Installation and Setting Instructions
Installing and setting the Video recorder

SIREMOBIL Iso-C Register 3 SPR2-230.033.03 Page 2 of 4 Siemens AG
Rev. 03 10.99 TD SD 24 Medical Engineering
2 Installing and setting the Video Recorder1
General 1
Safety information 1
Checks and adjustments which must be performed with radiation switched ON are identi-
fied by the radiation warning symbol . During these types of adjustments, radiation pro-
tective clothing must be worn.
Protective conductor test 1
Perform the protective conductor test according to ARTD - 002.731.17... after completing
all work and reinstalling all covers.
The protective conductor resistance must not exceed 0.2 ohms.
Additional Information 1
These instructions apply to retrofitting a video recorder on a SIREMOBIL Iso-C system
with Memoskop C / Memoskop C & MOD / Memoskop C-SUB /
Memoskop C-SUB & MOD.
Materials required 1
Measurement and auxiliary devices required 1
Tools required 1
•Tool kit (see ARTD /part3)
•1 set of Allen keys
When performing service work and tests, adhere to the product-specific
safety information contained in the documents as well as the general
safety information contained in the ARTD part 2.
•Video recorder connection kit 31 00 489 G5437
•Service PC
•Digital-Multi-Meter DMM
•Service software (see Log book)
•Connecting cable (from service PC to host) 99 00 440 RE999
•Protective conductor meter 44 15 899 RV 090
CAUTION

Installing and setting the Video Recorder 3
Siemens AG Register 3 SPR2-230.033.03 Page 3 of 4 SIREMOBIL Iso-C
Medical Engineering Rev. 03 10.99 TD SD 24
Line voltage cable 1
Video tape recorder with 100VAC line voltage:
•Connect theline wires to transformer T1, connector TI - 34 and TI - 36.
•Connect theprotective conductor to the protective conductor terminal stripe (ye/gn).
Video tape recorder with 120VAC line voltage:
•Connect theline wires to transformer T1, connector TI - 35 and TI - 36.
•Connect theprotective conductor to the protective conductor terminal stripe (ye/gn).
Video tape recorder with 230VAC line voltage:
•Connect the video recorder line wires at terminals X2.1 and X2.2.
•Connect theprotective conductor to the protective conductor terminal strip (ge/gn).
•Route the video recorder line wires to the video recorder compartment.
Remote Release 1
•Connect the supplied control cable to the MEMOSKOP.
•Connect the cable end to the video recorder.
Video cable 1
With an existing multiformat camera or video printer 1
•Removethe75Otermination from thevideo output of themuliformat camera or switch off
the75Otermination for the video printer.
•Connect the video cable at the video output of the multiformat camera or the video printer
and route the cable to the video recorder compartment.
•Connect the video recorder input. Ensure 75O termination of the video cable.
•Connect the video recorder output to the MEMOSKOP video recorder input.
Without a multiformat camera or video printer 1
•Connect thevideo cable to Memoskop connector "Out3".
•Route the video cable to the video recorder compartment.
•Connect the video recorder input. Ensure 75O termination of the video cable.
•Connect the video recorder output to the MEMOSKOP video recorder input.
Disconnect the SIREMOBIL Iso-C line voltage cable prior to begin-
ning work.
CAUTION

SIREMOBIL Iso-C Register 3 SPR2-230.033.03 Page 4 of 4 Siemens AG
Rev. 03 10.99 TD SD 24 Medical Engineering
4 Installing and setting the Video Recorder
Programming 1
•Switchthe system on.
•Simultaneously press keys[CTRL] and [U] onthe memorykeyboard.
 This calls the "User Setup menu" for Memoskop.
•Configure the video recorder output for monitor A.
(Perform the configuration for monitor B only by special customer request).
•Endthe "usermenu".
•SwitchtheSIREMOBILIso-Coffandonagain toactivatethenewconfiguration.
Function check 1
•Set the video recorder to record.
•With Fluoro, move the collimator blades slightly into the field.
Releasefluoroforapproximately20seconds.
•Stopthevideorecorderandrewindthetape.
•Replay the scene.
Concluding work 1
•SwitchOFFtheSIREMOBIL.
•Check theprotective conductor function using the protective conductor meter 44 15 899
RV. Refer also to TI236 / ARTD - 002.731.17...
Changes to previous version 1
Page 3: Paragraph "Line voltage cable" changed.
TD SD 24 / Arnold TD SD 24/ Schlee SMS Iselin / Ristau
