Siemens Simogear BA 2331 Quick guide

BA 2331
SIMOGEAR
Geared motor with DRIVE-CLiQ
rotary encoder
BA 2331
Operating Instructions
Supplement to SIMOGEAR Operating Instructions
BA
2030 and BA 2330
07/2021
A5E50553480A/RS
-AB
General information and
safety instructions
1
Installation of the rotary
encoder
2
Ensuring functional safety
3
Technical specifications
4
Disposal
5

Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E50553480A/RS-AB
Ⓟ
09/2021 Subject to change
Copyright © Siemens AG 2020 - 2021.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

BA 2331
Operating Instructions, 07/2021, A5E50553480A/RS-AB 3
Table of contents
1 General information and safety instructions ........................................................................................ 5
1.1 General information ............................................................................................................ 5
1.2 Copyright ............................................................................................................................ 7
1.3 Intended use ....................................................................................................................... 7
1.4 Encoder systems with DRIVE-CLiQ interface.......................................................................... 9
1.5 Handling electrostatic sensitive devices (ESD)..................................................................... 10
2 Installation of the rotary encoder........................................................................................................ 11
2.1 Electrical installation of the encoder................................................................................... 11
2.2 Motors with encoder with DRIVE-CLiQ interface.................................................................. 11
2.3 Design of the signal plug connector ................................................................................... 12
2.4 Connecting to a converter.................................................................................................. 12
2.4.1 Connecting to a converter.................................................................................................. 12
2.4.2 Signal lines for motors with DRIVE-CLiQ encoder ................................................................ 13
3 Ensuring functional safety .................................................................................................................. 15
3.1 Fundamental safety instructions for Safety Integrated ........................................................ 15
3.2 General information .......................................................................................................... 17
3.3 Unpacking ......................................................................................................................... 19
3.4 Commissioning the DRIVE-CLiQ rotary encoder................................................................... 20
4 Technical specifications....................................................................................................................... 23
4.1 General technical specifications ......................................................................................... 23
4.2 Type designation of the geared motor................................................................................ 24
4.3 Technical specifications of the brake for encoders for functional safety............................... 25
5 Disposal ............................................................................................................................................... 27

Table of contents
BA 2331
4Operating Instructions, 07/2021, A5E50553480A/RS-AB

BA 2331
Operating Instructions, 07/2021, A5E50553480A/RS-AB 5
General information and safety instructions
1
1.1 General information
Note
Siemens
AG does not accept any liability for damage and operational disturbances that result
from the non-observance of these operating instructions.
Note
European RoHS directive
SIMOGEAR geared motors comply with the stipulations laid down in Directive 2011/65/EU
regarding the restriction in the use of certain hazardous substances.
These operating instructions are included with the geared motor when delivered. Keep the
operating instructions close to the geared motor. Please read the operating instructions prior
to handling the geared motor and observe the information they contain. This way you will
ensure safe and disturbance-free operation.
These operating instructions apply to the DRIVE-CLiQ rotary encoders in table 1-1, which are
mounted on the SIMOGEAR geared motor. The DRIVE-CLiQ rotary encoders with options
Q20 - Q23 are in compliance with the relevant standards listed in the Declaration of
Conformity. Furthermore, the DRIVE-CLiQ rotary encoders with Q22 and Q23 options, which
are mounted on SIMOGEAR geared motors together with the SINAMICS S120, comply with
the relevant standards for safety-related applications listed in the Declaration of Conformity.
The BA 2331 Operating Instructions supplement the following operating instructions:
•BA 2030 SIMOGEAR gearboxes
The operating instructions apply to the standard version of SIMOGEAR gearboxes
•BA 2330 Motors LA/LE/LES for mounting on SIMOGEAR gearboxes
The operating instructions apply to the standard version of the motors for mounting on
the SIMOGEAR gearbox series
For the safety-relevant encoder evaluation, refer to the documentation of the
SINAMICS S120:
•SINAMICS S120 Commissioning Manual
•SINAMICS S120 Getting Started
•SINAMICS S120 Drive Functions Function Manual

