INSTRUCTION MANUAL
Read entire manual before operating this product.
Use only as directed.
SIX PACK ABS
Item No. 206098

• If you are in the care of a physician, consult
your physician before using this device.
• DO NOT use this device if you have a
cardiac pacemaker, implanted debrillator,
or other implanted metallic or electronic
devices.
• DO NOT place this device over your neck.
• DO NOT place this device across your
chest.
• DO NOT use this device during pregnancy.
• DO NOT use this device on children.
• DO NOT place this device over the carotid
sinus nerves, the front of the neck, or
around the mouth.
• DO NOT open unit. Opening will void
warranty.
• DO NOT use this device over, or in
proximity to, cancerous lesions.
• DO NOT place device over open wounds,
sores, or rashes, or over swollen, red,
infected, or inamed areas or skin eruptions
(e.g., phlebitis, thrombosis, varicose veins).
• DO NOT use this device when in bath or
shower.
• DO NOT use this device while sleeping.
• DO NOT use this device while driving or
operating machinery.
• DO NOT use this device in the presence of
electromagnetic elds.
• DO NOT use this device if unit has been
damaged.
• DO NOT use on children or pets.
• DO NOT use in an area where water or
moisture can get on the unit, such as
a bathroom or other places with high
humidity.
WARNINGS
PRECAUTIONS
• The long-term effects of electrical
stimulation are unknown.
• Since the effects of stimulation of the brain
are unknown, stimulation should not be
applied across your head.
• The safety of electrical stimulation during
pregnancy has not been established.
• Use caution if you have a tendency to
bleed internally, such as following an injury
or fracture.
• You may experience skin irritation or
hypersensitivity.
• If you have suspected or diagnosed heart
disease, you should follow precautions
recommended by your physician.
• Keep this device out of the reach of
children.
• If you have suspected or diagnosed
epilepsy, you should follow precautions
recommended by your physician.
• Consult with your physician prior to
using the device after a recent surgical
procedure, because stimulation may
disrupt the healing process.
• Use caution if stimulation is applied over
the menstruating or pregnant uterus.
• Use caution if stimulation is applied over
areas of skin that lack normal sensation.
• Use this device only with the electrodes
and accessories recommended by the
manufacturer.
• Avoid placing the pads over metal
implants.

ADVERSE EFFECTS
• Skin irritation and burns beneath the stimulation electrodes applied to
your skin can occur.
• On very rare occasions, rst-time users of EMS have reported feeling light-
headed or faint. We recommend that you use the product while seated
until you become accustomed to the sensation.
Power Supply: DC 3.7v
Output Voltages: 55 V at 500 Ω
Pulse Width: 100 µS
Frequency: 0-200 Hz
Timer: 20 min
Intensity: 15 Levels
Modes: 5 Pulse Modes
Operation Condition: -10~40 °C, 30%~85% Humidity
Storage Condition: -10~50 °C, 10%~95% Humidity
Transportation Condition: -10~50 °C, 35%~85% Humidity
SPECIFICATIONS
You should stop using the device and consult with your
physician if you experience adverse reactions from the device.
The Sharper Image SixPackTM Abs deliverselectrical pulses through the
included electrodes. Each features multiple modes of different pulse
frequencies, providing Electrical Muscle Stimulation (EMS), as well as
Transcutaneous Electrical Nerve Stimulation (TENS). There are 5 pulse
modes, each with 15 intensity levels. Each unit includes conductive gel
pads and one USB charging cable.
Indications for Use
Use SixPackTM Abs to stimulate healthy abdominal muscles in order to
improve and facilitate muscle performance. It is also intended for
temporary relief of pain associated with sore and aching abdominal
muscles from exercise or normal work activities.
INTRODUCTION

UNIT DIAGRAM
1. Electrodes (on back of unit)
2. + button (increase intensity, change pulse mode)
3. LED light
4. Power button
5. - button (decrease intensity)
6. Control panel
SixPackTM Abs
6
2
3
4
5
1 1
1 1
1 1

