Sharper Image HW562 User manual

iJoy®Turbo 2
Robotic Massage®
Chair
HW562 Instructions
Read and save these instructions.
1SPEVDUJE
VOMFBTI
ZPVS
NVTJD
VOMFBTI
ZPVS
NVTJD
-PHPSFWFSTFEPVUPGBQIPUP

Dear Sharper Image Customer,
Thank you for your purchase of a Sharper Image product. We appreciate
your business very much.
Please accept my personal assurance of your complete satisfaction with
this product’s quality and performance. We offer generous return
privileges and excellent warranties on all our products.
For more than 25 years, The Sharper Image has shared the fun of
discovering innovative products that make life better and more enjoy-
able. We’ve been in business a long time because we are an exciting
place to shop and — just as importantly — we strive to deliver great
customer service that exceeds your expectations.
Enjoy your purchase!
Respectfully,
Richard Thalheimer
Founder, Chairman and Chief Executive Officer
Call 1-800-344-4444 for 24-7 ordering and customer service,
or go to , our complete online store.

Table of Contents
Important Safety Instructions .....................................................6
Warnings................................................................................9
Grounding Instructions.........................................................15
Massage Chair Safety Precautions.........................................17
Quick Start ..............................................................................19
Important Assembly Instructions and Operation ...................19
iJoy®Turbo 2 Instructions .........................................................23
Introduction.........................................................................23
Massage Softening Pad .........................................................24
Built-In Power Outlet ...........................................................25
Basic Operating Instructions .................................................26
Massage Functions ...............................................................28
Product Care & Storage........................................................35
iJoy®Turbo 2 Specifications..................................................36
ZipConnect™ Instructions........................................................38
Introduction.........................................................................38
ZipConnect™ Operation......................................................39
Table of Contents
Changing the ZipConnect™ Module ....................................40
Limited One-Year Warranty......................................................42
Extended Warranties ............................................................46

Important Safety Instructions
THE APPARATUS SHOULD NOT BE EXPOSED TO DRIPPING
OR SPLASHING. OBJECTS FILLED WITH LIQUIDS, SUCH AS
VASES, SHOULD NOT BE PLACED ON THE APPARATUS.
READ AND SAVE THESE INSTRUCTIONS
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this product near water.
•Clean only with a dry cloth.
•Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
•Do not install near any heat sources such as radiators, heat
registers, stoves or other products (including amplifiers) that
produce heat.
•Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding-type plug has two blades and a third
7
Important Safety Instructions
CAUTION: TO AVOID THE HAZARDS OF FIRE OR ELECTRI-
CAL SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
OTHER MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT. FULLY INSERT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
66

Important Safety Instructions
9
• Unplug this product during lightning storms or when left un-
used for a long period of time.
• Refer all servicing to qualified service personnel. Servicing is
required when the product has been damaged in any way,
such as if the power supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the product, the prod-
uct has been exposed to rain or moisture, does not operate
normally or has been dropped.
Warnings
PLEASE READ: To achieve the maximum results from your
iJoy®Turbo 2 ZipConnect™ Robotic Massage®Chair, carefully
read this manual. For additional questions, please call Interac-
tive Health®Customer Service Representatives at
[phone].
CAUTION: Only for household use. Please read and observe
these safety instructions carefully to reduce the possibility of
fire or injury.
Important Safety Instructions
grounding prong. The wide blade and/or the third prong are
provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the
obsolete outlet.
•Protect the power cord from being walked on or pinched at
plugs, convenience receptacles (e.g. standard wall outlets) and
the point where they exit from the product.
•Only use attachments/accessories specified by the
manufacturer.
•Use only with the cart, stand, tripod, bracket or table specified by
the manufacturer, or sold with the product. When a cart is used,
use caution when moving the cart/apparatus combination to
avoid injury from tip-over.
Portable Cart Warning (Symbol provided by RETAC) S3125A
8

