SIMATIC NET
Industrial Wireless LAN
SCALANCE W1750D CLI
Function Manual
03/2019
C7
9000-G8976-C452-04
About this guide
1
Security recommendations
2
SCALANCE W CLI
3
CLI Commands
4
Appendix A
A

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
Document order number: C79000-G8976-C452
Ⓟ
03/2019 Subject to change
Copyright © Siemens AG 2016 - 2019.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04 3
Table of contents
1 About this guide .................................................................................................................................... 13
2 Security recommendations.................................................................................................................... 15
3 SCALANCE W CLI................................................................................................................................ 19
3.1 Saving Configuration Changes ...............................................................................................22
3.2 Command Line Editing............................................................................................................23
3.3 Specifying Addresses and Identifiers in Commands ..............................................................24
3.4 Typographic Conventions .......................................................................................................25
3.5 Industry Online Support ..........................................................................................................26
4 CLI Commands..................................................................................................................................... 27
4.1 A..............................................................................................................................................27
4.1.1 a-channel ................................................................................................................................27
4.1.2 aaa dns-query-interval ............................................................................................................28
4.1.3 aaa radius-attributes ...............................................................................................................29
4.1.4 aaa radius modifier .................................................................................................................30
4.1.5 aaa test-server ........................................................................................................................31
4.1.6 a-ant-pol..................................................................................................................................31
4.1.7 advanced-zone .......................................................................................................................32
4.1.8 aeroscout-rtls ..........................................................................................................................33
4.1.9 airgroup...................................................................................................................................34
4.1.10 airgroupservice .......................................................................................................................36
4.1.11 airwave-rtls..............................................................................................................................37
4.1.12 ale-report-interval....................................................................................................................38
4.1.13 ale-server ................................................................................................................................39
4.1.14 alg ...........................................................................................................................................40
4.1.15 allowed-ap...............................................................................................................................41
4.1.16 allow-new-aps .........................................................................................................................42
4.1.17 a-max-clients...........................................................................................................................42
4.1.18 ams-backup-ip ........................................................................................................................43
4.1.19 ams-identity.............................................................................................................................44
4.1.20 ams-ip .....................................................................................................................................45
4.1.21 ams-key ..................................................................................................................................45
4.1.22 ap1x ........................................................................................................................................46
4.1.23 ap1x-peap-user.......................................................................................................................47
4.1.24 ap-frequent-scan.....................................................................................................................48
4.1.25 ap-installation..........................................................................................................................49
4.1.26 apply........................................................................................................................................49
4.1.27 arm ..........................................................................................................................................50
4.1.28 attack.......................................................................................................................................56
4.1.29 auth-failure-blacklist-time........................................................................................................57
4.1.30 auth-survivability cache-time-out ............................................................................................58

Table of contents
SCALANCE W1750D CLI
4Function Manual, 03/2019, C79000-G8976-C452-04
4.2 B............................................................................................................................................. 59
4.2.1 banner .................................................................................................................................... 59
4.2.2 blacklist-client......................................................................................................................... 60
4.2.3 blacklist-time .......................................................................................................................... 60
4.2.4 ble .......................................................................................................................................... 61
4.3 C............................................................................................................................................. 64
4.3.1 calea....................................................................................................................................... 64
4.3.2 cellular-uplink-profile .............................................................................................................. 65
4.3.3 clarity...................................................................................................................................... 68
4.3.4 clear ....................................................................................................................................... 69
4.3.5 clear airgroup state statistics ................................................................................................. 70
4.3.6 clear-dhcpoption82 ................................................................................................................ 70
4.3.7 clear-cert ................................................................................................................................ 71
4.3.8 clock set ................................................................................................................................. 72
4.3.9 clock summer-time................................................................................................................. 73
4.3.10 clock timezone ....................................................................................................................... 75
4.3.11 cluster-security....................................................................................................................... 75
4.3.12 cluster-security logging .......................................................................................................... 77
4.3.13 commit.................................................................................................................................... 78
4.3.14 configure terminal................................................................................................................... 79
4.3.15 console................................................................................................................................... 79
4.3.16 content-filtering....................................................................................................................... 80
4.3.17 convert-aos-ap ....................................................................................................................... 81
4.3.18 copy........................................................................................................................................ 82
4.3.19 custom_var............................................................................................................................. 84
4.4 D............................................................................................................................................. 85
4.4.1 debug-rtls-logs ....................................................................................................................... 85
4.4.2 deny-inter-user-bridging......................................................................................................... 85
4.4.3 deny-local-routing................................................................................................................... 86
4.4.4 device-id................................................................................................................................. 87
4.4.5 dhcp ....................................................................................................................................... 88
4.4.6 disable-prov-ssid.................................................................................................................... 89
4.4.7 disconnect-user...................................................................................................................... 89
4.4.8 dot-11a-radio-disable ............................................................................................................. 90
4.4.9 dot-11g-radio-disable ............................................................................................................. 91
4.4.10 download-cert......................................................................................................................... 91
4.4.11 download-dhcpopt82.............................................................................................................. 93
4.4.12 dpi .......................................................................................................................................... 94
4.4.13 dpi-error-page-url ................................................................................................................... 95
4.4.14 dynamic-cpu-mgmt ................................................................................................................ 95
4.4.15 dynamic-dns........................................................................................................................... 96
4.4.16 dynamic-dns-ap...................................................................................................................... 98
4.4.17 dynamic-dns-interval.............................................................................................................. 99
4.4.18 dynamic-radius-proxy........................................................................................................... 100
4.4.19 dynamic-tacacs-proxy .......................................................................................................... 100

