Siemens SIMATIC Rack PC IL 40 User manual

Contents, Preface
Important Information 1
Commissioning 2
Operating 3
Appendix
Guidelines for ESD A
SIMATIC
Rack PC IL 40
Intel Pentium 4 Platform
Getting Started
First Steps in Commissioning
Edition 03/2003
A5E00171493-02

Copyright © Siemens AG 2003 All rights reserved
The reproduction, transmission or use of this document or its
contents is not permitted without express written authority.
Offenders will be liable for damages. All rights, including rights
created by patent grant or registration of a utility model or design,
are reserved.
Siemens AG
Bereich Automation and Drives
Geschaeftsgebiet Systems Engineering
Postfach 2355, D- 90766 Fuerth
Disclaimer of Liability
We have checked the contents of this manual for agreement with
the hardware and software described. Since deviations cannot be
precluded entirely, we cannot guarantee full agreement. However,
the data in this manual are reviewed regularly and any necessary
corrections included in subsequent editions. Suggestions for
improvement are welcomed.
©Siemens AG 2003
Technical data subject to change.
Siemens Aktiengesellschaft A5E00171493-02
Safety Guidelines
This Getting Started contains notices intended to ensure personal safety, as well as to protect the products
and connected equipment against damage. These notices are highlighted by the symbols shown below and
graded according to severity by the following texts:
!Danger
indicates that death, severe personal injury or substantial property damage will result if proper
precautions are not taken.
!Warning
indicates that death, severe personal injury or substantial property damage can result if proper
precautions are not taken.
!Caution
indicates that minor personal injury can result if proper precautions are not taken.
Caution
indicates that property damage can result if proper precautions are not taken.
Notice
draws your attention to particularly important information on the product, handling the product, or to a
particular part of the documentation.
Qualified Personnel
Repair, maintenance and servicing of device only to be carried out by qualified personnel. Qualified persons
are defined as persons who are authorized to commission, to ground and to tag circuits, equipment, and
systems in accordance with established safety practices and standards.
Correct Usage
Note the following:
!Warning
This device and its components may only be used for the applications described in the catalog or the
technical description, and only in connection with devices or components from other manufacturers
which have been approved or recommended by Siemens.
This product can only function correctly and safely if it is transported, stored, set up, and installed
correctly, and operated and maintained as recommended.
Trademarks
SIMATIC®, SIMATIC HMI® and SIMATIC NET® are registered trademarks of SIEMENS AG.
Third parties using for their own purposes any other names in this document which refer to trademarks might
infringe upon the rights of the trademark owners.

SIMATIC Rack PC IL 40, Getting Started
A5E00171493-02 iii
Contents
Preface..........................................................................................................................................v
1 Important Information ....................................................................................................1-1
1.1 Safety Instructions.............................................................................................1-1
1.2 Certificates, Directives and Declarations ..........................................................1-5
1.3 Certification for the USA, Canada and Australia...............................................1-7
1.4 Transport...........................................................................................................1-8
2 Commissioning...............................................................................................................2-1
2.1 Unpacking the SIMATIC Rack PC IL................................................................2-1
2.2 Installing the SIMATIC Rack PC IL...................................................................2-2
2.3 Preparing for Operation.....................................................................................2-5
2.4 Initial Startup .....................................................................................................2-7
2.5 Normal Operation..............................................................................................2-9
2.6 Connecting Peripheral Units ...........................................................................2-10
2.7 Ethernet (RJ45 Ethernet Port).........................................................................2-13
2.8 Connection under Windows............................................................................2-13
3 Operating.........................................................................................................................3-1
3.1 Switch on the PC...............................................................................................3-1
3.2 Switch off the PC...............................................................................................3-1
3.3 Operating modes...............................................................................................3-2
3.4 Reset via On/Off button.....................................................................................3-2
3.5 LEDs at the PC..................................................................................................3-3
3.6 Monitoring Functions.........................................................................................3-3
3.7 Floppy Disk Drive..............................................................................................3-4
3.8 CD ROM Drive ..................................................................................................3-5
3.9 BIOS-Settings....................................................................................................3-6
3.10 Property and data protection.............................................................................3-7
3.10.1 Mechanical housing lock...................................................................................3-7
3.10.2 Access protection under Windows....................................................................3-7
3.10.3 BIOS Setup security functions ..........................................................................3-7
A Guidelines for Handling Electrostatically-Sensitive Devices (ESD).........................A-1
A.1 What is ESD?................................................................................................... A-1
A.2 Electrostatic Charging of Persons.................................................................... A-2
A.3 General Protective Measures Against Electrostatic Discharge Damage......... A-3

