ShowPro DIAMONDBACK LEDDIA100 User manual

Guangdong Yiri Lighting Technology Co., Ltd.
No. 55, Zhongzhun Road, Cuiheng New District,
Zhongshan City, Guangdong, China
Tel +86 0760 8828 0099
www.eklights. com
DIAMONDBACK Tour Pack of 3
MANUAL
LEDDIA100

FEATURES
• 1100W RGBW+CW+WW LED to produce perfect colour blending and stunning strobe effects
• Ultra high brightness of 60000lm
• Zoom range from 3°~56°
• White color temperature from 2700K~8000K, WW: Ra≥90
• 14 RGBW pixels + 56 individually controllable WW/CW segments for dynamic effects and visuals
• Built-in effects and macros give multi-selections of fast programming
• Selectable PWM frequency for flicker-free video with any camera
• Advanced thermal designs with multi fan modes for proper noise level at different applications
• DMX, Art-Net and RDM control
SPECIFICATIONS
Light Source: RGBW+CW+WW, 1100W, LED
Beam Angle: 3°~56°
Output: 60K lm(peak value)
Color Mixing: RGBW+CW+WW
CRI:W:≥70; CW:≥80; WW:≥90
Zoom: 3°~56°
Strobe: 0~30Hz + strobe effect macros
Dimming: 4 dimming curves with 0~100% dimming
Tilt Movement: 205°(16bit)
Mains: 100~240VAC,50~60Hz
Consumption: 620W /230V
Power Connections: IP PowerCON IN/OUT
Protocol: DMX512/RDM/ArtNet+DMX512
DMX Channels: 14CH/32CH/118CH/91CH/119CH
Data Connections: 3pin(or 5pin) DMX IN/OUT,linking up to 32pcs at a chain
Onboard Menu: 2.83 inches TFT with gravity sensor
IP Rating: IP 20
Cooling: Noiseless fan for forced air
Ambient Temp.: -10℃~45℃
Dimensions: 1000 x 110 x 284.5mm
Weight: 20.3kg
Accessories: Power Cable. Omega Bracket
INTRODUCTION
PIXEL-MAPPABLE FULL-COLOR LED STROBE/BEAM/WASH MOVING BAR WITH ZOOM

WARNING!Before carrying out any operations with the unit,carefully read this instruction
manual and keep it with care for future reference,It contains important information about
the installation,user and maintenance of the unit.
SAFETY
General instruction
-The products referred to in this manual conform to the European Community Directives and are therefore
marked wihth CE.
-The unit is supplied with hazardous network voltage (230V~) .Leave serving to skilled personnel only.
Never make any modifications on the unit not described in this instruction manual,otherwise you will risk
an electric shock.
-Connection must be made to power supply system fitted with efficient earthing (Class I appliance acc-
ording to standard EN60598-1) .It is moreover,recommended to protect the supply lines of the units from
indirect contact and/or shorting to earth by using appropriately sized residual current devices.
-The connection to the main network of electric distribution must be carried out by a qualified electrical
installer.Check that the main frequency and voltage correspond to those for which the unit is designed as
given on the electrical data lable.
-This unit is not for home use,only professional applications.
-Never use the fixture under the following conditions:
• in places subject to vibrations or bumps;
• in places with a temperature of over 40℃.
-Make certain that no inflammable liquids,water ot metal objects enter the fixture,
-Do not dismantle or modify the fixture.
-All work must always be carried out by qualified technical personnel.Contact the nearest sales point for
an inspection or contact the manufacturer directly.
-If the unit is to be put out of operation definitively,take it to a local recyling
plant for a dosposal which is not harmful to the environment.
Warnings and installation precautions
-If this device will be operated in any way different to the one described in this manual,it may suffer
damage and the guarantee becomes void.Furthermore,any operation may lead to dangers like short
circuit,burns,electric shock,etc.
-Before starting any maintenance work or cleaning the fixture,cut off power from the main supply.
-Always additionally secure the fixture with the safety rope.When carrying out any work,always comply
scrupulously with all the regulations (particularly regarding safety) currently in force in the country in
which the fixture’s being used.
-Install the fixture in a well ventilated place.
-Keep any inflammable materials at a safe distance from the fixture.
-Shields,lenses or ultraviolet screens shall be changed if they have become damaged to such an extent
that their effectiveness is impaired.
-The lamp (LED) shall be changed if it has become damaged or thermally deformed.
-Never look directly at the light beam.Please note that fast changes in lighting,e.g. flashing light,may
trigger epileptic seizures in photosensitive persons or persons with epilepsy.
-Do not touch the product’s housing when operating because it may be very hot.
MAINTENANCE AND CLEANING THE UNIT
- Make sure the ar
- Swit
- All screw
be cor
- Housings,fixa
defor
- The main cables must be in impeccable c
small problem is det
- It is rec
par
from the socket.U
For cleaning other housing par
and cause damage to it.
FUSE REPLACEMENT
1.Disconnec
2.Using a scr
3.Remov
-ing.
4.Screw the fuse holder cap back in plac
Con
be resolv
ww

