SIMATIC S5
3964(R) Driver
1 System Configuration....................................................................................................... 3
2 External Device Selection ................................................................................................ 7
3 Communication Settings .................................................................................................. 8
4 Setup Items ....................................................................................................................11
5 Cable Diagram ............................................................................................................... 15
6 Supported Device Addresses......................................................................................... 17
7 Device Code and Address Code.................................................................................... 18
8 Error Messages.............................................................................................................. 19

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 2
Introduction
This manual describes how to connect the Display and the External Device (target PLC).
In this manual, the connection procedure is described in the sections identified below:
1System Configuration
This section lists the types of External
Devices and SIO that you can connect.
)"1 System Configuration" (page 3)
2External Device Selection
Select a model (series) of the External
Device and its connection method.
)"2 External Device Selection" (page 7)
3Communication Settings
This section shows setting examples for
communicating between the Display and
the External Device.
)"3 Communication Settings" (page 8)
4Setup Items
This section describes communication
setup items on the Display.
Set the Display’s communication settings
in GP-Pro EX or in offline mode.
)"4 Setup Items" (page 11)
5Cable Diagrams
This section shows cables and adapters
for connecting the Display and the
External Device.
)"5 Cable Diagram" (page 15)
Operation

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 3
1 System Configuration
The following section shows system configurations for connecting the Siemens AG External Device and the
Display.
Connection Configuration
• 1:1 Connection
Series CPU Link I/F SIO Type Setting
Example
Cable
Diagram
SIMATIC
S5 Series
90U
95U
100U
CP521 SI RS-232C
Setting
Example 1
(page 8)
Cable
Diagram 1
(page 15)
115U
135U
155U
CP524
CP525 RS-232C
115U(CPU 944)
135U/155U(CPU 928B) SI2 port on CPU unit RS-232C
• Set the execution time of the logic functions in the Display to “100 ms” or less. If the longer time is
set, an error may occur in the communication with the external device.
Display External Device

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 4
IPC COM Port
When connecting IPC with an External Device, the COM port used depends on the series and SIO type. Please
refer to the IPC manual for details.
Usable port
Series
Usable Port
RS-232C RS-422/485(4 wire) RS-422/485(2 wire)
PS-2000B COM1*1 , COM2,
COM3*1, COM4
*1 The RI/5V can be switched. Use the IPC’s switch to change if necessary.
--
PS-3450A, PS-3451A,
PS3000-BA, PS3001-BD COM1, COM2*1*2 COM2*1*2 COM2*1*2
PS-3650A (T41 model),
PS-3651A (T41 model) COM1*1 --
PS-3650A (T42 model),
PS-3651A (T42 model) COM1*1*2, COM2 COM1*1*2 COM1*1*2
PS-3700A (Pentium®4-M)
PS-3710A
COM1*1, COM2*1,
COM3*2 , COM4
*2 Set up the SIO type with the DIP Switch. Please set up as follows according to SIO type to be used.
COM3*2 COM3*2
PS-3711A COM1*1, COM2*2 COM2*2 COM2*2
PS4000*3
*3 When making communication between an External Device and COM port on the Expansion slot,
only RS-232C is supported. However, ER (DTR/CTS) control cannot be executed because of the
specification of COM port.
For connection with External Device, use user-created cables and disable Pin Nos. 1, 4, 6 and 9.
Please refer to the IPC manual for details of pin layout.
COM1, COM2 - -
PL3000 COM1*1*2, COM2*1,
COM3, COM4 COM1*1*2 COM1*1*2
PE-4000B Atom N270 COM1, COM2 - -
PE-4000B Atom N2600 COM1, COM2 COM3*4 , COM4*4,
COM5*4, COM6*4
*4 Set up the SIO type with the BIOS. Please refer to the IPC manual for details of BIOS.
COM3*4, COM4*4,
COM5*4, COM6*4
PS5000 (Slim Panel Type
Core i3 Model) *5 *6 COM1, COM2*4 COM2*4 COM2*4
PS5000 (Slim Panel Type
Atom Model)
*5 *6
COM1, COM2*7 COM2*7 COM2*7
PS5000 (Enclosed Panel
Type)*8 COM1 - -
PS5000 (Modular Type
PFXPU/PFXPP)*5 *6
PS5000 (Modular Type
PFXPL2B5-6)
COM1*7 COM1*7 COM1*7
PS5000 (Modular Type
PFXPL2B1-4) COM1, COM2*7 COM2*7 COM2*7

