Siemens SIPROCESS GA700 User manual

Continuous gas analysis
SIPROCESS GA700
Operating with the Local User
Interface
Operating Manual
06/2017
A5E31930478
-05
Introduction
1
General information
2
Description
3
Operation
4
Commissioning
5
Functions
6
Alarm, error, and system
messages
7
Appendix
A

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
Document order number: A5E31930478
Ⓟ
08/2017 Subject to change
Copyright © Siemens AG 2013 - 2017.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury
may
result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05 3
Table of contents
1 Introduction........................................................................................................................................... 11
1.1 Purpose of this documentation ...............................................................................................11
1.2 History.....................................................................................................................................11
1.3 Notes on warranty...................................................................................................................12
1.4 Target group ...........................................................................................................................12
1.5 Conventions ............................................................................................................................12
2 General information .............................................................................................................................. 15
2.1 KC Safety note - Information for Korea only...........................................................................15
2.2 Safety instructions...................................................................................................................15
2.3 Information on use ..................................................................................................................16
2.3.1 Prerequisites for safe use .......................................................................................................16
2.3.2 Security messages..................................................................................................................16
2.3.3 Communications .....................................................................................................................17
2.3.4 Qualified personnel.................................................................................................................17
2.3.5 Automatic reset .......................................................................................................................17
3 Description............................................................................................................................................ 19
3.1 Overview .................................................................................................................................19
3.2 OXYMAT 7..............................................................................................................................20
3.2.1 Design.....................................................................................................................................20
3.2.2 Functional principles ...............................................................................................................22
3.3 ULTRAMAT 7..........................................................................................................................24
3.3.1 Design.....................................................................................................................................24
3.3.2 How the ULTRAMAT 7 works.................................................................................................25
3.4 CALOMAT 7............................................................................................................................27
3.4.1 Design.....................................................................................................................................27
3.4.2 How the CALOMAT 7 works...................................................................................................28
3.4.3 CALOMAT 7 measurement task.............................................................................................28
3.5 Option modules.......................................................................................................................30
3.6 Combined operation................................................................................................................31
3.6.1 Analyzer module/installation location combinations ...............................................................31
3.6.1.1 Safety instruction(s) ................................................................................................................31
3.6.1.2 Analyzer module/slot combinations: Slots ..............................................................................33
3.6.2 Operating modes ....................................................................................................................33
3.6.2.1 Setting instructions..................................................................................................................33
3.6.2.2 Operating modes: Serial/parallel operation ............................................................................34
3.6.2.3 Operating modes: Selection of operating mode .....................................................................35
3.6.3 Gas connections .....................................................................................................................35
3.6.3.1 Safety instruction(s) ................................................................................................................35

Table of contents
Operating with the Local User Interface
4Operating Manual, 06/2017, A5E31930478-05
3.6.3.2 Sample gas restrictors/clamping screws ............................................................................... 37
3.6.3.3 Conditions for use/installation ................................................................................................ 40
3.6.4 Plug & measure permitted activities ...................................................................................... 44
3.6.4.1 Plug & measure...................................................................................................................... 44
3.6.4.2 Setting instructions................................................................................................................. 45
3.6.4.3 Case differentiations .............................................................................................................. 46
4 Operation.............................................................................................................................................. 51
4.1 Local User Interface (LUI)...................................................................................................... 51
4.2 Keyboard................................................................................................................................ 55
4.2.1 Structure................................................................................................................................. 55
4.2.2 Key functions.......................................................................................................................... 56
4.2.3 UNDO function....................................................................................................................... 58
4.2.3.1 UNDO overview ..................................................................................................................... 58
4.2.3.2 Undo actions with the <UNDO> key ...................................................................................... 59
4.3 Display ................................................................................................................................... 60
4.3.1 Structure................................................................................................................................. 60
4.3.2 Header ................................................................................................................................... 61
4.3.3 Display area ........................................................................................................................... 63
4.3.3.1 Main view (read mode) .......................................................................................................... 63
4.3.3.2 Main view (selection mode) ................................................................................................... 67
4.3.3.3 Navigational view ................................................................................................................... 67
4.3.3.4 Parameter view ...................................................................................................................... 68
4.3.4 Status bar............................................................................................................................... 71
4.4 Menu structure ....................................................................................................................... 72
4.4.1 Main menu ............................................................................................................................. 72
4.4.2 Subordinate menus................................................................................................................ 73
5 Commissioning ..................................................................................................................................... 77
5.1 Requirements......................................................................................................................... 77
5.2 Commissioning the SIPROCESS GA700 .............................................................................. 78
6 Functions.............................................................................................................................................. 83
6.1 [1] Quick Start ........................................................................................................................ 83
6.1.1 Quick Start Overview ............................................................................................................. 83
6.1.2 Requirements......................................................................................................................... 83
6.1.3 [1.1] Basic settings................................................................................................................. 83
6.1.4 [1.2] Automatic log-off ............................................................................................................ 85
6.1.5 [1.3] Analog outputs ............................................................................................................... 86
6.1.6 [1.4] Measuring ranges .......................................................................................................... 88
6.1.6.1 Overview of measuring ranges .............................................................................................. 88
6.1.6.2 Setting the measuring ranges................................................................................................ 89
6.1.6.3 Setting Autoranging ............................................................................................................... 91
6.1.7 [1.5] Calibration...................................................................................................................... 92
6.1.7.1 Calibration/validation overview .............................................................................................. 92
6.1.7.2 Execute calibration/validation ................................................................................................ 96
6.1.8 [1.6] Save parameter set........................................................................................................ 98
6.1.8.1 Parameter sets overview ....................................................................................................... 98
6.1.8.2 Save parameter set................................................................................................................ 98
6.2 [2.01] Settings >Display/USER FUNC key ............................................................................ 98

