Siemens SD 270 User manual

Operating Manual
(Applies from Serial Number 8200 onwards)
SD 270 Diagnostic Audiometer

Overview of SD 270 Audiometer Controls

3
Contents
Overview of SD 270 Audiometer Controls 2
Contents 3
1 Introduction 6
- 1.1 Intended applications 6
- 1.2 Unpacking 6
- 1.3 Standard contents 6
- 1.4 Optional accessories 7
- 1.5 Frequently used functions 7
- 1.6 Known contradictions 7
2 Important Safety Instructions 8
- 2.1 Precautions 8
- 2.2 Electromagnetic compatibility (EMC) considerations 9
- 2.3 Mains supply operation 10
- 2.4 Audiometer connections 11
- 2.5 Data transfer to a printer 12
- 2.6 Data transfer to a computer 13
- 2.7 Line in/out connection (audio) 13
3 Using the Audiometer 14
- 3.1 Ambient conditions 14
- 3.2 Switching the audiometer on and off 14
- 3.3 Operating language 14
- 3.4 Testing the patient response switch 15
- 3.5 Audiometer display 15
- 3.6 Audiometer controls 15
- 3.7 Threshold Retention Function 30
- 3.8 Uncomfortable loudness levels 31
- 3.9 Saving audiograms in internal memory 31
- 3.10 Loading audiograms from internal memory 32
- 3.11 Printing audiograms 32
- 3.12 Data transfer to a NOAH database 33

4
4 Sequence of Operation and Suggested Test Procedure 34
- 4.1 Pre-test 34
- 4.2 Test 34
- 4.3 Post-test 35
5 Specification 36
- 5.1 Output data 36
- 5.2 Maximum hearing levels provided at each frequency 37
- 5.3 Physical Data 37
- 5.4 Equipment classification 38
6 Symbols 39
7 Technical Information 40
8 Routine Maintenance 43
- 8.1 Audiometer maintenance 43
- 8.2 Transducer maintenance 43
- 8.3 Mains adapter maintenance 45
- 8.4 Perform listening check 45
9 Instrument Storage and Transportation 46
10 Calibration & Return of the Instrument 47
11 Guarantee 48
12 Ordering Consumables & Accessories 49
Appendix 1 ‒ Speech Audiometry 50
- Headphone and Free Field Testing 50
- Operator Monitoring 50
- Test Modes in Speech Audiometry 51
- Display Counter 51
- 1. Live Voice Speech Audiometry to Headphones 52
- 2. Live Voice Speech Audiometry with Contralateral Masking 53
- 3. Recorded Speech Audiometry to Headphones 54
- 4. Recorded Speech Audiometry to Headphones with
Contralateral Masking 55

5
- 5. Free Field Live Voice Speech Audiometry 56
- 6. Free Field Recorded Speech Audiometry 57
- 7. Free Field Recorded Speech Audiometry with Competing
Noise (Audiometer-Generated) 58
- 8. Free Field Recorded Speech Audiometry with Competing
Noise (Recorded) 59
Appendix 2 ‒ Free Field Calibration Procedure 60
- 1. Assurance Of Calibration 60
- 2. External Amplifier and Loudspeaker 60
- 3. Calibration Overview 60
- 4. Free-field Speech Calibration 61
- 5. Free-field Warble Tones Calibration 64
- 6. Free-field Live Speech Calibration 67
Appendix 3 ‒ EMC Guidance & Manufacturer’s Declaration 68
Appendix 4 ‒ Use with Non-medical Electrical Equipment 74
Appendix 5 ‒ Technical Support Contacts 81
Disposal information 83

6
1 Introduction
Thank you for purchasing a Siemens audiometer. The Siemens
SD 270 is a diagnostic audiometer that will give many years of
reliable service if treated with care.
1.1 Intended applications
The Siemens SD 270 diagnostic audiometer is designed for use by
audiologists, general practitioners, hearing aid dispensers and child
health professionals. Capable of undertaking both air and bone
conduction tests with or without masking, the audiometer also has
many additional features such as the facility to support speech au-
diometry from live or recorded sources, the option to select
free-field equivalent output from the headphones in speech mode
and a range of clinical audiometry tests.
1.2 Unpacking
Open the shipping carton and carefully remove all the equipment.
Check against the delivery note that all the accessories ordered
have been included with your audiometer. If anything is missing,
please contact your local Service department – see Appendix 5.
If you have purchased from a distributor you should contact them
directly.
Please retain the shipping carton and packing materials as the
audiometer will need calibrating on an annual basis and should
be returned for service in its original shipping carton.
1.3 Standard contents
Siemens SD 270 Audiometer Audiometric headset
Bone conductor headset Patient response switch
Mains adaptor, see 2.3 Audiogram cards
Operating manual Calibration certificate
Carrying case

7
1.4 Optional accessories
Masking earpiece Microphone and monitor headset
Printer Additional audiogram cards
Printer cable Insert earphones
Data cable for NOAH Link driver disk for NOAH
1.5 Frequently used functions
How to switch on/off or set the language or control the level?
Please refer to section 3 of this instruction.
1.6 Known contradictions
There are no contradictions known for the use and application of
the SD 270 Audiometer.

