Siemens POLYMOBIL Plus Operating and maintenance instructions

© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted without express written
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
Print No.:
Friedrich
POLYMOBIL Plus
System
Maintenance Instructions
SP
2005
SPR8-125.831.01.02.02
Replaces: SPR8-125.831.01.01.02
English
Doc. Gen. Date: 05.05
POLYMOBIL Plus
The protocol SPR8-125.832.01.02.02 is required for
these instructions
01818231

2 Revision / Disclaimer
POLYMOBIL Plus SPR8-125.831.01.02.02 Siemens AG
05.05 CS PS 24
Page 2 of 40 Medical Solutions
1Revision / Disclaimer
Document revision level
The document corresponds to the version/revision level effective at the time of system
delivery. Revisions to hardcopy documentation are not automatically distributed.
Please contact your local Siemens office to order current revision levels.
Disclaimer
The installation and service of equipment described herein is to be performed by qualified
personnel who are employed by Siemens or one of its affiliates or who are otherwise
authorized by Siemens or one of its affiliates to provide such services.
Assemblers and other persons who are not employed by or otherwise directly affiliated
with or authorized by Siemens or one of its affiliates are directed to contact one of the
local offices of Siemens or one of its affiliates before attempting installation or service pro-
cedures.

Siemens AG SPR8-125.831.01.02.02 POLYMOBIL Plus
05.05 CS PS 24
Table of Contents 3
Page 3 of 40
Medical Solutions
0Table of Contents
1 _______ General ________________________________________________________ 4
Required documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Required tools, measurement and auxiliary equipment . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Required lubricant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Text emphasis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safety information and protective measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Explanation of abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Information on the protective conductor resistance test . . . . . . . . . . . . . . . . . . . . . . . . . 12
Information on the device leakage current measurement . . . . . . . . . . . . . . . . . . . . . . . 14
Technical Safety Checks (TSC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2 _______ Inspection and Maintenance______________________________________ 22
Visual inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Checking for signs of damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Customer documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Checking the screws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Checking the handles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Checking the wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Checking the pedal positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Single tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Double-slot diaphragm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Radiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Control console. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Protective conductor test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Device leakage current measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
DAP measuring system (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Final Work Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3 _______ Changes to the previous version __________________________________ 40

4 General
POLYMOBIL Plus SPR8-125.831.01.02.02 Siemens AG
05.05 CS PS 24
Page 4 of 40 Medical Solutions
1-
1 General
1.1 Required documentation
* According to DIN VDE 0751-1, we recommend documenting the maintenance results in
the maintenance protocol as well as the TSC protocol, completing it fully and handing it
over to the customer.
•Maintenance Protocol SPR8-125.832...
•Service Instructions SPR8-125.061...
•Instructions for Use SPR8-125.201...
•Block Circuit Diagram X069I
•Function Description SPR8-125.041...
•Technical Safety Checks - Protocol * SP00-000.834.01...

Siemens AG SPR8-125.831.01.02.02 POLYMOBIL Plus
05.05 CS PS 24
General 5
Page 5 of 40
Medical Solutions
1.2 Required tools, measurement and auxiliary equipment
NOTE All tools, measurement and auxiliary devices, with the exception of
those marked "* ", are listed in the STC (Service Tools Catalogue)
along with their specifications.
•Standard service tools *
•2-channel memory oscilloscope
•Protective conductor and device leakage current meter
•Torque wrench 20 Nm - 100 Nm
•Loctite 242
•Dose meter (for optional "DAP measuring system" only)
•Calibration tool for "DAP measuring system", part no. 65 84 978

6 General
POLYMOBIL Plus SPR8-125.831.01.02.02 Siemens AG
05.05 CS PS 24
Page 6 of 40 Medical Solutions
1.3 Required lubricant
•All purpose spray WD-40 28 70 061
•Optimol Longtime PD2 grease (20 g)
(1 kg)
34 91 271
73 95 445

Siemens AG SPR8-125.831.01.02.02 POLYMOBIL Plus
05.05 CS PS 24
General 7
Page 7 of 40
Medical Solutions
1.4 Text emphasis
Fig. 1: Safety notes

