Sharp CD-BK3100W User manual

OPERATION MANUAL
MODE D’EMPLOI
MANUAL DE MANEJO
SHARP CORPORATION
MODEL
MODÈLE
MODELO
CD-BK3100W
MINI COMPONENT SYSTEM
MINI-CHAÎNE
SISTEMA MINI
CD-BK3100W Mini Component System consisting of CD-BK3100W (main unit) and CP-
BK3100 (speaker system).
Mini-chaîne CD-BK3100W composée de CD-BK3100W (appareil principal) et de CP-
BK3100 (enceintes acoustiques).
Sistema mini CD-BK3100W que consta de CD-BK3100W (aparato principal) y CP-BK3100
(sistema de altavoces).
CD-BK3100W CD-BK3100W CP-BK3100
Please refer to pages E-1 to E-32.
Se reporter aux pages F-1 à F-32.
Consulte las páginas S-1 a S-32.
ENGLISH
FRANÇAIS
ESPAÑOL

E-1 ENGLISH
ENGLISH
Important Instruction
- Introduction / Special Notes -
Introduction
Thank you for purchasing this SHARP product. To obtain the best performance from
this product, please read this manual carefully. It will guide you in operating your
SHARP product.
Special Notes
zWhen the ON/STAND-BY button is set at STAND-BY position, mains voltage is still
present inside the unit. When the ON/STAND-BY button is set at STAND-BY posi-
tion, the unit may be brought into operation by the timer mode or remote control.
zAudio-visual material may consist of copyrighted works which must not be
recorded without the authority of the owner of the copyright. Please refer to the rel-
evant laws in your country.
Warning:
This unit contains no user serviceable parts. Never remove covers unless qualified to
do so. This unit contains dangerous voltages, always remove mains plug from the
socket before any service operation and when not in use for a long period.
Warning:
To prevent fire or shock hazard, do not expose this appliance to dripping or splashing.
No objects filled with liquids, such as vases, shall be placed on the apparatus.
CAUTION Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
zThis Mini Component System is classified as a CLASS 1 LASER product.
zThe CLASS 1 LASER PRODUCT label is located on the rear cover.
zUse of controls, adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
As the laser beam used in thiscompact disc player is harmful to the eyes, do not
attempt to disassemble the cabinet. Refer servicing to qualified personnel only.
CAUTION-INVISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO
BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.
VARNING-OSYNLIG LASERSTRALNING NAR DENNA DEL AR OPPNAD. STIRRA
EJ IN I STRALEN OCH BETRAKTA EJ STRALEN MED OPTISKA INSTRUMENT.
ADVERSEL-USYNLIG LASERSTRALING VED ABNING. SE IKKE IND I
STRALEN-HELLER IKKE MED OPTISKE INSTRUMENTER.
VARO! AVATTAESSA OLET ALTTIINA NAKYMATON LASERSATEILYLLE.
ALA TUIJOTA SATEESEEN ALAKA KATSO SITA OPTISEN LAITTEEN LAPI.
VARNING-OSYNLIG LASERSTRALNING NAR DENNA DEL AR OPPNAD.
STIRRA EJ IN I STRALEN OCH BETRAKTA EJ STRALEN GENOM OPTISKT
INSTRUMENT.
ADVERSEL-USYNLIG LASERSTRALING NAR DEKSEL APNES. STIRR IKKE
INN I STRALEN ELLER SE DIREKTE MED OPTISKE INSTRUMENTER.