8
2 Important Safety Instructions
Safety Note!
Any modification of the device itself or its accessories is not
allowed and may lead to inaccepteable risk of harm or inju-
ries.
Safety Note!
The SD 270 diagnostic audiometer must be used only by
practitioners qualified to perform audiometric tests. It is
intended for use as a screening and diagnostic tool.
2.1 Precautions
READ THIS OPERATING MANUAL BEFORE ATTEMPTING TO USE
THE INSTRUMENT.
To comply with the standards IEC 60601-1 for safety and
IEC 60601-1-2 for EMC the audiometer is designed to be used
only with the medically-approved mains adapter supplied, which
is specified as part of the equipment. Do not use any other type
of mains adapter with this instrument. Refer to Section 12 for
the stock number of the adapter.
The audiometer is for indoor use only and should be used only as
described in this manual.
The transducers supplied with the audiometer are specifically
calibrated with it; if these transducers are changed calibration
will be required.
Do not immerse the unit in any fluids. See Section 8 for the proper
cleaning procedure for the instrument and its accessories and the
function of single-use parts.
Do not use the instrument in an oxygen-rich environment or in the
presence of a flammable anaesthetic mixture or other flammable
agents.

9
Do not drop or otherwise impact this instrument. If the instrument
is dropped or damaged, return it to the manufacturer for repair
and/or calibration. Do not use the instrument if any damage is
suspected.
The instrument must be stored and used within the specified
temperature, pressure and humidity ranges (see Sections 7 and 9).
Do not attempt to open or service the instrument. Return the
instrument to the manufacturer or distributor for all repair and
servicing requirements. Opening the instrument will void the
warranty.
2.2 Electromagnetic compatibility (EMC) considerations
Medical electrical equipment needs special precautions regarding
EMC and needs to be installed and put into service according to
the EMC information provided in Appendix 3. This provides
guidance on the electromagnetic environment in which to
operate the instrument.
Portable and mobile radio-frequency (RF) communications
equipment can affect medical electrical equipment. The
instrument should not be used adjacent to or stacked with
other equipment; if this is unavoidable the instrument should
be observed to verify normal operation.

10
2.3 Mains supply operation
The audiometer is designed for continuous operation and is
powered by a mains adapter which is supplied, and specified
as part of the equipment. If a replacement is required, please
contact your local Service department (see Annexx 5).
All other connections must be made before connecting the output
lead from the adapter into the POWER input socket on the back of
the audiometer. Switch on the mains supply - the indicator on the
adapter and the POWER indicator on the audiometer will both
illuminate green, showing that the instrument is ready for use.
The output from mains adapter is fitted with electronic circuit
protection. In case of overload the adapter will shut down and the
indicator will be extinguished. When the fault is cleared the adapter
will operate as normal.
The input is to the mains adapter is protected with a non-replacea-
ble fuse. If this fails the adapter will not operate.
The mains adapter is the mains disconnect device and therefore
the audiometer should be positioned such that easy access to the
mains adapter is possible.
Safety Note!
DO NOT USE ANY OTHER MAINS ADAPTER WITH THIS IN-
STRUMENT.
To comply with the standards IEC 60601-1 for safety and
IEC 60601-1-2 for EMC the audiometer is designed to be used
only with the medical approved mains adapter supplied with
the product. If a replacement is required, please contact your
local Service department (see Annexx 5).

11
2.4 Audiometer connections
To disconnect the device from mains supply, unplug the DC-con-
nector from the input socket.
All the relevant accessory terminals and connections are labeled to
ensure correct identification and connection as follows:
Socket
Label
Socket Type Colour
Code
Connected Part Notes
MIC 1 3.5mm jack Speech Input Microphone*
MONITOR 3.5mm jack Monitor Earphone*
BONE 6.3mm jack Grey Bone Vibrator Headset*
INSERT 3.5mm jack Masking Earphone*
RIGHT
LEFT
6.3mm jack
6.3mm jack
Red
Blue
Air conduction headset*
MIC 2 3.5mm jack Talkback Microphone*
POWER 2.5mm power
jack
Mains AC/DC Adapter*
RESPONSE 6.3mm jack Black Patient Response Switch*
LINE IN
LINE OUT
3.5mm jack
3.5mm jack
CD/tape player
External amplifier
See
2.7
DATA 6 pin mini DIN Printer* See
2.5
USB USB Connec-
tor
Computer (via USB port) See
2.6
The relevant part numbers are indicated in Section 12.

