SIIG AV-GM02R3-S1 User manual

HDMI 1.3 over Single CAT5 Direct
Plug-in Extender
P/N: AV-GM02R3-S1

~ 1 ~
Safety and Notice
The AV-GM02R3-S1 HDMI 1.3over Single CAT5 Direct Plug-in Extender has been tested for
conformity to safety regulations and requirements, and has been certified for international use.
However, like all electronic equipments, the AV-GM02R3-S1 should be used with care. Please
read and follow the safety instructions to protect yourself from possible injury and to minimize
the risk of damage to the unit.
Follow all instructions and warnings marked on this unit.
Do not attempt to service this unit yourself, except where explained in this manual.
Provide proper ventilation and air circulation and do not use near water.
Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
Use only the power adapter and power cords and connection cables designed for this unit.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the
device before cleaning.

~ 2 ~
The AV-GM02R3-S1 HDMI 1.3 over Single CAT5 Direct Plug-in Extender boosts up your
video/audio transmission distance up to 25m (80ft) in HDTV 1080i format. With only one cost
effective LAN cable, users can directly plug the receiver in to HDTV sources from DVD players,
Blu-ray Disc player, PS3, PC, and any other kinds of sources compliant with TMDS to distant
display monitors including HDMI/DVI enabled TV sets or LCD PC monitors. This cost effective
flexibility makes HDCP compliant DVD players or PS3 transmit high quality video and audio with
a greater distance at the minimal cost, when integrating several components apart.
The AV-GM02R3-S1 includes two units: transmitting (AV-GM02R3-S1-TX) and receiving
(AV-GM02R3-S1-RX) units. The transmitting unit is used to capture the input HDMI/DVI signals
and carry the signals through one RJ-45 connector into one cost effective Cat-5/5e/6 cable. The
transmission distance between the sending and receiving units can be up to 25m (80ft) under HD
(720p/1080i) or 15m (50ft) under Full HD (1080p). With direct plug-in to the HDTV, users do not
need to have to find a power outlet for the traditional HDMI over CAT5 receiver and can save an
HDMI cable with ease of use.
Features
State-of-the-art Silicon Image (founder of HDMI) chipset embedded for utmost compatibility
and reliability
HDMI 1.3c compliant
Extend the transmission length up to 25m (80ft) from the HDMI sources under HD resolution
(1080i or 720p)
Extend the transmission length up to 15m (50ft) from the HDMI sources under Full HD
resolution (1080p)
HDCP compliant
Pure unaltered uncompressed 7.1ch digital HDMI over UTP/STP cable transmission
Allows direct plug-in to the HDMI displays
Perfectly integrated with other HDMI over CAT5 series products
The length depends on the characteristics and quality of the cables. Higher resolutions and
longer transmission distances require low skew cables (<25ns/100m) for best performance.
Unshielded CAT6 with metal RJ-45 connectors is recommended.
Introduction

