Siemens SIMATIC HMI TP700 Comfort User manual

TP700 Comfort Outdoor, TP1500
Comfort Outdoor
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SIMATIC HMI
HMI devices
TP700 Comfort Outdoor,
TP1500 Comfort Outdoor
Compact Operating Instructions
03/2016
A5E35956909
-AB
Preface
Overview
1
Safety instructions
2
Mounting and connecting the
HMI device
3
Configuring the device
4
Commissioning a project
5
Maintenance and care
6
Technical information
7
Technical Support
A

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E35956909-AB
Ⓟ
03/2016 Subject to change
Copyright © Siemens AG 2016.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

TP700 Comfort Outdoor, TP1500 Comfort Outdoor
Compact Operating Instructions, 03/2016, A5E35956909-AB 3
Preface
Scope
These compact operating instructions apply to the following HMI devices in conjunction with
the WinCC software package:
●TP700 Comfort Outdoor, article number 6AV2124-0GC13-0AX_
●TP1500 Comfort Outdoor, article number 6AV2124-0QC13-0AX_
"_" stands for the variant key of the article number.
These compact operating instructions describe the technical differences of the Outdoor
devices to the corresponding standard devices.
The information in these compact operating instructions take precedence in terms of their
binding character over the statements in the following underlying operating instructions, the
release notes and the online help.
Operating instructions on the Comfort Panels
(http://support.automation.siemens.com/WW/view/en/49313233)
Note
This document belongs to the device and will also be required for repeat commissioning.
Keep all supplied and supplem
entary documentation for the entire service life of the device.
Provide all associated documents to any future owner of the device.
Style conventions
Style Convention
Scope
"Add screen" •Terminology that appears in the user interface, for example,
dialog names, tabs, buttons, menu commands
•Required input, for example, limits, tag values.
•Path information
"File > Edit" Operational sequences, for example, menu commands, shortcut
menu commands.
<F1>, <Alt+P>
Keyboard operation
Please observe notes labeled as follows:
Note
A note contains important information about the product described in the manual and its use,
or a specific section of the manual to which you should pay particular attention.

Preface
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
4Compact Operating Instructions, 03/2016, A5E35956909-AB
Naming conventions
Term
Applies to
System •System
•Machining center
•One or more machines
HMI device
Device
•TP700 Comfort Outdoor
•TP1500 Comfort Outdoor
WinCC
WinCC V13 SP1 (TIA Portal)
Figures
This document contains figures of the devices described. The figures can deviate from the
particularities of the delivered device.

TP700 Comfort Outdoor, TP1500 Comfort Outdoor
Compact Operating Instructions, 03/2016, A5E35956909-AB 5
Table of contents
Preface ................................................................................................................................................... 3
1 Overview................................................................................................................................................. 7
1.1 Product description ...................................................................................................................7
1.2 Software requirements..............................................................................................................8
1.3 Scope of delivery ......................................................................................................................9
1.4 Configuration of the devices ...................................................................................................10
1.4.1 Device views ...........................................................................................................................10
1.4.2 Interfaces ................................................................................................................................11
2 Safety instructions................................................................................................................................. 12
2.1 General safety instructions .....................................................................................................12
2.2 Notes about usage..................................................................................................................13
3 Mounting and connecting the HMI device .............................................................................................. 14
3.1 Preparing for installation .........................................................................................................14
3.1.1 Checking the package contents..............................................................................................14
3.1.2 Checking the operating conditions..........................................................................................15
3.1.3 Selecting a mounting position.................................................................................................15
3.1.4 Checking clearances...............................................................................................................17
3.1.5 Preparing the mounting cutout................................................................................................17
3.2 Mounting the device................................................................................................................19
3.3 Connecting the device ............................................................................................................20
4 Configuring the device .......................................................................................................................... 21
4.1 Overview .................................................................................................................................21
4.2 Changing the brightness settings ...........................................................................................21
5 Commissioning a project ....................................................................................................................... 23
5.1 Overview .................................................................................................................................23
5.2 Using existing projects ............................................................................................................23
6 Maintenance and care........................................................................................................................... 24
6.1 Cleaning the device ................................................................................................................24
6.2 Repair, spare parts, recycling and disposal............................................................................24

