KION / KION-i anesthesia workstation
Service Manual
E382 E392E 061 01 02 02

Siemens-Elema AB
Notes KION / KION-i
E382 E392E 061 01 02 02
Notes

E382 E392E 061 01 02 02 Siemens-Elema AB
KION / KION-i Important
1 - 1
1
Contents
Contents
1. Important.......................................................................................................
2. Introduction ..................................................................................................
3. Description of functions.............................................................................
4. Disassembling and assembling...............................................................
5. Service procedures.....................................................................................
6. Troubleshooting...........................................................................................
7. Preventive maintenance............................................................................
8. Index...............................................................................................................
9. Diagrams .......................................................................................................
2
3
4
5
6
7
8
9

Siemens-Elema AB
Important KION / KION-i
E382 E392E 061 01 02 02
1 - 2
1
Important
General
• Service documentation for the KION™ / KION-i™
anesthesia workstation consists of:
– Operating Manual. The Operating Manual is an
indispensable complement to the Service
Manual for proper servicing.
– Service Manual
– Installation Instructions
– Spare Parts information
– Documentation for the KION / KION-i Monitor.
– Documentation for all optional equipment
included in the KION / KION-i workstation.
• The following conventions are used throughout
this Service Manual:
–KION represents KION anesthesia workstation.
–KION-i represents KION-i anesthesia
workstation.
• The information in this Service Manual is based
on:
– KION version 7.x.
– KION-i version 10.x.
The information in this Service Manual is valid for
both versions unless otherwise stated.
• Serial number of the unit is found on a label
attached by the mains power inlet.
• A system version label is found by the mains
power inlet. Make sure that the version of the
Operating Manual corresponds to this system
version.
Text inside a box is used to highlight important
information.
• In addition to the Important information given
here and in the related documents (e. g. in the
Operating Manual), always pay attention to
applicable local and national regulations.
• Responsibility for the safe functioning of the
equipment reverts to the owner or user in all
cases in which service or repair has been done by
a non-professional or by persons who are not
employed by or authorized by Siemens, and
when the equipment is used for other than its
intended purpose.
Hazard notices
• Before disassembling or assembling, make sure
that:
– Gas supply is disconnected.
– Mains power cable is disconnected.
– Power switch is set to Off. If the power switch
is set in any other position, the internal battery
will supply power to the PC boards.
– The internal battery is disconnected when the
power section is open.
– All gas conveying parts are cleaned according
to instructions in the KION / KION-i – Operating
Manual, chapter Routine cleaning.
• With power supply connected to the KION /
KION-i workstation, there are energized electrical
components inside the unit. All personnel must
exercise extreme caution if fault tracing or
adjustments are performed with power supply
connected and with user interface and patient
unit covers removed.
Installation
• Only personnel trained and authorized
by Siemens shall be permitted to
install the KION / KION-i workstation.
The installation and handing-over
procedures are described in the
”Installation Instructions”.
Symbols used in this manual
•ESD sensitive components. When
handling ESD-sensitive devices,
established procedures must be
observed to prevent damage.
•Special waste. Discard disposable,
replaced and left-over parts in accor-
dance with appropriate industrial and
environmental standards.
•Recycling. Recycle if possible.
Recycling facilities may not be
available in all areas.
•Technical training. Refers to the
Technical training supplied by
Siemens.
•Service contract. Refers to the
Service contract supplied by
Siemens.

