Siemens SITRANS LR560 Instruction manual

Radar Transmitters
Quick Start Manual 11/2012
SITRANS LR560 (mA/HART)
SITRANS

IQ300IX.fm Page 5 Tuesday, October 2, 2001 1:43 PM

7ML19985XF82 SITRANS LR560 (HART) Page EN-1
mmmmm
English
SITRANS LR560 (HART) Quick Start Manual
This manual outlines the essential features and functions of the SITRANS LR560 (HART 1)). We
strongly advise you to acquire the detailed version of the manual so you can use your device to
its fullest potential. The complete manual can be downloaded from the SITRANS LR560
product page of our web site at: www.siemens.com/LR560. The printed manual is available
from your local Siemens Milltronics representative.
Questions about the contents of this manual can be directed to:
Siemens AG
Siemens Milltronics Process Instruments
1954 Technology Drive, P.O. Box 4225
Peterborough, Ontario, Canada, K9J 7B1
Email: [email protected]
MILLTRONICS is a registered trademark of Siemens Milltronics Process Instruments.
Technical Support
Support is available 24 hours a day.
To find your local Siemens Automation Office address, phone number, and fax number, go to:
www.siemens.com/automation/partner:
• Click on the tab Contact, select Service, then click Service again to find your
product group (+Automation Technology > +Sensor Systems >+Process
Instrumentation > +Level Measurement > +Continuous). Select Radar.
• Select the country followed by the City/Region.
• Select Technical Support under Service.
For on-line technical support go to: www.siemens.com/automation/support-request
• Enter the device name (SITRANS LR560) or order number, then click on Search, and
select the appropriate product type. Click on Next.
• Enter a keyword describing your issue. Then either browse the relevant documentation,
or click on Next to email a description of your issue to Siemens Technical Support staff.
Siemens IA/DT Technical Support Center: phone [phone]
1) HART® is a registered trademark of HART Communication Foundation.
Copyright Siemens AG 2012.
All Rights Reserved Disclaimer of Liability
We encourage users to purchase autho-
rized bound manuals, or to view elec-
tronic versions as designed and
authored by Siemens Milltronics Process
Instruments. Siemens Milltronics Pro-
cess Instruments will not be responsible
for the contents of partial or whole
reproductions of either bound or elec-
tronic versions.
While we have verified the contents of this manual
for agreement with the instrumentation described,
variations remain possible. Thus we cannot guar-
antee full agreement. The contents of this manual
are regularly reviewed and corrections are
included in subsequent editions. We welcome all
suggestions for improvement.
Technical data subject to change.

Page EN-2 SITRANS LR560 (HART) 7ML19985XF82
mmmmm
English
Safety Guidelines
Warning notices must be observed to ensure personal safety as well as that of others, and to
protect the product and the connected equipment. These warning notices are accompanied by
a clarification of the level of caution to be observed.
FCC Conformity
US Installations only: Federal Communications Commission (FCC) rules
Industry Canada
a) Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
b) This device shall be installed and operated in a completely enclosed container to prevent
RF emission which otherwise can interfere with aeronautical navigation. Installation shall
be done by trained installers, in strict compliance with the manufacturer’s instructions.
c) The use of this device is on a “no-interference, no-protection” basis. That is, the user
shall accept operations of high-powered radar in the same frequency band which may
interfere with or damage this device. On the other hand, level probing devices found to
interfere with primary licensing operations will be required to be removed at the user’s
expense.
WARNING symbol relates to a caution symbol on the product, and means that
failure to observe the necessary precautions can result in death, serious injury,
and/or considerable material damage.
WARNING symbol, used when there is no corresponding caution symbol on the
product, means that failure to observe the necessary precautions can result in
death, serious injury, and/or considerable material damage.
Note: means important information about the product or that part of the operating manual.
WARNING: Changes or modifications not expressly approved by Siemens
Milltronics could void the user’s authority to operate the equipment.
Notes:
• This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference when the equipment is operated in a com-
mercial environment.
• This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful inter-
ference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference to radio communications, in which case the user will
be required to correct the interference at his own expense.