E-2
ENGLISH
General Information
- Accessories / Contents -
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Contents
Page
„General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 6
„Preparation for Use
System Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 10
General Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
„Basic Operation
Sound Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
„CD Playback
Listening to a CD (CDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14, 15
To Specify a Disc to Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Repeat or Random Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Programmed Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
„Radio
Listening to the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Listening to the Memorised Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
„Tape Playback
Listening to a Cassette Tape (TAPE 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Listening to a Cassette Tape (TAPE 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
„Karaoke
Playing Karaoke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22, 23
„Tape Recording
Recording from the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Recording from a CD (CDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Dubbing from Tape to Tape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
„Advanced Features
Timer and Sleep Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27, 28
Enhancing Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
„References
Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30, 31
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Remote control 1 "AA" size battery (UM/SUM-3, R6,
HP-7 or similar) 2
AM loop aerial 1 FM aerial 1

E-3 ENGLISH
General Information
- Precautions -
Precautions
„General
zPlease ensure that the equipment is positioned in a well-ventilated area and
ensure that there is at least 10 cm (4") of free space along the sides, top and back
of the unit.
zUse the unit on a firm, level surface free from vibration.
zKeep the unit away from direct sunlight, strong magnetic fields, excessive dust,
humidity and electronic/electrical equipment (home computers, facsimiles, etc.)
which generates electrical noise.
zDo not place anything on top of the unit.
zDo not expose the unit to moisture, to temperatures higher than 60°C (140°F) or to
extremely low temperatures.
zIf your system does not work properly, disconnect the AC power lead from the wall
socket. Plug the AC power lead back in, and then turn on your system.
zIn case of an electrical storm, unplug the unit for safety.
zHold the AC power plug by the head when removing it from the wall socket, as
pulling the lead can damage internal wires.
zDo not remove the outer cover, as this may result in electric shock. Refer
internal service to your local SHARP service facility.
zThe ventilation should not be impeded by covering the ventilation openings with
items, such as newspapers, tablecloths, curtains, etc.
zNo naked flame sources, such as lighted candles, should be placed on the appa-
ratus.
zAttention should be drawn to the environmental aspects of battery disposal.
zThis unit should only be used within the range of 5°C - 35°C (41°F - 95°F).
Warning:
The voltage used must be the same as that specified on this unit. Using this product
with a higher voltage other than that which is specified is dangerous and may result in
a fire or other type of accident causing damage. SHARP will not be held responsible
for any damage resulting from use of this unit with a voltage other than that which is
specified.
„Volume control
The sound level at a given volume setting depends on speaker efficiency, location,
and various other factors. It is advisable to avoid exposure to high volume levels,
which occurs whilst turning the unit on with the volume control setting up high, or
whilst continually listening at high volumes.
„Condensation
„Care of compact discs
Compact discs are fairly resistant to damage, however mistracking can occur due to
an accumulation of dirt on the disc surface. Follow the guidelines below for maximum
enjoyment from your CD collection and player.
zDo not write on either side of the disc, particularly the non-label side from which
signals are read. Do not mark this surface.
zKeep your discs away from direct sunlight, heat, and excessive moisture.
zAlways hold the CDs by the edges. Fingerprints, dirt, or water on the CDs can
cause noise or mistracking. If a CD is dirty or does not play properly, clean it with a
soft, dry cloth, wiping straight out from the centre, along the radius.
10 cm (4") 10 cm (4") 10 cm (4")
10 cm (4") Sudden temperature changes, storage or opera-
tion in an extremely humid environment may
cause condensation inside the cabinet (CD pick-
up, tape heads, etc.) or on the transmitter on the
remote control.
Condensation can cause the unit to malfunction.
If this happens, leave the power on with no disc
(or cassette) in the unit until normal playback is
possible (about 1 hour). Wipe off any condensa-
tion on the transmitter with a soft cloth before op-
erating the unit.
NO YES
Correct