E382 E392E 061 01 02 02 Siemens-Elema AB
KION / KION-i Important
1 - 3
1
Important To the responsible service personnel
• The contents of this document are not binding.
If any significant difference is found between the
product and this document, please contact
Siemens for further information.
• We reserve the right to modify products without
amending this document or advising the user.
• Only personnel trained and authorized
by Siemens shall be permitted to
perform service or repair the KION /
KION-i workstation. Only Siemens
genuine spare parts must be used.
PC boards (spare parts) must always be kept in a
package for sensitive electronic devices. Siemens
will not otherwise assume responsibility for the
materials used, the work performed or any
possible consequences of same.
• The device complies to standards and require-
ments as stated in the KION / KION-i workstation
– Operating Manual.
Calibration and Functional check
• After any installation, maintenance or service
intervention in KION / KION-i workstation,
perform a ”Calibration” and a ”Function check”
according to instructions in the KION / KION-i –
Operating Manual.
Service
• The KION / KION-i workstation must
be serviced at regular intervals by
personnel trained and authorized by
Siemens. Any maintenance or service
must be noted in a log book provided.
• It is recommended that maintenance
and service is done as a part of a
service contract with Siemens.
• Preventive maintenance must be performed
every:
– Six months. This corresponds to approx. 1.000
hours of operation calculated as operating time
of 40 hours a week during six months. Details
are found in the Operating Manual.
– Twelve months or every 3000 hours of
operation whichever comes first. Details are
found in this Service Manual, chapter
”Preventive maintenance”.
– Three years. The internal battery shall be
replaced every three years according to
instructions in this Service Manual, chapter
”Preventive maintenance”.
• Worn-out batteries must be recycled or
disposed of properly according to local
regulations. Recycle facilities may not
be available in all areas.
• Batteries must not be disposed of with
ordinary waste. Discard disposable,
replaced and left-over parts in accor-
dance with appropriate industrial and
environmental standards.
• When handling ESD-sensitive devices,
established procedures must be
observed to prevent damage.

Siemens-Elema AB
Important KION / KION-i
E382 E392E 061 01 02 02
1 - 4
1
Notes

E382 E392E 061 01 02 02 Siemens-Elema AB
KION / KION-i Introduction
2 - 1
2
2. Introduction
Main units .......................................................... 2 - 2
Battery drawer................................................ 2 - 3
Pneumatic section.......................................... 2 - 4
Vaporizer section ............................................ 2 - 5
Patient unit ..................................................... 2 - 6
User interface ................................................. 2 - 7
Electronic structure ........................................... 2 - 8
General ........................................................... 2 - 8
Internal communication.................................. 2 - 9
Only personnel trained and authorized
by Siemens shall be permitted to
perform installation, service or
maintenance of the KION / KION-i
workstation.
Make sure to prepare the KION / KION-i
workstation properly before disassembling and
assembling. Refer to section ”Hazard notices” in
chapter ”Important”.
Any service or maintenance must be noted in a
log book.
Discard disposable, replaced and left-over parts in
accordance with appropriate industrial and
environmental standards.
After any installation, maintenance or service
intervention in the KION / KION-i, perform a
”Calibration” and a ”Function check”.
Refer to the ”KION / KION-i anesthesia
workstation – Operating Manual” for details.

Siemens-Elema AB
Introduction KION / KION-i
E382 E392E 061 01 02 022 - 2
2
Main units
The KION / KION-i workstation can be divided into
the following functional main units:
• User interface, i. e. the Control panel and the KION
Monitor. The Monitor is a Siemens patient monitor
(SC 7000, SC 9000 or SC 9000XL) used with the
KION / KION-i workstation.
• Battery drawer
• Pneumatic section
• Vaporizer section
• Patient unit.
All these main units are incorporated in or attached to
the cart which is the main body of the system.
Patient unit
Vaporizer section
User
interface
Battery drawer
Pneumatic section
KION
Monitor
Control
panel
The following optional equipment can also be
incorporated in the KION / KION-i workstation:
• DuoView™ overflow screen
• Built-in multigas analyzer
– KION MultiGas 2000
– KION MultiGas+
• O2 Monitoring MiniOX
• Isolation transformer
• Backup gas supply manifold
• Suction equipment
• Auxiliary O2supply
• Gas evacuation
• Accessory and Monitor shelfs
• Medside Data Station for KION.
Functional descriptions, as well as service and
maintenance procedures for these optional
equipments, can be found in this Service Manual. For
Installation Instructions, refer to separate documents.

