Siemens SIPROTEC T103 User manual

Edition: Apr. 2014
C53000-L2540-C558-1
SIPROTEC
Redundant T103 Bus
mapping
7VU68x
Communication module
Redundant IEC 60870-5-103
Bus mapping
Preface
Table of Contents
Notes to SIPROTEC®objects 1
IEC 60870-5-103 Interoperability 2
Point List 3
Glossary
Index

Siemens AG Book No. C53000-L2540-C558-1
Copyright
Copyright © SIEMENS AG 2014. All rights reserved.
Copying of this document and giving it to others and the use or
communication of the contents thereof, are forbidden without ex-
pressauthority.Offenders areliabletothepayment of damages.All
rights are reserved, especially in the event or grant of a patent or
registration of a utility model or design.
Registered trademarks
SIPROTEC, SINAUT, SICAM, and DIGSI are registered trade-
marks of SIEMENS AG. Other names and terms can be trade-
marks the use of which may violate the rights of thirds.
Liability statement
We have checked the contents of this manual against the
describedhardwareandsoftware.Nevertheless,deviations
may occur so that we cannot guarantee the entire harmony
with the product.
The contents of this manual will be checked in periodical in-
tervals, corrections will be made in the following editions.
We look forward to your suggestions for improvement.
We reserve the right to make technical improvements with-
out notice.
Document version: V01.00.01

37VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
Preface
Aim of This Manual The manual is devided into the following topics:
•Notes to SIPROTEC®objects
•Redundant IEC 60870-5-103 Device Profile
•Redundant T103 Bus mapping
General information about design, configuration, and operation of SIPROTEC®devic-
es are laid down in the SIPROTEC®4 system manual, order no.
E50417-H1176-C151.
Target Audience Protection engineers, commissioning engineers, persons who are involved in setting,
testingandservice ofprotection,automation, andcontroldevices, aswell asoperation
personnel in electrical plants and power stations.
Additional
literature This manual describes the redundant IEC 60870-5-103 Device Profile of the SIPROTEC®devices.
The following additional manuals inform you about the redundant IEC 60870-5-103
and the function, operation, assembly and commissioning of the SIPROTEC®devic-
es:
IEC 60870-5-103
Specification The IEC 60870-5-103 specification and the structure of the IEC 60870-5-103 messag- es are defined in:
>International Standard IEC 60870-5-103
Transmission protocols-
Companion standard for the informative interface of protection equipment
Edition 1997-12
Reference number CEI/IEC 60870-5-103: 1997
Manual Contents Order number
SIPROTEC Device
7VU68x Function, operation, assembly and commissioning of
the SIPROTEC®device 7VU68x C53000-G1176-C349-2
IEC 60870-5-103
Communication
Database
redundant IEC 60870-5-103 communication
database of the SIPROTEC®devices C53000-L2540-C558-1

47VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
Applicability of this
Manual This manual is valid for
•SIPROTEC®4 devices 7VU683 version V4.70 and 7VU681 version V4.60
•Redundant IEC 60870-5-103 communication module version 01.01.00 or higher.
For device parameterization DIGSI®4version 4.8 or higher and IEC 60870-5-103
standard mappings 3-1 to 3-n (n = device type dependent number of standard map-
pings) have to be used.
Additional Support Should further information be desired or should particular problems arise which are
not covered sufficiently for the purchaser's purpose, the matter should be referred to
the local Siemens representative.
Instructions and
Warnings The warnings and notes contained in this manual serve for your own safety and for an appropriate lifetime of the device. Please observe them!
The following terms are used:
DANGER
indicates that death, severe personal injury or substantial property damage will result
if proper precautions are not taken.
Warning
indicates that death, severe personal injury or substantial property damage can result
if proper precautions are not taken.
Caution
indicates that minor personal injury or property damage can result if proper precau-
tions are not taken. This particularly applies to damage on or in the device itself and
consequential damage thereof.
Note
indicates information about the device or respective part of the instruction manual
which is essential to highlight.
Note:
The redundant IEC 60870-5-103 module is not for all SIPROTEC®devices available.
Check the manual of the device or contact your Siemens representative.

57VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
QUALIFIED PERSONNEL
Forthe purposeof thisinstruction manualandproductlabels,a qualifiedperson is one
who is familiar with the installation, construction and operation of the equipment and
the hazards involved. In addition, he has the following qualifications:
•Is trained and authorized to energize, de-energize, clear, ground and tag circuits
and equipment in accordance with established safety practices.
•Is trained in the proper care and use of protective equipment in accordance with es-
tablished safety practices.
•Is trained in rendering first aid.
Typographic and
Symbol Conven-
tions
The following text formats are used when literal information from the device or to the
device appear in the text flow:
Parameter names, i.e. designators of configuration or function parameters which
may appear word-for-word in the display of the device or on the screen of a personal
computer (with operation software DIGSI®4), are marked in bold letters of a mono-
space type style.
Parameter options, i.e. possible settings of text parameters, which may appear
word-for-word in the display of the device or on the screen of a personal computer
(with operation software DIGSI®4), are written in italic style, additionally.
“Annunciations”, i.e. designators for information, which may be output by the relay
or required from other devices or from the switch gear, are marked in a monospace
type style in quotation marks.
Warning!
Hazardous voltages are present in this electrical equipment during operation. Non–
observance of the safety rules can result in severe personal injury or property dam-
age.
Only qualified personnel shall work on andaround this equipment after becoming thor-
oughly familiar with all warnings and safety notices of this manual as well as with the
applicable safety regulations.
The successful and safe operation of this device is dependent on proper handling, in-
stallation, operation, and maintenance by qualified personnel under observance of all
warnings and hints contained in this manual.
In particular the general erection and safety regulations (e.g. IEC, DIN, VDE, EN or
other national and international standards) regarding the correct use of hoisting gear
must be observed. Non–observance can result in death, personal injury or substantial
property damage.

67VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1

77VU68x Bus mapping
C53000-L2540-C558-1
Table of Contents
Preface.................................................................................................................................................. 3
Table of Contents ................................................................................................................................ 7
1 Notes to SIPROTEC®objects ........................................................................................................... 11
1.1 Annunciations....................................................................................................................... 12
1.1.1 Error With A Summary Alarm............................................................................................... 12
1.1.2 Alarm Summary Event.......................................................................................................... 12
1.1.3 Stop Data Transmission....................................................................................................... 12
1.2 Commands........................................................................................................................... 13
1.2.1 Single Commands................................................................................................................ 13
1.2.2 Changing The Setting Group................................................................................................ 13
1.3 Measured Values ................................................................................................................. 14
2 IEC 60870-5-103 Interoperability ...................................................................................................... 15
2.1 Physical Layer...................................................................................................................... 16
2.1.1 Electrical Interface................................................................................................................ 16
2.1.2 Optical Interface ................................................................................................................... 16
2.1.3 Transmission Speed............................................................................................................. 16
2.2 Link Layer............................................................................................................................. 16