Table of contents
SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04 5
4.5 E............................................................................................................................................102
4.5.1 enet-vlan ...............................................................................................................................102
4.5.2 enet0-bridging .......................................................................................................................103
4.5.3 enet0-port-profile...................................................................................................................103
4.5.4 enet1-port-profile...................................................................................................................104
4.5.5 enet3-port-profile...................................................................................................................105
4.5.6 enet2-port-profile...................................................................................................................105
4.5.7 enet4-port-profile...................................................................................................................106
4.5.8 enhanced-mesh-role-detect..................................................................................................107
4.5.9 extended-ssid........................................................................................................................108
4.6 F............................................................................................................................................109
4.6.1 facebook ...............................................................................................................................109
4.6.2 factory-ssid-enable................................................................................................................109
4.6.3 firewall...................................................................................................................................110
4.6.4 firewall-external-enforcement ...............................................................................................111
4.7 G ...........................................................................................................................................113
4.7.1 g-channel ..............................................................................................................................113
4.7.2 g-ant-pol................................................................................................................................113
4.7.3 g-max-clients.........................................................................................................................114
4.7.4 gre.........................................................................................................................................115
4.8 H............................................................................................................................................118
4.8.1 hash-mgmt-password ...........................................................................................................118
4.8.2 hash-mgmt-user....................................................................................................................118
4.8.3 help .......................................................................................................................................120
4.8.4 hostname ..............................................................................................................................121
4.8.5 hotspot anqp-3-gpp-profile....................................................................................................122
4.8.6 hotspot anqp-domain-name-profile.......................................................................................123
4.8.7 hotspot-anqp-ip-addr-avail-profile.........................................................................................124
4.8.8 hotspot anqp-nai-realm-profile..............................................................................................126
4.8.9 hotspot anqp-nwk-auth-profile ..............................................................................................130
4.8.10 hotspot anqp-roam-cons-profile............................................................................................132
4.8.11 hotspot anqp-venue-name-profile.........................................................................................133
4.8.12 hotspot h2qp-conn-cap-profile ..............................................................................................137
4.8.13 hotspot h2qp-oper-class-profile ............................................................................................138
4.8.14 hotspot-h2qp-oper-name-profile ...........................................................................................140
4.8.15 hotspot h2qp-osu-provider-profile.........................................................................................141
4.8.16 hotspot h2qp-wan-metrics-profile .........................................................................................145
4.8.17 hotspot hs-profile ..................................................................................................................147
4.8.18 hs2-osu-icon-delete ..............................................................................................................157
4.8.19 hs2-osu-icon-download.........................................................................................................158
4.9 I .............................................................................................................................................160
4.9.1 iap-master .............................................................................................................................160
4.9.2 ids..........................................................................................................................................160
4.9.3 ignore-image-check ..............................................................................................................168
4.9.4 inactivity-ap-timeout..............................................................................................................169
4.9.5 inbound-firewall.....................................................................................................................170
4.9.6 internal-domains ...................................................................................................................172
4.9.7 iot transportProfile.................................................................................................................173
4.9.8 iot usetransportProfile...........................................................................................................177
4.9.9 ip-address .............................................................................................................................178

