Sharper Image Relieve 3D User manual

RELIEVE 3D
MASSAGE CHAIR
SHARPER IMAGE
USER MANUAL
R

WELCOME TO
Thank you, and congratulations on purchusing your very own Sharper Image
Massage Chair - you’ve made a great buying decision.
Sharper Image is an american company founded in 1977 that offers products
that give people a taste of the future. The brand was the brainchild of Richard
Thalheimer, and started as a catalog business to sell advanced jogging watches.
Later, through what had become an iconic catalog, Sharper Image expanded its
product line and positioned itself as an iconic American brand for futuristic products.
Inside this manual, you are going to find everything you need to safely operate your
chair. If at any point you are having difficulties, or we havent answered one of your
questions, please dont hesitate to contact our outstanding customer service team at
888-894-9150. We are here for you.
To ensure you don’t overlook any of your chair’s features, and that you use it safely,
please read this manual carefully and keep for future reference. If you lose this
manual, refer to our website www.sharperimagemassagechairs.com. Here you
will find additional resources, copies of all documents, and tutorial videos on our
products.
Register your product at www.sharperimagemassagechairs.com/
warranty/registration to ensure it is in our system. This will simplify
the warranty process should you ever need it.
Alternatively, scan the QR code to go directly to the URL above. SCAN CODE

EXTERNAL STRUCTURE
POWER PANEL
MASSAGE CHAIR TERMINOLOGY
Shoulder Airbags
Headrest
Speakers
Backrest Cushion
Quick Access Panel
Arm Airbags
Controller Holder
Hip Airbags
Legrest
Footrest
Casters
Main Power Switch
Fuse
Power Cord Port

TABLE OF CONTENTS
INSTALLATION & PLACEMENT
REMOTE CONTROL BUTTONS
REMOTE & MASSAGE CHAIR OPERATION
PRODUCT CARE & STORAGE
CUSTOM MASSAGE
BLUETOOTH SPEAKERS
RELIEVE 3D APP
SPECIFICATIONS
SAFETY PRECAUTIONS
FCC INFORMATION
LIMITED WARRANTY
TROUBLESHOOTING
Moving the Massage Chair
Chair Placement
Preparing the Massage Chair
Turning off the Massage Chair
6
6
7
7
Remote Diagram
In-Use Screen Remote Display
Quick Acess Panel
Starting, Pausing, & Stopping Your Massage
Main Menu Options
Body Scanning
8
9
9
10
10
11
Storing the Massage Chair
Cleaning the Massage Chair
Custom Massage Configuration
Pairing a Device
Using the Relieve 3D App
16
16
12
14
15
17
Caution
Grounding Instructions
19
20
21
22
18

6
SHARPER IMAGE R
MOVING THE MASSAGE CHAIR
CHAIR PLACEMENT
INSTALLATION & PLACEMENT
As illustrated, push the backrest downwards and
tilt the chair onto its wheels at a 45 angle. Slowly
push and maneuver the massage chair to the
desired location. Lower the chair slowly until it is
fully flat on the floor.
Caution:
- Do not move the massage chair when
occupied or in use.
- Moving the massage chair may damage floors.
We recommend moving the chair on rugs or
carpeted floors.
- Do not drop or suddenly let go of the chair
when moving it, as this may damage the chair
or the floor.
- We advise two people move the massage chair
together.
When placing your massage chair, be sure to
leave at least 3-4 inches of space between the
back of the chair and any wall or other objects to
allow it to recline safely.
When using the massage chair, ensure there are
no people, pets, or objects within 32 inches of the
chair to allow the footrest to extend safely.
Caution:
- In order to avoid damage or injury, do not place
the massage chair on a wet or uneven floor.
3 - 4 in. 32 in.
45°45°

