Siemens 1FK7 01. User manual

Synchronous motors
1FK7 01. - 1FK7 10.
Instructions Edition 10/2007
Synchronmotoren
Moteurs synchrones
Motores sincrónicos
610.40 700.21
Motori sincroni

ENGLISH
2610.40 700.21 Siemens AG
CONTENTS
1 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 Product information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1 Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1 Rating plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4 Transport, Installation and Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.1 Transport, Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Electrical connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.1 Important instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.2 Plug design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.3 Motors with DRIVE-CLiQ interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6 Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.1 Checks before starting up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.2 Commissioning procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7 Instructions in case of faults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
8 Inspection, maintenance, disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

ENGLISH
Siemens AG 610.40 700.21 7
This manual contains notes which you should observe to ensure your own personal
safety, as well to protect the product and connected equipment. These notices are
highlighted in the manual by a warning triangle and are marked as follows to the level of
danger. They are shown as follows according to the degree of danger involved.
DANGER!
Pictogram
indicates an imminently hazardous situation which, if
not avoided by the appropriate precautionary
measures, will result in death, serious injury or
substantial material damage.
WARNING
Pictogram
indicates an imminently hazardous situation which, if
not avoided by the appropriate precautionary
measures, could result in death, serious injury or
substantial material damage.
CAUTION
Pictogram used with the safety alert symbol indicates a
potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
CAUTION
used without the safety alert symbol indicates a potentially
hazardous situation which, if not avoided, may result in damage to
property.
NOTICE
indicates a potential situation which, if not avoided, may result in an
undesirable result or state.

ENGLISH
8610.40 700.21 Siemens AG
Qualified Personnel
The device/system may only be set up and operated in conjunction with this manual. Only
qualified personnel should be allowed to install and work on the this equipment. Qualified
persons are defined as persons who are authorized to commission, to ground, and to bag
circuits, equipment, and systems in accordance with established safety practices and
standards.
Intended Usage
Please note the following:
This device and its components may only be used for the applications described in the
catalog or technical description, and only in connection with devices or components from
other manufacturers which have been approved or recommended by Siemens.
This product can only function correctly and safely if it is transported, stored, set up, and
installed correctly, and operated and maintained as recommended.
Disclaimer of Liability
We have checked the contents of this manual. Since deviations cannot be precluded
entirely, we cannot guarantee full agreement. However, the data in the manual are
reviewed regularly and any necessary corrections included in subsequent editions.
Suggestions for improvement are welcomed.
©Copyright Siemens AG 2007. All rights reserved
The reproduction, transmission or use of this document or its contents is not permitted
without express written authority. Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or
design, are reserved.
Siemens AG
Bereich Automatisierungs- und Antriebstechnik
Geschäftsgebiet Motion Control Systeme (MC)
D-97615 Bad Neustadt an der Saale

ENGLISH
Siemens AG 610.40 700.21 9
1 General safety instructions
The synchronous motors correspond to the harmonized standards of the EN 60034 and
EN 60204-1 and there is conformity with the 73/23/EEC Low Voltage Directive.
Standard motors conform to UL regulations. The rating plates of these motors are marked
with UR.
Ensure that your end product conforms to all currently valid legal requirements.
Follow the compulsory national, local and installation-specific regulations.
EU Manufacturer`s Declaration According to Article 4 Paragraph 2 of the
EU Directive 98/37/EU:
- The products supplied fulfill the requirements of standard EN 60204-1.
- The products supplied are intended exclusively for installation in a machine.
- Commissioning is prohibited it has until been established that the end product conforms
with the Directive 98/37/EU.
- All safety instructions in the associated product documentation must be observed and
given to the end user for his/her information.
- This declaration contains no condition and durability guarantee to § 443 BGB.
The operating manual applies in conjunction with the SIEMENS Configuration Manual, see
table.
Configuration Manual
All safety instructions must be observed during the transport, storage, assembly,
disassembly and operation of the synchronous motors!
Failure to observe the instructions can lead to serious personal injuries or property damage.
The motors’ rotors contain permanent magnets with high magnetic flux densities
which exert strong attractive forces on ferromagnetic bodies.
People fitted with a heart pacemaker are at risk in the vicinity of a disassembled rotor.
Data stored on electronic data media may be destroyed.
It is forbidden to use the motors in areas at risk of explosion, unless expressly stated.
Thermal hazards
The temperatures of motor surfaces can reach more than 100 °C (212 °F).
Do not touch hot surfaces!
Temperature-sensitive components (electric lines, electronic components) must not touch
hot surfaces.
Overheating in the motors may destroy the windings and bearings, and demagnetize the
permanent magnets.
Only operate the motors with effective temperature control.
Intended use
Usage for the intended purpose includes observing all the specifications in the operating
manual and the Configuration Manual "Synchronous motors“.
Code Titel Order No.
/PFK7S/ Synchronous motors 1FK7 for SINAMICS 6SN1197-0AD16-0BP1
/PFK7/ Synchronous motors 1FK7 for SIMODRIVE/MASTERDRIVES 6SN1197-0AD06-0BP1

