CMS-R600X/R600XT
SERVICE MANUAL
No. S8644CMSR600X
SHARP CORPORATION
• SRS technology Licensed from SRS Labe. SRS technology holds
the follwing patents: U.S. Patent No. 4,748,669, U.S. Patent No.
4,841,572 and U.S. Patent No. 4,866,774.
• SRS the SRS Logo ( ) and the SOUND RETRIEVAL SYSTEM
are registered trademarks of SRS Labs, Inc.
• In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified
should be used.
CMS-R600X(BK)
CMS-R600XT(BK)
Illustration: CMS-R600X(BK)
Page
SPECIFICATIONS ............................................................................................................................................................. 2
VOLTAGE SELECTION..................................................................................................................................................... 2
NAMES OF PARTS ........................................................................................................................................................... 3
OPERATION MANUAL...................................................................................................................................................... 5
DISASSEMBLY.................................................................................................................................................................. 6
REMOVING AND REINSTALLING THE MAIN PARTS..................................................................................................... 8
ADJUSTMENT................................................................................................................................................................. 10
NOTES ON SCHEMATIC DIAGRAM .............................................................................................................................. 12
TYPES OF TRANSISTOR AND LED .............................................................................................................................. 12
BLOCK DIAGRAM ........................................................................................................................................................... 13
SCHEMATIC DIAGRAM / WIRING SIDE OF P.W.BOARD............................................................................................. 16
WAVEFORMS OF CD CIRCUIT...................................................................................................................................... 36
LCD DISPLAY.................................................................................................................................................................. 37
TROUBLESHOOTING (CD SECTION) ........................................................................................................................... 38
FUNCTION TABLE OF IC ............................................................................................................................................... 42
REPLACEMENT PARTS LIST/EXPLODED VIEW
CONTENTS
DIFFERENCE BETWEEN CMS-R600X(BK) AND CMS-R600XT(BK)
CMS-R600XT(BK)CMS-R600X(BK)
POWER AC 110/127/220/230-240 V, AC 220 V, 50 Hz
SOURCE 50/60 Hz
SPEAKER
SRS

CMS-R600X/R600XT
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
92LCoRD577B
General
Power source: AC 110/127/220/230-240 V,
(CMS-R600X) 50/60 Hz
Power source: AC 220 V, 50 Hz
(CMS-R600XT)
Power consumption: 170 W
Dimensions: Width; 360 mm (14-3/16")
Height; 390 mm (15-3/8")
Depth; 379 mm (14-15/16")
Weight: 7.3 kg (16.1 lbs.)
Amplifier section
Output power: PMPO; 300 W (total)
MPO; 84 W (42 W + 42 W)
(10 % T.H.D.)
RMS; 50 W (25 W +25 W)
(10 % T.H.D.)
Input terminals: VIDEO/AUX; 245 mV/47 kohms
Output terminals: Speakers; 8 ohms
Headphones; 8 - 50 ohms
(recommended; 32 ohms)
Tuner section
Frequency range: FM; 88 - 108 MHz
AM; 531 - 1,620 kHz
Cassette deck section
Frequency response: 50 - 14,000 Hz (Normal tape)
Motor: DC motor with electronic governor
x 1
Signal/noise ratio: 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/
playback)
Wow and flutter: 0.15 % (WRMS)
Bias and erasure system: AC
Tape speed: 4.76 cm/sec. (1-7/8 ips.)
Heads: TAPE-1; Playback x 1
TAPE-2; Record/Playback x 1
Erase x 1
Compact disc player section
Type: 5-disc multi-play compact disc
player
Signal readout: Non-contact; semiconductor laser
Rotational speed: 200 - 500 rpm CLV, Approx.
Error correction: CIRC (Cross Interleave Reed-
Solomon Code)
Quantization: 16-bit linear
Filter: 4-times oversampling digital
filter
D/A Converter: 1-bit D/A converter
Frequency response: 20 - 20,000 Hz
Dynamic range: 90 dB (1 kHz)
Wow and flutter: Unmeasurable
(less than 0.001% W. peak)
Speaker system (CMS-R600X ONLY)
Type: 3-way type [13 cm (5-1/8")
woofer,
5 cm (2") tweeter and super
tweeter]
Maximum input power: 50 W
Rated power: 25 W
Impedance: 8 ohms
Dimensions: Width; 215 mm (8-1/2")
Height; 390 mm (15-3/8")
Depth; 195 mm (7-11/16")
Weight: 3.4 kg (7.5 lbs.)/each
SPECIFICATIONS
– 2 –
VOLTAGE SELECTION
Before operating the unit on mains, check the preset voltage. If the votage is different from your local voltage. Slide the AC power
supply socket cover by slightly loosing the screw to the visible indication of the side of your local voltage.
QACCE0005AW00 92LPLUG155A 92LPLUG027
Specifications for this model are subject to change without
prior notice.
Figure 2 AC POWER SUPPLY CORD AND AC PLUG ADAPTOR

CMS-R600X/R600XT
NAMES OF PARTS
Front panel
1. Disc Tray
2. Disc Number Select Buttons
3. Disc Skip Button
4. Open/Close Button:
5. Power Switch
6. (TUNER) Memory Button
7. Tuning Up/Down Buttons:
8. Timer Indicator
9. Remote Control Sensor
10. Reset Button
11. Band Selector Button
12. Preset and Time Up/Down Buttons:
13. Disc Number Indicator
14. Extra Bass Indicator: X-BASS
15. Record Indicator: REC
16. Function/CD Track/CD Counter/Frequency/
Preset Channel/Volume Indicator
17. CD Pause Indicator:
18. CD Play Indicator:
19. Memory Indicator
20. CD Repeat Indicator:
21. SRS Indicator (CMS-R600X ONLY)
22. FM Stereo Mode Indicator: ST
23. FM Stereo Indicator:
24. Equalizer Mode Buttons
25. Extra Bass Button: X-BASS
26. Function Selector Buttons
27. Volume Up/Down Buttons:
28. Editing Speed Selector Buttons
29. CD Pause Button
30. Record Pause Button
31. (CD/TAPE) Stop Button:
32. (CD) Track Down/Review Button:
(TAPE) Rewind Button:
33. (CD) Track Up/Cue Button:
(TAPE) Fast Forward Button:
34. (CD) Play/Repeat Button:
(TAPE) Play Button:
35. Memory/Set Button
36. Clock/Timer Button
37. (TAPE 1) Cassette Compartment
38. (TAPE 2) Cassette Compartment
39. Level Meters
40. 3D Surround Mode Button (CMS-R600X ONLY)
41. Headphone Socket
1234
567
8910
11
12
37 38
39 40 41
24 25 26 27
28 3029 31 32 33 34 35 36
54321
X-BASS
REC
ST
MEMORY
5432
X-BASS
REC
ST
MEMORY
kHz
MHz
SRS
16
13 14 15
17 18 19 22
23
20 21
– 3 –
(Illustration: CMS-R600X)

CMS-R600X/R600XT
Rear panel
1. Speaker Terminals
2. Phono Power Supply Socket (DC 12V)
(CMS-R600X ONLY)
3. AC Power Input Socket
4. AC Voltage Selector (CMS-R600X ONLY)
5. FM 75 ohns Aerial Terminal
6. Aerial Earth Terminal
7. AM Loop Aerial Socket
8. Phono Input Sockets (CMS-R600X ONLY)
9. Video (Audio Signal) / Auxiliary Input Sockets
10. Phono/Auxiliary/Video Input Selector Switch
(CMS-R600X ONLY)
11. Span Selector Switch (CMS-R600X ONLY)
1
2
3
4
5
6
7
8
9
10
11
Remote Control
1. Remote Control Transmitter LED
2. 3D Surround Mode Button (CMS-R600X ONLY)
CD control section
3. Disc Number Select Buttons
4. Track Down/Review Button:
5. Disc Skip Button
6. Pause Button:
7. Random Button
8. Play/Repaet Button:
9. Stop Button:
10. Memory Button
11. Track Up/Cue Button:
12. Clear Button
Tape Control Section
13. (TAPE 1) Stop Button:
14. (TAPE 1) Play Button:
15. (TAPE 2) Rewind Button:
16. (TAPE 2) Fast Forward Button:
17. (TAPE 2) Stop Button:
18. (TAPE 2) Play Button:
19. (TAPE 2) Record Pause Button:
Tuner control section
20. Band Selector Button
21. Preset Up/Down Buttons:
22. Function Selector Buttons
23. Balance Control Buttons
24. Power Button
25. Extra Bass Button: X-BASS
26. Equalizer Mode Selector Button
27. Volume Up/Down Buttons:
– 4 –
Speaker Section
12. Tweeter
13. Super Tweeter
14. Woofer
15. Bass Reflex Ducts
16. Speaker Wire
12
13
14
16
15
25
26
27
19 20 21
1
2
5
6
7
11 1210 9
8
1413
22
23
24
3
4
15 16 17 18
(Illustration: CMS-R600X)

CMS-R600X/R600XT
OPERATION MANUAL
SETTING THE CLOCK
Setting method when the POWER switch is in the STAND-BY
position.
