SIIG DP CyberSerial 4S PCIe User manual

1
04-0995A
Introduction
The DP CyberSerial 4S PCIe high-speed serial I/O card
provides four additional 9-pin serial ports.
Keyfeatures and Benefits
•Compliant with PCI Express Base Specification
Revision 1.1
•PCI Express 1-lane (x1) serial I/O card works with
PCI Express slots with different lane width
•Installs in any available PCI Express slot and
provides four 9-pin RS232 serial ports via a fan-out
cable
•Spare enhanced low profile bracket is included to
work in low profile chassis
•256-byte FIFO buffers dramatically increase data
transmit/receive speed and supports data rates up
to 921 Kbps
System Requirements
•PCI Express-enabled system with an available PCI
Express slot
•Windows® 10(32-/64-bit) / 8.x (32-/64-bit) / 7 (32-/
64-bit) / Vista (32-/64-bit) / XP (32-/64-bit) / Server
2003 & 2008 (32-/64-bit) / Server 2008 R2 / 2000
•Windows® Embedded 8 / 7
DP CyberSerial 4S PCIe
Installation Guide

2
PackageContents
•DP CyberSerial 4S PCIe
• Spare enhanced low profile bracket
• 4-port fanout cable & "Y" split power cable
• Driver CD
• Installation guide
Layout
Power connector*
Jumper settings
Fanout cable connector
Jumper Settings (J1-J4)
Short 2-3 = 0 volts
Short 1-2 = 5V
Short 3-4 = 12V
* Note: If the serial port(s) requires power output,
connect the system power source to board's power
connector,otherwiseleaveitunconnected.However,
most serial devices do not require additional power
through the serial port. Refer to your serial device's
manual for more information. The jumpers can be
omitted if no power output is required.
S1 (J1)
S3 (J3)
S4 (J4) S2 (J2)
Figure 1: DP CyberSerial 4S PCIe
1 2 3 4 1 2 3 4

3
Board connector
9-pin serial
4-port Fan-out Cable
Figure 2: 4-port fanout cable
Hardware Installation
Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer’s case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges.
Note: For low profile systems, remove the installed full
size bracket and install the spare low profile bracket now.
1. Turn OFF the power to your computer and any
other connected peripheral devices.
2. Unplug the power cord from the back of the
computer. Remove the computer cover.
3. Remove the slot bracket from an available PCIe slot.
4. Set J1-J4 jumpers (this step is optional). See Jumper
Settings (J1-J4) on page 2for more information.
5. Carefully align the card's bus connector with the
selected PCIe slot on the motherboard. Push the
board down firmly, but gently, until it is well seated.

4
6. Secure the card with the slot bracket holding screw.
7. Replacethe computercover andreconnect thepower
cord.
8. Connect the Mini 4-port fan-out cable to the fan-out
cable connector on the card.
Windows Driver Installation
Follow below instructions to install the driver for the DP
CyberSerial 4S PCIe :
1. After Hardware Installation, start the computer and
insert the driver CD.
2. Browse the driver CD and choose the folder
according to your OS. Then, choose 32-bit or 64-bit
folder accordingly.
3. Run StnSetup.exe, and follow the on-screen steps
to install the driver.
4. When"Installation completed"message shows, click
Exit.
5. Restart the computer and it's ready for use now.
Win 8/7 Embedded Driver Installation
Follow the instructions to install the driver.
1. Browse the driver CD and go to Windows
Embedded / Win8 or Win7 folder.
2. Copy the Mf folder to your Local Disk (C:drive).
3. Enter the Mf folder on your C: drive, and double
click (x64 or x86) according to your version of
Windows Embedded.
4. Click Yes at User Account Control window if
prompted.

5
5. When the message appears "Do you want to restart
...?", press Y key.
6. After restarting, browse the CD and go to Windows
Embedded / Win8 orWin7 /32-bit or 64-bit folder.
7. Run StnSetup.exe and follow the on-screen steps to
install the driver.
To Verify Installation
1. Right click This PC, Computer or My computer on
the desktop, click Manage, then click Device
Manager.
2. Double click Ports (COM&LPT), and PCIe to High
Speed Serial Port (COMx) should be displayed.
Changing COM Port Number
Some serial devices need a specific port in order to work.
If your device works properly, do not make any changes.
1. Double click PCIe to High Speed Serial Port
(COMx). Refer to To Verify Installation section for
more details if needed.
2. Click the Port Settings tab.
3. Clickthedownarrownexttothechangeportnumber
under Port Settings table. Select a COM port that is
not in use, then click OK.
4. Restart your system to take effect.

6
Blank page

7
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site
at www.siig.com and click Support. Our online support database is updated
daily with new drivers and solutions. Answers to your questions could be just
a few clicks away. You can also submit questions online and a technical support
analyst will promptly respond.
SIIG offers a 2-year manufacturer warranty with this product. This warranty
covers the original purchaser and guarantees the product to be free of any defects
in materials or workmanship for two (2) years from the date of purchase of the
product. This warranty is not transferable and is available only to the original
purchaser of the product.
SIIGwill,atourdiscretion,repairorreplace(withanidenticalproductorproduct
having similar features and functionality) the product if defective in materials or
workmanship. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state. Please see our web site for more
warranty details.
If you encounter any problems with this product, please follow the procedures
below.
A) If it is within the store's return policy period, please return the product to the
store where you purchased it.
B) Ifyourpurchasehaspassedthestore'sreturnpolicyperiod, please follow these
steps to have the product repaired or replaced.
Step 1: Submit your RMA request. Go to www.siig.com, clickSupport,then
Request A Product Replacement to submit a request to SIIG RMA or fax
arequestto 510-657-5962. Your RMA request will be processed, if the product
is determined to be defective, an RMA number will be issued.
Step 2: After obtaining an RMA number, ship the product.
•Properly pack the product for shipping. All software, cable(s) and any
other accessories that came with the original package must be included
• Include a copy of your original sales receipt inside the package with date
of purchase and place of purchase circled and clearly visible
•Clearly write your RMA number on the top of the returned package. SIIG
willrefuse to accept any shipping package, and will not be responsible for
a product returned without an RMA number posted on the outside of the
shipping carton
•You are responsible for the cost of shipping to SIIG. Ship the product to
the following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
•SIIG will ship the repaired or replaced product via Ground in the U.S. and
International Economy outside of the U.S. at no cost to the customer