E382 E392E 061 01 02 02 Siemens-Elema AB
KION / KION-i Introduction
2 - 3
2
Battery drawer
The battery drawer can be pulled out from the cart
for easy access. It contains functions for power
supply and communication:
1. AC/DC Converter
2. Internal battery. An optional Extra internal battery
can be installed to prolong the backup time.
Included in the Battery drawer is also the Power &
Communication interface containing:
3. Communication ports
4. PC 1747 CAN/RS232 INTERFACE
5. PC 1753 DC/DC CONVERTER
6. PC 1675 POWER SUPPLY
7. MIB CONNECTOR (MIB = Medical Information Bus):
– PC 1761 for KION with S/N 03645 or lower.
– PC 1843 for KION / KION-i with S/N 03646 or
higher.
8. CONNECTOR board:
– PC 1754 for KION with S/N 03645 or lower.
– PC 1856 for KION / KION-i with S/N 03646 or
higher.
9. COMMUNICATION INTERFACE board:
– PC A101 CPS NETWORK PCB including the small
PC A301 MONITOR OPTION AND SETUP MEMORY
BOARD for KION with S/N 03645 or lower.
– PC A110 IDS NETWORK PCB and PC A120 CAN/
MIB for KION / KION-i with S/N 03646 or higher
(not shown in illustration).
These PC boards are also included in the Siemens
patient monitor Communication/Power Supply
module alt. Infinity Docking Station module. For
further information regarding these modules,
refer e. g. to the SC 7000/9000XL or SC 9000
Service Manuals.
The following cables are connected to the Power &
Communication interface:
10. Multigas analyzer communication cable (RS232)
11. Multigas analyzer power cable (24 V DC)
12. DuoView cable (RS232 & supply voltage)
13. CAN loop-back
14. KION / KION-i Monitor communication cable
(TAXI and supply voltage)
15. Isolation transformer cable (optional)
16. AC/DC Converter cable.
KN9001
6;9H<
KN9002
=
?
@
A
KN9003



.
!
"
#

Siemens-Elema AB
Introduction KION / KION-i
E382 E392E 061 01 02 022 - 4
2
Pneumatic section
The pneumatic section, accessible when the top
cover and shield cover is removed, controls the
inspiratory fresh gas flow and the expiratory gas
flow.
The main parts inside the pneumatic section are:
1. Gas distribution block
2. PC 1720 WALL PRESSURE
3. PC 1765 VALVE INTERCONNECTION
4. Gas module AIR (N2O) – BP
5. Gas module O2– BP
6. Gas module Drive Gas AIR (O2)
7. Inspiratory gas block
8. Fresh gas pressure container
9. Inspiratory fresh gas flow transducer
10. Inspiratory fresh gas valve with PC 1751 STEP
MOTOR
11. PC 1737 MEASURING
12. PC 1730 CONTROL
13. PC 1797 FRESH GAS FLOW (PC 1748 on units with
S/N 00125 – 01405)
14. PEEP valve
15. PC 1796 INTERCONNECTION (PC 1733 on units with
S/N 00125 – 01405)
16. PC 1750 TRANSDUCER including four pressure
transducers:
– On PC 1750A/B, the four pressure transducers
are the integrated in PC 1750.
– As from PC 1750C or later, four separate
pressure transducers, PC 1781 PRESSURE
TRANSDUCER board, are used (not shown in
illustration).
The PC board protective plate shown in the upper
illustration was introduced on KION workstations
delivered as from July 1998.
KN9005 KN9004
96=<;H
@A ?
." #


!

E382 E392E 061 01 02 02 Siemens-Elema AB
KION / KION-i Introduction
2 - 5
2
Vaporizer section
The vaporizers used in the KION / KION-i workstation
are the Precision Injection Vaporizers, PIVap.
The vaporizers are color-coded for the different
anesthetic liquids and the filling is key-indexed.
Three vaporizers can be mounted onto the vaporizer
magazine. The main functions are:
1. Vaporizer magazine. The magazine can be
revolved to facilitate easy access to the active
vaporizer.
2. PIVap vaporizers
3. Vaporizer locking lever
4. Vaporizer concentration knob. Only one vaporizer
can be active at a time due to the interlocking
system. To activate the vaporizer; push-in and
turn the vaporizer concentration knob counter-
clockwise.
Vaporizers for the following anesthetic agents are
available:
• Halothane
• Enflurane
• Isoflurane
• Sevoflurane
• Desflurane.
Handle the vaporizers with care when filled with
anesthetic liquids. Never turn them upside down
or lay them sideways.
KN9006
H;
69

