ShowPro PLUTO 250 User manual

PLUTO 250
USER MANUAL
® PLUTO 250
LEDMOV510
- .

1
358 mm
1
Product Introduction
1.1 Specification
Product Code
SS662SC
Dimenson
358×250×609(mm)
Weight
19KG
Rated Power
320W
Input Voltage
AC100~240V
Frequency Range
50/60Hz
Ambient Temperature
0 ℃ ~45 ℃
Beam Angle
3°~35°
Control Model
DMX512/RDM
250 mm
609 mm

2
1.2 Safety warning
IMPORTANT
Always read the user manual before operation.
Please confirm that the power supply stated on the product is the same as the
mains power supply in your area.
•This product must be installed by a qualified professional.
•Always operate the equipment as described in the user manual.
•A minimum distance of 0.5m must be maintained between the equipment and
combustible surface.
•The product must always be placed in a well ventilated area.
•Always make sure that the equipment is installed securely.
•Do not stand close to the equipment and stare directly into the LED light source.
•Always disconnect the power supply before attempting and maintenance.
•Always make sure that the supporting structure is solid and can support the
combined weight of the products.
•The earth wire must always be connected to the ground.
•Do not touch the power cables if your hands are wet.
••Do not open the fixture or remove any cover. Refer any service operation not
described in this
•manual to an authorized Show Technology Service Centre
ATTENTION
•This product left the place of manufacture in perfect condition. In order to
maintain this condition and for safe operation, the user must always follow the
instructions and safety warnings described in this user manual.
•Avoid shaking or strong impacts to any part of the equipment.
•Make sure that all parts of the equipment are kept clean and free of dust.
•Always make sure that the power connections are connected correct and
secure.
•If there is any malfunction of the equipment, contact your distributor
immediately.
•When transferring the product, it is advisable to use the original packaging in
which the product left the factory.
•Shields, lenses or ultraviolet screens shall be changed if they have become
damaged to such an extent that their effectiveness is impaired.
•The lamp (LED) shall be changed if it has become damaged or thermally
deformed.
Caution, risk of electric shock
The light source contained in this luminaire shall only be replaced
by the manufacturer or his service agent or a similar qualified person.
!
ATTENTION
!

3
2 Installation
2.1 Mounting
Thefixture can be mounted in any position.
Always ensurethat mounting surface can withstand 10times the weight of the
fixture.
Always use a safety cable when mounting the fixturein anyelevated position.
Contact your ShowPRO supplier for assistance if you have any questions about how to install this
product safely.
UPRIGHT HANGING
Important safety note!!
Always use a safety cable when installing this unit!!
Be sure that the safety cable is connected to a solid load-bearing structure.
2.2 Fuse replacement
●Remove the safety cap by a screwdriver.
●Fetch the old fuse from safety cap.
●Install a new fuse.
●Install the safety cap.
Saftycap
Fuse
POW ER IN
POW ER OUT

4
2.3 Power connections
This product uses input and output power cable is 1.5 square mm copper wire
Note:
If the signal cable is over 60m between the DMX512 controller and fixture or beween
two fixtures, then a DMX signal amplifier is needed as well.
This product provides for the use of input power and signal cables are
three-core,the connection diagram is as follows
● When using this product to connect 220V AC, the number
of tandem fixtures must not exceed eight.
● When using this product to connect 110V AC, the number
of tandem fixtures must not exceed four.
100~240VAC Input

5
3.Display panel operation
3.1 Display operation
Down Enter
<UP> Scroll 'UP' through the menu list or increase the value of the current function.
<DOWN> Scroll 'DOWN' through the menu list or decrease the value of the current
function.
<BACK> Scroll through the main menu or exit current function.
<ENTER> Enter the currently selected menu or confirm the current function value.
To Unlock (Wake) the display:
1. eep pressing BACK around 5 seconds, until the display shows password prompt
2. ress “<UP> <DOWN><UP><DOWN><ENTER>” to unlock.
Back
Up

