Sharp CD-RW5000 User manual

– 1 –
CD-RW5000
CONTENTS Page
IMPORTANT SERVICE NOTES (FOR U.S.A. ONLY)...................................................................................................... 2
SPECIFICATIONS ............................................................................................................................................................ 2
NAMES OF PARTS .......................................................................................................................................................... 3
OPERATION MANUAL..................................................................................................................................................... 5
DISASSEMBLY................................................................................................................................................................. 8
REMOVING AND REINSTALLING THE MAIN PARTS.................................................................................................. 11
CD CHANGER MECHANISM MAIN BASE PARTS ASSEMBLING/ADJUSTING PROCEDURE ................................. 13
ADJUSTMENT................................................................................................................................................................ 20
TEST MODE ................................................................................................................................................................... 21
ERROR MESSAGE LIST................................................................................................................................................ 24
NOTES ON SCHEMATIC DIAGRAM ............................................................................................................................. 25
TYPES OF TRANSISTOR AND LED.............................................................................................................................. 25
BLOCK DIAGRAM .......................................................................................................................................................... 26
SCHEMATIC DIAGRAM ................................................................................................................................................. 32
WIRING SIDE OF P.W.BOARD...................................................................................................................................... 43
WAVEFORMS OF CD CIRCUIT..................................................................................................................................... 52
TROUBLESHOOTING .................................................................................................................................................... 53
FUNCTION TABLE OF IC .............................................................................................................................................. 56
LCD DISPLAY................................................................................................................................................................. 62
PARTS GUIDE/EXPLODED VIEW
PACKING OF THE SET (FOR U.S.A. ONLY)
SERVICE MANUAL
SHARP CORPORATION
No. S9071CDRW5000
• In the interests of user-safety the set should be restored to its original
condition and only parts identical to those specified should be used.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
CD-RW5000
CD-RW5000 Audio Tower System consisting of CD-RW5000 (main
unit) and CP-RW5000 (speaker system).
MODEL
AUDIO TOWER SYSTEM

CD-RW5000
– 2 –
IMPORTANT SERVICE NOTES (FOR U.S.A. ONLY)
BEFORE RETURNING THE AUDIO PRODUCT
(Fire & Shock Hazard)
Before returning the audio product to the user, perform the
following safety checks.
1. Inspect all lead dress to make certain that leads are not
pinchedorthathardwareisnotlodgedbetweenthechassis
and other metal parts in the audio product.
2. Inspect all protective devices such as insulating materials,
cabinet,terminalboard,adjustmentandcompartmentcovers
or shields, mechanical insulators etc.
3. To be sure that no shock hazard exists, check for leakage
current in the following manner.
* Plug the AC line cord directly into a 120 volt AC outlet.
* Using two clip leads, connect a 1.5k ohm, 10 watt resistor
paralleled by a 0.15µF capacitor in series with all exposed
metal cabinet parts and a known earth ground, such as
conduit or electrical ground connected to earth ground.
* Use a VTVM or VOM with 1000 ohm per volt, or higher,
sensitivity to measure the AC voltage drop across the
resistor (See diagram).
* Connect the resistor connection to all exposed metal parts
havingareturnpathtothechassis(antenna,metalcabinet,
screw heads, knobs and control shafts, escutcheon, etc.)
and measure the AC voltage drop across the resistor.
AlltestsmustberepeatedwiththeAClinecordplugconnection
reversed.
Anyreadingof0.3voltRMS(thiscorrespondsto 0.2 milliamp.
AC.) or more is excessive and indicates a potential shock
hazard which must be corrected before returning the audio
product to the owner.
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
AC SCALE
VTVM
1.5k ohms
10W
0.15µF
TEST PROBE
TO EXPOSED
METAL PARTS
CONNECT TO
KNOWN EARTH
GROUND
SPECIFICATIONS
CD-RW5000
Specifications for this model are subject to change
without prior notice.
■Cassette deck
Frequency response 50-14,000 Hz (Normal tape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.3 % (WRMS)
■Tuner
Frequency range FM: 87.5-108.0 MHz
AM: 530-1,720 kHz
■CD-R
Type 1-disc compact disc recorder/player
Signal readout Non-contact, 3-beam semiconductor laser pickup
Rotational speed 200-500 rpm CLV
Error correction CIRC (Cross Interleave Reed-Solomon Code)
Quantization 16-bit linear
Filter 64 fs digital interpolation filter
Frequency response 20 - 20,000 Hz
D/A converter 1-bit D/A converter
Dynamic range 90 dB (1 kHz) playback
84 dB (1 kHz) recording
■General
Power source AC 120 V, 60 Hz
Power consumption 200 W
Dimensions Width: 7-7/8" (200 mm)
Height: 13-7/8" (352 mm)
Depth: 14-7/8" (377 mm)
Weight 23.8 lbs (10.8 kg)
■Amplifier
Output power 100 watts minimum RMS into 6 ohms from 60 Hz to 20
kHz, 10 % total harmonic distortion
Subwoofer : 60 W/ch
(60 Hz - 200 Hz, 6 ohms, 10 % T.H.D.)
Main : 40 W/ch
(200 Hz - 20 kHz, 6 ohms, 10 % T.H.D.)
Output terminals Speakers: 6 ohms
Headphones: 16-50 ohms (recommended; 32 ohms)
Digital output (optical)
Input terminals Auxiliary: 500 mV/47 kohms
Phono: 2.5 mV (1 kHz)
Digital input (optical)
■CD player
Type 6-disc multi-play compact disc changer player
Signal readout Non-contact, 3-beam semiconductor laser pickup
D/A converter 1-bit D/A converter
Frequency response 20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Type 3-way type speaker system
2" (5 cm) Tweeter
5-1/4" (13 cm) Woofer
5-1/4" (13 cm) Subwoofer
Maximum input power (Total) 200 W
Rated input power (Total) 100 W
Impedance 6 ohms
Dimensions Width: 8-1/4" (210 mm)
Height: 15-7/16" (392 mm)
Depth: 13-9/16" (345 mm)
Weight 11.2 lbs. (5.1 kg)/each
CP-RW5000

