Siemens airanger DPL PLUS User manual

Instruction Manual September 2005
DPL PLUS
airanger

© Siemens Milltronics Process Instruments Inc. 2005
Safety Guidelines: Warning notices must be observed to ensure personal safety as well as that of
others, and to protect the product and the connected equipment. These warning notices are
accompanied by a clarification of the level of caution to be observed.
Qualified Personnel: This device/system may only be set up and operated in conjunction with this
manual. Qualified personnel are only authorized to install and operate this equipment in accordance with
established safety practices and standards.
Unit Repair and Excluded Liability:
• The user is responsible for all changes and repairs made to the device by the user or the user’s
agent.
• All new components are to be provided by Siemens Milltronics Process Instruments Inc.
• Restrict repair to faulty components only.
• Do not reuse faulty components.
Warning: This product can only function properly and safely if it is correctly transported, stored,
installed, set up, operated, and maintained.
Note: Always use product in accordance with specifications.
Copyright Siemens Milltronics Process
Instruments Inc. 2005. All Rights Reserved Disclaimer of Liability
This document is available in bound version and in
electronic version. We encourage users to purchase
authorized bound manuals, or to view electronic versions
as designed and authored by Siemens Milltronics Process
Instruments Inc. Siemens Milltronics Process Instruments
Inc. will not be responsible for the contents of partial or
whole reproductions of either bound or electronic
versions.
While we have verified the contents of this
manual for agreement with the
instrumentation described, variations
remain possible. Thus we cannot
guarantee full agreement. The contents of
this manual are regularly reviewed and
corrections are included in subsequent
editions. We welcome all suggestions for
improvement.
Technical data subject to change.
MILLTRONICS®is a registered trademark of Siemens Milltronics Process Instruments Inc.
Contact SMPI Technical Publications at the following address:
Technical Publications
Siemens Milltronics Process Instruments Inc.
1954 Technology Drive, P.O. Box 4225
Peterborough, Ontario, Canada, K9J 7B1
Email: [e-mail]
• For a selection of Siemens Milltronics level measurement manuals, go to:
www. siemens.com/processautomation. Under Process Instrumentation, select
Level
Measurement
and then go to the manual archive listed under the product family.
• For a selection of Siemens Milltronics weighing manuals, go to:
www. siemens.com/processautomation. Under Weighing Technology, select
Continuous
Weighing Systems
and then go to the manual archive listed under the product family.

i
Table of Contents
Introduction ....................................................................................................................................................1
AiRanger DPL Plus .................................................................................................................................1
AiRanger DPL Plus Features ................................................................................................................3
Programmable Features ..............................................................................................................4
The Manual ...............................................................................................................................................4
Specifications ...............................................................................................................................................5
Electronics .................................................................................................................................................5
Programmer ..............................................................................................................................................6
Transducer ................................................................................................................................................7
Options .......................................................................................................................................................7
Cable ...........................................................................................................................................................7
Safety marking symbols ..............................................................................................................8
Installation ......................................................................................................................................................9
AiRanger DPL Plus ..................................................................................................................................9
Location ...........................................................................................................................................9
Cable/Conduit Entry Requirements ...........................................................................................9
Mounting .................................................................................................................................................10
Transducer Mounting .................................................................................................................10
Interconnection ......................................................................................................................................11
Optional SmartLinx Module ................................................................................................................13
System Diagram .....................................................................................................................................14
Transducer ...................................................................................................................................14
Temperature Sensor ..................................................................................................................15
Relays ............................................................................................................................................15
mA Outputs ...................................................................................................................................15
Communication ......................................................................................................................................16
Serial ...............................................................................................................................................16
SmartLinx ................................................................................................................................................16
Level System Synchronization ...........................................................................................................16
Power .......................................................................................................................................................17
AC Supply Wiring .......................................................................................................................17
DC Supply Wiring .......................................................................................................................17
Programmer ..................................................................................................................................18
Communications Access ...........................................................................................................18
Programming ...............................................................................................................................................19
Display ......................................................................................................................................................19
Keypad .....................................................................................................................................................20
Program Mode Entry ............................................................................................................................21
Changing Parameters ...........................................................................................................................21
Parameter Reset Features ..................................................................................................................22
Parameters Types ..................................................................................................................................22
Programming Security .........................................................................................................................22