7ML19985XF82 SITRANS LR560 (HART) Page EN-3
mmmmm
English
d) This level probing device is only permitted for installation inside enclosed containers. The
installer/user of this device shall ensure that it is at least 10 km from the Penticton radio
astronomy station (British Columbia latitude: 49° 19' 12" N, longitude: 119° 37'12" W). For
devices not meeting this 10 km separation (e.g. the Okanagan Valley, British Columbia)
the installer/ user must coordinate with and obtain the written concurrence of the
Director of the Penticton radio astronomy station before the equipment can be installed
or operated. The Penticton contact is Tel: [phone]/ fax: [phone]. (In case of
difficulty, the Manager, Radio Equipment Standards, Industry Canada, may also be
contacted.)
R&TTE Compliance (Europe)
Hereby, Siemens Milltronics Process Instruments, declares that the SITRANS LR560
is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
The LR560 complies with EN 302 372 for use in closed storage vessels, when installed
according to the installation requirements of EN 302 372, and may be used in all EU countries.
The LR560 complies with Draft ETSI EN 302 729 for use outside of closed tanks in most EU
countries. (For a list of exceptions, see the LR560 Declaration to EN 302 729, which can be
accessed online at www.siemens.com/LR560.) For open air installations, the following
conditions must be observed:
Installation and maintenance is performed by suitably qualified and trained personnel.
The LR560 shall be installed only in a permanent fixed position pointing downwards. Its
location shall comply with the following two restrictions:
1) It shall be installed with a minimum separation distance of 4 km from Radio
Astronomy sites listed below unless special authorization has been provided by the
responsible national regulatory authority.
2) If it is installed at a location between 4 and 40 km from any Radio Astronomy site
listed below, the LR560 shall be installed at a height not exceeding 15m from the
ground.
The LR560 Declaration of Conformity may be accessed online at www.siemens.com/LR560.
.
Country Name of Station Geographic Latitude Geographic Longitude
France Plateau de Bure 44°38’01” N 05°54’26” E
Bordeaux 44°84’00” N 0°52’00” W
Germany Effelsberg 50°31’32” N 06°53’00” E
Italy Sardinia 39°29’50” N 09°14’40” E
Spain Yebes 40°31’27” N 03°05’22” W
Pico Veleta 37°03’58.3” N 03°23’33.7” W
Sweden Onsala 57°23’45” N 11°55’35” E

Page EN-4 SITRANS LR560 (HART) 7ML19985XF82
mmmmm
English
SITRANS LR560
SITRANS LR560 is a 2-wire 78 GHz FMCW radar level transmitter for continuous monitoring of
solids in vessels to a range of 100 m (329 ft). The plug and play performance is ideal for all solids
applications, including those with extreme dust and high temperatures to +200 °C (+392 °F).
The device is an electronic circuit coupled to a lens antenna and flange for quick and easy
positioning.
SITRANS LR560 supports HART communication protocol, and SIMATIC PDM software. Signals
are processed using Process Intelligence.
Specifications
For a complete listing, see the SITRANS LR560 (HART) Instruction Manual. For Approvals
information see
Approvals on page 5.
Ambient/Operating Temperature
Power
• Maximum 30 V DC 1)
• 4 to 20 mA loop power
WARNING: SITRANS LR560 is to be used only in the manner outlined in this manual,
otherwise protection provided by the equipment may be impaired.
Note: This product is intended for use in industrial areas. Operation of this equipment in a
residential area may cause interference to several frequency based communications.
Notes:
• The reference drawing listed on the device label can be downloaded from the Siemens
website at: www.siemens.com/LR560 under Support.
• Maximum and minimum temperatures are dependent on the process connection, antenna
and O-ring materials. Use of the Easy Aimer limits maximum temperature.
•See
Temperature De-Rating Curve on page 16, for more details.
Nominal 24 V DC with
max. 550 Ohm loop resistance1).
For other configurations, see the chart under
Loop Power on page 16.
1) Check the device label for the characteristics of the device, and confirm the loop load.
process temperature at process connection:
–40 oC to +100 oC (–40 oF to +212 oF) or
–40 oC to +200 oC (–40 oF to +392 oF) depending on the version
ambient temperature
(surrounding enclosure)
–40 °C to 80 °C (–40 °F to 176 °F) device label
pressure and
temperature
related
information