Table of contents
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
6Compact Operating Instructions, 03/2016, A5E35956909-AB
7 Technical information............................................................................................................................ 25
7.1 Certificates and approvals ..................................................................................................... 25
7.2 Electromagnetic compatibility ................................................................................................ 25
7.2.1 Emitted interference............................................................................................................... 25
7.2.2 Immunity to interferences....................................................................................................... 25
7.3 Mechanical ambient conditions.............................................................................................. 26
7.3.1 Storage conditions ................................................................................................................. 26
7.3.2 Operating Conditions ............................................................................................................. 26
7.4 Climatic ambient conditions ................................................................................................... 26
7.4.1 Long-term storage.................................................................................................................. 26
7.4.2 Transport and short-term storage .......................................................................................... 27
7.4.3 Operating Conditions ............................................................................................................. 27
7.5 Protection classes.................................................................................................................. 28
7.5.1 Insulation test ......................................................................................................................... 28
7.5.2 Protection against foreign objects and water......................................................................... 28
7.6 Dimension drawings............................................................................................................... 29
7.6.1 Dimension drawings of the TP700 Comfort Outdoor............................................................. 29
7.6.2 Dimension drawings of the TP1500 Comfort Outdoor ........................................................... 30
7.7 Specifications ......................................................................................................................... 31
7.8 Description of the ports .......................................................................................................... 32
7.9 Scope of functions with WinCC.............................................................................................. 33
A Technical Support................................................................................................................................. 36
A.1 Service and support ............................................................................................................... 36
A.2 Troubleshooting and system alarms...................................................................................... 36
Index .................................................................................................................................................... 37

TP700 Comfort Outdoor, TP1500 Comfort Outdoor
Compact Operating Instructions, 03/2016, A5E35956909-AB 7
Overview
1
1.1
Product description
SIMATIC Comfort Outdoor devices with glass touch screen and powder-coated, UV-resistant
aluminum front are designed for use in indoor and outdoor areas, for example, in the fields of
Oil&Gas, Marine or Refrigeration Technology.
All devices offer the same excellent functionality and are configured exclusively with the
innovative HMI software, WinCC. The engineering software is integrated in the engineering
framework, "Totally Integrated Automation Portal".

Overview
1.2 Software requirements
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
8Compact Operating Instructions, 03/2016, A5E35956909-AB
Features
Front
•External dimensions of the front and mounting cutout correspond to the
standard product
•Durable powder coating
•High UV resistance
•GFG (Glass-Film-Glass) touch screens, analog resistive
•Manual or automatic brightness control with brightness sensor
Display
•High-resolution TFT display in widescreen format with 16 million colors
•Suitable for use in daylight
•Anti-reflective and bonded for glare-free reading
Touch screen
•Resistive single touch screen
•Suitable for operation with gloves, pen and fingers
Interfaces
•2 PROFINET interfaces
•1 PROFIBUS interface
•USB 2.0 ports:
–2 x USB host interface (type A)
–1 x USB device interface (type mini B)
Mechanical differences to the standard product
Device depth
The Comfort Outdoor devices are deeper than the corresponding Comfort HMI
device.
Read the information in the following sections:
•Preparing the mounting cutout (Page 17)
•Dimension drawings (Page 29)
Slots for SD
memory cards
The protection mechanism of the SD memory card for the Comfort Outdoor
devices is mechanically differently than that of the corresponding Comfort HMI
device. The safety tab is not required with the Comfort Outdoor devices.
1.2
Software requirements
You require the software WinCC V13 SP1 (TIA Portal) Update 6 with the Hardware Support
Package "HSP0149 HMI TP700_1500 Comfort Outdoor" or later versions. You can find the
software under Technical Support on the Internet.

