Web server

SIMATIC
S7-1500, SIMATIC Drive Controller,
ET 200SP, ET 200pro
Web server
Function Manual
11/2019
A5E034846
25-AG
Preface
Function manuals
Documentation Guide
1
General information
2
Web pages
3

Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E03484625-AG
Ⓟ
10/2019 Subject to change
Copyright © Siemens AG 2012 - 2019.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Web server
Function Manual, 11/2019, A5E03484625-AG 3
Preface
Purpose of the documentation
This documentation supports you in the operation of the Web server.
The Web server offers, among other things, web page access to diagnostic data and to
process data of the CPU.
Basic knowledge required
The following knowledge is required in order to understand the documentation:
●General knowledge in the field of automation technology
●Knowledge of the SIMATIC industrial automation system
●Experience of working with Windows-based computers
●Knowledge about how to use STEP 7 (TIA Portal)
Scope of the documentation
This documentation is valid for CPUs as of firmware version V2.5 and contains illustrations
of the Web server user interface. The illustrations used can be transferred to the following
CPUs:
●The CPUs of the SIMATIC S7-1500 automation system
●The CPUs of the SIMATIC Drive controller
●The CPUs of the ET 200SP Distributed I/O System
●The CPUs 1516pro-2 PN and 1513pro-2 PN of the ET 200pro distributed I/O system
The displayed illustrations can differ from the interface of the Web server in some details,
e.g. depending on the browser used.

Preface
Web server
4Function Manual, 11/2019, A5E03484625-AG
What's new in the Web Server function manual, Version 11/2019 compared to Version 12/2017
What's new?
What are the customer benefits?
Where can I find information?
New contents The CPU has an API (Appli-
cation Programming Inter-
face) as an interface for:
•Reading and writing
CPU data
•Executing functions (e.g.
backing up and restoring
the CPU configuration,
changing the operating
state)
The Web API supports all
common browsers and
command line programs,
such as cURL and Wget.
•Established standard mechanisms for
creating Web pages:
Automation Web Programming com-
mands (AWP commands) are no long-
er required for output of CPU data
•No dependency between custom Web
pages and CPU program:
No synchronization between user pro-
gram and Web server required by the
SFC 99 instruction
•Lower communication load:
A smaller data packet is transferred
between server and client (JSON in-
stead of HTML of the custom Web
page generated by the CPU). This im-
proves the communication perfor-
mance. The CPU needs less runtime
to generate the information and make
it available.
•Secure data traffic:
the Web API only supports the trans-
mission protocol "HTTPS"
Section API (Application Pro-
gramming Interface) (Pa-
ge 158)
Changed
contents
Scope of the function man-
ual expanded to include the
CPUs of the SIMATIC Drive
Controller
Webserver functions which you are famil-
iar with from the CPUs of the SIMATIC
S7-1500 can now also be used on the
CPUs of the SIMATIC Drive Controller.
•System Manual SIMATIC
Drive Controller
(https://support.industry.sie
mens.com/cs/ww/en/view/1
09766665)
•Manual SIMATIC Drive
Controller
(https://support.industry.sie
mens.com/cs/ww/en/view/1
09766666)