1 Press the MEMORY/SET button.
When the power is ON, press the CLOCK/TIMER button.
Then, within 5 seconds, press the MEMORY/SET button.
2 Press the PRESET/TIME ( or ) button to select the time
display.
PRESET/
TIME ( )
CLOCK/
TIMER
MEMORY/
SET
1
2
AM 0:00 AM 12:000:00
3
4
5
6
7
"0:00" → The 24-hour display will appear.
(0:00 - 23:59)
"AM 0:00" →The 12-hour display will appear.
(AM 0:00 - PM 11:59)
"AM 12:00" →The 12-hour display will appear.
(AM 12:00 - PM 11:59)
3
Press the MEMORY/SET button.
4 Press the PRESET/TIME ( or ) button to adjust the hour.
Press the PRESET/TIME button once to advance the time by
1 hour. Press for more than 0.5 seconds to advance continu-
ously.
When the 12-hour display is selected, "AM" will change auto-
matically to "PM".
5 Press the MEMORY/SET button.
6 Press the PRESET/TIME ( or ) button to adjust the
minutes.
Press the button for at least 0.5 seconds to advance continu-
ously.
The hour setting will not advance even if minutes advance
from "59" to "00".
7 Press the MEMORY/SET button.
The clock starts operating from "0" seconds. (Seconds are
not displayed.)
Note:
In the event of a power failure or when the AC power lead
is disconnected, the clock display will go out.
When the AC power supply is resumed, the clock display will
flash on and off to indicate that the time must be reset.
If this happens, follow steps 1 and 4 - 7 in the procedure
described above.
To change the clock time:
1 Whilst the clock is displayed, press the MEMORY/SET button.
When the power is ON, press the CLOCK/TIMER button.
Then, within 5 seconds, press the MEMORY/SET button.
2 Perform steps 4 - 7 above.
To see the time display: (When the power is ON)
Press the CLOCK/TIMER button.
The time display will appear for about 5 seconds.
To switch the time display mode:
1 Set the POWER switch to STAND-BY.
2 Whilst holding down the CLOCK/TIMER button, press the
POWER switch twice.
3
Perform steps 1 - 7 above.
In this example, the clock is set for the 24-hour
(0:00) system.
15
15
Notes concerning use:
Replace the batteries if control distance decreases or oper-
ation becomes erratic.
Periodically clean the transmitter LED on the remote control
and the sensor on the main unit with a soft cloth.
Exposing the sensor on the main unit to strong light may in-
terfere with operation. Change the lighting or the direction of
the unit.
Keep the remote control away from moisture, excessive heat,
shock, and vibrations.
0.2 m - 6 m
(8" - 20')
PREPARATION FOR USE
RESETTING THE MICROCOMPUTER
Reset the microcomputer by performing the following
procedure for the cases shown below:
To erase all of the stored memory contents, or
If the display does not function properly, or
The unit does not operate properly.
1 Set the POWER switch to STAND-BY.
2 Disconnect the AC power lead from the AC socket.
3 Press the RESET button for at least 3 seconds.
RESET
– 5 –

CMS-R600X/R600XT
DISASSEMBLY
Caution on Disassembly
Follow the below-mentioned notes when disassembling
the unit and reassembling it, to keep it safe and ensure
excellent performance:
1. Take cassette tape and compact disc out of the unit.
2. Be sure to remove the power supply plug from the wall
outlet before starting to disassemble the unit.
3.Takeoffnylonbandsorwireholderswheretheyneedbe
removed when disassembling the unit. After servicing
theunit,besuretorearrangetheleadswheretheywere
before disassembling.
4. Take suffcient care on static electricity of integrated
circuits and other circuits when servicing.
Figure 6-3
MAIN UNIT
1 Top Cabinet 1. Screw .....................(A1) x4 6-1
2 Side Panel 1. Screw .....................(B1) x6 6-1
(Left/Right)
3 CD Player Unit/ 1. Turn on the power supply,.
CD Tray Cover open the disc tray, take out
the CD cover, and close.
(Note 1)
2. Hook ...................... (C1) x2 6-2
3. Screw .................... (C2) x5
4. Flat Wire .................(C3) x1
5. Socket ................... (C4) x2 6-3
4 Back Board 1. Screw .................... (D1) x8 6-2
5 Front Panel 1. Screw .....................(E1) x3 6-3
2. Socket .................... (E2) x4
3. Flat Cable.............. (E3) x3
6 Main PWB/ 1. Screw ..................... (F1) x3 6-3
SRS PWB 2. Socket .................... (F2) x1
3. Flat Wire ................. (F3) x1
7 Power PWB 1. Screw .................... (G1) x5 6-3
8 Tape Mechanism 1. Open the cassette holder.
2. Flat Wire .................(H1) x1 7-1
3. Screw .................... (H2) x6
9 Switch PWB 1. Screw ..................... (J1) x4 7-1
10 Display PWB 1. Screw .....................(K1) x9 7-1
11 Headphones PWB 1. Screw .....................(L1) x1 7-1
12 Level Meter PWB 1. Screw ................... (M1) x2 7-2
13 Switch PWB 1. Screw .................... (P1) x2 7-2
14 Turntable 1. Screw .................... (Q1) x2 7-3
2. Cover..................... (Q2) x1
15 CD Tray 1. Screw .................... (R1) x4 7-3
2. Guide..................... (R2) x2
16 CD Servo PWB 1. Screw .....................(S1) x2 7-4
17 Sensor PWB 1. Screw .....................(T1) x1 7-4
2. Hook ....................... (T2) x2
18 CD Mechanism 1. Screw .................... (U1) x2 7-5
STEP REMOVAL FIGURE
PROCEDURE
Note 1: If the power supply cannot be turned on, <A> turn the
pulleybyhandasshownin Figure6-2 toopenthedisc
tray.
