Siemens Simatic RF600 Instruction sheet

___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SIMATIC Ident
RFID systems
SIMATIC RF600
Configuration Manual
11/2018
C79000
-G8976-C386-07
Introduction
1
Security recommendations
2
Description
3
Commissioning
4
Configuration via STEP 7
(PROFINET device)
5
Configuring with Studio 5000
Logix Designer
6
Configuring with the WBM
7
Programming via SIMATIC
controller
8
Programming via Rockwell
controller
9
Programming via XML
interface
10
Programming via the OPC
UA interface
11
Application examples
12
Service and maintenance
13
Appendix
A

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
Ⓟ
10/2018 Subject to change
Copyright © Siemens AG 2014 - 2018.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIMATIC RF600
Configuration Manual, 11/2018, C79000-G8976-C386-07 3
Table of contents
1 Introduction............................................................................................................................................. 7
2 Security recommendations...................................................................................................................... 9
3 Description............................................................................................................................................ 13
3.1 Properties of the UHF readers................................................................................................13
3.2 User-specific procedures ........................................................................................................17
4 Commissioning ..................................................................................................................................... 21
4.1 Important notes on using the device.......................................................................................21
4.2 Connect the hardware.............................................................................................................22
4.3 Setup/network topology ..........................................................................................................25
4.4 Assign the IP address / device name .....................................................................................26
4.4.1 Assigning the IP address / device name with the PST ...........................................................27
4.4.2 Assigning the IP address / device name with STEP 7............................................................29
4.4.3 Assigning an IP address via DHCP ........................................................................................31
5 Configuration via STEP 7 (PROFINET device) ...................................................................................... 33
5.1 Linking readers into STEP 7 (Basic / Professional)................................................................33
5.2 Creating a STEP 7 project (Basic / Professional)...................................................................33
5.3 Overview of the configurable properties .................................................................................34
6 Configuring with Studio 5000 Logix Designer ........................................................................................ 37
6.1 Configuring with Studio 5000 Logix Designer.........................................................................37
6.2 Linking readers into Studio 5000 Logix Designer ...................................................................37
6.3 Creating a Studio 5000 Logix Designer project ......................................................................38
7 Configuring with the WBM..................................................................................................................... 39
7.1 Starting WBM..........................................................................................................................39
7.2 The WBM ................................................................................................................................41
7.3 The menu items of the WBM ..................................................................................................46
7.3.1 The "Start page" menu item....................................................................................................46
7.3.2 The "Settings - General" menu item .......................................................................................48
7.3.3 The "Settings - Read points" menu item.................................................................................52
7.3.4 The "Settings - Tag fields" menu item ....................................................................................63
7.3.5 The "Settings - Filters" menu item ..........................................................................................66
7.3.6 The "Settings - Digital outputs" menu item .............................................................................69
7.3.7 The "Settings - Communication" menu item...........................................................................71
7.3.8 The "Settings - Adjust antenna" menu item ............................................................................80
7.3.9 The "Settings - Activation power" menu item..........................................................................83
7.3.10 The "Diagnostics - Tag monitor" menu item ...........................................................................87
7.3.11 The "Diagnostics - Log" menu item ........................................................................................91

