Siemens SIRIUS Soft Starter 3RW5 User manual

SIRIUS Soft Starter 3RW5 PCS 7 Library
Industrial Controls
SIRIUS Soft Starter 3RW5
SIRIUS Soft Starter 3RW5 PCS 7
Library
Getting Started
02/2020
A5E48411356002A/RS
-AA/001
Security information
1
Preface
2
Product specific security
information
3
Introduction
4
Getting Started
5
Reference
6
List of Abbreviations
7

Siemens AG
Smart Infrastructure
Control
Products
Werner
-von-Siemens-Str. 48-50
92224 AMBERG
GERMANY
A5E48411356002A/RS-AA/001
Ⓟ
02/2020 Subject to change
Copyright © Siemens AG 2019.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIRIUS Soft Starter 3RW5 PCS 7 Library
Getting Started, 02/2020, A5E48411356002A/RS-AA/001 3
Table of contents
1 Security information ................................................................................................................................ 5
2 Preface ................................................................................................................................................... 7
3 Product specific security information ..................................................................................................... 11
4 Introduction ........................................................................................................................................... 13
4.1 Introduction .............................................................................................................................13
5 Getting Started...................................................................................................................................... 15
5.1 Versions and Documentation..................................................................................................15
5.2 Installation...............................................................................................................................15
5.3 HW Config...............................................................................................................................16
5.4 CFC.........................................................................................................................................17
5.5 Operator Station......................................................................................................................22
6 Reference ............................................................................................................................................. 33
7 List of Abbreviations.............................................................................................................................. 35
7.1 Abbreviations ..........................................................................................................................35

Table of contents
SIRIUS Soft Starter 3RW5 PCS 7 Library
4Getting Started, 02/2020, A5E48411356002A/RS-AA/001

SIRIUS Soft Starter 3RW5 PCS 7 Library
Getting Started, 02/2020, A5E48411356002A/RS-AA/001 5
Security information
1
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be
connected to an enterprise network or the internet if and to the extent such a connection is
necessary and only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit
https://www.siemens.com/industrialsecurity.
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customer’s exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
https://www.siemens.com/industrialsecurity.

Security information
SIRIUS Soft Starter 3RW5 PCS 7 Library
6Getting Started, 02/2020, A5E48411356002A/RS-AA/001

SIRIUS Soft Starter 3RW5 PCS 7 Library
Getting Started, 02/2020, A5E48411356002A/RS-AA/001 7
Preface
2
Brief description
The Getting Started for the Soft Starter 3RW5 PCS 7 Library uses a simple sample project to
show you the basic procedures:
●Basic configuration steps
●Handling and monitoring different signal blocks
This Getting Started document is intended to be an introduction for using Soft Starter 3RW5
PCS 7 Library.
Requirements
Basic knowledge of creating a SIMATIC PCS 7 project is necessary. You will find information
about this in the Process Control System PCS 7; Getting Started (V9.0 or higher with APL)
documentation on the Internet
(https://support.industry.siemens.com/cs/document/109756196).
Conventions
This documentation contains designations of the software interface elements. If you have
installed a multi-language package for the operating system, some of the designations will
be displayed in the base language of the operating system after a language switch and will,
therefore, differ from the designations used in this documentation.
Soft Starter 3RW5 PCS 7 Library - Information, versions and documentation
Please find an overview of all versions, manuals, readmes, readme_oss, sample project and
additional information on the internet
(https://support.industry.siemens.com/cs/document/109770336).

Preface
SIRIUS Soft Starter 3RW5 PCS 7 Library
8Getting Started, 02/2020, A5E48411356002A/RS-AA/001
Software Requirements
●You can execute the example project on any PC or programming device on which the
following software is installed:
–Windows operating system
–Internet Explorer
–Message Queuing service
–SQL server
Note
The versions required depend on the version of SIMATIC PCS 7 installed.
You can find further relevant details in the following manuals:
–SIMATIC Process Control System PCS 7 PC Configuration and Authorization (V9.0
SP1) on the Internet (https://support.industry.siemens.com/cs/document/109754983).
–SIMATIC Process Control System PCS 7 Released Modules (V9.0 SP2) on the
Internet (https://support.industry.siemens.com/cs/document/109767525).
●You create the SIMATIC PCS 7 project with SIMATIC Manager.
To do so, follow the instructions in the Process Control System PCS 7; Getting Started
documentation.
Hardware used inside this sample project
This SIMATIC PCS 7 sample project was created with the following hardware for the
automation station (AS):
Table 2- 1 Hardware - Automation station 1: Configuration direct on the master system
Order number
Description
6ES7 410-5HX08-0AB0 SIMATIC S7-400, CPU 410-5H with 1*DP and 2*PN interfaces
6ES7 407-0KA02-0AA0 SIMATIC S7-400, power supply PS 407 10A, AC 120/230V/10A
standard PS