E-4
ENGLISH
General Information
- Controls and Indicators -
Controls and Indicators
„Front panel Reference page
1.Disc Trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.CD Direct Play Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16, 17, 25
4.CD Eject Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.Memory/Set Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 17, 19
6.Equalizer Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8.Extra Bass/Demo Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . 10, 12
9.Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . 24 - 26
10.Tape 2 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . 21,26
11.Tape 1 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . 20,26
12.CD Track Down or Fast Reverse, Tape 2 Fast Wind,
Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 19, 21
13.CD Track Up or Fast Forward, Tape 2 Fast Wind,
Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 19, 21
14.CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 25
15.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
16.Tape 2 Reverse Play Button (with Indicator) . . . . . . . . . . . . . . . . . . 21
17.Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20, 21, 26
18.Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27, 29
19.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
20.Dimmer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
21.Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
22.CD or Tape Stop Button (with Indicator) . . . . . . . . . . . . . . . 15, 20, 21
23.CD Play or Repeat, Tape 1 Play,
Tape 2 Forward Play Button (with Indicator) . . . . . . . . 15, 16, 20, 21
24.Tape 2 Reverse Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . 21
25.Microphone Level Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
26.Microphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
27.Clock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 27
28.Timer/Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27, 28
29.Tuning and Time Down Button . . . . . . . . . . . . . . . . . . . . . . . . . 13, 18
30.Tuning and Time Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 18
22
23
24
12
3029282725 26
13 1415 16 17 18
19
20
21
1
2
34
5
6
7
8
9
10
11
Description of remote control (See page 6.)

E-5 ENGLISH
General Information
- Controls and Indicators -
Controls and Indicators (continued)
„Display
1.CD Music Schedule Indicators
2.CD Indicators
3.FM Stereo Mode Indicator
4.FM Stereo Receiving Indicator
5.Memory Indicator
6.CD Random Play Indicator
7.Tape 2 Record Indicator
8.Extra Bass Indicator
9.Timer Recording Indicator
10.Timer Play Indicator
11.Sleep Indicator
12.Spectrum Analyser/Volume Level Indicator
13.CD Play Indicator
14.CD Pause Indicator
15.Tape Reverse Mode Indicator
16.Tape 2 Reverse Play Indicator
17.Tape 1 Play or Tape 2 Forward Play Indicator
18.CD Repeat Play Indicator
19.Karaoke Mode Indicator
„Rear panel Reference page
1.Transport screw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7, 31
2.FM 75 Ohms Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7, 8
3.FM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7, 8
4.AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7, 8
5.Span Selector Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
6.Video/Auxiliary (Audio Signal) Input Sockets . . . . . . . . . . . . . . . . .29
7.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7, 8
8.AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
9.AC Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
„Speaker system
1.Subwoofer
2.Bass Reflex Duct
3.Tweeter
4.Woofer
5.Speaker wire for SUBWOOFER terminals
6.Speaker wire for MAIN terminals
5
6
8
432
9
10
11
12
7
119
181716
13 1415
3
4
2
1
5
6
9
12
4
5
3
2
1
7
6
8

E-6
ENGLISH
General Information
- Controls and Indicators -
„Remote control Reference page
1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.Echo Level Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.Karaoke Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.CD Direct Play Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16, 17, 25
5.CD Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6.Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 - 26
7.CD Track Down or Fast Reverse, Tape 2 Fast Wind,
Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 19, 21
8.Equalizer Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
9.Tape 2 Reverse Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
10.CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 25
11.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
12.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
13.Extra Bass Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
14.CD Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
15.CD Memory Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
16.CD Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
17.CD Track Up or Fast Forward, Tape 2 Fast Wind,
Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 19, 21
18.CD or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 20, 21
19.CD Play or Repeat, Tape 1 Play,
Tape 2 Forward Play Button . . . . . . . . . . . . . . . . . . . . . . . 15, 16, 20, 21
20.Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
21.Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20, 21, 26
22.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1
2
15
16
17
18
19
20
22
3
6
4
7
8
9
10
13
12
11
5
14
21
Buttons with " " mark in the illustration can be operated on the remote control
only.
Other buttons can be operated both on the main unit and the remote control.
Battery installation for remote control (See page 11.)