7ML19985XF82 SITRANS LR560 (HART) Page EN-5
mmmmm
English
Approvals
•General CSA
US/C, FM, CE, C-TICK
• Radio R&TTE (Europe), FCC, Industry Canada,
• Hazardous
Non-sparking/
Energy Limited 1) (Europe) ATEX II 3G Ex nA/nL IIC T4 Gc
Dust Ignition Proof 1) (Europe/International) ATEX II 1D, 1/2D, 2D
IECEx SIR 09.0149X
Ex ta IIIC T139oC Da
Dust Ignition Proof 2) (US/Canada) FM/CSA:
Class II, Div. 1, Groups E, F, G
Class III T4
Non-incendive 2) (US/Canada) FM/CSA Class I, Div. 2,
Groups A, B, C, D, T4
Pressure Application
Pressure Equipment Directive, PED, 97/23/EC
SITRANS LR560 Radar Level Measurement instrument falls below the limits of Article 3,
sections 1&2 of the Pressure Equipment directive (PED, 97/23/EC), as a category I pressure
accessory. However, in accordance with PED, 97/23/EC, Article 3, section 3, this equipment has
been designated and manufactured in accordance with Sound Engineering Practice (SEP) (see
EU Commission Guideline 1/5).
Notes:
• The device label lists the approvals that apply to your device.
• Use appropriate conduit seals to maintain IP or NEMA rating.
1) See also
Non-Sparking/Energy Limited wiring (Europe) and Dust Ignition Proof wiring (Europe/Inter-
national) on page 17.
2) See also
Non-incendive and Dust Ignition Proof wiring (US/Canada) on page 17.
WARNINGS:
• Do not attempt to loosen, remove, or disassemble process connection or instru-
ment housing while vessel contents are under pressure.
• Improper installation may result in loss of process pressure.
Note: Pertains to pressure-rated version only.

Page EN-6 SITRANS LR560 (HART) 7ML19985XF82
mmmmm
English
Installation
Nozzle location
Beam angle
• Beam angle is the width of the cone where
the energy density is half of the peak
energy density.
• The peak energy density is directly in front
of and in line with the antenna.
• There is a signal transmitted outside the
beam angle, therefore false targets may be
detected.
Emission cone
• Keep emission cone free of interference
from ladders, pipes, I-beams or filling
streams.
• Avoid central locations on tall, narrow ves-
sels.
WARNINGS:
• Installation shall be performed only by qualified personnel and in accor-
dance with local governing regulations.
• Never attempt to loosen, remove, or disassemble process connection or
instrument housing while vessel contents are under pressure.
• The user is responsible for the selection of bolting and gasket materials
which will fall within the limits of the flange and its intended use and which
are suitable for the service conditions.
• Improper installation may result in loss of process pressure.
Note: SITRANS LR560 units are pressure tested, meeting or exceeding the requirements of
the ASME Boiler and Pressure Vessel Code and the European Pressure Equipment Directive.
emission
cone
4°

7ML19985XF82 SITRANS LR560 (HART) Page EN-7
mmmmm
English
Environment
• Provide easy access for viewing the display and programming via the hand programmer.
• Provide an environment suitable to the housing rating and materials of construction.
Sun Shield
The LR560 display can be protected by an
optional sun shield if the instrument will be
mounted in direct sunlight
Aimer Adjustment
3" flange 4 and 6" flange
1) For 4" and 6" Aimer: Loosen the set screws in the locking ring.
Holding the electronics enclosure firmly, loosen the Aimer locking ring using the supplied
C spanner, until the LR560 drops down slightly. The enclosure can then be turned freely.
2) Direct SITRANS LR560 so the antenna is pointed at an angle perpendicular to the
material surface, if possible.
Aimer
Aiming is not
required for signal
optimization with
78 GHz frequency.
Aiming will assist
in measuring
material in the
cone.

Page EN-8 SITRANS LR560 (HART) 7ML19985XF82
mmmmm
English
3) When the desired position is reached, re-tighten the locking ring using the C spanner, and
tighten set screws.
4) For the 3" Aimer flange, tapered split washers with pressure rated versions are provided
to keep nuts and bolts perpendicular to the flange surface.
Air Purge System
The purge airflow is designed to create a strong vortex of air that rapidly cleans the face of the
lens. See the full manual for details.
Wiring
Power
Connecting SITRANS LR560
1) Loosen locking screw.
2) Remove LR560 lid.
3) Remove optional display by gently turning the
display a quarter turn counter-clockwise until it is
free.
4) Strip the cable jacket for approximately 70 mm
(2.75") from the end of the cable, and thread the
wires through the gland 1).
WARNINGS:
The DC input terminals shall be supplied from a source providing electrical
isolation between the input and output, in order to meet the applicable safety
requirements of IEC 61010-1.
All field wiring must have insulation suitable for rated voltages.
WARNINGS:
• Check the device label to verify the approval rating.
• Use appropriate conduit seals to maintain IP or NEMA rating.
• Read
Instructions specific to hazardous area installations on page 17.
Notes:
• Use twisted pair cable: AWG 22 to 14 (0.34 mm² to 2.5 mm²).
• Separate cables and conduits may be required to conform to standard instrumentation
wiring practices or electrical codes.
1) If cable is routed through conduit, use only approved suitable-size hubs for waterproof applications.
1)
2)
3) ¼ turn