Preface
SIRIUS Soft Starter 3RW5 PCS 7 Library
Getting Started, 02/2020, A5E48411356002A/RS-AA/001 9
Table 2- 2 Soft Starter hardware
Device
Order number
Description
3RW55 3RW5 513-*HA** V2.0 SIRIUS 3RW55 Soft Starter, High Performance,
13A, 3 phase controlled, motor overload
protection, torque control.
3RW52 3RW5 2**.**C** V2.0 SIRIUS 3RW52 Soft Starter, General
Performance, ** A, 3 phase controlled, motor
overload protection.
PROFIBUS
Communication module
3RW5 980-0CP00 PROFIBUS communication module for 3RW5
Soft Starters.
PROFINET
Communication module
3RW5 980-0CS00 PROFINET Standard communication module for
3RW5 Soft Starters, 1 port.
HMI 3RW5 980-0HF00 SIRIUS HMI High Feature for 3RW5 Soft
Starters.

Preface
SIRIUS Soft Starter 3RW5 PCS 7 Library
10 Getting Started, 02/2020, A5E48411356002A/RS-AA/001

SIRIUS Soft Starter 3RW5 PCS 7 Library
Getting Started, 02/2020, A5E48411356002A/RS-AA/001 11
Product specific security information
3
Product specific security information
This library is designed to run under the SIMATIC PCS 7 environment. Therefore, it is
recommended to follow the security principles for SIMATIC PCS 7 to support a secure
operation, such as:
●User rights
●Password protection of
–WinCC
For more information, click here
(https://support.industry.siemens.com/cs/document/60119725).

Product specific security information
SIRIUS Soft Starter 3RW5 PCS 7 Library
12 Getting Started, 02/2020, A5E48411356002A/RS-AA/001

SIRIUS Soft Starter 3RW5 PCS 7 Library
Getting Started, 02/2020, A5E48411356002A/RS-AA/001 13
Introduction
4
4.1 Introduction
Introduction
This document was created under the usage of Soft Starter 3RW5 PCS 7 Library V9.0 SP2
and explains the basic principles of using this library. The Soft Starter 3RW5 PCS7 Library is
designed according to APL standards for both, blocks and faceplates. This library contains
two CFC templates to fulfill the configurations for 3RW52 and 3RW55 devices.
For reducing configuration time, module driver generation is supported by the library. By
using this driver generator it is ensured that all necessary interconnections will be handled
automatically and the device is ready to operate in SIMATIC PCS 7 environment.
Custom configuration can be done by the user as well. User manual and online help will give
detailed information about the blocks and their input and output pins.
This document will guide you through the necessary steps for using the template and the
module driver generator in a SIMATIC PCS 7 environment using a sample project. This
sample project uses minimum hardware, single station, PLC connected to one 3RW52 Soft
Starter via PROFINET and one 3RW55 Soft Starter via PROFIBUS.
Prerequisites
User
SIMATIC PCS 7 knowledge:
●Project creation
●HW-Config
●CFC-Editor
●WinCC-Explorer
Refer reference (Page 33) section for the link to "Process Control System PCS 7 Getting
Started" for further details and to find the manuals for your SIMATIC PCS 7 Version in the
manual collection.
System
●Installed and compatible SIMATIC PCS 7 version
●Installed Soft Starter 3RW5 PCS7 Library V9.0 SP2
●SIMATIC PCS 7 Multiproject (created by Project-Wizard).

Introduction
4.1 Introduction
SIRIUS Soft Starter 3RW5 PCS 7 Library
14 Getting Started, 02/2020, A5E48411356002A/RS-AA/001
Communication
Active communication network between Engineering Station (ES) / Operator Station (OS)
and the PLC.