E-7 ENGLISH
Preparation for Use
- System Connections -
System Connections
VCR, DVD, etc.
AM loop aerial
Right speaker Left speaker
FM aerial
not supplied
Transport screw
To a wall socket
(See page 9. )

E-8
ENGLISH
Preparation for Use
- System Connections -
„Removing the transport screw
Before turning the power on, be sure to remove the transport screw on
the back of the unit using a flat-blade screwdriver or a coin.
Note:
This screw is required when transporting the unit again. Please keep it (see page 31).
„Aerial connection
Note:
Placing the aerial on the unit or near the AC power lead may cause noise pickup.
Place the aerial away from the unit for better reception.
Installing the AM loop aerial:
External FM aerial:
Use an external FM aerial if you require better reception. Consult your dealer.
Note:
When an external FM aerial is used, disconnect the supplied FM aerial wire.
„Speaker connection
Main terminals:
Connect the lower black wire to the MAIN (-) terminal and the blue wire to the MAIN
(+) terminal.
Subwoofer terminals:
Connect the upper black wire to the SUBWOOFER (-) terminal and the red wire to
the SUBWOOFER (+) terminal.
Caution:
Supplied FM aerial:
Connect the FM aerial wire tothe FM 75 OHMS
terminal and position the FM aerial wire in the di-
rection where the strongest signal can be re-
ceived.
Supplied AM loop aerial:
Connect the AM loop aerial wire to the AM
LOOP socket. Position the AM loop aerial for
optimum reception. Place the AM loop aerial on
a shelf, etc., or attach it to a stand or a wall with
screws (not supplied).
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
External
FM aerial
75 ohm
coaxial
cable
Right speaker Left speaker
zNever mistake the MAIN and the SUBWOOFER terminals.
The unit or the speakers may be damaged.
zOnly the included speakers should be used with this prod-
uct. Do not use other speakers with this unit or use the sup-
plied speakers with other units.
zDo not mistake the right and the left channels. The right
speaker is the one on the right side when you face the unit.
zDo not let the bare speaker wires touch each other.
zDo not allow any objects to fall into or to be placed in the
bass reflex ducts.
zDo not stand or sit on the speakers. You may be injured.
Incorrect
Black
Red
Blue

E-9 ENGLISH
Preparation for Use
- System Connections -
System Connections (continued)
„Placing the speaker system
The left and right speakers have individual shapes. For best performance, place the
speakers according to the diagram below.
Bi-amp system:
Each speaker unit has a built-in subwoofer (low frequency range) which is driven sep-
arately from the woofer and tweeter (mid-to-high frequency range). Two independent
amplifiers which have individual frequency characteristics are used. By amplifying
separately the two frequency bands, clearer sound is achieved.
„Setting the AC voltage selector
Check the setting of the AC voltage selector located on the rear panel before plug-
ging the unit into a wall socket. If necessary, adjust the selector to correspond to the
AC power voltage used in your area.
Turn the selector with a screwdriver until the appropriate voltage num-
ber appears in the window (110 V, 127 V, 220 V or 230 V - 240 V AC).
„Connecting the AC power lead
After making all connections, plug the unit. If you plug the unit first,
the unit will enter the demonstration mode (see page 10).
Note:
Unplug the AC power lead from the wall socket if the unit will not be in use for a pro-
longed period of time.
AC Plug Adaptor
In areas (or countries) where a wall socket as shown in illustration is used, connect
the unit using the AC plug adaptor supplied with the unit, as illustrated. The AC plug
adaptor is not included in areas where the wall socket and AC power plug can be
directly connected (see illustration ).
Left speaker Right speaker
Speaker grilles are removable:
Make sure nothing comes into contact with thespeaker
diaphragms when you remove the speaker grilles.
Power amplifier
Mid-to-high range
(200 Hz - 20 kHz)
Ultra-low range
(60 Hz - 200 Hz)
Pre-amplifier
Pre-amplifier
Power amplifier
L-ch
Tweeter
Woofer
Sub-
woofer
1
2
Demonstration mode (See page 10.)

