Siemens 3TK2810-1 User manual

SIRIUS industrial controls
Safety relays
3TK2810-1 safety-related speed
monitor
Equipment Manual
05/2020
NEB926246402000/RS-AE/007
Introduction 1
Safety information 2
Product description 3
Functions 4
Assembling 5
Connecting 6
Operation 7
Diagnostics/
troubleshooting 8
Technical data 9
Dimension drawings 10
Circuit diagrams 11
Appendix A

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage
to property. The notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices
referring only to property damage have no safety alert symbol. These notices shown below are graded according to
the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be
used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property
damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication may
be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described.
Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the information in this
publication is reviewed regularly and any necessary corrections are included in subsequent editions.
Siemens AG
Smart Infrastructure
Electrical Products
Postfach 10 09 53
93009 Regensburg
GERMANY
3ZX1012-0TK28-0AC0
Ⓟ 06/2021 Subject to change
Copyright © Siemens AG 2010.
All rights reserved

Table of contents
1 Introduction ........................................................................................................................................... 7
1.1 Purpose of this manual ........................................................................................................ 7
1.2 Required basic knowledge.................................................................................................... 8
1.3 Validity range ...................................................................................................................... 9
1.4 Siemens Industry Online Support ....................................................................................... 10
1.5 User responsibility for system design and function.............................................................. 12
1.6 Product-speci󹪝c information............................................................................................... 13
2 Safety information............................................................................................................................... 19
2.1 Security information .......................................................................................................... 19
3 Product description.............................................................................................................................. 21
3.1 Overview........................................................................................................................... 21
3.2 Application ........................................................................................................................ 23
3.3 Basic versions .................................................................................................................... 24
3.4 Accessories........................................................................................................................ 29
4 Functions ............................................................................................................................................. 31
4.1 Terminals and their functions ............................................................................................. 31
4.2 Function diagram for setup and automatic mode................................................................ 34
4.3 Function diagram for automatic mode................................................................................ 35
5 Assembling .......................................................................................................................................... 37
5.1 Mounting the device on a DIN rail ...................................................................................... 37
5.2 Mounting the device on a level surface............................................................................... 38
5.3 Disassembling the device ................................................................................................... 39
6 Connecting .......................................................................................................................................... 41
6.1 Connection data for terminal blocks ................................................................................... 41
6.2 Connecting terminal blocks................................................................................................ 42
6.3 Disconnecting.................................................................................................................... 44
6.4 Plugging in terminal blocks ................................................................................................ 46
7 Operation............................................................................................................................................. 47
7.1 Times ................................................................................................................................ 47
7.2 Parameterizing/con󹪝guring ................................................................................................ 49
7.2.1 Commissioning.................................................................................................................. 49
7.2.2 Parameterization using the display ..................................................................................... 49
3TK2810-1 safety-related speed monitor
Equipment Manual, 05/2020, NEB926246402000/RS-AE/007 3

7.2.3 Lock changes..................................................................................................................... 50
7.2.4 Change tracking of parameterization.................................................................................. 50
7.2.5 Parameterization menu...................................................................................................... 51
7.2.6 Parameterization and pin assignments of the RJ45 interface ............................................... 55
7.2.7 Copying parameters........................................................................................................... 55
7.3 Con󹪝guring........................................................................................................................ 57
7.3.1 Con󹪝guration information.................................................................................................. 57
7.3.2 Con󹪝guration examples ..................................................................................................... 58
7.3.2.1 Rotational motion, rotary encoder...................................................................................... 58
7.3.2.2 Translational motion, rotary encoder.................................................................................. 60
7.3.2.3 Translational motion, linear encoder .................................................................................. 61
8 Diagnostics/troubleshooting ............................................................................................................... 63
8.1 Reading the setting values during operation....................................................................... 63
8.2 Troubleshooting................................................................................................................. 64
8.3 Corrective action................................................................................................................ 65
8.4 Behavior in the event of a fault........................................................................................... 66
8.4.1 Power failure ..................................................................................................................... 66
8.4.2 Internal error ..................................................................................................................... 66
8.4.3 Sensor fault ....................................................................................................................... 66
8.4.3.1 Position switch protective door........................................................................................... 66
8.4.3.2 Speed sensor ..................................................................................................................... 66
8.4.4 Fault in the feedback circuit................................................................................................ 67
8.4.4.1 Contacts of the feedback circuit are not closed on starting.................................................. 67
8.4.4.2 Contacts of the feedback circuit do not close after stopping................................................ 67
8.4.5 Cross-circuit/short-circuit.................................................................................................... 67
8.4.6 Fault in the connection to the adapter ................................................................................ 67
8.4.7 Violation of upper/lower parameterized speed limits........................................................... 67
8.4.7.1 Automatic speed exceeded ................................................................................................ 67
8.4.7.2 Automatic speed undershot ............................................................................................... 67
8.4.7.3 Setup speed exceeded ....................................................................................................... 68
8.4.7.4 Setup speed undershot ...................................................................................................... 68
8.4.7.5 Standstill speed exceeded .................................................................................................. 68
8.4.7.6 Start override time exceeded.............................................................................................. 68
8.4.8 Parameterized monitoring times exceeded/undershot......................................................... 68
8.4.8.1 Release delay time undershot............................................................................................. 68
8.5 Device replacement ........................................................................................................... 69
9 Technical data...................................................................................................................................... 71
9.1 Technical data in Siemens Industry Online Support............................................................. 71
9.2 Overview tables ................................................................................................................ 72
10 Dimension drawings............................................................................................................................ 73
10.1 Dimension drawings .......................................................................................................... 73
11 Circuit diagrams................................................................................................................................... 75
11.1 Circuit diagram .................................................................................................................. 75
Table of contents
3TK2810-1 safety-related speed monitor
4Equipment Manual, 05/2020, NEB926246402000/RS-AE/007