3.2 Menu
MENU
ADDRESS
PERSON
001-512
STANDARD
BASIC
RUNMODE
DMX512
AUTO
CUSTOM 1
CUSTOM 2
OPTION
PAN INVERT
TILT INVERT
OFF/ON
OFF/ON
FANS
SLOW
NORMAL
FAST
AUTO
BLACKOUT
NO/YES
DIMMER
DIM 4
DIM 3
DIM 2
DIM 1
OFF
LED PWM
1200Hz
2400Hz
4000Hz
6000Hz
25000Hz
DMX ERROR
SAVE/BLACK
DISPLAY ON
OFF/ON
DISPLAY LOCK
OFF/ON
LOAD PARA
NO/YES
SETTING
RECOVERY
CLEAN EDIT 1
CLEAN EDIT 2
WDMX HIDE
****
****
****
YES/NO
PT ENCODER
OFF/ON
WDMX RESET
NO/YES
SIGNAL
ONLY XLR
ONLY WDMX
WDMX TO DMX
EDIT
EDIT 1-20
STEP(01-30)
PAN
0-255
TILT
0-255
PT SPEED
0-255
COLOR
0-255
FIXED GOBO
0-255
ROTA.GOBO
0-255
GOBO.ROTA
0-255
PRISM
0-255
ZOOM
0-255
FOCUS
0-255
DIMMER
0-255
STROBE
0-255
TIME
0-255(×0.1S)
USE
YES/NO

7
MANUAL
AUTO TEST
CHANNEL
PAN
0-255
TILT
0-255
PT SPEED
0-255
COLOR
0-255
FIXED GOBO
0-255
ROTA.GOBO
0-255
GOBO.ROTA
0-255
PRISM
0-255
ZOOM
0-255
FOCUS
0-255
DIMMER
0-255
STROBE
0-255
TIME
0-255(×0.1S)
USE
YES/NO
DEBUG HIDE
YES/NO
RESET
ALL RESET
PT RESET
COLOR SYSTEM
GOBO SYSTEM
OTHER
INFO
FIXTURE HOURS
LED USE HOURS
TEMPERATURE
VERSION
RDM
UID
0x388Axxxxxxxx
LABEL
PLUTO 250
SYSTEM ERROR
MEMORY IC
ANGLESENSOR
PAN SENSOR
PAN ENCODER
PAN DRIVEIC
TILT SENSOR
TILTENCODER
TILTDRIVEIC
TEMPERATURE
COLOR RESET
FGOBO RESET
GOBO RESET
RGOBO RESET
ZOOM RESET
FOCUS RESET
PRISM RESET
SERVICE
****
PAN
±127
TILT
±127
COLOR
±127
FIXED GOBO
±127
ROTA. GOBO
±127
GOBO.ROTA
±127
FOCUS
±127
ZOOM
±127
PRISM
±127
DIMMER
128 -255

8
ADDRESS
PERSON
STANDARD
BASIC
RUNMODE
3.3 DMX Address
• Enterthe【DMX】modetosettheDMXaddress.
• Enter Up/Down select【1~512】address.
• Enter【MENU】return.
3.4 Personality(Person)
• Enter the【PERSON】mode to select DMX mode:【STANDRAD】,【BASIC】.
3.5 Runmode
• 【RUNMODE】menu,selectrequiredrunmode,therearesixmodesinside:【DMX512】
DMX512mode,【AUTO】autorunmode,【CUSTOM1】customerself-editingscene
mode1,【CUSTOM2】customerself-editingscenemode2pressDown/Upselectmode.
• press【ENTER】accept,press【MENU】return.
3.6 Performance(Option)
MENU
OPTION
PAN INVERT
OFF/ON
TILT INVERT
FANS
OFF/ON
SLOW
NORMAL
FAST
AUTO
BLACKOUT
DIMMER
NO/YES
DIM 4
DIM 3
DIM 2
DIM 1
OFF
LED PWM
1200Hz
2400Hz
4000Hz
6000Hz
25000Hz