Table of contents
SCALANCE W1750D CLI
6Function Manual, 03/2019, C79000-G8976-C452-04
4.9.10 ip dhcp.................................................................................................................................. 179
4.9.11 ip dhcp pool.......................................................................................................................... 185
4.9.12 ip-mode ................................................................................................................................ 187
4.9.13 ipm ....................................................................................................................................... 188
4.9.14 ip radius................................................................................................................................ 189
4.10 L ........................................................................................................................................... 190
4.10.1 l3-mobility ............................................................................................................................. 190
4.10.2 lacp-mode ............................................................................................................................ 191
4.10.3 led-off ................................................................................................................................... 192
4.10.4 loginsession ......................................................................................................................... 193
4.10.5 logout ................................................................................................................................... 194
4.11 M .......................................................................................................................................... 195
4.11.1 mas-integration .................................................................................................................... 195
4.11.2 managed-mode-profile......................................................................................................... 196
4.11.3 managed-mode-sync-server................................................................................................ 198
4.11.4 mesh .................................................................................................................................... 198
4.11.5 mesh-cluster......................................................................................................................... 200
4.11.6 mesh-disable........................................................................................................................ 201
4.11.7 mgmt-accounting.................................................................................................................. 201
4.11.8 mgmt-auth-server................................................................................................................. 202
4.11.9 mgmt-auth-server-load-balancing........................................................................................ 203
4.11.10 mgmt-auth-server-local-backup ........................................................................................... 204
4.11.11 mgmt-user ............................................................................................................................ 205
4.11.12 mtu ....................................................................................................................................... 206
4.12 N........................................................................................................................................... 207
4.12.1 name .................................................................................................................................... 207
4.12.2 ntp-server ............................................................................................................................. 207
4.13 O .......................................................................................................................................... 209
4.13.1 opendns ............................................................................................................................... 209
4.13.2 openflow-server.................................................................................................................... 210
4.13.3 organization.......................................................................................................................... 211
4.13.4 out-of-service-hold-on-time .................................................................................................. 212
4.14 P........................................................................................................................................... 213
4.14.1 pcap ..................................................................................................................................... 213
4.14.2 per-ap-ssid ........................................................................................................................... 214
4.14.3 per-ap-vlan ........................................................................................................................... 214
4.14.4 pin-enable ............................................................................................................................ 215
4.14.5 pin-puk ................................................................................................................................. 216
4.14.6 pin-renew ............................................................................................................................. 216
4.14.7 ping ...................................................................................................................................... 217
4.14.8 pppoe-uplink-profile ............................................................................................................. 218
4.14.9 proxy .................................................................................................................................... 219
4.15 R........................................................................................................................................... 221
4.15.1 radius-vsa-redirect-url .......................................................................................................... 221
4.15.2 reload ................................................................................................................................... 222
4.15.3 remove-blacklist-client ......................................................................................................... 223
4.15.4 reset drt ................................................................................................................................ 224
4.15.5 restrict-corp-access.............................................................................................................. 224
4.15.6 restrict-mgmt-access............................................................................................................ 225

Table of contents
SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04 7
4.15.7 rf-band...................................................................................................................................226
4.15.8 rf-zone...................................................................................................................................227
4.15.9 rf dot11g-radio-profile............................................................................................................227
4.15.10 rf dot11a-radio-profile............................................................................................................232
4.15.11 routing-profile ........................................................................................................................236
4.16 S............................................................................................................................................238
4.16.1 show 1xcert...........................................................................................................................238
4.16.2 show aaa...............................................................................................................................238
4.16.3 show about............................................................................................................................239
4.16.4 show access-rule ..................................................................................................................240
4.16.5 show access-rule-all .............................................................................................................242
4.16.6 show acl ................................................................................................................................243
4.16.7 show airgroup .......................................................................................................................244
4.16.8 show airgroupservice ............................................................................................................254
4.16.9 show aigroupservice-ids .......................................................................................................257
4.16.10 show ale................................................................................................................................258
4.16.11 show ale stats .......................................................................................................................260
4.16.12 show alert global ...................................................................................................................261
4.16.13 show alg................................................................................................................................263
4.16.14 show all monitor ....................................................................................................................264
4.16.15 show allowed-aps .................................................................................................................265
4.16.16 show a-max-clients ...............................................................................................................266
4.16.17 show amp-audit.....................................................................................................................267
4.16.18 show ap allowed-channels....................................................................................................272
4.16.19 show ap allowed-max-EIRP..................................................................................................273
4.16.20 show ap arm .........................................................................................................................275
4.16.21 show ap association..............................................................................................................283
4.16.22 show ap bss-table .................................................................................................................284
4.16.23 show ap cacert......................................................................................................................286
4.16.24 show ap mesh cluster ...........................................................................................................288
4.16.25 show ap mpskcache .............................................................................................................290
4.16.26 show ap checksum ...............................................................................................................291
4.16.27 show ap client-match-live .....................................................................................................292
4.16.28 show ap client-match-history ................................................................................................293
4.16.29 show ap client-match-refused...............................................................................................294
4.16.30 show ap client-match-ssid-table radio-mac ..........................................................................296
4.16.31 show ap client-match-triggers...............................................................................................297
4.16.32 show ap client-probe-report ..................................................................................................298
4.16.33 show ap client-view...............................................................................................................299
4.16.34 show ap debug airwave ........................................................................................................300
4.16.35 show ap debug airwave-config-received ..............................................................................311
4.16.36 show ap debug airwave-data-sent........................................................................................312
4.16.37 show ap debug airwave-events-pending ..............................................................................313
4.16.38 show ap debug airwave-restore-status.................................................................................314
4.16.39 show ap debug airwave-signon-key .....................................................................................314
4.16.40 show ap debug airwave-state ...............................................................................................315
4.16.41 show ap debug airwave-stats ...............................................................................................317
4.16.42 show ap debug am-config.....................................................................................................319
4.16.43 show ap debug auth-trace-buf ..............................................................................................320
4.16.44 show ap debug ble-config.....................................................................................................321
4.16.45 show ap debug ble-counters.................................................................................................323
4.16.46 show ap debug ble-daemon .................................................................................................323