MAINTENANCE
MAINTENANCE AND CLEANING THE UNIT
- Make sure the area below the installation place is free from unwanted person during setup.
- Switch off the unit,unplug the main cable and wait till the unit has cooled down.
- All screws used for installing the device and any of its parts should be tightly fastened and should not
be corroded.
- Housings,fixations and installation spots (celling,trusses,suspensions) should be totally free from any
deformation.
- The main cables must be in impeccable condition and should be replaced immediately even when a
small problem is detected.
- It is recommended to clean the front at regular intervals,from impurities caused by dust,smoke,or other
particles to ensure that the ligh is radiated at maximum brightness.For cleaning,disconnect the main plug
from the socket.Use a soft,clean cloth moistened with a mild detergent.Then carefully wipe the parts dry.
For cleaning other housing parts use only a soft,clean cloth.Never use a liquid,it might pernetrate the unit
and cause damage to it.
FUSE REPLACEMENT
1.Disconnect this product from the power outlet.
2.Using a screwdriver,unscrew the fuse holder cap from the housing.
3.Remove the blown fuse and replace with a good fuse of the same type and rat
-ing.
4.Screw the fuse holder cap back in place and reconnect power.
Contact an authorized service center in case of technical problems or not reported in the above table cannot
be resolved by the procedure given in the table.

OVERVIEW
OK
UP ENTERRIGHTLEFTDOWN
Confirm the displayed
value, or activevates
the displayed functions,
or enter the sucessive
menu
Increase the value
display or passes
to the previous
item in a menu
Decreases the value
display or passes
to the next item in
the menu
Return to the top level
Commute from unites,
tens, hundreds in the
menu
1
9
2 3 4 5 67 - 1 8
7 - 2
8
1. Art-Net In/Out
2. DMX IN/OUT
3. Control Panel
4. Fuse
5. Power In
6. Fan for ventilation
7-1. Side Lock
7-2. Side Lock Pins
8. Tilt Lock
9. Omega Adapting Holes
DMX
/ NE
7
8
9
10
11
12
13
14
15
60
61
62
63
64
65
66
67
88
89
90
91
DMX
/ NE
1
2
3
ww

PHOTOMETRICS
Beam Angle 3°
Beam Angle 34°
Diameter(cm)
φ17cm φ28cm φ57cm φ85cm φ133cm
Distance (m) 3m 5m 10m 15m 20m
R 3200 1152 288 128 72
G 7800 2808 702 312 176
B 1900 684 171 76 43
W 12000 4320 1080 480 270
RGBW 22000 7920 1980 880 495
CW 167 60 15 7 4
WW 140 50 13 6 3
ALL 24000 8640 2160 960 840
Illuminance(Lux)
Diameter(cm)
φ185cm φ308cm φ616cm φ925cm φ1233cm
Distance (m) 3m 5m 10m 15m 20m
R 377 121 30 13 8
G 840 302 76 34 19
B 160 58 14 6 4
W 1400 504 126 56 32
RGBW 2500 900 225 100 56
CW 166 60 15 7 4
WW 140 50 13 6 3
ALL 2800 1008 252 112 63
Illuminance(Lux)
DMX
/ NE
63
64
65
66
67
11
11
11
11
DMX
/ NE
1
2
3
4
5
6
7
8
9
10
11
12
57
58
59
60
61
62
63
ww

DIMENSION
150.7
110

INSTALLATION
The Diamondback may be set up on a solid and even surface. By means of the fixing facilities of the
baseplate,the unit can also be mounted upside down to a cross arm. For fixing, stablemounting clips
are required. The bolts of the brackets are placed into the openings provided in the base plate and
turned clockwise until they lock (to the stop). Always ensure that the unit is firmly fixed to avoid vibration
and slipping while operating. The mounting place must be of sufficient stability and be able to support a
weight of 10 times of the unit’s weight. When carrying out any installation,always comply scrupulously with
all the regulations (particularly regarding safety) currently in force in the country in which the fixture’s being
used. Always additionally secure the projector with the safety rope from falling down. For this purpose, fasten
the safety rope at a suitable position so that the maximum fall of the projector will be 20 cm.

