Siemens ACUSON P300 User manual

ACUSON P300™ Ultrasound System
Control Panel Diagram
Power On / O
1
1
TGC Controls
2
2
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
3
3Le Mouse Click
4
4Action
5
5Right Mouse Click
6
6 Trackball
7
7 Pointer
8
8 Freeze
Start/End
9
9
Color Doppler
16
16 Dual (Le)
23
23
Probe/Preset
10
10
Measure (Label)
17
17 Dual (Right)
24
24 ECG/Transmit Power/
Edit ID
31
31
Conguration Menu
11
11
Measure (Generic)
18
18 Auto Optimization/
2D, M-mode Gain
25
25
Archive Review
12
12
Update/Line/
Doppler Gain
19
19 Record/Print
26
26 Pictogram
33
33
Exam Review
13
13 Audio (Decrease)
20
20 Clip/Image Store
27
27 Report
34
34
CW Doppler
14
14 Audio (Increase)
21
21 2D
28
28 Start/Stop VPan
35
35
PW Doppler
15
15 eSie Wheel
(Sokey control)
22
22 M-mode
29
29 Depth/Zoom
36
36
9
9
13
13
12
12
11
11
10
10
14
14
15
15
16
16
17
17
18
18
19
19
20
20
21
21
22
22
23
23
24
24
25
25
26
26
27
27
28
28
29
29
30
30
31
31
33
33
34
34
35
35
36
36
www.siemens.com
Tools/VPan (Panoramic)
32
32
32
32
30
30 [Inactive - For Future Use]
© Siemens 2012. All rights reserved.

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 1
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
ACUSON P300™ Ultrasound System*
Quick Reference Guide – System Overview
Introduction
This Quick Reference Guide contains brief descriptions and instructions for the functions
most commonly used to perform 2D, M-mode and Doppler exams
This supplement is not a substitute for the system Operators Manual.
Contents
Exam Basics
2D Controls
Color, PW and CW Doppler and M-mode Optimization
Measurements and Calculations
Text and Pictograms
Data and Image Management
Exam Basics
The Power On/Off button is located on the upper right side of the system.
A solid yellow light will indicate the power is on.
The Battery option will allow the system to run on internal battery for 80 minutes
(scanning) or 120 minutes (standby).
Begin an Exam
Press START/END
Enter patient name, ID and other exam information
Press TAB to move between data fields
or
Roll the trackball to move to the next data field and press Right Select
Select the proper APPLICATION, PRESET and PROBE
Press Enter or select OK to start exam

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 2
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Modify Patient Data During an Open Exam
Press OPTIONS
Rotate S wheel to EDIT ID and press the S button
Edit patient data
Select OK
or
Press Enter on the QWERTY keyboard
Note: Editing patient data will re-name all previously stored images/clips within the study.
Modify Patient Data From Patient Archive
Press ARCHIVE/REV
Highlight patient
Rotate Swheel to NEXT/PREVIOUS and press the S button
Rotate Swheel to EDIT ID and press the S button
Note: Editing patient data will re-name all previously stored images/clips within the study.
Modify Application
Press START/END
Select CURRENT
Select new APPLICATION, PRESET and PROBE
Select OK
Change Transducer and/or Preset
Press PROBE/PRESET
Select PRESET and/or PROBE
Select OK
The UPDATE/LINE/GAIN controls gain levels (rotate) and cursor/update
(press) for CW, PW and Color Doppler
The AUTO/GAIN controls 2D and M-mode gain levels (rotate), one-button gain
and TGC optimization for 2D (press)