8 General
POLYMOBIL Plus SPR8-125.831.01.02.02 Siemens AG
05.05 CS PS 24
Page 8 of 40 Medical Solutions
1.5 Safety information and protective measures
WARNING Risk of death, injuries or material damage
Non-compliance can lead to death, injuries or material damage.
Please observe:
¹the product-specific safety information in these instruc-
tions
¹the general safety information in the document
TD00-000.860.01... and
¹the safety information according to ARTD part 2.
WARNING X-ray radiation!
Non-compliance can lead to illness, irreversible damage to body
cells and genetic material, severe injuries and death.
When working on the unit which requires release of radiation, the
radiation protection guidelines and the radiation protection rules
according to ARTD-002.731.02... must be observed.
Observe the following:
¹Use available radiation protection equipment.
¹Wear radiation protective clothing (lead apron).
¹Keep distance to radiation source as large as possible.
¹Only release radiation if necessary.
¹Set radiation as low as possible (low kV and mAs val-
ues).
¹Release radiation as briefly as possible.
X¹Checks that require radiation to be released are marked
by the radiation warning symbol displayed on the left.

Siemens AG SPR8-125.831.01.02.02 POLYMOBIL Plus
05.05 CS PS 24
General 9
Page 9 of 40
Medical Solutions
Fig. 2:

10 General
POLYMOBIL Plus SPR8-125.831.01.02.02 Siemens AG
05.05 CS PS 24
Page 10 of 40 Medical Solutions
DANGER When working on the open unit there is a risk of electrical shock!
Non-compliance can lead to injuries or death.
Observe the following:
¹The capacitor bank can still be charged. Do not attempt
to work on the system while this condition exists.
¹After switching off the system, approximately 450 VDC
(350 VDC for Serial No. < 10100) may still be present in
the system even after disconnecting the line voltage
plug. Within 10 minutes this voltage will drop to approxi-
mately 10 V.
¹Always measure the actual voltage present with the DVM
at test points -VCC and + VCC on the D 960 inverter
board or (more accessible) on the D 970 capacitor board
at the + connection point of capacitor C3 and on the right
side of fuse F3 (Fig.2/p.9).
¹LEDs V1 ... V10 on D 970 go out at a significantly higher
voltage level and are therefore not reliable safety indica-
tors.
¹If a fuse on the D 970 has responded, high voltage may
still be present at the affected capacitor even after a pro-
longed period of time.
¹The capacitor discharge circuit utilizes the D925 board,
CS and LS relays. If connectors X3 or X9 on D 925 or D
950 are not inserted or if there is a defect in the circuit,
the C-bank will not discharge. This can cause life-threat-
ening voltage to be present in the system even after a
prolonged period of time.
¹Also refer to the Polymobil Plus Service instructions
SPR8-125.061... "Replacing the capacitor bank".
•Connect the Polymobil Plus only to a line voltage supply (line voltage receptacle) that
complies with the requirements of VDE 0107 or corresponds to the local national regu-
lations.
•Disconnect the Polymobil Plus at the line voltage OFF switch on the operating console
and disconnect the line voltage plug prior to performing any service work.
•Remove or insert boards with the generator switched OFF only; observe ESD guide-
lines when handling boards.

Siemens AG SPR8-125.831.01.02.02 POLYMOBIL Plus
05.05 CS PS 24
General 11
Page 11 of 40
Medical Solutions
1.6 Explanation of abbreviations
The items identified by these abbreviations are contained in the Maintenance Protocol
and should be checked off upon completion.
Abbrev. Explanation
SI Safety Inspection
SIE Electrical Safety Inspection
SIM Mechanical Safety Inspection
PM Preventive Maintenance
PMP Preventive Maintenance Preventive Parts Replacement, External Inspec-
tion, etc.
PMA Preventive Maintenance Adjustments
PMF Preventive Maintenance, Function Check, Operating Value Check
Q Quality Check
QIQ Image Quality Check
QSQ System Quality Check
SW Software Maintenance

