SIMATIC
Industrial PC
SIMATIC IPC847C
Getting Started
12/2010
A5E02669190-02
Introduction 1
Description
2
Application planning
3
Installing
4
Connection
5
Commissioning
6
Troubleshooting
7
Dimension drawings
8
Appendix
A

Legal information
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation for the specific task, in particular its warning notices and
safety instructions. Qualified personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be adhered to. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E02669190-02
Ⓟ 12/2010
Copyright © Siemens AG 2010.
Technical data subject to change

SIMATIC IPC847C
Getting Started, 12/2010, A5E02669190-02 3
Table of contents
1 Introduction................................................................................................................................................ 5
2 Description................................................................................................................................................. 7
2.1 External structure...........................................................................................................................7
2.2 Operator Controls ..........................................................................................................................8
2.3 Connecting elements ...................................................................................................................10
2.4 Status displays.............................................................................................................................13
3 Application planning................................................................................................................................. 17
3.1 Transport......................................................................................................................................17
3.2 Unpacking and checking the delivery unit ...................................................................................17
3.3 Ambient and environmental conditions........................................................................................19
3.4 Access protection.........................................................................................................................19
4 Installing .................................................................................................................................................. 21
4.1 Installing the device .....................................................................................................................21
4.2 Technical data of the telescopic rails...........................................................................................22
5 Connection .............................................................................................................................................. 23
5.1 Connecting peripherals ................................................................................................................23
5.2 Connecting the device to power...................................................................................................24
5.3 Equipotential bonding ..................................................................................................................28
5.4 Strain relief for network cables.....................................................................................................29
6 Commissioning ........................................................................................................................................ 31
6.1 Requirements for commissioning.................................................................................................31
6.2 Initial Commissioning - Initial Startup...........................................................................................32
6.3 Reinstalling the software..............................................................................................................33
7 Troubleshooting....................................................................................................................................... 35
7.1 General problems ........................................................................................................................35
8 Dimension drawings ................................................................................................................................ 39
8.1 Dimensional drawing of the device ..............................................................................................39
8.2 Dimensional drawing for the use of telescopic rails.....................................................................40
A Appendix.................................................................................................................................................. 41
A.1 Guidelines and declarations.........................................................................................................41
A.2 Certificates and Approvals...........................................................................................................42
A.3 Service and support.....................................................................................................................44
Index........................................................................................................................................................ 45

Table of contents
SIMATIC IPC847C
4 Getting Started, 12/2010, A5E02669190-02

SIMATIC IPC847C
Getting Started, 12/2010, A5E02669190-02 5
Introduction 1
Objective of this documentation
This Getting Started documentation contains all the information you need for commissioning
and using the SIMATIC IPC847C.
Scope of validity of this document
This documentation is valid for all supplied variations of the SIMATIC IPC847C and describe
the delivery status as of May 2010.
Operating instructions SIMATIC IPC847C
The operating instructions are available on the supplied "Documentation and Drivers" DVD.
To view and print the operating instructions, run Start and follow the instructions on the
screen.
The operating instructions provide useful information on many topics such as the hardware
expansion options, modification of the system configuration and technical data.
Conventions
The term "rack PC" or "device" is sometimes used to refer to the SIMATIC IPC847C product
in this documentation. The abbreviation "CP" stands for CP 1616 onboard.
Note
Safety-related Notices
To avoid damage to assets and for the sake of your own personal safety, please take note of
the information on safety in this Getting Started and in the operating instructions. A warning
triangle references this safety information and is shown depending on the potential hazard.