POWER CONNECTION
Power In
Using Power Con In
Power cable connected in series
Attention: due to the power rating
one 1.5mm² power cable can connect 1 unit maximum
Do not connect more than 1 unit in series with one power cable
Do not use damage power cable
Turn off the power when the units are not in use
WARNING
1
2
3
4
5
6
7
8
9
10
11
12
DMX
/ NE
13
14
59
60
61
62
63
64
65
ww

DATA CONNECTION
ETHERNET CONNECTION
DMX CONNECTION

DATA CONNECTION
Depending on the length of the DMX cable run, or other factors, it may be advisable to install a
terminator at the last fixture in the run.
The illustration below shows the correct placement of a 120Ω 0.25W resistor in a terminator, as
well as the standard DMX signal pin-outs.
DMX INPUT
1
3
2
1
3
2
COMMON
DMX+
DMX-
DMX OUTPUT 1
3
2
120Ω
1/4 W
resistor
DMX INPUT
1
3
2
45
1
3
2
45
COMMON
DMX-
DMX+
Not Used
DMX OUTPUT
NotUsed 3
2
4
5
1
Relation between DMX and Address
Follow above method for subsequent fixtures, calculating starting addressed as indicated.
EXAMPLE OF DMX ADDRESSING
The below table shows an example of starting addresses for four fixtures assuming a first fixt-
ure with starting address of 001.
The actual starting addresses will be determined by the operator as needed to match external
controller settings.
04314CH
32CH
118CH
001-014
001-032
001-118
001 015 029
096
355
001
001
033
119
065
237
START ADDRESS
4TH FIXTURE
MODE ALLOCATION START ADDRESS
1ST FIXTURE
START ADDRESS
2ND FIXTURE
START ADDRESS
3RD FIXTURE
9
10
11
12
13
14
DMX
/ NE
ww

FEATURES
• 1100W RGB
• Ultra high br
• Zoom r
• W
• 14 RGB
• Built-in eff
• Selec
• Adv
• DMX, Ar
DMX CHANNELS
PIXEL CONTROL
88Ch Mode
DMX
/ NET
DMX
+NET Function Value Percent/Setting
64 60 Warm White2 000-255 0~100%
... 000-255 0~100%
... 000-255 0~100%
... 000-255 0~100%
85 81 Cool White13 000-255 0~100%
86 82 Warm White13 000-255 0~100%
87 83 Cool White14 000-255 0~100%
88 84 Warm White14 000-255 0~100%
ww

MENU
NO. Main Menu Menu level 1 Menu level 2 Menu level3 Menu level4 Default Description for use
1 SETUP
DMX Address 1-512 1
DMX Channel
14CH
32CH
32CH
118CH
91CH
119CH
88CH
Protocol
DMX
DMX
Artnet
DMX+Artnet
Ethernet Interface
Universe 0-255 0
Start Channel 1-512 1
Custom IP Address 2.133.139.215 2.xxx.xxx.xxx
Custom IP Mask 255.0.0.0 255.0.0.0
Ethernet To DMX NO No
Yes
2 OPTION
Movement
Setting
Tilt Reverse Off Off
On
Encoder Pan/Tilt Off On
On
Display Setting
Warn Cue Off On
On
Backlight Off Off Screen shut off automatically after 30s
On
Display Reverse Off Off Hold UP+DOWN for 3S at main menu
On
Key Lock Off Off
On
Fixture Setting
Fan Mode
Auto
Auto
Theatre
High
Dimmer Mode
Dimmer Mode 1
Dimmer Mode 1
Dimmer Mode 2
Dimmer Mode 3
Dimmer Mode 4
Dimmer Curve
Dimmer Curve 1
Dimmer Curve 2
Dimmer Curve 2
Dimmer Curve 3
Dimmer Curve 4
Dimmer Curve 5
PWM Frequency
600Hz
2000Hz
1200Hz
2000Hz
4000Hz
6000Hz
25000Hz
LED Reverse Off Off
On
Reset Setting
All No No
Yes
Tilt No No
Yes
Zoom No No
Yes
Artnet only controls color