12 General
POLYMOBIL Plus SPR8-125.831.01.02.02 Siemens AG
05.05 CS PS 24
Page 12 of 40 Medical Solutions
1.7 Information on the protective conductor resistance test
Observe the information in the “Safety rules for installation and maintenance”
(ARTD-002.731.17...).
The protective conductor resistance is to be measured, documented and evaluated during
maintenance.
NOTE For evaluation, the value first measured and values documented
during previous maintenance or safety checks are to be compared
to the measured values. A sudden increase of the measured val-
ues, even if the limit value of 0.2 Ohm is not exceeded, indicates
errors in the protective conductor connection (protective conduc-
tor or contacts).
Measurement is to be carried out according to DIN VDE 0751, part 1 (see ARTD part 2).
In doing so, the protective conductor resistance to all conductive and accessible parts is
to be measured in the normal operating status of the unit.
Make sure that control or data cables between components of the unit do not simulate a
protective conductor connection.
During measurement, the power supply cable and additional connection cables with inte-
grated protective conductor are to be moved section by section in order to detect breaks
in the cables.
The protective conductor resistance must not exceed 0.2 Ohm.
Fig. 3: Measuring circuit for measuring the protective conductor resistance for units that are
disconnected from power, in compliance with DIN VDE 0751-1/2001-10, Fig. C2.
Pos. 1 = System
Pos. 2 = Application part type B (if available)
Pos. 3 = Measurement setup (integrated into measuring device)

Siemens AG SPR8-125.831.01.02.02 POLYMOBIL Plus
05.05 CS PS 24
General 13
Page 13 of 40
Medical Solutions
The values that were determined are to be logged and evaluated in the report “Protective
conductor resistance / report” by indicating the measuring points.
In addition, the measuring procedure and the measuring device used (designation and
serial number) are to be documented.
NOTE The report “Protective conductor resistance / report” is filed in the
“Certificates” register in the system folder.
NOTE If documentation of protective conductor resistance measure-
ments is missing, a new report must be created.
A new report “Protective conductor resistance / report” is included
in the SPR8-125.034.02.02 startup instructions. Detach this report
from these instructions, complete it and file it in the “Certificates”
register in the system folder. For a first determination, the deter-
mined values are to be logged as values measured for the first
time. Evaluation is not required in this case.

14 General
POLYMOBIL Plus SPR8-125.831.01.02.02 Siemens AG
05.05 CS PS 24
Page 14 of 40 Medical Solutions
1.8 Information on the device leakage current measurement
NOTE During maintenance, the device leakage current measurement is
to be carried out and logged as repeated measurement.
However, under the following circumstances the value first mea-
sured is to be determined again and a new report is to be created:
- If documentation of device leakage current measurement is miss-
ing.
- If local mains voltage deviates from the mains voltage document-
ed in the report (e.g. in case of change of location / change of op-
erator).
- When using another measuring process for measuring the device
leakage current than that documented in the report.
For traceability, the newly created report is to be referenced in
writing on the old report. The reason for new determination of the
value which was first measured is to be documented and con-
firmed with name and signature.
Observe the instructions in the “Safety rules for installation and maintenance”
(ARTD-002.731.17...).
WARNING Electrical voltage!
Non-compliance can lead to severe injuries even resulting in
death.
¹The device leakage current measurement for devices of
protection class I may only be carried out after protective
conductor tests were carried out successfully.
First measured value
The first measured value was determined already and documented in the report “Device
leakage current / report”. The measuring method was also logged.
Measurement was carried out with the logged mains voltage and the logged measuring
devices.
Measurement
Measurement is to be carried out according to DIN VDE 0751, part 1 (see
ARTD-002.731.17...) and the determined value is to be logged.
The measuring method indicated in the report is to be used for this.
If the value first measured needs to be determined again (see instructions above), either
direct measurement or differential measurement can be selected.