Preface
Web server
Function Manual, 11/2019, A5E03484625-AG 5
What's new in the Web Server function manual, Version 12/2017 compared to Version 09/2016
What's new?
What are the customer benefits?
Where can I find the infor-
mation?
New contents New web page "User files" You can download ASCII files (files in
binary format) from the SIMATIC Memory
Card, directory UserFiles\ to the web page
and delete them.
Section User files (Page 115)
Time display as Coordinated
Universal Time (UTC) or as
PLC local time
The display of the UTC allows you to use
a uniform time for the web pages.
You can set the format of the time display
to Coordinated Universal Time (UTC) or
PLC local time (default setting).
Section Start page with general
CPU information (Page 33)
Automated downloading,
reading out and archiving of
DataLogs
You can, for example, read out and ar-
chive DataLogs daily from one or more
CPUs at a specific time via the Web serv-
er.
Automatic downloading of DataLogs is
realized either by the execution of scripts
in, for example, Bash or via JavaScript on
your HTML user page.
Section Automated reading out
of data logs (Page 113)
The “Permit access only
with HTTPS" check box is
activated in the default set-
ting of a configured CPU.
The web pages are transmitted by default
via a secure connection and are protected
from attacks by third parties.
Section Configuring the Web
server (Page 19)
Changed
contents
Web page "Module infor-
mation”: New column De-
vice number
You can read the assignment of the de-
vice number to the device name.
Section Module information
(Page 57)
Web page "Topology": Se-
lection of the available
PROFINET interfaces, for
example X1, X2, CM 1542-1
You can select the topology display for the
PROFINET interfaces X1, X2 and for
connected PROFINET communication
modules.
Section Topology (Page 72)
Web page "DataLogs": New
column for deleting DataLog
files
You can delete DataLog files via the Web
server.
Section DataLogs (Page 112)
Web page "Record":
Changes in the display of
Trace recordings
You can evaluate the Trace recordings in
more detail through the extension of the
display.
Section Record (Page 92)
Web page "Record": New
arithmetic functions
In the case of completed measurements
you can combine the measured signals
mathematically with each other and this
generate signals that were not recorded.
You can, for example, form the difference
of two signals in order to better display the
deviation of the current pressure of a boil-
er from the set setpoint value.

Preface
Web server
6Function Manual, 11/2019, A5E03484625-AG
What's new in the Web Server function manual, Version 09/2016 compared to Version 12/2014
What's new?
What are the customer benefits?
Where can I find the infor-
mation?
New contents Handling of certificate modi-
fied
You protect the web server connection
against tapping or distortion of the com-
munication through access via the secure
transmission protocol "HTTPS" including a
special web server certificate.
Section Configuring the Web
server (Page 19)
Four additional languages
for the Web server interface
You can set the Web server interface to
the following languages:
•Korean
•Russian
•Turkish
•Portuguese (Brazil)
Section Start page with general
CPU information (Page 33)
Assignment of different
project languages extended
You can assign up to three different pro-
ject languages for comments, alarm texts
and diagnostic information to the user
interface languages of the Web server.
Section Language settings
(Page 29)
"Start page" web page ex-
tended
The display of the TIA project name im-
mediately indicates whether the desired
project is selected.
Section Start page with general
CPU information (Page 33)
"Diagnostics" web page
extended by one tab:
•"Program protection"
•"Runtime information"
•"Fail-safe" (with an F-
CPU)
Here you can find information about:
•Know-how protection or copy protec-
tion of the PLC program
•Program/communication load and
cycle time
•F-collective signatures, cycle times
and runtimes of the F-runtime group(s)
Section Diagnostics (Page 38)
"Alarms" web page exten-
ded
You can acknowledge alarms of the CPU
via the Web server.
Section Alarms (Page 65)
"Tag status" and "Watch
tables" web pages extended
You can change the value of tags and
write them to the CPU, also using the
absolute address.
•Section Tag status
(Page 82)
•Section Watch tables (Pa-
ge 85)
New web page "Online
backup"
You can back up and restore the CPU
configuration to/from the SIMATIC
memory card via the Web server.
Section Online backup
(Page 87)
New "Motion Control diag-
nostics" web page
You can monitor statuses, errors, technol-
ogy alarms and the current values of con-
figured technology objects (TOs) with the
Web server without STEP 7.
Section Motion Control diag-
nostics (Page 49)
New "Record" web page You can read, view and save trace record-
ings via the Web server and thus obtain
plant and project information for diagnos-
tics and maintenance without STEP 7.
Section Record (Page 92)