Siemens-Elema AB
Introduction KION / KION-i
E382 E392E 061 01 02 022 - 6
2
Patient unit
The patient unit controls the gas flow to and from the
patient. The main functions are:
1. Patient cassette. Removable unit containing
mushroom valves, expiratory flow transducer,
inspiratory and expiratory unidirectional valves
and the APL valve. The patient tubes and the
manual breathing bag are connected to the
patient cassette.
2. Support plate for patient cassette. There are five
solenoid valves and a mechanically controlled cut-
off valve included in the support plate.
The solenoid valves are electrically connected to
PC 1755 PATIENT CASSETTE VALVE CONTROL. All these
parts are protected by a cover plate.
3. Bag-in bottle. The breathing bellows and the
bellows container are connected to the breathing
system when Circle System is selected.
A bellows position sensor (4) including PC 1766
BNB SENSOR is mounted on the cart.
5. The CO2Absorber purifies the rebreathing gas
when Circle System is selected.
6. Auxiliary fresh gas outlet to be used in combina-
tion with external breathing systems.
7. The section Instant O2supply contains the:
– Emergency O2 switch (8) marked 5 L/min O2.
When switched on, it secures a continuous gas
flow from the O2gas supply of approx. 5 l/min.
This function enables manual ventilation, e. g.
in case of ventilator malfunction.
–O
2 Flush push-button (9) marked O2+.
A gas flow of 35 – 75 l/min (depending on the
O2supply pressure) will be delivered to the
breathing system as long as this button is
pressed.
KN9007
H= <6
9
KN9008
@?
H
;
A

E382 E392E 061 01 02 02 Siemens-Elema AB
KION / KION-i Introduction
2 - 7
2
User interface
Control panel
The control panel section consists of the:
1. Control panel housing.
2. Front panel mounted onto the Control panel
housing. The front panel is available in different
language versions.
3. PC 1672 CONTROL PANEL mounted inside the
control panel housing. The control panel selectors
and potentiometers are connected to PC 1672
CONTROL PANEL.
KION Monitor
The KION Monitor (1) used on the KION workstation
is a Siemens Patient Monitor, SC 7000, SC 9000 or
SC 9000XL. The KION Monitor, that is mounted on
the DOCKING STATION™, will make the KION workstation
an integrated part of the PICK AND GO™ concept.
The KION Monitor is used not only for clinical
information but also for displaying technical
information during pre-use check, calibration and
troubleshooting of the KION workstation.
For information regarding the KION Monitor, refer to
the User's guides and the Service Manuals for the
Siemens Patient Monitors.
KN9011
6
9
KN9010 KN9009
H6

Siemens-Elema AB
Introduction KION / KION-i
E382 E392E 061 01 02 022 - 8
2
Electronic structure
General
The KION software can be divided into the following
functional electronic subsystems:
• Panel (PAN)
• Alarm (ALA)
• Measuring (MEA)
• Control (CON)
• Multigas analyzer interface (MGI)
• Monitor (MON)
• Power supply (PWR).
Measuring
MEA
Control
CON
Multigas
analyzer interface Monitor
MON
Alarm
ALA
Panel
PAN
Power supply
PWR
MGI
KN9012

E382 E392E 061 01 02 02 Siemens-Elema AB
KION / KION-i Introduction
2 - 9
2
Internal communication
The diagram below shows the basic electrical signals
between the different electronic subsystems:
CAN bus
Internal communication via CAN bus protocol (CAN =
Controller Area Network).
The CAN bus is a simple two-wire differential serial
bus system. The CAN bus operates in noisy electrical
environments with a high level of data integrity.
TAXI bus
Communication between the CPS/IDS and the KION
Monitor.
Emergency line
Digital signal in separate cabel for alarm distribution
in case of CAN bus malfunction.
Standby
Digital signal in separate cabel that activates standby
functions.
Reset
Digital signal in separate cabel that ensures a
controlled start of the microprocessors at a stable
voltage level.
PAN
MEA
CON
ALA
MON
MGI
CPS / IDS Diagnostic
VGA output
CIS (RS232)
Recorder
Infinity Network
RS232 Interface
(multigas analyzer)
CAN bus
Emergency line
Standby
PWR
Mains power
Power outputs (Optional
isolation transformer)
= CAN node
Reset
SC 9000 Diagnostic
MIB 1 & 2
KN9013
KION
Monitor
Reset
TAXI bus