Table of contents
SIMATIC RF600
4Configuration Manual, 11/2018, C79000-G8976-C386-07
7.3.12 The "Diagnostics - Messages" menu item ............................................................................. 93
7.3.13 The "Edit transponder" menu item ......................................................................................... 93
7.3.14 The "User management" menu item...................................................................................... 98
7.3.15 The "System" menu item ..................................................................................................... 102
7.3.16 The "Help" menu item .......................................................................................................... 103
8 Programming via SIMATIC controller ...................................................................................................105
8.1 Digital inputs/outputs............................................................................................................ 105
9 Programming via Rockwell controller....................................................................................................107
9.1 Importing add-on instructions............................................................................................... 107
9.2 Overview of the add-on instructions..................................................................................... 108
9.3 Project preparation............................................................................................................... 109
9.3.1 Assigning parameters to the "Param_RF68xR" block ......................................................... 109
9.3.2 Assigning parameters to the "Param_RF68xR" block ......................................................... 110
9.4 General structure of the add-on instructions........................................................................ 112
9.5 Programming add-on instructions........................................................................................ 113
9.5.1 Basic blocks ......................................................................................................................... 113
9.5.1.1 Param_RF68xR.................................................................................................................... 113
9.5.1.2 Reset_RF68xR..................................................................................................................... 114
9.5.1.3 Read..................................................................................................................................... 115
9.5.1.4 Write..................................................................................................................................... 116
9.5.1.5 Reader_Status ..................................................................................................................... 117
9.5.2 Extended blocks................................................................................................................... 118
9.5.2.1 Config_Upload/-_Download ................................................................................................. 118
9.5.2.2 Inventory .............................................................................................................................. 120
9.5.2.3 Read_EPC_Mem.................................................................................................................. 123
9.5.2.4 Set_Param ........................................................................................................................... 124
9.5.2.5 Write_EPC_ID ...................................................................................................................... 127
9.5.2.6 Write_EPC_Mem.................................................................................................................. 128
9.5.2.7 AdvancedCMD ..................................................................................................................... 129
9.6 Programming the Ident profile.............................................................................................. 130
9.6.1 Structure of the Ident profile................................................................................................. 130
9.6.2 Overview of the commands ................................................................................................. 132
9.6.3 Command structure ............................................................................................................. 133
9.6.4 Commands........................................................................................................................... 134
9.6.5 Chaining ............................................................................................................................... 135
9.6.6 Command repetition............................................................................................................. 135
9.7 Digital inputs/outputs............................................................................................................ 135
10 Programming via XML interface ...........................................................................................................137
10.1 Functionality of the XML interface........................................................................................ 137
10.2 Demo application ................................................................................................................. 139
10.2.1 Structure of the demo application ........................................................................................ 139
10.2.2 User interface of the demo application ................................................................................ 140
10.2.3 Working with the demo application ...................................................................................... 142
10.3 XML commands ................................................................................................................... 143
10.3.1 Connections ......................................................................................................................... 144

Table of contents
SIMATIC RF600
Configuration Manual, 11/2018, C79000-G8976-C386-07 5
10.3.1.1 hostGreetings........................................................................................................................145
10.3.1.2 hostGoodbye.........................................................................................................................146
10.3.1.3 heartBeat ..............................................................................................................................147
10.3.1.4 setIPConfig ...........................................................................................................................148
10.3.1.5 getIPConfig ...........................................................................................................................149
10.3.2 Reader settings.....................................................................................................................150
10.3.2.1 setConfiguration....................................................................................................................150
10.3.2.2 getConfiguration....................................................................................................................152
10.3.2.3 getConfigVersion ..................................................................................................................153
10.3.2.4 getActiveConfiguration..........................................................................................................154
10.3.2.5 getLogfile ..............................................................................................................................155
10.3.2.6 resetLogfile ...........................................................................................................................156
10.3.2.7 setParameter ........................................................................................................................157
10.3.2.8 getParameter ........................................................................................................................159
10.3.2.9 setTime .................................................................................................................................161
10.3.2.10 getTime .................................................................................................................................162
10.3.2.11 setIO......................................................................................................................................163
10.3.2.12 getIO .....................................................................................................................................164
10.3.2.13 resetReader ..........................................................................................................................166
10.3.2.14 getReaderStatus ...................................................................................................................168
10.3.2.15 getAllSources........................................................................................................................169
10.3.2.16 getAntennas..........................................................................................................................170
10.3.3 Transponder processing .......................................................................................................
172
10.3.3.1 editBlackList..........................................................................................................................172
10.3.3.2 getBlackList...........................................................................................................................174
10.3.3.3 triggerSource ........................................................................................................................175
10.3.3.4 readTagIDs ...........................................................................................................................177
10.3.3.5 getObservedTagIDs..............................................................................................................180
10.3.3.6 writeTagID.............................................................................................................................183
10.3.3.7 readTagMemory....................................................................................................................187
10.3.3.8 writeTagMemory ...................................................................................................................191
10.3.3.9 readTagField.........................................................................................................................195
10.3.3.10 writeTagField ........................................................................................................................200
10.3.3.11 killTag....................................................................................................................................204
10.3.3.12 lockTagBank .........................................................................................................................207
10.3.4 Negative XML replies............................................................................................................213
10.4 XML EventReports................................................................................................................215
10.4.1 Events ...................................................................................................................................215
10.4.1.1 tagEventReport .....................................................................................................................215
10.4.1.2 rssiEventReport ....................................................................................................................220
10.4.1.3 ioEventReport .......................................................................................................................221
10.4.2 Interrupts...............................................................................................................................223
11 Programming via the OPC UA interface .............................................................................................. 227
12 Application examples .......................................................................................................................... 231
12.1 Minimizing radiated power ....................................................................................................231
12.2 Initiating trigger through light barrier .....................................................................................233
12.3 Filtering out transponders detected due to overshoot ..........................................................235
12.4 Filtering out transponders using the "Black list" ...................................................................237