Preface
Web server
Function Manual, 11/2019, A5E03484625-AG 7
What's new?
What are the customer benefits?
Where can I find the infor-
mation?
Changed
contents
Extension of the validity
range of the function manual
to the CPUs of the ET
200SP distributed I/O sys-
tem and the CPU 1516pro-2
PN
Functions that you will be familiar with
from the SIMATIC S7-1500 CPUs are
implemented in CPUs in other designs
(ET 200SP) and in the CPU 1516pro-2 PN
(degree of protection IP65, IP66 and
IP67).
•Manual CPU 1510SP-1 PN
(https://support.industry.sie
mens.com/cs/ww/en/view/9
0157130)
•Manual CPU 1512SP-1 PN
(https://support.industry.sie
mens.com/cs/ww/en/view/9
0157013)
•Operating instructions CPU
1516pro-2 PN
(https://support.industry.sie
mens.com/cs/ww/en/view/1
09482416)
Web page "Watch tables":
Note added on the maximum configuration limits.
Section Watch tables (Pa-
ge 85)
Web page "User pages":
Note added on the maximum size of the HTML pages.
Section User pages (Pa-
ge 120)
Conventions
In this documentation, "STEP 7" is used as a synonym for all versions of the configuration
and programming software "STEP 7 (TIA Portal)".
Please also observe notes marked as follows:
Note
A note contains important information on the product described in the documentation, on the
handling of the product and on
the section of the documentation to which particular attention
should be paid.

Preface
Web server
8Function Manual, 11/2019, A5E03484625-AG
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be
connected to an enterprise network or the internet if and to the extent such a connection is
necessary and only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit (https://www.siemens.com/industrialsecurity).
Siemens' products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers' exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed visit (https://www.siemens.com/industrialsecurity).
Siemens Industry Online Support
You can find current information on the following topics quickly and easily here:
●Product support
All the information and extensive know-how on your product, technical specifications,
FAQs, certificates, downloads, and manuals.
●Application examples
Tools and examples to solve your automation tasks – as well as function blocks,
performance information and videos.
●Services
Information about Industry Services, Field Services, Technical Support, spare parts and
training offers.
●Forums
For answers and solutions concerning automation technology.
●mySupport
Your personal working area in Industry Online Support for messages, support queries,
and configurable documents.
This information is provided by the Siemens Industry Online Support in the Internet
(http://www.siemens.com/automation/service&support).

Preface
Web server
Function Manual, 11/2019, A5E03484625-AG 9
Industry Mall
The Industry Mall is the catalog and order system of Siemens AG for automation and drive
solutions on the basis of Totally Integrated Automation (TIA) and Totally Integrated Power
(TIP).
Catalogs for all the products in automation and drives are available on the Internet
(https://mall.industry.siemens.com).

Web server
10 Function Manual, 11/2019, A5E03484625-AG
Table of contents
Preface ................................................................................................................................................... 3
1 Function manuals Documentation Guide............................................................................................... 12
2 General information .............................................................................................................................. 14
2.1 Properties of the Web server ................................................................................................. 14
2.2 Configuring the Web server ................................................................................................... 19
2.3 Language settings.................................................................................................................. 29
2.4 Updating and saving information ........................................................................................... 32
3 Web pages ........................................................................................................................................... 33
3.1 Start page with general CPU information .............................................................................. 33
3.2 Diagnostics............................................................................................................................. 38
3.3 Diagnostics buffer .................................................................................................................. 48
3.4 Motion Control diagnostics..................................................................................................... 49
3.5 Module information ................................................................................................................ 57
3.6 Firmware update .................................................................................................................... 62
3.7 Alarms .................................................................................................................................... 65
3.8 Communication ...................................................................................................................... 67
3.9 Topology ................................................................................................................................ 72
3.9.1 Introduction ............................................................................................................................ 72
3.9.2 Graphical view........................................................................................................................ 73
3.9.3 Tabular view........................................................................................................................... 76
3.9.4 Status overview...................................................................................................................... 78
3.9.5 Examples for graphical topology views.................................................................................. 79
3.10 Tag status .............................................................................................................................. 82
3.11 Watch tables .......................................................................................................................... 85
3.12 Online backup ........................................................................................................................ 87
3.13 Record.................................................................................................................................... 92
3.14 DataLogs.............................................................................................................................. 112
3.14.1 Automated reading out of DataLogs .................................................................................... 113
3.15 User files .............................................................................................................................. 115
3.15.1 Automatically read or upload user files................................................................................ 117

