Siemens SIMATIC IOT User manual

5
4
1
3
2
6
1
1.1
Expand device
Gerät erweitern
3
3.1 Install Arduino shield – Arduino-Shield einbauen
3.2 Remove the top housing
RESTREST
Customize the shield cover according to the arduino shield.
2
3
Die Schutzabdeckung entsprechend dem Arduino Shield anpassen.
1.2
1.3
1.4 Mounting the device – Gerät anbauen
1.4
2.1
2.2
2.3
Mounting the device – Gerät anbauen
40 °C
0 °C
40 °C
0 °C
45 °C
0 °C
50 °C
0 °C
Click!
4
1
Connecting the function earth – Anschließen der Funktionserde
Connecting the power supply – Stromversorgung anschließen
Switching on the device –
Before mounting and commissioning – Vor Einbau und Inbetriebnahme
Mounting the device
Gerät einbauen
WICHTIG: Beachten Sie alle dem Gerät beiliegenden Dokumente und die Betriebsanleitung, bevor
Sie das Gerät einbauen und anschließen. Die vollständige Dokumentation des Geräts finden Sie im
Internet http://www.siemens.de/simatic-ipc-doku-portal
IMPORTANT: observe all documents enclosed with the device and the operating instructions manual
before mounting and connecting the device. You find the complete documentation of the internet
http://www.siemens.com/simatic-ipc-doku-portal
Das Handbuchsymbol weist auf detaillierte Informationen in der Betriebsanleitung hin.
The manual symbol refers to detailed information in the operating instructions.
Valid Mounting positions – Zulässige Einbaulagen
Scope of delivery – Lieferumfang
Horizontal/horizontal
One SIMATIC IOT device, one terminal connector, one mounting accessory kit including one mounting
clamp, two mounting brackets and screws. No accessories such as Micro SD card and cables.
Beachten Sie beim Einsatz im Bereich Industrial Control Equipment entsprechend UL61010‑2‑201,
dass das Gerät als "Open Equipment" klassifiziert ist. Voraussetzung für die Zulassung bzw.
den Betrieb nach UL61010‑2‑201 ist deshalb der Einbau des Geräts in ein der UL61010‑2‑201
entsprechendes Gehäuse.
When the device is used in the area of Industrial Control Equipment in accordance with
UL61010‑2‑201, note that the device is classified as "Open Equipment
". A UL61010‑2‑201 conform
enclosure is therefore a mandatory requirement for approval or operation according to
UL61010‑2‑201.
Free space required around the device - Erforderlicher Freiraum um das Gerät
50 mm
50 mm
Vertical mounting on DIN rails / vertikale Hutschienenmontage
2
2
1
1
3
3
Click!
4
Horizontal mounting on DIN rails / horizontale Hutschienenmontage
Vertical wall mounting / vertikale Wandmontage
Horizontal wall mounting / horizontale Wandmontage
Connecting the device
Gerät anschließen
2
50 mm
50 mm
33
2
1
RESTREST
3
11 22
M4
2.5 mm²
T20
2
1
Das Gerät darf nur an eine DC 12...24-V‑Stromversorgung angeschlossen werden, die den Anforde-
rungen einer sicheren Kleinspannung (SELV) gemäß der IEC/EN/DINEN/UL 61010‑1 entspricht.
Gibt es Spannungsspitzen auf den Stromversorgungsleitungen, dann verwenden Sie eine
Schutzeinrichtung in Form eines Varistors
(MOV) UMOV = Urated x 1.2 (BLITZDUCTOR BVT AVD 24 (918 422) oder kompatibel).
The device must only be connected to a 12 to 24 VDC power supply which meets the requirements
of safe extra low voltage (SELV) according to IEC/EN/DIN EN/UL 61010-1.
If there are voltage peaks on power supply lines, use a protective device in the form of a varistor
(MOV) UMOV = U-rated x 1.2 (BLITZDUCTOR BVT AVD 24 (918 422) or compatible).
POWER
OFF
2
DC 12 to 24 V
Power
Supply
+ –
3
1
Tightening torque: 0.56 Nm
Wire range: 0.75 to 2.5 mm
Rated temperature of wire: 70
Conductor material: Cu
°C
Torque: 1 Nm
Torque: 0.6 Nm
Torque: 0.6 Nm
Torque: 0.6 Nm