87VU68x Bus mapping
C53000-L2540-C558-1
2.3 Application Layer.................................................................................................................. 17
2.3.1 Transmission Mode For Application Data............................................................................. 17
2.3.2 Common Address of ASDU.................................................................................................. 17
2.3.3 Selection of Standard Information Numbers In Monitor Direction......................................... 17
2.3.3.1 System Functions In Monitor Direction................................................................................. 17
2.3.3.2 Status Indications In Monitor Direction.................................................................................17
2.3.3.3 Supervision Indications In Monitor Direction.........................................................................18
2.3.3.4 Earth Fault Indications In Monitor Direction..........................................................................18
2.3.3.5 Fault Indications In Monitor Direction ...................................................................................19
2.3.3.6 Auto-reclosure Indications In Monitor Direction....................................................................19
2.3.3.7 Measurands In Monitor Direction..........................................................................................19
2.3.3.8 Generic Functions In Monitor Direction ................................................................................ 20
2.3.4 Selection of Standard Information Numbers In Control Direction......................................... 21
2.3.4.1 System Functions In Control Direction ................................................................................. 21
2.3.4.2 General Commands In Control Direction.............................................................................. 21
2.3.4.3 Generic Functions In Control Direction................................................................................. 21
2.3.5 Basic Application Functions.................................................................................................. 21
2.3.6 Miscellaneous.......................................................................................................................22
3 Point List............................................................................................................................................. 23
3.1 General Command (Control Direction).................................................................................24
3.1.1 User defined double point command.................................................................................... 24
3.1.2 Single Point Command......................................................................................................... 24
3.1.3 User defined Single Point Command.................................................................................... 24
3.2 Indications In Monitor Direction ............................................................................................24
3.2.1 HSBT (For 7VU683 Only).....................................................................................................24
3.2.2 ATS (For 7VU681 only) ........................................................................................................26
3.2.3 Protections............................................................................................................................ 26
3.3 Measurements...................................................................................................................... 28
3.3.1 ASDU3 (Measurements I).....................................................................................................28
3.3.2 ASDU9 (Measurements II)....................................................................................................28
3.3.3 User Defined ASDU9 (Measurements II).............................................................................. 28
3.4 Settings................................................................................................................................. 30
Index.................................................................................................................................................... 33
Glossary.............................................................................................................................................. 73

97VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
Notes to SIPROTEC®objects 1
This chapter contains notes for the use and evaluationof certain SIPROTEC®objects
which are available via IEC 60870-5-103 communication.
1.1 Annunciations 10
1.2 Commands 11
1.3 Measured Values 12

Notes to SIPROTEC®objects
10 7VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
1.1 Annunciations
1.1.1 Error With A Summary Alarm
The "Error with a summary alarm" (Obj.- Adr.140) is ON if at least one of the following
internal alarms assumes the value ON:
•"Error 5V", “Error 0V”, “Error -5V”, “Failure Battery empty”, “Error Power Supply”
•"Error I/O Board", “Error Board 1“, “Error Board 2“, "Error Board 3“, "Error Board 4“,
"Error Board 5“, “Error Board 6“, "Error Board 7“
•“Error Offset”, “Calibration data fault”
1.1.2 Alarm Summary Event
The"Alarm summaryevent" (Obj.-Adr. 160)is indicated,if atleast oneof thefollowing
internal alarms assumes the ON status:
•"Failure Current Balance", "Failure Current Summation", "Voltage Balance"
•“Failure Phase Sequence Current”, “Failure Phase Sequence Voltage”
1.1.3 Stop Data Transmission
The functionality "Stop data transmission" is not supported via IEC 60870-5-103 com-
munication. If "Stop data transmission" is active nevertheless data via IEC 60870-5-
103 will be transmitted furthermore.
Note
The description of the standard mappings contains the pre-allocation of the mapping
files at delivery or first assignment of a mapping in DIGSI®4 to the SIPROTEC®de-
vice.
Changes of the allocation and the scaling of the measured values are possible in ad-
aptation to the concrete installation environment (ref. to page 3).
Note
Depending on the device composition and the existing protection packages not all of
the indicated binary inputs or protection annunciations (and corresponding IEC
60870-5-103 Information numbers) may be available in the SIPROTEC®device