ii
Operation .......................................................................................................................................................23
Display in RUN Mode ...........................................................................................................................23
Keypad .....................................................................................................................................................24
System Performance Evaluation .......................................................................................................25
Performance Test Results ...................................................................................................................26
Parameter Reference ..............................................................................................................................27
Helpful Hints .................................................................................................................................27
Parameter Reset Features ..................................................................................................................28
Programming Security .........................................................................................................................28
Quick Start (P001 to P007) ...................................................................................................................29
Application Parameters .......................................................................................................................33
Volume (P050 to P055) .........................................................................................................................33
Display and Reading (P060 to P062) ................................................................................................36
Failsafe (P070 to P072) ........................................................................................................................38
Relays (P100 to P119) ...........................................................................................................................40
Custom Relays (P110 to P113) .............................................................................................................43
Independent Relay Setpoints ...................................................................................................45
Independent Relay Failsafe (P129) ...................................................................................................48
mA Output (P200 to P219) ....................................................................................................................49
Independent mA Setpoints (P210 and P211) ...................................................................................50
mA Output Limits (P212 and P213) .....................................................................................................51
mA Output Trim (P214 to P215) ...........................................................................................................52
mA Output Failsafe (P219) ...................................................................................................................52
Standard Data Logging (P300 to P321) ...........................................................................................53
Record Temperatures (P300 to P303) ..............................................................................................53
Profile Records (P330 to P337) ..........................................................................................................53
Auto Record ON and OFF Setpoints (P334 to P337) ......................................................................55
Installation Records (P340 to P342) .................................................................................................57
Range Calibration (P650 to P654) ......................................................................................................58
Temperature Compensation (P660 to P664) ....................................................................................60
Rate (P700 to P707) ..............................................................................................................................63
Measurement Verification (P710 to P713) ......................................................................................65
Transducer Scanning (P725 to P729) ...............................................................................................68
Display (P730 to P733) .........................................................................................................................69
Peripheral Communication Support Parameters (P740 to P749) ...............................................71
SmartLinx Reserved (750 to 769) ......................................................................................................72
Communications (P772) ......................................................................................................................72
SmartLinx Hardware Testing ..............................................................................................................72
Echo Processing (P800 to P807) ........................................................................................................73
Advanced Echo Processing (P810 to P825) ....................................................................................76
Profile Pointer (P817 to P825) .............................................................................................................78
Advanced TVT Adjustment (P830 to P835) .....................................................................................82
Advanced Shot Adjustment (P840 to P852) ....................................................................................84
Test (P900 to P913) ................................................................................................................................87
Measurement (P920 to P927) .............................................................................................................90
Technical Reference ................................................................................................................................92
Transmit Pulse ........................................................................................................................................92
Echo Processing ....................................................................................................................................92

iii
Echo Processing Displays (Scope Displays, P810) .............................................................93
Dolphin Plus Display ...................................................................................................................93
Distance Calculation ............................................................................................................................93
Sound Velocity .......................................................................................................................................93
Scanning ..................................................................................................................................................94
Volume Calculation ...............................................................................................................................94
Universal, Linear (P050 = 9) .......................................................................................................95
Universal, Curved (P050 = 10) ...................................................................................................95
Maximum Process Speed ...................................................................................................................95
Application Examples ...........................................................................................................................96
Example 1 - Level Measurement .............................................................................................97
Material Volume ..........................................................................................................................99
Example 2 - Space Measurement ...........................................................................................99
Example 3 - Dual Point Differential ...................................................................................... 102
Example 4 - Dual Point Average ........................................................................................... 105
Example 5 - Tripper Measurement ...................................................................................... 107
Tripper Switch Setting ............................................................................................................. 108
Application Assistance ........................................................................................................... 108
Communication Support ................................................................................................................... 109
MT-00 Measurement Message ............................................................................................110
MT-01 Hold Message .............................................................................................................. 111
MT-03 Point Not Scanned ....................................................................................................... 111
Maintenance ..............................................................................................................................................112
Unit Repair and Excluded Liability ........................................................................................112
Troubleshooting Guide ........................................................................................................................113
Measurement Difficulties ..................................................................................................................114
Flashing LOE Display ..........................................................................................................................114
Fixed Reading .......................................................................................................................................115
Wrong Reading ....................................................................................................................................116
Programming Charts ..............................................................................................................................118