E-10
ENGLISH
Preparation for Use
- System Connections / General Control -
„Setting the FM/AM span selector
The International Telecommunication Union (ITU) has established that member coun-
tries should maintain either a 100 kHz or a 50 kHz interval between broadcasting fre-
quencies of FM stations and 10 kHz or 9 kHz for AM station. The illustration shows
the 50/9 kHz zones (regions 1 and 3), and the 100/10 kHz zone (region 2).
Before using the unit, set the SPAN SELECTOR switch (on the rear panel) to the
interval (span) of your area.
To change the tuning zone:
Caution:
This operation will erase all data stored in memory including clock, timer settings,
tuner preset, and CD programme.
General Control
„Demonstration mode
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode), press the
X-BASS/DEMO button. The demonstration mode will be cancelled and the display
will disappear.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the X-BASS/DEMO button again.
Note:
When the power is on, the X-BASS/DEMO button can be used to select the extra
bass mode.
„To turn the power on
Press the ON/STAND-BY button to turn the power on.
To set the unit to stand-by mode:
Press the ON/STAND-BY button again.
„To change the display brightness (2 levels)
You can switch the display brightness by pressing the DIMMER button.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Set the SPAN SELECTOR switch (on the rear panel) as follows.
zFor 50 kHz FM interval (9 kHz in AM) 50/9
zFor 100 kHz FM interval (10 kHz in AM) 100/10
3 Whilst pressing down the MEMORY/SET button and the X-BASS/DEMO button,
press the ON/STAND-BY button until "CLEAR AL" appears.
The first time the unit is plugged, the unit will enter
the demonstration mode. You will see words scroll.
Dimmed Brightened

E-11 ENGLISH
Preparation for Use
- Remote Control -
Remote Control
„Battery installation
Precautions for battery use:
zReplace all old batteries with new ones at the same time.
zDo not mix old and new batteries.
zRemove the batteries if the unit will not be used for long periods of time. This will
prevent potential damage due to battery leakage.
Caution:
zDo not use rechargeable batteries (nickel-cadmium battery, etc.).
zInstalling the batteries incorrectly may cause the unit to malfunction.
Notes concerning use:
zReplace the batteries if the operating distance is reduced or if the operation
becomes erratic. Purchase 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).
zPeriodically clean the transmitter on the remote control and the sensor on the unit
with a soft cloth.
zExposing the sensor on the unit to strong light may interfere with operation.
Change the lighting or the direction of the unit.
zKeep the remote control away from moisture, heat, shock, and vibrations.
„Test of the remote control
Face the remote control directly to the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy the
music.
1 Remove the battery cover.
2 Insert the batteries according to the direction indicated in the bat-
tery compartment.
When inserting or removing the batteries, push them towards the battery termi-
nals.
3 Replace the cover.
0.2 m - 6 m
(8" - 20')
Remote sensor

E-12
ENGLISH
Basic Operation
- Sound Control -
Sound Control
„Volume control
Main unit operation:
When the VOLUME control is turned clockwise, the volume will increase. When it is
turned anti-clockwise, the volume will decrease.
Remote control operation:
Press the VOLUME button to increase the volume and the VOLUME button for
decreasing.
„Bass control
When the power is first turned on, the unit will enter the extra bass mode which
emphasises the bass frequencies, and "X-BASS" will appear. To cancel the extra
bass mode, press the X-BASS/DEMO (X-BASS) button.
„Equalizer
When the EQUALIZER (EQUALIZER MODE) button is pressed, the current mode
setting will be displayed. To change to a different mode, press the EQUALIZER
(EQUALIZER MODE) button repeatedly until the desired sound mode appears.
X-BASS indicator
The sound is not modified.
Bass and treble are emphasised.
Bass and treble are slightly emphasised.
Treble is cut a little.
Treble is reduced a lot.
Vocals (midrange tones) are emphasised.
012 29 30 MAXIMUM
.....