9
• Enter【OPTION】intothemachineset.
• 【PANINVERT】menu,select【NORMAL】for normal direction, select【INVERT】for
invertedof the PAN direction.
• 【FANS】menu,select【Slow/Norm/Fast/Auto】as required fan speed.
• Choose【OFF】and【ON】to closeand openthe【BLACKOUT】mode.
• 【DIMMER】menuforselectionof【DIM1/DIM2/DIM3/DIM4/OFF】specialdimming
curves.
• 【LEDPWM】isPWMrefreshratebottom,pressUP/DOWNtochoose<1200Hz>、
<2000Hz>、<2400Hz>、<6000Hz>、<25000Hz>;Attention: the gray level of dimming will
be reduced as the refresh rate increases.
• 【DMXERROR】menu,select【SAVE】tomaintainlastcommandincaseof DMXerror
orforblackout.
• Choose【OFF】and【ON】tocloseandopenthedisplayopen&closemodeinmenu
【DISPLAY】
• Choose【OFF】and【ON】tocloseandopenthescreenlockmodeinmenu 【DISPLAY
LOCK】
• 【LOADPARA】is parameteruploadSettings,enter【NO】donot upload,enter 【YES】
upload.
• 【SETTING】maintainsettings,select【RECOVERY】isrestoredefaultfactorysettings.
press【ENTER】enterpasswordthenpress【ENTER】,ifyourpasswordcorrecttherewill
display【OK】.
【CLEANEDIT1】clean customerself-editing scene 1, press【ENTER】confirm.
【CLEANEDIT2】cleancustomerself-editingscene2, press【ENTER】confirm.
【WDMXHIDE】hidewirelessmode,WDMXRESETandSIGNALhideandthedefaultis
wiredmodeonly.
DMX ERROR
DISPLAY ON
DISPLAY LOCK
LOAD PARA
SETTING
RESET
SIGNAL

10
• 【PT ENCODER】XYencoder switch,【OFF】is close,【ON】is open.【WDMX
RESET】wireless resetting,use forpatch wireless signal,【YES】is clearthereceiver's
message,pressagainpatchwirelesssignal,【No】donotclearthereceiver'smessage.
• 【SIGNAL】issignalsetting,ONLYXLRiswireonly, XLRFIRSTiswirefirst,ONLYWDMX
iswirelessonly.WDMXFIRSiswirelessfirst , WDMXTODMXiswirelessto wired.
3.7 Edit
MENU
EDIT
EDIT 1-2
STEP(01-30)
PAN
0-255
TILT
0-255
PT SPEED
0-255
COLOR
0-255
FIXED GOBO
0-255
ROTA.GOBO
0-255
GOBO.ROTA
0-255
PRISM
0-255
ZOOM
0-255
FOCUS
0-255
DIMMER
0-255
STROBE
0-255
TIME
0-255(×0.1S)
USE
YES/NO
• Enterthe【EDIT】modetoeditthecustomprogramsby adjustingthevalueof【PAN】,
【TILT】,【PT SPEED】,【COLOR】,【FIXED GOBO】,【ROTA.GOBO】,
【GOBO.ROTA】,【PRISM】,【FROST】,【ZOOM】,【FOCUS】,【DIMMER】,
【STROBE】,【TIME】.Enter【Use】andselect【Yes】torun thesteps userneed.
3.8 Manual control mode
MENU
MANUAL
AUTO TEST
CHANNEL
PAN
0-255
TILT
0-255
PT SPEED
0-255
COLOR
0-255
FIXED GOBO
0-255
ROTA.GOBO
0-255
GOBO.ROTA
0-255
PRISM
0-255
ZOOM
0-255
FOCUS
0-255
DIMMER
0-255
STROBE
0-255
DEBUG HIDE
YES/NO
RESET
ALL RESET
PT RESET
COLOR SYSTEM
GOBO SYSTEM
OTHER