SPEAKER BOX [CMS-R600X ONLY]
1 Speaker 1. Front Panel ............. (A1) x1 7-6
2. Screw ......................(A2) x4 7-7
3. Screw ......................(A3) x2
STEP REMOVAL PROCEDURE FIGURE
– 6 –
(A1) x 2
ø3 x 12mm Top Cabinet
Side Panel
Side Panel
(A1) x 2
ø3 x 12mm
(B1) x 2
ø3 x 10mm
(B1) x 2
ø3 x 10mm
(B1) x 2
ø3 x 12mm
Figure 6-1
(C2) x 1
ø3 x 10mm
(C2) x 1
ø3 x 10mm (C1) x 1
(C1) x 1
CD Tray Cover
CD Player Unit
(D1) x 3
ø3 x 8mm
(D1) x 3
ø3 x 12mm
(C2) x 3
ø3 x 12mm
(D1) x 2
ø3 x 8mm (C3) x 1
Pulley <A>
Figure 6-2
(G1) x 1
ø3 x 10mm
(G1) x 4
ø4 x 6mm
(E2) x 2
(E2) x 2
(F2) x 1
(F3) x 1
(C4) x 1
(C4) x 1
Front Panel
(E1) x 3
ø3 x 10mm
(F1) x 2
ø3 x 10mm
(F1) x 1
ø3 x 10mm
(E3) x 3
Power PWB
Main PWB
SRS
PWB

CMS-R600X/R600XT
Figure 7-3
(T1) x 1
ø3 x 10mm
(S1) x 2
ø3 x 10mm
(T2) x 2
Sensor PWB
CD Servo
PWB
CD Tray
Figure 7-4
(U1) x 2
Special
CD Mechanism
Figure 7-5
Front Panel
(A1) x 1
Screw Driver
Figure 7-6
(A2) x 4
ø 4 x 32mm (A3) x 2
ø 4 x 32mm
Figure 7-7
(Q1) x 2
ø3 x 10mm
(R1) x 2
ø3 x 10mm (R2) x 1
(R2) x 1
Turntable (Q2) x 1
CD Tray
(R1) x 2
ø3 x 10mm
Loading
Chassis
Figure 7-1
(J1) x 4
ø3 x 10mm
(K1) x 9
ø3 x 10mm
(L1) x 1
ø3 x 8mm
Headphones PWB Tape
Mechanism
Display PWB
Front Panel
(H2) x 6
ø3 x 10mm
Switch PWB
(H1) x 1
Figure 7-2
(P1) x 1
ø3 x 10mm (P1) x 1
ø3 x 10mm
(M1) x 2
ø3 x 10mm
Level Meter PWB
Switch PWB
– 7 –

CMS-R600X/R600XT
REMOVING AND REINSTALLING THE MAIN PARTS
Figure 8-5
Erase Head Record/Playback
Head
Pawl (B1) x3 Pawl (A1) x2
TAPE 2
<B>
<B> <B>
<A> <A>
Figure 8-4
Figure 8-3
Figure 8-2
Figure 8-1
TAPE MECHANISM SECTION
Performsteps1,2,3,4,5 and 8 of the disassembly method to
remove the tape mechanism.
How to remove the record/playback and erase
heads (TAPE 2) (See Fig. 8-1.)
1. Carefully bend the record/playback head pawls (A1) x 2
pcs., in the direction of the arrow <A> , and remove the
record/playback head upwards.
2. Carefully bend the three pawls (B1) x 3 pcs., in the arrow
direction <B>, and remove the erase head upward.
How to remove the playback head (TAPE 1)
(See Fig. 8-2.)
1.Carefullybendtheplaybackhead pawls(C1) x2pcs.,inthe
direction of the arrow <C>, and remove the playback head
upwards.
How to remove the pinch roller (TAPE 1/2)
(See Fig. 8-3.)
1. Carefully bend the pinch roller pawl in the direction of the
arrow <D>, and remove the pinch roller (D1) upwards.
Note:
When installing the pinch roller, pay attention to the spring
mounting method.
How to remove the belt (TAPE 1) (See Fig. 8-4.)
1. Remove the main belt (E1) x 1 pc., from the motor side.
How to remove the motor
(See Figs. 8-4 and 8-5.)
1. Remove the belt.
2. Remove the screws (G1) x 2 pcs., to remove the motor
fixture.
3. Remove the screws (G2) x 2 pcs., to remove the motor.
Note:
Whenmountingthemotor,payattentiontothemotormounting
angle.
How to remove the belt (TAPE 2) (See Fig. 8-4.)
1. Remove the tape 1 main belt (E1) x 1pc., from the motor
side.
2. Remove the tape 2 main belt (F1) x 1pc., from the motor
side.
3. Remove the FF/REW belt (F2) x 1 pc.
Playback Head
Pawl (C1) x2
TAPE 1
<C>
<C>
Pinch Roller (D1) x1
Pawl
<D>
(G1) x2
ø2 x4mm
Motor
(G2) x2
ø2 x4mm
Motor Bracket
Motor TAPE 1
TAPE 2
FF/REW Belt
(F2) x1
Flywheel Main Belt
(F1) x1 Main Belt
(E1) x1
Flywheel
Motor
TAPE 2
Main Belt
(F1) x1 TAPE 1
Main Belt
(E1) x1
– 8 –

CMS-R600X/R600XT
Figure 9-3
Figure 9-1
Figure 9-2
( C1 ) x2
ø2.6 x6mm
( C2 ) x1 ( C3 ) x1 ( C4 ) x1
CD Mechanism
Pickup
( A1 ) x2
ø2.6 x5mm
Loading Motor
CD Tray
( B1 ) x2
ø2.6 x5mm
CD Tray
Turntable
Up/Down Motor
CD MECHANISM SECTION
Perform steps 1, 2, 3, 14, 15 and 16 of the disassembly
method to remove the CD mechanism.
How to remove the loading motor
(See Fig. 9-1)
1. Remove the screws (A1) x 2 pcs., to remove the loading
motor.
How to remove the pickup (See Fig. 9-3)
1.Removethe screws (C1)x2pcs., to removetheshaft(C2).
2. Remove the stop washer (C3) x 1 pc., to remove the gear
(C4).
3. Remove the pickup.
How to remove the turntable up/down motor
(See Fig. 9-2)
1. Remove the screws (B1) x 2 pcs., to remove the turntable
up/down motor.
– 9 –

CMS-R600X/R600XT
TAPE MECHANISM SECTION
• Driving Force Check
Torque Meter Specified Value
Play: TW-2412 Tape 1: Over 50 g
Tape 2: Over 100 g
• Torque Check
Torque Meter
Tape 2
Play: TW-2111 30 to 60 g. cm 30 to 60 g.cm
Fast forward: TW-2231 — 80 to 135 g.cm
Rewind: TW-2231 — 80 to 135 g.cm
Specified
Value
Adjusting
Point Instrument Connection
Test Tape
Normal MTT-111 VRM1 3,000 ±Speaker
speed 30 Hz terminal
(Load
resistance:
8 ohms)
ADJUSTMENT
Specified Value
Tape 1
• Tape Speed
*1. Input: Antenna, Output: TP301
*2. Input: Antenna, Output: Speaker terminal
• FM RF
Signal generator: 1 kHz, 75 kHz dev., FM modulated
• Detection
Signal generator: 10.7 MHz, FM sweep generator
IF 10.7 MHz 98.00 MHz T301(Turn Input: Pin 1 of
the core of IC301
transformer Output: TP302
T301 fully
counter-
clookwise.)