Table of contents
SCALANCE W1750D CLI
8Function Manual, 03/2019, C79000-G8976-C452-04
4.16.47 show ap debug ble-relay...................................................................................................... 324
4.16.48 show ap debug ble-table...................................................................................................... 327
4.16.49 show ap debug ble-table assettags ..................................................................................... 328
4.16.50 show ap debug client-frame-history ..................................................................................... 329
4.16.51 show ap debug client-match ................................................................................................ 330
4.16.52 show ap debug client-stats .................................................................................................. 331
4.16.53 show ap debug client-table .................................................................................................. 337
4.16.54 show ap debug core-info...................................................................................................... 339
4.16.55 show ap debug crash-info.................................................................................................... 340
4.16.56 show ap debug dhcp-packets .............................................................................................. 340
4.16.57 show ap debug dot1x-statistics............................................................................................ 342
4.16.58 show ap debug driver-config................................................................................................ 343
4.16.59 show ap debug lldp .............................................................................................................. 348
4.16.60 show ap debug lldp neighbor ............................................................................................... 350
4.16.61 show ap debug lldp state ..................................................................................................... 351
4.16.62 show ap debug mgmt-frames .............................................................................................. 352
4.16.63 show ap debug network-bssid ............................................................................................. 353
4.16.64 show ap debug persistent-clients......................................................................................... 354
4.16.65 show ap debug power-table................................................................................................. 355
4.16.66 show ap debug radio-stats................................................................................................... 356
4.16.67 show ap debug radius-statistics........................................................................................... 359
4.16.68 show ap debug rfc3576-radius-statistics ............................................................................. 360
4.16.69 show ap debug shaping-table .............................................................................................. 362
4.16.70 show ap debug spanning-tree.............................................................................................. 364
4.16.71 show ap debug stm-config ................................................................................................... 365
4.16.72 show ap debug stm-role....................................................................................................... 366
4.16.73 show ap debug stystem-status ............................................................................................ 366
4.16.74 show ap debug tacas-statistics............................................................................................ 367
4.16.75 show ap dot11k-beacon-report ............................................................................................ 368
4.16.76 show ap dot11k-nbrs............................................................................................................ 369
4.16.77 show ap flash-config ............................................................................................................ 370
4.16.78 show ap mesh counters ....................................................................................................... 371
4.16.79 show ap mesh link ............................................................................................................... 373
4.16.80 show ap mesh neighbors ..................................................................................................... 375
4.16.81 show ap monitor................................................................................................................... 377
4.16.82 show ap pmkcache .............................................................................................................. 389
4.16.83 show ap virtual-beacon-report ............................................................................................. 390
4.16.84 show ap1x ............................................................................................................................ 392
4.16.85 show ap1xcert...................................................................................................................... 392
4.16.86 show ap-alert........................................................................................................................ 393
4.16.87 show ap-env......................................................................................................................... 394
4.16.88 show aps .............................................................................................................................. 395
4.16.89 show app-services ............................................................................................................... 398
4.16.90 show arm config................................................................................................................... 400
4.16.91 show arm-channels.............................................................................................................. 402
4.16.92 show arp............................................................................................................................... 404
4.16.93 show attack .......................................................................................................................... 405
4.16.94 show audit-trail ..................................................................................................................... 407
4.16.95 show auth-surviveability....................................................................................................... 408
4.16.96 show backup-config ............................................................................................................. 409
4.16.97 show banner......................................................................................................................... 411
4.16.98 show blacklist-client ............................................................................................................. 412

Table of contents
SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04 9
4.16.99 show ble-config .....................................................................................................................413
4.16.100 show calea config .................................................................................................................414
4.16.101 show calea statistics .............................................................................................................415
4.16.102 show cellular .........................................................................................................................416
4.16.103 show cert all ..........................................................................................................................419
4.16.104 show clarity ...........................................................................................................................421
4.16.105 show clearpassca .................................................................................................................423
4.16.106 show clients ..........................................................................................................................423
4.16.107 show clock ............................................................................................................................427
4.16.108 show cluster-security ............................................................................................................430
4.16.109 show config-status ................................................................................................................436
4.16.110 show configuration ................................................................................................................437
4.16.111 show console-setttings..........................................................................................................443
4.16.112 show country-codes ..............................................................................................................444
4.16.113 show cpcert...........................................................................................................................447
4.16.114 show cpu...............................................................................................................................448
4.16.115 show datapath.......................................................................................................................450
4.16.116 show ddns.............................................................................................................................471
4.16.117 show delta-config ..................................................................................................................472
4.16.118 show derivation-rules ............................................................................................................473
4.16.119 show dhcp-allocation ............................................................................................................474
4.16.120 show dhcps config ................................................................................................................475
4.16.121 show dhcpc-opts ...................................................................................................................477
4.16.122 show dhcp.............................................................................................................................478
4.16.123 show distributed-dhcp-branch-counts...................................................................................480
4.16.124 show domain-names.............................................................................................................482
4.16.125 show dpi................................................................................................................................482
4.16.126 show dpi-error-page-urls.......................................................................................................489
4.16.127 show dpi-stats .......................................................................................................................490
4.16.128 show drt state........................................................................................................................494
4.16.129 show election ........................................................................................................................495
4.16.130 show esl ................................................................................................................................497
4.16.131 show esl-radio.......................................................................................................................497
4.16.132 show facebook ......................................................................................................................498
4.16.133 show fault..............................................................................................................................499
4.16.134 show fiewall...........................................................................................................................500
4.16.135 show g-max-clients ...............................................................................................................501
4.16.136 show gre config.....................................................................................................................502
4.16.137 show gre status.....................................................................................................................503
4.16.138 show ids ................................................................................................................................505
4.16.139 show ids-detection config .....................................................................................................507
4.16.140 show ids-protection config ....................................................................................................509
4.16.141 show inbound-firewall-rules ..................................................................................................510
4.16.142 show interface counters........................................................................................................511
4.16.143 show image...........................................................................................................................512
4.16.144 show iot transportProfile .......................................................................................................513
4.16.145 show ip dhcp database .........................................................................................................514
4.16.146 show ip igmp .........................................................................................................................515
4.16.147 show ip interface ...................................................................................................................517
4.16.148 show ip route.........................................................................................................................518
4.16.149 show ipv6 interface ...............................................................................................................519
4.16.150 show ipv6 route.....................................................................................................................520