ENGLISH
10 610.40 700.21 Siemens AG
2 Product information
2.1 Product description
Motors of 1FK7 series are permanent magnet excited, synchronous motors for operating
with indirect a.c. converters according to the sinusoidal current principle.
The motors are intended for driving and positioning machine tools, production machines,
robots and handling devices.
2.2 Scope of delivery
The drive systems are arranged individually. Immediately upon receipt of delivery, check
whether the scope of delivery corresponds with the consignment notes. SIEMENS cannot
accept any liability for any shortages or deficiencies reported at a later date.
Complaint instructions:
- Report detectable transport damage immediately to the carrier.
- Report detectable defects / incomplete delivery immediately to the responsible
SIEMENS representative.
The operating manual is part of the scope of delivery and shall therefore be kept in an
accessible place.
As the delivery includes a separate type plate, the motor data must also be kept on or near
the machine or system.

ENGLISH
Siemens AG 610.40 700.21 11
3 Technical data
3.1 Rating plate
Fig. 1 Rating plate
1 SIEMENS motor type / designation 11 Zero-speed current I0[A]
2 IID No., production number 12 Temperature class
3 Zero speed torque M0[Nm] 13 Degree of protection
4 Rated torque MN[Nm] 14 Encoder version
5 Encoder type 15 Bar code
6 Holding brake data: 16 Motor version
Type, voltage, power consumption 17 Motor weight m [kg]
7 Customer specifications 18 Balancing method marked
8 Standards and regulations 19 Rated speed nN[rpm]
9 Rated current IN[A] 20 Maximum speed nmax [rpm]
10 Induced voltage UIN [V] 21 Order options
The type plate is covered by a yellow protective foil for motors without paint finish. This foil
should be removed unless the motor will be painted over again.
+
PNJ
a0RWRU ).$)$%
1R<)31 ;;;;;
;;;;;
0
(QFRGHU,65
%UDNH('%%.9:
7K&O))
&
51
,
,
8
Q
Q
,3
(1
0DGHLQ*HUPDQ\








   







&
1P
0

1
,1
PD[
1

1
1P
$
$
9
PLQ
PLQ

ENGLISH
12 610.40 700.21 Siemens AG
3.2 Features
Types of construction (EN 60034-7) IM B5 (IM V1, IM V3)
Degree of protection (EN 60034-5) IP64 (1FK701.: IP54)
Cooling (EN 60034-6) Self-cooling
A-grade sound pressure level (EN 60034-9)
for speed range up to 3,000 rpm
1FK701. - 1FK704. approx. 55 dB(A)
1FK706. approx. 65 dB(A)
1FK708., 1FK710. approx. 70 dB(A)
Thermal motor protection (EN 60034-11) Temperature sensor KTY84
in the stator winding
Shaft end (DIN 748-3; IEC 60072-1) cylindrical; without keyway,
Tolerance range k6 (1FK701.: h6)
true running, coaxiality, axial run-out deviation Tolerance N
(DIN 42955; IEC 60072-1)
Oscillating quantity level (N 60034-14) level A (up to rated speed)
Bearing design Rolling contact bearing with permanent
grease lubrication (lifetime lubrication)
fixed bearing on non-drive end
Service life of bearing 20000 h (guideline)
Winding insulation (EN 60034-1) Temperature class 155 °C (311 °F) (F)
Ambient temperatures -15 °C to +40 °C (5 °F to 104 °F)
otherwise the rated data are reduced
(see Configuration Manual)
Installation altitude (EN 60034-1) up to 1000 m a.s.l,
otherwise the rated data are reduced
(see Configuration Manual)
Magnetic material Rare-earth material
Electrical connections Revolving plug for output and
encoder signals
Encoder system fitted encoder
- speed recording
- recording the rotor position
- indirect positional recording
Options/expansions
Low inertia series HD (High Dynamic)
Type of protection (EN 60034-5) IP65; additional drive end flange IP67
Fitted/mounted elements - closed current holding brake (DIN VDE 0580)
Supply voltage 24 V DC ±10%
- planetary gearing
Encoder system - incremental encoder sin/cos 1 VPP
- absolute value encoder EnDat
- simple, absolute value encoder
- resolver
Encoder system without
DRIVE-CLiQ Interface - I2048S/R = incremental encoder sin/cos 1 VPP 2048 S/R
- AM2048S/R = absolute value encoder EnDat
- AM512S/R = absolute value encoder EnDat
- AM32S/R = absolute value encoder EnDat
- AM16S/R = absolute value encoder EnDat
- resolver