– 3 –
CD-RW5000
NAMES OF PARTS
CD-RW5000
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
20
17
18
19
■ Front panel
01. Cassette Compartment
02. Volume Up/Demo Button
03. Volume Down Button
04. Timer Set Indicator
05. Power Button
06. CD Direct Play Buttons (with Indicator)/
CD Tray Eject Buttons
07. CD Trays
08. CD/CD-R/CD-RW Play Mode Select Button
09. CD-R/CD-RW Text Edit Button
10. Headphone Jack
11. CD-R/CD-RW Tray Eject Button
12. CD-R/CD-RW Tray
13. Control Panel Open/Close Button
14. Equalizer Mode Select Button
15. Extra Bass Button
16. Menu Button
17. Display/Character Button
18. Jog Dial
19. Enter Button
20. Delete Button
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
21. Tuner (Band) Button
22. CD-R/CD-RW Record Button
23. CD Button
24. CD Track Edit Button
25. CD-R Button
26. CD CD-R One Touch Edit Button
27. CD-R/CD-RW Finalize Button
28. CD/CD-R/CD-RW Fast Reverse, Tape Fast Wind
or Tuning Down Button (with Indicator)
29. Stop Button (with Indicator)
30. Tape Reverse Play Button (with Indicator)
31. Tape Button
32. CD-R/CD-RW Record Mode Button
33. Auxiliary Button
34. CD-R/CD-RW Record Speed Select Button
35. Erase Button
36. CD-R/CD-RW Auto Mark Button
37. Tape Record Pause Button
38. CD/CD-R/CD-RW Fast Forward, Tape Fast Wind
or Tuning Up Button (with Indicator)
39. CD/CD-R/CD-RW Play or Pause/
Tape Forward Play Button (with Indicator)
8
9
1
2
3
4
5
6
7
■Rear panel
01. AM Loop Antenna Terminal
02. Antenna Ground Terminal
03. FM Antenna Terminal
04. Auxiliary Input Jacks
05. Phono Input Jacks
06. Digital Input Jack
07. Digital Output Jack
08. Speaker Terminals
09. AC Power Cord

CD-RW5000
– 4 –
1
2
3
4
5
6
7
12
13
14
15
16
17
18
19
20 22 24 26
21 23 25
891011
■Multi-function LCD display
01. Function Indicator
02. Timer Play Indicator
03. FM Stereo Mode Indicator
04. FM Stereo Indicator
05. Extra Bass Indicator
06. Record Indicator
07. CD/CD-R/CD-RW Play Indicator
08. CD Indicators
09. Cassette Indicator
10. CD CD-R High Speed Record Indicator
11. CD-R/CD-RW Indicator
12. Auto Mark Indicator
13. Erase Indicator
14. Digital Source Indicator
15. Finalize Indicator
16. Memory Indicator
17. CD All Disc Play Indicator
18. Random Play Indicator
19. Music Schedule Indicator
20. Synchronized Recording Indicator
21. CD/CD-R/CD-RW Repeat Indicator
22. CD/CD-R/CD-RW Pause Indicator
23. Tape Reverse Mode Indicator
24. Sleep Indicator
25. Timer Recording Indicator
26. Character Information Display
■Remote control
01. Remote Control Transmitter
02. Power Button
03. CD-R Button
04. CD Button
05. CD/CD-R/CD-RW Play or Pause/Tape Play Button
06. Enter Button
07. CD/CD-R/CD-RW Fast Reverse, Tape Fast Wind
or Preset Down Button
08. Dimmer Button
09. CD-R/CD-RW Record Button
10. CD-R/CD-RW Record Mode Button
11. CD-R/CD-RW Finalize Button
12. Memory Button
13. Tape Reverse Mode Select Button
14. Control Panel Open/Close Button
15. Volume Up or Down Buttons
16. Tuner (Band) Button
17. Tape Button
18. Auxiliary Button
19. CD Direct Play Buttons
20. Menu Button
21. CD/CD-R/CD-RW Fast Forward, Tape Fast Wind
or Preset Up Button
22. Stop Button
23. Display Button
24. Tape Record Pause Button
25. CD/CD-R/CD-RW Play Mode Select Button
26. Clear Button
27. FM Stereo Mode Button
28. Equalizer Mode Select Button
29. Time Button
30. Extra Bass Button
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
1. Tweeter
4. Subwoofer
2. Woofer
5. Subwoofer Terminals
3. Bass Reflex Duct
6. Main Speaker Terminals
1
2
3
4
5
6
CP-RW5000
CD-RW5000

– 5 –
CD-RW5000
OPERATION MANUAL
To confirm the time display in the stand-by mode:
Press the DISPLAY button on the remote control. The time display will appear for
about 3 seconds.
Note:
“CLOCK” will appear or time will flash at the push of the DISPLAY button when the AC
power supply is restored after a power failure or after unplugging the unit.
Reset the clock as follows.
To reset the clock:
Perform “Setting the Clock” from the beginning.
At this time, step 5 (for selecting the 12-hour or 24-hour display) will be skipped.
To change the 12-hour or 24-hour display:
1. Clear all the programmed contents.
[Refer to “If trouble occurs (reset)” on page 44 for details.]
2. Perform “Setting the Clock” from the beginning.
Setting the Clock
In this example, the clock is set for the 12-hour (AM12:00) display.
1 Press the POWER button to turn the power on.
2 Press the MENU button.
3 Turn the jog dial to select “CLOCK” and within 10 seconds, press
the ENTER button.
4 Within 2 minutes, press the ENTER button again.
5 Turn the jog dial to select the 12-hour or 24-hour display and
within 2 minutes, press the ENTER button.
6 Turn the jog dial to adjust the hour and within 2 minutes, press
the ENTER button.
● When the 12-hour display is selected, “AM” will change automatically to “PM”.
7 Turn the jog dial to adjust the minutes and within 2minutes, press
the ENTER button.
● The hour will not advance even if minutes advance from “59” to “00”.
● The clock starts from “0” second. (Seconds are not displayed.)
The time display will disappear after a few seconds.
“AM 12:00”→The12-hourdisplay will appear.(AM 12:00 -PM 11:59)
“AM 0:00” →The12-hour display will appear.(AM0:00 - PM 11:59)
“0:00” →The 24-hour display will appear. (0:00 - 23:59)
■
Test of the remote control
Face the remote control directly to the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the POWER button. Does the power turn on? Now, you can enjoy the music.
8" - 20'
(0.2 m - 6 m)
Remote Control
Remote sensor
Troubleshooting Chart (continued)
■ If trouble occurs (reset)
When this product is subjected to strong external interference (mechanical shock, ex-
cessive static electricity, abnormal supply voltage due to lightning, etc.) or if it is oper-
ated incorrectly, it may malfunction.
If such a problem occurs, do the following:
1. Press the POWER button to enter the power stand-by mode.
2. While pressing down the VOLUME button, press the POWER button un-
til “ALL CLEAR” appears.
Caution:
This operation will erase all data stored in memory including clock and timer settings,
and tuner and CD presets.
■ Before transporting the unit
Remove the CD-R/CD-RW disc and all CDs from the unit. Your unit checks whether
there are any discs inside the unit when the tray is closed. “CDR NO DISC” and “CD
NO DISC” appear if no disc is left. Then, set the unit to the power stand-by mode.
Carrying the unit with discs left inside can damage it.
and