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 5
DIP Switch settings (PL3000 / PS3000 Series)
RS-232C
*5 When setting up communication between an External Device and the RS-232C/422/485 interface
module, use the IPC (RS-232C) or PS5000 (RS-422/485) cable diagrams. However, when using
PFXZPBMPR42P2 in a RS-422/485 (4-wire) configuration with no flow control, connect 7.RTS+
and 8.CTS+, and connect 6.RTS- and 9.CTS-.
When using RS-422/485 communication with External Devices, you may need to reduce the
transmission speed and increase the TX Wait time.
*6 To use RS-422/485 communication on the RS-232C/422/485 interface module, the DIP Switch
setting is required. Please refer to "Knowledge Base" (FAQs) on the support site. (http://www.pro-
face.com/trans/en/manual/1001.html)
*7 Set up the SIO type with the DIP Switch. Please refer to the IPC manual for details of DIP Switch.
The BOX Atom has not a switch to set the RS-232C, RS-422/485 mode. Use the BIOS for the
setting.
*8 For the connection with the External Device, on the user-created cable read as if the connector on
the Display-side is a M12 A-coding 8 pin socket. The pin assignment is the same as described in
the cable diagram. For the M12 A-coding connector, use PFXZPSCNM122.
DIP Switch Setting Description
1OFF
*1
*1 When using PS-3450A, PS-3451A, PS3000-BA and PS3001-BD, turn ON the set value.
Reserved (always OFF)
2OFF
SIO type: RS-232C
3OFF
4 OFF Output mode of SD (TXD) data: Always output
5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None
6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None
7 OFF Short-circuit of SDA (TXA) and RDA (RXA): Not available
8 OFF Short-circuit of SDB (TXB) and RDB (RXB): Not available
9OFF
RS (RTS) Auto control mode: Disabled
10 OFF
Settings FAQ ID
PFXZPBMPR42P2, RS422/485 change method FA263858
PFXZPBMPR42P2 termination resistor setting FA263974
PFXZPBMPR44P2, RS422/485 change method FA264087
PFXZPBMPR44P2 termination resistor setting FA264088

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 6
RS-422/485 (4 wire)
RS-422/485 (2 wire)
DIP Switch Setting Description
1 OFF Reserved (always OFF)
2ON
SIO type: RS-422/485
3ON
4 OFF Output mode of SD (TXD) data: Always output
5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None
6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None
7 OFF Short-circuit of SDA (TXA) and RDA (RXA): Not available
8 OFF Short-circuit of SDB (TXB) and RDB (RXB): Not available
9OFF
RS (RTS) Auto control mode: Disabled
10 OFF
DIP Switch Setting Description
1 OFF Reserved (always OFF)
2ON
SIO type: RS-422/485
3ON
4 OFF Output mode of SD (TXD) data: Always output
5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None
6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None
7 ON Short-circuit of SDA (TXA) and RDA (RXA): Available
8 ON Short-circuit of SDB (TXB) and RDB (RXB): Available
9ON
RS (RTS) Auto control mode: Enabled
10 ON