A Appendix.............................................................................................................................................. 79
A.1 Printed form for documenting the setting parameters......................................................... 79
Table of contents
3TK2810-1 safety-related speed monitor
Equipment Manual, 05/2020, NEB926246402000/RS-AE/007 5

Table of contents
3TK2810-1 safety-related speed monitor
6Equipment Manual, 05/2020, NEB926246402000/RS-AE/007

Introduction 1
1.1 Purpose of this manual
Note
Original system manual
The system manual of the 3TK2810-1 safety-related speed monitor described below is the
original system manual.
This manual contains a detailed description of the 3TK2810-1 safety-related speed monitor and
its components. The manual provides you with the information you require for con󹪝guring,
commissioning and using the 3TK2810-1 safety-related speed monitor. Typical application
examples provide you with a clear and practice-oriented introduction.
Furthermore, the manual contains dimension drawings, circuit diagrams and technical data of
the relay to facilitate con󹪝guration.
3TK2810-1 safety-related speed monitor
Equipment Manual, 05/2020, NEB926246402000/RS-AE/007 7

1.2 Required basic knowledge
A general knowledge of the following areas is needed in order to understand this manual:
• Low-voltage switchgear
• Digital circuit logic
• Automation systems
• Safety systems
Introduction
1.2 Required basic knowledge
3TK2810-1 safety-related speed monitor
8Equipment Manual, 05/2020, NEB926246402000/RS-AE/007

1.3 Validity range
The manual is valid for the present 3TK2810-1 safety-related speed monitor. It contains a
description of the components valid at the time of publication.
SIEMENS reserves the right of including a Product Information for each new component, and for
each component of a later version.
Introduction
1.3 Validity range
3TK2810-1 safety-related speed monitor
Equipment Manual, 05/2020, NEB926246402000/RS-AE/007 9

1.4 Siemens Industry Online Support
Information and service
At Siemens Industry Online Support you can obtain up-to-date information from our global
support database:
• Product support
• Application examples
• Forum
• mySupport
Link: Siemens Industry Online Support (https://support.industry.siemens.com/cs/de/en)
Product support
You can 󹪝nd information and comprehensive know-how covering all aspects of your product
here:
•FAQs
Answers to frequently asked questions
•Manuals/operating instructions
Read online or download, available as PDF or individually con󹪝gurable.
•Certi󹪝cates
Clearly sorted according to approving authority, type and country.
•Characteristics
For support in planning and con󹪝guring your system.
•Product announcements
The latest information and news concerning our products.
•Downloads
Here you will 󹪝nd updates, service packs, HSPs and much more for your product.
•Application examples
Function blocks, background and system descriptions, performance statements,
demonstration systems, and application examples, clearly explained and represented.
•Technical data
Technical product data for support in planning and implementing your project
Link: Product support (https://support.industry.siemens.com/cs/ww/en/ps)
mySupport
The following functions are available in your personal work area "mySupport":
•Support Request
Search for request number, product or subject
•My 󹪝lters
With 󹪝lters, you limit the content of the online support to di󹪜erent focal points.
Introduction
1.4 Siemens Industry Online Support
3TK2810-1 safety-related speed monitor
10 Equipment Manual, 05/2020, NEB926246402000/RS-AE/007