1. With the SixPackTM Abs turned off, remove the backing from
a single gel pad and align the gel pad with the SixPackTM
Abs electrode. Place the gel pad onto the electrode, making
sure to completely cover the electrode. Repeat for each of
the electrodes.
2. Remove the second backing from each of the gel pads.
3. After making sure your skin is clean and dry, place the
SixPackTM Abs onto the muscle group you wish to target. If
using the SixPackTM Abs, the control panel should be located
over the belly button.
4. Turn the electrodes on by pressing the power button. The
LED light will blink and the unit will beep. The intensity will
be on the lowest setting.
5. Press the + or - buttons to adjust intensity. The LED light will
blink and a beep will sound to indicate a successful level
change. There are 15 intensity levels.
Use for 20 minutes at a time, 1-2 times per day per area.
6. When the session is complete, power off the unit by pressing
the power button and place it onto the mounting sheet.
7. To charge the unit, connect the USB cable to the device and
plug into a USB wall adapter for 20 minutes.
8. Best results are achieved with a combination of diet and
exercise.
USING THE SIXPACKTM
The device has multiple modes, covering EMS, as well as TENS.
If you are using the device for the rst time, it is recommended
that you start with the default Mode 1 for improving muscle
performance. After the muscle training, you may feel sore and
aching muscles due to strain from exercise. We recommend you
follow up with one of the TENS modes, as they are good for the
relief of such pain. Please see the EMS and TENS modes in the
following table.
PULSE MODES
Continues Next Page

• Before applying the unit to the skin, make sure to clean the
desired area beforehand. To clean skin, simply wet a towel or
napkin with rubbing alcohol and gently wipe the area.
• It is recommended to remove excess hair from the desired
workout area in order to maximize product lifespan.
• Do not apply lotions or oils before using the device as this will
prevent the gel pad from sticking to the skin.
• When done with your workout session, make sure to place the
unit onto the protective plastic sheet.
• Only use the provided plastic sheet for storing the product
and gel pads. This plastic sheet is designed to maximize the
lifespan of the gel pads.
• The lifespan of the gel pads will vary depending on the
use frequency and care taken. Keeping gel pads clean and
stored properly on the provided plastic sheet will extend
their lifespan. Replace the gel pads when they lose their
adhesiveness.
GEL PAD MAINTENANCE
PULSE MODES (continued)
Hold down the + button for 3 seconds to change the mode.
Successful mode change will be indicated by the LED light
ashing twice and two audible beeps.
1. Mode 1(EMS): Stimulation of healthy muscles in order to
improve and facilitate muscle performance
2. Mode 2 (TENS): Relief of pain associated with sore and
aching muscles due to strain from exercise or work activities
3. Mode 3 (EMS): Visible muscle contraction seen for
improving muscle performance
4. Mode 4 (TENS): Deeper relief of pain associated with sore
and aching muscles due to strain from exercise or work
activities
5. Mode 5 (EMS and TENS): Combination of the benet from
both EMS and TENS

• To remove gel pads from electrodes, gently roll the edge of
the gel pad back with your thumb. When rolled back correctly,
the gel pad will roll off in one single piece as seen in Figure 1.
•Stimulation is weak or non-existent
Be sure skin is clean and pads are firmly attached.
•Device does not turn on
Recharge for 20 minutes.
•Gel pads are not sticky
The gel pads will lose adhesiveness over the course of use.
Please visit SharperImage.com for replacements.
TROUBLESHOOTING
Figure 1

Read Instructions
Before Operating
MADE IN
CHINA
Sharper Image branded items purchased from SharperImage.com include a 1-year limited replacement warranty. For Customer
Service, please call 1 [phone].
DO NOT DISPOSE OF BATTERIES IN FIRE. ALWAYS DISPOSE OF BATTERIES PER LOCAL & FEDERAL GUIDELINES.
The SHARPER IMAGE® name and logo are registered trademarks.
©Sharper Image. All Rights Reserved.