11
INFO
FIXTURE HOURS
LED USE HOURS
TEMPERATURE
VERSION
RDM
UID
LABEL
MEMORY IC
ANGLESENSOR
PAN SENSOR
PAN ENCODER
PAN DRIVEIC
TILT SENSOR
TILTENCODER
TILTDRIVEIC
TEMPERATURE
COLOR RESET
FGOBO RESET
GOBO RESET
RGOBO RESET
ZOOM RESET
FOCUS RESET
0x388Axxxxxxxx
PLUTO 250
SYSTEM ERROR
Press【ENTER】into【INFO】check information，press up and down
PRISM RESET
• Press【ENTER】into【AUTOTEST】at 【MENUAL】.
• 【PAN】panset,【TILT】tiltset,【PTSPEED】set thepan&tiltspeed,【COLOR】color
temperature,【FIXEDGOBO】set the static gobo wheel【ROTA.GOBO】set therotating
gobo wheel,【GOBO.ROTA】set the autogiration of gobo wheell,【PRISM】set the
prism,【FROST】setthefrostlens,【ZOOM】setthezoomoffixture,【FOCUS】setthe
focusing,【DIMMER】setthedimmer,【STROBE】setthestrobe,pushtheUP/DOWNto
setthevalue【000~255】.
• 【DEBUGHIDE】isthefactorytestingmode.Allsteppermotorsarenotcontrolledby
signal,It only works againafterthe reset. enter No out、enter Yes in.
• 【RESET】set the reset：
【ALLRESET】menu,select Yes/No tocarryoutallreset.
【PT RESET】menu,select Yes/No tocarryoutPAN/TILTreset.
【COLORSYSTEM】colorwheel、CMYresetting，pressNodo not resetting,pressYes
resetting.
【GOBOSYSTEM】fixgoboresetting.pressNo do not resetting,pressYesresetting.
【OTHER】focus、zoom、prism、frost、iris，pressNodonotresetting,pressYes
resetting.
3.9 Info
• 【FIXTUREHOURS】is hours offixtureuse；
• 【LEDUSEHOURS】isLEDusetime；

SERVICE
****
PAN
TILT
COLOR
FIXED GOBO
ROTA. GOBO
GOBO.ROTA
FOCUS
ZOOM
PRISM
DIMMER
±127
±127
±127
±127
±127
±127
±127
±127
±127
128 -255
• 【TEMPERATURE】isledtemperature.
• 【VERSION】is software versions；
• 【NETWORKPARA】checknetworkparameter；
• 【RDM】check fixture's ID；
• 【SYSTEM ERROR】system information error:Memory IC,AngleSensor,PanSensor,Pan
Encoder,Pan Drive IC,Tilt Sensor,TiltEncoder,TiltDriveIC,Temperature,Color Reset,FGobo
Reset,Gobo Reset,RGobo Reset,Zoom Reset,Focus Reset,Prism Reset.
3.10 Service
• Press【ENTER】into【SERVICE】enterpassword"updownup down" toentertheoptions
page.
• 【PAN】Panpositionfineadjustment，pushupanddownbuttonsadjust±127value.
• 【TILT】tiltpositionfineadjustment，pushup and downbuttonsadjust±127value.
• 【COLOR】colorpositionfineadjustment，Pushup and downbuttonsadjust±127value.
• 【FIXEDGOBO】fixgobopositionfineadjustment，Pushupanddownbuttonsadjust±127
value.
• 【ROTA.GOBO】rotationgobopositionfineadjustment，Pushup and downbuttons
adjust±127value.
• 【GOBO.ROTA】goboself-rotationpositionfineadjustment，Pushup and downbuttons
adjust±127value.
• 【FOCUS】focuspositionfineadjustment，Pushup and downbuttonsadjust±127value.
• 【ZOOM】zoompositionfineadjustment，Pushupanddownbuttonsadjust±127value.
• 【PRISM】prismpositionfineadjustment，Pushupand downbuttonsadjust±127value.
• 【DIMMER】isadimmingsettingthatlimitsthemaximumbrightness,rangeofvaluesis
128~255thelowerthevalue,thehigherthelimit,255isunlimited. 12