Table of contents
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05 5
6.2.1 Setting the measured-value format.........................................................................................98
6.2.2 Setting the extended measured-value display........................................................................99
6.2.3 Displaying additional process values....................................................................................100
6.2.4 Customizing the display settings ..........................................................................................101
6.2.5 Setting the symbol sets.........................................................................................................101
6.2.6 Assigning USER FUNC key..................................................................................................102
6.3 [2.02] Settings > Time/Date ..................................................................................................102
6.3.1 Setting the time and date......................................................................................................102
6.4 [2.03] Settings > Measuring ranges......................................................................................103
6.4.1 Overview of measuring ranges .............................................................................................103
6.4.2 Setting the measuring ranges...............................................................................................105
6.4.3 Setting Autoranging ..............................................................................................................106
6.5 [2.04] Settings > Limits .........................................................................................................107
6.5.1 Overview of limits..................................................................................................................107
6.5.2 Setting limits..........................................................................................................................108
6.6 [2.07] Settings > Noise suppression .....................................................................................111
6.6.1 Overview of noise suppression.............................................................................................111
6.6.2 Setting noise suppression.....................................................................................................112
6.7 [2.08] Settings > Calibrations................................................................................................114
6.7.1 Basics....................................................................................................................................114
6.7.1.1 Calibration/validation.............................................................................................................114
6.7.1.2 Sequence of a calibration/validation .....................................................................................116
6.7.2 Calibration requirements.......................................................................................................118
6.7.2.1 Overview ...............................................................................................................................118
6.7.2.2 Permissibility of calibrations..................................................................................................118
6.7.2.3 Non-permissibility of calibrations ..........................................................................................119
6.7.3 [2.08.1] Setpoints, tolerances, purging time .........................................................................121
6.7.3.1 Overview ...............................................................................................................................121
6.7.3.2 Setting the setpoints .............................................................................................................121
6.7.3.3 Setting validation tolerances.................................................................................................123
6.7.3.4 Setting the calibration tolerances..........................................................................................124
6.7.3.5 Setting the sample gas purging time ....................................................................................124
6.7.4 [2.08.2] Calibration pool........................................................................................................126
6.7.4.1 Overview ...............................................................................................................................126
6.7.4.2 Assigning parameters for calibration pool entries.................................................................126
6.7.5 [2.08.3] Execute calibrations.................................................................................................128
6.7.5.1 [2.08.3.1] Use calibration pool ..............................................................................................128
6.7.5.2 [2.08.3.2] Free calibration .....................................................................................................129
6.7.6 [2.08.4] AutoCal/AutoVal 1 and [2.08.5] AutoCal/AutoVal 2.................................................131
6.7.6.1 Overview of AutoCal/AutoVal ...............................................................................................131
6.7.6.2 Setting the AutoCal/AutoVal sequence.................................................................................132
6.7.6.3 Setting the AutoCal/AutoVal mode .......................................................................................134
6.8 [2.09] Settings > Inputs/outputs ............................................................................................137
6.8.1 [2.09.1] Analog inputs ...........................................................................................................137
6.8.1.1 Overview ...............................................................................................................................137
6.8.1.2 Set analog inputs ..................................................................................................................137
6.8.2 [2.09.2] Analog output...........................................................................................................141
6.8.2.1 Overview ...............................................................................................................................141
6.8.2.2 Setting the analog outputs ....................................................................................................142