E-13 ENGLISH
Basic Operation
- Setting the Clock -
Setting the Clock
In this example, the clock is set for the 24-hour (0:00) display.
Note:
The "CLOCK" or time will flash at the push of the CLOCK button when the AC power
supply is restored after a power failure or unplugging the unit.
Readjust the clock as follows.
To readjust the clock:
Perform "Setting the Clock" from the beginning. If the time display is flashing, step 3
(for selecting the 24-hour or 12-hour display) will be skipped.
To change the 24-hour or 12-hour display:
1Press the ON/STAND-BY button to turn the power on.
2Press the CLOCK button and within 5 seconds, press the MEMO-
RY/SET button.
3Press the TUNING/TIME ( or ) button to select 24-hour or 12-
hour display and then press the MEMORY/SET button.
"0:00" The 24-hour display will appear.
(0:00 - 23:59)
"AM 12:00" The 12-hour display will appear.
(AM 12:00 - PM 11:59)
"AM 0:00" The 12-hour display will appear.
(AM 0:00 - PM 11:59)
Note that this can only be set when the unit is first installed or it has been reset.
[Refer to "Clearing all the memory (reset)" on page 31 for details.]
4Press the TUNING/TIME( or ) button to adjust the hour andthen
press the MEMORY/SET button.
zPress the TUNING/TIME ( or ) button once to advance the time by 1 hour.
Hold it down to advance continuously.
zWhen the 12-hour display is selected, "AM" will change automatically to "PM".
5Press the TUNING/TIME ( or ) button to adjust the minutes and
then press the MEMORY/SET button.
zPress the TUNING/TIME ( or ) button once to advance the time by 1
minute. Hold it down to change the time in 5-minute intervals.
zThe hour will not advance even if minutes advance from "59" to "00".
zThe clock begins counting from "0" seconds. (Seconds are not displayed.)
The time display will disappear after a few seconds.
To confirm the time display:
Press the CLOCK button.
The time display will appear for about 5 seconds.
1 Clear all the programmed contents. [Refer to "Clearing all the memory (reset)" on
page 31 for details.]
2 Perform "Setting the Clock" from the beginning.

E-14
ENGLISH
CD Playback
- Listening to a CD (CDs) -
Listening to a CD (CDs)
This system can play audio CD-R and CD-RW discs just as CD discs, but cannot per-
form recording. (However, some CD-R and CD-RW discs may not be played.)
„To play discs in turn (from Disc 1 to Disc 6)
Note:
The system will search CD trays until it finds a CD and will not search the rest of the
trays.
Continued to the next page
1Press the ON/STAND-BY button to turn the power on.
2Press the CD button.
3Press the 1 button to open the disc tray 1.
4Place the CD on the disc tray 1, label side up.
Be sure to place 8 cm (3") CD in the middle of the disc trays.
5Press the 1 button to close the disc tray 1.
Music schedule Total number of tracks Total playing time
Means "disc inside"
The music schedule will display only the number of tracks on the disc.
If the CD contains more than 15 tracks, " " will appear.
6You can place discs on the trays 2 - 6 by following steps 3 - 5.
12 cm (5") 8 cm (3")
Sound Control (See page 12.)