Table of contents
Web server
Function Manual, 11/2019, A5E03484625-AG 11
3.16 User pages............................................................................................................................120
3.16.1 AWP commands ...................................................................................................................124
3.16.1.1 PLC tags ...............................................................................................................................125
3.16.1.2 Special tags ..........................................................................................................................129
3.16.1.3 Enum types ...........................................................................................................................131
3.16.1.4 Fragments.............................................................................................................................133
3.16.1.5 Arrays....................................................................................................................................135
3.16.1.6 Structures..............................................................................................................................136
3.16.2 Configuring user pages.........................................................................................................138
3.16.3 Programming the WWW instruction......................................................................................139
3.16.4 Defining the user page as start page....................................................................................141
3.16.5 Example of a user page ........................................................................................................143
3.16.5.1 Website for monitoring and controlling a wind turbine..........................................................143
3.16.5.2 Reading and displaying data from the CPU..........................................................................145
3.16.5.3 Using enum types .................................................................................................................147
3.16.5.4 Writing user inputs into the controller ...................................................................................148
3.16.5.5 Writing special tags...............................................................................................................149
3.16.5.6 HTML code of the user page "Remote Wind Turbine Monitor" ............................................150
3.17 Filebrowser ...........................................................................................................................154
3.18 Reading out service data ......................................................................................................155
3.19 Basic websites ......................................................................................................................156
3.20 API (Application Programming Interface) .............................................................................158
3.20.1 Web API................................................................................................................................158
3.20.2 The available Web API methods ..........................................................................................161
3.20.2.1 Api.Login ...............................................................................................................................162
3.20.2.2 Api.GetPermissions ..............................................................................................................163
3.20.2.3 Api.Browse............................................................................................................................164
3.20.2.4 Api.Version............................................................................................................................165
3.20.2.5 Api.Ping.................................................................................................................................165
3.20.2.6 Api.GetCertificateUrl .............................................................................................................166
3.20.2.7 Api.Logout.............................................................................................................................166
3.20.3 Web API integration ..............................................................................................................166
3.20.4 Web API sessions.................................................................................................................169
3.20.5 Read and write process data ................................................................................................170
3.20.5.1 Supported data types............................................................................................................170
3.20.5.2 Parameter assignment of the block properties .....................................................................175
3.20.5.3 PlcProgram.Read..................................................................................................................176
3.20.5.4 PlcProgram.Write..................................................................................................................177
3.20.5.5 PlcProgram.Browse ..............................................................................................................179
3.20.6 Website for monitoring and controlling a wind turbine..........................................................183
Glossary ............................................................................................................................................. 196
Index................................................................................................................................................... 200

Web server
12 Function Manual, 11/2019, A5E03484625-AG
Function manuals Documentation Guide
1
The documentation for the SIMATIC S7-1500 automation system, for CPU 1516pro-2 PN
based on SIMATIC S7-1500, and for the distributed I/O systems SIMATIC ET 200MP,
ET 200SP and ET 200AL is divided into three areas.
This division allows you easier access to the specific information you require.
Basic information
System manuals and Getting Started manuals describe in detail the configuration,
installation, wiring and commissioning of the SIMATIC S7-1500, ET 200MP, ET 200SP and
ET 200AL systems; use the corresponding operating instructions for CPU 1516pro-2 PN.
The STEP 7 online help supports you in configuration and programming.
Device information
Product manuals contain a compact description of the module-specific information, such as
properties, terminal diagrams, characteristics and technical specifications.

