1 Preface
1.1 Purpose of this document
This operating instructions decribe the wiring of SIPLUS CMS4000 ION, IFN, MCN11
and RPN IEEE1394.
1.2 Required basic knowledge
Basic knowledge of automation technology and condition monitoring equipment is nec-
essary.
This operating instructions contain a description of the components, which are valid at
the time of publishing the manual. We reserve the right, to enclose product information
with current information to new components and updated components.
1.3 Validity of this document
This document is valid for the Condition Monitoring System SIPLUS CMS1000.
1.4 Modification compared with the previous version
- None
Notice
You will find the version of the operating instructions in the number of the footer: A5E02298098B-01.
1.5 CE marking
According to EG cable must not be CE marked.
1.6 Standards
Notice
The specified concessions are only valid according to an authorized label on the product.
1.7 Position in information environment
In addition to this operating instructions you need the manual of the applied ION and IFN
hardware.
SIPLUS CMS4000 IFN AI, IFN VIB-A, ION PROFIBUS DP Spy T001, MCN11 and RPN
IEEE1394.

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 5
1.8 Directory
This operating instructions consist of chapters for guidance and of technical data.
They contain the following topics:
•Product overview (Chapter 2)
•Typical configurations (Chapter 3)
•Cable types (Chapter 4)
•Connecting the cable (Chapter 5)
•List of abbreviations with explanation of the general definitions of the used terms
(Chapter 6.2)
1.9 Recycling and disposal
For environmentally compatible recycling and disposal of your old device contact a
certified waste disposal for electronic.

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 6
2 Product Overview
2.1 What is SIPLUS CMS?
SIPLUS CMS is an industrial-suited Condition Monitoring System for technical and tech-
nological services in industrial plants. SIPLUS CMS is a modular, scalable analysis and
diagnosis system. It is optimized for reaction less measurement of analog, binary and
numerical data. SIPLUS CMS can be integrated in existing and new industrial plants.
SIPLUS CMS can be integrated into the TIA-Architecture.
Picture 1 Typical Configuration

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 7
2.2 What is an Interface Node ION or IFN?
Definition
With an ION or IFN binary, analog or vibration signals are measured and transfered via
bus system to an industry PC according to the EEE1394a Standard.
The application of an ION or IFN allows the recording/digitalization of voltage signals
(IFN AI, IFN VIB-A) or the sampling of bus signals (ION PROFIBUS DP Spy T001).
Example
Picture 2 Front view IFN VIB-A
2.3 What are Media Converter Node (MCN11) and Repeater Node (RPN
IEEE1394)?
Definition
MCN11 and RPN IEEE1394 transform the data on the IEEE1394-bus (firewire bus)
physical from one medium (electrical) into another medium (optical) and the other way
around. MCN and RPN are used if the required linking length is longer than 4.5 meter.
The RPN IEEE1394 is designed in protection category IP20, the MCN11 in protection
category IP67.

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 8
Picture 3 Front view MCN11

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 9
3 Typical Configurations
3.1 Tree topology
The IEEE1394a technology allows to create extended networks with up to 63 partici-
pants. The attendance of one branch must not be more than 16 devices.
The tree-topology allows the construction of a network system by connecting one bus
participant with two further ones.
Picture 4 Tree topology with IFN
3.2 Line topology
The line topology allows the construction of a network system by connecting one bus
participant with one other participant.
The maximum number of point-to-point connections from one bus participant to any oth-
er participant in the IEEE1394 bus is limited to 15 – which means that not more than 16
devices are allowed to be connected in series (line topology)
This is the most used topology since only in rare cases the number of devices in a mea-
suring system exceed 16 devices.
IFN/IFN-Cable
Interface Node (IFN)
Line 1
Line 2 Line 1.1
Line 1.2

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 10
Picture 5 Line topology with IFN
3.3 Connection with fibre optic cable
The MCN11 can be connected to any IEEE1394 – connection (LNK0/1/2) on the IFN.
In accordance to the minimum distance up to three MCN11 can operate at the same
time.
Picture 6 Configuration with fibre optic cable between two IFN
Interface Node (IFN)
LWL
IFN/MCN-Cable
IFN/MCN-Cable
Interface Node (IFN)
Media Converter
Node (MCN11)
Media Converter
Node (MCN11)
IFN/IFN-Cable
Interface Node (IFN)
IFN/IFN-Cable

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 11
Picture 7 Optical connection of a PC on a CMS4000 System
Interface Node (IFN)
IFN/MCN-Cable
Media Converter
Node (MCN11)
Multi-Port-Repeater
(RPN IEEE1394B T001/T002)
RPN/PC-Cable
PC / SIPLUS CMS Microbox
LWL