Torque: 0.6 Nm
POWER
ON
DC 12 to 24 V
Power
Supply
PWR
12
Gerät einschalten
0.5 x 2
2
Vertical/vertikal, preferred/Empfohlen
Ein SIMATIC IOT-Gerät, ein Klemmenanschluss, ein Montagezubehör-Set mit einer Montage-
-klemme, zwei Montagewinkeln und -schrauben; kein Zubehör wie Micro SD-Karte und -Kabel.
3
Loosen the top housing. Carefully press with the blade of a flat-blade screwdriver in the marked
recesses and carefully pull on the appropriate place on the top housing of the enclosure.
Lösen Sie das obere Gehäuse. Drücken Sie die Klinge eines Schlitzschraubendrehers vorsichtig
in die gekennzeichneten Aussparungen und ziehen Sie vorsichtig an einer geeigneten Stelle des
oberen Gehäuses.
1
2
Remove the top housing with shield cover.
Remove the power plug and marked
screws.
Ziehen Sie den Netzstecker ab und
entfernen Sie die gekennzeichneten
Schrauben.
Nehmen Sie das obere Gehäuse mit Schutzabdeckung ab.
3
2
08/2022
A5E51844350-AB
SIMATIC
SIMATIC IOT
SIMATIC IOT 2050
Quick Install Guide
Mounting the device
Gerät einbauen
Connecting the device
Gerät anschließen
Expand Device
Gerät erweitern
1
2
3
3.6 Replacing the backup battery - Pufferbatterie austauschen
3.3 Install Mini PCIe card - Mini PCIe-Karte Installieren
Inserting Micro SD/ Nano SIM card – Einsetzen Micro SD/ Nano SIM-Karte3.5
3.4 Install M.2 card - M.2-Karte Installieren
3
Expand device
Gerät erweitern
3
Illustrations
This document contains illustrations of the described devices andaccessories.
The illustrations may deviate from the particularities of the delivered device and accessories.
Abbildungen
Das vorliegende Dokument enthält Abbildungen zu den beschriebenen Geräten und Zubehör.
Die Abbildungen können bezogen auf das gelieferte Gerät und Zubehör in Einzelheiten abweichen.
Central Technical Support
Technische Support-Zentrale
https://support.industry.siemens.com
Service and spare parts
Reparatur und Ersatzteile
https://support.industry.siemens.com/sc/de/en/sc
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and
software described. Since variance cannot be precluded entirely, we cannot guarantee full
consistency. However, the information in this publication is reviewedregularly andany necessary
corrections are included in subsequent editions.
Haftungsausschluss
Wir haben den Inhalt der Druckschrift auf Übereinstimmung mit der beschriebenen Hard- und
Software geprüft. Dennoch können Abweichungen nicht ausgeschlos sen werden, so dass wir für die
vollständige Übereinstimmung keine Gewähr übernehmen. Die Angab en in dieser Druckschrift
werden regelmäßig überprüft, notwendige Korrekturen sind in dennachfolgenden Auflagen
enthalten.
Siemens AG
DI FA
Postfach 48 48
90026 NÜRNBERG
© Siemens AG 2022. All rights reserved
A5E51844350-AB, 08/2022
1
2
3
n Sie das Gehäuse.
3
4
2
4
length of E-Key card /
Länge Key E-Karte:
30 mm
length of B-key card /
Länge Key B-Karte:
42 mm or 52 mm
Produktlieferung: Rückmeldung zur
Qualitätskontrolle
Product Delivery: Feedback on Quality Control
http://www.siemens.com/asis
Technical Support
https://support.industry.siemens
.com/cs/ww/en/sc/4868
Ersatzteil-Services
Spare Parts Services
https://support.industry.siemens
.com/cs/ww/en/sc/2110
A
B
Note: This part is not applied for 6ES7647-0BA00-0YA2 .
Hinweis: Dieses Ersatzteil ist nicht fuer 6ES7647-0BA00-0YA2 vorgesehen.
Note: This part is not applied for 6ES7647-0BB00-1YA2.
Hinweis: Dieses Ersatzteil ist nicht fuer 6ES7647-0BB00-1YA2 vorgesehen.
Then install the motherboard again and close the housing.
Bauen Sie anschließend die Grundplatine wieder ein und schließe
Remove the marked screws on the
motherboard.