Table of contents
SIMATIC RF600
6Configuration Manual, 11/2018, C79000-G8976-C386-07
13 Service and maintenance.....................................................................................................................239
13.1 Diagnostics........................................................................................................................... 239
13.1.1 Diagnostics via the LED displays......................................................................................... 240
13.1.2 Diagnostics via LED display elements................................................................................. 242
13.1.3 Diagnostics via SNMP ......................................................................................................... 243
13.1.4 Diagnostics using the WBM ................................................................................................. 243
13.1.5 Diagnostics using the TIA Portal (STEP 7 Basic / Professional) ......................................... 244
13.1.6 Diagnostics using Studio 5000 Logix Designer ................................................................... 246
13.2 Error messages.................................................................................................................... 246
13.2.1 How the LED status display works....................................................................................... 246
13.2.2 XML/PLC error messages.................................................................................................... 247
13.2.3 OPC UA error messages ..................................................................................................... 253
13.3 Module replacement ............................................................................................................ 257
13.3.1 Backup configuration data ................................................................................................... 257
13.3.2 Replacing a module ............................................................................................................. 260
13.4 Firmware update .................................................................................................................. 261
13.5 Factory settings.................................................................................................................... 262
A Appendix .............................................................................................................................................265
A.1 Planning and installation of UHF read points....................................................................... 265
A.1.1 Technical basics................................................................................................................... 265
A.1.2 Implementation of UHF RFID installations........................................................................... 268
A.1.2.1 Preparation phase................................................................................................................ 268
A.1.2.2 Test phase ........................................................................................................................... 269
A.1.2.3 Setting up read points .......................................................................................................... 269
A.1.3 Dealing with field disturbances ............................................................................................ 273
A.1.3.1 Types and approaches to solutions ..................................................................................... 273
A.1.3.2 Measures for eliminating field disturbances......................................................................... 274
A.2 Command and acknowledgement frames ........................................................................... 276
A.2.1 General structure of the adapted commend frame .............................................................. 276
A.2.2 READER-STATUS or DEV-STATUS................................................................................... 277
A.2.3 INVENTORY ........................................................................................................................ 278
A.2.4 PHYSICAL-READ ................................................................................................................ 279
A.2.5 PHYSICAL-WRITE............................................................................................................... 280
A.2.6 WRITE-ID............................................................................................................................. 281
A.2.7 KILL-TAG ............................................................................................................................. 282
A.2.8 LOCK-TAG-BANK................................................................................................................ 283
A.2.9 EDIT-BLACKLIST ................................................................................................................ 284
A.2.10 GET-BLACKLIST ................................................................................................................. 285
A.2.11 READ-CONFIG.................................................................................................................... 286
A.2.12 WRITE-CONFIG .................................................................................................................. 287
A.3 List of the country profiles (approvals)................................................................................. 289
A.4 Service & Support ................................................................................................................ 293