CD-RW5000
– 6 –
Accessories
Accesorios
Speaker wire for
MAIN terminals × 2
Cable del altavoz para
los terminales MAIN
× 2
AM loop antenna × 1
Antena de cuadro de AM × 1
Remote control × 1
Controlador remoto × 1
Blue
Azul
Black
Negro
CD-R × 1
CD-R × 1
1
1
Speaker wire for
SUBWOOFER terminals × 2
Cable del altavoz para los
terminales SUBWOOFER
× 2
Black
Negro
Red
Rojo
FM antenna × 1
Antena de FM × 1
1 2 3
Battery Installation of the Remote Control
Instalación de las pilas del controlador remoto
Use 2 “AA” size batteries (UM/SUM-3, R6, HP-7 or similar). Batteries are not included.
Use dos pilas del tamaño“AA” (UM/SUM-3, R6, HP-7 o equivalentes). Las pilas no están incluidas.
Open the Insert the batteries Close the cover.
battery cover.
as shown.
Abra la cubierta Inserte las pilas Cierre la cubierta
de las pilas. como se muestra. de las pilas.
2
2
System Connections
Conexiones del sistema
3
3
Turning on Your System
Conexión de la alimentación de su sistema
4
4
The first time the unit is plugged, the
unit will enter the demonstration
mode. You will see words scroll.
Cuando se enchufe por primera vez el
aparato, se establecerá en el modo de
demostración. Verá un desplazamiento
de palabras.
12
Press the DEMO
button to cancel
the demonstra-
tion mode.
Pulse el botón
DEMO para
cancelar el modo
de demostración.
Press the POWER
button to turn the
power on.
Pulse el botón POWER
para conectar la
alimentación.
FM antenna
Antena de FM
AM loop antenna
Antena de cuadro de AM
Right speaker
Altavoz derecho
Left speaker
Altavoz izquierdo
Blue
Azul
Red
Rojo
Black
Negro
Right speaker
Altavoz derecho
Left speaker
Altavoz izquierdo
AC outlet
(AC 120 V, 60 Hz)
A un tomacorriente de
CA (120 V de CA, 60 Hz)
Listening to a CD (CDs)
Audición de un disco CD (CDs)
1
Press the CD button.
Pulse el botón CD.
2
Press the DISC 1 button to open the disc tray 1.
Pulse el botón DISC 1 para abrir la bandeja del disco 1.
3
Place the CD on the disc tray 1, label side up.
Coloque el disco compacto en la bandeja del disco 1, con el lado de la etiqueta
hacia arriba.
4
Press the DISC 1 button to close the disc tray 1.
Pulse el botón DISC 1 para cerrar la bandeja del disco 1.
5
You can place discs on the trays 2 - 6 by following the steps 2 - 4.
Podrá colocar discos en las bandejas 2 - 6 según los pasos 2 - 4.
6
Press the button to start playback.
Pulse el botón para iniciar la reproducción.
Total playing time
Tiempo total de reproducción
Means “disc inside ”
Significa “disco dentro”
DISC 1
5” (12 cm)
5” (12 cm)
3” (8 cm)
3” (8 cm)
Total number of tracks
Número total de pistas
DISC 1
DISC 1
Listening to a Cassette Tape
Audición de una cinta cassette
1
Press the TAPE button.
Pulse el botón TAPE.
2
Open the cassette door by pushing the area marked “PUSH EJECT ”.
Abra la puerta del cassette pulsando la parte marcada “PUSH EJECT ”.
PUSH EJECT
3
Load the cassette into the compartment with side A facing you.
Cargue el cassette en el compartimiento con la cara A encarada hacia usted.
4
Press the REV. MODE button to choose one side or both side.
Pulse el botón REV. MODE para seleccionar una cara o ambas caras.
5
Press the button to listen to side A, or the button for side B.
Pulse el botón para escuchar la cara A, o el botón para la cara B.
... To listen to both sides.
Para escuchar ambas caras.
... For endless repeat play of both sides.
Para repetir indefinidamente ambas caras.
... To listen to one side.
Para escuchar una cara.

