Signature S29005 Mounting instructions

MODEL S29005
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
3 in 1
WINDOW VAC
www.signaturebrand.co

2
CUSTOMER SUPPORT TEAM: [phone]
TECHNICAL DATA
Description: 3 in 1 Window Vac
Model: S29005
Rated Voltage: 240V ~50Hz
Adaptor:
Input: 100-240V ~50/60Hz 0.3A Max
Output: DC 5V 500mA
Battery: 3.7V 1.5Ah Li-ion Battery
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RK Wholesale LTD Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.

3
www.signaturebrand.co
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Please ensure that the appliance
is used on a stable, level, and
heat resistant surface.
• DO NOT immerse cords, plugs
or any part of the appliance in
water or any other liquid.
• DO NOT leave the appliance
unattended while it is operating.
• Close supervision is necessary
when any appliance is used by
or near children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved.
• Children shall not play with the
appliance.
• Cleaning and user maintenance
shall not be made by children
without supervision.
• Switch o at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or appliance
is damaged, stop using the
appliance immediately and seek
advice from the manufacturer
or its service agent or a similarly
qualied person.
• DO NOT let the cord hang over
the edge of a table or counter or
let it come into contact with any
hot surfaces.
• The use of accessory
attachments is not
recommended by the appliance
manufacturer, apart from those
supplied with this product.
• DO NOT pull the plug out by the
cord as this may damage the
plug and/or the cable.
• DO NOT use this product for
anything other than its intended
use.
• This appliance is for household
use only.
• DO NOT carry the appliance by
the power cord.

4
CUSTOMER SUPPORT TEAM: [phone]
• DO NOT insert objects into the
air outlets.
• DO NOT spray liquid from
the spray bottle directly onto
equipment containing electrical
components, such as the
interior of ovens.
• DO NOT place in front of or
close to radiators, heaters or
res.
• Always test by wiping high
shine surfaces by wiping the
microber cloth on a small area,
prior to using the appliance on
the surface.
• This appliance is intended for
wet pick up only. DO NOT use
for picking up dust or other dry
materials.
• DO NOT use to pick up hot ash,
ammable liquids, or any other
hot, smoking or burning objects
or glowing embers.
• DO NOT use to pick up hard,
sharp objects such as glass or
nails.
• DO NOT use any accessories or
parts that are not supplied with
the appliance.
• The appliance must only be
supplied at a Low Voltage
corresponding to the markings
on the rating plate.
• Only use the appliance when
the adaptor is supplied with the
appliance.
• NEVER leave the appliance on
charge when unattended.
• NEVER leave on charge over
night.
• Only adults should charge the
appliance
• In the unlikely event the
appliance develops a fault,
stop using it immediately and
seek advice from the Customer
Support Team.
HIGH VOLTAGE

5
www.signaturebrand.co
WHAT’S IN THE BOX
Instruction Manual
Water Jug
Microbre Cloth
Charger
1. Squeegee vacuum head
2. Spray nozzle
3. Clean water tank cover
4. Water tank
5. Water jug
6. Recycled water tank cover
7. Microbre cloth
8. Power button
9. Trigger
10. Charge indicator
11. Charging port
BEFORE YOUR FIRST USE:
1. Carefully remove all contents from packaging and inspect product to make sure there is no
damage.
2. Assemble the appliance as per the instructions.
3. Charge for 4 hours.
4. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
1
2
3
4
5 6
7
8
9
10
11

6
CUSTOMER SUPPORT TEAM: [phone]
CHARGING
Before rst use, charge for 4 hours.
The window vac needs to be charged for
4 hours for 30 minutes of continuous use.
To charge:
1. Connect the lead from the charging
adaptor to the charging port on the
window vac.
2. Plug the adaptor into a mains power
supply. The indicator light will illuminate
red show the battery is charging. When
the window vac is full charged the
indicator light will illuminate green.
3. Switch o at the mains and remove the
charger from the window vac.
Note: If the indicator light is ashing, the
window vac is not charging, press the power
button to reset the window vac.
ASSEMBLY
1. Align the squeegee vacuum head and the
main body and click into place
2. To attach the microbre cloth, attach the
Velcro that is on the squeegee vacuum
head.
USING YOUR APPLIANCE
1. Wipe the leading edge of the squeegee to
avoid any streaks.
2. Using the water jug, ll the water tank by
removing the clear water tank cover. Take
care not to over ll. You can add a small
amount of window cleaning solution.
3. Using the trigger to spray the window and
wipe any excess dirt away with the cloth.
4. Turn the window vac on by pressing the
power button.
5. Using a vertical motion, use the window
vac from the top to the bottom of the
window, until the window is clear.
6. Hold the window vac at the bottom of the
window to suck up any excess dirty water.
7. Turn the window vac o when the dirty
water inside lls the tank.
8. Open the recycled water tank cover and
pour away the dirty water.
Note: Always unplug the window vac from
the charger before assembly, cleaning,
maintenance or use.

7
www.signaturebrand.co
CLEANING & CARE
• Do not immerse the main body in water.
• Always unplug the window vac from the
charger before cleaning or maintenance.
• Wash the microbre cloth in warm soapy
water and allow to air dry thoroughly.
• To clean the exterior of the window vac,
wipe it with a soft, damp cloth and then
allow to dry thoroughly.
• Clean the squeegee vacuum head and
spray head in warm soapy water and
allow to dry.
TROUBLESHOOTING
Questions Answers
No spray.
Fill the water tank with water.
Spray system is blocked. Try using warm water in the tank and spray
gently to unblock. If this fails then Customer Support Team.
Water is leaking from
the tank.
The water tank has been overlled or the recycled water tank is full.
Check the rubber seal of the lter unit, if it is damaged, contact the dealer
to change.
No suction. The vac doesn’t have enough charge.
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.

We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are oering you an extra 1 year peace of mind.
*To receive your extra 2 years guarantee, register your appliance online
within 28 days of purchase by visiting:
www.signaturebrand.co
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
[phone]
Distributed throughout the UK by RK Wholesale LTD
1217.V2