~ 3 ~
Specifications & Package Contents
Model Name
AV-GM03E3-S1
AV-GM02R3-S1
Technical
TX
RX
TX
RX
Role of usage
Transmitter [TX]
Receiver [RX]
Transmitter [TX]
Receiver [RX]
HDMI compliance
HDMI 1.3c
HDCP compliance
Yes
Video bandwidth
Single-link 225MHz [2.25Gbps]
Video support
480i / 480p / 720p / 1080i / 1080p60 36-bit color depth
Transmission
over LAN
Full HD
[1080p]
40m [130ft] for CAT5e
50m [165ft] for CAT6
15m [50ft] for CAT5e
18m [65ft] for CAT6
HD
[1080i/720p]
50m [165ft] for CAT5e
60m [200ft] for CAT6
25m [80ft] for CAT5e
30m [100ft] for CAT6
Audio support
Surround sound [up to 7.1ch) or stereo digital audio
Equalization
8-level digital control at RX
No
Input TMDS signal
1.2 Volts [peak-to-peak]
Input DDC signal
5 Volts [peak-to-peak, TTL]
ESD protection
[1] Human body model —±19kV [air-gap discharge] & ±12kV [contact
discharge]
[2] Core chipset —±8kV
PCB stack-up
4-layer board [impedance control —differential 100; single 50]
Input
1x HDMI
1x RJ-45
1x HDMI
1x RJ-45
Output
1x RJ-45
1x HDMI
1x RJ-45
1x HDMI
HDMI connector
Type A [19-pin female]
RJ-45 connector
WE/SS 8P8C with 2 LED indicators
Rotary switch
Mode
EQ
Mode
None
Mechanical
AV-GM03E3-S1
AV-GM03E3-S1
AV-GM02R3-S1-TX
AV-GM02R3-S1-RX
Housing
Metal
enclosure
Metal
enclosure
Metal enclosure
Plastic molding
Dimensions
[L x W x H]
Model
[TX/RX] –93 x 60 x 25mm
[3.7”x2.4”x1”]
[TX] –93 x 60 x 25mm [3.7”x2.4”x1”]
[RX] –45 x 25 x 22mm [1.8”x1”x0.9”]
Package
270 x 175 x 80mm [10.6”x6.9”x3.1”]
Carton
450 x 370 x 300mm (1’5.7”x1’2.6”x11.8”]
Weight
Model
405g [14oz]
340g [12oz]
Package
815g [1.8 lbs]
685g [1.5 lbs]
Fixedness
Wall-mounting case
Power supply
5V 2A DC
5V 2A DC
5V 2A DC
None
Power consumption
1 Watt [max]
Operation temperature
0~40C [32~104F]
Storage temperature
-20~60C [-4~140F]
Relative humidity
20~90% RH [no condensation]
Package Contents
1x AV-GM03E3-S1
2x 5V power adapter
1x User Manual
1x AV-GM02R3-S1 [TX & RX]
1x 5V power adapter
1x User Manual

~ 4 ~
Front Panel —Transmitting Unit AV-GM02R3-S1-TX
MODE: 0 = [Video] –supports up to HDMI 1.3 output. [Audio] –supports up to 7.1ch output
1 = [Video] –supports up to HDMI 1.3 output. [Audio] –locks to stereo audio output
2 = [Video] –locks to HDMI 1.2 output. [Audio] –supports up to 7.1ch output
3 = [Video] –locks to HDMI 1.2 output. [Audio] –locks to stereo audio output
4 = [Video] –DVI display mode. [Audio] –no audio output
5 = [Safe Mode] –uses default EDID1with video supported up to 1080p and stereo
audio
6 = [Default Mode] –uses default EDID2with video supported up to 1080p and 7.1ch
audio
7 = [EDID Learning Mode] –learns EDID3from the display
Note for EDID (Extended Display Identification Data) learning
1. Please connect the display which you want to read EDID with a HDMI cable to the
transmitter’s HDMI-IN and turn Mode to 7 so the TX can learn the EDID information from
the connected HDTV. The LED on the RJ45-OUT of TX will dim and light again in a few
seconds, which indicates the EDID learning process is completed.
2. Turn Mode clockwise from Mode 7 to Mode 0 or Mode 1 for desirable audio setting and
enjoy the experience. DO NOT let the rotary arrow pass by Mode 6 which will erase the
EDID just learned and restore the default EDID.
3. If use Mode 6 EDID(1080p),turn Mode clockwise from Mode 6 to Mode 0~4.
If use Mode 5 EDID(1080p),turn Mode anticlockwise from Mode 5 to Mode 0~4
Panel Descriptions

~ 5 ~
Rear Panel —Transmitting Unit AV-GM02R3-S1-TX
+5V DC: Connect to 5V DC power supply.
RJ45-OUT:Plug in a CAT-5/5e/6 LAN cable that needs to be linked to the RJ-45 connector of the
receiving unit AV-GM02R3-S1-RX.
1. Connect your HDMI/DVI source (such as a Blu-ray Disc player) to the transmitting unit
AV-GM02R3-S1-TX.
2. Plug-in the receiving unit AV-GM02R3-S1-RX to your HDMI display (such as a HDTV or a
projector).
3. Connect your CAT-5/5e/6 LAN cable between the transmitting and receiving units.
4. Make sure your CAT-5/5e/6 LAN cable is tightly connected and not loose.
5. Plug in 5V DC power cord to the power jack of the transmitting unit AV-GM02R3-S1-TX.
Hardware Installation