Table of contents
Operating with the Local User Interface
6Operating Manual, 06/2017, A5E31930478-05
6.8.3 [2.09.3] Digital inputs ........................................................................................................... 143
6.8.3.1 Overview of digital inputs ..................................................................................................... 143
6.8.3.2 Setting digital inputs............................................................................................................. 148
6.8.4 [2.09.4] DI links .................................................................................................................... 150
6.8.4.1 Overview of DI links ............................................................................................................. 150
6.8.4.2 Linking digital inputs............................................................................................................. 150
6.8.5 [2.09.5] Digital outputs ......................................................................................................... 152
6.8.5.1 Overview .............................................................................................................................. 152
6.8.5.2 Functions.............................................................................................................................. 153
6.8.5.3 Setting digital outputs........................................................................................................... 155
6.8.5.4 Setting functions/components of a digital output ................................................................. 156
6.9 [2.10] Settings > Correction of cross-interferences ............................................................. 160
6.9.1 Overview .............................................................................................................................. 160
6.9.2 Correction coefficients ......................................................................................................... 160
6.9.3 Application scenarios ........................................................................................................... 161
6.9.3.1 Applications of OXYMAT 7 .................................................................................................. 161
6.9.3.2 ULTRAMAT 7 application scenarios.................................................................................... 163
6.9.3.3 CALOMAT 7 application scenarios...................................................................................... 165
6.9.4 Setting instructions............................................................................................................... 166
6.9.5 Setting the correction of cross-interference ......................................................................... 168
6.9.6 OXYMAT 7 ........................................................................................................................... 169
6.9.6.1 Assigning correction of cross-interference with a constant ................................................. 169
6.9.6.2 Assigning variable correction of cross-interference ............................................................. 170
6.9.7 ULTRAMAT 7....................................................................................................................... 172
6.9.7.1 Assigning correction of cross-interference with a constant ................................................. 172
6.9.7.2 Assigning variable correction of cross-interference ............................................................. 172
6.9.8 CALOMAT 7......................................................................................................................... 174
6.9.8.1 Correction of cross-interference in the application "H2 in N2 (Q)" for furnace gas,
converter gas and wood distillation...................................................................................... 174
6.9.8.2 Assigning correction of cross-interference with a constant ................................................. 176
6.9.8.3 Assigning variable correction of cross-interference............................................................. 177
6.9.9 Enabling/disabling all corrections of cross-interferences..................................................... 179
6.10 [2.11] Settings > Pressure sensor selection ........................................................................ 179
6.10.1 Overview .............................................................................................................................. 179
6.10.2 Setting instructions............................................................................................................... 180
6.10.3 Using device-internal pressure sensor ................................................................................ 181
6.10.4 Integrating external pressure sensor via MODBUS TCP .................................................... 182
6.10.5 Integrating external pressure sensor via analog inputs ....................................................... 182
6.11 [2.12] Settings > Gas path/process tag label....................................................................... 183
6.12 [2.13] Setting > Process tag switchover............................................................................... 185
6.12.1 Setting the process tag switchover ...................................................................................... 185
6.12.2 Assigning process tags ........................................................................................................ 185
6.12.3 Enabling/disabling all process tags...................................................................................... 186
6.13 [2.14] Settings > Set message parameters.......................................................................... 187
6.13.1 Set message parameters..................................................................................................... 187
6.13.2 Filtering messages ............................................................................................................... 188
6.13.3 Set individual message parameters..................................................................................... 189
6.14 [2.20] Settings > Service...................................................................................................... 190
6.14.1 [2.20.02] Heaters.................................................................................................................. 190