13
4 Using a DMX512 Controller
4.1 Channel Assignment
Note: this product have two DMX512 channel configuration:【STANDARD】,【BASIC】.
STANDARD
8 ON CHANNELS 10.
CHANNEL
VALUE
FUNCTION
CH.1
000
255
PAN 0-540°
CH.2
000
255
PAN FINE
CH.3
000
255
TITL 0-270°
CH.4
000
255
TITL FINE
CH.5
000
255
PT SPEED
CH.6
COLOR WHEEL 8+1
000
007
WHITE
008
014
COLOR01
015
021
COLOR02
022
028
COLOR03
029
035
COLOR04
036
042
COLOR05
043
049
COLOR06
050
056
COLOR07
057
063
COLOR08
064
191
COLOR WHEEL 0-360°
192
222
COLOR WHEEL RAINBOW EFFECT (SPEED 100%->1)
223
224
STOP
225
255
COLOR WHEEL RAINBOW EFFECT (SPEED 1-> 100%)
CH.7
000
255
COLOR WHEEL FINE ADJUSTMENT. AVAILABLE WHEN THE VALUE IS UNDER 12
STATIC GOBO 11+1
000
010
WHITE
011
015
GOBO1
016
020
GOBO2
021
025
GOBO3
026
030
GOBO4
031
035
GOBO5
036
040
GOBO6
041
045
GOBO7
046
050
GOBO8

14
)
CHANNEL
VALUE
FUNCTION
CH.8
051
055
GOBO9
056
060
GOBO10
061
065
GOBO11
066
070
GOBO1 SHAKE (SPEED 1 —> 100%)
071
075
GOBO2 SHAKE (SPEED 1 —> 100%)
076
080
GOBO3 SHAKE (SPEED 1 —> 100%)
081
085
GOBO4 SHAKE (SPEED 1 —> 100%)
086
090
GOBO5 SHAKE (SPEED 1 —> 100%)
091
095
GOBO6 SHAKE (SPEED 1 —> 100%)
096
100
GOBO7 SHAKE (SPEED 1 —> 100%)
101
105
GOBO8 SHAKE (SPEED 1 —> 100%)
106
110
GOBO9 SHAKE (SPEED 1 —> 100%)
111
115
GOBO10SHAKE (SPEED 1 —> 100%)
116
120
GOBO11SHAKE (SPEED 1 —> 100%)
121
127
WHITE
128
190
STATIC GOBO FLOWING WATER EFFECT (SPEED 100%—>1)
191
192
STOP
193
255
STATIC GOBO FLOWING WATER EFFECT (SPEED 1—> 100%)
CH.9
ROTATING GOBO 8+1
000
010
WHITE
011
016
GOBO1
017
022
GOBO2
023
028
GOBO3
029
034
GOBO4
035
040
GOBO5
041
046
GOBO6
047
052
GOBO7
053
058
GOBO8
059
066
GOBO1
SHAKE (SPEED 1 —> 100%)
067
074
GOBO2
SHAKE (SPEED 1 —> 100%)
075
082
GOBO3
SHAKE (SPEED 1 —> 100%)
083
090
GOBO4
SHAKE (SPEED 1 —> 100%)
091
098
GOBO5
SHAKE (SPEED 1 —> 100%)
099
106
GOBO6
SHAKE (SPEED 1 —> 100%)
107
114
GOBO7
SHAKE (SPEED 1 —> 100%)
115
122
GOBO8
SHAKE (SPEED 1 —> 100%)
123
127
WHITE
128
190
ROTATING GOBO FLOWING WATER EFFECT (SPEED 100%—>1
191
192
STOP