SIMATIC RF600
Configuration Manual, 11/2018, C79000-G8976-C386-07 7
Introduction
1
Purpose of this document
This manual contains all the information required for the parameter assignment and
commissioning of the SIMATIC RF615R, RF650R, RF680R and RF685R readers of the
SIMATIC RF600 system.
This manual is intended for:
●Commissioning engineers
●Configuration engineers
●Service technicians
Scope of validity of this document
This documentation is valid for all supplied versions of the SIMATIC
RF615R/RF650R/RF680R/RF685R readers and describes the delivery state as of 11/2018
and firmware version V3.1 or V3.2 for RF615R.
Registered trademarks
SIMATIC ®, SIMATIC RF ®, MOBY ®, RF MANAGER ® and SIMATIC Sensors ® are registered
trademarks of Siemens AG.
Documentation classification
You will find additional information on the properties, technical specifications and possible
applications of the RF600 readers in the "SIMATIC RF600 System Manual
(https://support.industry.siemens.com/cs/ww/en/view/22437600)".
You will find more information on operating the readers via communications modules
(PROFIBUS operation) in the manuals of the relevant communications module
(https://support.industry.siemens.com/cs/ww/en/ps/15105/man).
You will find further information on the Ident profile and Ident blocks based on the "Proxy
Ident Function Block" protocol and described in this manual in the manual "Ident profile and
Ident blocks, standard function for Ident systems
(https://support.industry.siemens.com/cs/ww/en/ps/14971/man)".
For S7 programmers who create their own command and acknowledgment frames, the
communications rules and frames that are required can be found in the Appendix in the
section "Command and acknowledgement frames (Page 276)". XML programmers will find
the required communications rules and frames in the section "Programming via XML
interface (Page 137)".

Introduction
SIMATIC RF600
8Configuration Manual, 11/2018, C79000-G8976-C386-07
History
The following edition(s) of the configuration manual have been published up to now:
Edition
Note
10/2014
First edition
07/2015 Revised and expanded edition
Expansion of the documentation by the following:
•PROFIBUS connection
•MRP and SNMP capability
•Capability of processing transponders of the ISO 18000-62 standard
10/2015
Revised and expanded edition
01/2016 Revised and expanded edition
10/2016 Revised and expanded edition
Expansion of the documentation by the following:
•New functions of the WBM V3.0
•Functions for Rockwell controllers
•OPC UA interface
•Ethernet/IP interface
02/2018 Revised and expanded edition
Expansion of the documentation by the following:
•New functions of WBM V3.1
11/2018 Revised and expanded edition
Expansion of the documentation by the following:
•SIMATIC RF615R
Abbreviations and naming conventions
The following terms/abbreviations are used synonymously in this document:
Reader
Write/read device (SLG)
Transponder, tag
Data carrier, mobile data storage, (MDS)
Communications module (CM)
Interface module (ASM)

SIMATIC RF600
Configuration Manual, 11/2018, C79000-G8976-C386-07 9
Security recommendations
2
To prevent unauthorized access, observe the following security recommendations when
working with the reader and WBM (Web Based Management).
General
●Check regularly that the device complies with these recommendations and/or other
internal security policies.
●Evaluate your plant as a whole in terms of security. Use a cell protection concept with
suitable products.
●Do not connect the device directly to the Internet. Operate the device within a protected
network area.
Physical access
●Restrict physical access to the device to qualified personnel.
●Lock unused physical ports (e.g. Ethernet ports) on the device. Unused ports can be used
to access the system without authorization.
Software (security functions)
●Keep the software up to date. Keep yourself informed regularly about safety updates for
the product.
You can find additional information about this at the following link
(http://www.siemens.com/industrialsecurity).
●Activate only protocols that you actually need to use the device.
●Limit access to the device using a firewall or rules in an access control list (ACL).
●The configuration files are available in XML format for simple use. Make sure that the
configuration files outside the device are suitably protected. You can, for example,
encrypt the files, store them at a safe location and transfer them only via secure
communications channels.
Passwords
●Activate user management and create new user profiles.
●Change all default passwords for users before operating the device.
●Only use passwords with high password strength. Avoid weak passwords, e.g.
password1, 123456789, abcdefgh.
●Define rules for using devices and assigning passwords.
●Make sure that all passwords are protected and inaccessible to unauthorized personnel.