Table of contents
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05 7
6.14.1.1 [2.20.02] Heaters OXYMAT 7 ...............................................................................................190
6.14.1.2 [2.20.02] Heaters ULTRAMAT 7...........................................................................................190
6.14.1.3 [2.20.02] Heaters CALOMAT 7.............................................................................................190
6.14.2 [2.20.03] Factory calibrations................................................................................................190
6.14.2.1 Overview ...............................................................................................................................190
6.14.2.2 Note on setting......................................................................................................................191
6.14.2.3 [2.20.03] Factory calibrations OXYMAT 7 ............................................................................191
6.14.2.4 [2.20.03] Factory calibrations ULTRAMAT 7 ........................................................................193
6.14.2.5 [2.20.03] Factory calibrations CALOMAT 7 ..........................................................................195
6.14.3 [2.20.04] Calibrate pressure sensor......................................................................................196
6.14.3.1 Overview ...............................................................................................................................196
6.14.3.2 [2.20.04] Calibrate pressure sensor OXYMAT 7 ..................................................................197
6.14.3.3 [2.20.04] Calibrate pressure sensor ULTRAMAT 7 ..............................................................198
6.14.3.4 [2.20.04] Calibrate pressure sensor CALOMAT 7 ................................................................198
6.14.4 [2.20.06] Reference gas pump OXYMAT 7 ..........................................................................199
6.14.5 [2.20.10] Name/unit...............................................................................................................200
6.14.6 [2.20.11] Physical measuring range .....................................................................................201
6.14.7 [2.20.12] Switch message system off/on ..............................................................................202
6.15 [3.01] Maintenance & Diagnostics > Current messages ......................................................203
6.15.1 Displaying current messages................................................................................................203
6.15.2 Filtering current messages ...................................................................................................204
6.15.3 Reading current messages...................................................................................................205
6.16 [3.02] Maintenance & Diagnostics > Messages to be acknowledged ..................................206
6.16.1 Displaying messages to be acknowledged...........................................................................206
6.16.2 Acknowledge message.........................................................................................................207
6.16.3 Acknowledge all messages ..................................................................................................208
6.17 [3.03] Maintenance & Diagnostics > Logbook ......................................................................209
6.17.1 Overview of logbook .............................................................................................................209
6.17.2 [3.03.1] Display logbook .......................................................................................................212
6.17.3 [3.03.1] Filter logbook entries ...............................................................................................213
6.17.4 [3.03.2] Delete logbook .........................................................................................................214
6.18 [3.04] Maintenance & Diagnostics > Measured value status................................................214
6.19 [3.05] Maintenance & Diagnostics > Diagnostics values......................................................215
6.19.1 [3.05.1] Measured signal diagnostics ...................................................................................215
6.19.1.1 Measured signal....................................................................................................................215
6.19.1.2 Heating controller..................................................................................................................217
6.19.2 [3.05.2] Predictive self-diagnostics ULTRAMAT 7................................................................218
6.19.3 [3.05.3] Electric parameters..................................................................................................219
6.19.4 [3.05.4] Inputs/outputs ..........................................................................................................221
6.19.4.1 [1] Analog inputs ...................................................................................................................221
6.19.4.2 [2] Analog outputs .................................................................................................................221
6.19.4.3 [3] Digital inputs ....................................................................................................................222
6.19.4.4 [4] Digital outputs ..................................................................................................................222
6.19.5 [3.05.5] Communications ......................................................................................................223
6.19.5.1 MODBUS TCP node .............................................................................................................223
6.19.5.2 MODBUS TCP digital inputs.................................................................................................224
6.19.6 [3.05.6] Operating hours counter ..........................................................................................224
6.20 [3.06] Maintenance & Diagnostics > Drift values ..................................................................225
6.20.1 Editing zero point drift values................................................................................................225