Siemens-Elema AB
Introduction KION / KION-i
E382 E392E 061 01 02 022 - 10
2
Panel (PAN)
The PAN-software is stored in an exchangable
program memory (PAN-PROM) mounted on
PC 1672 CONTROL PANEL.
The main functions of the PAN subsystem are:
• Forwarding panel settings to CON and MEA.
• Displaying set and measured parameters.
• Barometer calibration and forwarding of barometric
pressure.
• Adjusting display brightness.
• Supervision of ALA.
• Control panel check (displays and LEDs) at startup.
Alarm (ALA)
The ALA-software is stored in an exchangable
program memory (ALA-PROM) mounted on
PC 1672 CONTROL PANEL.
The main functions of the ALA subsystem are:
• Alarm gateway; transfers alarms from the different
subsystems to the MON subsystem for
presentation on the KION Monitor.
• Alarm backup in case of communication error with
the KION Monitor.
• System release at power-up.
• Supervision of power supply.
• Supervision and calculation of battery capacity.
• Supervision of system status (OFF/Standby/ON).
• Supervision of internal CAN-nodes.
• Handling E2PROM-data concerning system
configuration.
• Mains/battery indication on the control panel.
• Alarm silencing on the control panel.
Measuring (MEA)
The MEA-software is stored in an exchangable
program memory (MEA-PROM) mounted on
PC 1737 MEASURING.
The main functions of the MEA subsystem are:
• Measuring, calculation and supervision of
expiratory flow (minute and tidal volume).
• Measuring and supervision of airway pressure
(software and hardware detection).
• Supervision of gas supply pressure.
• Heating, calibration and zeroing of the expiratory
flow transducer.
• Calibration of pressure transducers.
• Supervision of ”Disconnect”.
The measured values are distributed to the correct
subsystem via the CAN bus.
MEA handles alarm detection and forwards the
alarms to the ALA subsystem. Alarm limits are either
constant values or values set on the control panel.
Multigas analyzer interface (MGI)
The MGI-software is stored in an exchangable
program memory (MGI-PROM) mounted on
PC 1747 CAN/RS232 INTERFACE.
The main functions of the MGI subsystem are:
• Protocol converter between KION (CAN) and the
multigas analyzer (RS232).
• Startup of multigas analyzer.

E382 E392E 061 01 02 02 Siemens-Elema AB
KION / KION-i Introduction
2 - 11
2
Monitor (MON)
The Monitor (MON) subsystem includes the:
•C
OMMUNICATION INTERFACE, CPS alt. IDS Network PCB.
• PC 1754 CONNECTOR alt. PC 1856 CONNECTOR.
• PC 1761 MIB CONNECTOR alt. PC 1843 MIB
CONNECTOR 2.
• KION Monitor.
The COMMUNICATION INTERFACE is also included in the
Siemens Communication Power Supply (CPS) alt.
Infinity Docking Station (IDS) module.
The software in the COMMUNICATION INTERFACE , CPS-
SW alt. IDS-SW, and KION MONITOR-SW in the
KION Monitor is installed from a PC Card via the
KION Monitor.
The main functions of the MON subsystem are:
• Displaying patient parameters and wave forms.
• Displaying gas supply pressures.
• Displaying set and measured gas concentrations.
•Displaying alarms.
• Handling external communication.
Control (CON)
The CON-software (CON-SW) is stored in a FLASH-
PROM on PC 1730 CONTROL. New versions of the
CON-SW can be installed either by replacing PC 1730
or by using the Software download tool.
The main functions of the CON subsystem are:
• Control of breathing systems.
• Control of ventilation modes.
• Control and measuring of fresh gas flow including
gas mixture selection (O2/AIR, O2/N2O).
• Calculation of inspiratory flow.
• Calculation of spontaneous breathing frequency.
• Conversion of panel settings and feedback to
panel.
• Controlling the ”Pre-use check” and the
”Calibration” sequences.
• Control of all electromagnetic valves.
Power supply (PWR)
The Power supply (PWR) subsystem includes the:
• AC/DC Converter.
• Internal battery.
• PC 1753 DC/DC CONVERTER.
• PC 1675 POWER SUPPLY.
• Isolation transformer (if connected).
• Control of power-up and power-down sequences.
The Power supply subsystem is responsible for
converting mains power and battery power to the
voltage levels requested by the system. Power
supply will also supply these voltages to the electrical
parts within the system.
Panel
PAN
GND
+5 V
+15 V
+24 V
-15 V
+24 V_VALVE
+12 V
-12 V
+13 V
For supervision purposes
Multi gas
analyzer
interface
MGI
Monitor
MON
Alarm
ALA
Pneumatic
section
including
MEA
and
CON
Power supply
PWR
KN9014