ENGLISH
Siemens AG 610.40 700.21 13
Encoder system with
DRIVE-CLiQ Interface - I22DQ = incremental encoder 22 bit
- AM22DQ = absolute value encoder 22 bit Singleturn
+ 12 bit Multiturn
- AM20DQ = absolute value encoder 20 bit Singleturn
+ 12 bit Multiturn
- AM16DQ = absolute value encoder 16 bit Singleturn
+ 12 bit Multiturn
- AM15DQ = absolute value encoder 15 bit Singleturn
+ 12 bit Multiturn
- Resolver 15 bit
- Resolver 14 bit
Shaft end cylindrical with keyway and feather key;
(DIN 748-3; IEC 60072-1) Tolerance range k6 (balancing with half feather key)
You will find more technical details, e.g. motor dimensions, in the catalogs NC 60, NC 61,
D 21.1 or Configuration Manual.
4 Transport, Installation and Assembly
4.1 Transport, Storage
Observe the transport regulations applying in the country/countries concerned.
Use suitable load suspension devices for transport and assembly.
Use lifting eyes for transporting the motors where these are provided by the manufacturer.
Lifting tackle as per 98/37/EU Directive for Machines, Appendix I.
The motor weight is indicated on the rating plate.
Fig. 2 Lift and transport with suspension bands
WARNING
Danger during lifting and transporting procedures!
Improper handling, unsuitable or defective devices, tools etc. can
cause injuries and/or property damage.
Lifting devices, ground conveyors and lifting tackle must correspond
to the valid regulations.

ENGLISH
14 610.40 700.21 Siemens AG
The motors should be stored indoors in dry, low-dust and low-vibration (veff < 0,2 mm/s)
rooms. The motors should not be stored longer than two years at room temperature
(+5 °C to +40 °C) (41 °F to 104 °F) to retain the service life of the grease.
4.2 Installation
Fig. 3 Types of construction
- Take note of and observe the information on the rating plate and warning and informative
notices on the motor.
- Observe the permitted transverse and axial forces (see project planning instructions).
Axial forces are not permitted on motors with an integrated brake.
- Check for compliance with the conditions (e.g. temperature, site altitude) at the assembly
site (see Section 3.2).
- It is forbidden to use them in areas at risk of explosion.
- Remove all anti-corrosion agents from the shaft end (use commercially available
solvent).
- Ensure that waste heat is adequately dissipated.
It is recommended to maintain a clearance of 100 mm from adjacent parts on at least
three sides.
- Tighten the flanges equally, avoid distortions when tightening the fixing screws. Use
hexagon socket head cap screws, strength class at least 8.8.
- In the case of a vertical installation with the shaft end at the top, ensure that no fluid
penetrates into the upper bearing.
- Lifting eye-bolts which have been screwed in may be removed after the motor has been
installed.
- Turn the output elements by hand. If grinding noises occur, eliminate the cause or
contact the manufacturer.
- Please observe the tightening torques to be applied to the motor flange fastening screws:
Motor ISO 4762
screw
ISO 7092
washer
Tightening torque for screws (not for
electrical connections) in Nm
1FK701. M4 4 (d2 = 8) 2,2
1FK702. M5 5 (d2 = 9) 4
1FK703. M6 6 (d2 = 11) 8
1FK704. M6 6 (d2 = 11) 8
1FK706. M8 8 (d2 = 15) 20
1FK708. M10 10 (d2 = 18) 35
1FK710. M12 12 (d2 = 20) 60
IM B 5 IM V 1 IM V 3