Instrument
Connection
Test
Stage Adjusting Parts
Frequency
Display
Frequency
• AM IF/RF
Signal generator: 400 Hz, 30%, AM modulated
TUNER SECTION
fL: Low-range frequency
fH: High-renge frequency
*1. Input: Antenna, Output: TP302
*2. Input: Antenna, Output: TP301
Figure 10 ADJUSTMENT POINTS
– 10 –
Band — 87.50 MHz L303(fL): *1
Coverage 1.85 V ±50 mV
RF 98.00 MHz 98.00 MHz L302 *2
(10-30 dB)
Test Stage Instrument
Connection
Frequency Frequency
Display Serring/ Adjusting
Point
IF 450 kHz 1,720 kHz T351 *1
Band — 530 kHz (fL): T333 *2
Coverage 3.4 V ±0.1 V
Tracking 990 kHz 990 kHz (fL): T331 *1
Test Stage Frequency Frequency
Display Setting/
Adjusting
Parts
Instrument
Connection
Adjusting
Parts Instrument Connection
Frequency
Display
Frequency
• FM Mute Level
98.00 MHz 98.00 MHz VR351 *1 Input: SO301
(25 dBµV) Output: Speaker
Terminal
*1 Adjust so that an output signal appears.
TAPE MECHANISM PWB-G
VRM1
TAPE
SPEED
L303
T331
T301
L302
CNP301
T351
T333
1
12
24
2113
IC351
IC301
FM RF
AM TRAKING fL
AM LOOP ANTENNA
FM IF
AM IF
VR351
R358
C364
TP302
FM BAND
COVERAGE fL
FM MUTE
LEVEL
AM BAND
COVERAGE fL
1
1
2
MAIN PWB-A1
TP301
SO301
ANTENNA
TERMINAL

CMS-R600X/R600XT
CD SECTION
Since this CD system incorporates the following automatic
adjustment function, when the pickup is replaced, it is not
necessary to readjust it.
SincethisCDunitdoesnotneedadjustment,thecombination
of PWB and laser pickup unit is not restricted.
• Automatic adjustment item
1. Focus offset (Fig. 11-1)
2. Tracking offset (Fig. 11-2)
3. E/F balance (tracking error balance) (Fig. 11-3)
4. RF level AGC function (HF level: constant)
5. RF level automatic follow-up of the tracking gain
This automatic adjustment is performed each time a disc is
changed. Therefore, each disc is played back using the
optimal settings.
CD TEST MODE
When the CD, STOP and POWER keys are
pressed at the same time, to turn on the power,
the unit will enter the test mode.
↓
"VOL" will appear. After "CD" has appeared, all
of the LCDs will light up.
↓
The OPEN/CLOSE operation can be performed
manually.
↓It is OK if the display does not change.
Use of the or key allows you to slide the
pickup.
→Press the PLAY key.
↓All of the LCDs will go out.
ATOC and IL will be performed and nor-
mal playback can be performed. When
the following keys are pressed during
playback,thetrack numberscanbe speci-
fied directly.
↓
DISC 1 →Track 3
DISC 2 →Track 8
DISC 3 →Track 15
↓
Press the STOP key.
↓
Stop
←
→Press the APMS MEMORY key. ←
↓All of the LCDs will go out.
The tracking servo will turn on, and playback will begin.
↓The track No. and time will appear.
Press the STOP key.
↓"01 0:00" will appear.
The pickup will return normally to the STOP position.
↓
Press the APMS MEMORY key.
↓"01 0:00" will appear.
The tracking servo will turn off, and playback will begin.
↓
Press the STOP key.
↓"01 0:00" will appear.
The pickup will return normally to the STOP position.
Initialization
(IL) is not
performed.
The display
will look the
same as
usual.
2
0.1s
0.50 V
IC1 20 FE
0.1s
0.50 V
IC1 7 TE
1
FOCUS
OFF-SET
ADJUST
TRACKING
OFF-SET
ADJUST
Figure 11-1
2
1
10ms
0.50 V
IC1 20 FE
10ms
0.50 V
IC1 7 TE
Enlarged
View
TRACKING
OFF-SET
ADJUST
Figure 11-2
2
1
TO
TE
200 ms
1V/diV
IC 1 15
200 ms
1V/diV
IC 1 7
TRACKING/
ERROR
BARANCE
ADJUST
Figure 11-3
Cancel method: POWER OFF
LCDdisplay:After the PLAY orAPMS MEMORYkey has been
pressed, the track No. and time only will appear
(valid). The other items are optional.
Note: The pickup can be slid using the or key only
while in the stop mode.
INITIALIZING THE CD CHANGER MECHANISM
When the CD, DOWN and POWER keys are pressed at the
same time to turn on the power, the CD changer mechanism
will be initialized.
• The entire CDAPMS memory will be cleared.
• The FUNCTION button can be used to start the CD. The
other initializations are the same as usual.
• The CD changer mechanism will be initialized. DISC 1 will be
chucked, initialized, and stopped.
• "INITIAL" will flash on the LCD. After initialization, the LCD
will return from the display of DISC 1 being initialized to the
normal display.
ALL CLEAR AND RE-START FUNCTION
When the CLEAR and POWER keys are pressed to turn on
the power, the entire internal memory will be cleared and the
mechanism will run from address 0.
All of the tuner presets, APMS,TOC and disc numbers which
were last stored in memory will be cleared, and the tuner,
changer mechanism and all of the other items will be initial-
ized.
– 11 –

CMS-R600X/R600XT
• The indicated voltage in each section is the one measured
by Digital Multimeter between such a section and the chas-
sis with no signal given.
1. In the tuner section,
( ) indicates AM
< > indicates FM stereo
2. In the main section, a tape is being played back.
3. In the deck section, a tape is being played back.
( ) indicates the record state.
4. In the power section, a tape is being played back.
5. In the CD section, the CD is stopped.
• Parts marked with “ ” ( ) are important for
maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and
performance of the set.
NOTES ON SCHEMATIC DIAGRAM
– 12 –
• Resistor:
Todifferentiatethe unitsofresistors,the symbol asKandM
are used: the symbol K means 1000 ohm and the symbol M
means1000kohm and theresistorwithoutany symbol isan
ohmresistor.Theresistordesignated“Fusible”isafusetype
resistor.
• Capacitor:
To indicate the unit of capacitor, a symbol P is used: this
symbol P means Pico-farad and the unit of the capacitor
without such a symbol is microfarad. As to electrolytic
capacitor, the expression “capacitance/withstand voltage”
is used.
(CH), (TH), (RH), (UJ): Temperature compensation
(ML): Mylar type
(P.P.): Polypropylene type
• Schematic diagram and Wiring Side of P.W.Board for this
model are subject to change for improvement without prior
notice.
Figure 12 TYPES OF TRANSISTOR AND LED
ECB
(S) (G) (D)
(1) (2) (3)
FRONTVIEW FRONTVIEW
FRONT
VIEW FRONT
VIEW
2SD468 C
2SK246 GR
KRC102 M
KRC104 M
KTA1266 GR
KTA1270 Y
KV1236Z23 KDV147C 5N4GTN52
KTA1271 Y
KTC3194 Y
KTC3199 GR
KTC3200 GR
KTC3203 Y
KTD2058 Y
SW2 DISC UP ON—OFF
SW4 PICKUP IN ON—OFF
SW291 SPAN SELECTOR 100/10—
[CMS-R600X ONLY] 50/9
SW421 PHONO/VIDEO/AUX PHONO—
[CMS-R600X ONLY] VIDEO/AUX.