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 7
2 External Device Selection
Select the External Device to be connected to the Display.
Setup Items Setup Description
Number of Devices/
PLCs Enter an integer from 1 to 4 to define the number of Devices/PLCs to connect to the display.
Manufacturer Select the manufacturer of the External Device to connect. Select "Siemens AG".
Series
Select the External Device model (series) and the connection method. Select "SIMATIC S5
3964(R)".
In System configuration, make sure the External Device you are connecting is supported by
"SIMATIC S5 3964(R)".
)"1 System Configuration" (page 3)
Port Select the Display port to connect to the External Device.
Use System Area
Check this option to synchronize the system data area of the Display and the device (memory)
of the External Device. When synchronized, you can use the External Device’s ladder
program to switch the display or display the window on the Display.
Cf. GP-Pro EX Reference Manual "LS Area (Direct Access Method Area)"
This feature can also be set in GP-Pro EX or in the Display's offline mode.
Cf. GP-Pro EX Reference Manual "System Settings [Display Unit] - [System Area]
Settings Guide"
Cf. Maintenance/Troubleshooting Guide "Main Unit - System Area Settings"

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 8
3 Communication Settings
This section provides examples of communication settings recommended by Pro-face for the Display and the
External Device.
3.1 Setting Example 1
GP-Pro EX Settings
Communication Settings
To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 9
External Device Settings
Use the program controller (SIMATIC PG615) to configure communication settings for the External Device.
Refer to your External Device manual for details.
1Set the RUN/STOP switch on the CPU unit to STOP.
2Turn the program controller power ON to check that it is configured as shown below.
3Define the BLOCK OB.
Press the ENTER key to move to the INIT.STATE menu.
4Select the INPUT menu.
5Select the INPUT PC menu.
6Select the DX.
7Press key 2.
8Press the ENTER key to display [KH•••KC].
9Press key 1 to display the first address [0000:KH=].
10 Set each address as shown below.
To move the address, press the down key.
11 After all addresses are set, press the ENTER key to display [OVERWRITE?].
12 Press the ENTER key to move to the INIT.STATE menu.
13 Define the BLOCK DB.
Press key 1 to move to the INPUT menu.
14 Select the INPUT PC menu.
15 Select the DB.
16 Press key 9.
17 Press the ENTER key to display [KH•••KC].
Setup Items Setting Value
ON-LINE YES
SYSTEM OP YES
WORD ADDR YES
• If there are any items set differently from the above settings, set the cursor to the item using
the up key or the down key and press key 1.
Address Setting Value Address Setting Value
0000 4D41 0008 0000
0001 534B 0009 0000
0002 5832 0010 0000
0003 0020 0011 0000
0004 4409 0012 0000
0005 0000 0013 0000
0006 0000 0014 4D00
0007 0000 0015 0020

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 10
18 Press key 1 to display the first address [0000:KH=].
19 Set each address as shown below.
To move the address, press the down key.
20 After all addresses are set, press the ENTER key to display [OVERWRITE?].
21 Press the ENTER key to move to the INIT.STATE menu.
22 Once the communication settings are complete, set the RUN/STOP switch on the CPU to RUN.
Address Setting Value Address Setting Value
0000 0009 0006 0000
0001 0002 0007 0000
0002 0008 0008 0000
0003 0001 0009 0000
0004 0000 0010 0000
0005 0002
• If input was unsuccessful, press the CE key to clear, or press the BRK key to return to the
original menu.
• If the RUN/STOP switch on the CPU is not set to RUN, communication is not executed.

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 11
4 Setup Items
Set up the Display’s communication settings in GP-Pro EX or in the Display’s offline mode.
The setting of each parameter must match that of the External Device.
)"3 Communication Settings" (page 8)
4.1 Setup Items in GP-Pro EX
Communication Settings
To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].
Setup Items Setup Description
SIO Type
Select the SIO type to communicate with the External Device.
In the communication settings, set [SIO Type] correctly according to the serial
interface specifications of the Display.
If you select an SIO type that the serial interface does not support, proper
operation cannot be guaranteed.
Refer to your Display manual for details on the serial interface specifications.
Speed Select the communication speed between the External Device and the Display.
Data Length Display the data length.
Parity Select how to check parity.
Stop Bit Select the stop bit length.
continued on next page

