Siemens Sicharge Uc 8EM4 Series Instructions for use

an

Preventive Maintenance Checklist for SICHARGE UC
Preventive Maintenance Checklist
for SICHARGE UC
Product Information
02/2023
A5E52548311
-AA
Introduction
1
SICHARGE UC Charger
2
SICHARGE UC Dispenser
3
SICHARGE UC MastHood
4
SICHARGE UC MastPanto
5
Appendix
A

Siemens AG
Smart Infrastructure
Schuhstr.
60
91052 Erlangen
GERMANY
A5E52548311-AA
Ⓟ
03/2023 Subject to change
Copyright © Siemens AG 2023.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Preventive Maintenance Checklist for SICHARGE UC
Product Information, 02/2023, A5E52548311-AA 3
Table of contents
1 Introduction ........................................................................................................................................... 4
2 SICHARGE UC Charger............................................................................................................................ 5
2.1 Preventive Maintenance Checklist ........................................................................................ 5
3 SICHARGE UC Dispenser ........................................................................................................................ 7
3.1 Preventive Maintenance Checklist ........................................................................................ 7
4 SICHARGE UC MastHood ........................................................................................................................ 9
4.1 Preventive Maintenance Checklist ........................................................................................ 9
5 SICHARGE UC MastPanto ..................................................................................................................... 11
5.1 Preventive Maintenance Checklist ...................................................................................... 11
A Appendix.............................................................................................................................................. 13
A.1 Maintenance Plan .............................................................................................................. 13

Preventive Maintenance Checklist for SICHARGE UC
4Product Information, 02/2023, A5E52548311-AA
Introduction
1
The condition of the system and any defects found must be documented with suitable
photos.
If an inspection point is marked "FAIL (F)", a more detailed description of the defect must be
given at the end of the checklist.
Criteria that cannot be checked, e.g. because they are not present, are to be marked with
"N/A".
The list must be filled in completely.
Defects that have been directly eliminated are to be entered in the defect list and marked as
completed.
Note
Carry out the tests after commissioning a
t the following intervals:
•
2 months after commissioning
•
6 months after commissioning
•
12 months after commissioning
After the first year, carry out the checks every 12 months or at shorter intervals if necessary
due to the ambient conditions.

Preventive Maintenance Checklist for SICHARGE UC
Product Information, 02/2023, A5E52548311-AA 5
SICHARGE UC Charger
2
2.1 Preventive Maintenance Checklist
Control (annually)
Customer:
Date:
Serial number:
Date of manufacture:
Location:
-
Name:
-
No.
Checklist item
P
F
N/A
1
Check the touch screen (HMI) for errors and solve them if possible.
Check whether an error message appears on the HMI after opening the cabinet door.
☐
☐
☐
☐
☐
☐
2
Check the DC shutdown button (NOT during charging process)
Check whether an error message appears on the touch screen display (HMI) after pressing the
button.
Observe if the charger comes back to default function after the emergency stop button is re-
leased.
☐
☐
☐
☐
☐
☐
☐
☐
☐
3
Disconnect the charger safely on its MCCB according to the 5 safety rules. Regarding the AC and
DC capacitors pay attention to the follow note.
☐
☐
☐
Note: The DC capacitors may not be fully discharged after switching off the power supply. DC live parts remain under
dangerous electrical voltage for up to 10 minutes during discharging. AC live parts may remain under dangerous
electrical voltage until they are manually discharged. Touching the live parts can lead to death or serious injury.
•Wait 10 minutes after switching off the power supply.
•Heed warnings about charged capacitors
•Make sure that the charging station and its parts are de-energized.
•Only then should you start work on the charging station.
4 Check the exterior of the cabinet for visible damage, stickers, graffiti, etc.
Check the touch screen (HMI) for visible damage
Check the charging cable and plug for moisture, dust or corrosion
Check the position of the charging plug in the plug holder if applicable
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
5
Check the correct function of the cabinet door (lubricate hinges if necessary)
Check that the door locks and hinges move easily
☐
☐
☐
☐
☐
☐
6 Check the ventilation openings
Clean the grilles of fans and the air intakes
Check the air filters for the upper and lower fans and the air filters in the bottom cover of the
charging station. Clean or replace them if they are dirty
Check the indoor fans and clean them if necessary
Check the fans for any unusual running noises
Check fan for damages
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
7
Inspect inside charger ceiling, doors, grating, and cable bushings
☐
☐
☐
8
Make a visual inspection of the cabinet for any damages of all components
☐
☐
☐
9
Clean the interior if necessary
☐
☐
☐