Function manuals Documentation Guide
Web server
Function Manual, 11/2019, A5E03484625-AG 13
General information
The function manuals contain detailed descriptions on general topics such as diagnostics,
communication, Motion Control, Web server, OPC UA.
You can download the documentation free of charge from the Internet
(https://support.industry.siemens.com/cs/ww/en/view/109742705).
Changes and additions to the manuals are documented in product information sheets.
You will find the product information on the Internet:
●S7-1500/ET 200MP (https://support.industry.siemens.com/cs/us/en/view/68052815)
●ET 200SP (https://support.industry.siemens.com/cs/us/en/view/73021864)
●ET 200AL (https://support.industry.siemens.com/cs/us/en/view/99494757)
Manual Collections
The Manual Collections contain the complete documentation of the systems put together in
one file.
You will find the Manual Collections on the Internet:
●S7-1500/ET 200MP (https://support.industry.siemens.com/cs/ww/en/view/86140384)
●ET 200SP (https://support.industry.siemens.com/cs/ww/en/view/84133942)
●ET 200AL (https://support.industry.siemens.com/cs/ww/en/view/95242965)
"mySupport"
With "mySupport", your personal workspace, you make the best out of your Industry Online
Support.
In "mySupport", you can save filters, favorites and tags, request CAx data and compile your
personal library in the Documentation area. In addition, your data is already filled out in
support requests and you can get an overview of your current requests at any time.
You must register once to use the full functionality of "mySupport".
You can find "mySupport" on the Internet (https://support.industry.siemens.com/My/ww/en).
Application examples
The application examples support you with various tools and examples for solving your
automation tasks. Solutions are shown in interplay with multiple components in the system -
separated from the focus on individual products.
You will find the application examples on the Internet
(https://support.industry.siemens.com/sc/ww/en/sc/2054).

Web server
14 Function Manual, 11/2019, A5E03484625-AG
General information
2
2.1 Properties of the Web server
Benefits of the Web server
The Web server enables monitoring and administering of the CPU by authorized users over
a network. Evaluations, diagnostics, and modifications are thus possible over long distances.
Monitoring and evaluation is possible without STEP 7, only a web browser is required. Note
that you must take appropriate measures to protect the CPU from compromise (such as
restricting network access, using firewalls).
Activating the Web server
The web server is deactivated in the delivery state of the CPU. This means that you must
load a project in which the Web server is activated to enable access using the Web browser.
Security functions
The Web server provides the following security functions:
●Access via the secure transmission protocol "HTTPS" using the CA-signed web server
certificate
●User authorizations you can configure by means of user list
●Activation for specific interfaces

General information
2.1 Properties of the Web server
Web server
Function Manual, 11/2019, A5E03484625-AG 15
Web browser
You need a web browser to access the HTML pages of the CPU.
The web browsers listed below have been tested for communication with the CPU. Other
web browsers may also work, especially newer versions. However, if problems occur with
web browsers not mentioned here that cannot be rectified, use one of the following tested
web browsers:
●Microsoft Internet Explorer (Version 11.x)
●Microsoft Edge (Version 44.x)
●Google Chrome (Version 75.x)
●Mozilla Firefox (Version 64.x)
●Opera (Version 58.x)
●Mobile Safari and Chrome for iOS (iOS 12)
●Android browser (Android 7.x)
●Chrome for Android (Android 7.x to 8 (certificates work only to limited extent in Android
8))
Note
If you are using Internet Expl
orer, disable "Compatibility view" in the settings ("Options"
menu).
Note
For access to display devices with low screen resolution
, we recommend the use of basic
websites, see section
Basic websites (Page 156).
Note
Older
versions of the web browsers named above, which pr
eviously supported access to the
HTML pages of the CPU, continue to allow this. However, these older versions do not
support the new functions and HTML pages described in this edition.
Note
Two reserved communication connections are available to the We
b server for
communication with the CPU.
Depending on the web browser used, different numbers of connections to the CPU are
established. If more connections are available, more communication con
nections will be
established.
If no more connections are avail
able, display or functional problems may occur, because the
Web server will reject all other communication connections apart from the two that are
reserved.
For this reason, the web pages may no
t load fully.