12
Safety Note!
For connected parts marked * only connect the accessories
supplied with the instrument. These parts have been tested
for use with the Siemens SD 270 Diagnostic Audiometer for
compliance with the standards IEC 60601-1 and
IEC 60601-1-2.
The use of accessories other than those specified may
compromise compliance with these standards. For other
sockets refer to Appendix 4.
2.5 Data transfer to a printer
Safety Note!
Please refer to Appendix 4 for important information regar-
ding the connection of non-medical electrical equipment to
medical electrical equipment.
The audiometer can be upgraded with an option to allow
connection to a designated portable thermal printer for printing
air conduction, bone conduction, speech and ULL test results
(see 3.11). You must use the designated cable which is supplied
with this option.
Upon receipt of the printer it is recommended that the printer is ini-
tially charged for a minimum of 15 hours prior to use.

13
2.6 Data transfer to a computer
Safety Note!
Please refer to Appendix 4 for important information regar-
ding the connection of non-medical electrical equipment to
medical electrical equipment.
The audiometer can be upgraded with an option to allow connec-
tion to a computer with the NOAH application for the transfer of
air conduction, bone conduction, speech and ULL test results
(see 3.12). You must use the designated cable which is supplied
with this option.
2.7 Line in/out connection (audio)
Safety Note!
Please refer to Appendix 4 for important information regar-
ding the connection of non-medical electrical equipment to
medical electrical equipment.
The Siemens SD 270 has audio line in/out connections for CD or
tape player input (e.g. for recorded speech testing) and amplifier
output.
Important Note:
Line out connections are switched on only when FREEFIELD is
selected. The following connections apply to both LINE IN and
LINE OUT.
Main body segment Mid segment End segment
Ground Right Channel Left Channel
For more information on live and recorded speech please see
Appendix 1.

14
3 Using the Audiometer
3.1 Ambient conditions
Audiometric testing should always be performed in a quiet room or
in an acoustic booth.
3.2 Switching the audiometer on and off
fPress the key highlighted centre right of front panel.
No warm-up time is required. The display will briefly show the
model and the type of headphones currently selected for use.
If a secondary headphone has been enabled (e.g. E-5A) it will then
be necessary to select the required headphone as follows:
fEither - press the key under OK (on the display) to confirm the
current headphone selection
fOr - press the key under CHANGE to toggle to the other option
and then OK to confirm the selection
Important Note:
The headphone selection must be confirmed before any other
operation can be performed.
The display will then be as shown in 3.5.
fTo switch off, press the key again and then the key under YES
to confirm. To cancel switch-off press the key under NO or QUIT.
3.3 Operating language
fTo select the operating language for the audiometer (English
or German) continue to hold the key when switching on.
An additional display will allow the selection of English
(Softkey 1) or Deutsch (Softkey 3).

15
3.4 Testing the patient response switch
fPress the patient response switch and the light labeled
RESPONSE (to the left of the display) will illuminate green.
3.5 Audiometer display
On start-up the display will show the following default setting:
This indicates that when the PRESENT key is pressed, the tone
presented will be at 30dBHL at a frequency of 1kHz (1000 Hz)
to the designated ear. Please note that on start up, the
audiometer defaults to the left ear.
3.6 Audiometer controls
3.6.1 SoftKeys
Four softkeys are provided below the display that may refer to an
associated option shown on the display. In this operating manual
these are referenced as Softkey 1 to Softkey 4 from left to right.

16
3.6.2 OPTIONS key
Pressing the OPTIONS key and then using the softkeys allows the
operator to step through the options (use the NEXT softkey) and
modify the settings as required. Pressing the softkey below QUIT
exits the options menu and saves the settings.
Menu Option Description
Clear test?: Clears all displayed test results if the
YES key is pressed; stored test results
are not affected
Save audiogram to (1): Use UP key to select intended storage
location and press SAVE key to save
test results

17
Load audiogram no (1): Use UP key to select the required sto-
rage location and press LOAD key to
retrieve test results
Contrast: Adjust using the UP and DOWN keys
Bone masking: Selects the headset or the optional
masking earpiece as the means of mas-
king; select ‘Insert’ or ‘Phones’ key

18
Select phones: This option is only available if a se-
condary headphone is enabled; use
Softkeys 1 or 2 to select the required
headphone type.
FF equiv speech?: This option is only available if eit-
her DD45 or TDH39 is the selected
headphone; if activated, free-field
equivalent levels will output to the
headphone in speech mode (refer to
Appendix 1).

19
Store on 2 of 3?: Automatically stores a threshold if the
responses made to two out of three
test signals are at the same hearing
level.
Set freefield levels?: This option provides access to the
freefield calibration function; refer to
Appendix 2 for details.
External Talkover?: Select NO to use the internal micro-
phone and YES to use the MIC 1 input.

20
Display Counter?: Activates a percentage counter for
use with speech testing (refer to
Appendix 1).
Omit 750/1k5/3k/6k?: To exclude these frequencies from
those available for testing press the
YES key.