Contents
SIMATIC Rack PC IL 40, Getting Started
iv A5E00171493-02

SIMATIC Rack PC IL 40, Getting Started
A5E00171493-02 v
Preface
Purpose of the Getting Started
This Getting Started contains all the information you need for commissioning and
using the SIMATIC Rack PC Industrial Lite (abbreviated in the manual as
Rack PC IL).
It is intended both for programming and testing/debugging personnel who
commission the device itself as well as for service and maintenance personnel who
install expansions or carry out fault/error analyses.
Validity of the Getting Started
This Getting Started is valid for all supplied variations of the Rack PC IL and
describes the state of delivery as of March 2003.
Certifications, Standards and Approvals
Certifications
The device fulfils the following guidelines and certifications:
•EN 60950 (Security)
•EN 61000-6-2 (Noise Immunity)
•Norm EN 50081-1 (Emitted Interference)
•Underwriters Laboratories (UL) to Standard UL 1950
•Canadian Standard Association (CSA) to Standard C22.2 No. 950
Standards and Approvals
The device fulfils the requirements for the CE approval.
Further information on the approvals, certificates, and licenses for your device is
provided in Chapter 1.

Preface
SIMATIC Rack PC IL 40, Getting Started
vi A5E00171493-02
Electronic Manual
You can find the electronic manual on the included CD "Rack PC IL 40
Documentation and Drivers". To read or to print out the manual start the Start
program and follow the instructions on the screen.
The manual offers information on useful topics, for example, optional hardware-
expansion and technical data.
Further Support
If you have any technical questions, please get in touch with your Siemens
representative or agent responsible.
http://www.siemens.com/automation/partner
Training Centers
Siemens offers a number of training courses to familiarize you with the SIMATIC
S7 automation system. Please contact your regional training center or our central
training center in D 90327 Nuremberg, Germany for details:
Telephone: [phone].
Internet: http://www.sitrain.com

Preface
SIMATIC Rack PC IL 40, Getting Started
A5E00171493-02 vii
A&D Technical Support
Worldwide, available 24 hours a day:
Beijing
Nuernberg
Johnson City
Worldwide (Nuernberg)
Technical Support
24 hours a day, 365 days a year
Phone: [phone]
Fax: [phone]
E-Mail: adsupport@
siemens.com
GMT: +1:00
Europe / Africa (Nuernberg)
Authorization
Local time: Mon.-Fri. 8:00 to 17:00
Phone: [phone]
Fax: [phone]
E-Mail: adsupport@
siemens.com
GMT: +1:00
United States (Johnson City)
Technical Support and
Authorization
Local time: Mon.-Fri. 8:00 to 17:00
Phone: [phone]
Fax: [phone]
E-Mail: simatic.hotline@
sea.siemens.com
GMT: -5:00
Asia / Australia (Beijing)
Technical Support and
Authorization
Local time: Mon.-Fri. 8:00 to 17:00
Phone: [phone]
Fax: [phone]
E-Mail: adsupport.asia@
siemens.com
GMT: +8:00
The languages of the SIMATIC Hotlines and the authorization hotline are generally German and English.

Preface
SIMATIC Rack PC IL 40, Getting Started
viii A5E00171493-02
Service & Support on the Internet
In addition to our documentation, we offer our Know-how online on the internet at:
http://www.siemens.com/automation/service&support
where you will find the following:
•The newsletter, which constantly provides you with up-to-date information on
your products.
•The right documents via our Search function in Service & Support.
•A forum, where users and experts from all over the world exchange their
experiences.
•Your local representative for Automation & Drives via our representatives
database.
•Information on field service, repairs, spare parts and more under "Services".

