Silicon Laboratories C8051F93 Series User manual

Rev 0.7 5/14 Copyright © 2014 by Silicon Laboratories C8051F93x/92x
C8051F93x/92x
C8051F930 DEVELOPMENT KIT USER’SGUIDE
1. Relevant Devices
The C8051F930 Development Kit is intended as a development platform for the microcontrollers in the
C8051F93x-C8051F92x MCU family.
Notes:
1. The target board included in this kit is provided with a pre-soldered C8051F930 MCU (LQFP32 package).
2. Code developed on the C8051F930 can be easily ported to the other members of this MCU family.
3. Refer to the C8051F93x-C8051F92x data sheet for the differences between the members of this MCU
family.
2. Kit Contents
The C8051F930 Development Kit contains the following items:
C8051F930 Target Board
C8051Fxxx Development Kit Quick-Start Guide
AC to DC Power Adapter
USB Debug Adapter (USB to Debug Interface)
2 USB Cables
2 AAA Batteries
CD-ROM
Figure 1. C8051F930 Target Board

C8051F93x/92x
2 Rev 0.7
3. Hardware Setup Using a USB Debug Adapter
The target board is connected to a PC running the Silicon Laboratories IDE via the USB Debug Adapter as shown
in Figure 2.
1. Connect the USB Debug Adapter to the DEBUG connector on the target board with the 10-pin ribbon
cable.
2. Connect one end of the USB cable to the USB connector on the USB Debug Adapter.
3. Verify that a shorting block is installed on J17 and that SW5 is in the ON position.
4. Connect the other end of the USB cable to a USB Port on the PC.
5. Connect the ac/dc power adapter to power jack P1 on the target board (Optional).
Notes:
Use the Reset button in the IDE to reset the target when connected using a USB Debug Adapter.
Remove power from the target board and the USB Debug Adapter before connecting or disconnecting the
ribbon cable from the target board. Connecting or disconnecting the cable when the devices have power
can damage the device and/or the USB Debug Adapter.
Figure 2. Hardware Setup Using a USB Debug Adapter
PC
USB
Cable
AC/DC
Adapter
Target Board
P0.2 P0.3
J3
J4
J2
`
P3
CP
2103
U3
P2
DEBUG
J9
USB POWER
RESET
P1.6
P1.5
POWER OFF BEFORE
SW4
SWITCHING MODE
2 CELL 1 CELL
J17
IMEASURE
H2
SILICON LABS
www.silabs.com
H1
J6 VDD/DC+
J5
J7 J13
F930
U1
J14
J11
J10
VBAT
WALL_PWR
AAA_BAT
COIN_CELL
TOUCH SENSE SWITCH
P2.0 TOUCH SENSE SWITCH P2.1
J15
J16
R15
J12J8
+3VD
+1VD
VBAT
J1
SW5
ON
OFF
Silicon Laboratories
USB DEBUG ADAPTER
Run
Stop Power
USB Debug
Adapter

C8051F93x/92x
Rev 0.7 3
4. Software Setup
Simplicity Studio greatly reduces development time and complexity with Silicon Labs EFM32 and 8051 MCU
products by providing a high-powered IDE, tools for hardware configuration, and links to helpful resources, all in
one place.
Once Simplicity Studio is installed, the application itself can be used to install additional software and
documentation components to aid in the development and evaluation process.
Figure 3. Simplicity Studio
The following Simplicity Studio components are required for the C8051F930 Development Kit:
8051 Products Part Support
Simplicity Developer Platform
Download and install Simplicity Studio from www.silabs.com/8bit-software or www.silabs.com/simplicity-studio.
Once installed, run Simplicity Studio by selecting StartSilicon LabsSimplicity StudioSimplicity Studio
from the start menu or clicking the Simplicity Studio shortcut on the desktop. Follow the instructions to install the
software and click Simplicity IDE to launch the IDE.
The first time the project creation wizard runs, the Setup Environment wizard will guide the user through the
process of configuring the build tools and SDK selection.
In the Part Selection step of the wizard, select from the list of installed parts only the parts to use during
development. Choosing parts and families in this step affects the displayed or filtered parts in the later device
selection menus. Choose the C8051F93x family by checking the C8051F93x/92x check box. Modify the part
selection at any time by accessing the Part Management dialog from the WindowPreferencesSimplicity
StudioPart Management menu item.
Simplicity Studio can detect if certain toolchains are not activated. If the Licensing Helper is displayed after
completing the Setup Environment wizard, follow the instructions to activate the toolchain.