MENU
NO. Main Menu Menu level 1 Menu level 2 Menu level3 Menu level4 Default Description for use
3 INFORMATION
System Errors
System Version
DISP:V1.0
NET-V1.0
CTR1-XY:V1.0
CTR2-MOTOR:V1.0
Led Hours
Total Hours 0~65000H
Partial Hours 0~65000H Reset
Go Back
Fixture Hours
Total Hours 0~65000H
Partial Hours 0~65000H Reset
Go Back
Led Temperature
LED A
LED B
LED C
LED D
UID 030F0A2*****
4 TEST
AUTO
Tilt
Colour
Zoom
All
Channel
1 Tilt 0-255
2 Zoom 0-255
3 Strobe 0-255
4 Dimmer 0-255
5 White Strobe 0-255
6White Dimmer 0-255
7 Red 0-255
8 Green 0-255
9 Blue 0-255
10 White 0-255
11 Top Cool White 0-255
12 Top Warm White 0-255
13 Bottom Cool White 0-255
14 Bottom Warm White 0-255
5
ADVANCED
(Code:1234)
Calibration Tilt Offset 000-255 128
Zoom Offset 000-255 128
Color Calibration
OFF
OFF
Factory Calibration
Red1-14 <125-255>
Green1-14 <125-255>
Blue1-14 <125-255>
White1-14 <125-255>
customized
Calibration
Red1-14 <125-255>
Green1-14 <125-255>
Blue1-14 <125-255>
White1-14 <125-255>
Recove No No
Yes
5
10
11
12
DMX
/ NE
13
14
DMX
/ NE
1
2
3
4
ww

DMX CHANNELS
1 1 Tilt 000-255 0~100%
2 2 Zoom 000-255 From narrow to wide beam
3 3 Strobe
000-003 Light OFF
004-103 Strobe from low (1Hz) to fast (25Hz)
104-107 Light ON
108-207 Pulsation from slow (0.5 Hz) to fast (25 Hz)
208-212 Light ON
213-225 Random Slow Strobe
226-238 Random Medium Strobe
239-251 Random Fast Strobe
252-255 Light ON
4 4 Dimmer 000-255 0~100%
5 5 White Strobe
000-003 Light OFF
004-103 Strobe from low (1Hz) to fast (25Hz)
104-107 Light ON
108-207 Pulsation from slow (0.5 Hz) to fast (25 Hz)
208-212 Light ON
213-225 Random Slow Strobe
226-238 Random Medium Strobe
239-251 Random Fast Strobe
252-255 Light ON
6 6 White Dimmer 000-255 0~100%
7 1 Red 000-255 0~100%
8 2 Green 000-255 0~100%
9 3 Blue 000-255 0~100%
10 4 White 000-255 0~100%
11 5 Top Cool White 000-255 0~100%
12 6
14Ch Mode
DMX
/ NET
DMX
+NET Function Value Percent/Setting
Top Warm White 000-255 0~100%
13 7 Bottom Cool White 000-255 0~100%
14 8 Bottom Warm White 000-255 0~100%
DMX
/ NET
DMX
+NET Function Value Percent/Setting
1 1 Tilt 000-255 0~100%
2 2 Tilt Fine 000-255 0~100%
3 3 Zoom 000-255 From narrow to wide beam
4 4 Strobe
000-003 Light OFF
004-103 Strobe from low (1Hz) to fast (25Hz)
104-107 Light ON
108-207 Pulsation from slow (0.5 Hz) to fast (25 Hz)
208-212 Light ON