ENGLISH
Siemens AG 610.40 700.21 15
Vibrations, balancing
Motors with a keyway are balanced by the manufacturer with a half feather key.
The site vibration response of the system is determined by the output elements, the
mounting conditions, the alignment, the installation and the effects of external vibrations.
This may cause a modification of the motor vibration values.
Output elements
Suitable devices should always be used to push on or pull off the output elements (e.g. the
coupler, gear wheel, belt pulley, Fig. 4).
- Use the tapped hole in the shaft end.
- Heat up the output elements if necessary.
- Use a shim to protect the centering in the shaft end when pulling output elements off.
- If necessary, fully balance the motor with the output elements according to ISO1940
Fig. 4 Pulling off and putting on output elements.
AShim (protects the centering in the shaft end)
5 Electrical connections
5.1 Important instructions
NOTICE
Do not strike the shaft or bearings of the motors.
Do not exceed the permissible axial and radial forces on the shaft end stated
in the configuration specification.
Axial forces are not permitted on motors with an integrated brake.
DANGER!
Electric shock hazard!
When the rotor is rotating, the motor terminals carry a voltage of
up to approx. 300 V.
Stop the motor before commencing any electrical work.
Only use trained, qualified personnel for assembly work on the
converters and plugs.
Observe the regulations for working in electrotechnical plants.
Do not plug or unplug any connectors unless they are in a de-
energized condition.
A

ENGLISH
16 610.40 700.21 Siemens AG
Safety rules for working in electrical installations as per
EN 50110-1 (DIN VDE 0105-100):
- Work always with the equipment electrically dead.
- Isolate from electrical supply.
- Secure against switching on again.
- Check electrical deadness.
- Earth and short-circuit.
- Cover or cordon off adjacent parts which are electrically live.
- Release for work.
- Connect the PE conductor to
Assembly requirements
Pre-assembled cables from SIEMENS are recommended (not included in scope of delivery).
These cables reduce the assembly time and increase operational safety (see project
planning instructions).
- Proper installation is the responsibility of the manufacturer of the system / machine.
- Observe the data on the type plate (Section 3.1)and the information in the wiring
diagrams (Fig. 5).
- Connecting leads must be suitable for the type of application and for the anticipated
currents and voltages.
- If the motor is supplied by means of converters, high-frequency current and voltage
harmonics in the motor supply leads can cause electromagnetic interference to be
emitted.
Use shielded power and signal lines.
Observe the EMC instructions of the converter manufacturer.
- The inside of the plug must be kept clean and free from cable residues and moisture.
- Avoid protruding wire ends.
- Check the seals and sealing surfaces of plug to ensure that the degree of protection is
maintained.
- The connecting leads are to be equipped with the strain relief device and the devices
which protect against rotation and transverse forces, and must be prevented from
kinking. The plugs must not be subjected to continuous forces.
- The coding slot on the plug connector must be aligned when inserted into the female
connector in each case, and the union nut tightened up to the stop by hand.
The protective function with a fitted temperature sensor is inadequate for high thermal loads,
e.g. overload with the motor at a standstill. Additional protective measures are to be provided
for such cases, e.g. a i²t monitoring.
CAUTION
Warning of motor damage!
Connecting the motor directly to a three-phase system will destroy it.
Motors may only be driven with configured converters!
Ensure that the phase sequence is correct.
Encoder systems and temperature sensor contain electrostatically
endangered components (EEC).
Do not touch the connections with your hands or tools which could be
electrostatically charged!