IQ300IX.fm Page 5 Tuesday, October 2, 2001 1:43 PM

7ML19981BD02 AiRanger DPL Plus – INSTRUCTION MANUAL Page 1
mmmmm
Introduction
Introduction
AiRanger DPL Plus
The AiRanger DPL Plus is an ultrasonic long-range level monitoring system for liquids and
solids. AiRanger DPL Plus level monitor uses one or two Siemens Milltronics ultrasonic
transducers (ordered separately) to accurately monitor material level in one or two
vessels without material contact.
The AiRanger DPL Plus transmits electronic pulses to each connected ultrasonic
transducer. The transducer converts the electronic pulses to ultrasonic pulses which are
emitted from the transducer face in a narrow beam. The AiRanger DPL Plus measures the
time from the pulse emission, to reception of the reflection (echo) from the material.
Using the time measured, the AiRanger DPL Plus calculates the distance from the
transducer face to the material.
The distance calculation depends upon the sound velocity within the vessel. When
Echomax transducers are used, variable air temperatures are automatically
compensated. For superior air temperature compensation, individual Siemens Milltronics
TS-3 temperature sensors may be used for each vessel. A simple calibration feature
compensates for homogeneous atmospheres other than air.
The AiRanger DPL Plus uses Siemens Milltronics patented Sonic Intelligence®echo
processing. Sonic Intelligence provides high measurement reliability, regardless of
changing conditions within the vessel monitored. By using ultrasonic echo ranging
principles with Sonic Intelligence and velocity compensation, the AiRanger DPL Plus
provides outstanding measurement accuracy, usually within 0.25% of range.
The distance calculation can be converted to space, material level, material volume,
remaining vessel capacity, differential level, or average level readings. The reading
chosen (and operating data) for each vessel is displayed on the LCD (liquid crystal
display).
Note: The AiRanger® DPL Plus is to be used only in the manner outlined in this
instruction manual.
mA
5
9
C
PP
6
0
78
1234
123 4

Page 2 AiRanger DPL Plus – INSTRUCTION MANUAL 7ML19981BD02
mmmmm
Introduction
The relays and mA outputs may be used as preset (or programmed as desired) to activate
alarms and/or operate remote monitoring equipment and/or process control equipment.
With the addition of a Siemens Milltronics Smartlinx ®protocol specific plug-in
communications module, the AiRanger DPL Plus is compatible with popular industrial
control system standards. Supported protocol include PROFIBUS DP, Allen-Bradley®1
Remote I/O, Modbus® RTU, and DeviceNetTM.
Programming can be done locally using the portable programmer keypad, or remotely
through optional Dolphin Plus software or SmartLinx.
• The programmer transmits the keypad entries via infrared link to the AiRanger DPL
Plus, and can be removed when not in use.
• Dolphin Plus allows programming either through the RJ-11 port or hardwired via the
RS-232/485 communication port.
• SmartLinx provides protocol specific hardware and software for interface with
popular industrial communication systems.
1. Allen-Bradley is a registered trademark of Rockwell Automation. Modbus is a
registered trademark of Schneider Electric. DeviceNet is a trademark of ODVA
(Open DeviceNet Vendor Association).
1234
mA
5
9
C
PP
6
0
78
1 234
plant-wide
control system
network
RS-232 or 485
(local)
SmartLinx
0/4--20mA
(PLC or DCS)