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 3
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Storing Images/Clips
When frozen, press CLIP/IMAGE to save a static image to the local archive
When live, press CLIP/IMAGE to acquire and save a clip to the local archive
The saved data displays in the thumbnail panel on the right of the screen
Press REC/PRINT to print the onscreen image
Note: Press MENU to set up PERIPHERALS assigned to REC/PRINT
Review an Image
Press EXAM/REV during an active exam to view and delete images
To view thumbnails 1:1, roll trackball to thumbnails and press Right Select or Left
Select
To delete images, roll trackball to thumbnail and double-click Right Select
A red check mark will appear in the upper left corner
Select DELETE
Select YES
Activate Review on a Previous Exam
Press ARCHIVE/REV to view patient archive
Highlight patient name and double-click Right Select or Left Select to review
2D Controls
Basic System Optimization
The following table identifies 2D system optimization and technologies which can be
used during exams.
The Swheel controls the softkey options located at the bottom of the imaging
screen, rotating the S wheel (green) allows the user to scroll between softkeys, pressing
the S button (yellow) changes the value and the NEXT/PREVIOUS softkey scrolls to
additional pages.
Items in table are not arranged sequentially
To Adjust / Control Do This
Depth Rotate the DEPTH/ZOOM wheel

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 4
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Zoom Press DEPTH/ZOOM
Use trackball to adjust position; rotate wheel to adjust size of
ROI
Press DEPTH/ZOOM
Focus Roll trackball to move focal zone(s)
To anchor position of focal zones, press ACTION
TEI
Harmonic Imaging
Rotate S wheel to TEI, then press S button
To change harmonic frequencies, rotate Swheel to
FREQUENCY, then press S button
TEI frequencies range from PEN, GEN, RES
Orient
Up/down invert
Rotate S wheel to ORIENT and press S button
Frequency Rotate Swheel to FREQUENCY and press S button
Rotate Swheel to adjust
Range varies from transducer and application
Size (2D Sector Width)
Increases line
density/frame rate
*Not available on linear
transducers
Rotate S wheel to SIZE and press Sbutton
Rotate Swheel to decrease size of sector
Note: CONCURR is available on phased array transducers
and will automatically reduce 2D image width to the Color
Doppler ROI and allows user to pan image.
Dynamic Range
Adjusts grayscale levels
Rotate Swheel to DYN RANGE and press S button
Rotate Swheel to adjust
Adding Focal Zones Rotate Swheel to FOCUSES and press S button for additional
foci
Select ACTION to lock focus in place
Range: 1-4; ALTERNATE
Reverse
Left/right invert
Rotate Swheel to REVERSE and press Sbutton
TPVIEW (Trapezoid)
Linear transducers only Rotate Swheel to TPVIEW and press Sbutton
Gray Maps
Applies a post processing
curve that assigns echo
amplitudes to grayscale
Rotate S wheel to GRAY MAP and press Sbutton
Rotate Swheel to adjust
Range: 1-5

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 5
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
levels
Colorize (Tint)
Sets the chromatic scale
active in 2D
Rotate Swheel to COLORIZE and press S button
Rotate Swheel to adjust
Range: Off(-), Orange, Indigo, Magenta, Blue, Yellow, RGB
Sharpness
Accentuates edges and
small differences in tissues
Rotate Swheel to SHARPNESS and press Sbutton
Rotate Swheel to adjust
Range: 1-5
Density
Adjusts line density
Rotate Swheel to DENSITY and press S button
Rotate Swheel to adjust
Range: LOW, HIGH
Persistence
Weighted average of
frames over time
Rotate Swheel to PERSIST and press S button
Rotate Swheel to adjust
Range: Off(-),1-6; AVERAGE
Clip Duration
Sets duration of clips
Rotate Swheel to CLIPS DUR and press Sbutton
Range (seconds): 1, 2, 3, 4, 5, 7, 10, 20, 30, 60, UNLIMITED
MVIEW
Spatial Compounding
Rotate Swheel to MVIEW and press S button
Rotate Swheel to adjust
Range: Off(-), 1-10
XVIEW
Provides speckle reduction
and contrast enhancement
Rotate Swheel to XVIEW and press S button
Rotate Swheel to adjust
Range: Off(-), 1, 2, C.
XVIEW level Coptions: X SMOOTH 1-5, X DETAIL 1-8,
X ENHAN 1-12
2D Imaging Features
The following table identifies 2D imaging features.
Items in table are not arranged sequentially
Feature To Use Feature
One button image
optimization
Press AUTO to automatically adjust the general gain
and TGC