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 12
Flow Control Select the communication control method to prevent transmission and reception data
overflow.
Timeout Enter the time (seconds) for which the Display waits for the response from the External
Device, from "1 to 127".
Retry In case of no response from the External Device, use an integer from 0 to 255 to enter how
many times the Display retransmits the command.
Wait To Send Enter the standby time (milliseconds) from when the Display receives packets until it
transmits the next command, from "0 to 255".
RI/VCC
You can switch RI/VCC of the 9th pin when you select RS-232C for SIO type.
When connecting with the IPC, change RI/5V with the IPC changeover switch. Please refer
to the IPC manual for more details.
• Refer to the GP-Pro EX Reference Manual for Indirect Device.
Cf. GP-Pro EX Reference Manual "Changing the Device/PLC at Runtime (Indirect
Device)"
Setup Items Setup Description

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 13
4.2 Setup Items in Offline Mode
Communication Settings
To display the setting screen, touch [Device/PLC Settings] from [Peripheral Equipment Settings] in offline mode.
Touch the External Device you want to set from the displayed list.
• Refer to the Maintenance/Troubleshooting guide for information on how to enter offline mode
or about the operation.
Cf. Maintenance/Troubleshooting Guide "Offline Mode"
• The number of the setup items to be displayed for 1 page in the offline mode depends on the
Display in use. Please refer to the Reference manual for details.
Setup Items Setup Description
SIO Type
Select the SIO type to communicate with the External Device.
In the communication settings, set [SIO Type] correctly according to the serial
interface specifications of the Display.
If you select an SIO type that the serial interface does not support, proper
operation cannot be guaranteed.
Refer to your Display manual for details on the serial interface specifications.
Speed Select the communication speed between the External Device and the Display.
Data Length Display the data length.
Parity Select how to check parity.
Stop Bit Select the stop bit length.
Flow Control Select a communication control method to prevent transmission and reception data
overflow.
continued on next page

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 14
Option
To display the setting screen, touch [Device/PLC Settings] from [Peripheral Settings]. Touch the External Device
you want to set from the displayed list, and touch [Option].
Timeout (s) Enter the time (seconds) for which the Display waits for the response from the External
Device, from "1 to 127"
Retry In case of no response from the External Device, use an integer from 0 to 255 to enter how
many times the Display retransmits the command.
Wait To Send (ms) Enter the standby time (milliseconds) from when the Display receives packets until it
transmits the next command, from "0 to 255".
Setup Items Setup Description
RI/VCC
You can switch RI/VCC of the 9th pin when you select RS232C for SIO type.
When connecting with the IPC, change RI/5V with the IPC changeover switch. Please refer
to the IPC manual for more details.
• GP-4100 series, GP-4*01TM, GP-Rear Module, LT-4*01TM and LT-Rear Module do not
have the [Option] setting in the offline mode.
Setup Items Setup Description

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 15
5 Cable Diagram
The following cable diagram may be different from the cable diagram recommended by Siemens AG. Please be
assured there is no operational problem in applying the cable diagram shown in this manual.
• Please ground the FG pin of the External Device body. Use a grounding resistance of 100Ω2mm2or thicker
wire, or your country's applicable standard. Refer to your External Device manual for more details.
• The SG and FG are connected inside the Display. When connecting the External Device to the SG, design
your system to avoid short-circuit loops.
• Connect an isolation unit if the communication is not stable due to noise or other factors.
Cable Diagram 1
Display
(Connection Port) Cable Notes
GP3000 (COM1)
GP4000*1 (COM1)
SP5000*2 (COM1/2)
SP-5B00 (COM1)
ST (COM1)
LT3000 (COM1)
IPC*3
PC/AT
*1 All GP4000 models except GP-4100 Series and GP-4203T
*2 Except SP-5B00
*3 Only the COM port which can communicate by RS-232C can be used.
)IPC COM Port (page 4)
1A User-created cable Cable length: 15m or less.
GP-4105 (COM1)
GP-4115T (COM1)
GP-4115T3 (COM1)
1B User-created cable Cable length: 15m or less.
LT-4*01TM (COM1)
LT-Rear Module
(COM1) 1C
RJ45 RS-232C Cable (5m) by Pro-face
PFXZLMCBRJR21 Cable length: 5m or less.