Introduction
SIMATIC IPC847C
6 Getting Started, 12/2010, A5E02669190-02

SIMATIC IPC847C
Getting Started, 12/2010, A5E02669190-02 7
Description 2
2.1 External structure
Front view of the device (example) Item Description
① Front panel with vent openings
(filter mat and fan behind the front
panel). Check the filter mat
regularly for soiling and, if
appropriate, replace it.
② Status displays
③ Cover screws
④ On/off button
⑤ Reset button
⑥ Lock
⑦ Features for the installation of
DVD ROM drives, DVD burners
and removable racks
⑧ Installation option for 3.5" drive
⑨ 2 x USB interface


    

⑩ Lockable front door for access
security. Keep the front door
closed during normal operation.
Rear view of the device (example) Item Description
① Rear drive cooling fan
② Modules of the redundant power
supply (optional)
③ Expansion slots
④ Connection elements




⑤ Mains connection of the
redundant power supply modules

Description
2.2 Operator Controls
SIMATIC IPC847C
8 Getting Started, 12/2010, A5E02669190-02
2.2 Operator Controls
WARNING
The on/off button signal does not cut off power to the PC!
CAUTION
Data may be lost when the PC performs a hardware reset.
Control elements line side switch, On/Off button and Reset button Item Description
① On/Off button for switching the device on
or off.
Note: The device rear has one or 2 line
side switches ③. These have to be
switched on so that the on/off button at
the front functions.


② Reset button
The reset button can be operated using a
pointed object or a paper clip, for
example. The button signal triggers a
hardware reset. The PC performs a
restart (cold start).

③ On/Off switch
Used to connect the device to the mains.
Depending on the BIOS set-up entry
"After Power Failure" the PC switches on
automatically or the On/Off button ① on
the front has to be pressed.

Description
2.2 Operator Controls
SIMATIC IPC847C
Getting Started, 12/2010, A5E02669190-02 9
Control elements line side switch, On/Off button and Reset button Item Description
③ On/Off switch
Used to connect the device to the mains.
Depending on the BIOS set-up entry
"After Power Failure" the PC switches on
automatically or the On/Off button ① on
the front has to be pressed.


④ Acknowledgement button of the
redundant power supply
The acoustic error signal is deactivated
when the button is pressed.

Description
2.3 Connecting elements
SIMATIC IPC847C
10 Getting Started, 12/2010, A5E02669190-02
2.3 Connecting elements
Interfaces
Layout of the interfaces on the rear of the device
     


   

Description
2.3 Connecting elements
SIMATIC IPC847C
Getting Started, 12/2010, A5E02669190-02 11
Layout of the interfaces on the rear of the device
Item Designation Description
PROFIBUS/MPI PROFIBUS interface (RS 485, electrically isolated), 9-pin D-sub socket (optional product
characteristic)
①
PROFINET CP-1616 onboard interface, three RJ45 sockets (optional product version)
② USB Connection for USB devices, USB Port 1 to 4
③ ETHERNET 1, 2 * 2 x RJ45 connectors, Ethernet 10/100/1000 Mbps
④ COM Serial interface (V.24), 9-pin sub D plug
⑤ LPT Parallel interface, 25-pin
⑥ DP 2 x display port, DP connection of Dual Head graphics card (optional)
⑦ KEYBOARD Connection for a PS/2 keyboard
⑧ MOUSE Connection for a PS/2 mouse
⑨ DVI-I DVI/VGA port for CRT or LCD monitor with DVI interface, VGA via DVI/VGA adapter
⑩ Audio (input) Connection for analog audio source, microphone, 3.5 mm phono jack
⑪ Audio (output) Connection for active speakers or headset, 3.5 mm phono jack
⑫ DVI-D DVI-D connection of the DP adapter
⑬ VGA VGA connection of the DP adapter
⑭ DP Display port connection of the DP adapter at Dual Head graphics card (optional)
⑮ Connecting
potentials
Connection for equipotential bonding
* For unique labeling, the LAN interfaces are numbered on the enclosure. The numbering by the operating
system may deviate from this.

Description
2.3 Connecting elements
SIMATIC IPC847C
12 Getting Started, 12/2010, A5E02669190-02
Power supply
Position of the connector for cooling devices Description

Connector for cooling devices ③ of the AC
power supply to the device. The permitted
power range is 100 VAC to 240 VAC.