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 6
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Dual Mode
Side-by-side imaging Press left DUAL to activate dual screen display
Press right DUAL to activate right screen display
Press 2D to escape
Note: For live dual, rotate S wheel to NEXT/PREVIOUS, scroll to
SIMULT and press S button.
QUAD Imaging When in DUAL function, select NEXT/PREVIOUS, scroll to
QUAD, press the S button
Press right DUAL button to advance
2D-CFM
Live Dual 2D and Color
Doppler
Rotate Swheel to 2D-CFM and press S button
Allows for live 2D and Color Doppler imaging
VPAN
Activates panoramic
imaging
Press TOOLS , select VPAN, select OK
Press ACQUIRE to activate ROI box, press ACQUIRE to
begin scanning, scan, then press ACQUIRE to end acquisition
Press MEASURE for labeled measurement
Press GENERIC MEASUREMENTS for generic
measurement
Steer Image
Linear transducers only Note: MVIEW must be deactivated.
Rotate Swheel to B-STEER and press S button
Rotate Swheel to steer image
Biopsy
Activates or de-activates
biopsy display
Rotate Swheel to BIOPSY and press S button
Color, PW and CW Doppler and M-mode Optimization
The UPDATE/LINE/GAIN controls gain levels (rotate) and cursor/update (press)
for CW, PW and Color Doppler.

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 7
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Color Doppler Imaging
Items in table are not arranged sequentially
To Adjust / Control Do This
Engage Color Doppler Press Cbutton
Color Gain
Rotate the UPDATE/LINE/GAIN wheel
ROI Size and Position Roll trackball to desired position
Press ACTION and roll trackball to desired size
Press ACTION to set
2D-CFM
Live dual 2D and color
Doppler
Rotate Swheel to 2D-CFM and press S button
PWR D (Power Doppler) Rotate Swheel to PWR D and press S button
PRF (Scale/Velocity) Rotate Swheel to PRF and press S button
Rotate Swheel to change PRF
Baseline Rotate Swheel to BASEL and press S button
Rotate Swheel to change
D-Steer
Linear transducers only
Rotate Swheel to D-STEER and press S button
Rotate Swheel to desired steering angle
Color Doppler Frequency Rotate Swheel to FREQUENCY and press S button
Rotate Swheel to adjust
Sensitivity
Rotate Swheel to SENSIT and press S button
Rotate Swheel to adjust
Range: 1, 2, 3
Density
Rotate Swheel to DENSITY and press S button
Rotate Swheel to adjust
Range: LOW, HIGH
Persistence Rotate Swheel to PERSIST and press S button

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 8
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Rotate Swheel to adjust
Range: Off(-), 1-7
Color Map Rotate Swheel to COLOR MAP and press S button
Rotate Swheel to adjust
Range: V1-V6, plus two Velocity/Variance maps (VV1 and
VV2).
Filter
Used to reduce the
artifacts caused by
acoustic decoupling or
moving structures
Rotate Swheel to FILTER and press S button
Rotate Swheel to adjust
Range: LOW, MEDIUM, HIGH,ARTEF SUP
Smooth
Makes the flow
representation
homogenous
Rotate Swheel to SMOOTH and press S button
Rotate Swheel to adjust
Range: LOW, HIGH
PW Doppler
PW Doppler audio volume can be decreased or increased by pressing or .
Items in table are not arranged sequentially
To Adjust / Control Do This
Engage PW Doppler Press UPDATE/LINE to activate cursor
Roll the trackball to position cursor
Press the PW control to activate
Auto-Doppler Optimization
Press AUTO
ADM
Automatic Doppler Trace
Rotate Swheel to ADM and press S button
Note: These calculations will not be sent to the report.
B-Ref
Alternates between split
screen or full screen in
PW
Rotate Swheel to B-REF and press S button
Velocity (PRF/Scale) Rotate Swheel to VELOCITY and press S button
Rotate Swheel to adjust
Baseline Rotate Swheel to BASEL and press S button