C8051F93x/92x
4 Rev 0.7
4.1. Running Blinky
Each project has its own source files, target configuration, SDK configuration, and build configurations such as the
Debug and Release build configurations. The IDE can be used to manage multiple projects in a collection called a
workspace. Workspace settings are applied globally to all projects within the workspace. This can include settings
such as key bindings, window preferences, and code style and formatting options. Project actions, such as build
and debug are context sensitive. For example, the user must select a project in the Project Explorer view in order
to build that project.
To create a project based on the Blinky example:
1. Click the Software Examples tile from the Simplicity Studio home screen.
2. In the Kit drop-down, select C8051F930 Development Kit, in the Part drop-down, select C8051F930, and
in the SDK drop-down, select the desired SDK. Click Next.
3. Select Example and click Next.
4. Under C8051F930 Development Kit in the Blinky folder, select F93x-92x Blinky and click Finish.
5. Click on the project in the Project Explorer and click Build, the hammer icon in the top bar. Alternatively,
go to ProjectBuild Project.
6. Click Debug to download the project to the hardware and start a debug session.
7. Press the Resume button to start the code running. The LED should blink.
8. Press the Suspend button to stop the code.
9. Press the Reset the device button to reset the target MCU.
10. Press the Disconnect button to return to the development perspective.
4.2. Simplicity Studio Help
Simplicity Studio includes detailed help information and device documentation within the tool. The help contains
descriptions for each dialog window. To view the documentation for a dialog, click the question mark icon in the
window:
This will open a pane specific to the dialog with additional details.
The documentation within the tool can also be viewed by going to HelpHelp Contents or HelpSearch.

C8051F93x/92x
Rev 0.7 5
4.3. Simplicity Configurator
The Simplicity Configurator is a configuration and code generation tool. This utility helps accelerate development
by automatically generating initialization source code to configure and enable the on-chip resources needed by
most design projects. In just a few steps, the wizard creates complete startup code for a specific Silicon Labs MCU.
To create a new Simplicity Configurator project:
1. Click the Create new project link from the welcome screen or go to FileNewSilicon Labs MCU
Project.
2. In the Kit drop-down, select C8051F930 Development Kit or None, in the Part drop-down, select
C8051F930, and in the SDK drop-down, select the desired SDK. Click Next.
3. Select Simplicity Configurator Program and click Next.
4. Fill in the Project name and select the desired device. The C8051F930-G-GQ-LQFP device is on the
C8051F930 Target Board. Click Finish.
The Simplicity Configurator project displays properties for each peripheral. To configure a peripheral, click on the
DefaultMode Peripherals tab at the bottom and click on a peripheral. Checking the box for a peripheral will add it
to code generation. Once a peripheral is selected, configure the registers using the Properties view. Select a new
value for a property with either an input box or a drop-down menu and press Enter to set it.
Figure 4. Simplicity Configurator – Configuring Peripheral Properties

C8051F93x/92x
6 Rev 0.7
To configure pins, click on the DefaultMode Port I/O tab at the bottom of main window. Clicking on a pin brings up
a property window for the pin. Clicking anywhere else in the main window opens a property window for the
crossbar. Select multiple pins with Ctrl + left click or mouse dragging over the desired set of pins. The package
diagram displays the configured peripherals on the pins, including non-crossbar signals (i.e. ADC inputs).
Code generation updates every time the configuration project saves. After configuring the device, add any non-
initialization code, build, and debug the same as with any other project.
More information on Simplicity Configurator can be found in AN0823: Simplicity Configurator User’s Guide and
AN0821: Simplicity Studio C8051F85x Walkthrough. Application notes can be found on
www.silabs.com/8bit-appnotes.
Figure 5. Simplicity Configurator – Configuring Port I/O

C8051F93x/92x
Rev 0.7 7
4.4. CP210x USB to UART VCP Driver Installation
The MCU Card includes a Silicon Labs CP210x USB-to-UART Bridge Controller. Device drivers for the CP210x
need to be installed before the PC software can communicate with the MCU through the UART interface. Use the
drivers included CD-ROM or download the latest drivers from the website (www.silabs.com/interface-software).
1. If using the CD-ROM, the CP210x Drivers option will launch the appropriate driver installer. If downloading
the driver package from the website, unzip the files to a location and run the appropriate installer for the
system (x86 or x64).
2. Accept the license agreement and follow the steps to install the driver on the system. The installer will let
you know when your system is up to date. The driver files included in this installation have been certified by
Microsoft.
3. To complete the installation process, connect the included USB cable between the host computer and the
COM PORT USB connector (J5) on the MCU Card. Windows will automatically finish the driver installation.
Information windows will pop up from the taskbar to show the installation progress.
4. If needed, the driver files can be uninstalled by selecting the Windows Driver Package—Silicon
Laboratories... option in the Programs and Features window.