7ML19981BD02 AiRanger DPL Plus – INSTRUCTION MANUAL Page 3
mmmmm
Introduction
The AiRanger DPL Plus is typically used to monitor material level in open or closed
vessels but can be used in almost any process which requires a distance measurement
(within the system range).
Refer to Technical Reference Application Examples on page 96 for detailed descriptions
of some configuration examples to which the AiRanger DPL Plus may be applied. If
process or equipment position monitoring at distances greater than 60 m (200 ft) is
required, refer to Example - 6, Tripper Measurement.
AiRanger DPL Plus Features
• Enclosure: Chemical resistant, light weight, dust tight, liquid tight,
easy to work with.
• Backlit LCD: Large digits for Reading and programming value displays.
Illuminated LCD insures readability under all lighting
conditions. Includes custom Graphic Symbols for continuous
indication of operating conditions.
• Programmer: 20 tactile feedback keys for easy access to programming
and operating functions. Magnetic mounting and infrared
interface permit removal on programming completion.
• Scanning: Substantially reduces equipment costs for an additional
vessel (present or future).
• Communications: SmartLinx Compatible
Communications ready when equipped with an appropriate
Milltronics SmartLinx module.
• Dolphin Compatible Communications
Dolphin Plus is Windows®1-compatible configuration software
connected to the unit via the RG-11 port or remote connection
through the RS-232 or RS-485 port. The software provides an
easy means for programming, uploading,or downloading
parameters.
• Speed: 16/32 bit microprocessor at 16.7 MHz clock speed. 1 vessel
(point) per second scanning speed capability.
• Reliability: Sonic Intelligence ensures all measurements are accurate
and reliable. Immune to power interruptions. All programming
is stored indefinitely. Dynamic operating data is retained for
one hour and updated immediately onpower resumption.
1. Windows is a registered trademark of Microsoft Corporation.

Page 4 AiRanger DPL Plus – INSTRUCTION MANUAL 7ML19981BD02
mmmmm
Introduction
Programmable Features
The AiRanger DPL Plus is easy to program, yet versatile enough to handle complex level
measurement requirements.
General Features
•Direct Access: Any operator programmable feature may be accessed directly.
•Scroll Access: Scroll forward, scroll back, to key features.
•Operation: Select level, space, distance, difference, average, or tripper
operation.
•Material: Liquid or solid; automatically adjusts echo processing with one
entry.
•Response: Slow, medium, fast, surge, or immediate response to material
level changes.
•Units: Display Readings in m, cm, mm, ft, in, %, or any other units
desired.
• Volume: 8 pre-programmed tank shape options. 2 universal tank shape
programming methods
• Failsafe: Failsafe options for process control equipment activation.
• Relays: 8 functions including level, rate of change, pump control,
temperature and more.
Fixed or independent on/off setpoints
• mA Outputs: Based on level, space, distance, volume, difference, or
average.There are 4 range selections: 0-20, 4-20, 20-0, or
20-4 mA with an adjustable range and over-range limits
The Manual
The manual is designed to help you get the most out of your AiRanger DPL Plus, and it
provides information on the following:
If you have any questions, comments, or suggestions about the manual contents, please
e-mail us at [e-mail].
For the complete library of Siemens Milltronics manuals, go to
www.siemens-milltronics.com.
• Product specifications
• Outline diagrams
• Wiring diagrams
• Installation and interconnection
requirements
• How to program the unit
• Principles of operation
• Parameter values
• Technical Reference
• Example applications
• Troubleshooting guide
• Programming chart
REMEMBER!
Fill out Programming chart on page 118 or record parameters using Dolphin Plus.

7ML19981BD02 AiRanger DPL Plus – INSTRUCTION MANUAL Page 5
mmmmm
Specifications
Specifications
Electronics
Power
• AC model: 100/115/200/230 V AC ±15%, 50/60 Hz, 31 VA
• DC model: 18 to 30 V DC, 25 W
Environmental
• location indoor / outdoor
• altitude 2000 m max
• ambient temperature –20 to 50 °C (–5 to 122 °F)
• relative humidity suitable for outdoor (Type 4X / NEMA 4X / IP65 enclosure)
• installation category II
• pollution degree: 4
Scan Points
• 2 points per AiRanger DPL Plus max.
• frequency independent
Range
• Level Measurement: 0.3 m (1 ft) to 60 m (200 ft) max.
• Tripper Car: 1.2 m (4 ft) to 120 m (400 ft) max.
Accuracy
• 0.25% of range or 6 mm (0.24"), whichever is greater
Resolution
• 0.1% of program range1or 2 mm (0.08"), whichever is greater
Memory
• EEPROM (non-volatile) no back-up battery required
Programming
• via removable programmer or optional Dolphin Plus software
Display
• custom graphics backlit LCD with 51 mm (2 in) x 127 mm (5 in) viewing area
Synchronization
• up to 16 AiRangers DPL Plusunits can be synchronized together
Temperature Compensation
• –50 to 150 °C (–58 to 302 °F)
• integral temperature sensor in transducer
• 2 TS-3 temperature sensors max.
• programmable fixed temperature
1. program range is defined as the empty distance to the face of the transducer
(P006) plus any range extension (P801).