Table of contents
SCALANCE W1750D CLI
10 Function Manual, 03/2019, C79000-G8976-C452-04
4.16.151 show l3-mobility.................................................................................................................... 521
4.16.152 show lacp status................................................................................................................... 526
4.16.153 show ldap-servers................................................................................................................ 527
4.16.154 show lhm .............................................................................................................................. 528
4.16.155 show log ap-debug............................................................................................................... 530
4.16.156 show log apifmgr.................................................................................................................. 531
4.16.157 show log convert .................................................................................................................. 531
4.16.158 show log debug.................................................................................................................... 531
4.16.159 show log drive ...................................................................................................................... 532
4.16.160 show log kernel .................................................................................................................... 532
4.16.161 show log l3-mobility.............................................................................................................. 533
4.16.162 show log network ................................................................................................................. 534
4.16.163 show log openflow ............................................................................................................... 535
4.16.164 show log papi-handler.......................................................................................................... 535
4.16.165 show log pppd ...................................................................................................................... 535
4.16.166 show log rapper.................................................................................................................... 536
4.16.167 show log rapper-brief ........................................................................................................... 536
4.16.168 show log rapper-counter ...................................................................................................... 537
4.16.169 show log sapd ...................................................................................................................... 538
4.16.170 show log scd ........................................................................................................................ 539
4.16.171 show log security.................................................................................................................. 540
4.16.172 show log system................................................................................................................... 540
4.16.173 show log upgrade................................................................................................................. 541
4.16.174 show log user ....................................................................................................................... 541
4.16.175 show log user-debug............................................................................................................ 542
4.16.176 show log vpn-tunnel-primary................................................................................................ 542
4.16.177 show log vpn-tunnel-backup ................................................................................................ 543
4.16.178 show log vpn-tunnel ............................................................................................................. 544
4.16.179 show log wireless................................................................................................................. 545
4.16.180 show memory....................................................................................................................... 545
4.16.181 show mgmt-user................................................................................................................... 547
4.16.182 show network ....................................................................................................................... 548
4.16.183 show network-summary ....................................................................................................... 550
4.16.184 show openflow ..................................................................................................................... 551
4.16.185 show opendns ...................................................................................................................... 552
4.16.186 show out-of-service.............................................................................................................. 553
4.16.187 show pppoe.......................................................................................................................... 554
4.16.188 show port status................................................................................................................... 555
4.16.189 show process ....................................................................................................................... 557
4.16.190 show proxy config ................................................................................................................ 558
4.16.191 show radio config ................................................................................................................. 559
4.16.192 show radio profile................................................................................................................. 561
4.16.193 show radius-redirect-url ....................................................................................................... 563
4.16.194 show radius-servers support................................................................................................ 564
4.16.195 show radius status ............................................................................................................... 565
4.16.196 show radseccert................................................................................................................... 567
4.16.197 show rlts-logs ....................................................................................................................... 568
4.16.198 show rlts-tags ....................................................................................................................... 569
4.16.199 show running-config............................................................................................................. 569
4.16.200 show snmp-configuration ..................................................................................................... 573
4.16.201 show snmp trap-queue ........................................................................................................ 574
4.16.202 show ssh .............................................................................................................................. 575