Overview
1.3 Scope of delivery
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
Compact Operating Instructions, 03/2016, A5E35956909-AB 9
1.3
Scope of delivery
The following components are included in the scope of delivery of the HMI device.
Name
Figure
Quantity
HMI device 1
Installation instructions
(Quick Install Guide)
1
Mounting clips Aluminum mounting clip 8 TP700 Comfort Outdoor
Steel mounting clip 12 TP1500 Comfort Outdoor
Strain relief Example: Strain relief 1 TP700 Comfort Outdoor
Power supply terminal Connector, female, 2-pin, type 1 1
Some components in the scope of delivery are also available as accessories, see
"Accessories" section in the Comfort Panels operating instructions or directly in the Industry
Mall (https://mall.industry.siemens.com).

Overview
1.4 Configuration of the devices
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
10 Compact Operating Instructions, 03/2016, A5E35956909-AB
1.4
Configuration of the devices
1.4.1
Device views
This section describes the basic design of the device using the example of the
TP700 Comfort Outdoor.
Front view and side view
①
Light sensor
②
Aluminum front, powder coated
③
Glass touch screen / display
④
Cutouts for attaching the mounting clamps
Rear view
①
Rating plate
②
Slot for data memory card
③
Slot for system memory card
④
Interface inscription

Overview
1.4 Configuration of the devices
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
Compact Operating Instructions, 03/2016, A5E35956909-AB 11
1.4.2
Interfaces
Position of the interfaces
The figure below shows the interfaces of the HMI devices.
①
X80 power supply connector
⑤
X1 PROFINET (LAN), 10/100 Mb
②
Connection for equipotential bonding (ground)
⑥
X90 Audio Line IN / OUT
③
X2 PROFIBUS (Sub-D RS422/485)
⑦
X60 USB type Mini B
④
X61 / X62 USB type A
Additional information
Use the X1 or X60 interface to connect a configuration PC. Use the X61 / X62 interfaces to
connect peripheral devices such as a printer or keyboard. Use the X90 interface to connect a
loudspeaker.
You can fasten the USB and PROFINET connecting cables to the rear panel of the
HMI device with cable ties.
Secure the cables with a separate strain relief for the TP700 Comfort Outdoor. Install the
strain relief on the HMI device.

TP700 Comfort Outdoor, TP1500 Comfort Outdoor
12 Compact Operating Instructions, 03/2016, A5E35956909-AB
Safety instructions
2
2.1
General safety instructions
The general safety instructions in the "Comfort Panel" operating instructions apply.
Also note the following for Comfort outdoor devices:
WARNING
Unintended functions may be triggered with icing
If the operating temperature is below 2 °C, icing may occur on the front of the device. Icing
may trigger unintended functions in some circumstances.
To avoid triggering unintended functions, you can take the following measures, for
example:
•Install an additional enabling switch in your plant for operator actions that initiate a
dangerous operating state.
•Assign a password to operator actions or inputs that initiate a dangerous operating
state.

Safety instructions
2.2 Notes about usage
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
Compact Operating Instructions, 03/2016, A5E35956909-AB 13
2.2
Notes about usage
Industrial applications
The HMI device is designed for outdoor areas in industrial applications. It conforms to the
following standards:
●Requirements of the emission standard for industrial environments,
EN 61000-6-4: 2007 + A1:2011
●ESD immunity requirements to DIN EN 61000-6-2:2005
Use in residential areas
Note
The HMI device is not intended for use in residential areas. Operation of an HMI device in
residential areas can have a negative influence on radio/TV reception.
If the HMI device is used in a residential area, you must take measures to achieve
Limit Class B conforming to EN 55011 for RF interference.
Individual acceptance is required.
Use with additional measures
The HMI device should not be used at the following locations unless additional measures are
taken:
●In locations with a high degree of ionizing radiation
●In locations with severe operating conditions, for example, due to:
–Corrosive vapors, gases, oils or chemicals
–Electrical or magnetic fields of high intensity
●In systems that require special monitoring, for example, in:
–Elevators
–Systems in especially hazardous rooms