– 7 –
CD-RW5000
Listening to the Radio
Audición de la radio
1
Press the TUNER (BAND) button to select the desired frequency band (FM
or AM).
PulseelbotónTUNER(BAND)para seleccionar la banda defrecuenciadeseada
(FM o AM).
2
Press the TUNING ( or ) button to tune into the desired station.
When the TUNING button is pressed for more than 0.5 seconds, scanning will start
automatically and the tuner will stop at the first receivable broadcast station.
Pulse el botón TUNING ( o ) para sintonizar la emisora deseada.
Cuando se pulse el botón TUNING durante más de 0,5 segundos, la exploración se
iniciará automáticamente y el sintonizador se parará en la primera emisora difusora que
pueda recibirse.
3
To receive an FM stereo transmission, press the ST-MODE button on the
remote control. The “ST” indicator lights up.
“ ” will appear when an FM broadcast is in stereo.
Para recibir la transmisión de FM en estéreo, pulse el botón ST-MODE del
controlador remoto. Se enciende el indicador “ST”.
“ ” aparecerá cuando una difusión de FM sea en estéreo.
Recording to a Cassette Tape
Grabación en una cinta cassette
1
Press the CD button and load the desired disc.
Pulse el botón CD y cargue el disco deseado.
2
Load a cassette into the compartment with side A facing you.
Cargue un cassette en el compartimiento con la cara A encarada hacia usted.
3
Press the REV. MODE button to choose one side or both side.
Pulse el botón REV. MODE para seleccionar de una cara o ambas caras.
4
Press the TAPE REC button repeatedly to switch to the side you record
on.
Pulse repetidamente el botón TAPE REC para cambiar a la cara que grabe.
5
Press one of the DISC 1 - DISC 6 buttons to start recording.
Pulse uno de los botones DISC-1 a DISC 6 para iniciar la grabación.
... To record on both sides.
Para grabar en ambas caras.
... To record on only one side.
Para grabar sólo en una cara.
■
Playable discs
Discos que pueden reproducirse
This player is compatible with CD-R discs, CD-RW discs, and audio CDs with either mark below.
Este reproductor es compatible con discos CD-R, discos CD-RW, y discos compactos de audio con
cualquiera de las dos marcas de abajo.
■
Differences between the CD-R disc and the CD-RW disc
Diferencias entre el disco CD-R y el disco CD-RW
What is CD-R or CD-RW?
¿Qué es CD-R o CD-RW?
Playback
Reproducción
Erasing
Borrado
CD-R
Can be played on a standard CD player
when it is finalized after recording.
Se puede reproducir en un reproductor de
CD estándar cuando se finaliza después
de la grabación.
Erasing is impossible.
El borrado es imposible.
CD-RW
Cannot be played on a standard CD
player.
If it is finalized after recording, it can
be played only on a CD-RW compatible
player.
Nosepuedereproducirenun reproductor
deCDestándar.Sise finaliza después de
la grabación, se puede reproducir sólo en
unreproductor compatible condiscos CD-
RW.
Recorded tracks can be deleted.
A finalized disc can be restored.
Se pueden borrar pistas grabadas.
Se puede restaurar un disco finalizado.
CD-R: Compact Disc-Recordable
CD-R: Disco compacto grabable
CD-RW: Compact Disc-ReWritable
CD-RW: Disco compacto regrabable
Recording to a CD-R or a CD-RW
Grabación en un CD-R o en un CD-RW
1
Press the CD button and load the desired CD(s).
Pulse el botón CD y cargue el disco deseado (los discos deseados).
2
Load the CD-R or CD-RW disc.
Cargue el disco CD-R o CD-RW.
3
Press the REC MODE button and select the desired CD using the jog dial.
Within 10 seconds, press the ENTER button.
Pulse el botón REC MODE y seleccione el disco compacto deseado empleando el
mando de lanzadera. Antes de transcurrir 10 segundos, pulse el botón ENTER.
In steps 4 - 6, operate within 5 seconds. Otherwise, the system will go to the next step automatically.
En los pasos 4 – 6, opere antes de 5 segundos. De lo contrario, el sistema pasará al paso siguiente automáticamente.
4 Press the CD CDR button.
Pulse el botón CD CDR.
5
Select “AUTO” using the jog dial to finalize the disc. Then press the EN-
TER button.
Seleccione “AUTO” empleando el mando de lanzadera para finalizar el disco.
Entonces, pulse el botón ENTER.
6
Select “HIGH” using the jog dial to record at high speed. Then press the
ENTER button to start recording.
Seleccione “HIGH” empleando el mando de lanzadera para grabar a alta
velocidad. Luego, pulse el botón ENTER para iniciar la grabación.

CD-RW5000
– 8 –
1 Top Cabinet 1. Screw ................ (A1) x5 8-1
2 Side Panel (Left/Right) 1. Screw ................ (B1) x8 8-1
3 Rear Panel 1. Screw ................ (C1) x3 8-2
2. Screw ................ (C2) x10
4 Front Panel 1. Flat Cable.......... (D1) x1 8-2
2. Screw ................ (D2) x4
3. Socket ............... (D3) x6
5 Sub Trans PWB 1. Screw ................ (E1) x3 8-2
2. Socket ............... (E2) x5
6 Main PWB 1. Flat Cable.......... (F1) x1 8-2
2. Screw ................ (F2) x2
3. Screw ................ (F3) x1
4. Socket ............... (F4) x3
5. Flat Cable.......... (F5) x2
7 CD-R Unit 1. Socket ............... (G1) x1 9-1
2. Screw ................ (G2) x4
8 Power PWB/ 1. Socket ............... (H1) x1 9-1
Speaker PWB 2. Screw ................ (H2) x2
9 Tape Mechanism 1. Open the cassette holder 9-2
2. Screw ................ (J1) x4
10 CD Switch PWB/ 1. Socket ............... (K1) x1 9-2
CD-R PWB 2. Screw ................ (K2) x7
3. Hook .................. (K3) x2
11 Switch PWB 1. Screw ................ (L1) x1 9-2
12 Headphones PWB 1. Screw ................ (M1) x1 9-2
2. Bracket .............. (M2) x1
13 CD Changer door 1. Screw ................ (P1) x3 9-2
panel/ 2. Screw ................ (P2) x2
Control Panel
14 Motor PWB 1. Solder................ (Q1) x2 9-2
15 CD Changer door 1. Screw ................ (R1) x4 9-3
panel
16 Control Panel 1. Screw ................ (S1) x6 9-3
17 Control PWB 1. Screw ................ (T1) x5 9-4
2. Socket ............... (T2) x1
18 Jog PWB 1. Screw ................ (U1) x5 9-4
19 LED B PWB 1. Screw ................ (V1) x3 9-4
20 Cassette holder 1. Open the cassette holder Cover 9-5
Cover 2. Screw ................ (W1) x4
3. Display Panel .... (W2) x1
4. Hook .................. (W3) x4
21 Display PWB/ 1. Screw ................ (X1) x4 9-6
LED A PWB 2. Hook .................. (X2) x2
DISASSEMBLY
Figure 8-2
STEP REMOVAL PROCEDURE FIGURE
Figure 8-1
CD-RW5000
CD-RW5000
Caution on Disassembly
Follow the below-mentioned notes when disassembling
the unit and reassembling it, to keep it safe and ensure
excellent performance:
1. Take cassette tape and compact disc out of the unit.
2. Be sure to remove the power supply plug from the wall
outlet before starting to disassemble the unit.
3.Take offnylon bands orwire holderswhere they needto
beremovedwhendisassemblingtheunit.Afterservicing
theunit, be sure to rearrangethe leads wherethey were
before disassembling.
4. Take sufficient care on static electricity of integrated
circuits and other circuits when servicing.
Front Panel Top Cabinet
Side Panel(Right)
Side Panel
(Left)
Rear Panel
(B1)x4
ø3x10mm
(A1)x2
ø3x16mm
(B1)x4
ø3x10mm
(A1)x1
ø3x10mm
(A1)x2
ø3x16mm
(C2)x10
ø3x10mm
Main PWB
Front Panel
Tape Mechanism PWB
(D3)x2
Speaker
PWB
(C1)x1
ø3x10mm
(F2)x2
ø3x10mm
(C1)x2
ø3x10mm
Rear
Panel
(D2)x2
ø3x8mm
(F3)x1
ø3x8mm
(F4)x1
(F1)x1
(D1)x1
CD PWB
Power PWB
(D2)x1
ø3x8mm
(E1)x3
ø3x8mm
CD-R Unit
(E2)x3
(F4)x2
Power PWB
Main PWB
Sub Trans
PWB
Speaker
PWB
(D2)x1
ø3x8mm
(D3)x4
(F5)x2
(E2)x2