Page 6 AiRanger DPL Plus – INSTRUCTION MANUAL 7ML19981BD02
mmmmm
Specifications
Temperature Error
• with compensation: 0.09% of range
• fixed temperature: 0.17% / °C deviation from programmed temperature.
Outputs
• relays: 4 alarm/control relays
1 form "C" SPDT contact per relay, rated 5 A at 250 V AC,
non-inductive
• analog: 2 outputs max.
0.1% resolution
0-20 or 4-20 mA, scalable
750 Ω, isolated, 30V rms
Communications (see Options)
• SmartLinx compatible
• RS-232 / 485 port
• Dolphin Plus compatible
• proprietary bipolar current loop
Enclosure
• Type 4X / NEMA 4X / IP65 1
• 285 mm W x 209 mm H x 92 mm D (11.2" W x 8.2" H x 3.6" D)
• polycarbonate
Weight
• 2.7 kg (6 lb)
Approvals
• CE, CSANRTL/C, FM
• Lloyd’s Register of Shipping, Categories ENV1, ENV2, ENV3, and ENV5
Programmer
Ambient Temperature
• –20 to 50 °C (–5 to 122 °F)
Keypad
• 20 keys with tactile feedback
Interface
• non-invasive, digital, infra-red
Enclosure
• general purpose
• 67 mm W x 100 mm H x 25 mm D (2.6" W x 4" H x 1" D)
• ABS plastic
Weight
• 150 g (0.3 lb)
1. The use of approved watertight hubs/glands is required for Type 4X / NEMA 4X,
IP65 on watertight applications.

7ML19981BD02 AiRanger DPL Plus – INSTRUCTION MANUAL Page 7
mmmmm
Specifications
Transducer
Compatible Models
• STH and Echomax®series
• Refer to the associated instruction manual.
Options
Temperature Sensor
• TS-3
SmartLinx Modules
• Supported protocols: PROFIBUS DP
Allen-Bradley Remote I/O
Modbus RTU
DeviceNet
Dolphin Plus
• Windows®-compatible configuration software connected to the unit via infrared
Comverter link
Refer to associated product documentation.
Cable
Transducer
• RG-62 A/U (or equivalent), 365 m (1,200 ft) max.
See transducer instructions for short extensions (in grounded metal conduit, separate
from other wiring)
mA Output
• Belden 8760, shielded / twisted pair, 18 AWG (0.75 mm2) or equivalent or Belden 9552,
shielded / two twisted pair, 18 AWG (0.75 mm2)
• maximum separation 1,500 m (5,000 ft)
Synchronisation
• Belden 8760, shielded / twisted pair, 18 AWG (0.75 mm2) or equivalent
Relays
• No shielded cable necessary
Temperature sensor
• Belden 8760 shielded / twisted pair, 18 AWG (0.75 mm2) or equivalent
• 365 m (1,200 ft) per TS-3 maximum
RJ11 Link
• No shielded cable necessary
• maximum length 3 m
RS-232 Link
• Belden 8770, 3 conductor/shielded, 18 AWG (0.75 mm2) or equivalent
• maximum separation 15 m (50 ft)
RS-485 Link

Page 8 AiRanger DPL Plus – INSTRUCTION MANUAL 7ML19981BD02
mmmmm
Specifications
• Belden 8770, 3 conductor/shielded, 18 AWG (0.75 mm2) or equivalent
• maximum separation 1200 m (4000 ft)
SmartLinx module
• refer to the associated instruction manual.
Safety marking symbols
In manual On Product Description
(Label on product: yellow background.)
Caution: refer to accompanying documents (manual) for
details.
Alternating Current
Direct Current
Earth (ground) Terminal
Protective Conductor Terminal