SIRIUS Soft Starter 3RW5 PCS 7 Library
Getting Started, 02/2020, A5E48411356002A/RS-AA/001 15
Getting Started
5
5.1 Versions and Documentation
Please find an overview of all versions, manuals, readmes, readme_oss, sample project and
additional information on the internet
(https://support.industry.siemens.com/cs/document/109770336).
Reference section (Page 33) contains further information regarding PCS 7 Environment and
3RW5 GSD / GSDML files.
5.2 Installation
Installation
The setup supports German and English. The Setup will guide you through the required
steps. Use "< Back" and "Next >" buttons to navigate through the screens during the
installation process. You can choose your language at the initial screen.
The Soft Starter 3RW5 PCS7 Library has two components:
●AS = Components for Automation System
●OS = Components for Operator Station
For example:
●Soft Starter 3RW5 PCS 7 Library - AS
●Soft Starter 3RW5 PCS 7 Faceplates - OS
Installation program will ask you to decide, which product you want to install. Below is the
decision matrix:
AS
OS
Single Station
X
X
AS
OS
Distributed System
Engineering Station
X
-
Operator Station
-
X
"X" - required; "-" - not required

Getting Started
5.3 HW Config
SIRIUS Soft Starter 3RW5 PCS 7 Library
16 Getting Started, 02/2020, A5E48411356002A/RS-AA/001
5.3 HW Config
HW Config
Open HW-Config to retrieve the input address of the Soft Starter device.
Note
Note it down or insert it in symbol table for later usage. Each address in the symbol table
should have a valid symbolic name.
Note
•
GSD use: SI0281CF.gs? V3.0, 3RW55 device on PROFIBUS network
•
GSDML use: GSDML V2.34- Siemens-3RW5-20191030.zip, 3RW52 device on
PROFINET network

Getting Started
5.4 CFC
SIRIUS Soft Starter 3RW5 PCS 7 Library
Getting Started, 02/2020, A5E48411356002A/RS-AA/001 17
5.4 CFC
Master data library
For using the library in a plant, it is recommended to store the Soft Starter template in the
Master data library. Since this would be beyond the scope of this document, we recommend
you to take a look in "Process Control System PCS 7 CFC for SIMATIC S7" Function
manual. (https://support.industry.siemens.com/cs/document/109765729)
CFC Template
1. Open CFC-Editor by double clicking on the desired CFC-Object.
2. There are two ways to access 3RW5 teplates:
–Master data library
If the Soft Starter template was placed in the Master data library, you will find it in the
project library folder (Notation: ‘Project Name’+’_Lib’ e.g.: GS_SoSt_Lib). Expand the
Master data library node ("ProjName" + "_Lib" e.g.: GS_SoSt_Lib). You will find two
nodes:
- Blocks
- Templates

Getting Started
5.4 CFC
SIRIUS Soft Starter 3RW5 PCS 7 Library
18 Getting Started, 02/2020, A5E48411356002A/RS-AA/001
–3RW5 Soft Starter library
Else, select tab Libraries, located underneath the Catalog view. You will find the Soft
Starter templates in the Soft Starter 3RW5 PCS 7 Library (e.g.:
3RW5_PCS7_LibV90SP2).
Expand the 3RW5_PCS7_LibV90SP2 node. Now you will see two templates,
3RW52_Soft_Starter and 3RW55_Soft_Starter.

Getting Started
5.4 CFC
SIRIUS Soft Starter 3RW5 PCS 7 Library
Getting Started, 02/2020, A5E48411356002A/RS-AA/001 19
3. Drag the desired template object by pressing the left mouse button and drop the object in
the Chart view, as a reference, this getting started document shows both the templates.
The 3RW52_Soft_Starter and 3RW55_Soft_Starter template is now instantiated.
4. The input address of the Soft Starter 3RW52 / 3RW55 device at HW Config can be
assigned to the interconnectable chart I/O "PZDIn03", the interconnection type will be
DWORD and it should be connected with syntax "ID" as shown in the above screenshot.
(Input address of 3RW52 / 3RW55 Softstarter device) without opening the template.
Note
Manual interconnections
In the CFC, connect "
PZDIn03 (Input address of 3RW52 / 3RW55 Soft Starter device)".
There are two ways:
•
Via the already created symbolic name
•
Via direct input of the calculated address

Getting Started
5.4 CFC
SIRIUS Soft Starter 3RW5 PCS 7 Library
20 Getting Started, 02/2020, A5E48411356002A/RS-AA/001
Generate module drivers
1. Go to Chart > Compile > Chart as Program or hit Ctrl+B or click in the toolbar. The
Compile dialog opens.
2. Make sure that the option Generate module drivers is ticked on.
3. Confirm dialog with the OK-Button.
4. After compilation has finished, Logs dialog will be displayed. Confirm this dialog by the
Close button.
5. Updated interconnection can now be checked in the chart view by pressing F5
