Siemens ARCADIS Avantic Operating and maintenance instructions

ARCADIS Avantic
English
Print No.: SPR2-330.662.01.02.02 Doc. Gen. Date: 05.06
Replaces: SPR2-330.662.01.01.02
© Siemens AG 2005
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model _or_design,_are_reserved.
SP
DHHS Maintenance Instructions

ARCADIS Avantic SPR2-330.662.01 Page 2 of 4 Siemens AG
Rev. 02 05.06 CS PS SP Medical Solutions
0 - 2 Revision
Document revision level
The document corresponds to the version/revision level effective at the time of system delivery. Revi-
sions to hardcopy documentation are not automatically distributed.
Please contact your local Siemens office to order current revision levels.
Disclaimer
The installation and service of equipment described herein is to be performed by qualified personnel
who are employed by Siemens or one of its affiliates or who are otherwise authorized by Siemens or
one of its affiliates to provide such services.
Assemblers and other persons who are not employed by or otherwise directly affiliated with or autho-
rized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or
one of its affiliates before attempting installation or service procedures.
Chapter Page Revision
all all 02

Contents 0 - 3
Siemens AG SPR2-330.662.01 Page 3 of 4 ARCADIS Avantic
Medical Solutions Rev. 02 05.06 CS PS SP
1 _______Safety Information ______________________________________________ 1 - 1
Text emphasis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Safety information and protective measures . . . . . . . . . . . . . . . . . . . . . . 1 - 2
2 _______General information and overview_________________________________ 2 - 1
After completion of maintenance: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
1 Required reference documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2
2 Required test equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2
3 Safety Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2
4 Notes for the Maintenance Instructions . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2
4.1 Calibration of the option Integrated Dose Measurement Device . . . . . . . . 2 - 2
4.2 Information about air kerma strength determination . . . . . . . . . . . . . . . 2 - 2
3 _______Visual checks__________________________________________________ 3 - 1
1 Radiation protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 1
2 Checking the DHHS and Identification Labels . . . . . . . . . . . . . . . . . . . . 3 - 1
4 _______Checking the function blocks and displays _________________________ 4 - 1
1 Checking the ”deadman” switch function . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
1.1 Exposure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
1.2 Fluoroscopy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
2 Radiation indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
3 Fluoroscopy timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
4 Indication of X-ray tube voltage and current. . . . . . . . . . . . . . . . . . . . . . 4 - 2
5 Minimum source to skin distance . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
5 _______Function tests _________________________________________________ 5 - 1
1 Checking the accuracy of the tube voltage . . . . . . . . . . . . . . . . . . . . . . 5 - 1
2 Reproducibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1
2.1 Measurement set-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1
2.2 Calculations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2
3 Entrance dose rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 3
4 Check the I.I. format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4
6 Check the smallest field size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4
6 Checking the field limitation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 5
6 _______Technical Data _________________________________________________ 6 - 1
Technical data for DHHS components. . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
X-Ray Controls and Generators . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
Generator ratings: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
Maximum deviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Tube Housing Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Page

0 - 4 Contents
ARCADIS Avantic SPR2-330.662.01 Page 4 of 4 Siemens AG
Rev. 02 05.06 CS PS SP Medical Solutions
Definitions of the measurement bases of technique factors . . . . . . . . . . . . . . 6 - 2
Peak tube potential: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Tube current: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
7 ______ Final steps ____________________________________________________7 - 1
Final visual and function checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 1
Page

1 - 1
Siemens AG SPR2-330.662.01 Page 1 of 4 ARCADIS Avantic
Medical Solutions Rev. 02 05.06 CS PS SP
Safety Information 1
Text emphasis 1
Symbols 1
DANGER indicates when there is an immediate danger that l e a d s
to death or serious physical injury.
WARNING indicates a risk of danger that m a y l e a d to death or
serious physical injury.
CAUTION used with the safety alert symbol indicates a risk of
danger that leads to slight or moderate physical injury and/ or
damage to property.
NOTICE used without the safety alert symbol indicates a risk of
danger that if disregarded leads or may lead to a potential situa-
tion which may result in an undesirable result or state other than
death, physical injury or property damage.
NOTE contains information provided with special emphasis to
facilitate proper use of the equipment or proper execution of a
procedure, i.e. hints, tips.
Checks and adjustments that must be performed with radiation ON are identified by the
radiation warning symbol.
DANGER
WARNING
CAUTION
NOTICE
NOTE