Security recommendations
SIMATIC RF600
10 Configuration Manual, 11/2018, C79000-G8976-C386-07
●Do not use the same password for different users and systems.
●Update passwords and keys regularly to improve security.
Keys and certificates
This section deals with the security keys and certificates that you need to set up SSL.
●We urgently recommend creating your own SSL certificates and making them available.
Preset certificates and keys are present in the device.
The preset and automatically created SSL certificates are self-signed. We recommend
using certificates signed either by a reliable external certification authority or an internal
certification authority.
The device has an interface via which you can import certificates and keys.
●We recommend using certificates with a key length of at least 2048 bits.
●If protocols support both certificates and keys, you should favor certificates.
Firmware encryption
The firmware itself is signed and encrypted. This ensures that only authentic firmware can be
downloaded to the device.
Secure/non-secure protocols
●Check whether it is necessary to use SNMPv1. SNMPv1 is classified as non-secure.
Make use of the possibility to prevent write access. The product offers corresponding
settings for this.
●If SNMP is activated, change the community names. If unrestricted access is not
necessary, limit access via SNMP.
●Use secure protocols if access to the device is not protected by means of physical
safeguards.
The following protocols provide secure alternatives:
HTTP → HTTPS
●To prevent unauthorized access to the device or network, set up appropriate safeguards
against non-secure protocols.
●Enable only the services (protocols) that will actually be used on the device. The same
applies to the installed interfaces/ports. Unused ports could be used to access the
network downstream from the device.

Security recommendations
SIMATIC RF600
Configuration Manual, 11/2018, C79000-G8976-C386-07 11
List of available protocols
All available protocols and their ports that are used with SIMATIC RF600 readers are listed
below.
Table 2- 1 List of available protocols
Protocol
Port number
Default port
status
Port configura-
ble
Authentication
Encryption
SSH
(OEM only)
TCP/22 Open -- Yes Yes
XML service TCP/10001 Open -- No No
DHCP
UDP/68
Closed
✓
No
No
PROFINET UDP/34964
UDP/49152-65535
Open ✓No No
HTTP
TCP/80
Open
--
No
No
HTTPS
TCP/443
Closed
✓
Yes
Yes
NTP
UDP/123
Closed
✓
No
No
SNMP
UDP/161
Closed
✓
No
No
OPC UA TCP/4840 Open ✓Yes (simple,
when config-
ured)
No
Ethernet/IP TCP/44818
UDP/44818
UDP/2222
Open ✓No No
Explanation of the table:
●Authentication
Specifies whether authentication of the communication partner takes place.
●Encryption
Specifies whether the transfer is encrypted.

Security recommendations
SIMATIC RF600
12 Configuration Manual, 11/2018, C79000-G8976-C386-07
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be
connected to an enterprise network or the internet if and to the extent such a connection is
necessary and only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit
Link: (http://www.siemens.com/industrialsecurity)
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers’ exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
Link: (http://www.siemens.com/industrialsecurity)

SIMATIC RF600
Configuration Manual, 11/2018, C79000-G8976-C386-07 13
Description
3
3.1
Properties of the UHF readers
Area of application
The readers of the SIMATIC RF600 product family are designed for use in logistics and in
automation. The RF615R, RF680R and RF685R readers are specifically intended for use in
automation environments, for example on a production line, but are equally suitable for
applications in logistics. To meet these requirements, the readers were equipped with a high
transmit power and degree of protection (IP65). For applications in logistics with less
demanding requirements relating to the protection class and transmit power, the RF650R
reader is a cost-effective alternative. All readers are equipped with extensive diagnostics
options and can process ISO 18000-62 and ISO 18000-63 transponders.
The RF685R has one special feature with its internal, adaptive antenna - just as with the
antenna RF680A. This significantly increases the reliability of read and write actions even
under difficult radio conditions.
The RF615R reader is characterized by a very compact design - with reduced transmit
power - as well as an internal antenna.
The RF680R and RF685R readers are either integrated without problems in SIMATIC S7
automation systems via an integrated PROFINET connector or via the RS-422 interface and
the ASM 456 communications module via PROFIBUS. Suitable programming blocks are
available. The connection to PC environments and Rockwell controllers is via Ethernet using
TCP/IP and the XML protocol, OPC UA or Ethernet/IP. A second Ethernet interface (both
M12) can be used for diagnostics during operation so that the connection to the higher-level
system does not need to be interrupted. Alternatively, the second Ethernet interface can be
used for PROFINET line/ring topologies.
The RF650R has one Ethernet interface (RJ-45). This is used both to connect to PC systems
as well as for configuration and diagnostics and it can also be used during operation. Higher-
level software communicates with the reader using TCP/IP, the XML protocol or OPC UA.
The RF615R reader is connected to SIMATIC S7 automation systems or PC systems via
PROFINET, XML protocol or OPC UA.
The WBM (Web Based Management) allows commissioning, configuration and diagnostics
of all three devices using an Internet browser. This makes additional updates and installation
of configuration and diagnostics software unnecessary.