SIMATIC Rack PC IL 40, Getting Started
A5E00171493-02 1-1
1 Important Information
1.1 Safety Instructions
Caution
The safety instructions given on the reverse of the title page of this Getting
Started must be observed. Before expanding your Rack PC IL refer to Chapter 5
in the electronic manual and read the relevant safety instructions.
This device corresponds to the relevant safety measures according to IEC, EN,
VDE, UL, and CSA. If you have questions about the permissibility of the installation
in the designated environment, please contact our service representative.
Installation Notes
Condensation can occur if the device is transported from a cold environment into
the operating area. Wait until the device has adapted to the room temperature and
is completely dry before operating it. Please observe the notes on ambient
conditions in Chapter 6 in the electronic manual and the installation notes in
Section 2.2 of this manual when installing and operating the device. The device is
to be installed so that there is no danger of it falling or of causing damage to itself
or others.
Be sure the fan ventilation slots are open so that a sufficient amount of air can be
drawn in to cool the housing interior.
!Warning
Take note of the permissible fitting positions without fail when installing the
systems (see Section 2.2).
If the systems are installed in a non-permissible fitting position, the approvals
pursuant to UL 1950 and EN60950 are no longer valid!

Important Information
SIMATIC Rack PC IL 40, Getting Started
1-2 A5E00171493-02
Power Connection
Install the cables so that no one can step on them or trip over them. When you
connect the device, adhere to the relevant instructions in Section 2.3 of this
manual.
Do not connect or disconnect power supply cables and data transmission lines
during thunderstorms.
In emergency situations (for example, damaged housing, damaged operator
elements, a damaged power supply cable, ingress of liquids or foreign particles),
switch off the device. Disconnect the power plug and inform the responsible service
personnel.
The Rack PC IL must be switched off when you connect or disconnect peripheral
devices (keyboard, mouse, printer, etc.). You can damage the PC if you do not
adhere to these instructions.
Notes for Devices with AC Power Supply
The device is intended for service in grounded electricity supply systems (TN
systems to VDE 0100, part 300, or IEC 364-3).
Service in non-grounded or impedance-grounded supply systems (IT systems) is
not intended.
The power cord should meet the respective local safety requirements.
Check whether the device's set supply voltage is the same as the local supply
voltage.
This device is equipped with a safety-tested power supply cable. You may connect
this device only to a grounding outlet with a grounding contact.
Make certain that the socket outlet on the device or the grounding contact for the
building wiring system is freely accessible and as near to the device as possible.
To establish a complete power separation, you must disconnect the power plug
(inlet connector on the back of the device). This location must be accessible. A
central isolating switch must be present for cabinet mounting.

Important Information
SIMATIC Rack PC IL 40, Getting Started
A5E00171493-02 1-3
Country-Specific Information
For the United States and Canada:
In the United States and Canada USA, a CSA or UL-listed power supply cable
must be used.
The male plug is a 5-15 style.
For operation with 120 V:
Use a UL Listed, CSA Labelles Cord Set, consisting of a min. 18 AWG. Type SVT
or STJ three conductor flexible cord, max. 4.5 m (15 feet) in length and a parallel
blade grounding type attachment plug rated 15 A, min 125 V.
For operation with 240 V:
Use a UL Listed, CSA Labeled Cord Set, consisting a min. 18 AWG. Type SVT or
SJT three conductor flexible cord, max. 4.5 m (15 feet) in length and a tandem
blade grounding type attachment plug, rated 15 A, 250 V.
For operation with 230 V (outside of USA and Canada)
Use a Cord Set consisting of a min 18 AWG cord and grounding type attachment
plug rated 15 A, 250 V. The cord set should have the appropriate safety approvals
for the country in which the equipment will be installed and marked
Repairs
Only authorized personnel are permitted to repair the Rack PC IL. Unauthorized
opening and improper repairs on the device can result in significant danger to the
user.
Before you open the device, first switch it off and then disconnect the power plug.
Install only system expansion devices provided for this computer. If you install
other expansion devices, you can damage the system or violate the safety
requirements and regulations for radio interference suppression. Contact your
technical support team or where you purchased your PC to find out which system
expansion devices may safely be installed.
!Caution
There are fast-running fans in Rack PC IL 40 which may cause injury when
touched.
Note
There is a filter mat behind the front panel, check it regularly for dirt and change
it if necessary.