ENGLISH
Siemens AG 610.40 700.21 17
5.2 Plug design
Fig. 5 Connection configurations and pin assignment of the connectors
Signal connections
Power connections
1FK702. - 1FK71001FK701. 1FK7101 / 1FK7103 / 1FK7105
Resolver Incremental Encoder sin/cos 1 Vpp
L1 L2 L3
3
3
UVW
U2 V2 W2
Supply
Motor
Connector size 1Connector size 0.5 Connector size 1.5
Encoder
UVW
3
M
Motor
Brake
Absolute Encoder
VBD1
+
BD2
-
WU
GNYE
BD1
+
BD2
-
V
W
U
GNYE
BD1
+
BD2
-
V
W
U
GNYE
BD1
+
BD2
-
1FK702. - 1FK710. size 1
1FK701. size 0.5
S1
not
connected
not
conn.
R2
S3
+1R1
-1R2
S2
R1
S4
not
conn.
not
conn.
+1R1 -1R2
not
conn.
S1
S3
not
conn.
not
conn.
S2
S4
not
conn.
not connected
R1
R2
not conn.
not
conn.
not
conn.
not conn.
RR*
B
B*
A
C
A*
M-Encoder
M-Encoder
P-Encoder P-Encoder
+1R1 +1R1
C-
-1R2 -1R2
not conn.
DD*
P Sense
data data*
B
B*
A
not conn.
A*
not connected
not conn.
clock*
clock
C
A
B*
A*
RD*
C*
D
+1R1
not
connected
-1R2
P Sense
B
R*
clock
A
B*
A*
data
clock*
M Sense
+1R1
not connected
-1R2
P Sense
B
data*
P Sense
M Sense
not connected
not conn.
M-
Encoder
M-
Encoder
P-Encoder
P-
Encoder
M Sense
M Sense

ENGLISH
18 610.40 700.21 Siemens AG
Power plug
1. Use plug size 0.5 / 1 or 1.5.
2. Assign the plugs according to figure Fig. 5 Connect the PE conductor.
3. Connect the brake via Fig. 5 the power plug. The polarity must be carefully observed.
Signal plug for the encoder system and temperature sensor.
1. Use an appropriate plug.
2. Assign the plugs according to Fig. 5.
PPower plug SSignal plug
Fig. 6 Degree of rotation of plugs
A suitable socket plug may be used for twisting the right-angle plug. Unscrew to open the
socket plug completely and avoid any damage to the pin contacts.
Maximum permissible twisting moments Mmax
WARNING
Improper change of the plug output direction leads to damage to
the connecting cables.
Do not exceed the permissible twisting moments as per Fig. 6.
A maximum of ten changes to the plug output direction are
permissible up to the stop with the attached, matching, mating
plug.
Plug Motor Plug size Mmax
Power plug
1FK701. 0.5 Mmax = 5 Nm
1FK702. - 1FK7100 1 Mmax = 12 Nm
1FK7101 - 1FK7105 1.5 Mmax = 20 Nm
Signal plug 1FK7. Mmax = 12 Nm
90°
180°
270°
270°
SP

ENGLISH
Siemens AG 610.40 700.21 19
5.3 Motors with DRIVE-CLiQ interface
Motors for the SINAMICS S120 drive system are equipped with a sensor module (electronic
module) which contains the encoder and temperature evaluation and an electronic rating
plate. This sensor module is mounted instead of the signal connector, and has a 10-pole
RJ45plus socket that is known as the DRIVE-CLiQ interface. The pin assignment is
independent of the encoder inside the motor.
Fig. 7 Motor with sensor modul (example)
The signal link between motor and converter is made by a DRIVE-CLiQ cable MOTION-
CONNECT. Only SIEMENS pre-assembled cables may be used. These cables reduce the
assembly time and increase operational safety.
The plug of the DRIVE-CLiQ cable must be pushed on until the catch springs slot in, pay
attention to the plug coding.
WARNING
The motor must not be lifted or transported by the sensor module.
CAUTION
The sensor module has direct contact to electrostatically sensitive devices
(ESD). Do not touch the connections with your hands or tools which could be
electrostatically charged!

ENGLISH
20 610.40 700.21 Siemens AG
Fig. 8 Pin assignment of DRIVE-CLiQ
Cable outlet direction
The sensor module is mounted on the motor instead of the signal connector. It can be turned
through about 270° or 180°. The turning range is shown in the following illustrations. The
typical twisting torque is 4...8 Nm. The sensor module may only be turned by hand. Pipe
wrenches, hammers and the like must not be used.
6 Commissioning
CAUTION
Improper change of the cable output direction leads to damage to the
connecting cables. The permissible twisting range must not be exceeded.
Only a maximum of ten changes to the rotational angle of the sensor module
are permitted within the rotational range.
CAUTION
Thermal hazard from hot surfaces!
The temperatures of motor surfaces can reach more than
100 °C (212 °F). Do not touch hot surfaces!
Protection must be provided against accidental contact if
necessary. Temperature-sensitive components (electric lines,
electronic components) must not touch hot surfaces.
SLQ,QSXW
(QFRGHU
'5,9(&/L4,QWHUIDFH
5
5
:+
%1
-
.7<

