Sierra InnovaMass 240 series User manual

InnovaMass®240/241 HART
Instruction Manual
HART Device Specification for Models:
240-V, -VT, -VTP, -LP & 241-V, -VT, -VTP, -LP
Multivariable Mass Vortex Flow Meters
Part Number: IM240/241 Modbus, Rev. V1
May 2013

GLOBAL SUPPORT LOCATIONS: WE ARE HERE TO HELP!
CORPORATE HEADQUARTERS
5 Harris Court, Building L Monterey, CA 93940
Phone [phone] [phone] Fax [phone]
www.sierrainstruments.com
EUROPE HEADQUARTERS
Bijlmansweid 2 1934RE Egmond aan den Hoef
The Netherlands
Phone [phone] Fax [phone]
ASIA HEADQUARTERS
Second Floor Building 5, Senpu Industrial Park
25 Hangdu Road Hangtou Town
Pu Dong New District, Shanghai, P.R. China
Postal Code 201316
Phone: + 8621 5879 8521 Fax: [phone]
IMPORTANT CUSTOMER NOTICE- OXYGEN SERVICE
Sierra Instruments, Inc. is not liable for any damage or personal injury, whatsoever, resulting from the use of Sierra Instruments
standard mass flow meters for oxygen gas. You are responsible for determining if this mass flow meter is appropriate for your
oxygen application. You are responsible for cleaning the mass flow meter to the degree required for your oxygen flow
application.
© COPYRIGHT SIERRA INSTRUMENTS 2012
No part of this publication may be copied or distributed, transmitted, transcribed, stored in a retrieval system, or translated
into any human or computer language, in any form or by any means, electronic, mechanical, manual, or otherwise, or
disclosed to third parties without the express written permission of Sierra Instruments. The information contained in this
manual is subject to change without notice.
TRADEMARKS
InnovaFlo®and InnovaMass®are trademarks of Sierra Instruments, Inc. Other product and company names listed in this
manual are trademarks or trade names of their respective manufacturers.

Warnings and Cautions
Warning! Agency approval for hazardous location installations varies between flow meter models. Consult the flow meter
nameplate for specific flow meter approvals before any hazardous location installation.
Warning! Hot tapping must be performed by a trained professional. U.S. regulations often require a hot tap permit. The
manufacturer of the hot tap equipment and/or the contractor performing the hot tap is responsible for providing proof of such a
permit.
Warning! All wiring procedures must be performed with the power off.
Warning! To avoid potential electric shock, follow National Electric Code safety practices or your local code when wiring this unit
to a power source and to peripheral devices. Failure to do so could result in injury or death. All AC power connections must be in
accordance with published CE directives.
Warning! Do not power the flow meter with the sensor remote (if applicable) wires disconnected. This could cause over-heating of the
sensors and/or damage to the electronics.
Warning! Before attempting any flow meter repair, verify that the line is de-pressurized.
Warning! Always remove main power before disassembling any part of the mass flow meter.
Caution! Before making adjustments to the device, verify the flow meter is not actively monitoring or reporting to any master
control system. Adjustments to the electronics will cause direct changes to flow control settings.
Caution! All flow meter connections, isolation valves and fittings for hot tapping must have the same or higher pressure rating
as the main pipeline.
Caution! Changing the length of cables or interchanging sensors or sensor wiring will affect the accuracy of the flow meter.
You cannot add or subtract wire length without returning the meter to the factory for re-calibration.
Caution! When using toxic or corrosive gases, purge the line with inert gas for a minimum of four hours at full gas flow
before installing the meter.
Caution! The AC wire insulation temperature rating must meet or exceed 80°C (176°F).
Caution! Printed circuit boards are sensitive to electrostatic discharge. To avoid damaging the board, follow these
precautions to minimize the risk of damage:
before handling the assembly, discharge your body by touching a grounded, metal object
handle all cards by their edges unless otherwise required
when possible, use grounded electrostatic discharge wrist straps when handling sensitive components
!


