SIIG AV-GM04S3-S1 Series User manual

HDMI 2.0 Extender over Single Cat.X with HDBaseT,
RS-232, Bi-directional IR, Ethernet & PoC
P/N: AV-GM04S3-S1

Safety and Notice
The AV-GM04S3-S1 HDMI 2.0 Extender over Single Cat.X with HDBaseT, RS-232, Bi-directional
IR, Ethernet & PoC has been tested for conformance to safety regulations and
requirements, and has been certified for international use. However, like all electronic
equipment the AV-GM04S3-S1 should be used with care. Please read and follow the
safety instructions to protect yourself from possible injury and to minimize the risk of
damage to the unit.
●Follow all instructions and warnings marked on this unit.
●Do not attempt to service this unit yourself, except where explained in this manual.
●Provide proper ventilation and air circulation and do not use near water.
●Keep objects that might damage the device and assure that the placement of this
unit is on a stable surface.
●Use only the power adapter and power cords and connection cables designed for
this unit.
●Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
TABLE OF CONTENTS
INTRODUCTION ................................................................................................................1
FEATURES ........................................................................................................................1
SPECIFICATIONS.............................................................................................................. 2
PACKAGE CONTENTS......................................................................................................3
CONNECTION DIAGRAM..................................................................................................3
PANEL DESCRIPTIONS....................................................................................................4
Transmitting unit ►............................................................................................... 4
Receiving unit ► ...................................................................................................6
HARDWARE INSTALLATION............................................................................................. 8
IR PASS-THROUGH.......................................................................................................... 9
HDMI PIN DEFINITION .................................................................................................... 11
NOTICE............................................................................................................................ 12
WARRANTY..................................................................................................................... 13
The SELLER warrants the EX-57V2KS HDMI 2.0 Extender over Single Cat.X
with HDBaseT free from defects in the material and workmanship for 1 year from

1
INTRODUCTION
The AV-GM04S3-S1 HDMI 2.0 Extender over Single Cat.X with HDBaseT, RS-232,
Bi-directional IR, Ethernet & PoC boosts up your video/audio transmission distance up to 100m
(330ft) in HDTV 1080p with 48-bit color depth and 70m (230ft) at 4K-HDR. AV-GM04S3-S1 has new
generation technology which makes sure the HDBaseT extender can support HDMI2.0a and HDCP
2.2. AV-GM04S3-S1 also supports the most advanced 3D video format complaint with HDMI
specification and therefore guarantees the highest 3D video compatibility on the market. With only
one cost-effective Cat.5/5e/6 cable, users can readily extend UHDTV sources from DVD players,
Blu-ray Disc player, PS4, PC, and any other kinds of sources compliant with TMDS to distant display
monitors including HDMI or DVI enabled TV sets or LCD PC monitors. With the advanced design for
the latest HDMI technology, deep color video, DTS-HD or Dolby TrueHD audio, and HDCP support
and compatibility are all further insured. This flexibility makes HDCP compliant DVD players or PS4
transmit utmost high quality video and audio with a greater distance at the minimal cost integrating
several components apart. In addition, AV-GM04S3-S1 is also equipped with bi-directional IR
pass-through path and RS-232 serial port control. These bonus features allow users to boost IR
control distance up to 100m (330ft) through only single Cat.5/5e/6 cable including HDMI signals. In
addition, serial port and USB2.0 offer the convenient path for AV-GM04S3-S1application, such as
touch panels. In addition, the extender also supports PoC (Power over Cable) which can power both
units from the TX or RX with one power supply.
The AV-GM04S3-S1 includes one transmitter (TX) and receiver (RX) unit. The transmitting unit is
used to capture the input HDMI / DVI signals with control packets. The receiving unit is responsible
for equalizing the transmitted HDMI signal and reconstructing IR and serial controls.
AV-GM04S3-S1offers the most convenient solution for digital signage with long distance A/V
transmission path.
FEATURES
●HDMI 2.0a compliant
●Supports 4K2K@60 4:4:4 8bits
●Supports High Dynamic Range (HDR)
●Extends the HDMI Signal up to 100m (330ft) from the HDMI source at Full HD 1080p 48-bit and
70m (230ft) at 4K2K@60 4:4:4 (4K-HDR Technology)
●Supports PoC (Power over Cable) which can power both units from TX or RX with power supply
●Supports ARC
●HDCP & EDID Bypass
●CEC support
●Auto equalization
●USB2.0 over Cat.5/5e/6 cable transmission
●Analog audio over Cat.5/5e/6 cable transmission from transmitter to receiver
●Pure unaltered uncompressed 7.1ch digital HDMI over Cat.5/5e/6 cable transmission
●DTS-HD Master Audio and Dolby TrueHD high bit rate audio support
●Supports full frequency IR signal from 20KHz to 60KHz
●Bi-directional IR path-through
●Integrated port for LAN/network device
●Full Duplex RS-232 control up to 115,200 bps through connector
●Wall mounting housing design for easy and robust installation