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 12
4 Cable Types
4.1 Overview
The following chart gives a survey about all cables and their usage combined with ION,
IFN, MCN und RPN:
Name Chapter Identifier
CABLE-IEEE1394A-66/46 4.2 2AA00
CABLE-IEEE1394A-8F 4.3 2AB20-1
CABLE-IEEE1394A-8M 4.4 2AB20-2
CABLE-Power 4.5 2AB30
IFN ADD 4.6 2AB50
CABLE-IO 4.7 2AB40
Picture 8 Cable overview
IFN
PCN
2AB30
2AB20-1
2AB50
IFN
2AB40 2AB40
ION
PCN
2AB30
2AA00
2AB40
2AB20-1
MCN11
PCN
2AB30
2AA00
IFN
2AB20-2
RPN
LWL

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 13
4.2 CABLE-IEEE1394A-66/46
Name: CABLE-IEEE1394A-66/46
Application: IEEE1394 coupling cable
PC-ION, PC-RPN, ION-ION, ION-RPN
Length: 30cm, 100cm, 200cm, 450cm
Order numbers: CABLE-IEEE1394A-66-0030 (30 cm) 6AT8000-2AA00-1AA3
CABLE-IEEE1394A-66-0100 (100 cm) 6AT8000-2AA00-1AB0
CABLE-IEEE1394A-66-0200 (200 cm) 6AT8000-2AA00-1AC0
CABLE-IEEE1394A-66-0450 (450 cm) 6AT8000-2AA00-1AE5
CABLE-IEEE1394A-46-0450 (450 cm) 6AT8000-2AA10-1AE5
Picture 9a CABLE-IEEE1394A-66 Picture 9b CABLE-IEEE1394A-46
This cable is used for IEEE1394 coupling of ION-ION, ION-PC, PC-RPN and ION-RPN.
The CABLE-IEEE1394A-46-0450 allows the conection of a notebook.
On ION and RPN the IEEE1394a interfaces (P1 / P2 / P3) are designed as 6-pin jacks.
Picture 9 IEEE1394a Interface
Notice
Only cables with maximum length of 4.5 m are allowed to be connected on an IEEE1394a interface.

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 14
4.3 CABLE-IEEE1394A-8F
Name: CABLE-IEEE1394A-8F
Application: IEEE1394 coupling cable
PC-IFN, ION-IFN, RPN-IFN
Length: 40cm, 200cm, 450cm
Order numbers: CABLE-IEEE1394A-8F-0040 (40 cm) 6AT8000-2AB20-1AB0
CABLE-IEEE1394A-8F-0200 (200 cm) 6AT8000-2AB20-1AC0
CABLE-IEEE1394A-8F-0450 (450 cm) 6AT8000-2AB20-1AE5
Picture 10 CABLE-IEEE1394A-8F
This cable is used for IEEE1394 coupling of PC-IFN, ION-IFN and RPN-IFN.
4.4 CABLE-IEEE1394A-8M
Name: CABLE-IEEE1394A-8M
Application: IEEE1394A coupling cable with power supply included
IFN-MCN11
Length: 30cm
Order numbers: CABLE-IEEE1394A-8M-0030 (30 cm) 6AT8000-2AB20-2AA2
Picture 11 CABLE-IEEE1394A-8M
This cable is used for IEEE1394 coupling of IFN-MCN11.

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 15
4.5 CABLE-Power
Name: CABLE-Power
Application: Power cable
IFN
Length: 135cm, 200cm, 500cm, 1000cm
Order numbers: CABLE-Power-135-0000 (135 cm) 6AT8000-2AB30-1AA1
CABLE-Power-200-0000 (200 cm) 6AT8000-2AB30-1AA2
CABLE-Power-500-0000 (500 cm) 6AT8000-2AB30-1AA5
CABLE-Power-1000-0000 (1000 cm) 6AT8000-2AB30-1AB0
Picture 12 CABLE-Power
This cable is used for energy supply of the IFN. To forward the power from the first IFN
to the following ones in a line topology IFN ADD must be applied, see. chapter 4.6.
Warning
The IFN device is built to operate with reliable low voltage. Therefore only reliable low voltage
according to IEC950/EN60950/VDE0805 must be connected to the supply connection.
The power adapter for feeding the IFN must fulfil NEC Class 2 (voltage range 18-32 V).
The IFN must not be connected to DC voltage higher than 32 V DC, or to AC voltage.