•If you detect a malfunction or any other abnormal condition in
the operation of your chair, turn off the power immediately and
disconnect the power cord from the outlet.
•If you feel severe discomfort during the operation of your
massage chair, stop using the chair and consult your physician.
•Should you have a power failure, turn the MASTER switch to
the OFF position.
•You should not use the chair for more than 15 minutes at
one time.
•If the chair has gotten wet or exposed to moisture, turn the
chair off, unplug it from the wall socket and call Interactive
Health®customer service.
•Keep your massage chair clean and away from humidity.
Read all instructions before using the iJoy®Turbo 2 ZipConnect™
Robotic Massage®Chair.
Warnings
11
•People with the following conditions should consult their
physician prior to using this massage chair:
a) Malignant tumor.
b) Heart Disease.
c) Pregnancy.
d) Conditions requiring rest.
e) Back Disease or back trouble from an injury or accident.
•Do not use your massage chair in an excessively humid or
dusty environment.
•Your massage chair should be operated at a room temperature
of between 40° and 100°F.
•Ensure all operation switches are in the OFF position before
connecting the power cord to an electrical outlet.
•Do not use attachments that are not recommended by the
manufacturer.
•When not in use, turn the MASTER switch on the back of the
chair to the OFF position.
Warnings
10

•Use this appliance only for its intended use as described in
this manual.
•Do not use attachments not recommended by the
manufacturer.
•Never operate this appliance if it has a damaged cord or plug, if
it is not working properly, if it has been dropped or damaged, or
dropped into water. Return the appliance to a service center for
examination and repair.
•Always keep the power cord away from heated surfaces.
•Never operate the appliance with the air openings blocked.
Keep the air openings free of lint, hair and the like.
•Never drop or insert any object into any opening.
•Do not use outdoors.
•Do not operate where aerosol (spray) products are being
used or where oxygen is being administered.
•To disconnect, turn all controls to the OFF position, then
remove plug from outlet.
Warnings
13
WARNING: Do not put hands or fingers near the massage
mechanism or rollers while the iJoy®Turbo 2 is running.
Touching the mechanism can result in injury from the rollers
squeezing together.
DANGER: To reduce the risk of electrical shock:
•Always unplug massager from the electrical outlet immediately
after using and before cleaning.
•Do not reach for an appliance that has fallen into water.
Unplug immediately.
WARNING: To reduce the risk of burns, fire, electric shock or
injury to persons:
•Never leave an appliance unattended when plugged in.
•Unplug from outlet when not in use, and before putting on or
taking off parts.
•Do not operate under blanket or pillow. Excessive heating can
occur and cause fire, electric shock, or injury to persons.
•Close supervision is necessary when this appliance is used by,
on or near children, invalids or disabled persons.
Warnings
12

For all grounded cord connected products:
This product must be grounded. If it should malfunction or
breakdown, grounding provides a path of least resistance for
electrical current to reduce the risk of electric shock. This prod-
uct is equipped with a cord having an equipment-grounding
conductor and a grounding plug. The plug must be plugged into
an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
WARNING: Improper connection of the equipment-grounding
conductor can result in a risk of electronic shock. Check with
a qualified electrician or serviceman if you are in doubt as to
whether this product is properly grounded. Do not modify
the plug provided with the product. If it will not fit the outlet,
have a proper outlet installed by a qualified electrician.
This product is for use on a normal 120-volt circuit and has a
grounding plug that looks like the plug illustrated in sketch (A).
A temporary adapter that looks like the adapter used in sketches
(B) and (C) may be used to connect this plug to a two-pole
Grounding Instructions
15
•Do not massage abdomen when pain is present or if you
are pregnant.
•Do not massage any area of the body that is swollen, inflamed
or covered with skin eruptions. Do not use on unexplained
calf pain.
•Do not use massager when standing on a damp floor, or when
any part of the body is in contact with plumbing or any similar
ground.
•Always connect massager to a properly grounded electrical
outlet.
•This unit is designed to operate on standard 120-Volt 60Hz
household current.
•Do not use unit if noise above normal sound is heard.
•The unit is designed for personal in-home use. Commercial use
will void warranty.
SAVE THESE INSTRUCTIONS
Warnings
14

suddenly stop and will not start, turn the MASTER switch, located
on the back of the chair, to the OFF position and do not operate
the chair for at least 30 minutes. Failure to turn the chair off may
result in the chair starting unexpectedly when the device cools.
Massage Chair Safety Precautions
•Comfortable clothing is recommended while using your
massage chair.
•Your massage chair is meant to be used in a relaxed position.
While sitting in the chair, never force any body part into the
backrest area while the rollers are moving.
•Do not allow children to use the massage chair.
•If you feel any abnormal discomfort during the operation of
your massage chair, turn off the power immediately and do
not use the chair. Consult your physician.
•Do not sit on the control panel.
•Do not pull on the AC power cord.
Grounding Instructions
17
receptacle as shown in sketch (B), if a properly grounded plug
is not available. The temporary adapter should be used only
until a properly grounded outlet sketch (A) can be installed by a
qualified electrician. The green colored, rigid ear tab or the like
extending from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover. Whenever
the adapter is used, it must be held in place by a metal screw.
Grounding Methods:
WARNING: Your chair is equipped with a thermal resetting
protection device. This is an added safety feature to protect you
and your massage chair from overheating. If the chair should
Grounded
Outlet
Grounding
pin (A) (B)
Grounded
Outlet Box
Adapter
Metal
Screw
Tab for
Grounding
Screw
(C)
Grounding Instructions
16