C8051F93x/92x
8 Rev 0.7
4.5. Silicon Labs Battery Life Estimator
The Battery Life Estimator is a system design tool for battery operated devices. It allows the user to select the type
of battery they are using in the system and enter the supply current profile of their application. Using this
information, it performs a simulation and provides an estimated system operating time. The Battery Life Estimator
is shown in Figure 6.
Figure 6. Battery Life Estimator Utility
From Figure 6, the two inputs to the Battery Life Estimator are battery type and discharge profile. The utility
includes battery profiles for common battery types such as AAA, AA, A76 Button Cell, and CR2032 coin cell. The
discharge profile is application-specific and describes the supply current requirements of the system under various
supply voltages and battery configurations. The discharge profile is independent of the selected power source.
Several read-only discharge profiles for common applications are included in the pulldown menu. The user may
also create a new profile for their own applications.
To create a new profile:
1. Select the profile that most closely matches the target application or choose the "Custom Profile".
2. Click Manage.
3. Click Duplicate.
4. Click Edit.
Profiles may be edited with the easy-to-use GUI (shown in Figure 7).

C8051F93x/92x
Rev 0.7 9
Figure 7. Battery Life Estimator Discharge Profile Editor
The Discharge Profile Editor allows the user to modify the profile name and description. The four text entry boxes
on the left hand side of the form allow the user to specify the amount of time the system spends in each power
mode. On the right hand side, the user may specify the supply current of the system in each power mode.
Since supply current is typically dependent on supply voltage, the discharge profile editor provides two columns for
supply current. The V2 and V1 voltages at the top of the two columns specify the voltages at which the current
measurements were taken. The Battery Life Estimator creates a linear approximation based on the input data and
is able to feed the simulation engine with an approximate supply current demand for every input voltage.
The minimum system operating voltage input field allows the system operating time to stop increasing when the
simulated battery voltage drops below a certain threshold. This is primarily to allow operating time estimates for
systems that cannot operate down to 1.8 V, which is the voltage of two fully drained single-cell batteries placed in
series.

C8051F93x/92x
10 Rev 0.7
The wakeup frequency box calculates the period of a single iteration through the four power modes and displays
the system wake up frequency. This is typically the "sample rate" in low power analog sensors.
Once the battery type and discharge profile is specified, the user can click the "Simulate" button to start a new
simulation. The simulation engine calculates the estimated battery life when using one single-cell battery, two
single-cell batteries in series, and two single-cell batteries in parallel. Figure 8 shows the simulation output window.
Figure 8. Battery Life Estimator Utility Simulation Results Form
The primary outputs of the Battery Life Estimator are an estimated system operating time and a simulated graph of
battery voltage vs. time. Additional outputs include estimated battery capacity, average current, self-discharge
current, and the ability to export graph data to a comma delimited text file for plotting in an external graphing
application.