7
SHARPER IMAGE R
PREPARING THE MASSAGE CHAIR
TURNING OFF THE MASSAGE CHAIR
2. Check the surrounding environment.
- Make sure there are no objects, pets, or small children around
the massage chair before using it.
3. Connect the chair to power:
- Connect the power cord to the chair, and then to a grounded
110V outlet.
- Turn on the power switch on the power box, located on the
rear of the chair.
1. After the massage program is completed, press the Power
button on the massage chair remote to turn it off. The chair
will reset to its original upright position.
- Ensure the surrounding area is clear of any pets, children, or
objects prior to turning off and resetting the chair.
- Keep your arms and legs away from gaps between the
armrest, legrest, and footrest to prevent any pinching or injury.
2. Exit chair and turn off the main power switch on the back of
the chair at the power panel.
3. Unplug the power cord from the outlet.
- Do not pull on the cord to unplug from the wall.
- Do not handle the power cord with wet hands.
Main power switch

8
SHARPER IMAGE R
REMOTE CONTROL BUTTONS
REMOTE DIAGRAM
Press buttons to make selection
OK
Zero Gravity
Pause
Power
Menu
Navigation
Control
Backrest
Position
Automatic
Programs
Quick (Demo) Program
Heat
3D Effect
Foot Rest Position
Foot Rest Rollers
and Airbags
Display Screen

9
SHARPER IMAGE R
INUSE SCREEN REMOTE DISPLAY
QUICK ACCESS PANEL DIAGRAM
Full
SPEED
AIR
WIDTH
ROLLER
1
2
3
4
6
5
8
7
910
VIGOR Back-roller position
6
Active Back Zone
7
Heat
8
Zero Gravit
9
Bluetooth
10
1Shoulder Adjust Indicator
2Active Rollers
3Meters
4Time Remaining
Active Massage Technique
5
2
ZERO
G
1
3
AUTO
4
5
y
1Volume Up/Volume Down
Bluetooth Button
2Bluetooth LED Indicator
3USB Charging Port
6Preset Automatic Programs-
While running an Automatic
Program, press and holdAuto
1, 2, or 3. The button will be set
to the current program. To run
the program in the future,
press the Auto 1, 2, or 3 button.
AUTO
Pause - Press this button to
force stop the chair during a
program
43D Level Up/Down -When
setting the 3D level, use the 3D
Level Up and 3D Level Down
buttons to change the depth
of the massage node rotation.
53D LED Indicator -The 3D LED
Indicator displays the depth.
3D Button
Power - Powers up the chair or
returns the chair to the exit
position and powers down
chair
ZERO
GEnter/Exit Zero Gravity Position -
Press the Zero Gravity button
on the controller to activate
Zero Gravity. Press again to
deactivate.
Play/Pause Sound

10
SHARPER IMAGE R
STARTING, PAUSING, AND STOPPING YOUR MASSAGE
MAIN MENU OPTIONS
REMOTE & MASSAGE CHAIR OPERATION
- To turn on the massage chair, click on the main power switch on the back of the chair, then
press the Power button on the controller, or on the Quick Access Panel . The chair moves
to its Home position (legrest slightly raised, backrest slightly reclined, rollers in upper part of
backrest), and the Menu Panel on the controller lights up.
- If no selection is made after 3 minutes, the chair will go into sleep mode and the Menu Panel
light will go off. The first press of the Power Button will wake the controller up; the second
press of the Power Button will return the chair to the Exit position. Any button pressed on the
controller will wake the controller from sleep mode.
- To pause the motion and timer, press the Pause Button on the controller, or on the Quick
Access Panel . The chair will enter idle mode. The air cells deflate, but the rollers do not
return to their Home position. Press again to resume your massage.
- To turn off the massage chair, ensure that there are no obstacles under the foot rest and
press the Power button on the controller, or on the Quick Access Panel, or in the Relieve 3D
app. The rollers return to their Home position, all air cells deflate, and the chair moves to the
Exit position. Click off the main power switch on the back of the chair and unplug the chair.
When you turn on the massage chair, the Display screen becomes active and displays the
Main Menu.
Press buttons to make selection
OK