5-B5;1


09


5-B;53
5-B7;1
5-B7;3
39

ENGLISH
Siemens AG 610.40 700.21 21
6.1 Checks before starting up
Before starting up, ensure that
- all connections have been properly made, and the plug connectors are secured against
working loose.
- all motor protection devices are active,
- the drive is not blocked,
- no other possible sources of danger are present,
- the drive is undamaged (no damage from transport/storage),
- the feather keys in the shaft end (if present) are secured against being thrown out.
6.2 Commissioning procedure
Observe the start up and commissioning instructions for the converter (e.g. SIMODRIVE,
MASTERDRIVES MC, SINAMICS).
1. Release brake, in as far as this is necessary.
2. Check the brake function (open and close).
Apply 24 V DC ±10% to the pins +BD1, -BD2 (Fig. 5), and ensure that the rotor is
running freely (no rubbing noises).
3. Check the mounting, seating and alignment of the motor.
4. Check the suitability and setting of the output elements for the intended conditions of
use, for example belt tension.
5. Check the power and signal plug connections.
6. Check the functional condition of the auxiliary devices present.
7. Check the protection against accidental contact with moving and live parts.
8. Bring the drive system into operation in accordance with the operating manual for the
converter or inverse rectifier.
9. Check that the maximum permissible speed nmax is observed (see type plate for
details). The maximum permissible speed is the highest permissible, short-term
operating speed.
10. The fitted temperature sensor cannot cater for all possible faults (note the instructions
in the Configuration Manual).
WARNING
Hazard from rotating rotor!
Protect the output elements against accidental contact!
Secure feather key (if present) against being thrown out.
NOTICE
The brake is designed as a holding brake. Emergency stops are permitted;
see project planning instructions.
It is not permitted to be used as a working brake.

ENGLISH
22 610.40 700.21 Siemens AG
7 Instructions in case of faults
In case of deviation from normal operation or faults, proceed first according to the following
list:
In this connection, please also refer to the relevant section of the operating manual for the
components of the entire drive system.
Do not disable the protective devices, even in trial operation.
Consult the manufacturer or the SIEMENS service center when necessary.
For start up, system motor converter: A&D Hotline [phone]
For motor / motor components: Contact in the works [phone]
Fault Cause Remedy
Irregular running Inadequate screening of the
motor or encoder cable.
Check screening and grounding (see
Section 5.1)
Amplification of the drive control-
ler too high
Adjust controller (see converter operat-
ing manual)
Vibrations Coupling elements or driven
machine are badly balanced
Rebalance
Inadequate alignment of the drive
train
Realign the machine set
Fixing screws are loose Check and tighten screw connections
Running noises Foreign bodies inside the motor Repair by the manufacturer
Bearing damage Repair by the manufacturer
Motor overheats
(surface temperature
> 140 °C (284 °F))
Temperature monitoring
responds
Drive overloaded Check load (see type plate)
Heat dissipation impaired by
deposits
Clean surface of drives.
Ensure that the cooling air can flow
freely in and out

ENGLISH
Siemens AG 610.40 700.21 23
8 Inspection, maintenance, disposal
Clean according to the degree of local contamination in order to ensure that the waste heat
is adequately dissipated.
As the operating conditions vary greatly, one can only cite general intervals for fault-free
operation.
Also replace the encoders whenever the motor ball bearings are replaced as the encoder
bearings wear out too.
Guidelines:
- Bearing service life 25 000 hours
- Radial shaft seals approx. 10 000 hours with oil lubrication.
Motors must be disposed of carefully taking into account domestic and local regulations in
the normal recycling process or by returning to the manufacturer.
The following must be taken into account when disposing of the motor:
- Oil according to the regulations for disposing of old oil
- Not mixed with solvents, cold cleaning agents of remains of paint
- Components that are to be recycled should be separated according to:
-. Electronics waste (e.g. sensor electronics, sensor modules)
-. Iron to be recycled
-. Aluminum
-. Non-ferrous metal (gearwheels, motor windings)
WARNING
Motor servicing is prohibited unless performed by an approved service work-
shop.

ENGLISH
24 610.40 700.21 Siemens AG