– 9 –
CD-RW5000
Figure 9-1
Figure 9-2
Figure 9-3
Figure 9-4
Figure 9-5
Figure 9-6
(H2)x1
ø3x10mm
(G2)x2
ø3x8mm
(G2)x2
ø3x8mm
(H2)x1
ø3x10mm
(H1)x1
Power PWB
Speaker
PWB
(G1)x1
CD Changer
Block
Main
Chassis
CD-R Unit
(W1)x4
ø2.6x12mm
Front Panel
(W2)x1
(W3)x4
Open Cassette
Holder Cover
(K2)x6
ø3x10mm
(P2)x1
ø3x20mm
(J1)x4
ø3x10mm
(K2)x1
ø3x10mm
Tape
Mechanism
Front Panel Cassette
HolderOpen
(K1)x1
(K3)x1
(K3)x1
Switch PWB
Headphones
PWB
(M2)x1
(P1)x3
ø3x10mm
(L1)x1
ø2.6x10mm(M1)x1
ø3x10mm
CD Changer
Door Panel
Motor
PWB
(Q1)x2
CD Switch
PWB
(P2)x1
ø3x20mm
CD-R PWB
(S1)x2
ø2.6x12mm
(R1)x1
ø2.6x10mm
(R1)x1
ø2.6x10mm
(R1)x2
ø2.6x10mm
(S1)x2
ø2.6x12mm
(S1)x2
ø2.6x12mm
CD Changer
Door Panel
Control Panel
(T1)x5
ø2.6x10mm
(T2)x1
(V1)x2
ø2.6x10mm
(V1)x1
ø2.6x10mm
(U1)x5
ø2.6x10mm
Control Panel B
Control PWB
Control Panel A
LED B PWB
LED Holder
Jog PWB
(X1)x4
ø3x14mm
(X2)x1
LED A
PWB
Cassette
Holder Cover
Display
PWB
(X2)x1

CD-RW5000
– 10 –
Figure 10-1
1 Woofer/Tweeter/ 1. Net................... (A1) x1 10-3
Sub Woofer 2. Front Panel ..... (A2) x1
3. Screw .............. (A3) x4 10-4
4. Ring ................. (A4) x1
5. Catching holder(A5) x2
6. Screw .............. (A6) x2
7. Cover............... (A7) x1
8. Screw .............. (A8) x2
9. Screw .............. (A9) x4 10-5
10. Cover............. (A10) x10
STEP REMOVAL PROCEDURE FIGURE
CP-RW5000
Figure 10-2
Figure 10-3
Figure 10-4
Figure 10-5
Top Side
Rear Side
Sub Woofer
(A10)x1
(A9)x4
ø4x20mm
Speaker Box
Driver should
be pried away
from Speaker Box.
Screw Driver
(A1)x1
(A2)x1
Speaker Box Bottom Side
(A3)x4
ø4x16mm (A4)x1 Woofer
Speaker Box
Tweeter
(A5)x2
(A7)x1
(A6)x2
ø3x10mm
(A8)x2
ø3x10mm
1 Top Cabinet 1. Screw ................ (A1) x5 8-1
2 Side Panel (Left/Right) 1. Screw ................ (B1) x8 8-1
3 Rear Panel 1. Screw ................ (C1) x3 8-2
2. Screw ................ (C2) x10
4 Front Panel 1. Flat Cable.......... (D1) x1 8-2
2. Screw ................ (D2) x4
3. Socket ............... (D3) x6
5 CD Changer 1. Flat Cable.......... (Y1) x1 10-1
Mechanism 2. Screw ................ (Y2) x2
3. Screw ................ (Y3) x5
6 CD PWB 1. Screw ................ (Z1) x4 10-2
(Note) 2. Socket ............... (Z2) x4
3. Flat Wire............ (Z3) x2
7 CD Mechanism 1. Screw ................ (ZZ1) x4 10-2
STEP REMOVAL PROCEDURE FIGURE
CD-RW5000 (CD CHANGER MECHANISM UNIT)
Note:
After removing the connector for the optical pickup from the
connector, wrap the conductive aluminium foil around the
front end of connector remove to protect the optical pickup
from electrostatic damage.
(Z1)x4
ø3x10mm (Z3)x1
(Z2)x1
(Z2)x1
(Z3)x1
(Z2)x2
(ZZ1)x4
ø2.6x10mm
CD PWB
CD Changer
Mechanism
CD Mechanism
(Y3)x3
ø3x10mm
(Y2)x1
ø3x10mm
Bottom Side
Slide it in the direction of the arrow
after removing the screw (Y2).
Front Side
(Y2)x1
ø3x10mm
(Y3)x2
ø3x10mm Main Chassis
CD PWB
(Y1)x1
CD Changer
Mechanism