Replace the battery and lock tape.
Unplug the battery cable
and remove the motherboard.
Entfernen Sie die gekennzeichneten
Schrauben an der Hauptplatine.
Stecken Sie das Batteriekabel aus und
entfernen Sie die Hauptplatine.
Tauschen Sie die Batterie und
das Klebeband aus.
Betriebssystem und Software für die SIMATIC IOT-Geräte sind frei programmierbar und werden
beim Booten des Geräts von der Micro SD-Karte geladen. Weitere Informationen zu den Themen
Software, Inbetriebnahme und Micro SD-Image finden Sie im SIMATIC IOT2000-Forum
(https://support.industry.siemens.com/tf/ww/de/threads/303/).
Operating system and software for the SIMATIC IOT devices are freely programmable and are
downloaded from the Micro SD card when the device is booted. Additional information on the
topics software, commissioning and Micro SD image is available in the SIMATIC IOT2000 Forum.
(https://support.industry.siemens.com/tf/ww/en/threads/303/).
Note: This part is for 6ES7647-0BB00-1YA2 only.
Hinweis: Dieses Ersatzteil ist nur für das 6ES7647-0BB00-1YA2 vorgesehen.
451
Remove the top housing
Then close the housing.
Dann schließen Sie das Gehäuse.
6
1
Remove the top housing.
2
Nehmen Sie das obere Gehäuse ab.
Drill holes with a corresponding diameter at the marking shown for mini PCIe installation
accessory. There are four reserved antenna holes, two on each side.
Bohren Sie an der dargestellten Kennzeichnung für das Mini PCIe-Montagezubehör
Löcher mit entsprechendem Durchmesser. Es sind insgesamt vier Antennenbohrungen
reserviert, jeweils zwei auf jeder Seite.
Insert the Mini PCIe card in the Mini PCIe interface and fix it with two M2 screws.
For half size Mini PCIe card, you need to move one standoff from A to B. Then install the half
size Mini PCIe card and fix it with a M2 screw.
3
Setzen Sie die Mini PCIe-Karte in die Mini PCIe-Schnittstelle ein und befestigen Sie sie mit
zwei Schrauben M2. Bei einer Mini PCIe Half Size-Karte müssen Sie einen Abstandshalter von
A nach B schieben. Installieren Sie anschließend die Mini PCIe-Karte und befestigen Sie sie
mit einer Schraube M2.
Connect the cables of mini PCIe installation accessory to the Mini PCIe card.
4
Schließen Sie die Kabel des Mini PCIe-Montagezubehörs an die Mini PCIe-Karte an.
Get the cable of mini PCIe installation accessory out of the housing through the hole
drilled.
5
Führen Sie das Kabel des Mini PCIe-Montagezubehörs über die gebohrte Öffnung aus dem
Gehäuse heraus.
1
Remove the top housing.
Nehmen Sie das obere Gehäuse ab.
2
Drill holes with a corresponding diameter for M.2 installation accessory. There are four
reserved antenna holes, two on each side.
Bohren Sie an der dargestellten Kennzeichnung für das Mini PCIe-Montagezubehör
Löcher mit entsprechendem Durchmesser. Es sind insgesamt vier Antennenbohrungen
reserviert, jeweils zwei auf jeder Seite.
3
Insert the M.2 card in the interface on the motherboard as illustrated.
Setzen Sie die M.2-Karte wie dargestellt in die Schnittstelle auf der Hauptplatine ein.
4
Fix the M.2 card with a M3 screw in the accessory package.
When fixing the M.2 card in B-key, make sure you fix the card between the spacer and
the screw head.
Befestigen Sie die M.2-Karte mit einer M3 Schraube aus dem Zubehörpaket. Bei Key B
müssen Sie die M.2-Karte zwischen Abstandshalter und Schraubenkopf befestigen.
Nehmen Sie das obere Gehäuse ab.
Get the cable of M.2 installation accessory out of the housing through the hole drilled.
5
Führen Sie das Kabel des M.2-Montagezubehörs über die gebohrte Öffnung aus dem
Gehäuse heraus.
Then close the housing.
Dann schließen Sie das Gehäuse.
6