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 9
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Rotate Swheel to change
SV Size (Gate) Rotate Swheel to SV SIZE and press S button
Rotate Swheel to adjust
ΘAngle Rotate Swheel to ΘANGLE and press S button
Rotate Swheel to adjust
D-Steer Rotate Swheel to D-STEER and press S button
Rotate Swheel to adjust
Color ROI and PW cursor will steer together
Invert (Reverse) Rotate Swheel to REVERSE and press S button
Triplex (PLEX) Rotate Swheel to PLEX and press S button
Frequency Rotate Swheel to FREQUENCY, press S button
Rotate Swheel to adjust
Format Rotate Swheel to B FORMAT and press S button
Rotate Swheel to adjust
Range: SMALL, MEDIUM, LARGE, and DUAL
Dynamic Range
Adjusts grayscale levels
Rotate Swheel to DYN RANGE and press Sbutton
Rotate Swheel to adjust
Gray Maps
Post processing curve
that assigns echo
amplitudes to grayscale
levels
Rotate Swheel to GRAY MAP and press S button
Rotate Swheel to adjust
Range: 1-5
Colorize (Tint)
Sets the chromatic scale
active in PW
Rotate Swheel to COLORIZE and press S button
Rotate Swheel to adjust
Range: Off(-), Orange, Indigo, Magenta, Blue, Yellow,
RGB
Filter
Filters Doppler signal
Rotate Swheel to FILTER and press S button
Rotate Swheel to adjust
Reject
Improves spectral curve
display
Rotate Swheel to REJECT and press S button
Rotate Swheel to adjust
Sweep Rotate Swheel to SWEEP and press S button
Rotate Swheel to adjust

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 10
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
CW Doppler
(Phased array transducers only)
CW Doppler audio volume can be decreased or increased by pressing or .
Items in table are not arranged sequentially
To Adjust / Control Do This
Engage CW Doppler Press UPDATE/LINE to activate cursor
Roll the trackball to position cursor
Press the CW control to activate
Auto-Doppler Optimization
Press AUTO
B-Ref
Alternates between split
screen or full screen in
CW
Rotate Swheel to B-REF and press S button
Velocity (PRF/Scale) Rotate Swheel to VELOCITY and press S button
Rotate Swheel to adjust
Baseline Rotate Swheel to BASEL and press S button
Rotate Swheel to change
Invert (Reverse) Rotate Swheel to REVERSE and press S button
Frequency Rotate Swheel to FREQUENCY, press S button
Rotate Swheel to adjust
Format Rotate Swheel to B FORMAT and press S button
Rotate Swheel to adjust
Range: SMALL, MEDIUM, LARGE, and DUAL
Dynamic Range
Adjusts grayscale levels
Rotate Swheel to DYN RANGE and press Sbutton
Rotate Swheel to adjust
Gray Maps
Post processing curve
that assigns echo
amplitudes to grayscale
Rotate Swheel to GRAY MAP and press S button
Rotate Swheel to adjust
Range: 1-5

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 11
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
levels
Colorize (Tint)
Sets the chromatic scale
active in CW
Rotate Swheel to COLORIZE and press S button
Rotate Swheel to adjust
Range: Off(-), Orange, Indigo, Magenta, Blue, Yellow,
RGB
Filter
Filters Doppler signal
Rotate Swheel to FILTER and press S button
Rotate Swheel to adjust
Reject
Improves spectral curve
display
Rotate Swheel to REJECT and press S button
Rotate Swheel to adjust
Sweep Rotate Swheel to SWEEP and press S button
Rotate Swheel to adjust
M-mode
Items in table are not arranged sequentially
To Adjust / Control Do This
Engage M-mode Press M-MODE
Overall Gain
Rotate AUTO/GAIN wheel
B-Ref
Alternates between split
screen or full screen in M -
mode
Rotate Swheel to B-REF and press S button
Gray Maps
Applies a post processing
curve that assigns echo
amplitudes to grayscale
levels
Rotate Swheel to GRAY MAP and press S button
Rotate Swheel to adjust
Colorize (Tint)
Sets the chromatic scale
active in M-mode
Rotate Swheel to COLORIZE and press S button
Rotate Swheel to adjust
Range: Off(-), Orange, Indigo, Magenta, Blue, Yellow,
RGB