SW561 3D SURROUND ON—OFF
SW702 CD DISC1 ON—OFF
SW703 CD DISC2 ON—OFF
SW704 CD DISC3 ON—OFF
SW705 CD DISC4 ON—OFF
SW706 CD DISC5 ON—OFF
SW707 CD DISC SKIP ON—OFF
SW708 CD OPEN/CLOSE ON—OFF
SW709 FLAT ON—OFF
SW710 BGM ON—OFF
SW711 VOCAL ON—OFF
SW712 HEAVY ON—OFF
SW713 X-BASS ON—OFF
SW714 TUNING UP ON—OFF
SW715 MEMORY ON—OFF
SW716 POWER ON—OFF
SW717 FORWARD ON—OFF
SW718 PRESET UP/TIME UP ON—OFF
SW719 STOP ON—OFF
REF. NO DESCRIPTION POSITION POSITIONREF. NO DESCRIPTION
SW720 REC PAUSE ON—OFF
SW721 CD PAUSE ON—OFF
SW722 TUNING DOWN ON—OFF
SW723 EDIT HIGH ON—OFF
SW724 EDIT NORMAL ON—OFF
SW725 REWIND ON—OFF
SW726 PRESET DOWN/TIME DOWN ON—OFF
SW728 VOLUME UP ON—OFF
SW729 CLEAR/TIMER ON—OFF
SW730 MEMORY/SET ON—OFF
SW732 PLAY/REPEAT ON—OFF
SW734 BAND ON—OFF
SW735 VOLUME DOWN ON—OFF
SW736 VIDEO/AUX ON—OFF
SW737 TAPE1 2 ON—OFF
SW738 TUNER ON—OFF
SW739 CD ON—OFF
SW740 RESET ON—OFF
SW801 OPEN/CLOSE ON—OFF
SW901 VOLTAGE SELECTOR 110—127—
[CMS-R600X ONLY] 220—230-240
SWM3 FULL PROOF ON—OFF
SWM4 F.A.S. ON—OFF
SWM5 CAM ON—OFF

CMS-R600X/R600XT
Figure 13 BLOCK DIAGRAM (1/3)
– 13 –
IC1
LA9240M
SERVO AMP.
IC2
LC78622E
SERVO/SIGNAL
CONTROL
CLK
DEF/THLD
SLI
SLC
CV+
JP– JP–
CLV+
EFMIN
EFMO
DEFI
50
49
~
44
43
40
32 20
1
61
9
~
12
10
XVDD
TEST2
VDD
VVDD
+B
43
11
23
6
58
53
SQOUT. RWC. WRQ
RES. CQCK. COIN
~
RVDD
LVDD
RCHO
RVSS
LVSS
LCHO
CONT5
CONT1
DRF CL DRF SL+ SL– SLD SPD FD TO
F
E
FIN1
FIN2
LDD
VCC1
CNS10
+5.6V
ASP
+5V
DSP
+5V
ALPC
CONTROL
POWER
LASER
IC51, IC52 : MOTOR DRIVER
2
6
6
2
DISC UP SW
PH2
DISC NO.
SENSOR
5.7V CDSVO
25
19
10
3
51 SECTION
TO MAIN
(OPEN)
L-CH OUT
AUDIO GND
R-CH OUT
GND
12V MECHA
CO IN
SQ OUT
CQCK
LOADING H/L
SLM–
SLM+
RWC
RES
WRC
DRF
DISC NO. SENSOR
PU-IN SW
DISC UP SW
20
19
18
17
16
14
15
13
12
11
10
9
8
7
6
5
4
3
2
1
Q81
CHANGER MECHA
M2
TURNTABLE
UP/DOWN
LOADING
M1
MOTOR
SW2
REGULATOR
M
M
Q51
7
3
891
TA7291S
IC51
Q52
IC52
TA7291S
7
3
8
9
1
AUDIO
+5V
40
39
38
37
36
41
28
24
~
DEF, CLK, CL, DAT, CE, DRF
44
45
27
16
15 29
~
54
+5.6V
28
13
8
7
21
BA5920FP
M3
SPIN MOTOR
M4
SLIDE MOTOR
Q1
62
PICKUP IN
SW4
TRACKING/
SPIN/SLIDE/
DRIVER
FOCUS/
XL1
16.93MHz
PICKUP UNIT
MM
TRACKING COIL
FOCUS COIL
+5V
XOUT
XIN
SL+. SL–. DRF
IC5
22
64
27
26
18
17
12
11
2
1
4
3
2
1
543130

CMS-R600X/R600XT
Figure 14 BLOCK DIAGRAM (2/3)
– 14 –
TERMINAL
ANTENNA
SO301
GND
FM 75ohms
IC301
TA7358AP
FM RF FM IF
OSC.
FM
FM IF
CF302
L303
T301
RF AMP.
FM MUTE
Q302
FM +B
L302
FROM CD SECTION
PHONO/VIDEO/AUX
AM ANT.
AM OSC. AM
ANT. T333T331
X351
MPX IN
D351
DET OUT
MUTING
Q372
Q371
MODE
R
C-IN
C-OUT
PASS/STEREO/MONO
SELECTOR
SRS MODE
Q504
Q506
Q502
PASS
SRS1 L
R
L
REGULATOR
VOLTAGE
+B5
Q501
SRS
SRS5250S
IC501
+B5
LEVEL
VR351
AM RF IN
+B5
IN
AM IF
CF352 +B5
FM FRONT END
RL
FULL PROOF
TAPE2 FULL PROOF
TAPE2 RUN PULSE
+B4
RL
TO CD
IC381
LC72131
PLL
VDD
LA1832
IC351
AM MIX
OUT
AM LOOP
ANTENNA
CD CHANGER
VRM1
PHM1
TAPE MOTOR
TAPE1 RUN PULSE
SOLENOID PLUNGER
TAPE MECHA STOP
P. B. MUTE
T1 R
T1 L
T2 R
T2 L
~
P. B. HEAD
REC/P. B.
Q213
Q281
L282 Q282 Q283
L REC IN
R REC IN
T1/T2
TERMINAL
CNP301
FM IF DET. /FM MPX. /AM IF
CF351
AM IF
T351
X381
Q381
SO401
R-CH
L-CH
SW801
HIGH SPEED
TAPE
MOTOR
MM1
SPEED
TAPE
Q712Q711
MOTOR
DRIVER SWITCHING
Q708Q707
Q714Q713
Q201
Q202
ALC CUT
SWITCHING
CrO
2
NOR/
Q210
Q209
Q256
Q255
Q212
Q211
REC. /P. B. AMP.