ARCADIS Avantic SPR2-330.662.01 Page 2 of 4 Siemens AG
Rev. 02 05.06 CS PS SP Medical Solutions
1 - 2 Safety Information
Safety information and protective measures 1
Dangerous X-ray radiation during checks and maintenance work
steps.
Risk of death or serious physical injury.
For checks and adjustments that must be performed with the
radiation switched on, radiation safety measures must be
observed.
¹Use available radiation protection devices.
¹Wear radiation protection clothing (lead
apron)
¹Stay as far away as possible from the radia-
tion source.
¹Release radiation only if necessary.
¹Release radiation for as short a time as possi-
ble.
¹Set the radiation activity as low as possible
(low kV values, low mA values, short radiation
time).
Checks requiring the release of radiation are identified by the
radiation warning symbol as shown on the left.
Risk of physical injury or death and property damage!
Noncompliance can lead to death, physical injury or property
damage.
When performing the checks and maintenance work steps,
please note:
¹the product-specific safety information in this
document,
¹the safety information in the register Safety of
the ARCADIS Operating Instructions.
WARNING
WARNING

Safety Information 1 - 3
Siemens AG SPR2-330.662.01 Page 3 of 4 ARCADIS Avantic
Medical Solutions Rev. 02 05.06 CS PS SP
Danger of pathogen infection!
Noncompliance can lead to death or physical injury.
¹This product is released for use in operating
rooms and can be contaminated with infec-
tious blood or other body secretions.
¹Avoid all contact with blood or other body
secretions!
WARNING

ARCADIS Avantic SPR2-330.662.01 Page 4 of 4 Siemens AG
Rev. 02 05.06 CS PS SP Medical Solutions
1 - 4 Safety Information
This page intentionally left blank.

2 - 1
Siemens AG SPR2-330.662.01 Page 1 of 2 ARCADIS Avantic
Medical Solutions Rev. 02 05.06 CS PS SP
General information and overview 2
To ensure compliance with the applicable provisions of the Federal Performance Stan-
dard, the user of the equipment has to ensure that the maintenance procedure described
below is performed at intervals of six months or less. In case the user does not comply
with these requirements, the manufacturer can no longer be held liable.
If the results of any of the tests described in this document exceed the tolerances given,
the required adjustments must be performed.
Contact Siemens service.
After performing any adjustment, all applicable tests must be repeated.
After completion of maintenance: 2
I hereby certify that all procedures described in these maintenance instructions have been
completed as specified and that the tolerance values are within the accepted range.
Customer: Customer No.: Room:
BZ-No.: Type No.: Serial No.:
_____________ __________________
Date Signature

ARCADIS Avantic SPR2-330.662.01 Page 2 of 2 Siemens AG
Rev. 02 05.06 CS PS SP Medical Solutions
2 - 2 General information and overview
1 Required reference documents 2
- DHHS Test certificate 1a+ and Acceptance Test Protocol (in Register 3 of the
Logbook)
2 Required test equipment 2
3 Safety Notes 2
4 Notes for the Maintenance Instructions 2
- Compliance with the applicable sections of the Federal Performance Standards is
assured when all procedures described in these instructions have been performed and
tolerance values are within the specified range.
- The unit movements required for these procedures must be performed cautiously to
prevent the unit from being damaged in the event of a malfunction.
- When performing safety checks or adjustments with radiation ON, radiation protection
clothing must be worn.
4.1 Calibration of the option Integrated Dose Measurement Device 2
A calibration of the optional installed Integrated dose measurement device
(air kerma measurement device or area dose product measurement device)
is not necessary.
4.2 Information about air kerma strength determination 2
The air kerma strength is determined with a measuring chamber integrated into the sys-
tem. The reference location for determining the air kerma strength is 30 cm in front of the
image intensifier input (70cm distance from the focal spot).
- PTW-Diados Serial-No.: .......... Date of calibration ..........
- Fluke Serial-No.: .......... Date of calibration ..........
-Calculator
All local safety regulations must be observed.
Checks or adjustments to be performed with radiation ON are
marked with the radiation warning symbol .
This value is used because in typical applications the object to be
examined is located approx. 30cm in front of the I.I.
CAUTION
WARNING
NOTICE

3 - 1
Siemens AG SPR2-330.662.01 Page 1 of 2 ARCADIS Avantic
Medical Solutions Rev. 02 05.06 CS PS SP
Visual checks 3
1 Radiation protection 3
Make sure that there is no mechanical damage on the POWERPHOS tube housing
assembly and image intensifier which could impair the radiation protection.
2 Checking the DHHS and Identification Labels 3
Confirm that the certification labels as well as serial number and model number labels are
legible. Use the illustrations which are shown in the Operating Instructions of the product.
If labels are required, contact the SIEMENS Medical Solutions Local Service Organization
or the SIEMENS Medical Solutions Regulatory Affairs department.
Damage present (brief description):
Component certified Model No. Serial No. Date
ARCADIS Avantic
X-ray control
Beam Limiting device
BLD
Powerphos Avantic
Tube housing assembly
Image Intensifier
Warning label present and legible YES
Powerphos and image intensifier
have been checked for mechanical
damage YES NO

ARCADIS Avantic SPR2-330.662.01 Page 2 of 2 Siemens AG
Rev. 02 05.06 CS PS SP Medical Solutions
3 - 2 Visual checks
This page intentionally left blank.