Siemens-Elema AB
Introduction KION / KION-i
E382 E392E 061 01 02 022 - 12
2
Notes

E382 E392E 061 01 02 02 Siemens-Elema AB
KION / KION-i Description of functions
3 - 1
3
3. Description of functions
Battery drawer................................................... 3 - 2
1. AC/DC Converter...................................... 3 - 2
2. Internal battery ......................................... 3 - 2
3. Extra internal battery (optional)................ 3 - 3
4. Power & Communication interface.......... 3 - 3
Pneumatic section ............................................. 3 - 6
5. Gas distribution block............................... 3 - 6
6. Inspiratory control .................................... 3 - 7
7. PEEP valve................................................ 3 - 10
8. PC 1733 / PC 1796 Interconnection......... 3 - 11
9. PC 1730 Control ....................................... 3 - 11
10. PC 1737 Measuring.................................. 3 - 16
11. PC 1750 Transducer................................. 3 - 18
Vaporizer section ............................................... 3 - 18
12. Vaporizer magazine .................................. 3 - 18
13. PIVap vaporizers ....................................... 3 - 19
Patient unit......................................................... 3 - 20
14. Patient cassette........................................ 3 - 20
15. Support plate for patient cassette ........... 3 - 22
16. Bag-in-bottle ............................................. 3 - 22
17. CO2Absorber ........................................... 3 - 23
18. Instant O2supply...................................... 3 - 23
19. Auxiliary fresh gas outlet.......................... 3 - 23
User interface .................................................... 3 - 24
20. Control panel ............................................ 3 - 24
21. KION Monitor ........................................... 3 - 24
Optional equipment ........................................... 3 - 25
22. DuoView ................................................... 3 - 25
23. Multigas analyzer ..................................... 3 - 25
24. Isolation transformer ................................ 3 - 25
25. Backup gas supply ................................... 3 - 26
26. Suction equipment ................................... 3 - 26
27. Auxiliary O2supply ................................... 3 - 26
28. Gas evacuation ......................................... 3 - 26
29. MiniOX 3000 Oxygen Monitor ................. 3 - 27
30. Accessory and Monitor shelf ................... 3 - 27
31. Medside Data Station for KION ............... 3 - 27
Only personnel trained and authorized
by Siemens shall be permitted to
perform installation, service or
maintenance of the KION / KION-i
workstation.
Make sure to prepare the KION / KION-i
workstation properly before disassembling and
assembling. Refer to section ”Hazard notices” in
chapter ”Important”.
Any service or maintenance must be noted in a
log book.
Discard disposable, replaced and left-over parts in
accordance with appropriate industrial and
environmental standards.
After any installation, maintenance or service
intervention in the KION / KION-i, perform a
”Calibration” and a ”Function check”.
Refer to the ”KION / KION-i anesthesia
workstation – Operating Manual” for details.

