FM aerial
Use an external FM aerial if you require better reception.
Consult your dealer.
Note:
When an external FM aerial is used, disconnect the supplied FM
aerial wire.
Note:
Front speakers and active subwoofer are not magnetically shielded
and must not be placed near the TV.
If colour variation occurs:
Turn off the TV (from the power switch).
After 15 - 30 minutes, turn the TV on again.
If the colour variation is still present:
Move the speakers further away from the TV.
If any kind of magnet or an electromagnet is placed too close to
the TV and the system, irregular colours may appear on the TV
screen.
Front
speaker
(left)
Front
speaker
(right) Front
speaker
(right)
Front
speaker
(left)
TV
Main unit
This illustration is for CD-G22000
Active
subwoofer
Active
subwoofer
External FM aerial
75 ohms
coaxial cable
ANTENNA
FM
75 OHMS
AM
GND

E-14
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
Preparation for Use
System connections (continued)
Connecting the subwoofer
Use the subwoofer cable to connect the SUBWOOFER PRE-OUT
socket on the main unit and the SUBWOOFER IN socket on the
active subwoofer.
Make sure to unplug the AC power lead of the main unit before
making any connections.
75 OHMS
FM GND AM
ANTENNA
RATEDSPEAKER IMPEDANCE : 6 OHMS MIN.
Main unit
Subwoofer cable
(For CD-G14000 and CD-G17000)
Active subwoofer
To subwoofer
output socket
To subwoofer
input socket
75 OHMS
FM GND AM
ANTENNA
RATEDSPEAKER IMPEDANCE : 12 OHMS MIN.
RATEDSPEAKER IMPEDANCE : 12 OHMS MIN.
RIGHT LEFT
Subwoofer
cable
Active subwoofers
To subwoofer
output sockets
To subwoofer
input sockets
(For CD-G22000)

E-15
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
Preparation for Use
AC power connection
After checking all the connections have been made correctly, plug
the AC power lead of this unit into the wall socket. If you plug in the
unit first, the unit will enter the demonstration mode.
Notes:
Cooling fan:
The main unit and the active subwoofer are built with a cooling fan at
the rear of the units for improved cooling. Please do not cover the
opening of the fan with any obstacles, as this will block proper
ventilation.
The unit will start the tape initialisation when plugged in to the wall
socket. During this process, an initialising sound will be heard and
the unit cannot be turned on. Wait until the process is finished.
Unplug the AC power lead from the wall socket if the unit will not
be in use for a prolonged period of time.
75 OHMS
FM GND AM
ANTENNA
RATEDSPEAKER IMPEDANCE : 6 OHMS MIN.
Active subwoofer
Main unit
Wall socket
(AC 120 V ~ 60 Hz)
Wall socket
(AC 120 V ~ 60 Hz)
Active subwoofer
Main unit
75 OHMS
FM GND AM
ANTENNA
RATEDSPEAKER IMPEDANCE : 6 OHMS MIN.

E-16
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
Preparation for Use
System connections (continued)
Demonstration mode
When you plug the unit in for the first time, the unit will enter the
demonstration mode. You will see words scroll.
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode),
press the X-BASS/DEMO button. The unit will enter the low power
consumption mode.
Remote control
Battery installation
Precautions for battery use:
Replace all old batteries with new ones at the same time.
Do not mix old and new batteries.
Remove the batteries if the unit will not be used for long periods
of time. This will prevent potential damage due to battery leakage.
Caution:
Do not use rechargeable batteries (nickel-cadmium battery, etc.).
Installing the batteries incorrectly may cause the unit to
malfunction.
Batteries (battery pack or batteries installed) shall not be exposed
to excessive heat such as sunshine, fire or the like.
Battery removal:
Open the battery cover and pull up the battery to take out.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the
X-BASS/DEMO button again.
Note:
When the power is on, the X-BASS/DEMO button can be used to
select the extra bass mode.
Use 2 “AA” size batteries (UM/SUM-3, R6, HP-7 or similar).
Batteries are not included.
1 Open the battery cover.
2 Insert the batteries according to the direction indicated in
the battery compartment.
When inserting or removing the batteries, push them towards the
battery terminals.
3 Close the battery cover.