Table of contents
Operating with the Local User Interface
8Operating Manual, 06/2017, A5E31930478-05
6.20.2 Editing QAL3 drift values ..................................................................................................... 226
6.20.3 Displaying control reserve.................................................................................................... 226
6.21 [3.08] Maintenance & Diagnostics > Maintenance intervals ................................................ 227
6.21.1 Displaying maintenance intervals ........................................................................................ 227
6.21.2 Assigning maintenance interval parameters........................................................................ 227
6.22 [3.09] Maintenance & Diagnostics > Identification............................................................... 229
6.22.1 Overview .............................................................................................................................. 229
6.22.2 Identifying a device .............................................................................................................. 230
6.22.3 Identifying analyzer modules ............................................................................................... 231
6.22.4 Identifying additional features .............................................................................................. 232
6.22.5 Identify sensor module CALOMAT 7 ................................................................................... 232
6.22.6 Identifying option modules ................................................................................................... 233
6.23 [3.10] Maintenance & Diagnostics > Save/load parameter set............................................ 233
6.23.1 Overview .............................................................................................................................. 233
6.23.2 Save parameter set.............................................................................................................. 234
6.23.3 Load parameter set.............................................................................................................. 235
6.24 [3.11] Maintenance & Diagnostics > Test ............................................................................ 236
6.24.1 Overview of test ................................................................................................................... 236
6.24.2 [3.11.1] Test inputs/outputs.................................................................................................. 236
6.24.2.1 Testing of analog outputs..................................................................................................... 236
6.24.2.2 Testing analog inputs........................................................................................................... 238
6.24.2.3 Testing of digital outputs ...................................................................................................... 241
6.24.2.4 Testing of digital inputs ........................................................................................................ 243
6.24.3 [3.11.2] Test display............................................................................................................. 244
6.24.4 [3.11.3] Test keyboard ......................................................................................................... 244
6.24.5 [3.11.4] Test internal communication................................................................................... 244
6.25 [3.12] Maintenance & Diagnostics > Cold restart ................................................................ 245
6.26 [3.20] Maintenance & Diagnostics > Service trace .............................................................. 245
6.27 [4] Communications ............................................................................................................. 245
6.27.1 Overview .............................................................................................................................. 245
6.27.2 Setting communication via Ethernet .................................................................................... 247
6.27.3 Setting communication via MODBUS TCP.......................................................................... 248
6.27.4 Setting MODBUS digital inputs ............................................................................................ 249
6.28 [5] Security ........................................................................................................................... 251
6.28.1 Assigning / changing personal identification numbers (PIN) ............................................... 251
6.28.2 Automatic log-off .................................................................................................................. 251
6.29 [6] Language ........................................................................................................................ 253
7 Alarm, error, and system messages .....................................................................................................255
7.1 LUI symbol sets.................................................................................................................... 255
7.2 OXYMAT 7 message list...................................................................................................... 257
7.3 ULTRAMAT 7 message list.................................................................................................. 264
7.4 CALOMAT 7 message list.................................................................................................... 269
7.5 Wizard-based error messages............................................................................................. 273
7.6 Measured value status......................................................................................................... 276

Table of contents
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05 9
7.6.1 Messages..............................................................................................................................276
7.6.2 Symbolic representation .......................................................................................................278
A Appendix............................................................................................................................................. 279
A.1 Technical support..................................................................................................................279
A.2 Approvals ..............................................................................................................................280
A.2.1 Conformity with European directives ....................................................................................280
A.3 Certificate..............................................................................................................................281
A.4 References............................................................................................................................281
A.5 MODBUS TCP ......................................................................................................................284
A.5.1 MODBUS interface for SIPROCESS GA700........................................................................284
A.5.2 Planning/configuring .............................................................................................................285
A.5.3 Transfer of device data .........................................................................................................288
A.5.3.1 Device data ...........................................................................................................................288
A.5.3.2 Device data: Extras...............................................................................................................298
Index................................................................................................................................................... 303

Table of contents
Operating with the Local User Interface
10 Operating Manual, 06/2017, A5E31930478-05

Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05 11
Introduction
1
1.1
Purpose of this documentation
This documentation contains all the information you need to operate the device using the
local user interface (LUI).
The LUI consists of a display and keyboard with four keypads with which all analyzer
functions can be set using menus.
The analyzer can also be operated with SIMATIC PDM. Additional information on this topic is
available by referring the list of references in: Table A-2 References 2 - Operating
Manuals PDM (Page 281).
1.2
History
The following table includes information on the different editions of this document.
Table 1- 1 Document history
Edition
Comment
01
01/2013
First edition
Function "Sync." cannot currently be executed.
02
07/2014
Second edition
•Support of option modules 1.1 and 2.2.
•"[1] Quick start" menu with new functions for easier commissioning (Local User Inter-
face).
•Advanced operating options, e.g., "UNDO key" (Local User Interface)
•Switchover to SIMATIC PDM 8.1
03
05/2015
Second edition.
Content supplemented by content for the additional analyzer modules ULTRAMAT 7 and
CALOMAT 7.
04
03/2016
Fourth edition.
Additional module combinations for CALOMAT 7 and ULTRAMAT 7.
Extended ULTRAMAT 7 area of application: measurement of components NO, N2O,
SO
2
, CH
4
, C
2
H
4
, NH
3
06/2017
CALOMAT 7: 1-point calibration with substitute gas to shift the characteristics offset

