SICK deTec2 Core User manual

OPERATING INSTRUCTIONS
deTec2 Core
Safety light curtain

Described product
deTec2 Core
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is
only permissible within the limits of the legal determination of Copyright Law. Any modi‐
fication, abridgment or translation of this document is prohibited without the express
written permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
2O P E R A T I N G I N S T R U C T I O N S | deTec2 Core 8014276/1DCM/2022-10-27 | SICK
Subject to change without notice

Contents
1 About this document........................................................................ 6
1.1 Purpose of this document........................................................................ 6
1.2 Scope......................................................................................................... 6
1.3 Target groups of these operating instructions........................................ 6
1.4 Additional information.............................................................................. 6
1.5 Symbols and document conventions...................................................... 7
2 Safety information............................................................................ 8
2.1 General safety notes................................................................................ 8
2.2 Correct use................................................................................................ 8
2.3 Inappropriate use..................................................................................... 8
2.4 Requirements for the qualification of personnel.................................... 9
3 Product description........................................................................... 10
3.1 Structure and function............................................................................. 10
3.2 Product characteristics............................................................................ 11
3.2.1 Device overview....................................................................... 11
3.2.2 Absence of blind zones........................................................... 11
3.2.3 Automatic calibration of the protective field width................ 11
3.2.4 Alignment aid........................................................................... 11
3.2.5 Status indicators...................................................................... 12
3.3 Example applications............................................................................... 13
4 Project planning................................................................................ 15
4.1 Manufacturer of the machine.................................................................. 15
4.2 Operating entity of the machine.............................................................. 15
4.3 Design........................................................................................................ 15
4.3.1 Scanning range and protective field width............................. 16
4.3.2 Minimum distance from the hazardous point....................... 17
4.3.3 Minimum distance to reflective surfaces............................... 19
4.3.4 Protection against interference from systems in close prox‐
imity to each other................................................................... 21
4.4 Integration in electrical control................................................................ 22
4.4.1 Restart interlock...................................................................... 24
4.4.2 External device monitoring (EDM).......................................... 24
4.4.3 Connection diagrams.............................................................. 25
4.5 Testing plan............................................................................................... 25
4.5.1 Test rod check.......................................................................... 26
4.5.2 Visual check of the machine and the protective device........ 29
5 Mounting............................................................................................. 30
5.1 Unpacking.................................................................................................. 30
5.2 Installation................................................................................................ 30
5.2.1 Mounting the QuickFix bracket............................................... 33
CONTENTS
8014276/1DCM/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec2 Core 3
Subject to change without notice

5.2.2 Mounting the FlexFix bracket.................................................. 35
5.2.3 Mounting the Compact FlexFix bracket.................................. 38
5.2.4 Mounting the upgrade bracket............................................... 39
6 Electrical installation........................................................................ 41
6.1 Safety......................................................................................................... 41
6.2 System connection (M12, 5-pin)............................................................. 42
6.3 System connection via connection cable (M12, 5-pin to 8-pin)............ 43
7 Commissioning.................................................................................. 44
7.1 Overview.................................................................................................... 44
7.2 Switching on.............................................................................................. 44
7.3 Sender and receiver alignment................................................................ 44
7.3.1 Aligning the sender and receiver............................................ 45
7.3.2 Alignment with the QuickFix bracket...................................... 46
7.3.3 Alignment with the FlexFix bracket or with the upgrade
bracket...................................................................................... 46
7.3.4 Alignment with the Compact FlexFix bracket......................... 47
7.3.5 Indication of the alignment quality......................................... 48
7.4 Check during commissioning and modifications.................................... 49
8 Operation............................................................................................ 50
8.1 Regular thorough check........................................................................... 50
9 Maintenance...................................................................................... 51
9.1 Regular cleaning....................................................................................... 51
9.2 Regular thorough check........................................................................... 52
10 Troubleshooting................................................................................. 53
10.1 Safety......................................................................................................... 53
10.2 Diagnostic LEDs........................................................................................ 53
10.2.1 Fault indicators........................................................................ 53
11 Decommissioning............................................................................. 55
11.1 Disposal..................................................................................................... 55
12 Technical data.................................................................................... 56
12.1 Data sheet................................................................................................. 56
12.2 Response time.......................................................................................... 58
12.3 Power consumption.................................................................................. 58
12.4 Length of cable......................................................................................... 59
12.5 Table of weights........................................................................................ 59
12.6 Dimensional drawings.............................................................................. 60
13 Ordering information........................................................................ 61
13.1 Scope of delivery....................................................................................... 61
13.2 Ordering information................................................................................. 61
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | deTec2 Core 8014276/1DCM/2022-10-27 | SICK
Subject to change without notice

