Silent Gliss 3000 User manual

2. Cleat 3. Tie cord
to itself
4. Cord tidy
(Silent Gliss
part No. 3799)
1. Clothes peg
or bulldog
clip
WARNING Parents should realise that children could accidentally strangle in window blind
cords. Keep the cords out of the reach of children using one of these devices.
Silent Gliss®
3000 Cord Drawn Curtain Track
Fitting Instructions
1
Firmly screw 3630 brackets to
wall or ceiling. The two outside
brackets should be located
12.5cm (5”) in from the ends
of track to provide stability.
Remaining brackets should be
equally spaced along track
(approx. every 60cm/2’).
Screw for wall or
ceiling with
universal bracket.
2
To install track
simply locate as
shown and press
onto bracket in
direction
indicated. Removal: Push upwards
and forwards.
4
3EXTRA SUPPORT FOR CORD DROP
It is often desirable when the track is wall-fixed to make an extra fixing point over the end
where the cord is pulled to give greater rigidity. A special tubular spacer and 11/2” No. 8 screw
are supplied with all systems pre-packed by Silent Gliss.
P. T. O. These instructions are continued on reverse side.
TRIMMING AND/OR ADJUSTING INSTRUCTIONS
If it is necessary to shorten your 3000 curtain track follow all instructions (1-8 overleaf) for
pair stacking. For single stacking follow steps 1, 2, 4, 5, 6 & 7 only. To adjust the point where
the curtains meet, follow steps 3 and 8 only. If cord drop is required at opposite ends to that
supplied, simply follow step 3, pull cord through and the follow step 8.
1. Unscrew
nylon cover.
2. Drill hole in wall
directly behind the ‘X’,
insert screw through hole
and spacer and screw
firmly into position.
Replace nylon cover.
3000

Where the track is slotted to allow insertion of
extra gliders without removing end pieces,
remove spingstops and insert gliders equally
at each side, replace springstops.
1. Place track face down on bench or floor
and operate to take gliders to centre.
2. Slacken screws and pull end piece free.
3. Carefully prise out cord retaining pin
from visible pilot runner.
4. Measure amount to be trimmed off
exposed end of track and mark. Where the
track is slotted the slot will no longer be
usable. Discard springstops.
5. Pull cords through
into glider channel and
clear of cutting point.
6. Cut track squarely with
junior hacksaw and carefully
de-burr with sharp knife or
small file, paying particular
attention to ends of cord
channels.
7. Pull cords back into cord
channels and check that they
operate freely – replace end
piece.
8. Move both pilot runners to
the extreme ends of the track
(i.e. in a fully open position) –
hold cords in tension and
press fully home cord
retaining pin into pilot runner.
(The pin must go through
cord and if inserted correctly
a ‘click’ will be heard.)
Two gliders plus overlap or, if
no overlap fitted, four gliders
should remain between pilot
runners.
Extras/Accessories (not supplied)
Two lengths of 3000 can be joined with a 3620
connecting bridge. Fixed or adjustable extension
brackets are also available to enable you to use
your 3000 track with a second Silent Gliss track to
hold nets, etc. Ask your dealer. 3000 can be bent
to order for bay windows, etc. from your stockist.
THIS TRACK CANNOT
BE BENT AT HOME.
Silent Gliss Limited
Star Lane, Margate, Kent CT9 4EF, England
Telephone: [phone] Fax: [phone]
E-mail: [email protected] www.silentgliss.co.uk
12/02