General information and safety instructions
1.1 General information
BA 2331
6Operating Instructions, 07/2021, A5E50553480A/RS-AB
•SINAMICS S120 Safety Integrated Function Manual
•SINAMICS S120 / S150 List Manual
•EMC Installation Guideline Configuration Manual (6FC5297-0AD30-0AP3)
Information about SIMOGEAR geared motors with DRIVE-CLiQ rotary encoders and the
following topics is provided in BA 2331:
•Intended use
•Ensuring functional safety
•Pin assignment for the DRIVE-CLiQ rotary encoder
•Checklist for commissioning the DRIVE-CLiQ rotary encoder
•Technical specifications for the motor and the brake
Table 1- 1 Article number code
Article number position Z
Order code of the special
version
Rotary encoder Safety Integrated Description
Q20
AS22DQC
No
Rotary encoder AS22DQC
Absolute encoder 22-bit
single-turn
Q21
AM22DQC
No
Rotary encoder AM22DQC
Absolute encoder 22-bit +
12-bit multiturn
Q22
AS22DQC
Yes
Functionally safe rotary
encoder AS22DQC
Absolute encoder 22-bit
single-turn
Q23
AM22DQC
Yes
Functionally safe rotary
encoder AM22DQC
Absolute encoder 22-bit +
12-bit multiturn
The geared motors described here correspond to state-of-the-art technology at the time these
operating instructions were printed.
Siemens AG reserves the right to change individual components and accessory parts in the
interest of further development. The changes are designed to improve performance and
safety. The significant features are retained. The operating instructions are updated regularly.
The latest version of the operating instructions, the declaration of incorporation and the
declarations of conformity are available in electronic form in the Industry Online Support
(https://support.industry.siemens.com/cs/ww/en/ps/13424/man).

General information and safety instructions
1.2 Copyright
BA 2331
Operating Instructions, 07/2021, A5E50553480A/RS-AB 7
You can find technical configuration data, spare parts lists and certificates of compliance on
the intranet at Once Delivered (https://c0p.siemens.com:8443/sie/1nce_delivered).
You can find the contact data of your Technical Support in the Database of contacts at
Siemens AG (www.siemens.com/yourcontact).
If you have any technical questions, please contact Technical Support
(https://support.industry.siemens.com/cs/ww/en/sc/2090).
Europe and Africa
Telephone: [phone]
[e-mail]
America
Telephone: [phone]
support.america.[email protected]
Asia / Australia / Pacific
Telephone: [phone]
support.asia.automati[email protected]
1.2 Copyright
The copyright to these operating instructions is held by Siemens AG.
These operating instructions must not be wholly or partly reproduced for competitive
purposes, used in any unauthorized way or made available to third parties without
agreement of Siemens AG.
1.3 Intended use
The geared motor complies with the requirements of the Machinery Directive 2006/42/EC.
The geared motor is certified for use at an installation altitude up to 1 000 m above sea level.
The DRIVE-CLiQ rotary encoder is certified for ambient temperatures from -30 °C to +50 °C at
the encoder flange, for simultaneous use of the motors according to temperature
class 155 (F) as a maximum.
The DRIVE-CLiQ rotary encoder is suitable for degrees of protection ≤IP66.
The motor is certified for vibrations and impact shocks according to EN 60721-3-3:1995, up
to and including Class 3M3.
The anti-condensation heating may only be used at standstill.