Description
3.1 Properties of the UHF readers
SIMATIC RF600
14 Configuration Manual, 11/2018, C79000-G8976-C386-07
Characteristics
The following features characterize the RF600 readers:
Table 3- 1 Characteristics of the readers
Characteristics
RF615R
RF650R
RF680R
RF685R
Antennas 1 x internal anten-
na
1 x external an-
tenna connector
4 x external antenna connectors 1 x internal, adap-
tive antenna
1 x external an-
tenna connector
Transmit power
(max.)
1)
400 mW 1000 mW 2000 mW
Digital inputs/
outputs
1x DI/DQ 4x DI and 4x DQ
RS-422 interface 1x socket,
M12 (8-pin)
-- 1x socket, M12 (8-pin)
PROFIBUS con-
nection
via CM
-- ASM 456
(115.2 kbps)
Ethernet interface 1 x Industrial
Ethernet, M12
1 x Industrial
Ethernet, RJ-45
2 x Industrial Ethernet, M12
Transmission
speed (max.)
100 Mbps
Degree of protec-
tion
IP65 IP30 IP65
Configura-
tion/diagnostics
options
WBM (browser)
STEP 7 (S7)
WBM (browser) WBM (browser)
STEP 7 (S7)
Interfaces to
PC/controller
XML interface
SIMATIC interface
(OPC UA,
PROFINET-
capable)
XML interface
(TCP/IP with XML
protocol, OPC UA)
XML interface
SIMATIC interface
(TCP/IP with XML protocol, OPC UA,
Ethernet/IP or PROFINET capability)
1) The maximum transmit power is restricted depending on the country of use.
NOTICE
IRT is not supported
Note that the RF615R/RF680R/RF685R readers do not support IRT (Isochronous Real
Time). The readers can also not function as IRT conductors (e.g. in a bus structure).
The readers can be configured as clients in MRP rings. Network diagnostics via SNMP is
supported by the readers.

Description
3.1 Properties of the UHF readers
SIMATIC RF600
Configuration Manual, 11/2018, C79000-G8976-C386-07 15
NOTICE
Operation in VLANs
Note that the readers cannot be operated in VLANs whose ID is ≠ 0.
Certificates
RF600 readers support the following certificates and approvals:
●RF615R certificates (https://support.industry.siemens.com/cs/ww/en/ps/25391/cert)
●RF650R certificates (https://support.industry.siemens.com/cs/ww/en/ps/15085/cert)
●RF680R/RF685R certificates
(https://support.industry.siemens.com/cs/ww/en/ps/15088/cert)
Integration
The following figures show examples of some of the of the integration options of the readers.
Note that, in all examples, the connection of the RF615R, RF680R and RF685R readers via
a SIMATIC controller can take place both via Industrial Ethernet / PROFINET and via
PROFIBUS.
Figure 3-1 RF650R reader in an IT environment
Figure 3-2 RF680R reader in an automation environment (PROFINET)

Description
3.1 Properties of the UHF readers
SIMATIC RF600
16 Configuration Manual, 11/2018, C79000-G8976-C386-07
Figure 3-3 RF680R reader in an automation environment (PROFIBUS)
Figure 3-4 RF685R in an IT environment, without external antenna
Figure 3-5 RF680R reader in an automation environment (PROFINET) with use of third-party
controller
All 3 readers can be integrated in an IT environment (XML, OPC UA). The RF68xR readers
can be integrated both in an IT and in an automation environment (S7).
The RF685R readers can also be operated without external antennas.