DMX CHANNELS
NO.
1
Artnet
2
s
u
4 4 Strobe
213-225 Random Slow Strobe
226-238 Random Medium Strobe
239-251 Random Fast Strobe
252-255 Light ON
5 5 Dimmer 000-255 0~100%
6 6 CTO 000-009 OFF
010-255 CTO 8000K~2700K
7 7 Background CTO 000-009 OFF
010-255 CTO 8000K~2700K
8 8 Effects
000-005 No Function
006-015 Effect 1
016-023 Effect 2
024-031 Effect 3
032-038 Effect 4
039-046 Effect 5
047-054 Effect 6
055-062 Effect 7
063-069 Effect 8
070-077 Effect 9
078-085 Effect 10
086-093 Effect 11
094-100 Effect 12
101-108 Effect 13
109-116 Effect 14
117-124 Effect 15
125-131 Effect 16
132-139 Effect 17
140-147 Effect 18
148-155 Effect 19
156-162 Effect 20
163-170 Effect 21
171-178 Effect 22
179-186 Effect 23
187-193 Effect 24
194-201 Effect 25
202-209 Effect 26
210-217 Effect 27
218-224 Effect 28
225-232 Effect 29
233-240 Effect
32 Ch Mode
DMX
/ NET
DMX
+NET Function Value Percent/Setting
30
241-248 Effect 31
249-255 Effect 32
ww

DMX CHANNELS
9 9 Effects speed
000-124 Normal
125-130 Static
131-255 Dynamic
10 10 White Strobe
000-003 Light OFF
004-103 Strobe from low (1Hz) to fast (25Hz)
104-107 Light ON
108-207 Pulsation from slow (0.5 Hz) to fast (25 Hz)
208-212 Light ON
213-225 Random Slow Strobe
226-238 Random Medium Strobe
239-251 Random Fast Strobe
252-255 Light ON
11 11 White Dimmer 000-255 0~100%
12 12 White CTO 000-009 OFF
010-255 CTO 8000K~2700K
13 13 White Background CTO 000-009 OFF
010-255 CTO 8000K~2700K
14 14 White Effects
000-005 No Function
006-015 Effect 1
016-023 Effect 2
024-031 Effect 3
032-038 Effect 4
039-046 Effect 5
047-054 Effect 6
055-062 Effect 7
063-069 Effect 8
070-077 Effect 9
078-085 Effect 10
086-093 Effect 11
094-100 Effect 12
101-108 Effect 13
109-116 Effect 14
117-124 Effect 15
125-131 Effect 16
132-
32 Ch Mode
DMX
/ NET
DMX
+NET Function Value Percent/Setting
139 Effect 17
140-147 Effect 18
148-155 Effect 19
156-162 Effect 20
163-170 Effect 21
171-178 Effect 22
179-186 Effect 23
187-193 Effect 24

DMX CHANNELS
14 14 White Effects
194-201 Effect 25
202-209 Effect 26
210-217 Effect 27
218-224 Effect 28
225-232 Effect 29
233-240 Effect 30
241-248 Effect 31
249-255 Effect 32
15 15 White Effects speed
000-124 Normal
125-130 Static
131-255 Dynamic
16 16 Device Setting
000-005 No Function
026-076 Head Reset (Hold 5S)
077-127 Pan/Tilt Reset (Hold 5S)
128-178 Complete Reset(Hold 5S)
179-192 No Function
193-200 Dimmer Mode 1
201-208 Dimmer Mode 2
209-216 Dimmer Mode 3
217-224 Dimmer Mode 4
225-255 No Function
17 1 Red 000-255 0~100%
18 2 Green 000-255 0~100%
19 3 Blue 000-255 0~100%
20 4 White 000-255 0~100%
21 5 Background Red 000-255 0~100%
22 6 Background Green 000-255 0~100%
23 7 Background Blue 000-255 0~100%
24 8 Background White 000-255 0~100%
25 9 Top Cool White 000-255 0~100%
26 10 Top Warm White 000-255 0~100%
27 11 Bottom Cool White 000-255 0~100%
28 12 Bottom
32 Ch Mode
DMX
/ NET
DMX
+NET Function Value Percent/Setting
Warm White 000-255 0~100%
29 13 Background Top Cool White 000-255 0~100%
30 14 Background Top Warm White 000-255 0~100%
31 15 Background Bottom Cool White 000-255 0~100%
32 16 000-255 0~100%
Background Bottom Warm White
ww