7ML19981BD02 AiRanger DPL Plus – INSTRUCTION MANUAL Page 9
mmmmm
Installation
Installation
Installation shall only be performed by qualified personnel, and in accordance with local
governing regulations.
The following procedure applies to all AiRanger DPL Plus level monitor installations. See
Application Examples on page 96 for additional installation requirements. Also, refer to
the instruction manuals of all other equipment connected to the AiRanger DPL Plus for
additional installation instructions.
AiRanger DPL Plus
Location
Recommended
• Ambient temperature is always within -20 to 50 °C (-5 to 122 °F)
• AiRanger DPL Plus display window is at shoulder level, unless most interaction is
through a SCADA system
• Easy access for hand programmer is provided
• Cable length requirements are minimal
• Mounting surface is free from vibration
• Leave sufficient room to swing unit lid open and have clear access.
• A place for a laptop computer is provided for on-site Dolphin Plus configuration
Avoid
• Exposure to direct sunlight. (Provide a sun shield to avoid direct sunlight.)
•Proximity to high voltage/current runs, contacts, SCR or variable frequency motor
speed controllers
Cable/Conduit Entry Requirements
Enclosure cable/conduit entries may be required for:
• Transducers
• TS-3 temperature sensors (if used)
• mA outputs (if used)
• Relays (if used)
• Synchronization (see Interconnection/Level System Synchronization)
• Power
• Communications: SmartLinx, RS-485, RS-232, bipolar.
Note: Transducer cables must be run in a grounded metal conduit, separate from
other wiring, (except TS-3 temperature sensor wiring, if applicable).

Page 10 AiRanger DPL Plus – INSTRUCTION MANUAL 7ML19981BD02
mmmmm
Installation
Mounting
Inspect all cartons and packaging for possible damage during shipment, before removing
the AiRanger DPL Plus and associated equipment.
1. Loosen the 6 enclosure lid (captivated) screws and swing the lid open.
2. Remove the 4 Board B mounting screws (outer corners) and remove the circuit
board assembly.
3. Drill required holes in the enclosure bottom to meet enclosure cable/conduit entry
requirements.
4. Attach the enclosure to the selected mounting surface (use four predrilled screw
holes).
5. Attach the conduits/cable hubs to the enclosure. (Do not apply undue force.)
6. Reinstall the circuit board assembly.
Transducer Mounting
Objects near the transducer face cannot be reliably detected. Mount the transducer
above the highest material level (away from the nearest monitored object) by the
following Nearest Distance.
Warnings
• Non metallic enclosure does not provide grounding between connections. Use
grounding type bushings and jumpers.
• This product is susceptable to electrostatic shock. Follow proper grounding
procedures.
Nearest Distance Transducer Types
0.5 m (1.65 ft)1
1. This is the recommended minimum distance. However, it can be reduced under certain circum-
stances. Please check the appropriate transducer manual for details.
ST-H, ST-25, XRS-5, XCT-8, XCT-12, XPS-10, XPS-15, ST-50
0.66 m (2.17 ft) XPS-30, XPS-40
0.99 m (3.25 ft) ST-100, LR-21, XLT-30, XLS-30
1.32m (4.33 ft) LR-13, XLT-60, XLS-60
123 4
12
mA
5
9
C
PP XXX
6
0
78
1234
267 mm
(10.5")
285 mm
(11.2")
lid screw
(6 places)
209 mm
(8.2")
172 mm
(6.8")
suitable location for conduit entrances.
Use water tight conduit hubs to maintain the enclosure rating.
mounting hole, 4.3 mm (0.17")
diameter, access under lid (4 places).
programmer
lid (hinged)
customer
mounting screws
106 mm
(4.2")