Important Assembly Instructions and Operation
Step 1: Connect the headrest wires to the top of the backrest.
Step 2: Align and insert the headrest posts into the two black
metal openings located on the top of the backrest.
(See Figure 1.)
Quick Start
19
Figure 1
•Always confirm that there are no obstacles behind the chair and
that there is sufficient space to recline.
•When using your massage chair after it has been in storage,
check to see that the chair is operating properly prior to sitting
in the chair.
•
Do not attempt to repair your massage chair.
If a malfunction occurs, please contact Interactive Health®at
[phone].
Massage Chair Safety Precautions
18

CHILD SAFETY LOCK down to the LOCK position when the
chair is not in use.
Step 5: For a milder massage, if desired, unzip the outer panel
on the backrest and insert the included massage soften-
ing pad into the open pocket. Close the zipper on the
backrest. (See Figure 4.)
Step 6: Open the convenient cupholder, located on the front of
the right-hand armrest, to support your favorite beverage.
(See Figure 5.)
Important Assembly Instructions and Operation
21
Figure 4
Figure 5
Step 3: Plug the AC power cord into a grounded wall outlet and
turn the MASTER switch to ON. (See Figure 2.)
Step 4: To activate the MASTER switch, slide the CHILD SAFETY
LOCK up to the UNLOCK position.
Important: To prevent children from using the iJoy®when left
unattended, always turn the MASTER switch OFF and slide the
Important Assembly Instructions and Operation
20
Figure 2
Figure 3

Introduction
Your iJoy®Turbo 2 ZipConnect™ Robotic Massage®Chair is a
quality piece of furniture, and should be used and cared for like
the rest of the furniture in your home.
The HTT®Robotic Massage®system inside your chair is a sophis-
ticated electro-mechanical device that requires some special care
and safety precautions.
Please follow these basic guidelines carefully. They are provided
to ensure the maximum enjoyment of your chair.
New Human Touch Technology®
Your new massage chair includes the revolutionary HTT®.
HTT®is a true step forward in Robotic Massage®technology. The
result of years of research and development, this revolutionary
system emulates the latest techniques used by massage and chiro-
practic professionals for back and spinal care.
iJoy®Turbo 2 Instructions
23
Step 7: Use the built-in ZipConnect™ audio console on the
right-hand armrest to listen to music through any audio
player with a headphone jack. (See Figure 6.) For more
information on using the ZipConnect™ console, see the
ZipConnect™ Instructions later in this manual.
Important Assembly Instructions and Operation
22
Figure 6

Warning: Do not use this outlet to power any appliance requir-
ing more than 100 Watts (.83 Amps).
Common Appliances Under 100 Watts: Laptop computer; por-
table MP3 player with AC adapter.
Common Appliances Over 100 Watts: Iron; hair dryer; vacuum;
stereo system.
Built-In Power Outlet
25
How does it work?
It starts with a multipatent-pending mechanism that is designed
to act like “wrists” and “arms.” Then, the built-in “hands” con-
sist of two three-dimensional moving discs that are surrounded
by a firm, yet comfortable material that feels like “fingers” and
“thumbs.” Working together, these robotic components deliver a
variety of massage functions that feel great and really work.
Massage Softening Pad
This pad can be used to soften the intensity of the massage.
To Install:
1. Unzip the zipper located on the front side of the backrest. In-
side, you will see a pocket. (See Figure 4 in the Quick Start.)
2. Insert the included massage softening pad into this pocket
and close the zipper.
Note: After installing the softening pad, you will find the massage
to be less intense. To intensify the massage, remove the softening
pad. Additional softening pads are available for purchase from
Interactive Health®.
Introduction
24