4 - 1
Siemens AG SPR2-330.662.01 Page 1 of 2 ARCADIS Avantic
Medical Solutions Rev. 02 05.06 CS PS SP
Checking the function blocks and displays 4
1 Checking the ”deadman” switch function 4
1.1 Exposure 4
An exposure value is set at the control console.
- Activate the exposure with the exposure switch and end it immediately by releasing the
switch.
The exposure must end immediately.
1.2 Fluoroscopy 4
Activate fluoroscopy for a short time and release the fluoroscopy switch.
Fluoroscopy must stop immediately.
a) with the fluoroscopic switch at the control console
b) with the foot switch
2 Radiation indicators 4
Check that the radiation indicators at the control console and on the monitor cart are visi-
ble during radiation and that an audible (whistling) signal is sounded after exposure
release for about 1.5 seconds.
Deadman’s switch is functioning YES NO
Radiation indicators are functioning YES NO

ARCADIS Avantic SPR2-330.662.01 Page 2 of 2 Siemens AG
Rev. 02 05.06 CS PS SP Medical Solutions
4 - 2 Checking the function blocks and displays
3 Fluoroscopy timer 4
1. Ensure that the persons present are not subject to radiation hazard during the
tests described below.
2. Set the manual fluoroscopy voltage to the lowest possible kV value.
Close the iris diaphragm, cover the tube assembly with a lead apron.
3. Switch on fluoroscopy.
4. Check that the acoustic signal sounds after a total fluoroscopy time of 4.5 minutes
has elapsed.
5. Reset the buzzer by pressing the button under the symbol in the display.
4 Indication of X-ray tube voltage and current 4
Confirm that tube voltage and current are continuously indicated during fluoroscopy.
5 Minimum source to skin distance 4
Confirm that a spacer limiting the source to skin distance (SSD) to 30 cm is present.
Fluoroscopy timer functioning correctly YES NO
Indicators functioning YES NO
Spacer present YES NO

5 - 1
Siemens AG SPR2-330.662.01 Page 1 of 6 ARCADIS Avantic
Medical Solutions Rev. 02 05.06 CS PS SP
Function tests 5
1 Checking the accuracy of the tube voltage 5
The actual kV value must agree with the indicated value within the limits stated by
Siemens (max. deviation &10 % for the ARCADIS Avantic), if the X-ray system is con-
nected to a power supply corresponding to Siemens specifications.
Tools: PTW-Nomex
Test procedure:
Refer to the information on the Nomex in the operating instructions
Connect the Nomex.
Remove the single-tank cap at the POWERPHOS after removing the two screws.
Select full image intensifier format and open the collimator fully.
Place the measuring detector on the diaphragm.
Set the following values in the operating field and check
2 Reproducibility 5
The coefficient of variation must not exceed 0.05 when the X-ray system is connected to a
power supply as specified by Siemens.
The technique factors should be adjusted to alternate settings and reset to the test setting
after each measurement.
2.1 Measurement set-up 5
Place the dosimeter in the center of the X-ray beam.
Before each new dose measurement, make sure that the indicator is reset to zero.
Operating mode Indicated Measured Tolerance
Fluoroscopy 70 kV 63 kV to 77 kV
Fluoroscopy 112 kV 101 kV to 123 kV
Fluoroscopy 125 kV 113 kV to 137 kV

ARCADIS Avantic SPR2-330.662.01 Page 2 of 6 Siemens AG
Rev. 02 05.06 CS PS SP Medical Solutions
5 - 2 Function tests
2.2 Calculations 5
Variation coefficient C
For n individual measurements, the coefficient of variation C amounts to:
s = calculated standard deviation
= mean value of all individual measurements
xi= measured value of the ith measurements.
1. To obtain the average x, the 4 dose values are added and the sum is divided by 4.
2. To obtain the difference, the average value is subtracted from each individual
measured value and entered into the column provided
Square the differences
3. Add the 4results: Σ....................:
4. Divide the sum by 4: ...............
5. Obtain the square root of the new result: Square root S: ..................
6. Divide the square root S by the average value x determined in step 1:
C = =
n1/2
Σ
i = 1
Measurement Radiation Exposure (xi ) Average ( ) = Difference*
1
2
3
4
*Disregard the sign if negative numbers are obtained.
Measurement Square of the difference (xi- )2
1
2
3
4
Coefficient of variation C = S
C = . . . . . . . . . . . . . . . (must be ≤0.05)
s
x
1
x
(xi- x)2
n -1
x
x
x
x