7ML19981BD02 AiRanger DPL Plus – INSTRUCTION MANUAL Page 11
mmmmm
Installation
Interconnection
Before interconnecting system components to the AiRanger DPL Plus terminals, verify all
components have been installed in accordance with the associated product instruction
manuals.
Connect all associated equipment cable shields to the AiRanger DPL Plus shield
connections. To avoid differential ground potentials, do not connect cable shields to
ground (earth) elsewhere. Insulate or tape cable shields at all shield junctions to prevent
ground loops.
AC Model
WARNINGS:
• All field wiring must have insulation suitable for at least 250V.
• Hazardous voltage present on transducer terminals during operation
• Relay contact terminals are for use with equipment having no accessible live
parts and wiring having insulation suitable for at least 250V.
display
voltage
select
EPROM
board A
optional
SmartLinx
module
scope
connections
communication
mode LED
NORM/TRIP
switch terminal
block board B
RJ-11 port

Page 12 AiRanger DPL Plus – INSTRUCTION MANUAL 7ML19981BD02
mmmmm
Installation
DC Model
Warnings:
• All field wiring must have insulation suitable for at least 250V.
• Hazardous voltage present on transducer terminals during operation
• Relay contact terminals are for use with equipment having no accessible live
parts and wiring having insulation suitable for at least 250V.
24 V
1 2 3 8 9 101112131415 26 27282930313233 35 3637
BIPOLAR C URRENT LOOP
RS-2 32
RX
12 12
SYNC
344 5 6 7 1617181920212223 2425
1 234
RELAYS
-+
REL AYS SHO WN IN
DE-EN ERG IZED POSI TIO N
250
SEE INSTRUCTION BOOK
FOR COMPLETE RATING
12
!
V5AMP
BOARD B
RJ-11
RS-232
RS-485
BIPOLAR
TE RM INATI O N
RS-4 85
SHLD
SHLD
TX
TX
RX
SHL DSHLD
SHL D
SHLD
COM
COM
B
A
TB1
!
!
-+
mA
OUTPUTS
NORM TRI P
BL K
WHT/SHLD
WHT/
SHLD
WHT/
SHLD
12
BLK
BLK BLK
WHT/SHLD
2
TEMP
SEN SOR
TEMP
SEN SOR
1
S1
U31
TP6TP5TP4
GND SCOPE SYNC
display EPROM
board A
optional
SmartLinx
module
scope
connections
communication
mode LED
NORM/TRIP
switch terminal block board B
RJ-11 port

7ML19981BD02 AiRanger DPL Plus – INSTRUCTION MANUAL Page 13
mmmmm
Installation
Optional SmartLinx Module
The standard AiRanger DPL Plus unit may also be enhanced with Siemens Milltronics
SmartLinx communication modules that provide an interface to popular industrial
communication systems.
To change or install SmartLinx module:
With power off and AiRanger DPL Plus lid opened:
1. Remove the 4 LCD card screws and the card itself.
2. Remove the one dummy card screw and the card itself.
3. Mount the card by mating the connectors and secure the card in place using the two
screws provided.
4. Wire in the SmartLinx card according to SmartLinx Manual.
5. Replace the LCD card and secure in place using the screws removed in Step 1.
Note:Refer to the SmartLinx module documentation for any required hardware
settings prior to replacing the LCD card or closing the AiRanger DPL Plus lid.
LCD Card
SmartLinx module
dummy card
board A

Page 14 AiRanger DPL Plus – INSTRUCTION MANUAL 7ML19981BD02
mmmmm
Installation
System Diagram
Transducer
Note: Maximum system capability. Not all components or their maximum quantity
may be required.
4
2
2
2
Siemens Milltronics transducer
see Specifications
Siemens Milltronics
temperature sensor
customer device
customer alarm, pump
or control device
Dolphin Plus, or
customer device
industry control system
such as PLC or DCS,
SCADA, etc.
mA output
relay output
point to point communication
fieldbus communication
AiRanger
DPL Plus
optional
SmartLinx
65
# 1
BLK BLK BLK WHT/SHLD WHT/SHLD N12V
7
# 2
21
8910
TEMP
SENSOR
1
Notes:
• Transducer cables must be run in a
grounded metal conduit separate from
other wiring (except TS-3 temperature
sensor wiring, if applicable).
• Hazardous voltage present on
transducer terminals during operation.