Important Information
SIMATIC Rack PC IL 40, Getting Started
1-4 A5E00171493-02
Battery
There is a battery in this device below the device fan. Batteries may only be
exchanged by technical personnel.
Observe the local regulations on disposal of special waste when disposing of dead
batteries.
!Caution
There is the danger of an explosion, if the battery is not exchanged as directed.
Replace only with the same type or an equivalent type recommended by the
manufacturer. Dispose of used batteries in accordance with the manufacturer's
instructions.
Notes on Inserting and Removing Modules (ESG Guidelines)
Modules containing electrostatically sensitive devices (ESDs) can be identified by
the following label:
Please observe and carefully follow the guidelines mentioned below when handling
modules equipped with electrostatically sensitive devices:
•Always discharge your body before handling modules equipped with ESDs (for
example, by touching a grounded object).
•Devices and tools must be free of static electricity.
•Always pull the power plug and disconnect the battery before connecting or
disconnecting modules (containing ESDs).
•Touch modules fitted with ESDs by their edges only.
•Never touch wiring posts or printed conductors on modules containing ESDs.
For more information on electronic charging and safety measures, refer to
Appendix A.

Important Information
SIMATIC Rack PC IL 40, Getting Started
A5E00171493-02 1-5
1.2 Certificates, Directives and Declarations
Notes on the CE Symbol
The following applies to the SIMATIC product described in this Getting Started:
EMC Directive
This product fulfils the requirements for the EC directive 89/336/EEC on
„electromagnetic compatibility" and the following fields of application apply
according to this CE symbol:
Field of Application Requirement For
Emitted Interference Noise Immunity
Residential and commercial
areas and small businesses. EN 50081-1: 1992 EN 61000-6-2
Industry EN 50081-2: 1992 EN 61000-6-2
In addition, the EN 61000-3-2 (harmonic currents) and EN 61000-3-3 (voltage
fluctuation and flicker) have been fulfilled.
Low Voltage Directive
This product fulfils the requirements for the EC directive 73/23/EEC on „low
voltage" and was tested to EN60950.
Declaration of Conformity
The EC declarations of conformity and the documentation relating to this are
available to the authorities concerned, according to the above EC directive, from:
Siemens AG
Bereich Automation and Drives
A&D AS RD 4
Postfach 1963
D-92209 Amberg
Tel.: [phone]
Fax: [phone]

Important Information
SIMATIC Rack PC IL 40, Getting Started
1-6 A5E00171493-02
Observing the Setup Guidelines
The setup guidelines and safety instructions given in this Getting Started must be
observed on startup and during operation.
Connecting Peripherals
The requirements regarding noise immunity (EN61000-6-2) are met when you
connect a peripheral suitable for an industrial environment. Peripherals should only
be connected via shielded cables.
Software License Agreement
The SIMATIC Rack PC IL is shipped with the operating system on the Restore CD.
Please observe the relevant license agreements.

Important Information
SIMATIC Rack PC IL 40, Getting Started
A5E00171493-02 1-7
1.3 Certification for the USA, Canada and Australia
Security
One of the following markings on a device is indicative of the corresponding
approval:
Underwriters Laboratories (UL) to the UL 1950 Standard (I.T.E)
or to the UL508 (IND.CONT.EQ)
C
Underwriters Laboratories (UL) to the Canadian Standard C22.2 No. 950
(I.T.E) or to the C22.2 No. 142 (IND.CONT.EQ)
CUS
Underwriters Laboratories (UL) to Standard UL 1950, Report E11 5352 and to the
Canadian Standard C 22.2 No.950 (I.T.E)
or to the UL508 and C22.2 No. 142 (IND.CONT.EQ)
UL-Recognition-Mark
Canadian Standard Association (CSA) to standard C22.2. No. 950
(LR 81690) or to C22.2 No. 142 (LR 63533)
NRTL
Canadian Standard Association (CSA) to the American Standard UL 1950
(LR 81690)
EMC
USA
Federal Communications Commission
Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
Shielded Cables
Shielded cables must be used with this equipment to maintain compliance
with FCC regulations.
Modifications
Changes or modifications not expressly approved by the manufacturer could
void the user's authority to operate the equipment.
Conditions of Operations
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

Important Information
SIMATIC Rack PC IL 40, Getting Started
1-8 A5E00171493-02
1.4 Transport
Transporting
Despite the fact that the Rack PC IL is of rugged design, its internal components
are sensitive to severe vibrations or shock. You must therefore protect the PC from
severe mechanical stress when transporting it.
Use the original packing material if you have to ship the Rack PC IL from one
location to another.
!Caution
Risk of damage!
When transporting the PC in cold weather, when it may be submitted to extreme
variations in temperature, make sure that there is no moisture (condensation) on
or in the PC.
The PC must be allowed to reach room temperature slowly before you switch it
on.