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 16
Chart 1: Pin assignment PWR
PIN Assignment Wire color View
1M24 (ground) brown
2 +24 V DC (18…32 V DC) white
3PD
(power down, ext. restart) blue
4 free black
5 free grey or
green/yellow
4.6 IFN ADD
A cable set consists of one power cable with Y-plug for straight power forwarding to a
neighbour IFN and one IEEE1394A coupling cable.
Name: IFN ADD
Application:: Power cable and IEEE1394A coupling cable
IFN-IFN
Length: 20cm, 100cm, 200cm, 450cm
Order numbers: IFN ADD0020 (20 cm) 6AT8000-2AB50-1AA2
IFN ADD0100 (100 cm) 6AT8000-2AB50-1AB0
IFN ADD0200 (200 cm) 6AT8000-2AB50-1AC0
IFN ADD0450 (450 cm) 6AT8000-2AB50-1AE5
Picture 13 IFN ADD CABLE-Power with Y-plug
Picture 14 IFN ADD CABLE IEEE1394A

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 17
Warning
The IFN ADD power cable with Y-plug is designed for max. current load of 4 A .
Maximum 16 IFNs are allowed to be connected in a line.
Notice
CABLE-Power-xxx-0000 (6AT8000-2AB30-1Axx) and CABLE-IEEE1394A-88-0020 (6AT8000-
2AB20-2AD2) must be applied to obtain protection class IP67.
IFN ADD power cable with Y-plug does NOT fulfil protection class IP67 !
Name: CABLE-IEEE1394A-88
Application: IEEE1394A coupling cable
IFN-IFN
Length: 20cm
Order numbers: CABLE-IEEE1394A-88-0020 (20 cm) 6AT8000-2AB20-2AD2
Picture 15 CABLE-IEEE1394A-88
Join the IFN ADD CABLE IEEE1394A and CABLE-IEEE1394A-88 bus connections to
the 8-pole flange sleeves M12 (LNK0 / LNK1/ LNK2) on the front of the device.
Notice
Only join cables of maximum 4.5m length to the IEEE1394 connections. We recommend the
usage of standard SIPLUS CMS cables.
When using self-made cable connections no warrenty is assumed..
Cahrt 2 Pin assignment IEEE1394
PIN Assignment View
1TBIAS *)
2Wire *)
3TPA- (Twisted-pair A)
4 TPA+ (Twisted-pair B)
5Masse
6TPB+ (Twisted-pair B)
7 TPB- (Twisted-pair A)
8Power supply *)
*) only relevant while coupling with MCN11

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 18
4.7 CABLE-IO
Name: CABLE-IO
Application: Input/Output-cable
IFN-sensor
Length:: 200cm, 500cm, 1000cm
Order numbers: CABLE-IO-200-0000 (200 cm) 6AT8000-2AB40-1AA2
CABLE-IO-500-0000 (500 cm) 6AT8000-2AB40-1AA5
CABLE-IO-1000-0000 (1000 cm) 6AT8000-2AB40-1AB0
Picture 16 CABLE-IO
This cable allows connecting the sensor technology to the IFN. The cable can be used
for IFNA AI and IFN VIB-A.
The following chart shows the assignment of the analog inputs (CH1-CH6) using an
IFN AI.
Chart 3 Pin assignment analog input (CH1-CH6)
PIN Assignment Wire color View
1GND (ground) brown
2 free white
3signal blue
4 free black
5 free grey or
green/yellow

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 19
The following chart shows the assignment of the IEPE inputs (CH1 - CH6) using an
IFN VIB-A.
Chart 4 Pin assignment IEPE sensor input (CH1-CH6)
PIN Assignment Wire color View
1GND (ground) brown
2 free white
3signal blue
4 free black
5 free grey or
green/yellow
The following chart shows the assignment of the IFN VIB-A CH6 input used as analog
input.
Chart 5 Pin assignment CH6 as analog input
PIN Assignment Wire color View
1GND (ground) brown
2 +/- 24 V signal white
3free blue
4 free black
5 Free grey or
green/yellow
Notice
Only use the factory assembled shielded CABLE-IO! There shield on IFN AI and VIB-A is electronical con-
nected to the plug housing!

Operating Instructions SIPLUS CMS4000 Wiring
SIPLUS CMS4000 Cable
Operating Instructions, 06/2017, A5E02298098B-01 20
4.8 Accessories
Mounting brackets for wall mounting are available for IFN - IFN Mounting Set (6AT8000-
2BB00-0XB0) and for MCN11 - MCN Mounting Set (MLFB 6AT8000-2BB00-0XC0).
Unused jacks can be closed by a capping set, IFN Coping Set (MLFB 6AT8000-2BB00-
0XA0).
Picture 17 Mounting Set