06 17
INSTALLATION DMX CHANNELS
The Diamondback may be set up on a solid and even surface. By means of the fixing facilities of the
baseplate,the unit can also be mounted upside down to a cross arm. For fixing, stablemounting clips
are required. The bolts of the brackets are placed into the openings provided in the base plate and
turned clockwise until they lock (to the stop). Always ensure that the unit is firmly fixed to avoid vibration
and slipping while operating. The mounting place must be of sufficient stability and be able to support a
weight of 10 times of the unit’s weight. When carrying out any installation,always comply scrupulously with
all the regulations (particularly regarding safety) currently in force in the country in which the fixture’s being
used. Always additionally secure the projector with the safety rope from falling down. For this purpose, fasten
the safety rope at a suitable position so that the maximum fall of the projector will be 20 cm.
118Ch Mode
DMX
/ NET
DMX
+NET Function Value Percent/Setting
66
60
Warm White2
000-255
0~100%
...
000-255
0~100%
...
000-255
0~100%
... 000-255 0~100%
115 109 Cool White27 000-255 0~100%
116
110
Warm White27
000-255
0~100%
117
111
Cool White28
000-255
0~100%
118
112
Warm White28
000-255
0~100%
1 1 Tilt 000-255 0~100%
2 2 Zoom 000-255 From narrow to wide beam
3 3 Strobe
000-003
Light OFF
004-103
Strobe from low (1Hz) to fast (25Hz)
104-107
Light ON
108-207
Pulsation from slow (0.5 Hz) to fast (25 Hz)
208-212 Light ON
213-225 Random Slow Strobe
226-238 Random Medium Strobe
239-251
Random Fast Strobe
252-255
Light ON
4
4
Dimmer
000-255
0~100%
5 5 White Strobe
000-003
Light OFF
004-103 Strobe from low (1Hz) to fast (25Hz)
104-107 Light ON
108-207
Pulsation from slow (0.5 Hz) to fast (25 Hz)
208-212
Light ON
213-225
Random Slow Strobe
226-238
Random Medium Strobe
239-251 Random Fast Strobe
252-255 Light ON
6
6
White Dimmer
000-255
0~100%
7 7 Device Setting
000-005
No Function
026-076
Head Reset (Hold 5S)
077-127
Pan/Tilt Reset (Hold 5S)
128-178 Complete Reset(Hold 5S)
179-192
91Ch Mode
DMX
/ NET
DMX
+NET Function Value Percent/Setting
No Function
193-200 Dimmer Mode 1
www.eklights.com

DMX CHANNELS
91Ch Mode
DMX
/ NET
DMX
+NET Function Value Percent/Setting
7 7 Device Setting
201-208 Dimmer Mode 2
209-216 Dimmer Mode 3
217-224 Dimmer Mode 4
225-255 No Function
8 1 Red1 000-255 0~100%
9 2 Green1 000-255 0~100%
10 3 Blue1 000-255 0~100%
11 4 White1 000-255 0~100%
12 5 Red2 000-255 0~100%
13 6 Green2 000-255 0~100%
14 7 Blue2 000-255 0~100%
15 8 White2 000-255 0~100%
... 000-255 0~100%
... 000-255 0~100%
... 000-255 0~100%
... 000-255 0~100%
60 53 Red14 000-255 0~100%
61 54 Green14 000-255 0~100%
62 55 Blue14 000-255 0~100%
63 56 White14 000-255 0~100%
64 57 Cool White1 000-255 0~100%
65 58 Warm White1 000-255 0~100%
66 59 Cool White2 000-255 0~100%
67 60 Warm White2 000-255 0~100%
... 000-255 0~100%
... 000-255 0~100%
... 000-255 0~100%
88 81 Cool White13 000-255 0~100%
89 82 Warm White13 000-255 0~100%
90 83 Cool White14 000-255 0~100%
91 84 Warm White14 000-255 0~100%
119Ch Mode
DMX
/ NET
DMX
+NET Function Value Percent/Setting
1 1 Tilt 000-255 0~100%
2 2 Zoom 000-255 From narrow to wide beam
3 3 Strobe
000-003 Light OFF
004-103 Strobe from low (1Hz) to fast (25Hz)
104-107 Light ON
Table of contents
Other ShowPro Lighting Equipment manuals

ShowPro
ShowPro UniFog DMX User manual

ShowPro
ShowPro LED EPAR CW MULTI User manual

ShowPro
ShowPro Venue Haze 1200 User manual

ShowPro
ShowPro H1 PROFILE User manual

ShowPro
ShowPro NITEC photon multi LEDNIT141 User manual

ShowPro
ShowPro X-Blinder User manual

ShowPro
ShowPro Dreampix Driver 1800 IP User manual

ShowPro
ShowPro PLUTO 600 PROFILE User manual

ShowPro
ShowPro PLUTO 250 User manual

ShowPro
ShowPro LED UP Quad-4 User manual