Introduction
1.3 Notes on warranty
Operating with the Local User Interface
12 Operating Manual, 06/2017, A5E31930478-05
1.3
Notes on warranty
The content of these instructions is neither a part of a previous or existing agreement,
promise or legal relationship, nor is it intended to modify these. All obligations on the part of
Siemens AG are contained in the respective sales contract, which also contains the
complete and solely applicable warranty conditions. Any statements contained in this
documentation do not create new warranties or restrict the existing warranty.
The content reflects the technical status at the time of publishing. We reserve the right to
make technical changes in the course of further development.
1.4
Target group
This document is intended for all persons using the modular device for continuous
monitoring of process gases in an industrial environment. This specifically includes:
●Measurement technicians
●Plant operators
●Maintenance staff
●Service personnel
1.5
Conventions
Overview
To allow easier navigation within this documentation, the tables below provide information on
the use of markups and terminology.
Table 1- 2 Conventions on markups
Representation
type
Scope
"Add screen" •Terminology that appears in the user interface, for example, dialog names,
tabs, buttons, menu commands
•Required inputs, for example, limits, tag values.
•Path information
"File > Edit" Operational sequences, for example, menu commands, shortcut menu com-
mands.
<F1>, <Alt+P>
Keyboard operation

Introduction
1.5 Conventions
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05 13
Representation
type
Scope
[1] to [6] Numbers of the main menu in the LUI, part of the
menu name
The square brackets identi-
fy the chapter numbers that
precede the menu names.
[1. ...] to [6] Numbering of the menus downstream from the
main menu, part of the menu name
→Introduces a text-dependent reference to a section or a paragraph in this docu-
mentation. The page numbers are always specified in parentheses for refer-
ences in the document. Example of a reference (hyperlink):
→Appendix (Page 279)
Table 1- 3 Conventions on terminology
Term
Convention/alternative name
Local user inter-
face
"LUI" for short.
Auto hotspot
Defective reference
"See also"
At the end of the paragraph/page: Text-independent reference

Introduction
1.5 Conventions
Operating with the Local User Interface
14 Operating Manual, 06/2017, A5E31930478-05

Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05 15
General information
2
2.1
KC Safety note - Information for Korea only
Class A Equipment (Industrial Broadcasting & Communication Equipment)
This equipment is Industrial (Class A) electromagnetic wave suitability equipment and seller
or user should take notice of it, and this equipment is to be used in the places except for
home.
2.2
Safety instructions
WARNING
Laws and directives
The failure to observe directives and laws when connecting and installing increases the
danger of explosion and leakage due to improper handling. When connecting and installing,
observe the test certificates, stipulations and laws applicable in your country in order to
avoid danger.
These include, for example:
•IEC 60079-14 (international)
•National Electrical Code (NEC - NFPA 70) (USA)
•Canadian Electrical Code (CEC) (Canada)
•EN 60079-14 (formerly VDE 0165, T1) (EU)
•EN 61010
•Ordinance on Industrial Safety and Health (Germany)
WARNING
Device modifications
Danger to personnel, system and the environment can result from modifications and repairs
to the device, especially in hazardous areas.
•Only carry out modifications or repairs that are described in the instructions for the
device. Failure to observe this requirement cancels the manufacturer's warranty and the
product approvals.
See also
References (Page 281)

General information
2.3 Information on use
Operating with the Local User Interface
16 Operating Manual, 06/2017, A5E31930478-05
WARNING
Information and symbols on the device
•Observe the information and symbols on the device.
•Do not remove any information or symbols from the device.
•Always keep the information and symbols in a completely legible state.
2.3
Information on use
2.3.1
Prerequisites for safe use
In terms of safety, this device left the factory in perfect condition. In order to maintain this
status and to ensure safe operation of the device, observe these instructions and all the
information relevant to safety.
2.3.2
Security messages
Siemens provides automation and drive products with industrial security functions that
support the secure operation of plants or machines. They are an important component in a
holistic industrial security concept. With this in mind, our products undergo continuous
development. We therefore recommend that you keep yourself informed with respect to our
product updates. Detailed technical information can be found at:
http://support.automation.siemens.com (https://support.industry.siemens.com).
To ensure the secure operation of a plant or machine it is also necessary to take suitable
preventive action (e.g. cell protection concept) and to integrate the automation and drive
components into a state-of-the-art holistic industrial security concept for the entire plant or
machine. Products used from other manufacturers should also be taken into account here.
You will find further information under:
http://www.siemens.com/industrialsecurity (http://www.siemens.com/industrialsecurity).