Siemens AG SPR8-125.831.01.02.02 POLYMOBIL Plus
05.05 CS PS 24
General 15
Page 15 of 40
Medical Solutions
Measuring the device leakage current according to the differential current method (mea-
suring setup according to (Fig.4/p.15)) is the preferred method, as the person carrying
out the measurement or other persons are not endangered during the measurement.
However, observe the minimum resolution of the leakage current measuring device and
additional manufacturer specifications which limit usage of the measuring device.
Fig. 4: Measuring circuit for measuring the leakage current according to the differential current
method in compliance with DIN VDE 0751-1/2001-10, Fig. C6 for protection class I.
Pos. 1 = System
Pos. 2 = Application part type B (if available)
Pos. 3 = Measurement setup (integrated into measuring device)
If direct measurement of the device leakage current is used (measuring setup according
to (Fig.5/p.16)), the system must be installed in an insulated way and must not be
touched during measurement.

16 General
POLYMOBIL Plus SPR8-125.831.01.02.02 Siemens AG
05.05 CS PS 24
Page 16 of 40 Medical Solutions
Fig. 5: Measuring circuit for direct measurement of the leakage current in compliance with DIN
VDE 0751-1/2001-10, Fig. C5 for protection class I.
Pos. 1 = System
Pos. 2 = Application part type B (if available)
Pos. 3 = Measurement setup (integrated into measuring device)
WARNING Electrical voltage!
Non-compliance can lead to serious injuries or even death.
¹When measuring device leakage current directly, during
measurement, no housing parts of the unit must be
touched (Fig.5/p.16)).
¹Access to the unit by third parties must be prevented.
The unit must be switched on during measurement. Therefore, measuring devices with
automated measuring procedure must be set to manual measuring.
The highest value must be entered into the report “Device leakage current / report”.
This value must not exceed the permissible leakage current values according to DIN VDE
0751-1/2001-10, Table F.1, line “Device leakage current for units according to remarks 1
and 3”, of 2.5 mA.
The actual mains voltage is to be measured and logged. If the measured mains voltage
deviates from the nominal voltage, the measuring value is to be corrected to the value
which corresponds to a measurement with the nominal value of the mains voltage. This is
to be additionally documented.

Siemens AG SPR8-125.831.01.02.02 POLYMOBIL Plus
05.05 CS PS 24
General 17
Page 17 of 40
Medical Solutions
The measuring method (differential measurement or direct measurement) and the mea-
suring device used (designation and serial number) are to be documented.
For repeated measurements, the measuring value is to be evaluated additionally.
NOTE For evaluation, the value first measured and the values document-
ed during previous maintenance or safety tests are to be com-
pared with the measured values. A sudden increase of the
measured values, even if the limit value of 2.5 mA is not exceeded,
indicates errors in the primary circuit of the mains voltage supply
(insulation damages, damages due to dampness, faulty suppres-
sor element or similar).
In case of new determination, evaluation is not required.
The report “Device leakage current / report” is to be filed in the “Certificates” register in the
system folder.
NOTE The report “Device leakage current / report” is filed in the “Certifi-
cates” register in the system folder.
NOTE If documentation of device leakage current measurement is miss-
ing, a new report must be created.
A new report “Device leakage current / report” is included in the
startup instructions SPR8-125.034.02.02. Detach the report from
this instruction, complete it and file it in the “Certificates” register
in the system folder. For a first determination, the determined val-
ues are to be logged as values measured for the first time. Evalu-
ation is not required in this case.

18 General
POLYMOBIL Plus SPR8-125.831.01.02.02 Siemens AG
05.05 CS PS 24
Page 18 of 40 Medical Solutions
1.9 Technical Safety Checks (TSC)
Abbreviation: TSC = Technical Safety Checks
NOTE Within the scope of DIN VDE 0751-1, the operator of medical-tech-
nical products is required to carry out technical safety checks at
regular intervals.
The tests listed in these maintenance instructions include all tech-
nical safety checks required according to DIN VDE 0751-1.
For the technical safety checks, a separate report is available with
the print number SP00-000.834.01....
Within the scope of DIN VDE 0751-1, we recommend documenting
the results of maintenance in the maintenance protocol as well as
the TSC protocol, completing it and handing it over to the custom-
er.
The following table allocates the corresponding maintenance pro-
cedures to each technical safety check which is documented in the
document SP00-000.834.01....
Test certificate “Technical safety
checks”
Maintenance instructions, test / remarks
1 Information for identification Please complete fields.
2 General tests n.a.
2.1 Visual check: No damages affecting
safety?
2.1.1 Checks for signs of damage, tests:
SIM Covers
SIM Control box / control console
SIM Exposure release cable
SIM Power and primary cables
2.2 Cables and cable guides safe and
without visible damage?
2.1.1 Checks for signs of damage, tests:
SIM Exposure release cable
SIM Power and primary cables
2.3 Used accessories without damage? 2.1.1 Checks for signs of damage, test:
SIM DAP measuring system (optional)
2.4 Radiation protection equipment avail-
able and without damage? (no structural
radiation protection)
2.9 Radiation, tests:
SIE Radiation indicator
SIE Acoustic signal