Notes to SIPROTEC®objects
11
7VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
The annunciation "DataStop" (Obj.- Adr. 16) signals the activation of "Stop data trans-
mission" however and can be evaluated correspondingly in the IEC 60870-5-103 mas-
ter.
1.2 Commands
1.2.1 Single Commands
The command output mode (pulse output, continuous output) is changeable for the
single commands using parametrization software DIGSI®4.
The switching direction OFF for single commands with pulse output is not permitted
and is rejected in the SIPROTEC®device.
Reference ref. to chap. 3.1.1
1.2.2 Changing The Setting Group
Switching on one setting group automatically switches off the current active setting
group. Transmission of the value OFF is insignificant for the change of the setting
group and is refused by the device.
A change of the setting group is only possible via IEC 60870-5-103 if the parameter
CHANGE TO ANOTHER SETTING GROUP (parameter address = 302) has the value "Pro-
tocol".
Reference Refer to chapter 3.1.1 to the command for changing the setting group. The indication
for a change of a setting group is shown in chapter 3.2.3
Note
The allocation of the output relays to the switching devices and to the binary outputs
is defined during parametrization of the SIPROTEC®devices.
Depending on the device composition there may be less than the indicated output re-
lays (and corresponding IEC 60870-5-103 Information numbers) available in the
SIPROTEC®device.

Notes to SIPROTEC®objects
12 7VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
1.3 Measured Values
For the transmission of measured values, the compatible range and the private range
can beused. Are there several measurement telegrams parameterised then these are
transferred cyclically after each other.
The range of the values which can be transmitted is mostly +/-240% or +/-2.4 of the
rated value. The value in data unit 9 has 13 bit (1 sign, 12 bit data). That means that
+/- 4096 indicates +/- 240% of the measured value. Some following measured values
use a different definition:
•cos Phi: -4096 relates to cos PHI = -1; +4096 relates to cos PHI = +1
Changes of the scaling of the measured values are possible in adaptation to the con-
crete installation environment (ref. to manual “IEC 60870-5-103 Communication data-
base”).
Reference Refer to chapter 3.3
Note
Depending on the device composition not all of the indicated analog inputs (and cor-
responding IEC 60870-5-103 mapping entries) may be available in the SIPROTEC®
device.
Note
If all parameterised measurement telegrams aren't transferred, the parameter Scan-
ning period (in ms) for measurements must be put on a greater value.

137VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
IEC 60870-5-103 Interoperability 2
2.1 Physical Layer 14
2.2 Link Layer 14
2.3 Application Layer 15

IEC 60870-5-103 Interoperability
14 7VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
Redundant IEC 60870-5-103
DEVICE PROFILE DOCUMENT
Vendor Name: SIEMENS AG
Device Name: 7VU683/7VU681
2.1 Physical Layer
2.1.1 Electrical Interface
EIA RS-485
Number of loads _____________ for one protection equipment
2.1.2 Optical Interface
Glass fiber
Plastic fiber
F-SMA type connector
BFOC/2,5 type connector
2.1.3 Transmission Speed
2 400 bit/s
4 800 bit/s
9 600 bit/s
19 200 bit/s
38 400 bit/s
57 600 bit/s
2.2 Link Layer
There are no choices for the link layer.

IEC 60870-5-103 Interoperability
15
7VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
2.3 Application Layer
2.3.1 Transmission Mode For Application Data
Mode 1 (least significant octet first), as defined in 4.10 of IEC 60870-5-4, is used exclusively in this
companion standard.
2.3.2 Common Address of ASDU
One Common Address of ASDU (identical with station address)
More than one Common Address of ASDU
2.3.3 Selection of Standard Information Numbers In Monitor Direction
2.3.3.1 System Functions In Monitor Direction
INF Semantics
<0> End of general interrogation
<0> Time synchronization
<2> Reset FCB
<3> Reset CU
<4> Start/restart
<5> Power on
2.3.3.2 Status Indications In Monitor Direction
INF Semantics
<19> LED reset
<20> Monitor direction blocked
<21> Test mode
<22> Local parameter setting
<23> Characteristic 1
<24> Characteristic 2
<25> Characteristic 3
<26> Characteristic 4
<27> Auxiliary input 1
<28> Auxiliary input 2
<29> Auxiliary input 3
<30> Auxiliary input 4