Table of contents
SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04 11
4.16.203 show spectum-alert...............................................................................................................576
4.16.204 show speed-test....................................................................................................................577
4.16.205 show stats .............................................................................................................................578
4.16.206 show subscription-aps ..........................................................................................................586
4.16.207 show summary......................................................................................................................587
4.16.208 show supported-cert-formats ................................................................................................588
4.16.209 show swarm ..........................................................................................................................588
4.16.210 show syslog-level..................................................................................................................590
4.16.211 show tacas-servers ...............................................................................................................591
4.16.212 show tech-support.................................................................................................................592
4.16.213 show time-profile...................................................................................................................593
4.16.214 show time-range ...................................................................................................................594
4.16.215 show tspec-calls....................................................................................................................595
4.16.216 show usb status ....................................................................................................................596
4.16.217 show uncommitted-config .....................................................................................................598
4.16.218 show upgrade info.................................................................................................................598
4.16.219 show uplink ...........................................................................................................................599
4.16.220 show uplink-vlan ...................................................................................................................601
4.16.221 show url-visibility...................................................................................................................602
4.16.222 show user..............................................................................................................................604
4.16.223 show valid-channels..............................................................................................................605
4.16.224 show vlan ..............................................................................................................................607
4.16.225 show version .........................................................................................................................607
4.16.226 show vpn...............................................................................................................................608
4.16.227 show vpn tunnels ..................................................................................................................611
4.16.228 show walled-garden ..............................................................................................................612
4.16.229 show wifi-uplink.....................................................................................................................613
4.16.230 show wired-port.....................................................................................................................615
4.16.231 show wired-port-settings.......................................................................................................617
4.16.232 show wispr config..................................................................................................................619
4.16.233 show xml-api-server
..............................................................................................................620
4.16.234 sesimagotag-esl-channel......................................................................................................621
4.16.235 sesimagotag-esl-profile.........................................................................................................621
4.16.236 snmp-server ..........................................................................................................................622
4.16.237 speed test .............................................................................................................................623
4.16.238 speed test <server> ..............................................................................................................625
4.16.239 ssh.........................................................................................................................................627
4.16.240 subscription-ap......................................................................................................................627
4.16.241 subscription-ap-enable..........................................................................................................628
4.16.242 swarm-mode .........................................................................................................................629
4.16.243 syslog-level ...........................................................................................................................630
4.16.244 syslocation ............................................................................................................................631
4.16.245 syslog-server.........................................................................................................................632
4.17 T............................................................................................................................................633
4.17.1 telnet .....................................................................................................................................633
4.17.2 telnet-server ..........................................................................................................................633
4.17.3 terminal-access.....................................................................................................................634
4.17.4 tftp-dump-server....................................................................................................................635
4.17.5 traceroute..............................................................................................................................636
4.17.6 time-range.............................................................................................................................636
4.18 U............................................................................................................................................639

Table of contents
SCALANCE W1750D CLI
12 Function Manual, 03/2019, C79000-G8976-C452-04
4.18.1 upgrade-drt........................................................................................................................... 639
4.18.2 upgrade-image..................................................................................................................... 639
4.18.3 uplink.................................................................................................................................... 641
4.18.4 uplink-vlan ............................................................................................................................ 644
4.18.5 usb-port-disable ................................................................................................................... 645
4.18.6 user ...................................................................................................................................... 645
4.18.7 url-visibility............................................................................................................................ 647
4.19 V........................................................................................................................................... 649
4.19.1 version.................................................................................................................................. 649
4.19.2 virtual-controller.................................................................................................................... 649
4.19.3 vlan....................................................................................................................................... 651
4.19.4 vlan-name ............................................................................................................................ 652
4.19.5 vpn backup........................................................................................................................... 652
4.19.6 vpn fast-failover.................................................................................................................... 653
4.19.7 vpn gre-outside .................................................................................................................... 654
4.19.8 vpn hold-time........................................................................................................................ 655
4.19.9 vpn ikepsk ............................................................................................................................ 656
4.19.10 vpn monitor-pkt-lost-cnt ....................................................................................................... 656
4.19.11 vpn monitor-pkt-send-freq.................................................................................................... 657
4.19.12 vpn reconnect-user-on-failover ............................................................................................ 658
4.19.13 vpn reconnect-time-on-failure .............................................................................................. 659
4.19.14 vpn preemption .................................................................................................................... 660
4.19.15 vpn primary .......................................................................................................................... 660
4.20 W.......................................................................................................................................... 662
4.20.1 wlan walled-garden .............................................................................................................. 662
4.20.2 web-server ........................................................................................................................... 663
4.20.3 wlan captive-portal ............................................................................................................... 664
4.20.4 wlan ssid-profile ................................................................................................................... 667
4.20.5 wlan-external-captive-portal................................................................................................. 690
4.20.6 wlan auth-server................................................................................................................... 693
4.20.7 wlan access-rule .................................................................................................................. 696
4.20.8 wifi1-mode............................................................................................................................ 701
4.20.9 wificall-dns-pattern ............................................................................................................... 702
4.20.10 wlan wispr-profile ................................................................................................................. 703
4.20.11 wifi0-mode............................................................................................................................ 704
4.20.12 wlan ldap-server................................................................................................................... 705
4.20.13 write...................................................................................................................................... 708
4.20.14 wired-port-profile .................................................................................................................. 708
4.20.15 wlan sta-profile ..................................................................................................................... 717
4.20.16 wlan tacacs-server ............................................................................................................... 718
4.21 X........................................................................................................................................... 721
4.21.1 xml-api-server ...................................................................................................................... 721
4.22 Z ........................................................................................................................................... 723
4.22.1 zeroize-tpm-keys.................................................................................................................. 723
4.22.2 zonenmane .......................................................................................................................... 724
A Appendix A ..........................................................................................................................................725
A.1 Glossary of Terms................................................................................................................ 725
Index ...................................................................................................................................................757

SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04 13
About this guide
1
This document describes the CLI command syntax and provides the following information for
each command:
●Command Syntax—The complete syntax of the command.
●Description—A brief description of the command.
●Syntax—A description of the command parameters, the applicable ranges and default
values, if any.
●Usage Guidelines—Information to help you use the command, including prerequisites,
prohibitions, and related commands.
●Example—An example of how to use the command.
●Command Information—This table describes command modes and platforms for which
this command is applicable.
The commands are listed in alphabetical order.
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be
connected to an enterprise network or the internet if and to the extent such a connection is
necessary and only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit https://www.siemens.com/industrialsecurity.
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers’ exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under https://www.siemens.com/industrialsecurity.

About this guide
SCALANCE W1750D CLI
14 Function Manual, 03/2019, C79000-G8976-C452-04

SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04 15
Security recommendations
2
To prevent unauthorized access, note the following security recommendations.
General
●You should make regular checks to make sure that the device meets these
recommendations and/or other security guidelines.
●Evaluate your plant as a whole in terms of security. Use a cell protection concept with
suitable products (https://www.industry.siemens.com/topics/global/en/industrial-
security/pages/default.aspx).
●When the internal and external network are disconnected, an attacker cannot access
internal data from the outside. Therefore operate the device only within a protected
network area.
●For communication via non-secure networks use additional devices with VPN functionality
to encrypt and authenticate the communication.
●Terminate management connections correctly (WBM. Telnet, SSH etc.).
Physical access
●Restrict physical access to the device to qualified personnel.
Software (security functions)
●Keep the software up to date. Check regularly for security updates of the product. You will
find information on this on the Internet pages "Industrial Security
(https://www.siemens.com/industrialsecurity)" .
●Inform yourself regularly about security advisories and bulletins published by Siemens
ProductCERT (https://www.siemens.com/cert/en/cert-security-advisories.htm).
●Only activate protocols that you really require to use the device.
●Use the security functions such as address translation with NAT (Network Address
Translation) or NAPT (Network Address Port Translation) to protect receiving ports from
access by third parties.
●Restrict access to the device with a firewall or rules in an access control list (ACL -
Access Control List).
●If RADIUS authentication is via remote access, make sure that the communication is
within the secured network area or is via a secure channel.
●The option of VLAN structuring provides good protection against DoS attacks and
unauthorized access. Check whether this is practical or useful in your environment.
●Enable logging functions. Use the central logging function to log changes and access
attempts centrally. Check the logging information regularly.

Security recommendations
SCALANCE W1750D CLI
16 Function Manual, 03/2019, C79000-G8976-C452-04
●Configure a Syslog server to forward all logs to a central location.
●Use WPA2/ WPA2-PSK with AES to protect the WLAN.
Software (security functions)
●Restrict physical access to the device to qualified personnel
Passwords
●Define rules for the use of devices and assignment of passwords.
●Regularly update passwords and keys to increase security.
●Change all default passwords for users before you operate the device.
●Only use passwords with a high password strength. Avoid weak passwords for example
password1, 123456789, abcdefgh.
●Make sure that all passwords are protected and inaccessible to unauthorized personnel.
●Do not use the same password for different users and systems or after it has expired.
Keys and certificates
●This section deals with the security keys and certificates you require to set up HTTPS (
Hypertext Transfer Protocol Secured Socket Layer).
●We strongly recommend that you create your own HTTPS certificates and make them
available. There are preset certificates and keys on the device. The preset and
automatically created HTTPS certificates are self-signed. We recommend that you use
HTTPS certificates signed either by a reliable external or by an internal certification
authority. The HTTPS certificate checks the identity of the device and controls the
encrypted data exchange. You can install the HTTPS certificate via the Configuration
Manual “SCALANCE W UI”, see "Uploading Certificate".
●Handle user-defined private keys with great caution if you use user-defined SSH or SSL
keys.
●Use the certification authority including key revocation and management to sign the
certificates.
●Verify certificates and fingerprints on the server and client to avoid "man in the middle"
attacks.
●We recommend that you use certificates with a key length of 2048 bits.
●Change keys and certificates immediately, if there is a suspicion of compromise.