– 11 –
CD-RW5000
Figure 11-1
Figure 11-2
Figure 11-3
Figure 11-4
REMOVING AND REINSTALLING THE MAIN PARTS
TAPE MECHANISM SECTION
Perform steps 1 to 4 and 8 of the disassembly method to
remove the tape mechanism.
How to remove the record/playback and erase
heads (See Fig. 11-1)
1. When you remove the screws (A1) x 2 pcs., the recording/
playback head and three-dimensional head of the erasing
head can be removesd.
How to remove the pinch roller (Left/Right)
(See Fig. 11-2)
1. Carefully bend the pinch roller pawl in the direction of the
arrow <A>, and remove the pinch roller (B1) x1 pc., in the
direction of the arrow <B>.
Note:
When installing the pinch roller, pay attention to the spring
mounting position.
How to remove the belt (See Fig. 11-3)
1. Remove the motor.
2. Remove the main belt (C1) x 1 pc., from the motor side.
3. Remove the FF/REW belt (C2) x 1 pc.
How to remove the motor (See Fig. 11-4)
1. Remove the belt.
2. Remove the screws (D1) x 2 pcs., to remove the motor.
(D1)x2
Ø 2.6 x 5mm
Motor
Pinch
Roller
(B1)x1 <A>
Pinch
Roller
Pawl
Pull
<B>
Pull
(Left)
<A>
Pinch
Roller
Pawl
Pull
<B> Pull
(Right)
Main Belt
(C1)x1
FF/REW Belt
(C2)x1
Motor
Figure 11-5
How to remove the control panel motor
(See Fig. 11-5)
1. Remove the control panel.
2.Removethescrews(E1)x6pcs.,toremovetheCDchanger
door panel.
3. Remove the screws (F1) x 2 pcs., to remove the control
panel motor.
FRONT PANEL SECTION
Performsteps1to4ofthedisassemblymethodtoremovethe
front panel.
CD Changer
Door Panel CD Changer
Door Panel
Control
Panel
Motor
Gear Box A
(E1)x1
ø2.6x10mm
(E1)x3
ø2.6x10mm
(E1)x2
ø2.6x10mm
(F1)x2
ø2x5mm
Motor PWB
Gear Box B
Control Panel
(A1)x2
Ø2 x 6mm
Record/
Playback
Head
Erase
Head

CD-RW5000
– 12 –
CD MECHANISM SECTION
Performsteps1to7ofthedisassemblymethodtoremovethe
CD mechanism. (See page 10.)
Note:
After removing the connector for the optical pickup from the
connector, wrap the conductive aluminium foil around the
front end of connector remove to protect the optical pickup
from electrostatic damage.
How to Remove the pickup (See Fig. 12-1.)
1. Remove the screws (A1)x 2 pcs., to remove shaft (A2)x 1
pc.
2.Removestopwasher(A3)x1pc.,toremovegear(A4)x1pc.
3. Remove the pickup.
Figure 12-1
Figure 12-2
How to Remove the tray motor/main cam motor
(See Fig. 12-2.)
1. Remove the screws (B1)x 4 pcs., to remove the CD PWB.
2.Removethe(1)fronttopplate,(2)changerbox,left/rightand
(3)disc trays 1~6. After that, disassemble as shown in the
figure.
3. Remove the screws (B2)x 4 pcs.
4. Remove the tray motor and main cam motor.
CD CHANGER MECHANISM SECTION
Performsteps1to5ofthedisassemblymethodtoremovethe
CD changer mechanism. (See page 10.)
Note:
The parts of (1), (2) and (3) correspond to the drawing Nos.
117, 102, 103 and 108 to 113 of the CD change mechanism
disassembly drawing.
Remove the screws of 117, 102 and 103, and the parts of (1),
(2)and (3)will beready forremoval andthe screws of the tray
motor and main cam motor will be visible.
Main Cam Motor
Tray Motor
CD PWB
(1)Front Top Plate
(2)Changer Box,
Left
(2)Changer Box,
Right
(3)Disc Tray,1~6
CD Changer Mechanism
(B1)x4
ø3x10mm
(B2)x4
ø2.6x4mm
CD-R UNIT SERVICE PARTS
(A1) x1
ø2.6 x6mm
CD
Mechanism
Stop Washer
(A3) x1
Gear
(A4) x1
Shaft
(A2) x1
Pickup
(A1) x1
ø2.6 x6mm
Figure 12-3
NO. Parts Code Part Name
RUNTZ0022AWZZ CD-R Unit Ass’y
1 GCOVA1336AWSA CD-R Tray
2 NBLTK0038AWZZ CD-R Loading Belt
3 92LMTR3438AASY Tray Motor Ass’y
4 QSW-F9007AWZZ Tray Switch
5 LHLDZ1308AWSA Clamper Bridge
6 LHLDZ3020AWZZ Clamper
1. CD-R Tray
2. CD-R Loading Belt
3. Tray Motor Ass'y
4. Tray Switch
5. Clamper Bridge
6. Clamper