IEC 60870-5-103 Interoperability
16 7VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
2.3.3.3 Supervision Indications In Monitor Direction
INF Semantics
<32> Measurand supervision I
<33> Measurand supervision V
<35> Phase sequence supervision
<36> Trip circuit supervision
<37> I>> back-up operation
<38> VT fuse failure
<39> Teleprotection disturbed
<46> Group warning
<47> Group alarm
2.3.3.4 Earth Fault Indications In Monitor Direction
INF Semantics
<48> Earth fault L1
<49> Earth fault L2
<50> Earth fault L3
<51> Earth fault forward
<52> Earth fault reverse

IEC 60870-5-103 Interoperability
17
7VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
2.3.3.5 Fault Indications In Monitor Direction
INF Semantics
<64> Start /pick-up L1
<65> Start /pick-up L2
<66> Start /pick-up L3
<67> Start /pick-up N
<68> General trip
<69> Trip L1
<70> Trip L2
<71> Trip L3
<72> Trip I>> (back-up operation)
<73> Fault location X in ohms
<74> Fault forward/line
<75> Fault reverse/busbar
<76> Teleprotection signal transmitted
<77> Teleprotection signal received
<78> Zone 1
<79> Zone 2
<80> Zone 3
<81> Zone 4
<82> Zone 5
<83> Zone 6
<84> General start/pick-up
<85> Breaker failure
<86> Trip measuring system L1
<87> Trip measuring system L2
<88> Trip measuring system L3
<89> Trip measuring system E
<90> Trip I>
<91> Trip I>>
<92> Trip IN>
<93> Trip IN>>
2.3.3.6 Auto-reclosure Indications In Monitor Direction
INF Semantics
<128> CB ‘on’ by AR
<129> CB ‘on’ by long-time AR
<130> AR blocked
2.3.3.7 Measurands In Monitor Direction
INF Semantics
<144> Measurand I
<145> Measurands I, V
<146> Measurands I, V, P, Q
<147> Measurands IN, VEN
<148> Measurands IL1,2,3, VL1,2,3, P, Q, f

IEC 60870-5-103 Interoperability
18 7VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
2.3.3.8 Generic Functions In Monitor Direction
INF Semantics
<240> Read headings of all defined groups
<241> Read values or attributes of all entries of one group
<243> Read directory of a single entry
<244> Read value or attribute of a single entry
<245> End of general interrogation of generic data
<249> Write entry with confirmation
<250> Write entry with execution
<251> Write entry aborted

IEC 60870-5-103 Interoperability
19
7VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
2.3.4 Selection of Standard Information Numbers In Control Direction
2.3.4.1 System Functions In Control Direction
INF Semantics
<0> Initiation of general interrogation
<0> Time synchronization
2.3.4.2 General Commands In Control Direction
INF Semantics
<16> Auto-recloser on/off
<17> Teleprotection on/off
<18> Protection on/off
<19> LED reset
<23> Activate characteristic 1
<24> Activate characteristic 2
<25> Activate characteristic 3
<26> Activate characteristic 4
2.3.4.3 Generic Functions In Control Direction
INF Semantics
<240> Read headings of all defined groups
<241> Read values or attributes of all entries of one group
<243> Read directory of a single entry
<244> Read value or attribute of a single entry
<245> General interrogation of generic data
<248> Write entry
<249> Write entry with confirmation
<250> Write entry with execution
<251> Write entry abort
2.3.5 Basic Application Functions
Test mode
Blocking of monitor direction
Disturbance data
Generic services

IEC 60870-5-103 Interoperability
20 7VU68x Redundant T103 Bus mapping
C53000-L2540-C558-1
2.3.6 Miscellaneous
Measurand Max. MVAL = rated value times
1,2 or 2,4
Current L1
Current L2
Current L3
Voltage L1-E
Voltage L2-E
Voltage L3-E
Active power P
Reactive power Q
Frequency f
Voltage L1 - L2