2. STOP/AUTO PARK Button: Stops all massage functions and
parks the massage rollers in the highest position.
3. RECLINE Button: Reclines the backrest.
4. RECLINE Button: Brings the backrest to the desired
upright position.
5. MANUAL POSITION :Moves the massage rollers up
the backrest.
6. MANUAL POSITION :Moves the massage rollers down
the backrest.
7. MANUAL POSITION PARTIAL :Moves the massage
rollers in a partial stroke, up and down 3 inches from the
set position, after selecting AUTO KNEADING or AUTO
COMPRESSION massage.
8. AUTO ROLLING Button: Moves the massage rollers up
and down.
9. AUTO KNEADING Button: Moves the massage rollers
in a kneading motion.
Basic Operating Instructions
27
Control Panel Functions
1. Green Power LED: Illuminates when the MASTER switch is
turned ON.
Basic Operating Instructions
26
2
4
3
5
6
7
8 9
10 11 14
121
13

Plus, you can choose an automatic program mode that will run a
varied massage session.
Up/Down Massage Modes
Rolling
Description: Oval-elliptical nodes slowly and gently move up
and down your back, near the spine, gently alternating side
to side.
Feels Like: The hands of a therapist pressing firmly yet gently on
your muscles, first on one side of the spine, then on the other.
Massage Technique: Emulates effleurage, the first part of a
massage performed by a professional massage therapist. It is de-
signed to warm-up and loosen the muscles to relieve tension and
prepare the back for a deeper, therapeutic massage.
Massage Functions
29
10.AUTO COMPRESSION Button: Moves the massage rollers
in a compression motion.
11.AUTO PERCUSSION Button: Moves the massage rollers
in a percussion motion.
12.FULL PROGRAM Button: Activates a continuous 15-
minute program that consists of a series of combined
functions for your entire back.
13.UPPER PROGRAM Button: Activates a continuous 15-
minute program that consists of a series of combined
functions for your upper back only.
14.LOWER PROGRAM Button: Activates a continuous 15-
minute program that consists of a series of combined
functions for your lower back only.
Massage Functions
As with all Interactive Health®Robotic Massage®chairs, you can
customize the massage to your own needs. You can select the
massage functions, pinpoint the massage anywhere on your back
or let the massage automatically move up and down your spine.
Basic Operating Instructions
28

Benefits: Relieves tension and soreness by lifting and stretching
muscles; improves circulation and helps bring vital nutrients to
the spinal area.
Compression*
*Compression massage is an exclusive feature of the Interactive
Health®HTT®product line.
Description: Alternating strokes along the back that press on
both spinal muscles and spinal joint areas.
Feels Like: Heels of hand firmly pushing on muscles along the
side of the spine, then in toward the spine. Alternating “hands”
also deliver a soothing rocking motion for the body.
Massage Functions
31
Benefits: Relieves muscle tension; improves circulation and
relaxes the back.
Kneading
Description: Massage nodes move in a small, circular motion on
both sides of the spine simultaneously.
Feels Like: The thumbs or heels of the hand pressing firmly in a
circular motion on both sides of the spine.
Massage Technique: Emulates the thumb kneading performed
by a massage therapist or other professional. This second phase of
massage is slightly more intense than the rolling and is considered
to be more of a deep muscle massage.
Massage Functions
30

sion can also be applied in a single area. Use the MANUAL POSI-
TION and after selecting COMPRESSION to direct the
massage to a specific area.
Percussion
Description: Alternating strokes along the spine that stimulate
both spinal muscles and spinal joint areas.
Feels Like: Fists or the length of the hand rapidly tapping on back
muscles.
Massage Technique: Emulates percussive massage, popular in
sports medicine and deep muscle therapy.
Benefits: Flexes spinal joints and relieves pressure on the spinal
column. Invigorates the entire back area.
Massage Functions
33
Massage Technique: Emulates massage technique frequently
used in sports medicine and in spinal therapy by chiropractors.
The motion spreads and places pressure on deep muscle tissue,
forcing it to relax. The rocking motion also loosens spinal joints in
a manner characteristic of spinal therapy.
Benefits: Aids in muscle and joint repair due to strain from exer-
cise, long hours spent bent over a desk or high stress levels. It can
also improve mobility and overall posture.
Stationary Massage Modes
Kneading
The same feeling and benefits described in Up/Down Kneading
can also be applied in a single area. Use the MANUAL POSI-
TION and after selecting KNEADING to direct the
massage to a specific area.
Compression
The same feeling and benefits described in Up/Down Compres-
Massage Functions
32