15
)
CHANNEL
VALUE
FUNCTION
193
255
ROTATING GOBO FLOWING WATER EFFECT (SPEED 1—>100%
CH.10
GOBO ROTATING
0
120
ROTATING GOBO ANGLE ADJUSTMENT (0 —> 360°)
121
125
STOP
126
165
ROTATING GOBO SHAKE (SPEED 1 —> 100%)
166
170
STOP
171
210
ROTATING GOBO POSITIVE ROTATION (SPEED 100% —> 1)
211
215
STOP
216
255
ROTATING GOBO REVERSE ROTATION (SPEED 1 —> 100%)
CH.11
PRISM
0
1 0
WHITE
11
145
PRISM 0-360°
146
150
STOP
151
200
PRISM INSERT AND POSITIVE ROTATION (SPEED 100%—>1)
201
205
STOP
206
255
PRISM INSERT AND REVERSE ROTATION (SPEED 1—>100%)
CH.12
000
255
ZOOM
CH.13
AUTO FOCUS
0
1 2
NO FUNCTION
13
39
5M
40
66
7M
67
93
9M
94
120
11M
121
147
13M
148
174
15M
175
201
17M
202
228
19M
229
255
21M
CH.14
0
255
MANUAL FOCUS
CH.15
0
255
DIMMER
CH.16
0
255
16B DIMMER FINE
CH.17
STORBE
0
9
NO FUNCTION
10
99
STROBE FROM （SLOW TO FAST ,0-25Hz)
100
109
NO FUNCTION
110
179
LIGHTNING STROBE

16
CHANNEL
VALUE
FUNCTION
180
189
NO FUNCTION
190
255
RANDOM STROBE
CH.18
CONTROL
000
010
NO FUNCTION
011
020
PAN/TILT BLACK ACTIVATED
021
030
PAN/TILT BLACK DEACTIVATED
031
040
PAN INVERT
041
050
TILT INVERT
051
060
PAN/TILT INVERT OFF
061
070
FAN SLOW
071
080
FAN NORMAL
081
090
FAN FAST
091
100
FAN AUTO
101
110
DIM4
111
120
DIM3
121
130
DIM2
131
140
DIM1
141
150
DIM OFF
151
160
1200Hz
161
170
2400Hz
171
180
4000Hz
181
190
6000Hz
191
200
25000Hz
201
210
ALL RESET
211
220
XY RESET
221
230
COLOR SYSTEM RESET
231
240
GOBO RESET
241
250
FOCUS\ZOOM
251
255
NO FUNCTION
BASIC
CHANNEL
VALUE
FUNCTION
CH.1
000
255
PAN 0-540°
CH.2
000
255
TILT 0-270°
CH.3
000
255
PT SPEED
COLOR WHEEL 8+1
000
007
WHITE
008
014
COLOR01

17
8 ON CHANNELS 10.
CHANNEL
VALUE
FUNCTION
CH.4
015
021
COLOR02
022
028
COLOR03
029
035
COLOR04
036
042
COLOR05
043
049
COLOR06
050
056
COLOR07
057
063
COLOR08
064
191
COLOR WHEEL 0-360°
192
222
COLOR WHEEL RAINBOW EFFECT (SPEED 100%->1)
223
224
STOP
225
255
COLOR WHEEL RAINBOW EFFECT (SPEED 1-> 100%)
CH.5
000
255
COLOR WHEEL FINE ADJUSTMENT. AVAILABLE WHEN THE VALUE IS UNDER 12
CH.6
STATIC GOBO 11+1
000
010
WHITE
011
015
GOBO1
016
020
GOBO2
021
025
GOBO3
026
030
GOBO4
031
035
GOBO5
036
040
GOBO6
041
045
GOBO7
046
050
GOBO8
051
055
GOBO9
056
060
GOBO10
061
065
GOBO11
066
070
GOBO1 SHAKE (SPEED 1 —> 100%)
071
075
GOBO2 SHAKE (SPEED 1 —> 100%)
076
080
GOBO3 SHAKE (SPEED 1 —> 100%)
081
085
GOBO4 SHAKE (SPEED 1 —> 100%)
086
090
GOBO5 SHAKE (SPEED 1 —> 100%)
091
095
GOBO6 SHAKE (SPEED 1 —> 100%)
096
100
GOBO7 SHAKE (SPEED 1 —> 100%)
101
105
GOBO8 SHAKE (SPEED 1 —> 100%)
106
110
GOBO9 SHAKE (SPEED 1 —> 100%)
111
115
GOBO10SHAKE (SPEED 1 —> 100%)
116
120
GOBO11SHAKE (SPEED 1 —> 100%)
121
127
WHITE
128
190
STATIC GOBO FLOWING WATER EFFECT (SPEED 100%—>1)
191
192
STOP

