Sierra Smart-Trak 100 series User manual

Email Technical Support: [email protected]
24 Hour Live Help Online: www.sierrainstruments.com (Click “Sales & Service” button)
Telephone Technical Support: North America: 800.866.0200 or 831.373.0200 ; Europe, Middle East, Africa + 31 72 5071 400 ;
Asia: + 8620 3435 4870
PN47‐0435B
ick





Smart‐Trak2Model100Meters&Controllers
Note:AcopyofthisQuickStartGuide,theusersoftwareandthemanualarealsoincludedontheProductInformationCD
includedinyourshipment.

SAFETY
1. Applypoweronlyafterreviewingwiringdiagramsprintedonthebackofthiscard&inInstructionManual,Ch.2
2. Applygasflowonlyaftercheckingplumbingconnectionsforleaks
3. NEVERTESTFORLEAKSWITHLIQUIDLEAKDETECTOR.Ifliquidseepsintotheelectronicsorthehiddensensor
compartment,theinstrumentmaybedamaged.Instead,useapressure‐decaytest(ifliquidMUSTbeusedatall,
limitittothefittingsandkeepitoffthebodyoftheinstrument).

INSTALLATION
1. Consulttheinstrument’sDataLabel(ontherearoftheinstrument)forALLproperoperatingparameters.Ifthe
informationontheDataLabeldoesnotmatchyourprocessconditions,contactyourRepresentativeorSierra
InstrumentsCustomerService.
2. Installa10micronin‐linefilterupstreamofyourinstrument.Ifthegascontainsanymoisture,useanappropriate
dryerordesiccant.Particleslargerthan10micronandmoisturemaydamageyourinstrument.
3. MountaccordingtoDataLabelorientation.HorizontalflowispreferableandfactorydefaultUNLESSthefactory
calibrationwasperformedspecificallyforverticalflowupwardordownward,aslisted.Orientationislistedonthe
DataLabelandontheCalibrationCertificate.
4. DONOTAPPLYPOWERTOTHEOUTPUTLOOP.ThisisNOTaloop‐powereddevice.
5. Applypoweronlyafterreviewingwiringdiagramsprintedonthebackofthiscard&inInstructionManual,Ch.2
PowerisappliedviatheHDDB15connector.TheCAT‐5RJ45connectorisfortheSierraRemotePilotModuleor
provided‘CRN’cable.DONOTusetheCAT5RJ45portforEthernet—damagetoyourcomputersystemorthe
instrumentmayoccur.

OPERATION
1. Powertheunit.IfyouareusingtheSierraprovidedpowersupply,itisrecommendedyouattachtheD‐sub
connectortotheSmart‐Trak2beforepluggingtheadapterintothewall.Theunitmaytakelongertostartthan
normalifotherwise.Thiswillnotdamagetheunit.ThegreenLEDabovetheRJ45connectorwilllightwhenthe
unitpowered.
2. OurMassFlowControllersareshippedwithazerosetpointinAutomaticvalveoperationmode.Forsafety
considerations,itisrecommendedyouconfirmthispriortoapplyinggastotheunit.
3. ApplythegaslistedontheDataLabeltotheinletattherecommendedpressure(listedontheData
Label/CalibrationCertificate).YourSmart‐Trak2Meterwillbegintomeasuremassflow.Thiswillbedisplayedon
theusersoftwareordisplaymodulethatyouhavehookedup.
4. MassFlowControllerswillneedasetpointinputinordertocontrolflow.Dosocarefully!Youcandigitallyinputa
setpointusingtheprovidedUserSoftwareorPilotModule,orcontroldirectlywithyouranalogsetpointsource.
NOTE:YoucanchangethesetpointsourcetypeusingthesoftwareorPilotModule.Theunitshipsinthe
configurationinitiallychosen(ordefaultifnotspecified).ThisinformationisalsolistedontheDataLabelandon



PN47‐0435B
theCalibrationCertificate.Thisinformationisalsoinherentinthemodelcode.
SeetheInstructionManualfordetails.
5. DONOTleaveasetpointappliedforanextendedperiodoftimetoacontroller
whenthegassupplyisofforblocked.Damagemayresultfromexcessive
heating,andtheunitwillbecomehotenoughtoburnyou.Alternatively,youcan
maintainyoursetpointvaluebutclosethevalvebyswitchingValveOperationto
Closeddigitallywiththeusersoftwareorthedisplaymodule,orwithananalog
groundtotheappropriatepin(seeover).

WiringDefinitionsforOptionalCommunicationCable(Pinout)
Pin#WireColorinCableFunction
1. BrownAnalogGround/Output
2. Red0‐5VDCOutput(or0‐10,1‐5VDC)
3. OrangeAnalogGround/RS232
4. PinkValveOverridePurge
5. YellowPowerReturn(‐)
6. GreenPowerInput(+)
7. Green/WhiteRS‐232Transmit(out)
8. BlueSetpoint
9. PurpleNotUsed
10. GrayAnalogGround/Setpoint
11. WhiteReferenceVoltage
12. BlackValveOverrideClose
13. Brown/whiteRS‐232Receive(in)
14. Red/white4‐20mAOutput
15. Red/BlackNotUsed
ShieldChassis(Earth)Ground

Smart‐Trak2CompatibilityReference
Note: Original Smart-Trak=ST1; Smart-Trak 2 = ST2

Pilot:Notcompatible:Matchpilotandmeterfirmwarerevisions
UserSoftware:Notcompatible:ST2usersoftwarewillbeprovidedwitheachmeter
C10Cable/Pinout:Compatible.Seepinoutabove.Chassis(Earth)Groundmovedfrompin15toshiel
d

Power:Compatible.RCA'CRS'RS232Cable: ST1only.
CAT5DisplayCable:Compatible.RJ45'CRN'RS232Cable: ST2only.
Compod:Compatible.FollowingitemsnotsupportedbyST1:
 GasSpan:Willreadzero,writingtoitwillgenerateanexceptionerror
 SensorData:Willreadzero,sensoralarmnonfunctional
 SetUnittoZero:Writingtoitwillgenerateanexceptionerror
ResettoFactoryDefault:Writingtoitwillgenerateanexceptionerror
180Modbus
interface:Compatible
CommandSet:Notcompatible.Availableuponrequest.
NOTES:*Analoggroundsmustbekeptseparate
 *NeedEarth/ChassisGroundforST2

‐CanconnectmultipleRS232devicesatonce(Display,Compod,Computer)toST2
‐Unitcanonlyreceivecommandsfromoneatatime
*AllSerialNumbersafter125,000areST2.

Figure:PinLocationsonInstrument
NOTE: Pins 1, 3, and 10 are connected
together inside the instrument. DO NOT
tie these grounds together outside the
instrument. Must have one connection per
analog ground.