TP700 Comfort Outdoor, TP1500 Comfort Outdoor
14 Compact Operating Instructions, 03/2016, A5E35956909-AB
Mounting and connecting the HMI device
3
3.1
Preparing for installation
3.1.1
Checking the package contents
Check the package content for visible signs of transport damage and for completeness.
Note
Damaged parts
A damaged part will cause the HMI device to malfunction.
Do not install parts damaged during shipment. In the case of
damaged parts, contact your
Siemens representative.
Check the scope of supply of the HMI device (see Scope of delivery (Page 9)).
Additional documents may be included in the delivery.
The documentation is part of the HMI device and is required for subsequent commissioning.
Keep all enclosed documentation for the entire service life of the HMI device. You must pass
along the enclosed documentation to any subsequent owner or user of the HMI device.
Make sure that every supplement to the documentation that you receive is stored together
with the operating instructions.

Mounting and connecting the HMI device
3.1 Preparing for installation
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
Compact Operating Instructions, 03/2016, A5E35956909-AB 15
3.1.2
Checking the operating conditions
Note the following aspects before installing the HMI device:
1. Familiarize yourself with the technical specifications for operating the HMI device. You
can find this information in the section "Technical information (Page 25)".
2. Read the information about local use of the HMI device, see section
"Notes about usage (Page 13)".
3.1.3
Selecting a mounting position
The device is suitable for installation in:
●Mounting cabinets
●Control cabinets
●Switchboards
●Consoles
In the following, all of these mounting options are referred to by the general term "cabinet".
The device is self-ventilated and approved for inclined mounting at angles up to +/-35° from
the vertical in stationary cabinets.
NOTICE
Damage due to overheating
Inclined installation reduces the convection by the device and therefore the maximum
permitted ambient temperature for operation.
If there is sufficient forced ventilation, the device can also be operated in the inclined
mounting position up to the maximum permitted ambient temperature for vertical
installation. The device may otherwise be damaged and its certifications and warranty will
be rendered null and void.
The ambient temperature ranges listed in this section apply to the temperature inside the
cabinet.

Mounting and connecting the HMI device
3.1 Preparing for installation
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
16 Compact Operating Instructions, 03/2016, A5E35956909-AB
Mounting position
Select one of the approved mounting positions for your device. The approved mounting
positions are described in the following sections.
Mounting in horizontal format
Ambient temperature when mounted in horizontal format:
●Vertical mounting (0° inclined): Maximum +60 °C
●Inclined mounting (inclined up to 35°): Maximum +50 °C
Mounting in vertical format
Ambient temperature when mounted in vertical format:
●Vertical mounting (0° inclined): Maximum +50 °C
●Inclined mounting (inclined up to 35°): Maximum +45 °C
See also
Operating Conditions (Page 27)

Mounting and connecting the HMI device
3.1 Preparing for installation
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
Compact Operating Instructions, 03/2016, A5E35956909-AB 17
3.1.4
Checking clearances
The following clearances are required around the HMI device to ensure sufficient self-
ventilation:
●At least 15 mm to both the right and left of the mounting cutout (in x direction) to allow for
insertion of the mounting clips during installation
●At least 50 mm above and 50 mm below the mounting cutout (in the y direction) for
ventilation
●At least 10 mm behind the rear panel of the HMI device (in the z direction)
The following figure shows the clearances during mounting of the HMI devices in horizontal
and vertical formats:
Note
Ensure that the maximum ambient temperature is not exceeded when mounting the device
in a cabinet and especially in a closed enclosure.
3.1.5
Preparing the mounting cutout
Note
Stability of the mounting cutout
The material in the area of the mounting
cutout must provide sufficient strength to guarantee
lasting and safe mounting of the HMI device.
To achieve the degrees of protection described below, it must be ensured that deformation
of the material cannot occur due to the force of the mounting clips
or operation of the device.