General information and safety instructions
1.3 Intended use
BA 2331
8Operating Instructions, 07/2021, A5E50553480A/RS-AB
Supplements for the DRIVE-CLiQ encoders for safety applications (order codes Q22 and
Q23)
The SIMOGEAR geared motor with DRIVE-CLiQ rotary encoder has a signal yellow marking on
the fan cover. The marking SI04 for the DRIVE-CLiQ rotary encoder is stated on the rating
plate.
Figure 1-1 Marking for functional safety
The encoder is mounted in compliance with the relevant standards listed in the Declaration of
Conformity for safety-relevant applications. Observe the notes in Chapter Ensuring functional
safety (Page 15). Siemens AG does not accept any liability for injury or damage resulting from
non-observance of these operating instructions.
The DRIVE-CLiQ rotary encoder is suitable for
use in the following environments
The DRIVE-CLiQ rotary encoder is not suitable
for use in the following environments
Safety-relevant systems up to
•SIL2 / SIL3 acc. to EN 61800-5-2
•PLd / PLe acc. to EN ISO 13849-1 and
EN ISO 13849-2
Use in hazardous areas
Typical industrial environment
e.g. indoor installation for conveyor technology
Harsh industrial environments
e.g. offshore or the chemical industry
Conditionally in port installations
Areas with direct exposure to seawater
or splash seawater
The geared motor with DRIVE-CLiQ rotary encoder is only safe for use with a suitable encoder
evaluation unit on the SINAMICS S120 and corresponding safety settings (for details, please
refer to the SINAMICS S120 documentation) and activated motor protection evaluation.
The DRIVE-CLiQ rotary encoder is designed for a maximum input speed (motor speed) of
4500 rpm.
The DRIVE-CLiQ rotary encoder is designed for a maximum angular acceleration of the motor
of 4000 rad/s2.

General information and safety instructions
1.4 Encoder systems with DRIVE-CLiQ interface
BA 2331
Operating Instructions, 07/2021, A5E50553480A/RS-AB 9
An existing brake is only to be used as a holding brake with emergency stop function (≤2000
emergency stops during service life). Calculation of the number of permissible emergency
stops must be performed in the configuration.
The geared motors are designed and built according to state-of-the-art technology and are
shipped in an operationally safe condition. Changes made by users negatively impact
operational reliability and are forbidden.
The geared motor is designed for installation in a machine. The company operating the
machine is responsible for complying with functional safety. The person marketing or
operating the machine is responsible for the necessary safety functions and their attributes.
1.4 Encoder systems with DRIVE-CLiQ interface
Motors with a DRIVE-CLiQ encoder interface are provided for the SINAMICS S120 converter
system. Signal transmission to the converter is performed digitally. The DRIVE-CLiQ rotary
encoder has an electronic rating plate that simplifies commissioning and diagnostics. The
motor and encoder system are automatically identified and all motor parameters are
automatically set; see SINAMICS Equipment Manual.
NOTICE
Activation of thermal motor protection (Pt-1000)
SIMOGEAR geared motors feature a motor protection system that must be connected
directly to the converter system and is not evaluated via the DRIVE-CLiQ interface of the
encoder.
The temperature sensor on the SINAMICS S120 must be connected by the commissioning
engineer.

General information and safety instructions
1.5 Handling electrostatic sensitive devices (ESD)
BA 2331
10 Operating Instructions, 07/2021, A5E50553480A/RS-AB
1.5 Handling electrostatic sensitive devices (ESD)
Electrostatic sensitive devices (ESD) are individual components, integrated circuits, modules
or devices that can be damaged by either electrostatic fields or electrostatic discharge.
NOTICE
Damage caused by electric fields or electrostatic discharge
Electric fields or electrostatic discharge can cause malfunctions as a result of damaged
individual components, integrated circuits, modules or devices.
•Only pack, store, transport and send electronic components, modules or devices in their
original packaging or in other suitable materials, e.g. conductive foam rubber of
aluminum foil.
•Touch components, modules and devices only if you are grounded by wearing an ESD
bracelet, by wearing ESD shoes, or by means of ESD grounding strips in ESD areas with a
conductive floor.
•Only place electronic components, modules or devices on conductive surfaces (table
with ESD surface, conductive ESD foam, ESD packaging, ESD transport container).