– 13 –
CD-RW5000
1. Motor assembly (x 2) mounting (screw x 4) 101/129 Fig.14
2. MT idle gear mounting (screw x 1) 125 Fig.14
3. MT system gear assembly 123/124/126/127 Fig.14
4. STB/tray drive system gear and others assembling/ 137/138/145/146 (153)/147/148 Fig.14
mounting (screw x 3)
5. Tray big gear assembly 131 Fig.14 Gear positioning
6. T.M SW PWB mounting (screw x 3) Fig.15
7. STB holder assembling 103 Fig.14
8. STB drive gear L/R assembly mounting (screw x 2) 111 (110)/112 (110) Fig.14
9. Tray joint gear R/tray drive gear R assembling 134/136 Fig.15 Gear positioning
10. Tray gear A/B assembling 132/133 Fig.15 Gear positioning
11. Lift gear B/C assembling 143/144 Fig.16 Gear positioning
12. MT idler gear F assembling, mode big gear 128/142 Fig.16
mounting (screw x 1)
13. Change box R mounting (screw x 4) 104 Fig.16
14. Lift gear A assembling 142 Fig.16 Gear positioning
15. Change box L assembly mounting (screw x 4) 102/130/135 Fig.17
16. Lift cam assembling (shaft inserting) 144 Fig.17 Gear positioning
17. STB holder height adjusting Fig.18 Check/adjustment
18. Top plate F/disc OB LEV. mounting (screw x 6) 180 Fig.18
19. Trays 1 - 6 assembling 191/192/193/194/195/196 Fig.19
20. Top plate R mounting (screw x 6) -
Applied part No.
Work content Assembly fig. No. Remarks
CD CHANGER MECHANISM MAIN BASE PARTS ASSEMBLING/ADJUSTING
PROCEDURE
101 MAIN BASE
102 CHANGE BOX L
103 STB HOLDER
104 CHANGE BOX R
110 STB DRIVE GEAR A
111 STB DRIVE GEAR L
112 STB DRIVE GEAR R
120 STABILIZER FH
123 MT IDLER GEAR A
124 MT IDLER GEAR B
125 MT IDLER GEAR C
126 MT IDLER GEAR D
127 MT IDLER GEAR E
128 MT IDLER GEAR F
129 MOTOR GEAR
130 TRAY DRIVE GEAR F
131 TRAY BIG GEAR
132 TRAY GEAR A
133 TRAY GEAR B
134 TRAY DRIVE GEAR R
135 TRAY JOINT GEAR F
136 TRAY JOINT GEAR R
137 TRAY GEAR C
138 TRAY IDLER GEAR
Part name
No.
140 LIFT CAM
141 MODE BIG GEAR
142 LIFT GEAR A
143 LIFT GEAR B
144 LIFT GEAR C
145 STB GEAR A
146 STB GEAR B
147 STB GEAR C
148 STB GEAR D
150 LIFT LEVER
151 TRAY LOCK LEVER
152 DISC OB LEVER
153 STB GEAR ANG.
180 TOP PLATE F
181 TOP PLATE R
191 TRAY 1
192 TRAY 2
193 TRAY 3
194 TRAY 4
195 TRAY 5
196 TRAY 6
Part nameNo.
CD CHANGER MECHANISM PARTS LIST

CD-RW5000
– 14 –
Figure 14
131
TRAY BIG GEAR
131
TRAY BIG GEAR
137
TRAY GEAR C
138
TRAY IDLER GEAR
137
TRAY GEAR C
138
TRAY IDLER GEAR
147
STB GEAR C
147
STB GEAR C
146
STB GEAR B
146
STB GEAR B
110
STB DRIVE GEAR A
129
101
MAIN BASE
129 123
123
124
125
126
127
Mark position
103
STB HOLDER
148
STB GEAR D
112
STB DRIVE GEAR R
(ASSY)
111
STB DRIVE GEAR L
(ASSY)
111(/112) (110)
STB DRIVE GEAR L(/R)
(ASSY)
110
STB DRIVE GEAR A
145
STB GEAR A
145
STB GEAR A
153
STB GEAR ANG.
153
STB GEAR ANG.
After assembling TRAY BIG GEAR, turn it in the arrow direction.
TRAY BIG GEAR ASSEMBLING POSITION

– 15 –
CD-RW5000
Figure 15
131
M T SW PWB
133
TRAY
GEAR B
132
TRAY GEAR A
133
TRAY GEAR B
137
132
TRAY GEAR A
138
134
TRAY DRIVE GEAR R
136
TRAY JOINT GEAR R
147
146
134
TRAY DRIVE GEAR R
136
TRAY JOINT GEAR R
110
129
129 123
123
124
125
126
127 Mark position
111
145
TRAY BIG GEAR SET POSITION
133
132
Direct the recess part
(trapezoidal side) of the axis
135 in this direction.
* This position becomes the
reference (stock) position
of the tray.
These holes must align.
It must not rotate in contact
with the peripheral (hatched)
part of 131.
These holes must align.
After assembling 132,
assemble 133.
*1: To position the axis part of 136, engage it with 138.
*2: When it is aligned as described in *1, the hatched part
(low gear-height part of gear) will be positioned in this position.
Note: After positioning the tray big gear in the set position, engage these gears.
*1
*2
Scale: 2 magnifications
Scale: 2 magnifications

CD-RW5000
– 16 –
Figure 16
143
LIFT GEAR B
141
MODE BIG GEAR
133
132
104
CHANGE BOX R
147
146
128
MT IDLER GEAR F
110
Mark position
111
145
142
LIFT GEAR A
153
137
138
144
LIFT GEAR C
134
136
(A) (B)
144
LIFT GEAR C
143
LIFT GEAR B
142
LIFT GEAR A
141
MODE BIG GEAR
Note
(Assemble the mode big gear in this position.)
To assemble the mode
big gear, incline it,
bring it into contact with
the circumference and
put the center hole into
position since the
hatched part of the main
base is overlapped with
the circumference.
Direct the short tooth
toward the center.
MODE BIG GEAR
LIFT GEAR A/B/C
ASSEMBLING POSITION
Scale: 2 magnifications
Scale: 2 magnifications
<Assembling method of lift gear>
After setting up the mode big gear in the
shown position, engage it with the STB gear A
(gear on the lower side) at the position (A),
and assemble them, turning it in the arrow direction
into the position (B). (The short tooth directs toward the
center of the mode big gear.)
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,

– 17 –
CD-RW5000
Figure 17
143 144
141
133
132
147
146
128
110
Mark position
111
145
142
LIFT GEAR A
130
TRAY DRIVE GEAR F
135
TRAY JOINT GEAR F
135
TRAY JOINT GEAR F
102
CHANGE BOX L
*1
130
TRAY DRIVE GEAR F
140
LIFT CAM
140
LIFT CAM
130
TRAY DRIVE GEAR F
135
TRAY JOINT GEAR F
37°
*2
TRAY JOINT GEAR F
(CHANGE BOX L ASS'Y) ASSEMBLING POSITION
LIFT CAM
Direct the recess part (trapezoidal side)
of the axis 135 in this direction.
Assembling procedure
1. Turn the mode big gear approx. 37 degrees in the arrow direction.
2. Assemble the change box L ass'y.
Note: At this time, the tray joint gear F must be located in the position shown in figure.
Moreover, the gear must be engaged securely.
3. After assembly, return the mode big gear to the initial position.
4. Assemble the lift cam.
Note: At this time, the lift cam (No.140) must be located in the position shown in figure 17.
Scale: 2 magnifications
*1: To position the axis part
of 135, engage it with 133.
*2: When it is aligned as
described in *1, the hatched part
(low gear-height part of gear)
will be positioned as shown.
Since this gear engagement is not
visually checked, verify that it does
not float when the gear box L is installed.
Scale: 2 magnifications
During assembly, make the
O part visible in this direction.
Note: Among 4 ribs on the
circumference, one rib alone
is provided with O.