Mounting and connecting the HMI device
3.1 Preparing for installation
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
18 Compact Operating Instructions, 03/2016, A5E35956909-AB
Degrees of protection
The degrees of protection of the HMI device can only be guaranteed if the following
requirements are met:
●Material thickness at the mounting cutout for a protection rating of IP66 or Front face
only Type 4X/Type 12 (Indoor/Outdoor): 2 mm to 6 mm
●Permitted deviation from plane at the mounting cutout: ≤ 0.5 mm
This condition must be met for the mounted HMI device.
●Permitted surface roughness in the area of the mounting seal: ≤120 µm (Rz120)
Compatibility of the mounting cutout to other HMI devices
The mounting cutouts of the following HMI devices are compatible with the mounting cutouts
of the following predecessor devices:
HMI device
Mounting cutout compatible with
TP700 Comfort Outdoor
TP700 Comfort, TP 177B 6", MP 177 6", TP 277 6"
TP1500 Comfort Outdoor TP1500 Comfort
Please note that although the dimensions for the mounting cutout are the same, the device
depth and/or the enclosure front dimensions may differ from the respective dimensions of the
predecessor devices.
Dimensions of the mounting cutout
Width and height should be reversed accordingly when mounting in vertical format.

Mounting and connecting the HMI device
3.2 Mounting the device
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
Compact Operating Instructions, 03/2016, A5E35956909-AB 19
Mounting depth
The mounting depth of the devices is:
HMI device
Mounting depth
TP700 Comfort Outdoor
67 mm
TP1500 Comfort Outdoor 77 mm
3.2
Mounting the device
Positions of the mounting clips
To achieve the degree of protection for the HMI device, the positions for the mounting clips
shown below must be adhered to.
The positions of the mounting clips are marked by stamps on the cutouts. Fit the mounting
clips in all the stamped cutouts.
The following table shows the type, number, and position of the mounting clips needed for
the respective HMI devices.
HMI device
Mounting clips
Type
Number
Position on the HMI device
TP700 Comfort Outdoor Aluminum
mounting clip
8
TP1500 Comfort Outdoor Steel
mounting clip
12
Requirement
●All packaging components and protective films were removed from the HMI device.
●To install the HMI device, you need the mounting clips from the accessories kit.
●The mounting seal must be installed on the HMI device.

Mounting and connecting the HMI device
3.3 Connecting the device
TP700 Comfort Outdoor, TP1500 Comfort Outdoor
20 Compact Operating Instructions, 03/2016, A5E35956909-AB
Procedure
Note
Risk of guaranteed degree of protection not being met
If the mounting seal is
damaged, the degree of protection is not guaranteed. Replace the
device in this case.
Note
Installation of the HMI device
Always mount the HMI device according to the instructions in this manual.
Mounting clips for TP700 Comfort Outdoor:
Mounting clips for TP1500 Comfort Outdoor:
Proceed as follows:
1. Insert the HMI device into the mounting cutout from the front.
2. Insert the mounting clamp into the cutout provided on the HMI device.
3. Tighten the mounting clamp with the setscrew.
Note
Adhere to the permitted torque when tightening the setscrew of the mounting clamp:
0.5
Nm
4. Repeat steps 2 and 3 for all mounting clips.
5. Check the fit of the device in the mounting cutout.
3.3
Connecting the device
The specifications in "Comfort Panels" operating instructions apply.
The X3 interface "PROFINET (LAN) 10/100/1000 Mbit" is not featured on the
TP700 Comfort Outdoor and TP1500 Comfort Outdoor devices.