18
)
)
CHANNEL
VALUE
FUNCTION
193
255
STATIC GOBO FLOWING WATER EFFECT (SPEED 1—> 100%)
CH.7
ROTATING GOBO 8+1
000
010
WHITE
011
016
GOBO1
017
022
GOBO2
023
028
GOBO3
029
034
GOBO4
035
040
GOBO5
041
046
GOBO6
047
052
GOBO7
053
058
GOBO8
059
066
GOBO1 SHAKE (SPEED 1 —> 100%)
067
074
GOBO2 SHAKE (SPEED 1 —> 100%)
075
082
GOBO3 SHAKE (SPEED 1 —> 100%)
083
090
GOBO4 SHAKE (SPEED 1 —> 100%)
091
098
GOBO5 SHAKE (SPEED 1 —> 100%)
099
106
GOBO6 SHAKE (SPEED 1 —> 100%)
107
114
GOBO7 SHAKE (SPEED 1 —> 100%)
115
122
GOBO8 SHAKE (SPEED 1 —> 100%)
123
127
WHITE
128
190
ROTATING GOBO FLOWING WATER EFFECT (SPEED 100%—>1
191
192
STOP
193
255
ROTATING GOBO FLOWING WATER EFFECT (SPEED 1—>100%
CH.8
GOBO ROTATING
0
120
ROTATING GOBO ANGLE ADJUSTMENT (0 —> 360°)
121
125
STOP
126
165
ROTATING GOBO SHAKE (SPEED 1 —> 100%)
166
170
STOP
171
210
ROTATING GOBO POSITIVE ROTATION (SPEED 100% —> 1)
211
215
STOP
216
255
ROTATING GOBO REVERSE ROTATION (SPEED 1 —> 100%)
CH.9
PRISM
0
1 0
WHITE
11
145
PRISM 0-360°
146
150
STOP
151
200
PRISM INSERT AND POSITIVE ROTATION (SPEED 100%—>1)
201
205
STOP
206
255
PRISM INSERT AND REVERSE ROTATION (SPEED 1—>100%)

19
CHANNEL
VALUE
FUNCTION
CH.10
000
255
ZOOM
CH.11
AUTO FOCUS
0
1 2
NO FUNCTION
13
39
5M
40
66
7M
67
93
9M
94
120
11M
121
147
13M
148
174
15M
175
201
17M
202
228
19M
229
255
21M
CH.12
0
255
MANUAL FOCUS
CH.13
0
255
DIMMER
CH.14
STORBE
0
9
NO FUNCTION
10
99
STROBE FROM （SLOW TO FAST ,0-25Hz)
100
109
NO FUNCTION
110
179
LIGHTNING STROBE
180
189
NO FUNCTION
190
255
RANDOM STROBE
CH.15
CONTROL
000
010
NO FUNCTION
011
020
PAN/TILT BLACK ACTIVATED
021
030
PAN/TILT BLACK DEACTIVATED
031
040
PAN INVERT
041
050
TILT INVERT
051
060
PAN/TILT INVERT OFF
061
070
FAN SLOW
071
080
FAN NORMAL
081
090
FAN FAST
091
100
FAN AUTO
101
110
DIM4
111
120
DIM3
121
130
DIM2
131
140
DIM1
141
150
DIM OFF