2
SPECIFICATIONS
Model Name
AV-GM04S3-S1
Technical
AV-GM04S3-S1[Tx]
AV-GM04S3-S1[Rx]
Role of usage
Transmitter [TX]
Receiver [RX]
HDMI compliance
HDMI 2.0a
HDCP compliance
Yes (HDCP 2.2)
Video bandwidth
Single-link 600MHz [18Gbps]
Video support
HDR 4K2K@60 (4:2:0 10bits) / 4K2K@60 (4:4:4 8bits)
HDMI over UTP
1080p@60 100m (330ft) [CAT 5e]
4K2K@60 (4:4:4 8bit) 70m (230ft) [CAT 5e]
Audio support
Surround sound [up to 7.1ch] or stereo digital audio
Equalization
Auto
Input TMDS signal
1.2 Volts [peak-to-peak]
Input DDC signal
5 Volts [peak-to-peak, TTL]
ESD protection
Human body model —±15kV [air-gap discharge] & ±8kV [contact discharge]
IR pass-thru
Bi-directional
RS-232 support
Yes
USB support
USB2.0
PoC support
Yes
Input
1x HDMI + 2x 3.5mm
1x RJ-45 (Video) + 1x 3.5mm
Output
1x RJ-45 (Video) + 1x 3.5mm + 1xS/PDIF
1x HDMI + 2x 3.5mm+ 1x S/PDIF
In / Out
1x RS-232 + 2x USB + 2x RJ-45 (Ethernet)
1x RS-232 + 2x USB + 2x RJ-45 (Ethernet)
HDMI source control
Controllable via IR pass-through from RX to TX or TX to RX with IR extenders
HDMI connector
Type A [19-pin female]
RJ-45 connector
WE/SS 8P8C
USB connector
Type A & Type mini-USB
3.5mm connector
IR receiver / IR blaster / Stereo
IR receiver / IR blaster / Stereo
Mechanical
AV-GM04S3-S1[Tx]
AV-GM04S3-S1[Rx]
Housing
Metal enclosure
Dimensions
[L x W x H]
Model
Package
Carton
Model
Package
Fixedness
Wall-mounting case with screws
Power supply
24V1A

3
Power consumption
15W [Max]
Operation
temperature
0-50°C
Storage temperature
-20~60°C [-4~140°F]
Relative humidity
20~90% RH [no condensation]
PACKAGE CONTENTS
●1x AV-GM04S3-S1 [TX & RX]
●1x IR blaster
●1x IR receiver
●1x DC 24V1A
●1x User Manual
CONNECTION DIAGRAM