Security recommendations
SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04 17
Secure/non-secure protocols
●Avoid and disable non-secure protocols, for example Telnet and TFTP. For historical
reasons, these protocols are still available, however not intended for secure applications.
Use non-secure protocols on the device with caution.
●The following protocols provide secure alternatives:
–SNMPv1/v2 → SNMPv3
Check whether use of SNMPv1 is necessary. SNMPv1 is classified as non-secure.
Use the option of preventing write access. The product provides you with suitable
setting options. If SNMP is enabled, change the community names. If no unrestricted
access is necessary, restrict access with SNMP. Use SNMPv3 in conjunction with
passwords.
–HTTP → HTTPS
–Telnet → SSH
–SNTP → NTP
–Use secure protocols when access to the device is not prevented by physical
protection measures.
●To prevent unauthorized access to the device or network, take suitable protective
measures against non-secure protocols.
●If you require non-secure protocols and services, operate the device only within a
protected network area.
●Restrict the services and protocols available to the outside to a minimum.
Available protocols per port
The following list provides you with an overview of the open ports on this device. The table
includes the following columns:
●Protocol
All protocols that the device supports
●Port number
Port number assigned to the protocol
●Port status
–Open: The port is always open and cannot be closed.
●Factory setting
–Open: The factory setting of the port is "Open".
–Closed: The factory setting of the port is "Closed".
●Authentication
Specifies whether or not the protocol is authenticated.

Security recommendations
SCALANCE W1750D CLI
18 Function Manual, 03/2019, C79000-G8976-C452-04
Protocol
Port number
Port status
Factory setting of the
port
Authentication
Air Monitor
UDP/1144
Open
Open
Yes
Airgroup UDP/53536 Open Open Yes
Airgroup Master to
slave
UDP/53535 Open Open No
Bootps UDP/67 Open Open No
Captive portal
TCP/8080
Open
Open
Yes
DHCP
UDP/1067
Open
Open
No
UDP/4011
Open
Open
No
DTLS
UDP/4433
Open
Open
Yes
HTTP (redirect
4343)
TCP/80
Open
Open
No
TCP/4343
Open
Open
Yes
HTTPS
TCP/4343
Open
Open
Yes
TCP/443
Open
Open
Yes
mDNS
UDP/5353
Open
Open
No
NTP
UDP/123
Open
Open
No
Proprietary
UDP/8209
Open
Open
No
UDP/8211
Open
Open
No
Proprietary
(dTable)
UDP/8612 Open Open No
RADIUS
UDP/1616
Open
Open
No
UDP/1892
Open
Open
No
SNMPv1
UDP/161
Open
Open
No
SNMPv3 UDP/161 Open Open Yes
SSH
TCP/22
Open
Open
Yes
TCP/2322
Open
Open
Yes
Syslog
UDP/514
Open
Open
No
Telnet
TCP/23
Open
Open
Yes

SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04 19
SCALANCE W CLI
3
SCALANCE W supports the use of CLI for scripting purposes. You can access the
SCALANCE W CLI through a SSH.
To enable the SSH access to the SCALANCE CLI:
1. From the SCALCNCE W UI, navigate to System > Show advanced options.
2. Select Enabled from the Terminal access drop-down list.
3. Click OK.
Connecting to a CLI Session
On connecting to a CLI session, the system displays its host name followed by the login
prompt. Use the administrator credentials to start a CLI session. For example:
(scalance)
User: admin
Password: *****
If the login is successful, the privileged command mode is enabled and a command prompt
is displayed. For example:
(scalance)#
The privileged mode provides access to show, clear, ping, traceroute, and commit
commands. The configuration commands are available in the configuration (config) mode.
To move from privileged mode to the configuration mode, enter the following command at
the command prompt:
(scalance)# configure terminal
The configure terminal command allows you to enter the basic configuration mode and the
command prompt is displayed as follows:
(scalance)(config)#
The SCALANCE W CLI allows CLI scripting in several other sub-command modes to allow
the users to configure individual interfaces, SSIDs, access rules, and security settings.
You can use the question mark (?) to view the commands available in a privileged mode,
configuration mode, or sub-mode
Note
Although automatic completion is supported for some commands such as configure terminal,
the complete exit
and
end
commands must be entered at command prompt for successful
execution.

SCALANCE W CLI
SCALANCE W1750D CLI
20 Function Manual, 03/2019, C79000-G8976-C452-04
Applying Configuration Changes
Each command processed by the Virtual Controller is applied on all the slave APs in a
cluster. When you make configuration changes on a master AP in the CLI, all associated
APs in the cluster inherit these changes and subsequently update their configurations. The
changes configured in a CLI session are saved in the CLI context.
The CLI does not support the configuration data exceeding the 4K buffer size in a CLI
session: therefore, SCALANCE W recommends that you configure fewer changes at a time
and apply the changes at regular intervals.
To apply and save the configuration changes at regular intervals, use the following command
in the privileged mode:
(scalance)# commit apply
To apply the configuration changes to the cluster, without saving the configuration, use the
following command in the privileged mode:
(scalance)# commit apply no-save
To view the changes that are yet to be applied, use the following command in the privileged
mode:
(scalance)# show uncommitted-config
To revert to the earlier configuration, use the following command in the privileged mode.
(scalance)# commit revert
Example:
(scalance)(config)# rf dot11a-radio-profile
(scalance)# show uncommitted-config
Configuration Sub-modes
Some commands in configuration mode allow you to enter into a sub-mode to configure the
commands specific to that mode. When you are in a configuration sub-mode, the command
prompt changes to indicate the current sub-mode.
You can exit a sub-command mode and return to the basic configuration mode or the
privileged Exec (enable) mode at any time by executing the exit or end command.