BA 2331
Operating Instructions, 07/2021, A5E50553480A/RS-AB 11
Installation of the rotary encoder
2
2.1 Electrical installation of the encoder
WARNING
Premature damage or destruction of the rotary encoder
Electrostatic discharge can cause the rotary encoder to fail.
Do not touch the connector pins.
Do not exceed the following tolerances regarding the motor supply voltage according to
EN 60034-1 Range A.
•Voltage ±5%
•Frequency ±2%
Refer to the SINAMICS S120 documentation especially regarding the following topics:
•Functional safety engineering
•Electrical installation, EMC and general notes
•Data transfer to an encoder evaluation unit
Also note the information in the Configuration Manual of the EMC installation guideline
(6FC5297-0AD30-0AP3).
2.2 Motors with encoder with DRIVE-CLiQ interface
NOTICE
Damage to electrostatic sensitive devices
The DRIVE-CLiQ interface has direct contact to electrostatic sensitive devices (ESD). Encoder
systems and temperature sensors are electrostatically sensitive devices.
Electrostatically sensitive devices can be damaged if you touch the connections with your
hands or with electrostatically charged tools.
•
Observe the Handling electrostatic sensitive devices (ESD) (Page 10).
DRIVE-CLiQ rotary encoders for the SINAMICS drive system are equipped with an internal
module that includes an electronic rating plate. The DRIVE-CLiQ rotary encoder features a
built-in sensor module. The DRIVE-CLiQ rotary encoder is equipped with a 1 m cable with
flange socket. The flange socket has a SPEED-CONNECT-READY male thread M17 with O-ring.
This is referred to as the DRIVE-CLiQ interface.

Installation of the rotary encoder
2.3 Design of the signal plug connector
BA 2331
12 Operating Instructions, 07/2021, A5E50553480A/RS-AB
The signal connection between the motor and the Motor Module is established via a pre-
assembled MOTION-CONNECT DRIVE-CLiQ cable.
2.3 Design of the signal plug connector
M17 signal plug connector with DRIVE-CLiQ
1
TX-P
2
TX-N
3
-
4
-
5
RX-P
6
RX-N
7
-
8
-
9
24 V
10
0 V
2.4 Connecting to a converter
2.4.1 Connecting to a converter
•Use pre-assembled MOTION-CONNECT cables from SIEMENS.
•Pre-assembled MOTION-CONNECT cables reduce installation time and costs and increase
operational reliability.

Installation of the rotary encoder
2.4 Connecting to a converter
BA 2331
Operating Instructions, 07/2021, A5E50553480A/RS-AB 13
Note
The cable shieldi
ng, made up of as many strands as possible, must have a high electrical
conductivity. Braided shields made of copper or aluminum are well suited.
2.4.2 Signal lines for motors with DRIVE-CLiQ encoder
Use pre-assembled MOTION-CONNECT cables to connect motors with a DRIVE-CLiQ interface.
You will find detailed information in the printed or online version of the Catalog D 21.4 in
Chapter "SIMOTICS Servomotors"
(https://support.industry.siemens.com/cs/document/109747019/).

Installation of the rotary encoder
2.4 Connecting to a converter
BA 2331
14 Operating Instructions, 07/2021, A5E50553480A/RS-AB

BA 2331
Operating Instructions, 07/2021, A5E50553480A/RS-AB 15
Ensuring functional safety
3
WARNING
Inadequately qualified personnel
If the rotary encoder is electrically installed by inadequately qualified personnel, the
functional safety could be disabled.
Only qualified personnel are authorized to carry out the work.
Such personnel must be trained in:
•Topics relating to functional safety
•Legislation, safety regulations and standards for functional safety
•
The content of the detailed operating instructions provided
3.1 Fundamental safety instructions for Safety Integrated
DANGER
Risk minimization through Safety Integrated
Safety Integrated can be used to minimize the level of risk associated with machines and
plants.
Machines or plants, however, can only be operated safely in conjunction with Safety
Integrated if the machine manufacturer
•is familiar with and observes all aspects of this technical user documentation, including
the documented constraints, safety instructions and residual risks,
•carefully installs and configures the machine or plant and verifies this through an
acceptance test carefully performed and documented by qualified personnel,
•implements and validates all the measures required by the machine or plant risk analysis
based on the programmed and configured Safety Integrated Functions or by other
means.
The deployment of Safety Integrated does not replace the machine or plant risk assessment
by the machine manufacturer as stipulated by the EU Machinery Directive.
In addition to deploying Safety Integrated Functions, further risk reduction measures must
be implemented.