C8051F93x/92x
Rev 0.7 11
5. Target Board
The C8051F930 Development Kit includes a target board with a C8051F930 device pre-installed for evaluation and
preliminary software development. Numerous input/output (I/O) connections are provided to facilitate prototyping
using the target board. Refer to Figure 9 for the locations of the various I/O connectors. Figure 11 on page 13
shows the factory default shorting block positions.
P1 Expansion connector (96-pin)
P2 Power connector (accepts input from 7 to 15 VDC unregulated power adapter)
P3 USB connector (connects to PC for serial communication)
J1 Enable/Disable VBAT Power LED
J2, J3, J4 Port I/O headers (provide access to Port I/O pins)
J5 Enable/Disable VDD/DC+ Power LED
J6 Provides an easily accessible ground clip
J7 Connects pin P0.7 (IREF0 Output) to resistor R14 and capacitor C19
J8 Connects P0.2 and P0.3 to switches and P1.5 and P1.6 to LEDs
J9 DEBUG connector for Debug Adapter interface
J10, J11 Selects the power supply source (Wall Power, AAA Battery, or Coin Cell)
J12 Connects Port I/O to UART0 interface
J13 Connects external VREF capacitor to the P0.0/VREF
J14 Connects the PCB ground plane to P0.1/AGND
J15 Connects negative potentiometer (R14) terminal to pin P1.4 or to GND
J16 Connects the potentiometer (R14) wiper to P0.6/CNVSTR
J17 Creates an open in the power supply path to allow supply current measurement
H1 Analog I/O terminal block
H2 Provides terminal block access to the input and output nodes of J17
SW4 Switches the device between One-Cell (0.9–1.8 V supply) or Two-Cell (1.8–3.6 V) mode
SW5 Turns power to the MCU on or off
Figure 9. C8051F930 Target Board
P0.2 P0.3
Pin 1
Pin 2
J3
J4
J2
`
P3
CP
2103
U3
P2
DEBUG
J9
USB POWER
RESET
P1.6
P1.5
POWER OFF BEFORE
SW4
SWITCHING MODE
2 CELL 1 CELL
J17
IMEASURE
H2
SILICON LABS
www.silabs.com
H1
Pin 1
J6 VDD/DC+
J5
J7 J13
F930
U1
J14
J11
J10
VBAT
WALL_PWR
AAA_BAT
COIN_CELL
TOUCH SENSE SWITCH
P2.0 TOUCH SENSE SWITCH P2.1
P1.4
J15
GND
J16
R15
J12J8
+3VD
+1VD
VBAT
J1
SW5
ON
OFF
P1
SW2 SW3
PORT2
PORT1 SW1
PORT0

C8051F93x/92x
12 Rev 0.7
The following items are located on the bottom side of the board. See Figure 10.
BT1 Battery Holder for 1.5 V AAA. Use for one-cell or two-cell mode.
BT2 Battery Holder for 1.5 V AAA. Use for two-cell mode only.
BT3 Battery Holder for 3 V Coin Cell (CR2032).
BT4 Battery Holder for 1.5 V Button Cell (A76 or 357).
Figure 10. Bottom of C8051F930 Target Board
NEG
POS NEG
POS
BT4
BT2 BT1
BT3
(CR2032)
(A76 or 357)
(AAA)(AAA)
Note: BT2 is
only used in
two-cell mode.

C8051F93x/92x
Rev 0.7 13
5.1. Target Board Shorting Blocks: Factory Defaults
The C8051F930 target board comes from the factory with pre-installed shorting blocks on many headers. Figure 11
shows the positions of the factory default shorting blocks.
Figure 11. C8051F930 Target Board Shorting Blocks: Factory Defaults
P0.2 P0.3
Pin 1
Pin 2
J3
J4
J2
`
P3
CP
2103
U3
P2
DEBUG
J9
USB POWER
RESET
P1.6
P1.5
POWER OFF BEFORE
SW4
SWITCHING MODE
2 CELL 1 CELL
J17
IMEASURE
H2
SILICON LABS
www.silabs.com
H1
Pin 1
J6 VDD/DC+
J5
J7 J13
F930
U1
J14
J11
J10
VBAT
WALL_PWR
AAA_BAT
COIN_CELL
TOUCH SENSE SWITCH
P2.0 TOUCH SENSE SWITCH P2.1
P1.4
J15
GND
J16
R15
J12J8
+3VD
+1VD
VBAT
J1
SW5
ON
OFF
P1
SW2 SW3
PORT2
PORT1 SW1
PORT0

