Shure i4c-t User manual

I4c-T
Sound Isolating Earphones
These sound-isolating
earphones with VoicePort inline
microphone connect to your
integrated media player cell
phone. They feature Tuned
Port-enhanced High Definition
Drivers for a superior frequency
soundstage with extended bass
that you can now enjoy at low
listening levels, even in noisy
environments.
INSERTING THE EARPHONES
If the earphone seems to be lacking in low frequency response (bass), check
the tightness of the seal between the earphone and your ear, or try one of the
other sleeve options.
Warning: Do not push the earphone sleeve beyond the ear canal opening.
WEARING THE EARPHONES
CHOOSING AN EARPHONE SLEEVE
Your earphones come with a selection of sleeves. Make sure the sleeve you
use is easy to insert into your ear, fits comfortably, and is easy to remove from
your ear.
CLEANING THE EARPHONE NOZZLE
If the nozzle of your earphone is blocked, clean the nozzle using the supplied
wax removal loop.
Make sure that the sleeve completely covers
the earphone nozzle. If any part of the nozzle is
exposed, the sleeve is not properly installed
Nozzle
Wax Removal Loop
When cleaning, do not force any object through the earphone nozzle! This will
damage the earphone sound filter.
If necessary, the supplied replacement nozzles may be used. See the back of
this guide for instructions on nozzle replacement.
©2005, Shure Incorporated
27EN3213 (Rev. 2)
Printed in U.S.A.
Foam Sleeves
When using the foam sleeves, compress the sleeve between
your fingers before inserting it into the ear canal. Hold the
earphone in place for about ten seconds while the foam
expands and creates a tight seal.
Soft Flex Sleeves
In small, medium, and large sizes. Made from pliable rubber.
Flex Sleeves
In small, medium, and large sizes. Made from translucent
PVC.
Triple-Flange Sleeves
If desired, the sleeve nozzle may be shortened. Use sharp
scissors to carefully trim the nozzle to the desired length.
Over the ear
in front
INLINE SWITCH CONTROL
Push and hold to to MUTE cell phone microphone
Volume
Note: switching to media during a call mutes cell phone.
left
right
Wear the earphones as illustrated below.

REPLACING THE EARPHONE NOZZLE
Replace the nozzle if it becomes damaged, or if wax buildup cannot be
removed using the wax removal loop.
Unscrew the retainer  from the earphone base .
Remove the nozzle .
Slide the retainer  over the new nozzle �
Place the nozzle on the earphone base with the flange  aligned with the
groove in the base. Tighten the retainer .
Be careful when replacing the earphone nozzle. Parts are small and easily lost
if dropped.
1.
2.
3.
4.
FURNISHED ACCESSORIES
Carrying pouch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95A2259
Fit Kit w/cleaning tool . . . . . . . . . . . . . . . . . . . . . . . . 90XJ1371
Triple flange sleeves . . . . . . . . . . . . . . . . . . . . . . . . . 90WX1371
Replacement nozzles . . . . . . . . . . . . . . . . . . . . . . . . 90XF1371
Plug adapter — 1/8” to 1/4” . . . . . . . . . . . . . . . . . . . PA234
REPLACEMENT PARTS
Bag of 20 foam sleeves . . . . . . . . . . . . . . . . . . . . . . . PA750
Bag of 500 foam sleeves . . . . . . . . . . . . . . . . . . . . . . PA754
Bag of 10 clear flex sleeves:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . small PA756S
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . medium PA756M
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . large PA756L
Bag of 10 soft flex sleeves:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . small PA758S
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . medium PA758M
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . large PA758L
Triple-flange sleeves (2) . . . . . . . . . . . . . . . . . . . . . . PA755
Replacement nozzles (2) . . . . . . . . . . . . . . . . . . . . . . PA4NC

�
MAINTENANCE
Careful maintenance ensures a tight seal between the sleeve
and nozzle, improving sound quality and product safety.
Keep the earphones and sleeves as clean and dry as possible.
Do not expose earphones to extreme temperatures.
Wipe the earphones and sleeves with mild antiseptic to avoid
infections. Do not use alcohol-based disinfectants.
CERTIFICATION
Eligible to bear CE marking.
Conforms to European EMC Directive 89/336/EEC.
Meets applicable tests and performance criteria in European Standard
EN 55103 (1996) Parts 1 and 2, for residential (E1) and light industrial (E2)
environments.
TECHNICAL SPECIFICATIONS
Transducer type Single balanced armature
Sensitivity (at 1kHz) 109 dB SPL/mW
Impedance (at 1kHz) 29 W
Output connector 2.5mm-4pin jack for use with the
TREO650 smartphone.
Operational temperature -18° C to 57° C (0° F to 135° F)
Storage temperature -29° C to 74° C (-20° F to 165° F)
CUSTOM EARPHONE SLEEVES
Those who use earphones regularly for extended periods of time often find
custom-fit molded sleeves offer the best comfort and sound isolation.
Ask a Hearing Health Care Professional about creating custom molded sleeves
for your earphones. For more information, visit http://www.sensaphonics.com.
FULL TWO YEAR WARRANTY
SHURE Incorporated http://www.shure.com
United States, Canada, Latin America, Caribbean:
5800 W. Touhy Avenue, Niles, IL 60714-4608, U.S.A.
Phone: [phone] U.S. Fax: [phone] Int’l Fax: [phone]
Europe, Middle East, Africa:
Shure Europe GmbH, Phone: [phone] Fax: [phone]
Asia, Pacific:
SAFE USE
Use a slow twisting motion to remove the earphones. Never pull on
the earphone cord.
Warning: If a sleeve becomes lodged in your ear, seek skilled medical
assistance to remove the sleeve. Damage to the ear may be caused
by non-professionals attempting to remove the sleeve.
Prior to inserting the earphone, always recheck the sleeve to make
sure it is firmly attached to the nozzle.
 Turn up the volume control only far enough to hear properly.
Ringing in the ears may indicate that the volume level is too high. Try
lowering the volume.
If you connect these earphones to an airplane’s sound system, listen
at low levels so that loud messages from the pilot do not cause
discomfort.
Have your ears checked by an audiologist on a regular basis. If you
experience wax buildup, discontinue use until an audiologist has
examined your ears.
Stop using the earphones if they are causing great discomfort or
infection.
Shure Incorporated (“Shure”) hereby warrants that this product will be free
from defects in materials and workmanship for a period of two years from
the date of purchase. At its option Shure will repair or replace the defective
product and promptly return it to you, or refund the purchase price. You should
retain proof of purchase to validate the purchase date and return it with any
warranty claim.
If you believe this product is defective within the warranty period, carefully
repack the unit, insure it, and return it postage prepaid to:
Shure Incorporated
5800 W. Touhy Ave.
Niles, IL 60714-4608
