SIIG JU-CS0111-S1 User manual

1
04-0692B
USB to Serial Adapter Cable
Quick Installation Guide
Introduction
Addsone9-pinRS-232serialporttoUSB-equipped
computer systems.
Key Features and Benefits
• Provides one 9-pin (DB9) RS-232 port
• Supports data transfer rate up to 500kb/s
• USB plug-n-play and bus-powered
• Connectors: USB Type A (male); 9-pin
RS-232 serial (male)
Serial Number Sticker
For future product return or exchange, this serial
number is required. Please keep it for your
reference.
Serial Number Part Number

2
System Requirements
• USB equipped computer with an available
USB port
• Windows®
8 (32-/64-bit) / 7 (32-/64-bit) /
Vista (32-/64-bit) / XP (32-/64-bit) / Server
2003 (32-/64-bit) / Server 2008 (32-/64-
bit) / Server 2008 R2 / 2000
Package Contents
•USB to Serial Adapter Cable
• Driver CD
• Quick installation guide
Layout
Figure 1: Layout
Type A USB (to
computer)
Serial port

3
Windows Installation
Make sure the driver is installed before plugging
the USB to Serial Adapter Cable into the computer.
Do Not plug the USB to Serial Adapter Cable into
the computer until instructed to do so.
Windows 8 (32-/64-bit) / 7 (32-/64-bit) /
Server 2008 R2
1. At the Windows desktop insert the driver
CD. Close the CD autoplay box if prompted.
2. Click Windows key and R key, type
D:\setup.exe,then press Enter. (Change
D: to match your CD-ROM drive letter)
3. At User Account Control, click Yes. For
Server 2008 R2, skip this step.
4. At Welcome to the InstallShield Wizard for
PL-2303 USB to Serial, click Next,then click
Finish.
5. Plug the USB to Serial Adapter Cable into a
USB port and the driver will install
automatically.
6. Restart Windows to complete the
installation.

4
Windows Vista (32-/64-bit) / XP (32-/64-bit)
/ Server 2003 & 2008 (32-/64-bit) / 2000
1. At the Windows desktop insert the driver
CD.
2. At the CD autoplay window: Double click
the setup file in the driver CD.
If the CD autoplay window does not start:
Click Start, and Run, type D:\setup.exe,
then press Enter. (Change D: to match your
CD-ROM drive letter)
3. At User Account Control, click Allow. Skip
this step if not prompted.
4. At Welcome to the InstallShield Wizard for
PL-2303 USB to Serial, click Next,then click
Finish.
5. Plug the USB to Serial Adapter Cable into a
USB port and the driver will install
automatically.
6. Restart Windows to complete the
installation.

5
To Verify Windows Installation
1. Check Device Manager to verify
installation.
For Windows 8 / 7: Right click Computer,
click Manage, then click Device Manager.
For Windows Vista: Right click Computer,
click Manage, click Continue, then click
Device Manager.
For Server 2008 / 2008 R2: Right click
Computer, click Manage, double click
Diagnostics, then click Device Manager.
For Windows XP / Server 2003 / 2000:
Right click My Computer, click Manage,
then click Device Manager.
2. Double click Ports (COM & LPT), a Prolific
USB-to-Serial Comm Port... should be
displayed.

6
Blank Page

7
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site at
www.siig.com and click Support. Our online support database is updated daily with
new drivers and solutions. Answers to your questions could be just a few clicks away.
You can also submit questions online and a technical support analyst will promptly
respond.
SIIG offers a 5-year manufacturer warranty with this product. This warranty covers the
original purchaser and guarantees the product to be free of any defects in materials or
workmanship for five (5) years from the date of purchase of the product.
SIIG will, at our discretion, repair or replace (with an identical product or product
having similar features and functionality) the product if defective in materials or
workmanship. This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state. Please see our web site for more warranty details.
If you encounter any problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the product to the store
where you purchased from.
B) If your purchase has passed the store's return policy period, please follow the steps
below to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT
to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request
will be processed, if the product is determined to be defective, an RMA number will
be issued.
Step 2: After obtaining an RMA number, ship the product.
• Properly pack the product for shipping. All accessories that came with the
original package must be included.
• Clearly write your RMA number on the top of the returned package. SIIG will
refuse to accept any shipping package, and will not be responsible for a product
returned without an RMA number posted on the outside of the shipping
carton.
• You are responsible for the cost of shipping to SIIG. Ship the product to the
following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
• SIIG will ship the repaired or replaced product via Ground in the U.S. and
International Economy outside of the U.S. at no cost to the customer.

PRODUCTNAME
USB to Serial Adapter Cable
FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B
OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE
FCCCOMPLIANCESTATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE
SIIG,Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
Phone: [phone]