Connector for cooling devices ③ at
redundant power supply for the AC power
supply of the device. The permitted power
range amounts to 100 VAC to 240 VAC.

Description
2.4 Status displays
SIMATIC IPC847C
Getting Started, 12/2010, A5E02669190-02 13
2.4 Status displays
Front status displays
Display Meaning LEDs Description
OFF isolated from mains
YELLOW Standby (hibernating)
POWER PC status display
GREEN PC in operation
OFF no access HDD Display for hard disk
access GREEN Access
OFF  No connection
 No data traffic
ETHERNET 1 * ETHERNET status
display
GREEN Data traffic
OFF
 No connection
 No data traffic
ETHERNET 2 * ETHERNET status
display
GREEN Data traffic

Description
2.4 Status displays
SIMATIC IPC847C
14 Getting Started, 12/2010, A5E02669190-02
Front status displays
OFF
 No connection
 No data traffic
 PROFIBUS not equipped
Display of the
communication status
to S7 or PROFIBUS
GREEN  MPI/DP data traffic
OFF  No connection
 No data traffic
 CP 1616 onboard not
equipped
 CP disabled
 No error, communication
established
 Charging in progress
 CP 1616 driver not installed
 CP in NDIS mode
Flashes slowly
RED
 Link status error
 IO controller: IO device cannot
be addressed
 IO controller: Duplicate IP
address
Flashes rapidly
RED
Exception error: diagnostics via
Web or SNMP is no longer
possible
PN Ι MPI/DP
(optional)
Status display for
CP 1616 onboard
RED  Diagnostics information
available
 No communication established
OFF WATCHDOG not activated
GREEN WATCHDOG monitoring enabled
WATCHDOG WATCHDOG status
display
RED Monitoring time elapsed
OFF Internal temperature OK TEMP Internal temperature
monitoring RED Internal temperature critical
OFF Fan speed OK FAN Fan status (only with
active DiagBase or
DiagMonitor software) RED Fan speed too low
OFF RAID is OK
One RED HDD1, HDD2 or HDD3 not OK
All RED RAID not OK
(for information on locating the
faulty HDD, refer to the RAID
system section)
HDD1 ALARM
HDD2 ALARM
HDD3 ALARM
Hard disk alarm in
conjunction with RAID
and monitoring
software
All flashing RAID is synchronized
All displays are lit Error in early BIOS
Post
All lit CPU startup failure
Error in early POST
* For unique labeling, the LAN interfaces are numbered on the enclosure. The numbering by the
operating system may deviate from this.

Description
2.4 Status displays
SIMATIC IPC847C
Getting Started, 12/2010, A5E02669190-02 15
Rear status displays

/(' /('
Display Meaning LED Description
OFF  No cable connected
 Cable disabled
 Interface disabled, 10 MBit
cable active
GREEN 100 MBit cable active
Green LED
Link status display
ORANGE 1000 MBit cable active
OFF  No cable connected
 Cable disabled
 Interface disabled
 No activity
Ethernet LAN 1, 2 *
Yellow LED
Activity status display
YELLOW Data transfer active
OFF  No cable connected
 Cable disabled
 Interface disabled
Green LED
Link status display of
CP 1616 channel
GREEN Active cable connected
OFF  No cable connected
 Cable disabled
 Interface disabled
 No activity
PROFINET LAN X1,
P1, P2, P3 *
Yellow LED
Activity status display
of CP 1616 channel
YELLOW Data transfer active
* For unique labeling, the LAN and PROFINET interfaces are numbered on the housing. The
numbering by the operating system may deviate from this.
Virtual status displays
The two "virtual" CP 1616 LEDs are only visible in the SIMATIC software and can be read via SNMP.
RUN CP is active
STOP CP is in the stop state
PROFINET Virtual LEDs
Flashes The states "flashes slowly" or
"flashes rapidly" do not exist.