SICHARGE UC Charger
2.1 Preventive Maintenance Checklist
Preventive Maintenance Checklist for SICHARGE UC
6Product Information, 02/2023, A5E52548311-AA
No.
Checklist item
P
F
N/A
10
Check for additional country-specific signs
Is system documentation (circuit diagrams, product documentation, OEM documentation)
available?
☐
☐
☐
☐
☐
☐
11
Check if SW-updates are available
☐
☐
☐
12 Check the tightening torques or mark on nut of the L1, L2, L3 connections - 42,4Nm (when
using copper cables)
Check the tightening torque or mark on nut of the PE ground connections - 20 Nm
Check the tightening torques or mark on nut of the DC+ & DC- connections - 30 Nm
☐
☐
☐
☐
☐
☐
☐
☐
☐
13
Ensure that the earthing straps/wires are complete and check for any damage and tightness
☐
☐
☐
14
Follow the electrical safety measurements of electrical protective devices and earth resistance
according to local regulations and standards
☐
☐
☐
Comments and findings:
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Name
Function
Signature
Responsible person
(optional) Customer
Please take into consideration that the document is only valid after signatures of technician or if included in the final
document delivered to the customer.

Preventive Maintenance Checklist for SICHARGE UC
Product Information, 02/2023, A5E52548311-AA 7
SICHARGE UC Dispenser
3
3.1 Preventive Maintenance Checklist
Control (annually)
Customer:
Date:
Serial number:
Date of manufacture:
Location:
-
Name:
-
No.
Checklist item
P
F
N/A
1
Check touch screen display (HMI) for errors and solve if possible
Check whether an error message appears on the touch screen display (HMI) after opening the
cabinet door
☐
☐
☐
☐
☐
☐
2
Disconnect Dispenser from the Charger MCCB according to the 5 safety rules. Regarding the AC
and DC capacitors pay attention to the follow note.
☐
☐
☐
Note:
After disconnecting the power supply of the SICHARGE UC Dispenser and the connected SICHARGE UC charging
station, the capacitors in the SICHARGE UC charging station will start discharging. Live parts remain under danger-
ous electrical voltage for up to 10 minutes during discharging. Touching the live parts can lead to death or serious
injury.
•Wait 10 minutes after switching off the power supply.
•Make sure that the SICHARGE UC Dispenser does not carry any live voltage.
•Only then start working on the SICHARGE UC Dispenser.
3 Check the exterior of the cabinet for visible damage
Check the touch screen (HMI) for visible damage
Check the charging plug cable and plug for moisture, dust or corrosion
Check the position of the charging plug in the plug holder
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
4
Check the correct function of cabinet door (lubricate hinges if necessary)
Check that the door locks and hinges move easily
☐
☐
☐
☐
☐
☐
5
Check the exterior of the cabinet for visible damage
☐
☐
☐
6
Inspect inside dispenser ceiling, doors, cable glands/inlets, and cable bushings
☐
☐
☐
7
Check the cabinet for any damages of all components
☐
☐
☐
8
Clean the interior if necessary
☐
☐
☐
9
Check for additional country-specific additional signs
☐
☐
☐
10
Check the tightening torques (80%) of the DC+ and DC- connections - 45 Nm
Check the tightening torque (80%) of the PE ground connections - 45 Nm
☐
☐
☐
☐
☐
☐
11
Ensure that the earthing straps are complete and check for damage and tightness
☐
☐
☐
12
Follow the electrical safety measurements of electrical protective devices and earth resistance
according to local regulations and standards
☐
☐
☐

SICHARGE UC Dispenser
3.1 Preventive Maintenance Checklist
Preventive Maintenance Checklist for SICHARGE UC
8Product Information, 02/2023, A5E52548311-AA
Comments and findings:
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Name
Function
Signature
Responsible person
(optional) Customer
Please take into consideration that the document is only valid after signatures of technician or if included in the final
document delivered to the customer.