Ensuring functional safety
3.1 Fundamental safety instructions for Safety Integrated
BA 2331
16 Operating Instructions, 07/2021, A5E50553480A/RS-AB
WARNING
Unexpected movement of machines caused by inactive safety functions
Inactive or unadjusted safety functions can trigger unexpected machine movements that
may result in serious injury or death.
•Observe the information in the appropriate product documentation before
commissioning.
•Carry out a safety inspection for safety-relevant functions on the entire system, including
all safety-related components.
•Ensure that the safety functions used in your automation and drive tasks are adjusted
and activated through appropriate assignment of parameters.
•Run a function test.
•Only put your plant into live operation once you have ensured that the safety-relevant
functions are running correctly.
WARNING
Danger to life as a result of undesirable motor motion
Danger to life as a result of undesirable motor motion when the system runs up and the
drives are activated after modifying or replacing hardware and/or software.
After hardware and/or software components have been modified or replaced, it is only
permissible for the system to run up and the drive to be activated with the protective
devices closed. Personnel must not be present within the danger zone.
•It may be necessary to carry out a partial or complete acceptance test or a simplified
functional test depending on the modification or replacement.
•Before personnel are allowed to re-enter the hazardous area, all of the drives should be
tested to ensure that they exhibit stable control behavior by briefly moving them in both
the plus and minus directions (+/-).
•When switching on, observe the following:
The Safety Integrated Functions are only available and can only be selected after the
system has completely powered up.

Ensuring functional safety
3.2 General information
BA 2331
Operating Instructions, 07/2021, A5E50553480A/RS-AB 17
3.2 General information
The functional safety complies with the relevant standards listed in the Declaration of
Conformity for safety-relevant applications.
WARNING
Non-compliance with warning information
The functional safety can be disabled if you do not observe the warning information and
notes.
Comply with the valid regulations and operating instructions.
WARNING
Non-observance of intended use
The functional safety can be disabled if you do not observe the information regarding
correct usage.
Comply with the information regarding correct usage.
WARNING
Functional safety without conformity assessment
The geared motor is designed for installation in a machine. The operating company is
responsible for defining the safety level and its actual implementation in the machine.
Evaluate the conformity of the machine before commissioning.
WARNING
Functional safety with a motor that is not intended for the purpose
It is not permitted to retrofit the DRIVE-CLiQ rotary encoder.
The DRIVE-CLiQ rotary encoder is mounted on a SIMOGEAR geared motor with the
appropriate version. The geared motor with DRIVE-CLiQ rotary encoder must be ordered in
this particular version and must not be retrofitted by the user, as this could jeopardize
functional safety.
WARNING
Functional safety without safety-relevant encoder evaluation
The DRIVE-CLiQ rotary encoder is only safe in conjunction with a suitable SINAMICS S120.
Use the DRIVE-CLiQ rotary encoder together with a safety-
relevant rotary encoder evaluation
unit. Observe the requirements relating to suitable, safety-relevant encoder evaluation in
the documentation.

Ensuring functional safety
3.2 General information
BA 2331
18 Operating Instructions, 07/2021, A5E50553480A/RS-AB
WARNING
Functional safety without motor protection evaluation
The motor with functionally safe rotary encoder is equipped with thermal motor protection,
which must be evaluated.
Use the geared motor with motor protection evaluation.
WARNING
Resonance effects in operation
Resonance effects can occur on the geared motor as a result of the frequency converter or
comparable power controlling devices.
Resonance effects must be excluded.
Optimize, for example, the control parameters through an appropriate setpoint filtering.
Siemens AG takes responsibility for compliance with functional safety specifications relating
to the supplied geared motor with DRIVE-CLiQ rotary encoder and SINAMICS S120. The
safety-relevant connection elements are sealed before delivery.
Take into account the applicable national and regional legislation, standards and regulations.
If a geared motor with a DRIVE-CLiQ rotary encoder is used for safety-relevant applications
together with a brake, lower maximum permissible air gaps for the brake apply than for
standard applications, see Technical specifications of the brake for encoders for functional
safety (Page 25).
To ensure that the geared motor is not damaged:
•Do not step on the geared motor.
•Do not place any objects on the geared motor.
•Do not place the geared motor down on the fan cover.
Working on the rotary encoder and the brake
All safety-related mechanical connections for the rotary encoder or the brake are marked with
a seal (enamel dot).
Only Siemens service personnel or personnel trained and authorized by Siemens are
permitted to carry out the work.