4
PANEL DESCRIPTIONS
Transmitting unit ►AV-GM04S3-S1-TX
Front Panel
1. HDMI IN: Connect to a HDMI source with a HDMI male-male cable
2. Stereo Input: Provide a channel to extend an external analog audio to receiver over HDBaseT
3. S/PDIF Output: remote ARC output
4. IR Blaster: Infrared 3.5mm socket for plugging in the extension cable of IR blaster
5. IR Receiver: Infrared 3.5mm socket for plugging in the extension cable of IR receiver
6. USB: Connect to USB Device
7. Mini-USB: Connect to USB Host
Rear Panel
8. Ethernet port for LAN: Connect to network device
9. DIP Switch: PIN#1: Setup the USB communication
PIN#2: Setup the RS-232 transceiver mode for serial communication channel
PIN#3: For Firmware Update
10. RS-232: Connect to serial port device with a DSUB-9 male-male or male-female cable here
F/W update for Valens chipset
11. Link Indicator LED
12. RJ45: Plug in a Cat-5/5e/6 cable that needs to be linked to the transmitting unit RX
13. LED: Power indicator
14. +24V DC: Connect to a 24V DC power supply.

5

6
Receiving unit ►AV-GM04S3-S1-RX
Front Panel
15. HDMI OUT: Connect to a HDMI display with a HDMI male-male cable
16. Stereo Output: External analog audio output from transmitter over HDBaseT
17. S/PDIF Output: local ARC output
18. IR Blaster: Infrared 3.5mm socket for plugging in the extension cable of IR blaster
19. IR Receiver: Infrared 3.5mm socket for plugging in the extension cable of IR receiver
20. USB: Connect to USB Device
21. Mini-USB: Connect to USB Host
Rear Panel
22. Ethernet port for LAN: Connect to network device
23. DIP Switch: PIN#1: Setup the USB communication
PIN#2: Setup the RS-232 transceiver mode for serial communication channel
PIN#3: For Firmware Update
24. RS-232: Connect to serial port device with a DSUB-9 male-male or male-female cable here
F/W update for Valens chipset
25. Link Indicator LED
26. RJ45: Plug in a Cat-5/5e/6 cable that needs to be linked to the transmitting unit TX.
27. LED: Power indicator
DIP Switch Position
Description
TX & RX
PIN#1
ON []
Link to USB Host (USB Type-mini-B port)
OFF []
Link to USB Device (USB Type A port)
PIN#2
ON []
TxD: The 2nd pin of RS-232, which is in charge of sending data
RxD: The 3rd pin of RS-232, which is in charge of receiving data
OFF []
TxD: The 3rd pin of RS-232, which is in charge of sending data
RxD: The 2nd pin of RS-232, which is in charge of receiving data

7
28. +24V DC: Connect to a 24V DC power supply.
PIN#2
PIN#3
ON []
ON []
Firmware Update Mode
*DIP Switch Position (TX/RX)

8
HARDWARE INSTALLATION
1. Connect a HDMI or DVI source (such as a Blu-ray Disc player) to the transmitting unit
AV-GM04S3-S1-TX.
2. Connect a HDMI or DVI display (such as a LCD TV) to the receiving unit
AV-GM04S3-S1-RX.
3. Connect IR Blaster/Receiver to both TX and RX units.
4. Connect USB Host/Device to both TX and RX units
5. Connect audio source to TX and audio receiver/speaker to RX unit.
6. Connect a Cat-5/5e/6 cable between the transmitting and receiving units.
7. Make sure this Cat-5/5e/6 cable is tightly connected and not loose.
8. Plug in 24V DC power supply unit to the power jack of the transmitting unit
AV-GM04S3-S1-TX.

9
IR PASS-THROUGH
IR Extenders
IR Blaster
IR Receiver
IR Sockets
IR BLASTER: plug in the IR blaster to emit all IR command signals received from the IR
receiver from the other end to control the devices corresponding to the IR signals.
IR RECEIVER: plug in the IR receiver to receive all IR command signals from the IR remote
controls of the corresponding devices.
Definition of IR Earphone Jack
IR Blaster
IR Receiver
Incorrect placement of IR Blaster and Receiver may result in the failure of the IR
extenders. Please check carefully before plugging in the IR extender to the
respective IR sockets. Warranty will not cover the damage.
CAUTION!

