CCS MFU Series User manual

- 1 -
MFU Series
Instruction Guide
Thank you for purchasing a CCS product. To ensure proper use of the product,
please read this instruction guide before use and keep it for your future reference.
LED Light for Machine Vision
and Industrial Inspection
Operating Instructions3
Read the instruction guide of the Control Unit before use.
MANDATORY
ACTIO NS
MANDATORY
ACTIO NS
Make sure that the Control Unit for the LED Light is turned OFF.
For capturing the image using the Light Unit, it is necessary to use
a goniometer stage and others to precisely locate the equipment.
For detailed information on imaging procedures, refer to MFU series
Operating Procedures on the CCS web pages.
For information on applicable Control Units and cables, refer to the product
catalogs or the CCS web pages.
Connect the light cable of the Light Unit to the Control Unit.
1
Insert the plug all the way into the connector.
Turn ON the Control Unit to turn ON the light.
2
Adjust light range and radiant quantity to optimize images.
3
Inspection object
MFU series
Control Unit
- Conceptual Diagram -
The following tag is attached to the cable on the LED Light. The
color of the label indicates the luminescence color of the Light. The
back of the tag there is a name label that gives the model number,
power consumption, and serial number.
Be sure to check the contents before using the product and handle
the label with care. If the label is missing or damaged and the
contents cannot be checked, please contact CCS Inc.
Conrming Product Information2
PROHIBITED
DISASSEMBLY
PROHIBITED
DO NOT TOUCH
WITH WET HANDS
DO NOT SUBJECT
TO MOISTURE
MANDATORY
ACTIO NS
These symbols indicate prohibited actions. This symbol indicates required actions.
The following symbols in the Instruction Guide indicate and classify the precautions.
The following symbols are used in this instruction guide to indicate and
classify the relative importance of warnings and cautions.
Warning
Indicates that incorrect
usage may result in serious
injury or death.
Caution
Indicates that incorrect
usage may result in injury
or property damage.
These products have been designed with full consideration of safety. However,
incorrect usage of the products may result in fire, electric shock, or other serious
damages. Please ensure to follow the conditions below.
Important Information for Equipment Safety
- Read Before Use -
1
Warning
Do not disassemble or modify the
Light Unit. Doing so may result in
re or electric shock.
DISASSEMBLY
PROHIBITED
LED Light radiation may cause
corneal or retinal abnormalities
if you look directly at the light. To
prevent harmful light exposure,
never look directly at the LED Light.
MANDATORY
ACTIONS
Do not touch the Light Unit with
wet hands. Doing so may result in
electric shock.
DO NOT TOUCH
WITH WET HANDS
This Light Unit generates high
temperatures. Do not touch the Light
Unit while it is turned on or immediately
after it is turned off, or burning may
result. Provide cooling with a fan or
other ventilation if the Light Unit is to
be used in a closed space.
MANDATORY
ACTIONS
Make sure that the Light Unit is free
of moisture or any liquid. Exposure
to water may result in re, electric
shock.
DO NOT SUBJECT
TO MOISTURE
Connect or disconnect the light
cable only after turning off the
power source. Failure to do so
may result in circuit damage, fire
caused by a minute spark, or
electric shock.
MANDATORY
ACTIONS
If abnormal condition occurs such as fuming, heat, smell, noise, or so on,
stop using the Light Unit immediately, and turn o󰀨 the power source. A re or
electric shock may result if the Light Unit is kept used.
MANDATORY
ACTIONS
Caution
Do not use user-made cables. Doing
so may cause product failure. Use the
CCS extension cable if it is necessary
to extend the distance between the
Light Unit and the Control Unit.
PROHIBITED
Use Control Unit that is suitable
for the Light Unit ratings. Using an
incorrect Control Unit can cause
Light Unit failure.
MANDATORY
ACTIONS
Be careful of static electricity.
Damage to the LED Light may
occur, if a person charged with
static electricity touches it. Keep
the product away from all items
charged with static electricity.
PROHIBITED
Use a standard Extension Cable
that is manufactured by CCS.
However, if the cable is too long,
the light intensity will decrease due
to the DC resistance of the cable.
MANDATORY
ACTIONS
Do not drop the Light Unit or
subject it to impact. Doing so may
cause the Light Unit to malfunction.
PROHIBITED
Please install the Light Unit to locations with following conditions.
Incorrect installation location may cause Light Unit failure.
In a at and stable location with
minimal vibration.
Well-ventilated places with minimal dust.
Places that are not subject to sudden
temperature changes.
Places free from any water, oil, liquid,
chemical, or steam.
Places free from corrosive or combustible gas.
Places away from water faucets, boilers,
humidiers, air conditioners, heaters, or stoves.
Do not use the Light Unit in the following situations.
Under conditions or in an environment not described in this instruction guide.
In nuclear energy control systems, railroad systems, aviation systems, vehicles,
combustion equipment, medical equipment, amusement machines, or safety equipment.
In applications involving serious risk to life or property, particularly applications
demanding a high level of safety.
Backlights
Connect to the Control Unit equipped with SMP-03V-BC Connectors
for power output.
24 V output Control Units, such as PD3 and POD series manufactured
by CCS, are available for the Light Unit.
When the input voltage of the Light Unit is 24 V
Connect to the Control Unit equipped with SMP-02V-BC Connectors
for power output.
12 V output Control Units, such as PD2 and PSB series manufactured
by CCS, are available for the Light Unit.
When the input voltage of the Light Unit is 12 V
Tag Example
Back
Front
MADE IN JAPAN
MODEL
INPUT
S/N
MFU-nnXnnBL
12V=n.nW
0123456789
Manufacturer: CCS Inc.
374 Okakuencho, Kamigyo-ku,
Kyoto 602-8011, Japan
EU Importer: CCS Europe N. V.
Bergensesteenweg 421B,
1600 Sint-Pieters-Leeuw, Belgium
Caution Thin and delicate glasses are used for the Light Unit. Do not drop it or
subject it to impact. Doing so may cause damage to the Light Unit.