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 16
1A)
1B)
1C)
Legend Name Notes
(1)
RJ45 RS-232C Cable (5m) by Pro-face
PFXZLMCBRJR21
Shield
Display
Signal name
2
3
5
7
8
Shell
Pin
Display side
D-Sub 9pin (socket)
RD(RXD)
SD(TXD)
SG
RS(RTS)
CS(CTS)
FG
Signal name
2
3
7
4
5
6
20
1
Pin
External Device side
D-Sub 25pin (plug)
SD
RD
SG
RS(RTS)
CS(CTS)
DSR
DTR
FG
Shield
Display
Signal name
Display side
Terminal Block
RD(RXD)
SD(TXD)
SG
RS(RTS)
CS(CTS)
Signal name
2
3
7
4
5
6
20
1
Pin
External Device side
D-Sub 25pin (plug)
SD
RD
SG
RS(RTS)
CS(CTS)
DSR
DTR
FG
Display Signal name
2
3
7
4
5
6
20
1
Pin
External Device side
D-Sub 25pin (plug)
SD
RD
SG
RS(RTS)
CS(CTS)
DSR
DTR
FG
GND
TXD
RXD
(1)

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 17
6 Supported Device Addresses
The following section shows the range of supported device addresses. Please note that the actual supported range
of the devices vary depending on the External Device to be used. Please check the actual range in the manual of
your External Device.
: This address can be specified as system data area.
Device Bit Address Word Address 32 bits Remarks
Data Block DB002.DBX000.0 -
DB255.DBX255.15
DB002.DBW000 -
DB255.DBW255
*1*2*3
*1 When changing bit addresses, the Display reads the corresponding word address from the External Device, then
changes the defined bit in the word, and then returns the updated word value to the word address. In the
meantime, if the word address on the External Device is edited as a result of a ladder program or other means,
this value is overwritten with the word value from the Display.
*2 To use Data Blocks, allocate them on the External Device.
*3 Data Block addressing is as follows:
Example: In the case of DB002.DBW000:
• Refer to the GP-Pro EX Reference Manual for system data area.
Cf. GP-Pro EX Reference Manual "LS Area (Direct Access Method Area)"
• Refer to the precautions on manual notation for icons in the table.
)"Manual Symbols and Terminology"
DB002.DBW000
Data Word (DW) No. (000 to 255)
Data Block (DB) No. (002 to 255)

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 18
7 Device Code and Address Code
Use device code and address code if you select "Device Type & Address" for the address type in Data Displays.
Device Device Name Device Code
(HEX) Address Code
Data Block DB 0000 Value of (Data Block (DB) No. ×0x10000) +
Data Word (DW) No.

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 19
8 Error Messages
Error messages are displayed on the Display screen as follows: "No.: Device Name: Error Message (Error
Occurrence Area)". Each description is shown below.
Examples of Error Messages
"RHAA035: PLC1: Error has been responded for device write command (Error Code: 2[02H])"
Error Codes Unique to External Device
Item Description
No. Error number.
Device Name Name of the External Device where an error has occurred. Device name is the title of the
External Device set with GP-Pro EX. (Initial value [PLC1])
Error Message Displays messages related to an error that has occurred.
Error Occurrence Area
Displays the IP address or device address of the External Device where an error has
occurred, or error codes received from the External Device.
• IP address is displayed as "IP address (Decimal): MAC address (Hex)".
• Device address is displayed as "Address: Device address".
• Received error codes are displayed as "Decimal [Hex]".
• Refer to your External Device manual for details on received error codes.
• Refer to "Display-related errors" in "Maintenance/Troubleshooting Guide" for details on the
error messages common to the driver.
Error Code Error Description
0x0A Parameter error
Definition error by data exchange process
0x0C Parameter error
Command (packet) error
0x14 Parameter error
Command (packet) error
0x2A Communication process error other than command (packet) error
0x32 DB/DX access error
0x34 Command (packet) error
0x36 Communication process error other than command (packet) error

SIMATIC S5 3964(R) Driver
GP-Pro EX Device/PLC Connection Manual 20
