Introduction
TheDisplayPorttoCAT5eDaisyChain HD Extender Kit with
RS-232 & IR extends DisplayPort signal over one Cat5/6
cable up to 330ft and is cascade connection supported.
Features and Benefits
• Extend DisplayPort signals up to 100m over Cat5e/
6 cabling
• Cascade receivers up to 10 layers
• Supports video high resolution Full HD 1080p, 1920
x 1080@60Hz
• Supports local DisplayPort and audio output
• Metal housing with mounting mechanism
PackageContents
CE-DP0511-S1
04-0955A
DisplayPort to CAT5e Daisy
Chain HD Extender Kit
with RS-232 & IR
Installation Guide

2
Layout
Transmitter Unit (Tx)
Figure 1: Transmitter side panel
•DC 5V: DC 5V power jack. Plug the included power
adapter here
•PWR:LEDindicatorforpowerstatus.On/Offwhen
the Transmitter is powered on/off
CE-DP0611-S1

3
•LINK: LED indicator for link status. On when the
connection of Transmitter and Receiver is established
and detected
•DP IN: DisplayPort signal input port. Connect this
port to your DisplayPort source device by using a
DisplayPort cable (not included)
•DP OUT: DisplayPort signal output port. Connect
this port to a local DisplayPort display by using a
DisplayPort cable (not included)
• : Audio output port. Connect to the a local
3.5mm audio speaker by using the included audio
cable
•LINE : Signal output port, connected with Receiver's
LINE port by using a CAT X cable (not included)
•IR: Connect to the included IR blaster cable
•RS-232: RS-232 control port. Plug the included
3.5mm to RS-232 cable then an RS-232 cable here, if
needed
•RESET: Use the fine end of any object to press and
hold the bottom to return to default settings
Receiver / Repeater Unit (Rx)
Figure 2: Receiver/Repeater side panel

4
•DC 5V: DC 5V power jack. Plug the included power
adapter here
•IR: Connect to the included IR receiver cable
•RESET: Use the fine end of any object to press and
hold the bottom to return to default settings
•PWR:LEDindicatorforpowerstatus.On/Offwhen
the Receiver is powered on/off
•LINK: LED indicator for link status. On when the
connection of Transmitter and Receiver/Repeater is
established and detected
•RS-232: RS-232 control port. Plug the included
3.5mm to RS-232 cable then an RS-232 cable here, if
needed
•DP OUT: DisplayPort signal output port. Connect
this port to the remote DisplayPort display by using
a DisplayPort cable (not included)
• : Audio output port. Connect to the a remote
3.5mm audio speaker by using the included audio
cable
•LINE 1-3: Signal input port, connected with
Transmitter's LINE port by using a CAT X cable (not
included).
Either one port is connected to the Transmitter unit,
the other two ports could be connected to other
Receivers/Repeaters for further signal extension or
expansion. See the Function Diagram section on
page 7-10 for more details

5
IR Extension Cables
To control the source device from Receiver's end:
1. Plug the IR blaster cable to the Transmitter's IR
connector, then plug the IR receiver cable to the
Receiver's IR connector.
2. Point your source device's remote control to the IR
receiver's eye, the command will be sent to
Transmitter end, and the connected source device
will enforce the command accordingly.
Figure 3a: IR blaster cable Figure 3b: IR receiver cable
Hardware Installation
1. Power off all devices, including the source device
and display.
2. Connect your DisplayPort source (such as a PC or
NB) to the transmitter's DP IN connector by using a
DisplayPort cable.
3. ConnectthelocalDisplayPortdisplayto Transmitter's
DP OUT.
source
device
Figure 4
local
display

6
4. Connect remote DisplayPort display (such as a LCD
TV) to the receiver's DP OUT connector.
output
display
Figure 5
5. Connect the IR blaster cable and IR receiver cable
to the Transmitter and Receiver's IR ports separately.
Skip this step if not needed.
6. Connect the two 3.5mm to RS-232 cables to the
Transmitter and Receiver's RS-232 ports separately.
Skip this step if RS-232 controlling is not needed.
7. Connect your CAT5/6 cable between the
Transmitter's and Receiver's LINE port. Make sure
the CAT5/6 LAN cable is securely connected.
Figure 6
remote
output
display
local
output
display
source
device
8. Each Receiver/Repeater can cascade-chainable to 2
more Receivers/Repeaters for further extending or
expanding . Skip this step if not needed.
9. Connectthespeakersto the Transmitter andReceiver's
audio out ports separately.
Skip this step if not needed.
CAT5/
6 cable

7
Figure 7
2
2
1
DP
source
local DP
display
remote DP
display
• The extension distance through CAT. X cable is up
to 100 meters for one layer
10. Plug the included power adapters into the DC 5V
powerjack oftheTransmitter and Receiverseparately.
Power on the connected source device and
display(s), the Extender kit is ready for use.
Function Diagram
Basic connection
2
IR receiver
cable
(optional)
IR blaster
cable
(optional)
1CAT. X cable
DisplayPort cable
2

8
2
1CAT. X cable
DisplayPort cable
AdvancedConnections
Daisy Chain Connection
Figure 8
• The extension distance through CAT. X cable is up
to 100 meters for one layer
DP
Display
DP
Display
Rx
DP
Display
DP
source
DP
Display
Rx
1Rx
1
2
1
2
2
2
2

9
Cascade Connection
DP
source
DP
Display
DP
Display
DP
Display
DP
Display
Rx
Rx
Rx
Tx
1
1
1
2
2
2
Figure 9
2
• Cascadereceiversup to 10 layers; extension distance
through CAT. X cable up to 100 meters for one layer
2
2
1CAT. X cable
DisplayPort cable

10
Gigabit Ethernet Switch Connection
Figure 10: Used with Gigabit Ethernet switch
DP
source
DP
Display
DP
Display
Tx
Rx
1
1 1
1
2
2
2
2
Rx
Gigabit
switch
DP
Display
Rx
2
1
1
1
1
1
Rx
Rx
Rx
Rx
Rx
Rx
• Connect with the Gigabit Ethernet switch especially
when your Tx or Rx unit has only one signal input/
output port
• The extension distance through CAT. X cable is up
to 100 meters for one layer
DP
Display
1
2
1CAT. X cable
DisplayPort cable

11