SIMATIC Rack PC IL 40, Getting Started
A5E00171493-02 2-1
2 Commissioning
2.1 Unpacking the SIMATIC Rack PC IL
Unpack your Rack PC IL as follows:
1. Remove the packing.
2. Do not throw the original packing away. Keep it in case you have to transport
the unit again sometime in the future.
3. Please keep the documentation in a safe place. It is required during the initial
start up and is part of the device.
4. Check the packing and its contents for any shipping or transport damage
5. Check with the delivery note to make sure no components are missing. Also
check the accessory parts, which you can order separately.
6. Please inform your local dealer of any shipping or transport damages and of
outstanding items indicated on the delivery note.
Recording the Serial Number and the Ethernet address
7. Enter the serial number and the Ethernet address of your PC in the table
below. You can find the serial number on the type label attached to the rear of
the device. The Ethernet address can be found in the BIOS setup under Info
(key F1) > LAN Address.
The device can precisely be identified with the help of these numbers in case
of repairs or theft.
Enter the Microsoft Windows “Product Key" from the “Certificate of Authenticity"
8. Enter the Microsoft Windows "Product Key" from the "Certificate of
Authenticity" (COA) in the table. The product key is on the back of the device.
F-No.
Order No.
Microsoft Windows Product Key
Ethernet Address

Commissioning
SIMATIC Rack PC IL 40, Getting Started
2-2 A5E00171493-02
2.2 Installing the SIMATIC Rack PC IL
The Rack PC is suitable for vertical and horizontal fitting in consoles, switch boards
and 19" rack systems.
Notice
In the event of a vertical installation, make sure the right side of the device faces
up.
The Rack PC IL meets the requirements for a fire enclosure to EN 60950. It can
therefore be fitted without an additional fire enclosure.
Please note the following points when installing the PC:
•Avoid extreme ambient conditions as far as possible. Protect your PC from
dust, moisture, and heat.
•Keep the PC out of direct sunlight.
•Mount the PC as safely as possible to prevent any danger (for example, by
falling over).
•The clearance near the ventilation slots must be at least 50 mm, so that the PC
is sufficiently ventilated.
•Make certain that the ventilation slots for the housing are not covered.
•Make certain that the sliding door in front of the drives is closed during
operation.
•The Rack PC IL can be mounted on telescopic rails or on cabinet brackets. It is
not permitted to mount it at the 19" front supports only.
•Use the respective manufacturer's cabinet or rack slide rails or L-sections.
Contact your cabinet supplier directly regarding cabinet or rack installation.
•The use of the telescopic rails makes it possible to completely pull the Rack
PC out of the cabinet or rack.
Notice
If the systems are installed without keeping to the conditions mentioned above,
the approvals pursuant to UL 1950 and EN60950 are no longer valid!

Commissioning
SIMATIC Rack PC IL 40, Getting Started
A5E00171493-02 2-3
Dimensioned Drawing for installation in cabinet 19"
465
483
101
177
430
433,6
436
446
490
Upwards for
vertical
installation
Upwards for
vertical
installation

Commissioning
SIMATIC Rack PC IL 40, Getting Started
2-4 A5E00171493-02
Dimensioned Drawing for using telescopic rails
35
127
209,6
355,6
100 100 100
72,6
88,5
173,3
444,5
Dimensions for telescopic rails
by the company Rittal type 3659
Dimensions for telescopic rails by the
company Schroff type 69000-122
Technical Specifications of the Telescopic Rails
Load per pair minimum 30 kg
Pull-out length for complete pull-out minimum 470 mm
Rail thickness maximum 9,7 mm
Fixing screws M5 x 6mm
The fixing screw of the telescopic rail should not go beyond a maximum of 5 mm
into the housing.