Other manuals for SIMATIC IOT

1

This manual suits for next models

1

Other Siemens Gateway manuals

Siemens ProtoAir FPA-W44 User guide

Siemens

Siemens ProtoAir FPA-W44 User guide

Siemens FDCW221 User manual

Siemens

Siemens FDCW221 User manual

Siemens Instabus/DALI Gateway N 141 User manual

Siemens

Siemens Instabus/DALI Gateway N 141 User manual

Siemens GW-23 User manual

Siemens

Siemens GW-23 User manual

Siemens SIMATIC FDE Gateway V1.1 Technical Document

Siemens

Siemens SIMATIC FDE Gateway V1.1 Technical Document

Siemens SIMATIC PN/M-Bus LINK User manual

Siemens

Siemens SIMATIC PN/M-Bus LINK User manual

Siemens Gigaset Optical LAN Adapter Duo User manual

Siemens

Siemens Gigaset Optical LAN Adapter Duo User manual

Siemens SIMATIC User manual

Siemens

Siemens SIMATIC User manual

Siemens Advance Network Gateway User manual

Siemens

Siemens Advance Network Gateway User manual

Siemens SIMATIC FDE User manual

Siemens

Siemens SIMATIC FDE User manual

Siemens SpeedStream 6500 Series User manual

Siemens

Siemens SpeedStream 6500 Series User manual

Siemens Tiastar LV MCC User manual

Siemens

Siemens Tiastar LV MCC User manual

Siemens SMG 71 User manual

Siemens

Siemens SMG 71 User manual

Siemens FDCW221 User manual

Siemens

Siemens FDCW221 User manual

Siemens A53457 Maintenance and service guide

Siemens

Siemens A53457 Maintenance and service guide

Siemens FDCW241 User manual

Siemens

Siemens FDCW241 User manual

Siemens SIRIUS 3RK3141 Series User manual

Siemens

Siemens SIRIUS 3RK3141 Series User manual

Siemens Gigaset SE568 User manual

Siemens

Siemens Gigaset SE568 User manual

Siemens HG 3500 V4 User manual

Siemens

Siemens HG 3500 V4 User manual

Siemens FDCW221 User manual

Siemens

Siemens FDCW221 User manual

Siemens RUGGEDCOM WIN5137-V User manual

Siemens

Siemens RUGGEDCOM WIN5137-V User manual

Siemens Gigaset SE567 User manual

Siemens

Siemens Gigaset SE567 User manual

Siemens FDCW241 User manual

Siemens

Siemens FDCW241 User manual

Siemens SIMATIC IOT Gateway MQTT User guide

Siemens

Siemens SIMATIC IOT Gateway MQTT User guide

Popular Gateway manuals by other brands

Dialight IntelliLED quick start guide

Dialight

Dialight IntelliLED quick start guide

Rosslare AY-Q65 Installation and programming manual

Rosslare

Rosslare AY-Q65 Installation and programming manual

Arris Touchstone TG2472 user guide

Arris

Arris Touchstone TG2472 user guide

PEMTECH PT800 Series Operator's manual

PEMTECH

PEMTECH PT800 Series Operator's manual

PiiGAB M-Bus 810 user manual

PiiGAB

PiiGAB M-Bus 810 user manual

Inoteska ITX 495 01 Product documentation

Inoteska

Inoteska ITX 495 01 Product documentation

IntesisBox PA-AC-MBS-128 Installation sheet

IntesisBox

IntesisBox PA-AC-MBS-128 Installation sheet

COTX COTX-X3 quick start guide

COTX

COTX COTX-X3 quick start guide

Visual Circuits MG user manual

Visual Circuits

Visual Circuits MG user manual

AudioCodes Mediant 1000 user manual

AudioCodes

AudioCodes Mediant 1000 user manual

FibRSol FS-2LAN+1POTS+WiFi Dual Mode user manual

FibRSol

FibRSol FS-2LAN+1POTS+WiFi Dual Mode user manual

Juniper SRX5400 Hardware guide

Juniper

Juniper SRX5400 Hardware guide

Robustel R3010 user guide

Robustel

Robustel R3010 user guide

SSS Siedle Smart Gateway Commissioning instructions

SSS Siedle

SSS Siedle Smart Gateway Commissioning instructions

ADTRAN 424RG Installation

ADTRAN

ADTRAN 424RG Installation

2N Telekomunikace 2N StarGate user manual

2N Telekomunikace

2N Telekomunikace 2N StarGate user manual

Packet Force RVSG-4014 user manual

Packet Force

Packet Force RVSG-4014 user manual

Seneca R-KEY-LT user manual

Seneca

Seneca R-KEY-LT user manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