To keep your product working and looking its best, please follow
these simple care guidelines:
General Maintenance
1. Ensure the power cord is disconnected from the electrical
outlet before cleaning.
2. Do not use benzene, thinner or any other solvents on your
massage chair.
3. Remove dust on the backrest or armrest with a vacuum.
4. If the backrest or armrest becomes soiled, first wipe with a
damp cloth, then with a dry cloth.
5. Common velour cleaners may be used for tough stains. Please
follow all manufacturer’s instructions on velour cleaner
packaging and pre-test any cleaner on a small inconspicu-
ous area prior to use.
6. When cleaning the control panel or around the MASTER
switch, use a dry cloth only. Never use a damp cloth to
clean the control panel or MASTER switch.
Product Care & Storage
35
Manual Position / Feature
This feature manually moves the massage mechanism up or down
the back to a specific area and should be used with any station-
ary massage mode.
Programmed Massage Session
This feature utilizes all of the features listed above in a pre-deter-
mined program. Just sit back, relax and enjoy your massage. (See
Control Panel Functions for more information.)
Massage Functions
34

Weight: 95 lbs.
Recline Angle: 110° - 160°
Number of Massage Functions: Four (4)
Massage Head Storage: Auto at Top
Automatic Timer Shut-Off: 15 minutes
Total Massage Stroke Length: 20 Inches
Full Length Travel: 43 Seconds
Rolling: 1 Speed
Kneading: 1 Speed
Compression: 1 Speed
Percussion: 1 Speed
Up/Down: 45 Inches/Minute
Accessories: Rubber Pad for Audio Player
Massage Softening Pad
*Specifications are subject to change without prior notice.
iJoy®Turbo 2 Specifications
37
7. It is suggested that you cover the chair when it will not be in
use for a long period of time.
8. The mechanics of this product are specially designed and
constructed to be maintenance free. No periodic lubrication
or servicing is required.
9. Foreign objects should not be inserted between the massage
nodes or the unit housing.
10.When not in use for a long period of time, we recommend
that the power cord be coiled and that the unit be placed in
an environment free of dust and moisture.
11.Do not store near heat or an open flame. Do not leave this
product exposed to direct sunlight for long periods of time.
This may cause fading or damage.
iJoy®Turbo 2 Specifications
Operating Voltage: AC 110 - 120V 60Hz
Power Consumption: 90 Watts
Size (L x W x H; Reclined): 591⁄2"x 333⁄4"x 19"
Product Care & Storage
36

3. To activate the amplifier and speaker inside the massage chair,
press the POWER button on the ZipConnect™ console built
into the right-hand armrest.
4. Turn on the connected audio player according to the
manufacturer’s instructions.
5. Set the volume on your personal audio player to about 70%
of the maximum volume.
Note: You may need to adjust the volume on your personal
audio player above or below 70% to achieve a desired volume
level or to reduce distortion. Start at 70% of maximum volume
and adjust from there.
6. To adjust the volume of the built-in speakers, press the
VOLUME +/– buttons on the ZipConnect™ console.
Note: Some lightweight personal audio players may vibrate when
placed on the ZipConnect™ console. To minimize vibrations, use
the included rubber pad.
7. Remove the mini plug from your audio player after use.
ZipConnect™Operation
39
Introduction
The ZipConnect™ built into your iJoy®Turbo 2 ZipConnect™
Robotic Massage®Chair allows you to conveniently connect any
audio player with a headphone jack (MP3 player, iPod®, portable
CD player) and play music through the chair’s built-in stereo
speakers and subwoofer.
The ZipConnect™ interchangeable module features a retractable
cable that is compatible with any standard headphone jack. For
the iPod, iPod mini or iPod Shuffle™, you may purchase special
interchangeable ZipConnect™ modules with a custom designed
connection that charges your iPod’s internal battery as you
listen to music. These ZipConnect™ charge+play modules
for iPods, iPod minis and iPod Shuffle are available from The
Sharper Image by calling 1-800-344-4444, ordering online
at www.sharperimage.com or visiting a Sharper Image store
near you. (See Replacing the ZipConnect™ Module for
more information.)
1. To extend the ZipConnect™ cable, slowly pull on the mini plug.
2. Insert the mini plug into the headphone jack of your audio player.
38
ZipConnect™Instructions