Description
2.4 Status displays
SIMATIC IPC847C
16 Getting Started, 12/2010, A5E02669190-02

SIMATIC IPC847C
Getting Started, 12/2010, A5E02669190-02 17
Application planning 3
3.1 Transport
Despite the device's rugged design, its internal components are sensitive to severe
vibrations or shock. You must therefore protect the PC from severe mechanical stress when
transporting it.
You should always use the original packaging for shipping and transporting the device.
CAUTION
Risk of damage to the device!
When transporting the PC in cold weather, it may be submitted to extreme variations in
temperature. In this situation, ensure that no moisture (condensation) develops on or inside
the device.
If condensation has developed on the device, wait at least 12 hours before you switch it on.
3.2 Unpacking and checking the delivery unit
Unpacking the device
Note the following points when you unpack the unit
● It is advisable not to dispose of the original packing material. Keep it in case you have to
transport the unit again.
● Please keep the documentation in a safe place. It is required for initial commissioning and
is part of the device.
● Check the delivery unit for any visible transport damage.
● Verify that the shipment contains the complete unit and your separately ordered
accessories. Please inform your local dealer of any disagreements or transport damage.
● Please inform Siemens AG by means of the enclosed SIMATIC IPC/PG quality control
report form.

Application planning
3.2 Unpacking and checking the delivery unit
SIMATIC IPC847C
18 Getting Started, 12/2010, A5E02669190-02
Noting down the device identification data
The device can be clearly identified with the help of this identification data in case of repairs
or theft.
Enter the following data in the table below:
● Serial number: The serial number (S VP) is located on the rating plate either on the rear
panel of the device or on the inside of the front door.
Figure 3-1 Rating plate
● Order number of the device
● Device Ethernet address: The Ethernet address is printed on the device and is stored in
the BIOS Setup (F2 key) under "Advanced > Peripheral Configuration".
● Microsoft Windows "Product Key" on the "Certificate of Authenticity" (COA). The COA
label is attached to the inside of the front door.
You may need the Product Key in case you reinstall the operating system.
Figure 3-2 COA label
Serial number: S VP ...
Order no. 6AGA114-1 ...
Microsoft Windows Product Key
Ethernet 1 address
Ethernet 2 address
CP 1616 onboard layer 2
Device equipment
The device equipment is listed on the inner side of the front door.

Application planning
3.3 Ambient and environmental conditions
SIMATIC IPC847C
Getting Started, 12/2010, A5E02669190-02 19
3.3 Ambient and environmental conditions
WARNING
If the following requirements for system installation are not observed, approvals to UL
60950-2, EN 60950-2 are rendered void and there is a risk of overheating and injury.
When you plan your project, you should make allowances for:
● Climatic and mechanical environmental conditions defined in the "General technical data"
chapter of the operating instructions.
● Avoid extreme ambient conditions as far as possible. Protect your device against dust,
moisture and heat.
● This device was designed for use in a normal industrial environment. SIMATIC Rack PCs
may not be operated in severe environments which are subject to caustic vapors or
gases without taking additional protective measures (such as the provision of clean air.)
● Do not expose the device to direct sunlight.
● Install the device in such a way that it poses no danger, for example, by falling over.
● The device conforms to protection class IP41 at the front panel. Ensure that the
installation opening for the device is splash-proof in areas which may be subject to splash
water.
● Always maintain a minimum clearance of 50 mm to the area of the ventilation slots in
order to ensure adequate ventilation of the PC.
● Do not cover the ventilation slots of the enclosure.
● The device meets requirements for fire protection housings to EN 60950-1 and can be
installed without additional fire protection enclosure.
● The connected or built-in peripherals should not introduce a counter emf in excess of
0.5 V into the device.
3.4 Access protection
The access protection of the rack PC is only enabled if the front door is locked.

Application planning
3.4 Access protection
SIMATIC IPC847C
20 Getting Started, 12/2010, A5E02669190-02