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 12
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Sharpness
Accentuates the edges
and the small differences
in M-mode
Rotate Swheel to SHARPNESS and press S button
Rotate Swheel to adjust
Range: 1-5
Sweep Rotate Swheel to SWEEP and press S button
Rotate Swheel to adjust
Triplex (PLEX) Rotate Swheel to PLEX and press S button
Frequency Rotate Swheel to FREQUENCY and press S button
Rotate Swheel to adjust
Format Rotate Swheel to B FORMAT and press S button
Rotate Swheel to adjust
Range: SMALL, MEDIUM, LARGE, and DUAL
Dynamic Range
Adjusts grayscale levels
Rotate Swheel to DYN RANGE and press Sbutton
Rotate Swheel to adjust
Performing Measurements and Calculations
Measurements can be made on frozen, stored and archived images.
Labeled Measurements
Generic Measurements
Activate Calculations
Press MEASURE (Label) to activate the labeled measurement function on frozen 2D,
Color, PW or M-mode images
or
Press to go to generic measurements
Perform a Generic Measurement
Freeze image
Press
Select desired generic measurement and press Right Select
Place the first caliper and press Right Select
Place second caliper and press Right Select

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 13
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Move between active calipers (yellow) by pressing ACTION
Rotate Swheel and press S button for these options:
ADD TO RP adds a generic measurement to the report; user has the option to label
CLEAR
CLEAR ALL
Perform a Labeled Measurement
Application-specific measurements are particular to one study type
The measurement tools and labels are organized by the active imaging mode and
application (e.g., abdomen)
Freeze image
Press MEASURE
Select desired labeled measurement and press Right Select
Place the first caliper and press Right Select
Place second caliper and press Right Select
Move between active calipers (yellow) by pressing ACTION
The system automatically cascades to the next labeled measurement
Selective Deletion of a Measurement
Press POINTER
Position the arrow on the caliper to be deleted (yellow)
Rotate Swheel to CLEAR and press S button to delete measurement
Calculation Reports
Report
Calculation worksheets and reports are offered for each preset when labeled or generic
measurements are entered
Note: Application-specific reports are particular to one study type. Different report
options will be available within each application (e.g., OB).
Press REPORT to activate Reports
Rotate Swheel and press S button for the following options:

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 14
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
PREVIEW to preview printed report
PAGE to scroll between report pages
MEASURE to scroll between measurements within one page
CONFIG to configure descriptions and labels within current report only
To delete measurements within the report, scroll to desired measurement (measurement
will be framed in yellow), rotate Swheel to CLEAR and press S button
To hide measurements from the printed report, scroll to the desired measurement and
press the Right Select. The measurement will now be highlighted in black
To access descriptor drop-down menus, scroll to drop-down menu and make selection
To add free text to a report, scroll to text box and type desired text
Import Images into the Report
From live imaging screen, Press EXAM/REV
Scroll to thumbnails on the right hand side of the screen
Press the Right Select on desired image
Rotate Swheel to ATTACH and press the S button
An “A” will display in the lower left hand corner
Delete Images from the Report
Press REPORT
Rotate Swheel to PAGE and press the S button
Rotate until attached images are displayed
Scroll trackball to desired image and press the Right Select, image will be framed in red
Rotate Swheel to DELETE and press S button
Text and Pictograms
Text and Pictograms can be entered on both real-time and archived images/clips.
Enter Text
Press any alphanumeric key on the QWERTY keyboard to begin inputting text
Type the annotation and press the Right Select to set (white) or press Enter to auto-
complete when desired word is displayed
or
Press OPTIONS and select ANNOTATIONS
A pre-defined set of annotations will appear