CD-RW5000
– 18 –
Figure 18
143
141
133
132
147
146
110
Mark position
111
145
142
LIFT GEAR A
130
135
140
180
TOP PLATE F
180
TOP PLATE F
240
OS LEVER
140
144
130
135
,,
,,
,,
,,
,,
,,
,,
When the height of
STB holder is low,
(Increase the clearance.)
Bend this part.
When the height of
STB holder is high,
(Decrease the clearance.)
Scale: 2 magnifications Details Bend this part to adjust the height of the STB holder.
Adjusting procedure
1. Turn the mode big gear approx. 37 degrees in the arrow direction.
2. Viewing from the front side of the mechanism, verify that the guide ribs
(CHANGE BOX L/R and STB HOLDER)of tray are as tall as each other.
3. If they are not, bend the lever for adjustment. (Refer to the details.)
Note: Also apply the same adjustment on the R side.
Height of the rib
37°
STB HOLDER HEIGHT ADJUSTING METHOD

– 19 –
CD-RW5000
Measure to be taken when a disc cannot be removed due to a mechanism trouble
First, remove the mechanism unit section from the set, and check for the state of the disc.
(Remove the top plate R if necessary.)
<State of the disc>
(1) When the disc is in the normal PLAY (chucking) position -> Try to eject the disc by turning the mode big gear/tray big gear
manually.
* At this time, be sure to adjust the tray's position (height).
(2) When the disc is in the normal STOCK position -> Try to eject the disc by turning the tray big gear manually.
* At this time, be sure to adjust the tray's position (height).
(3) When the disc is not in the normal position -> The tray or disc is not in the normal position. (The tray or disc may catch
somewhere.)
Remove the TOP PLATE F/DISC OB lever.
Unlock the tray lock lever and pull out the tray which is not caught.
Move the caught tray or disc and remove the disc.
In case of (1) and (2), the mechanism is normal (defective circuit parts, etc.). However, it may stop somewhere.
This is the reason why you should try to turn the tray big gear first.
In case of (3), either of the big gears does not turn.
Figure 19
143
141
133
132
191~196
TRAY1~TRAY6
147
146
110
Mark position
111
145
142
LIFT GEAR A
130
135
140
140
144
130
135
,,,,
,,,,
,,,,
,,
,,
,,
Insert it along the guide of
the change box.
TRAY 6
TRAY 5
TRAY 4
TRAY 3
TRAY 2
TRAY 1
TRAY No.1~6
Be sure to assemble the tray into this position.
Tray installing method: (After adjusting the height of the STB holder)
1. Turn the mode big gear to the mark position to lower the STB holder to the bottom area.
2. From the front side, install the tray. (Securely insert it to the lock position.)
Rear surface: Stamped.
Note: During insertion,
Do not accidentally rearrange
tray numbers.
Rear side

CD-RW5000
– 20 –
MECHANISM SECTION
• Driving Force Check
Torque Meter Specified Value
Play: TW-2412 Over 80 g
• Torque Check
Torque Meter
Play: TW-2111 30 to 60 g. cm
Fast forward: TW-2231 60 to 120 g.cm
Rewind: TW-2231 60 to 120 g.cm
Specified
Value
Adjusting
Point Instrument
Connection
Test Tape
ADJUSTMENT
Specified Value
• Tape Speed
TUNER SECTION
Figure 20-2 ADJUSTMENT POINTS
MTT-111 Variable resistor 3,000 ±90 Hz Speaker
in motor terminal
*1. Input: Antenna Output: Speaker Terminal
*2. Input: Antenna Output: TP301
Frequency Frequency Display Setting/
Adjusting
Parts
Instrument
Connection
AM IF 450 kHz 1,720 kHz T351 *1
AM Band — 530 kHz (fL): T306 *2
Coverage 1.1 ±0.1 V
AM 990 kHz 990 kHz T302 *1
Tracking
fL: Low-range frequency
fH: High-range frequency
Signal generator: 400 Hz, 30%, AM modulated
• AM IF/RF
• FM RF
Signal generator: 1 kHz, 75 kHz dev., FM modulated
FM Band — 87.50 MHz (fL): T311 *1
Coverage 1.3 ±50mV
FM RF 98.00 MHz 98.0 MHz L312 *2
(10~30 dB)
Test Stage Frequency Frequency
Display Setting/
Adjusting
Parts
Instrument
Connection
*1. Input: Antenna Output: TP301
*2. Input: Antenna Output: Speaker Terminal
Figure 20-1 ADJUSTMENT POINT
Type
1. 33 Pin extension QCNWN6931AFZZ
flat cable, 500mm
Part No.
Extension cable
Figure 20-3
IC303
IC302
BI960
IC301
1
1
12
13
24
19
AM
FM
GND
CF352
T306
T302
T311
L312
BF301
MAIN PWB
FM Mute
Level
AM IF
TP301
SO301
ANTENNA
TERMINAL
AM
Tracking AM Band
Coverage fL
FM Band
Coverage fL
FM RF
FM IF
VR351
T351
T312
R345
SO301
CNP1
CD PWB-C
33
33
1
1
33
1
CNP901
33 1
33Pin extension flat cable
QCNWN6931AFZZ
MAIN PWB-A
Adjusting
Parts
Display
Frequency
• FM Mute Level (FM ST MODE)
Signal generator: 1 kHz, 40 kHz dev., FM modulated
*1. Adjust so that an output signal appears.
98.00 MHz 98.00 MHz VR351*1 Input:SO301
(26 dBµV) Output: Speaker
Terminal
Instrument
Connection
TAPE MECHANISM
Variable
Resistor
in motor
Tape motor