14 Accessories........................................................................................ 62
14.1 Brackets.................................................................................................... 62
14.2 Mounting accessories.............................................................................. 64
14.3 Weld spark guard...................................................................................... 64
14.4 Connectors................................................................................................ 66
14.5 Alignment aid............................................................................................ 67
14.6 Deflector mirrors....................................................................................... 67
14.6.1 Function and use..................................................................... 67
14.6.2 Mounting.................................................................................. 67
14.6.3 Change in scanning range using deflector mirrors................ 68
14.6.4 Deflector mirror PNS75 - ordering information...................... 68
14.6.5 Deflector mirror PNS125 - ordering information................... 68
14.7 Mirror columns.......................................................................................... 69
14.8 Device columns......................................................................................... 69
14.9 Cleaning agent.......................................................................................... 69
14.10 Test rods.................................................................................................... 70
15 Annex.................................................................................................. 71
15.1 Conformities and certificates................................................................... 71
15.1.1 EU declaration of conformity................................................... 71
15.1.2 UK declaration of conformity.................................................. 71
15.2 Note on standards.................................................................................... 71
15.3 Checklist for initial commissioning and commissioning........................ 73
16 List of figures..................................................................................... 74
17 List of tables....................................................................................... 75
CONTENTS
8014276/1DCM/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec2 Core 5
Subject to change without notice

1 About this document
1.1 Purpose of this document
These operating instructions contain information required during the life cycle of the
safety light curtain.
These operating instructions are available to all those who work with the safety light
curtain.
Please read these operating instructions carefully and make sure that you understand
the content fully before working with the safety light curtain.
1.2 Scope
This document applies to the following products:
•Product code: deTec2 Core
•“Operating instructions” type label entry: 8014274
Document identification
Document part number:
•This document: 8014276
•Available language versions of this document: 8014274
You can find the current version of all documents at www.sick.com.
1.3 Target groups of these operating instructions
Some sections of these operating instructions are intended for certain target groups.
However, the entire operating instructions are relevant for intended use of the product.
Table 1: Target groups and selected sections of these operating instructions
Target group Sections of these operating instructions
Project developers (planners, developers,
designers)
"Project planning", page 15
"Technical data", page 56
"Accessories", page 62
Installers "Mounting", page 30
Electricians "Electrical installation", page 41
Safety experts (such as CE authorized repre‐
sentatives, compliance officers, people who
test and approve the application)
"Project planning", page 15
"Commissioning", page 44
"Technical data", page 56
"Checklist for initial commissioning and com‐
missioning", page 73
Operators "Operation", page 50
"Troubleshooting", page 53
Maintenance personnel "Maintenance", page 51
"Troubleshooting", page 53
1.4 Additional information
www.sick.com
The following information is available on the Internet:
•Data sheets and application examples
•CAD data and dimensional drawings
1 ABOUT THIS DOCUMENT
6O P E R A T I N G I N S T R U C T I O N S | deTec2 Core 8014276/1DCM/2022-10-27 | SICK
Subject to change without notice

•Certificates (e.g. EU declaration of conformity)
•Guide for Safe Machinery Six steps to a safe machine
1.5 Symbols and document conventions
The following symbols and conventions are used in this document:
Safety notes and other notes
DANGER
Indicates a situation presenting imminent danger, which will lead to death or serious
injuries if not prevented.
WARNING
Indicates a situation presenting possible danger, which may lead to death or serious
injuries if not prevented.
CAUTION
Indicates a situation presenting possible danger, which may lead to moderate or minor
injuries if not prevented.
NOTICE
Indicates a situation presenting possible danger, which may lead to property damage if
not prevented.
NOTE
Indicates useful tips and recommendations.
Instructions to action
bThe arrow denotes instructions to action.
1. The sequence of instructions for action is numbered.
2. Follow the order in which the numbered instructions are given.
✓The check mark denotes the result of an instruction.
LED symbols
These symbols indicate the status of an LED:
oThe LED is off.
ÖThe LED is flashing.
OThe LED is illuminated continuously.
Sender and receiver
These symbols indicate the sender and receiver of the device:
sThe symbol indicates the sender.
rThe symbol indicates the receiver.
ABOUT THIS DOCUMENT 1
8014276/1DCM/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec2 Core 7
Subject to change without notice