General information
2.1 Properties of the Web server
Web server
16 Function Manual, 11/2019, A5E03484625-AG
Note
If you access the web server of the CPU
using a communications processor (CP), ensure
that the cache (temporary Internet files) is enabled in your browser. Choose the
"Automatically" option in the cache settings of your browser.
If
the cache is disabled or if a setting other than "Automaticall
y" is made in the cache settings
of your browser, this may result in slow access times and incomplete display.
Note
After a firmware update of the CPU, incorrect display of Web pages can occur in various
Web browsers. This is caused by problems of the
new CPU firmware with the cache of the
Web browser.
Solution:
Press F5 or clear the Web browser cache.

General information
2.1 Properties of the Web server
Web server
Function Manual, 11/2019, A5E03484625-AG 17
Reading out data
With the Web server, you can read out the following data from the CPU and, in some cases,
modify and write back the data to the CPU.
●Start page with general CPU information (Page 33)
●Information on Diagnostics (Page 38)
–Identification
–Program protection
–Memory
–Runtime information
–Fail-safe (with an F CPU)
●Contents of the diagnostics buffer (Page 48)
●Module information (Page 57)
●Firmware update (Page 62)
●Alarms (Page 65)
●Information on Communication (Page 67)
–Important interface parameters
–Port statistics
–Display of the communication resources
–Display of the communication connections
●PROFINET-Topology (Page 72)
–Graphical view (set and actual topology)
–Table view (actual topology)
–Status overview
●Tag status (Page 82)
●Watch tables (Page 85)
●User pages (Page 120)
●Filebrowser (Page 154)
●DataLogs (Page 112)
●User files (Page 115)
●Online backup and restoration of the configuration (Page 87)
●Diagnostic information for technology objects (Page 49)
●Evaluation of trace recordings (Page 92)
●Reading out service data (Page 155)
●Basic websites (Page 156)
The HTML pages are described in more detail on the following pages.
Note
Max. characters at data type WSTRING
Note that the data type WSTRING is limited to 254 char
acters for the display in the Web
server. If the 254 characters are exceeded, the Web server does not display the superfluous
characters.

General information
2.1 Properties of the Web server
Web server
18 Function Manual, 11/2019, A5E03484625-AG
Web access to the CPU via PG/PC, HMI devices and mobile terminal devices
Proceed as follows to access the Web server:
1. Use STEP 7 to download a project in which the web server is enabled to the CPU.
2. Connect the display device (PG/PC, HMI, mobile terminal device) with the CPU or a
communication module using a PROFINET interface.
If you are working with WLAN, activate the WLAN on the display device and establish a
connection to the access point (e.g. SCALANCE W788-1RR or SCALANCE W784-1),
which is in turn connected to the CPU.
3. Open the web browser on the display device.
4. Enter the IP address of the interface of the CPU which is connected to the client in the
"Address" field of the web browser in the following format: http://a.b.c.d or https://a.b.c.d
(example of input: http://192.168.3.141).
The intro page of the CPU opens. From the intro page you can navigate to additional
information.
Additional information on access using the secure transmission protocol "HTTPS" is
available in the section Configuring the Web server (Page 19).
Additional information
Using a smartphone, you can access the Web server of the CPU either via WLAN or access
to the CPU via the SIMATIC S7 app (using Web server functionality). You can find additional
information in the FAQ entry ID 103473392 on the Service&Support
(https://support.industry.siemens.com/cs/ww/en/view/103473392) Internet page.
Note: The Web server must also be activated for access to the CPU via the SIMATIC S7
app.
The SIMATIC S7 app offers you additional functions. You can find a detailed application
example with further documentation and example projects on the Service&Support
(https://support.industry.siemens.com/cs/ww/en/view/84133612) Internet page.

General information
2.2 Configuring the Web server
Web server
Function Manual, 11/2019, A5E03484625-AG 19
2.2 Configuring the Web server
To use the full functionality of the web server, the following settings in STEP 7 are
necessary.
Procedure
You have opened the properties dialog of the CPU in STEP 7 in the project view.
Figure 2-1 Web server settings in STEP 7