•My favorites
With favorites you bookmark articles and products that you need frequently.
•My noti󹪝cations
Your personal mailbox for exchanging information and managing your contacts. You can
compile your own individual newsletter in the "Noti󹪝cations" section.
•My products
With product lists you can virtually map your control cabinet, your system or your entire
automation project.
•My documentation
Con󹪝gure your individual documentation from di󹪜erent manuals.
•CAx data
Easy access to CAx data, e.g. 3D models, 2D dimension drawings, EPLAN macros, device
circuit diagrams
•My IBase registrations
Register your Siemens products, systems and software.
Introduction
1.4 Siemens Industry Online Support
3TK2810-1 safety-related speed monitor
Equipment Manual, 05/2020, NEB926246402000/RS-AE/007 11

1.5 User responsibility for system design and function
The products described here were developed to perform safety-related functions as part of an
overall installation or machine. A complete, safety-related system is generally equipped with
sensors, evaluation units, and signaling units, and uses reliable shutdown concepts. It is the
responsibility of the manufacturer of a system or machine to ensure that the product functions
properly.
Siemens AG, its regional o󹪟ces, and associated companies (hereinafter referred to as "Siemens")
cannot guarantee all the properties of an entire plant, system or machine that has not been
designed by Siemens.
Nor can Siemens assume liability for recommendations that appear or are implied in the
following description. No new guarantee, warranty, or liability claims beyond the scope of the
Siemens general terms of supply are to be derived or inferred from the following description.
Introduction
1.5 User responsibility for system design and function
3TK2810-1 safety-related speed monitor
12 Equipment Manual, 05/2020, NEB926246402000/RS-AE/007

1.6 Product-speci󹪝c information
Important note for maintaining the operational safety of your system
WARNING
Hazardous voltage
Can Cause Death, Serious Injury, or Property Damage.
Please take note of our latest information.
Systems with safety-related characteristics are subject to special operational safety
requirements on the part of the operator. The supplier is also obliged to comply with certain
actions when monitoring the product. For this reason, we publish a special newsletter
containing information on product developments and features that are (or could be) relevant
to operation of safety-related systems. By subscribing to the appropriate newsletter, you will
ensure that you are always up-to-date and able to make changes to your system, when
necessary:
SIEMENS Newsletter (http://www.siemens.com/sirius-newsletter)
Register for the Newsletter by checking the appropriate box:
• Controls and Distribution News
Safety notices
NOTICE
Observe the ESD guidelines
When handling and installing the devices, observe the ESD guidelines.
Connection is only permitted when the power adapters have been deactivated.
Introduction
1.6 Product-speci󹪝c information
3TK2810-1 safety-related speed monitor
Equipment Manual, 05/2020, NEB926246402000/RS-AE/007 13

ESD guidelines
ESD components are destroyed by voltage and energy far below the limits of human perception.
Voltages of this kind occur as soon as a device or an assembly is touched by a person who is not
electrostatically discharged. ESD components which have been subject to such voltage are
usually not recognized immediately as being defective, because the malfunction does not occur
until after a longer period of operation.
NOTICE
Damage to the speed monitor from electrostatic charging!
The speed monitor contains electrostatically sensitive devices. These modules will be
destroyed or damaged by improper handling.
• You must discharge your body electrostatically immediately before touching an electronic
component. To do this, touch a conductive, grounded object, e.g., a bare metal part of a
switch cabinet or the water pipe.
• Always hold the component by the plastic enclosure.
• Electronic modules should not be brought into contact with electrically insulating materials
such as plastic 󹪝lm, plastic parts, insulating table supports or clothing made of synthetic
󹪝bers.
• Always place electrostatic sensitive devices on conductive bases.
• Always store and transport electronic modules or components in ESD-safe conductive
packaging, e.g. metallized plastic or metal containers. Leave the component in its
packaging until installation.
Note
In the case of capacitive or inductive load at the output contacts, su󹪟cient suppressor circuits
must be provided to protect against contact overload. A fuse must also be connected in series
to protect against welding of the safety contacts (see Chapter "Technical data (Page 71)").
Note
Routing of the sensor cables
If electromagnetic interferences are to be expected, all initiator/encoder cables must be shielded
when laid. The shielding must be connected to PE at both ends.
Introduction
1.6 Product-speci󹪝c information
3TK2810-1 safety-related speed monitor
14 Equipment Manual, 05/2020, NEB926246402000/RS-AE/007