2 Safety information
2.1 General safety notes
DANGER
The product can not offer the expected protection if it is integrated incorrectly.
bPlan the integration of the product in accordance with the machine requirements
(project planning).
bImplement the integration of the product in accordance with the project planning.
DANGER
Death or severe injury due to electrical voltage and/or an unexpected startup of the
machine
bMake sure that the machine is (and remains) disconnected from the voltage
supply during mounting and electrical installation.
bMake sure that the dangerous state of the machine is and remains switched off.
DANGER
Improper work on the product
A modified product may not offer the expected protection if it is integrated incorrectly.
bApart from the procedures described in this document, do not repair, open, manip‐
ulate or otherwise modify the product.
2.2 Correct use
The deTec2 Core safety light curtain is an electro-sensitive protective device (ESPE) and
is suitable for the following applications:
•Hazardous point protection
•Access protection
•Hazardous area protection
The product may be used in safety functions.
The deTec2 Core safety light curtain must only be used within the limits of the prescri‐
bed and specified technical data and operating conditions at all times.
Any instance of improper use, incorrect modification, or manipulation of the deTec2
Core safety light curtain shall void any warranty provided by SICK AG; furthermore,
SICK AG shall not accept any responsibility or liability for any resulting damage and
consequential damage.
2.3 Inappropriate use
The safety light curtain works as an indirect protective measure and cannot provide
protection from parts thrown out nor from emitted radiation. Transparent objects are
not detected.
Among others, the deTec2 Core safety light curtain is not suitable for the following
applications:
•Outdoors
•Underwater
•In explosion-hazardous areas
2 SAFETY INFORMATION
8O P E R A T I N G I N S T R U C T I O N S | deTec2 Core 8014276/1DCM/2022-10-27 | SICK
Subject to change without notice

•At altitudes over 3,000m above sea level
•In environments with increased levels of ionizing radiation
2.4 Requirements for the qualification of personnel
The safety light curtain must only be configured, installed, connected, commissioned
and serviced by qualified safety personnel.
Project planning
You need safety expertise to implement safety functions and select suitable products
for that purpose. You need expert knowledge of the applicable standards and regula‐
tions.
Mounting, electrical installation and commissioning
You need suitable expertise and experience. You must be able to assess if the machine
is operating safely.
Operation and maintenance
You need suitable expertise and experience. You must be instructed in machine oper‐
ation by the machine operator. For maintenance, you must be able to assess if the
machine is operating safely.
SAFETY INFORMATION 2
8014276/1DCM/2022-10-27 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec2 Core 9
Subject to change without notice

3 Product description
3.1 Structure and function
Overview
The deTec2 Core safety light curtain is an electro-sensitive protective device (ESPE)
consisting of a sender and receiver.
A series of parallel infrared light beams forms a protective field between sender and
receiver that protects the hazardous area (hazardous point, access, and hazardous
area protection). When one or more beams are completely interrupted, the safety light
curtain reports the interruption in the light path to the secure output signal switching
devices (OSSDs) by a signal change. The machine or its control must safely analyze the
signals (for example using a safe control or safety relays) and stop the dangerous state.
Sender and receiver automatically synchronize themselves optically. An electrical con‐
nection between both components is not required.
r
s
Figure 1: Sender and receiver
Protective field height
The protective field height indicates the range within which the test rod belonging to the
safety light curtain is reliably detected.
Protective field width
The protective field width is the dimension of the light path between sender and
receiver. The maximum protective field width is limited by the scanning range.
Resolution
The resolution describes the size of the smallest object detected by the safety light
curtain in the protective field. The resolution corresponds to the diameter of the test rod
belonging to the safety light curtain.
The safety light curtain has a resolution of 14 mm. This resolution provides finger
protection.
The safety light curtain has a resolution of 30mm. This resolution provides hand
protection.
3 PRODUCT DESCRIPTION
10 O P E R A T I N G I N S T R U C T I O N S | deTec2 Core 8014276/1DCM/2022-10-27 | SICK
Subject to change without notice