Function tests 5 - 3
Siemens AG SPR2-330.662.01 Page 3 of 6 ARCADIS Avantic
Medical Solutions Rev. 02 05.06 CS PS SP
3 Entrance dose rate 5
The legal maximum entrance dose rate is 87 mGy/min (10 R/min).
For safety reasons, the value has been fixed at < 78 mGy/min (9 R/min) at the factory.
The entrance dose rate imust be checked by means of a dose rate meter.
In the measurement setup shown, the maximum adjustable value of 125 kV yields an
input dose rate of approx. 87mGy/min (10 R/min).
Measurement set-up
Position the measurement detector of the dosimeter as shown in the diagram.
Press the " ” button at the operating console.
Select 125 kV. Select full I.I. format, open the collimator to max. aperture, switch fluoros-
copy ”ON”. Measure the dose and record.
Fig. 1
30 cm
100 cm
2,1
cm
Image intensifier
Input screen
Ionization
chamber
Focal spot

ARCADIS Avantic SPR2-330.662.01 Page 4 of 6 Siemens AG
Rev. 02 05.06 CS PS SP Medical Solutions
5 - 4 Function tests
4 Check the I.I. format 5
Work sequence:
1. Select the full I.I. input format.
2. Set the iris diaphragm to max. aperture
3. Switch on fluoroscopy
If all eight blades of the iris diaphragm are still visible at the edge of the TV monitor
(Fig. 2), no further tests are necessary.
4. Select zoom format (check as in item 3).
6 Check the smallest field size 5
The smallest field size should be < 5 cm x 5 cm at the I.I. input.
The check is made at the TV monitor.
1. Select full I.I. view format.
2. Close the iris diaphragm and select full I.I. view format.
3. Attach a center cross with lead ruler to the center of the I.I. input screen.
4. Switch on fluoroscopy.
5. Read the size of the X iris on the monitor.
Fig. 2
I.I. format in order YES NO
Zoom format in order YES NO
Smallest field size at the I.I. input: ........ cm x ........ cm
TV image
Blades, iris diaphragm
During fluoro, neither the length nor the width of the
radiation field in the plane of the image receptor may
exceed that of the visible area of the image receptor
by more than 3 % of the SID (focus - I.I. distance).
The sum of the longitudinal deviation X and the width
deviation Y shall be no greater than 4 % of the SID.

Function tests 5 - 5
Siemens AG SPR2-330.662.01 Page 5 of 6 ARCADIS Avantic
Medical Solutions Rev. 02 05.06 CS PS SP
6 Checking the field limitation 5
REGULATION -
Fluoroscopy and radiography using the fluoroscopic imaging assembly with inherently
circular image receptors.
When any linear dimension of the visible area of the image receptor measured through
the center of the visible area is less than or equal to 34 cm in any direction, at least 80
percent of the area of the x-ray field overlaps the visible area of the image receptor.
The check is made at the TV monitor.
Determine the central point at the I.I. input. Use adhesive tape to attach center cross
(with lead ruler).
Open the slot collimator, adjust the iris diaphragm to an opening of about 15 cm.
Perform the test in the C-arm position shown.
Fig. 3
Fig. 4
Basic position
C-arm to the left
(top view)
C-arm to the right
(top view)
A = mid-point I.I. input
B = middle of the radiation
field
∆= deviation of A to B
x = deviation in the x-axis
y = deviation in the y-axis B
∆
A
y
x

ARCADIS Avantic SPR2-330.662.01 Page 6 of 6 Siemens AG
Rev. 02 05.06 CS PS SP Medical Solutions
5 - 6 Function tests
Work sequence:
1. Select full size (no zoom).
2. Adjust the Iris diaphragm to an opening of about 15 cm.
3. Adjust the C-arm (see Fig. 3).
4. Switch on fluoroscopy briefly.
5. Read the evaluation at the TV Monitor (Fig. 4).
(Use stored image).
6. Calculate the deviation
7. Test results (see also Fig. 4):
:
Average deviation permissible*Average deviation actual
Basic position must be < 47 mm
(equal to > 80% over-
lapping of the visible
area)
...................... mm
C-arm to the left must be < 47 mm
(equal to > 80% over-
lapping of the visible
area)
...................... mm
C-arm to the right must be < 47 mm
(equal to > 80% over-
lapping of the visible
area)
...................... mm
x2+ y2