General information
2.3 Information on use
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05 17
2.3.3
Communications
Note
Communication protocols
The devices described in this documentation are
able to communicate using Ethernet and
MODBUS
TCP. The protocols used are basically non-secure in the sense of IT security.
•
Make sure that only secure connections are used for communication.
•
Only use the device within appropriately secure networks.
Note
Illegal Ethernet connection
Illegal Ethernet connections to the analyzer device can bypass firewalls.
Make sure that the analyzer device is not connected to or can be connected to two separate
Ethernet networks.
2.3.4
Qualified personnel
Qualified personnel are individuals who are familiar with the installation, mounting,
commissioning, and operation of the product. These individuals have the following
qualifications:
●They are authorized, trained or instructed in operating and maintaining devices and
systems according to the safety regulations for electrical circuits, high pressures, and
aggressive as well as dangerous media.
●For explosion-proof devices: They are authorized, trained, or instructed in working on
electrical circuits for systems in hazardous areas.
●They are trained or instructed in maintenance and use of appropriate safety equipment
according to the safety regulations.
2.3.5
Automatic reset
All SIPROCESS GA700 devices feature internal monitoring. When this monitoring is
activated, the standard digital outputs switch after about 4 seconds for a period of approx. 60
seconds to "inactive", i.e. to a recognized safe operating mode. These times are valid for
devices manufactured as of 09/2017. You can find this information on the nameplate. It can
take up to 10 seconds for older devices to switch over, and up to 100 seconds to switch to
safe operating mode.

General information
2.3 Information on use
Operating with the Local User Interface
18 Operating Manual, 06/2017, A5E31930478-05
If you are using SIPROCESS GA700 devices in critical processes, observe the following
information:
●Monitor the limits externally via the control system.
●Read out the device status only via the digital outputs of the analyzer module.
●Use an available manual measuring range switchover instead of the autoranging.
●Only use the "Total" parameter with the "Off" setting for the measuring range switchover.
●If you use the "Correction of cross-interference" and "External pressure compensation"
functions, store suitable substitute values.
●Only access the measured value via an analog output.

Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05 19
Description
3
3.1
Overview
Distinction
The devices of the SIPROCESS GA700 product range are of modular design, and consist of
the basic device and at least one analyzer module. Certain analyzer and option modules can
be retrofitted.
Table 3- 1 Device/enclosure variants
Basic device (rack-mounted or wall enclosure)
Rack-mounted or wall-mounted device
Metal enclosure for wall mounting/for installation
in 19" rack, in each case with:
•Local user interface
•Processing module (PM)
•Power supply unit
•Preparation to accommodate analyzer and/or
option modules
General rule: Basic device (rack-mounted or wall
enclosure) with at least one analyzer module
Measuring principles/measuring tasks
The analyzer modules are matched with specific sample gas components and measuring
ranges. Various types of measuring methods are implemented:
Table 3- 2 Measuring principle and measuring task of the analyzer modules
Purpose
Analyzer modules 1)
OXYMAT 7
ULTRAMAT 7
CALOMAT 7
Measuring
principle
Paramagnetic alternating
pressure principle
Infrared push-pull chopped
radiation method
Difference in thermal con-
ductivity of gases
Measure-
ment task
Measurement of oxygen in
gas mixtures.
Measurement of the follow-
ing components in gas
mixtures:
CO, CO2, CH4, C2H4, SO2,
NO, N
2
O, NH
3
Application-dependent
measurement 2)
1)
Depending on the requirements profile, your device may optionally consist of other modules, for
example, an additional analyzer module and/or up to two additional option modules.
2) Particularly on H2.

Description
3.2 OXYMAT 7
Operating with the Local User Interface
20 Operating Manual, 06/2017, A5E31930478-05
See also
CALOMAT 7 measurement task (Page 28)
3.2
OXYMAT 7
3.2.1
Design
Note
Condensation in the analyzer module
Use a sample gas cooler that reduces the dew point of the sample gas to the extent that the
gas in the analyzer does not condense. The internal sample gas paths are not heated. The
sample chamber is warmed to 72 °C.