~ 6 ~
1. Turn on AV-GM02R3-S1-TX.
2. Turn the Mode of AV-GM02R3-S1-TX counterclockwise from 0 (for surround sound) or 1 (for
stereo) to 7.
3. Use a HDMI cable to connect AV-GM02R3-S1-TX & the display (better not connect to video
source). The LED on the RJ-45 of AV-GM02R3-S1-TX will dim and light again, which indicates
the EDID learning process is finished.
4. Turn the Mode of AV-GM02R3-S1-TX clockwise from 7 to 0 (for surround sound) or 1 (for
stereo). The most important thing is don’t let the rotary arrow pass through 6 which will erase the
EDID just learned and restore to default EDID.
5. Connect AV-GM02R3-S1-TX and the video source through a HDMI cable and enjoy the
experience.
EDID Learning

~ 7 ~
1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to
retrieve and provide DVI/HDMI EDID information.
2. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e 125MHz
LAN cable and ASTRODESIGN Video Signal Generator VG-859C.
3. The transmission length is largely affected by the type of LAN cables, the type of HDMI
sources, and the type of HDMI display. The testing result shows solid LAN cables (usually in
bulk cable 300m or 1000ft form) can transmit a lot longer signals than stranded LAN cables
(usually in patch cord form). Shielded STP cables are better suit than unshielded UTP cables.
A solid UTP CAT5e cable shows longer transmission length than stranded STP CAT6 cable. For
long extension users, solid LAN cables are your only choice.
4. EIA/TIA-568-B termination (T568B) for LAN cables is recommended for better performance.
5. To reduce the interference among the unshielded twisted pairs of wires in LAN cable, you can
use shielded LAN cables to improve EMI problems, which is worsen in long transmission.
6. Because the quality of the LAN cables has the major effects in how long transmission
distance will be made and how good is the received display, the actual transmission length is
subject to your LAN cables. For resolution greater than 1080i or 1280x1024, a CAT6 cable is
recommended.
7. If your HDMI display has multiple HDMI inputs, it is found that the first HDMI input [HDMI
input #1] generally can produce better transmission performance among all HDMI inputs.
Performance Guide for HDMI over LAN Cable Transmission
Performance rating
Type of LAN cable
Wiring
Shielding
CAT5
CAT5e
CAT6
Solid
Unshielded
(UTP)



Shielded (STP)



Stranded
Unshielded
(UTP)



Shielded (STP)



Notice

~ 8 ~
Termination
Please use EIA/TIA-568-B termination (T568B) at any time

~ 9 ~
The SELLER warrants the AV-GM02R3-S1 HDMI over Single CAT5 Direct Plug-in Extender to be
free from defects in the material and workmanship for 3 years from the date of purchase from
the SELLER or an authorized dealer. Should this product fail to be in good working order within 3
years warranty period, The SELLER, at its option, repair or replace the unit, provided that the unit
has not been subjected to accident, disaster, abuse or any unauthorized modifications including
static discharge and power surge. This warranty is offered by the SELLER for its BUYER with direct
transaction only. This warranty is void if the warranty seal on the metal housing is broken.
Unit that fails under conditions other than those covered will be repaired at the current price
of parts and labor in effect at the time of repair. Such repairs are warranted for 90 days from the
day of reshipment to the BUYER. If the unit is delivered by mail, customers agree to insure the
unit or assume the risk of loss or damage in transit. Under no circumstances will a unit be
accepted without a return authorization number.
The warranty is in lieu of all other warranties expressed or implied, including without
limitations, any other implied warranty or fitness or merchantability for any particular purpose,
all of which are expressly disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan are
responsible for shipping charges to and from the SELLER. Cables and power adapters are limited
to a 30 day warranty and must be free from any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be accurate.
However, The SELLER assumes no responsibility for any inaccuracies that may be contained in
this manual. The SELLER will NOT be liable for direct, indirect, incidental, special, or
consequential damages resulting from any defect or omission in this manual, even if advised of
the possibility of such damages. Also, the technical information contained herein regarding the
AV-GM02R3-S1 features and specifications is subject to change without further notice.
Limited Warranty

~ 10 ~
April, 2018
Support
For more info or tech support
http://www.siig.com/support