E-15 ENGLISH
CD Playback
- Listening to a CD (CDs) -
Listening to a CD (CDs) (continued)
To interrupt playback:
Press the button on the remote control.
To resume playback from the same point, press the button.
To stop playback:
Press the button.
To exchange other CDs whilst playing a disc:
Press CD eject button for any stopped CD from 1 to 6 and exchange discs.
To remove the CDs:
Whilst in the stop mode, press the CD eject button for any CD from 1 to 6 to
remove the disc.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
Caution:
zDo not place two CDs in one disc tray.
zDo not push the disc tray whilst it is moving.
zIf the power fails whilst the tray is open, wait until the power is restored.
zIf the disc tray is stopped forcibly, "ER-CD10" will appear in the display and the unit
will not function. If this occurs, press the ON/STAND-BY button to enter the power
stand-by mode and then turn the power on again.
zIf TV or radio interference occurs during CD operation, move the unit away from
the TV or radio.
zIf a disc is damaged, dirty, or loaded upside down, the disc will be skipped.
„To locate the beginning of a track
Note:
You can locate the beginning of a track on a single disc only.
„To locate the desired portion
Notes:
zNormal playback will resume when the / or / button is released.
zYou can locate the desired portion on a single disc only.
zWhen the end of the last track is reached during fast forward, "DISC END" will
appear on the display and CD operation will be paused. When the beginning of the
first track is reached during fast reverse, the disc will start playback automatically.
7Press the ( ) button to start playback.
zPlayback will begin from track 1 on the DISC 1. After that disc finishes playing,
the next disc will automatically play.
zWhen the last track on the DISC 6 has finished playing, the CD player will stop
automatically.
zWhen there is no CD in one of the disc tray 1 - 6 positions, that position will
be skipped and the next CD will be played.
To move to the beginning of the next track:
Press the / button for less than 0.5 seconds during playback.
zYou can skip to any track by pressing the
/ button repeatedly until the desired track
number appears.
To restart the track being played:
Press the / button for less than 0.5 seconds during playback.
zYou can skip to any track by pressing the
/ button repeatedly until the desired track
number appears.
For audible fast forward:
Press and hold down the / button during playback.
For audible fast reverse:
Press and hold down the / button during playback.

E-16
ENGLISH
CD Playback
- To Specify a Disc to Play / Repeat or Random Play -
To Specify a Disc to Play
You can play a disc by specifying the disc number.
Note:
Among discs 1 - 6, those with whitely illuminated CD indicators in the frame can be
played. However, if the button of the disc tray with no disc is pressed, playback will not
start and the indicator in the frame will go out.
To stop playback:
Press the button.
Repeat or Random Play
„Repeat Play
All tracks on up to 6 discs, or a programmed sequence can be continuously repeated.
To repeat a desired track:
Perform steps 1 - 4 in the "Programmed Play" section and then press the ( )
button twice.
To cancel repeat play:
Press the ( ) button again.
" " will go out.
„Random Play
The tracks on the disc(s) can be played in random order automatically.
To cancel random play:
Press the button.
Notes:
zIf you press the / button during random play, you can move to the track
selected next by the random operation. On the other hand, the / button
does not allow you to move to the previous track. The beginning of the track being
played will be located.
zIn random play, the CD player will select and play tracks automatically. (You cannot
select the order of the tracks.)
Caution:
After performing repeat or random play, be sure to press the button. Otherwise, the
disc(s) will play continuously.
Press one of the 1 - 6 buttons to play the desired disc.
Selected disc number
Only the chosen disc will be played and stopped automatically.
To repeat all tracks on up to 6 discs:
Press the ( ) button twice.
By pressing the ( ) button after one of the 1 - 6 buttons is pressed, repeat
play will be performed on that disc.
Press the RANDOM button on the remote control to begin random
play.
By pressing the RANDOM button after one of the 1 - 6 buttons is pressed, ran-
dom play will be performed on that disc.