IC201
Q206
Q203
Q208
Q207
Q272
Q274
Q273
L
R
L
AM IN FM IN
SWITCHING
FM
+B6
F.A.S
CAM
TAPE1
TAPE2
R-CH
L-CH
HEAD
R-CH
L-CH
AN7345K
R
L
P. B
RECL REC
R REC
SWITCHING
REC MUTING
+B5
VCC
L OUT
CD
R
L
R
L
R
L
TAPE
TUNER
TO CD
S
REC BIAS
FM DET
VCC
FM/AM
AM OSC
AM +B
R OUT
L OUT
ST ST MONO/ST
STEREO
VT
4.5MHz
SWITCHING
DRIVER
+B5
SWM5
SOLENOID
SOLM1
SWM4
SWM3
HEAD
ERASE
T1/T2
REC
SWITCHINGSWITCHINGBIAS OSC
SWITCHING
SWITCHING
PB MUTE
ALC
R OUT
PBREC
SWITCHING
POP
REDUCE
L NF
R NF
+
B
IL
L
CE
DI
CL
7
6
9
4
35
M
26
24
25
17
18
15
1
27
28
17
8
15
14
12
9
42
21 18 13
1
8
2
1
16
6
23 24
1
7
10 11
19
8
17
7
18
16
9
6
22
3
23
2
24
1
15
12
4
21
13
CE
DI
DO
CL
13
9
11 1016 15
7
17
22
1
20
3456
8
21
25 24 23 40
9
33
16 3514
21
28
17
32
19
30
CMS-R600X ONLY

CMS-R600X/R600XT
Figure 15 BLOCK DIAGRAM (3/3)
– 15 –
T500mA L 250V
F601, F602
L 250V
T2.5A
F902
T3.15A
L 250V
L 250V
T1.6A
F903
L 250V
T3.15A
F901
SWITCHING
SW901
VOLTAGE
SELECTOR
50/60Hz
230 – 240V
600X: AC 110/127/220/
SUPPLY CORD
AC SOCKET
SO901
230 – 240V
110V
127V
220V
600XT
ONLY
T. F
L
R
LATOR
AGE
0S
RL
DC 12V
ONLY
J901
DC SOCKET
FOR RP-R600 Q931 Q930
Q641
+B3
RESET IN
SYSTEM STOP
4.19MHz
XL701
+B3 (5V BACK UP)
+B2
RL
LCD BIAS
~~
COM 0 ~
COM 3 S0 ~ S31
HIGH SPEED
RL
TO CD SECTION
Q926
Q923
+B6(+5.7V)
+5V Q705
T901
TRANSFORMER
POWER
VCC
+27V
–27V
D901 ~ D904
+5.7V
D702
D705
D704
IC701
OPEN SW CLOSE SW DISC UP PU IN DISC NO
OUT
AC POWER
D905 ~ D908
P-CONT
SO601
J601
GND
GND
POWER AMP.
LM1876TF
IC601
R-IN
L-IN
R-OUT
L-OUT
SPEAKER SWITCH
HEADPHONES
TERMINAL
SPEAKER
NF
PRE
Q483
Q482
Q481
LMP561
EDGE LAMP
LMP802
32.768kHz
XL702
LMP801
SWITCHING
+B4
BACK LAMP
+B5
L
R
IC431
Q927
Q925
Q924
SW734 ~ SW739
SW732
SW728 ~ SW730
SW702 ~ SW726
Q701 ~ Q704
LED701 ~ LED704
RX701
DETECTOR
POWER FAIL
SW740
Q706
Q710
Q709
F921
LC75394E
DO
DI
CE
CL
DISPLAY
LCD701
TUNER MUTE
+B1
UN SWITCH
RESET
CD
R
L
R
L
R
L
TAPE
TUNER
AUDIO PROCESSOR
TO CD SECTION
SENSOR
REMOTE CONTROL
+B2 REMOTE IN
REGULATOR
VOLTAGE
REGULATOR
VOLTAGE
(ANALOG)+12V
+B5
(MECHA)+12V
+B4
REGULATOR
VOLTAGE
(MICOM)
+B1
REGULATOR
VOLTAGE
ILLUNIMATION GUIDE LED DRIVER
CE
DI
CL
+B2
KEY
BACK UPRESET MEMORY
+B2
VDD
GRAPHIC EQUALIZER
VOLUME
GRAPHIC EQUALIZER
X- BASS
36
5
15
27
28
15
4
2
47
46
45
4443
14
11
9
6
12
7
13
8
10
5
1
3
4
1
21
3
PASS SRS1 COIN SQOUT PLAYBACK MUTE
POWER CONT.
TAPE 2 RUN PULSE TAPE2 FULL PROOF
TAPE 1 RUN PULSE
CQCK DRF LODING MOTOR L/H SLIDE MOTOR–
SLIDE MOTOR +
RWC RES WRC SOLENOID PLUNGER T1/T2 TAPE REC TAPE BIAS TAPE MOTOR TAPE MECHA STOP
X IN
X OUT
RESET
VDD
VSS
AVSS
VREF
~~
~~~
INITIAL2
INITIAL1
IX0153AWZZ
IC701
SYSTEM
MICROCOMPUTOR
COM OUT
KEY IN
49
48
4
3
41
39
38 42 25
24
23
35
16
15
96
2120
19
18
97
17
5
26
36
37
9
27
40
12
8
7
13
22
98
34
33
2
99
1
32
28
95
92 14 50 58
55 54
51 91 10 11
60
25 24 23 48
1
47
2
46
3
45
4
44
5
43
6
42
7
41
8
40
9
A VSS VSS R VREF L VREF V REF
36
13
33
16 3514
58
55
21
28
17
32
19
30
57
26 27 391037 3811
12
50
63
56
600X
ONLY
600XT: AC 220 V, 50 Hz

CMS-R600X/R600XT
A
B
C
D
E
F
G
H
123456
Figure 15 WIRING SIDE OF P.W.BOARD (1/7)
– 16 –
• The numbers 1 to 12 are waveform numbers shown in page 36.
1
2
3
4
5
6
7
89
1
2
3
4
5
7
6
8
9
1
7
8
22
21
14 15
28
IC5
CNP2
CNP80
C50
C49
C42
1
16 17
32
33
48
49
64 CNP3
LNGR
CNP4
C55
C56
R89
C92
D2
1
510 15
16 17 20 25 30
32
33
35
40
50
55
60
45
510 15 20 25 30
35
40
50
55
60
45
48
49
64
1
2
3
4
5
6
7
8
9
1
2
3
4
5
1
2
3
4
56
1
2
3
4
5
6
7
8
123
ECB
ECB
123
C9
C8
R6
R5
C4
C7
C6
C3
R1
C1
C2
C40
R91
L51
R39
R40 R24
C21
C19
CNP10
D7
D8 R76
R4
R2
C5
R3 C10
R8
R11
R9
R42
R7
R12
C13
R13
R28
C14
R16
R15
R14 C24
C12
R17 R19
C15
R27
R26
C20
C16
R21
R20
C38
C35
C37
C39
C33
R33
C32
R37
R35 R32
R34
C34 C31
R41
C45
C29
R36
R38
R56
R57
R58 R62C22
R60
C41
C57
R93
R97
R95
L54 R99 R59
C91
C62
C61
XL1
C54 C51
C63
C60
C70 C69
R75
R82
C68
C67 C43
R74
C81
R81
ZD81
C52
R73
R86
R87 L1
L52
R96
R92
R49
R88
R94
R22
R23
C17
R43
R98
R100 L53
R10
R25
C18
C48
C25
R29
C11
Q1
IC1
IC2
IC51
IC52
Q52
Q81
Q51
FC700
CD PWB-C1
135791113151719
2468101214161820
5
11
3
4
2
9
81 6 7
10 12
P21 9 - H
TO DISPLAY PWB

CMS-R600X/R600XT
– 17 –
Figure 17 WIRING SIDE OF P.W.BOARD (2/7)
78 9 10 11 12
PH2
1
2
3
CNP90
C1B C2B
CNS3BCNS3A
CNS5 CNP901
TO POWER PWB
P32 3 - A
CNS80B
23 1
CNS80A
CNS4B
CNS4A
PICKUP UNIT CD MOTOR PWB-D
SUB PWB-C2
+
-
+
-
PICKUP IN
654321
SLIDE MOTOR
SPIN MOTOR
M4
CNP4A
SW4
M3
OR
RD
BR
YL
BK
GR
BL
RD
WH
GY
WH
GY
WH
GY
WH
RD
WH
GY
GY
WH
GY
WH
GY
9
8
7
6
5
4
3
2
1
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
1
2
3
4
5
6
M2
TURNTABLE UP/DOWN
M1
LOADING MOTOR SW2
DISC UP
CNS2B
CNS2A
PK
WH
BK
YL
BL BL
PK
WH
YL
BK
1
2
3
4
5
1
2
3
4
5
BR COLOR TABLE
RD(R)
OR
YL
GR
BL
BROWN
RED
ORANGE
YELLOW
GREEN
BLUE
VL
GY
WH(W)
BK
PK
VIOLET
GRAY
WHITE
BLACK
PINK
MM

CMS-R600X/R600XT
A
B
C
D
E
F
G
H
123456
• The numbers 1 to 12 are waveform numbers shown in page 36.