Siemens AG SPR8-125.831.01.02.02 POLYMOBIL Plus
05.05 CS PS 24
General 19
Page 19 of 40
Medical Solutions
2.5 Required operator documents com-
plete, available, readable
2.1.3 Customer documents, test:
SI customer documents
Ask the customer for additional required
operator documents and check for com-
pleteness, availability and readability.
2.6 All warnings available and visible? 2.1.2 Labels, test:
SIM labels
2.7 Operating icons, LEDs and key label-
ing ok?
2.9 Radiation, test:
SIE Radiation Indicator
2.10 Control console, tests:
SIE Operating elements
SIE Indicators
3. Electrical checks n.a.
3.1 Protective conductor resistance mea-
surement
2.11 Protective conductor test, test:
SIE Protective conductor test
3.2 Device leakage current or equivalent
device leakage current measurement
n.a.
3.2.1 Device leakage current measure-
ment
2.12 Device leakage current measurement,
test:
SIE Device leakage current measurement
3.2.2 Equivalent device leakage current
measurement
n.a.
3.3 Patient leakage current or equivalent
patient leakage current measurement
n.a.
3.3.1 Patient leakage current measure-
ment
n.a.
3.3.2 Equivalent patient leakage current
measurement
n.a.
4. Mechanical checks n.a.
4.1 Wall, ceiling and floor attachments
fixed and without damage?
n.a.
Test certificate “Technical safety
checks”
Maintenance instructions, test / remarks

20 General
POLYMOBIL Plus SPR8-125.831.01.02.02 Siemens AG
05.05 CS PS 24
Page 20 of 40 Medical Solutions
4.2 Mechanically moving unit parts clean
and easy to move (lubricated, if neces-
sary)?
2.8 Stand, test:
SIM Support arm locking device
2.6 Single tank, test:
SIM Locking device
2.7 Double-slot diaphragm, test:
SIM Rotating
4.3 Ropes, chains, belts and spindles
without signs of wear and tear?
2.8 Stand, test:
SIM Chains of the spring counterbalance
4.4 Mobile devices: wheels / pulleys and
brakes ok?
2.2 Checking the screws, test:
SIM Front wheels
2.4 Checking the wheels, tests:
SIM Noises
SIM Ease of movement
SIM Wear and tear on the rubber cover
2.5 Checking the pedal positions, test:
SIM Braking / locking
4.5 No conspicuous sound during opera-
tion (e.g., gear)?
2.4 Checking the wheels, test:
SIM Noises
2.8 Stand, test:
SIM Spring counterbalance
5. Functional checks n.a.
5.1 Emergency Stop- emergency shut-
down button functional
n.a.
5.2 Warning devices functional? 2.9 Radiation, tests:
SIE Radiation indicator
SIE Acoustic signal
5.3. Switch-off of unit movements in end
position OK?
n.a.
5.4 Switch-off of unit movements via col-
lision protection OK (e.g., collision pro-
tection)?
n.a.
5.5. Safety distances (wall, floor, ceiling)
complied with or ensured via other mea-
sures (e.g., light barrier)?
n.a.
5.6. Other safety shutoffs functional (e.g.,
safety floor plate)?
n.a.
Test certificate “Technical safety
checks”
Maintenance instructions, test / remarks