- 2 -
An aperture with an aperture hole diameter of Ø1 is attached to
the light source part at the factory shipment. You can change the
quantity and distribution of light by replacing the aperture with one
of those (Ø0.5 and Ø2) that come with the product.
Select the most suitable aperture depending on your application.
Note: When replacing the aperture, be careful not to drop the di󰀨usion plate from
the light source part. If you drop it, insert it with its glossy, smooth side
facing the light source.
Replacing the Aperture
Aperture hole diameter Light amount Light distribution
Small Small Narrow
Large Large Wide
Operating Instructions (Continued)3
Light source part
Di󰀨usion plate
M2 hexagon wrench
(accessory)
Aperture
Precautions
Dust, dirt, or ngerprints on the glass portions of the Light Unit
may a󰀨ect the captured image. In that case, clean the Light Unit
as follows:
Handle the Light Unit with care during daily use. Make sure no
dust, dirt, or ngerprints adhere to the Light Unit.
• Remove dust and dirt by blowing it o󰀨 with air. Do not touch
them with your hand.
• Use a soft, nely woven cloth to wipe away any marks, such as
ngerprints.
• Use a soft, nely woven cloth soaked with diluted neutral
detergent to remove any heavy dirt.
Set screw
(M2 x 2 mm, accessory)
Caution
• Do not remove the knurled screw from the barrel. Doing so may
allow the barrel falls into the main body.
• Tighten the barrel xing screw with the at surface of the barrel
facing downward.
Knurled screw
Barrel
Barrel xing screw
Flat surface
M3 hexagon wrench (available in the market)
You can change the position of the light source by loosening the
knurled screw. Also, you can change the position of the barrel by
loosening the barrel xing screw if necessary.
Changing the Light Source Position
Common Specications
Specications by Model
Main Specications
4
LED color Blue
Peak wavelength (typ.) 465 nm
Cable length 300 mm
Cooling method Natural air-cooling
Operating environment
(indoors only)
Temperature: 0 to 40°C, Humidity: 20 to 85%RH
(with no condensation)
Storage environment Temperature: -20 to 60°C, Humidity: 20 to 85%RH
(with no condensation)
CE marking Safety standard: Conforms to EN62471
Case material Aluminum alloy, steel plate, resin
Accessories
Aperture (Ø0.5) x 1 pc., aperture (Ø2) x 1 pc.,
set screws (M2 x 2 mm, black) x 3 pcs.,
M2 hexagon wrench x 1 pc.
Model name Input voltage Connector/
polarity
Power
consumption
(max.)
Weight
MFU-34X30BL2-12
12 VDC SMR-02V-B
1: (+), 2: (
- )
0.9 W
Approx. 0.2 kg
MFU-54X40BL2-12 0.9 W Approx. 0.4 kg
MFU-34X30BL2-24
24 VDC
SMR-03V-B
1: (+), 2: NC,
3: (
- )
1.7 W
Approx. 0.2 kg
MFU-54X40BL2-24 1.7 W Approx. 0.4 kg
Light source part

- 3 -
Copyright© 2021 CCS Inc. All Rights Reserved.
Descriptions in this instruction guide are based on information available as of April 2021. KZ12624-T001-001
Contents of this Instruction Guide may be changed without prior notice.
Illustrations used in this Instruction Guide may di󰀨er from actual products.
CCS maintains the copyright on this Instruction Guide. Unauthorized transfer or reproduction is strictly prohibited.
http://www.ccs-grp.com/
Dimensions (mm)
5
MFU-34X30BL2-12 Ø30
Ø30
300
+35
0
300
+35
0
300
+35
0
15 60
100
130
5
25
15
90
30
(Emitting surface)
40
(Emitting surface)
34
(Emitting surface)
54
(Emitting surface)
5
20
15
15
60100
100
15 15 60
(20 to 53)
(20 to 53)
10
10
(1.4)
(1.4)
38
48
46
66
603
33
10
10
340
23
6
6
2 x M3 x 5
(For installation)
2 x M3 x 5
(For installation)
2 x M3 x 5
(For installation)
2 x M3 x 5
(For installation)
4 x M3 x 6
(For installation)
4 x M3 x 6
(For installation)
MFU-54X40BL2-12
MFU-54X40BL2-24
MFU-34X30BL2-24 Same dimensions as MFU-34X30BL2-12 excluding the light cable.
Same dimensions as MFU-54X40BL2-12 excluding the light cable.
Barrel fixing screw
Barrel fixing screw
8