Preventive Maintenance Checklist for SICHARGE UC
Product Information, 02/2023, A5E52548311-AA 9
SICHARGE UC MastHood
4
4.1 Preventive Maintenance Checklist
Control (annually)
Customer:
Date:
Serial number:
Date of manufacture:
Location:
-
Name:
-
No.
Checklist item
P
F
N/A
1
Disconnect the MastHood form the Charger MCCB according to the 5 safety rules. Regarding the
AC and DC capacitors pay attention to the follow note.
☐
☐
☐
Note:
After disconnecting the power supply of the SICHARGE UC MastHood and the connected SICHARGE UC charging
station, the capacitors in the SICHARGE UC charging station will start discharging. Live parts remain under danger-
ous electrical voltage for up to 10 minutes during discharging. Touching the live parts can lead to death or serious
injury.
•Wait 10 minutes after switching off the power supply.
•Make sure that the SICHARGE UC MastHood does not carry any live voltage.
•Only then start working on the SICHARGE UC MastHood.
2 Check the exterior of the MastHood for visible damage
Check the Hood for moisture, dust or corrosion
☐
☐
☐
☐
☐
☐
3
Inspect inside the MastHood cable glands/inlets, and cable bushings
☐
☐
☐
4
Check all MastHood components for any damages
☐
☐
☐
5
Clean the interior if necessary
☐
☐
☐
6
Check for additional country-specific additional signs
☐
☐
☐
7
Check the tightening torques (80%) of the DC+ and DC- connections - 75 Nm
Check the tightening torque (80%) of the PE ground connections
☐
☐
☐
☐
☐
☐
8
Ensure that the earthing straps are complete and check for damage and tightness
☐
☐
☐
9 Follow the electrical safety measurements of electrical protective devices and earth resistance
according to local regulations and standards
☐☐☐

SICHARGE UC MastHood
4.1 Preventive Maintenance Checklist
Preventive Maintenance Checklist for SICHARGE UC
10 Product Information, 02/2023, A5E52548311-AA
Comments and findings:
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Name
Function
Signature
Responsible person
(optional) Customer
Please take into consideration that the document is only valid after signatures of technician or if included in the final
document delivered to the customer.

Preventive Maintenance Checklist for SICHARGE UC
Product Information, 02/2023, A5E52548311-AA 11
SICHARGE UC MastPanto
5
5.1 Preventive Maintenance Checklist
Control (annually)
Customer:
Date:
Serial number:
Date of manufacture:
Location:
-
Name:
-
No.
Checklist item
P
F
N/A
1
Make a visual inspection for external damage
Inspect the locks
Inspect the hinges
☐
☐
☐
☐
☐
☐
☐
☐
☐
2
Check the charge stop button
☐
☐
☐
3
Check the status indication LEDs
☐
☐
☐
4
Proceed with functional check of correct positioning
Check the set distance according to the Y-sensor setting instruction in the manual
☐
☐
☐
☐
☐
☐
5
Check the strength of a signal using the app "WLAN Analyzer" (≥80 dBm)
☐
☐
☐
6
Measuring the lowering and lifting times:
•Measure the lowering time, approx. 6 ... 10 s.
•Measure the lifting times, approx. 5 ... 8 s.
☐
☐
☐
☐
☐
☐
7
Check the proper function of the heating circuit (only annual). Use Laser Infrared Thermometer
or Thermal Imaging Device
☐
☐
☐
8
Disconnect the MastPanto from the Charger MCCB according to the 5 safety rules. Regarding
the AC and DC capacitors pay attention to the follow note.
☐
☐
☐
Note:
After disconnecting the power supply of the SICHARGE UC MastPanto and the connected SICHARGE UC charging
station, the capacitors in the SICHARGE UC charging station will start discharging. Live parts remain under danger-
ous electrical voltage for up to 10 minutes during discharging. Touching the live parts can lead to death or serious
injury.
•Wait 10 minutes after switching off the power supply.
•Make sure that the SICHARGE UC MastPanto does not carry any live voltage.
•Only then start working on the SICHARGE UC MastPanto.
9
Make a visual inspection of the pantograph
Make a visual inspection of the collector head
Make a visual inspection of the jumper leads
Make a visual inspection of the connector cables
Make a visual inspection of the contact bars
Use emery paper to sand contact bars
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
10
Clean and lubricate the set of screws on the spring balancer and the chain strand
☐
☐
☐
11
Follow the electrical safety measurements of electrical protective devices and earth resistance
according to local regulations and standards
☐
☐
☐