Intended use
WARNING
Intended use
Can Cause Death, Serious Injury, or Property Damage.
The devices may only be used for the applications described in the catalog and the technical
description (see Chapter "Application (Page 23)"), and only in conjunction with equipment or
components from other manufacturers which have been approved or recommended by
Siemens. You must also ensure that suitable and reliable sensors are used (see Chapter "Basic
versions (Page 24)" and "Con󹪝guring (Page 57)").
This product can function correctly and reliably only if it is transported, stored, assembled, and
mounted correctly, and operated and maintained as recommended.
Before you run any sample programs or programs that you have written yourself, make sure
that running the plant cannot cause injury to anyone else or damage to the machine itself.
EU notice: Start-up/commissioning is absolutely prohibited until it has been ensured that the
machine in which the component described here is to be installed ful󹪝lls the regulations/
speci󹪝cations of Machinery Directive 2006/42/EC.
Dormant error detection
Note
In case of longer standstill times (t >= 24 h), a start-up test (function test of the application) is
absolutely necessary before restarting the system.
Exception:
Such a startup test is not necessary when using NAMUR sensors.
Connection of the initiators
Note
If common sensor potentials are directly connected to the initiators and a common return wire
is connected to the 3TK2810-1 device, the 󹪝rst error that occurs will result in a loss of the safety
function. Thus the maximum achievable SIL = 1 and the PL = c.
A series connection of proximity switches is not permitted.
Introduction
1.6 Product-speci󹪝c information
3TK2810-1 safety-related speed monitor
Equipment Manual, 05/2020, NEB926246402000/RS-AE/007 15

Encoder
NOTICE
Use of encoders
In order to achieve the highest possible SIL/PL when using encoders, 2-channel encoders (4
tracks: A, A/, B, B/) with de󹪝ned failure response (high-impedance outputs) must be used.
If such information cannot be found on the encoder manufacturer's data sheet, then the failure
response data must be requested from the encoder manufacturer.
No speci󹪝c safety encoders have to be used on the 3TK2810-1 safety-related speed monitor.
If an encoder is used, the encoder's FIT (Failure in Time) value must be incorporated into the
calculation of the safety chain.
Encoders that are operated on a 3TK2810-1 safety-related speed monitor must have the
following properties:
• TTL/HTL encoders that provide two signal tracks with the respectively inverted signals.
• All sin/cos encoders that supply both the sine and the cosine tracks with the respectively
inverted signals (sin, /sin and cos, /cos).
• The phase o󹪜set of the two signals A (or sin) and B (or cos) must be 90 °, between A and /A
or B and /B it must be 180 ° in each case.
• The encoder's signals must have a high resistance in the event of failure.
The 3TK2810-1 speed monitor detects a disrupting o󹪜set of the signal track or mutual
overtaking of the signals in the case of sin/cos encoders. Detection of the fault is independent
of the set frequency. The 3TK2810-1 safety-related speed monitor assumes the safe state and
issues a fault message.
It is the responsibility of the user to check whether a speci󹪝c encoder and its pin assignments
match the 3TK2810-1 safety-related speed monitor.
Actuator wiring up to PL e / Cat. 4 per ISO 13849-1, or SILCL 3 per IEC 62061
13 23
14 24
Q1 Q2 440
Figure 1-1 Dual-channel actuator wiring via two terminals
Introduction
1.6 Product-speci󹪝c information
3TK2810-1 safety-related speed monitor
16 Equipment Manual, 05/2020, NEB926246402000/RS-AE/007

13 23
14 24
Q1 Q2 440
Figure 1-2 Dual-channel actuator wiring via one terminal
Note
To achieve SILCL 2/3 as per IEC 62061 or PL d/e as per EN ISO 13849‑1, a fault exclusion such as
a short-circuit to P or M is required. This can, for example, be implemented within a control
cabinet or by installing the connection cables in such a way that they are protected. If this is not
possible, the actuators must be wired via two safety-related outputs, see image "Dual-channel
actuator wiring via two terminals". For this purpose, separate cables must be laid to actuators /
contactors.
Introduction
1.6 Product-speci󹪝c information
3TK2810-1 safety-related speed monitor
Equipment Manual, 05/2020, NEB926246402000/RS-AE/007 17

Introduction
1.6 Product-speci󹪝c information
3TK2810-1 safety-related speed monitor
18 Equipment Manual, 05/2020, NEB926246402000/RS-AE/007

Safety information 2
2.1 Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is necessary
to implement – and continuously maintain – a holistic, state-of-the-art industrial security
concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected to
an enterprise network or the internet if and to the extent such a connection is necessary and only
when appropriate security measures (e.g. 󹪝rewalls and/or network segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit
https://www.siemens.com/industrialsecurity (https://new.siemens.com/global/en/company/
topic-areas/future-of-manufacturing/industrial-security.html).
Siemens’ products and solutions undergo continuous development to make them more secure.
Siemens strongly recommends that product updates are applied as soon as they are available
and that the latest product versions are used. Use of product versions that are no longer
supported, and failure to apply the latest updates may increase customer’s exposure to cyber
threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS Feed
under
https://www.siemens.com/industrialsecurity (https://new.siemens.com/global/en/company/
topic-areas/future-of-manufacturing/industrial-security.html).
3TK2810-1 safety-related speed monitor