Siemens-Elema AB
Description of functions KION / KION-i
E382 E392E 061 01 02 02
3 - 2
3
About this chapter
The Description of functions is divided in two levels:
•
Basic principles – Basic principles containing a
survey of the function. This text is written with an
italic typeface. The text refers to the diagram
”Basic principles” in chapter ”Diagrams”.
•Enhanced information – Enhanced information
about the function. Normal typeface is used in this
text. This text refers to the following diagrams in
chapter ”Diagrams”:
– Pneumatic block diagram
– Electronic interconnection.
Text written in SMALL CAPS refers to block names in
the diagrams mentioned above.
Battery drawer
The battery drawer contains functions for power
supply and communication.
1. AC/DC Converter
The AC/DC CONVERTER, containing the mains power
rectifier and the transformer, is a complete unit that
is mounted on the Power & Communication interface
casing. The AC/DC CONVERTER is electrically connected
to PC 1675 POWER SUPPLY.
There are two mains power inlet fuses in the AC/DC
CONVERTER. The fuses and the AC/DC CONVERTER FAN
are the only spare parts available for the AC/DC
CONVERTER.
The AC/DC CONVERTER FAN pulls cooling air into the
converter compartment. If the fan fails, the signal
FAN_FAIL generates a diagnostic log message.
If the AC/DC CONVERTER is overheated (above +90°C /
194°F), e. g. due to fan failure, the AC/DC CONVERTER
will be disabled. The KION / KION-i workstation will
then be power supplied by the INTERNAL BATTERY.
When the AC/DC CONVERTER cools down, it will
automatically be enabled.
Technical data for the AC/DC CONVERTER:
• AC/DC CONVERTER input: 100 – 240 V AC, 50 – 60 Hz.
• AC/DC CONVERTER output: Max. 400 W, output
voltage level 21–30 V DC controlled by an analog
signal from the Charging/Discharging control block
on PC 1675 POWER SUPPLY.
• Fuses: T 6.3 AL / 250 V AC (2 pcs).
2. Internal battery
The INTERNAL BATTERY (two serial connected 12 V
sealed lead acid batteries) supplies the KION / KION-i
workstation with backup power for min. 30 minutes
with full charged battery.
The INTERNAL BATTERY is used as an internal 24 V
backup. The batteries are rated 12 V, approx. 24 Ah.
The INTERNAL BATTERY is continously charged when the
KION / KION-i workstation is connected to mains
power. Charging time for empty batteries is approx.
6 hours.
The actual INTERNAL BATTERY capacity is continously
displayed on the KION Monitor. The battery capacity
indication, bargraph with %, is related to actual
battery voltage. ”100%” is indicated when trickle
charge level is reached (fully charged).
The following applies concerning battery voltage
supply:
• Battery voltage supply is used as soon as the
AC/DC CONVERTER voltage is less than the battery
voltage (e.g. if the power consumption is too high).
• If the AC/DC CONVERTER output voltage is below
19V (e.g. at loss of mains power), a ”Switching to
battery” alarm indicates that battery voltage supply
is in use.
• First battery alarm ”Limited battery capacity” is
activated when battery voltage reaches below 23 V
(22 V if an EXTRA INTERNAL BATTERY is connected).
These voltage levels correspond to ”20%”
indicated.
• Second battery alarm ”No battery capacity” is
activated 10 minutes after first battery alarm or
when battery voltage is below 22 V (21.5 V if an
EXTRA INTERNAL BATTERY is connected). These voltage
levels correspond to ”0 %” indicated.
• All functions will be cut off when battery voltage
reaches below 21 V.
Battery capacity indication and alarms are generated
via the ALA power supervision function.
Service interval for the INTERNAL BATTERY:
• The INTERNAL BATTERY must be checked during the
”Twelve months maintenance”.
• The INTERNAL BATTERY must be replaced every three
years. After replacement, allow the batteries to
recharge before clinical use of the KION / KION-i
workstation.
The lifetime of the INTERNAL BATTERY is reduced if it is
used frequently to supply the KION / KION-i
workstation with operating power or if the battery
temperature is above +50°C (122°F) e. g. due to
BATTERY DRAWER FAN failure. In such case, it is
recommended to check the INTERNAL BATTERY with
shorter intervals than 12 months.