SICHARGE UC MastPanto
5.1 Preventive Maintenance Checklist
Preventive Maintenance Checklist for SICHARGE UC
12 Product Information, 02/2023, A5E52548311-AA
Comments and findings:
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Name
Function
Signature
Responsible person
(optional) Customer
Please take into consideration that the document is only valid after signatures of technician or if included in the final
document delivered to the customer.

Preventive Maintenance Checklist for SICHARGE UC
Product Information, 02/2023, A5E52548311-AA 13
Appendix
A
A.1 Maintenance Plan
Table A- 1 SICHARGE UC
Installation1Commission-
ing
1
Final Customer
Acceptance
1 2
Preventive
Maintenance
1 3
Year
From 1 to 15
Interval [yr]
5
UC100C Com-
pact Charger
Effort [h]
4
2
1
2,2
1,0
Material [€]
50
Tools [€]
0
UC100
Effort [h]
4
2
1
2,2
1,0
Material [€]
50
Tools [€]
0
UC150C Com-
pact
Charger
Effort [h]
4
2
1
2,2
1,0
Material [€]
50
Tools [€]
0
UC150
Effort [h]
4
2
1
2,2
1,0
Material [€]
50
Tools [€]
0
UC300
Effort [h]
6
4
1
4,0
1,0
Material [€]
100
Tools [€]
0
UC450
Effort [h]
6
4
1
6,0
1,0
Material [€]
150
Tools [€]
0
UC600
Effort [h]
6
4
1
8,0
1,0
Material [€]
200
Tools [€]
0

Appendix
A.1 Maintenance Plan
Preventive Maintenance Checklist for SICHARGE UC
14 Product Information, 02/2023, A5E52548311-AA
Table A- 2 SICHARGE UC Dispenser type
Installation1Commission-
ing
1
Final Customer
Acceptance
1 2
Preventive
Maintenance
1 3
Year
From 1 to 15
Interval [yr]
5
Dispenser
Effort [h]
2
1
1
0,7
1,0
Material [€]
0
Tools [€]
0
Dispenser LiCo
Effort [h]
2
1
1
0,9
1,0
Material [€]
10
Tools [€]
0
Dispenser Roof
Mount
Effort [h]
3
2
2
1,1
1,0
Material [€]
0
Tools [€]
150
MastHood
Effort [h]
4
2
2
1,1
1,0
Material [€]
0
Tools [€]
150
MastPanto
4
Effort [h]
4-8
4
4
2,6
4
0,5
Material [€]
50
Tools [€]
300
4
1. HQ estimates, not binding. Assumption Based on the experience of the NOC expert team.
With little charger experience, longer I&C&M times can occur.
2. Preconditions for hr values are: already integrated vehicle, availability of vehicle for test,
availability of customer for test and signature. Vehicle integration activities are not included.
3. Apart from the filter mats, no working parts are proactively exchanged during preventive
maintenance. The material cost of replacing defective parts during a repair case is given by
the corrective maintenance estimate based on MTBF.
The interval of annual filter mat replacement is once a year when the ambient air is clean.
In case of contamination must be changed more often.
4. After 12 years, the MastPanto must be completely inspected once. Therefore, an increase of
Effort=6 [h] and Tools =800 [€] should be considered.
5. Preventive maintenance has to be performed at least once a year.