10

11
HDMI PIN DEFINITION
Type A (Receptacle) HDMI
Pin 1
TMDS Data2+
Pin 11
TMDS Clock Shield
Pin 2
TMDS Data2 Shield
Pin 12
TMDS Clock–
Pin 3
TMDS Data2–
Pin 13
NC
Pin 4
TMDS Data1+
Pin 14
Reserved (N.C. on device)
Pin 5
TMDS Data1 Shield
Pin 15
SCL
Pin 6
TMDS Data1–
Pin 16
SDA
Pin 7
TMDS Data0+
Pin 17
DDC/CEC Ground
Pin 8
TMDS Data0 Shield
Pin 18
+5V Power
Pin 9
TMDS Data0–
Pin 19
Hot Plug Detect
Pin 10
TMDS Clock+

12
NOTICE
1. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e
125MHz UTP cable and ASTRODESIGN Video Signal Generator VG-859C & VG-870B.
2. Incorrect placement of IR Blaster and Receiver may result in the failure of the IR
extenders. Please check carefully before plugging in the IR extender to the respective IR
sockets. Warranty will not cover the damage.
3. The transmission length is largely affected by the type of Cat-5/5e/6 cables, the type of
HDMI sources, and the type of HDMI display. The testing result shows solid UTP cables
(usually in the form of 300m [1,000ft] bulk cables) can transmit a lot longer signals than
stranded UTP cables (usually in the form of fixed length patch cords). A solid UTP
Cat-5e cable shows longer transmission range than stranded STP Cat-6 cable. For long
extension applications, solid UTP/STP cables are the only viable choice.
4. EIA/TIA-568-B termination (T568B) for Cat-5/5e/6 cables is recommended for better
performance.
5. To reduce the interference among the unshielded twisted pairs of wires in Cat-5/5e/6
cable, one can use shielded STP cables to improve EMI problems, which is worsen in
long transmission.
6. Because the quality of the CAT5/6 cables has the major effect on how long the
transmission limit can achieve and how good is the received picture quality, the actual
transmission range is subject to one’s choice of Cat-5/5e/6 cables. For desired
resolutions greater than 1080p, a Cat-6 cable is recommended.
7. If your HDMI display has multiple HDMI inputs, it is found that the first HDMI input
[HDMI input #1] generally can produce better transmission performance among all
HDMI inputs.

13
WARRANTY
The SELLER warrants the AV-GM04S3-S1 HDMI 2.0 Extender over Single Cat.X with
HDBaseT, RS-232, Bi-directional IR, Ethernet & PoC free from defects in the material and
workmanship for 3 years from the date of purchase from the SELLER or an authorized
dealer. Should this product fail to be in good working condition within the 3 years warranty
period, The SELLER, at its option, repair or replace the unit, provided that the unit has not
been subjected to accident, disaster, abuse or any unauthorized modifications including
static discharge and power surge. This warranty is offered by the SELLER for its BUYER with
direct transaction only. This warranty is void if the warranty seal on the metal housing is
broken.
Unit that fails under conditions other than those covered will be repaired at the current
price of parts and labor in effect at the time of repair. Such repairs are warranted for 90
days from the day of reshipment to the BUYER. If the unit is delivered by mail, customers
agree to insure the unit or assume the risk of loss or damage in transit. Under no
circumstances will a unit be accepted without a return authorization number.
The warranty is in lieu of all other warranties expressed or implied, including without
limitations, any other implied warranty or fitness or merchantability for any particular
purpose, all of which are expressly disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan
are responsible for shipping charges to and from the SELLER. Cables and power adapters
are limited to a 30 day warranty and must be free from any markings, scratches, and neatly
coiled.
The content of this manual has been carefully checked and is believed to be accurate.
However, The SELLER assumes no responsibility for any inaccuracies that may be contained
in this manual. The SELLER will NOT be liable for direct, indirect, incidental, special, or
consequential damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. Also, the technical information contained herein
regarding the AV-GM04S3-S1 features and specifications is subject to change without
further notice.
Support
For more info or tech support
http://www.siig.com/support

14
April, 2018