Figure 18 SCHEMATIC DIAGRAM (1/14)
– 18 –
4.9V
0V 4.9V
0V
2.5V
DISC NO. SENSOR
PWB-D
CD MOTOR
–
+
–
+
SUB PWB-C2
SENSOR
DISC NO.
DISC UP
GND
–
+
–
+
5.4V
GND
PICKUP UNIT
ACTUATOR
TR–
FO–
FO+
TR+
2200P
2200P
1M
1M
LD GND
LT0H30M1
C
F
A
B
E
K
LD MON
VR
LD
GND
+5V
F+
F–
T–
E
A
B
F
K
T+
E
K
A
B
F
/SPIN/SLIDE DRIVER
FOCUS/TRACKING
M
M
F
B
A
E
K
TR–
TR+
FO+
FO–
GND
PD
VR
LD
TR–
TR+
FO+
FO–
GND
PD
VR
LD
SP+
SP–
SL+
SL–
PUIN
GND
+
+
–
–
150
R59
CNS2B
5
4
2
1
8
7
CNS3B
1
2
3
4
5
6
8
7
CNS3A
1
2
3
4
5
6
CNS4B
1
CNP4A
1
33 44
M4
SLIDE
MOTOR M55 66
M3
SPIN
MOTOR M
22
SW4
PICKUP IN
9
8
7
6
5
4
3
2
CNS80A
1
9
8
7
6
5
4
3
2
CNP80
1
3
1
3
1
8
7
1
5
4
3
2
1
6
5
4
3
2
CNS4A
1
3
4
5
6
2
3
5
4
3
2
CNS2A
1
+B
+B
+B
+B
4.7K
R41
4.7/25
C45
1.2K
R23
10K
R20
5
4
3
2
CNP2
1
47/10
C2
7
6
5
4
3
2
CNP3
1
8
6
5
4
3
2
CNP4
1
BA5920FP
IC5
4.7
C2B
4.7
C1B
SW2
DISC UP
M2
TURNTABLE
UP/DOWN
M1
LOADING
MOTOR
RPI574N
PH2 33
22
CNP90
1
CNS80B
1
330K
R27
330K
R26
L51
27µH
L54
27µ
H
L52
27µH
L53
27µH
0.1
C50
1K
R7
0.047
C9
12K
R8 180P
C10
82K
R10 1SS
1
D
2
0.1
C11
22K
R40 1K
R29
22K
R39
0.01
C1
1K
R1
3.3K
R11
27K
R9
0.1/50
C3
15K
R3
100K
R2
0.001
C4
0.033
C5
2.2K
R4
6.8K
R5
0.1/50
C7
100
R6
0.068
C8
0.033
C6
33K
R13
0.1
C13
0.0033
C20
0.0027
C31 470
R35
56K
R32
5.6K
R33
1K
R34 15P C32
47K
R37
0.001
C33 47K R36
33K
R38
0.033
C34
0.01
C25
KTA1266 GR
Q1
1/50
C24
22
R43
560
R42
0.33/50
C40
0.47/50
C39
0.01
C38
100/10
C37
0.1/50
C35
10K
R24
1.2K
R25 47/10
C19
1/50
C18
0.47/50
C17
0.001
C16
6.8K
R22
56K
R21
0.0047
C15
39K
R19
0.01
C14
330P
C12
82K
R17
1.5K
R16
47K
R15
10K
R14
220P
C29
0.47/50
C21
470/10
C48
15K
R12
1K
R28
IC1
LA9240M
SERVO AMP.
FSC
DRF
HFL
–
+
–
+
JP+
CV+
+
+
+
+
–
–
–
–
+
–+ –
–
REF CLK
FD
TO
TH
F
E
FIN1
FIN2
TO
VCC1
LDS
LDD
BHI PHI
RF
REF
REF
VCR
REF
FE1
VCR
REF
–
+
–
+
–
+
REF –
+
REF
+
–
TESI
SCI
TE–
TA
TD–
TD
REF
–+
JP
REF
GEN
JP
REF
GEN
REF
GEN
FOSTA
REF
REF
FE1
+
–
+
–+–
REF
REF
+–
+–
SPI SPG SP AGND FE– FA– FE FD– FA
REF
–
+TGL
THDL
VCC
+
–
+
–
THD
GL
S. Q. R.
REF
JP +
–
+
–
REF
PSTA
OR
REF
SLOF
–
+
SL– SL+ SLD SLEQ SPD JP–
JP+
TGL
TOFF
TES
–
+
REF
SP–
SLOF
CV–
CV+
HFL
RF RFSM
RFS–
REF
CV–
JP–
SLC
+–
REF
SLI
+–
P-ON RES
DAT
CL
CE
EFBAL
FOSTA
TOSTA
2FREQ
LASER
FSTA
8/120M
SLOF
DGND
FSC
DRF
CE
DAT
CL
CLK
DEF
THLD
TBC
REFI
VR
REF
+
–
DEF
LF2
+
VCR
VCR
TE
TB
VCC2
FSS
9
10
11
12
13
14
15
16
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49505152535455565758596061626364
8
7
6
5
4
3
2
1
1234
5
6
7
89
10
11
1213
14
15 16 17 18 19 20 21 22 23 24 25 26 27 28
NC NC NC NC
++
NC NC NC
VCC
+
+
+++
–
–
––
–
+
–
–
–
––
+
+
VCC
NC
SHIFT
LEVEL
SHIFT
LEVEL SHIFT
LEVEL
SHIFT
LEVEL
0.001
C62
2
1
CNP901
TO POWER PWB
P33 6 - H CNS5

CMS-R600X/R600XT
Figure 19 SCHEMATIC DIAGRAM (2/14)
– 19 –
• NOTES ON SCHEMATIC DIAGRAM can be found on page 12.
78 9 10 11 12
2.7V
0V
0V
0V
5V
4V
0V
5V
11.2V
0V
5V
11.2V
0V
0V
0V
5V
11.2V
0V
5V
11.2V
0V
0V
2.5V
0V
0V
1.6V
0V
2.5V
2.5V
3.5V
3.5V
0V
2.5V
2.5V
2.5V
5.6V
5.6V
2.5V
2.5V
1V
0.7V
5.6V
0V
2.5V
3.5V
3.5V
3.5V
3.5V
3.5V
3.5V
0V
0V
2.5V
–
–
0V
4V
4V
0V
–
–
–
–
–
–
0V
2.2V
1.9V
5V
–
4.9V
2.5V
2.5V
5V
–
–
–
–
–
0V
0V
0V
0V
0V
5V
–
–
0V
0V
5V
5V
0V
0V
5V
0V
0V
0V
0V
1V
5V
2.3V
0V
0V
0V
0V
0V
0V
0V
2.5V
2.5V
5V
0V
5V
2.3V
1V
1V
5V
5V
0V
4V
4V
0V
0V
0V
0V
1.6V
0V
0V
0V
0V
0V
0V
0V
0V
0V
0V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
0V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
2.5V
0V
0V
4V
0V
0V
5V
5.6V
5V 5.7V
Fusible
IC51, IC52 : MOTOR DRIVER
P23 12 - C
FC700
TO DISPLAY
PWB
IC52
IC51
9
8
7
6
5
4
3
2
1
VOLTAGE
NO.