4
Note and Safety Information
We use caution and warning statements throughout this book to draw your attention to important
information.
Warning!
Caution!
This statement appears with information that
is important to protect people and equipment
from damage. Pay very close attention to all
warnings that apply to your application.
This statement appears with information that is
important for protecting your equipment and
performance. Read and follow all cautions that
apply to your application.
Receipt of System Components
When receiving a Sierra mass flow meter, carefully check the outside packing carton for damage
incurred in shipment. If the carton is damaged, notify the local carrier and submit a report to the
factory or distributor. Remove the packing slip and check that all ordered components are present.
Make sure any spare parts or accessories are not discarded with the packing material. Do not
return any equipment to the factory without first contacting Sierra Customer Service .
Technical Assistance
If you encounter a problem with your flow meter, review the configuration information for each
step of the installation, operation, and setup procedures. Verify that your settings and adjustments
are consistent with factory recommendations. Installation and troubleshooting information can be
found in the 240/241 Series Product Instruction Manual.
If the problem persists after following the troubleshooting procedures outlined in the 640S or 780S
product manuals, contact Sierra Instruments by fax or by E-mail (see inside front cover). For
urgent phone support you may call [phone] or [phone] between 8:00 a.m. and 5:00
p.m. PST. In Europe, contact Sierra Instruments Europe at [phone]. In the Asia-Pacific
region, contact Sierra Instruments Asia at + 86-21-58798521. When contacting Technical Support,
make sure to include this information:
 The flow range, serial number, and Sierra order number (all marked on the meter
nameplate)
 The software version (visible at start up)
 The problem you are encountering and any corrective action taken
 Application information (gas, pressure, temperature and piping configuration)
!


5
Table of Contents
Table of Contents ............................................................................................................................ 5
Chapter 1: HART Communications................................................................................................ 6
Loop Powered Meter Wiring ..........................................................................Error! Bookmark not defined.
DC Powered Meter Wiring ............................................................................................................................ 7
AC Powered Meter Wiring .............................................................................Error! Bookmark not defined.
Multi-Point Meter Wiring.................................................................................Error! Bookmark not defined.
Chapter 2: HART Commands with the DD Menu .......................................................................... 9
HART Commands with Generic DD Menu…………………………………………………………………….....14
Fast Key Sequence………………………………………………………………………………………………….15

6
Chapter 1: HART Communications
The HART Communications Protocol (Highway Addressable Remote Transducer Protocol) is a bidirectional
digital serial communications protocol. The HART signal is based on the Bell 202 standard and is
superimposed on 4-20 mA Output 1. Burst mode is not supported.
Wiring
The diagrams below detail the proper connections required for HART
communications:
Warning!
Place controls in manual
mode when making
configuration changes to
the instrument.

7
Loop Powered Meter Wiring, HART Point-to-Point, Shown Below
LOOP
POWER
+ -
FREQ
OUT
PULSE
OUT
-- + +
OPTIONAL BACKLIGHT POWER
+ -
R load,
250 ohm
minimum
+
_
DC
Power
Supply
Remote Connection
for Communicator
Current
Meter
Field Connection
for Communicator
Vortex Meter
DC Powered Meter Wiring, Shown Below
R load,
250 ohm
minimum
+
_
DC
Power
Supply
Remote Connection
for Communicator
Field Connection
for Communicator
Current
Meter
Vortex Meter
4-20
mA 3
4-20
mA 1
DC PWR
+ - +
4-20
mA 2
- + - +
RS485
RS485
RS485 GND
-
OPTION 2
+
ALARM
2
PULSE
OUT
FREQ
OUT
+ - +
ALARM
1
-+ -
4
OPTION 1
1 2 3 15 2 3
ALARM
3
- + -
4 5
+
-

8
AC Powered Meter Wiring, HART Point-to-Point, Shown Below
R load,
250 ohm
minimum
Remote Connection
for Communicator
Field Connection
for Communicator
Current
Meter
Vortex Meter
4-20
mA 3
AC
PWR
IN
4-20
mA 1
24
VDC OUT
+ - +
4-20
mA 2
- + - +
RS485
RS485
RS485 GND
-
OPTION 2
+
ALARM
2
HOT
PULSE
OUT
NEUT
FREQ
OUT
+ - +
ALARM
1
-+ -
4
OPTION 1
1 2 3 15 2 3
ALARM
3
- + -
4 5
+
-
Multi-Point Meter Wiring (digital only) Loop Power, Shown Below
Note: To activate Multi-drop mode, put a device ID of 1 to 15 in the “Dev id” menu (0 is point to point mode).
This fixes the 4-20 mA output to 4 mA. Typically DC power for the loop is provided by an external power
supply (isolated power on AC and DC models). Consult your HART modem manufactures documentation for
specific wiring requirements.

9