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 15
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Roll the trackball to scroll through the annotations
Press Right Select to set
Move text
Press any alphanumeric key on the QWERTY keyboard to activate the cursor
Roll the trackball to place the cursor within the text, press Right Select
Press ACTION , text will now be framed in yellow
Roll the trackball to the new location
Press Right Select to set
Delete Text
Press any alphanumeric key on the QWERTY keyboard to activate the cursor
Roll the trackball to place the cursor within the text
Press Right Select within the annotation (yellow)
Rotate Swheel to CLEAR or CLEAR ALL and press the S button
Place an Arrow/s
Press any alphanumeric key on the QWERTY keyboard to activate text menu
Rotate Swheel to ARROW and press the S button
Rotate Swheel to rotate arrow
Roll the trackball to desired location and press the Right Select to anchor (green)
Delete an Arrow/s
Rotate Swheel to CLEAR ALL and press the S button
Add a Pictogram/s
Press MARK
Arrow is active on the trackball
Rotate the arrow by rotating Swheel to ARROW, press the S button
To select a different pictogram, rotate Swheel to MARK and press the S button
Rotate Swheel until desired pictogram is displayed
Delete a Pictogram
If necessary, press MARK
Rotate Swheel to CLEAR and press the S button

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 16
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Data and image Management
Local Storage CD/DVD USB Review
CD/DVD Archive
User has the option to make patient exams anonymous during export procedures.
End an Exam
Press START/END
Select desired image archive/transfer/export
Select OK
Transferring Exams at the End of Exam
The following format options are available:
ACUSON P300 (native) format
BMP, PNG, JPEG and AVI
DICOM
Make selection by using the trackball and Right Select
or
Rotate the Swheel and press the S button

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 17
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Press START/END
Insert a CD/DVD or a USB
ARCHIVE
Selecting this option will transfer exams in native (ACUSON P300) format
Note: User must select this option to transfer to or view exams on the ACUSON P300
system.
EXPORT
Selecting this option will transfer images in PC format
DICOM
Selecting this option will transfer images in DICOM format, along with a DICOM viewer
The following options are also available:
ANONYMIZE
SEND REPORT
Transferring Exams/Images from Exam Review or Archive Review
Transferring images and/or exams can be done during live scanning or from the patient
archive
From Exam Review (USB only)
Transferring images and/or exams from the Exam Review screen will be done in PC
format
Press EXAM/REV
Insert USB
Select the desired images(s) by scrolling to thumbnail(s)
Place a checkmark in the upper left corner of the thumbnail to export
Note: Images/clips framed in green will also be exported.
Scroll to EXPORT and press the Right Select
Select OK
To confirm image/clip copy completion, select USB at the top of the image screen
From Archive Review
Press ARCHIVE/REV
Insert a CD/DVD or a USB
Highlight patient(s)
For multiple patients, press Shift or Ctrl on the QWERTY keyboard

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 18
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Make selection of the following format options:
COPY
Selecting this option will transfer images/clips in native (ACUSON P300) format
Note: User must select this option to transfer or view images/clips on the ACUSON
P300 system.
DICOM
Selecting this option will transfer images/clips in DICOM format, along with a DICOM
viewer
EXPORT
Selecting this option will transfer images/clips in PC format
Transferring Exam to PACS
Press ARCHIVE/REV
Highlight patient(s)
Select DICOM
Select DESTINATION
Select OK
Delete Images from an Active Exam
Press EXAM/REV
Select the desired images/clips to delete by scrolling to thumbnail(s) and placing a
checkmark in the upper left corner
Rotate S wheel to DELETE and press Sbutton
Select YES
Delete Exams from Local Archive
Press ARCHIVE/REV
Highlight patient(s)
Rotate S wheel to DELETE and press Sbutton
Select YES

ACUSON P300™ Ultrasound System Quick Reference Guide
Page | 19
© Siemens 2012. All rights reserved.
*The ACUSON P300 System is not commercially available.
Due to regulatory reasons its future availability cannot be guaranteed.
Import Exams from a CD/DVD or USB to the Local Database
Note: Only studies saved in ACUSON P300 (native) format are available for importing to
the system.
Insert the CD/DVD or USB
Press ARCHIVE/REV
Select USB ARCHIVE or CD/DVD Archive located at the top right of the
imaging screen
Highlight the patient(s) to import
Rotate S wheel to COPY and press Sbutton
Select OK