Description
3.2 User-specific procedures
SIMATIC RF600
Configuration Manual, 11/2018, C79000-G8976-C386-07 17
3.2
User-specific procedures
The readers of the SIMATIC RF600 product family are preconfigured when shipped and can
be put into operation without any further configuration. When shipped from the factory, the
readers are preconfigured as follows:
●First antenna connector occupied: RF650A
●Transmit power: 20 dBm
●IP address:
–RF650R: 192.168.0.254
–RF615R/RF680R/RF685R: DHCP
As described in the previous section, the RF600 readers are designed for different
environments and requirements.
If you operate the RF615R, RF680R and RF685R readers in an automation environment,
they are configured and programmed from the perspective of an S7 user. Integration in third-
party controllers (e.g. Rockwell controllers) is, of course, also possible. In this case the
configuration, engineering and programming is performed from the point of view of a
Rockwell user. If you operate the RF600 readers in an XML environment, they are
configured and programmed from the perspective of an XML user. If you operate the RF600
readers in an OPC UA environment, they are configured and programmed from the
perspective of an OPC UA user.
If you want to adapt the readers to your requirements, we recommend the following user-
specific procedure:
Procedure as S7 user
1. Connect the hardware
You will find information on this in the section "Connect the hardware (Page 22)".
2. Assign the IP address / device name
You will find information on this in the section "Assigning the IP address / device name
with the PST (Page 27)" or "Assigning the IP address / device name with STEP 7
(Page 29)".
3. Configure reader and if applicable communications module
You will find information on this in the sections "Configuration via STEP 7 (PROFINET
device) (Page 33)" and "Configuring with the WBM (Page 39)".
4. Configure / program reader commands
You will find information on this in the section "Programming via SIMATIC controller
(Page 105)".

Description
3.2 User-specific procedures
SIMATIC RF600
18 Configuration Manual, 11/2018, C79000-G8976-C386-07
Procedure as Rockwell user
1. Connect the hardware
You will find information on this in the section "Connect the hardware (Page 22)".
2. Assign the IP address / device name
You will find information on this in the section "Assigning the IP address / device name
with the PST (Page 27)" or "Assigning an IP address via DHCP (Page 31)".
3. Configure the reader
You will find information on this in the sections "Configuring with Studio 5000 Logix
Designer (Page 37)" and "Configuring with the WBM (Page 39)".
4. Configure / program reader commands
You will find information on this in the section "Programming via Rockwell controller
(Page 107)".
Procedure as XML user
1. Connect the hardware
You will find information on this in the section "Connect the hardware (Page 22)".
2. Assign the IP address / device name
You will find information on this in the section "Assigning the IP address / device name
with the PST (Page 27)".
3. Configure the reader
You will find information on this in the section "Configuring with the WBM (Page 39)".
4. Program reader commands
You will find information on this in the section "Programming via XML interface
(Page 137)".
Procedure as an OPC UA user
1. Connect the hardware
You will find information on this in the section "Connect the hardware (Page 22)".
2. Assign the IP address / device name
You will find information on this in the section "Assigning the IP address / device name
with the PST (Page 27)".
3. Configure the reader
You will find information on this in the section "Configuring with the WBM (Page 39)".
4. Program reader commands
You will find information on this in the section "Programming via the OPC UA interface
(Page 227)".

Description
3.2 User-specific procedures
SIMATIC RF600
Configuration Manual, 11/2018, C79000-G8976-C386-07 19
Note
Synchronize reader time of day
Note that the reader clock corresponds to UTC time and cannot be adapted to time zones.
You can, however, transfer
the local time of day stored in your operating system to the
reader. This time of day is retained on the reader for at least two days even without a power
supply. If the reader is disconnected from the power supply for a longer period, the time will
need
to be reset. This can be done manually via the WBM, using NTP or in a program.
Later in the document, these symbols will help your orientation and will show you whether
the section is of interest to you or not. Only the sections with user-specific content, in other
words content that is tool/interface-specific contain these symbols. Sections without these
symbols are general and relevant for both areas of application.

Description
3.2 User-specific procedures
SIMATIC RF600
20 Configuration Manual, 11/2018, C79000-G8976-C386-07