E-17 ENGLISH
CD Playback
- Programmed Play -
Programmed Play
Up to 32 tracks can be programmed.
To cancel the programmed play mode:
Whilst in the stop mode and the "MEMORY" indicator is lit, press the CLEAR button
on the remote control. The "MEMORY" indicator will disappear and all the pro-
grammed contents will be cleared.
Adding tracks to the programme:
If a programme has been previously stored, the "MEMORY" indicator will be dis-
played. Then follow steps 1 - 6 to add tracks. The new tracks will be stored after the
last track of the original programme.
To check which tracks are programmed:
Whilst the unit is stopped in the programmed play mode, press the / or /
button.
Notes:
zOpening any tray of the programmed discs automatically cancels the programmed
sequence.
zEven if you press the ON/STAND-BY button to enter the stand-by mode or change
the function from CD to another, the programmed selections will not be cleared.
zDuring programme operation, random play is not possible.
1Whilst in the stop mode, press
the MEMORY/SET (MEMORY)
button to enter the programming
save mode.
2Press one of the 1 - 6 buttons
to select the desired disc.
Selected disc number
3Press the / or / button
to select the desired track.
Selected track
number Playback order
4Press the MEMORY/SET (MEMO-
RY) button tosave the track num-
ber.
5Repeat steps 2 - 4 for other tracks. Up to 32 tracks can be pro-
grammed.
6Press the button.
7Press the ( ) button to start playback.
Note:
During programme play, buttons 1 - 6 will not work.
To clear the programmed selections:
Press the CLEAR button on the remote control
whilst the "MEMORY" indicator is flashing.
Each time the button is pressed, one track will
be cleared, beginning with the last track pro-
grammed.

E-18
ENGLISH
Radio
- Listening to the Radio -
Listening to the Radio
To receive an FM stereo transmission:
Press the TUNER (BAND) button to display the "ST" indicator.
z" " will appear when an FM broadcast is in stereo.
zIf the FM reception is weak, press the TUNER (BAND) button to extinguish the
"ST" indicator. The reception changes to monaural, and the sound becomes
clearer.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
1Press the ON/STAND-BY button to turn the power on.
2Press the TUNER (BAND) button repeatedly to select the desired
frequency band (FM or AM).
3Press the TUNING/TIME ( or ) button to tune in to the desired
station.
Manual tuning:
Press the TUNING/TIME button as many times as required to tune in to the de-
sired station.
Auto tuning:
When the TUNING/TIME button is pressed for more than 0.5 seconds, scanning
will start automatically andthe tuner willstop at the first receivable broadcast sta-
tion.
Notes:
zWhen radio interference occurs, auto scan tuning may stop automatically at
that point.
zAuto scan tuning will skip weak signal stations.
zTo stop the auto tuning, press the TUNING/TIME button again.
FM stereo mode indicator
FM stereo receiving indicator
Sound Control (See page 12.)

E-19 ENGLISH
Radio
- Listening to the Memorised Station -
Listening to the Memorised Station
„Memorising a station
You can store 40 AM and FM stations in memory and recall them at the push of a but-
ton. (Preset tuning)
Note:
The backup function protects the memorised stations for a few hours should there be
a power failure or the AC power lead disconnection.
„To recall a memorised station
„To scan the preset stations
The stations saved in memory can be scanned automatically. (Preset memory scan)
„To erase entire preset memory
1Perform the steps 1 - 3 in "Listening to the Radio" on page 18.
2Press the MEMORY/SET button to enter the preset tuning saving
mode.
3Within 30 seconds, press the PRESET ( or ) button to select the
preset channel number.
Store the stations in memory, in order, starting with preset channel 1.
4Within 30 seconds, press the MEMORY/SET button to store that
station in memory.
If the "MEMORY" and preset number indicators go out before the station is
memorised, repeat the operation from step 2.
5Repeat steps 1 - 4 to set other stations, or to change a preset sta-
tion.
When a new station is stored in memory, the station previously memorised will
be erased.
Press the PRESET ( or ) button for less than 0.5 seconds to select
the desired station.
Preset channel Frequency and frequency band
1Press the PRESET ( or ) button for more than 0.5 seconds.
The preset number will flash and the programmed stations will be tuned in se-
quentially, for 5 seconds each.
2Press the PRESET ( or ) button again when the desired station
is located.
1 Press the ON/STAND-BY button to enter the power stand-by mode.
2 Whilst pressing down the TUNER (BAND) button and the X-BASS/DEMO button,
press the ON/STAND-BY button until "TUNER CL" appears.
Listening to the Radio (See page 18.)