PIN
9
8
7
6
5
4
3
2
1VOLTAGE
NO.
PIN
9
8
7
6
5
4
3
2
1VOLTAGE
IC5
NO.
PIN
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
41
40
39
38
37
36
35
34
33
IC2
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
VOLTAGE
NO.
PIN
32
31
30
29
28
9
8
7
6
5
4
3
2
1VOLTAGE
NO.
PIN
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
41
40
39
38
37
36
35
34
33
IC1
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
VOLTAGE
NO.
PIN
32
31
30
29
28
9
8
7
6
5
4
3
2
1VOLTAGE
NO.
PIN
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
23
1
Fusible
132
DISC NO. SENSOR
DISC UP
GND
–
+
–
+
5.4V
GND
PUIN
SENSOR
DISC NO.
DRF
+12V
SQOUT
COIN
CQCK
LDM L/H
SLDM–
SLDM+
RWC
RES
WRC
DISC UP
5.7V
CD SIGNAL
CD PWB-C1
NC L–CH
AGND
R–CH
GND
LDM L/H LDM + LDM –
TTM L/H
TTM +
TTM –
10K
R91
1K
R93
KRC102 M
Q51
12K
R99
3.9
R95
12K
R92
12K
R100
3.9
R96
100/16
C92 10K
R98
1K
R94
KRC102 M
Q52
150
R59
9
8
7
6
5
4
3
2
N
S80A
1
9
8
7
6
5
4
3
2
CNP80
1375
8
6
2
9
1
92 6
8
5
7
3
1
+B
+B
+B
+B
+B
+B
+B
+B
4.7K
R41
4.7/25
C45
1K
R88
1K
R87
100P
C55
100P
C54
0.01
C22
100P
C56
100P
C57
0.047
C42
TA7291S
IC52
TA7291S
IC51
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
CNS10
1
10K
R76 220P
C70
220P
C69
10K
R75
100
R73
100
R74
10/16
C68
10/16
C67
KTC3203 Y
Q81
220
R81
MTZJ5.6B
ZD81
220/10
C81
100/10
C52
L1
0.82µH
100
R82
0.047
C41
27K
R57
1.2K
R56
680
R58
1K
R86 1K
R89
220/10
C43
L51
27µH
L54
27µH
L52
27µH
L53
27µH
0.1
C50
82K
R10 1SS133
D2
0.001
C60
0.0027
C31 470
R35
56K
R32
5.6K
R33
1K
R34 15P C32
47K
R37
0.001
C33 47K R36
33K
R38
0.033
C34
220P
C29
0.47/50
C21
1K
R49
0.001
C61
16.93MHz
XL1
1SS133
D8
1SS133
D7
2.2M
R62
0.1
C49
1K
R60
0.0012 C63
6.8K
R97
100/16
C91
IC2
LC78622E
SERVO/SIGNAL
CONTROL
NC NC NC
TEST1
/CS
XVSS
XIN
LVSS
JP– JP+ TGL
CLV–
PDO
DEFI
TEST3 DOUT C2F EMPH CONT5 CONT4 CONT3 CONT2 CONT1
DIGITAL
OUT
EXTERNAL
OUTPUT
TEST4
NC
MUTEL
LVDD
LCHO
1BIT
DAC
RVSS
RCHO
RVDD
MUTER
XVDD
NC
NC
NC
NC NC NC
SBSY
EFLG
PW
SFSY
SBCK
FSX
SUB-CODE
X-TAL
GENERATOR XOUT
WRQ
RWC
SQOUT
COIN
/CQCK
/RES
µ-COM
INTERFACE
NC NC
TST11
16M
4.2M
TEST5
TAI
VVSS
ISET
ERROR
CORRECT
FLAG
CONTROL
VCO
CLOCK
OSC
CONTROL
SLICE
LEVEL
CONTROL SYNC-DETECT
EFM DEMODULATE
CLV
DIGITAL
SERVO
VVDD
FR
VSS
EFMO
EFMIN
TEST2
CLV+
V/P
HFL
TES SERVO
COMMAND
TOFF FSEQ PCK
NC NC
VDD
4FS
DIGITAL
FILTER
RAM
10
11
12
13
14
15
16
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49505152535455565758596061626364
9
8
7
6
5
4
3
2
1
17 18 19 20 21 22 23 24 29 30 31 3225 26 27 28
0.001
C62

CMS-R600X/R600XT
A
B
C
D
E
F
G
H
123456
Figure 20 WIRING SIDE OF P.W.BOARD (3/7)
– 20 –
R
WTM1
CNPM2
12
1
4FWM1 FWM2
SWM3
TAPE MECHANISM PWB-E
SWM4
F. A. S
F. P.
123456789101112
3
4
2
1PHM1
RM1
VRM1
1171819 2021222324252627282930313233343536
TAPE
SPEED
TAPE
SPEED
3
1FW703 OPEN/CLOSE
SW708
DISC SKIP
SW707 DISC 5
SW706
R718
R719
DISC 4
SW705
R717
12
1
IC701
132
3
RESET
XL701
Q701
Q709
E
C
B
E
C
B
B
C
E
3
2
1
3
2
1
E
C
B
E
C
B
B
ECB
ECB
321
BCE
123
C
E
1
2
3
E
C
B
Q710
C713
C712
R829
R824
ZD702
R833
RX701
R702
R703
R701
R742
R740
R738
R839
Q702 Q703
R706
R750
C702
Q711
Q714
Q712
Q707
R801
1FW703
CNP701
UP
SW718
Q713
D708
TIME
PRESET
TUNER
R768
R767
SW740
R798
R799
R800
DOWN
SW726
R837
R838
BAND
SW734
Q708
R826
D703
R835
R845 R841
R843
R842
R830
R846
R825
R840
Q704
R704
R761
R763
R777
R778
R779
C715
C716
R854
LMP802 1
30 31
5101520 25 3540 45
55
60
65
70
75
80
85
90
95
100
81
LCD701
R794
R793
R792
R791
R783 R784
R785
R789
R788
R787
R786
R804
C703
XL702
R853
L700
R815
R802
TAPE 1/2
SW737
VIDEO/AUX
SW736
Q706
R819
Q705
R822
R817
C707
R818
R821
R831
D706
D701
D702
D705
R707
R708
C708
C704
ZD701
D707
R832
C710 C705
C706
R806
R709
RM703 RM704
R827
R823
600X
ONLY
R808
VOLUME UP
SW728
FW851
DOWN
VOLUME
SW735
C709
MEMORY/SET
SW730
TIMER
CLOCK/
SW729
R771
R772
R770
R774
D704
R828
R834
R836
R743
R744
R745
PLAY
SW732
PLAY
LED701 FORWARD
LED703
FORWARD
SW717
R
SW801
CD CHANGER
CLOSE
OPEN
3
2
1
CNS701
RD
BK
BL 1
12
LSOLM1
TAPE MOTOR
SOLNOID
MM1 M
H
SWM5
CAM