C8051F93x/92x
14 Rev 0.7
5.2. Target Board Power Options and Current Measurement
The C8051F930 Target Board supports three power options, selectable by the three-way header (J10/J11). The
power options vary based on the configuration (one-cell or two-cell mode) selected by SW4. Power to the MCU
may be switched on/off using the power switch (SW5). Important Note: The power switch (SW5) must be in the
OFF position prior to switching between one-cell and two-cell mode using SW4. The power options are
described in the paragraphs below.
5.2.1. Wall Power
When the J10/J11 three-way header is set to WALL_PWR, the C8051F930 Target Board may be powered from the
following power sources:
9 VDC power using the ac to dc power adapter (P2)
5 VDC USB VBUS power from PC via the USB Debug Adapter (J9)
5 VDC USB VBUS power from PC via the CP2103 USB connector (P3)
All the three power sources are ORed together using reverse-biased diodes (D1, D2, D3), eliminating the need for
headers to choose between the sources. The target board will operate as long as any one of the power sources is
present. The ORed power is regulated to a 3.3 V dc voltage using a LDO regulator (U2). The output of the regulator
powers the +3 VD net on the target board.
If SW4 is configured to select two-cell mode, the VBAT supply net on the target board is powered directly from the
+3 VD net. If SW4 is configured to select one-cell mode, the VBAT supply net is powered directly from the +1 VD.
This power supply net takes +3 VD and passes it through a 1.65 V LDO. The LDO’s output voltage is variable and
can be set by changing the value of resistor R32.
5.2.2. AAA Battery
When the J10/J11 three-way header is set to AAA_BAT, the C8051F930 Target Board may be powered from a
single AAA battery inserted in BT1 or from the series combination of the AAA batteries inserted in BT1 and BT2. A
single battery is selected when SW4 is configured to one-cell mode. The two AAA batteries configured in series to
provide a voltage of ~3 V are selected when SW4 is configured to two-cell mode.
5.2.3. Coin Cell Battery
When the J10/J11 three-way header is set to COIN_CELL, the C8051F930 Target Board may be powered from a
single 1.5 V Alkaline (A76) or Silver Oxide (357) button cell inserted in BT4 or from a single 3 V Lithium (CR2032)
coin cell inserted in BT3. The button cell (BT4) is selected when SW4 is configured to one-cell mode, and the coin
cell (BT3) is selected when SW4 is configured to two-cell mode.
5.2.4. Measuring Current
The header (J17) and terminal block (H2) provide a way to measure the total supply current flowing from the power
supply source to the MCU. The measured current does not include any current from the VBAT LED (DS2), the
address latch (U4) or the quiescent current from the power supply; however, it does include the current used by
any LEDs powered from the VDD/DC+ supply net or sourced through a GPIO pin. See the target board schematic
in Figure 12 through Figure 14 for additional information.
J11
J10
VBAT
WALL_PWR
AAA_BAT
COIN_CELL
J11
J10
VBAT
WALL_PWR
AAA_BAT
COIN_CELL
J11
J10
VBAT
WALL_PWR
AAA_BAT
COIN_CELL

C8051F93x/92x
Rev 0.7 15
5.3. System Clock Sources
5.3.1. Internal Oscillators
The C8051F930 device installed on the target board features a factory calibrated programmable high-frequency
internal oscillator (24.5 MHz base frequency, ±2%) and a low power internal oscillator (20 MHz ±10%). After each
reset, the low power oscillator divided by 8 results in a default system clock frequency of 2.5 MHz (±10%). The
selected system clock and the system clock divider may be configured by software for operation at other
frequencies. For low-frequency operation, the C8051F930 features a smaRTClock real time clock. A 32.768 kHz
Watch crystal (Y2) is included on the target board. If you wish to operate the C8051F930 device at a frequency not
available with the internal oscillators, an external crystal may be used. Refer to the C8051F93x-C8051F92x data
sheet for more information on configuring the system clock source.
5.3.2. External Oscillator Options
The target board is designed to facilitate the installation of an external crystal (Y1). Install a 10 Mresistor at R9
and install capacitors at C20 and C21 using values appropriate for the crystal you select. If you wish to operate the
external oscillator in capacitor or RC mode, options to install a capacitor or an RC network are also available on the
target board. Populate C21 for capacitor mode, and populate R16 and C21 for RC mode. Refer to the C8051F93x-
C8051F92x data sheet for more information on the use of external oscillators.
5.4. Port I/O Headers (J2, J3, J4, J6)
Access to all Port I/O on the C8051F930 is provided through the headers J2, J3, and J4. The header J6 provides
access to the ground plane for easy clipping of oscilloscope probes.

C8051F93x/92x
16 Rev 0.7
5.5. Switches and LEDs
Three push-button switches are provided on the target board. Switch SW1 is connected to the reset pin of the
C8051F930. Pressing SW1 puts the device into its hardware-reset state. Switches SW2 and SW3 are connected to
the C8051F930’s general purpose I/O (GPIO) pins through headers. Pressing SW2 or SW3 generates a logic low
signal on the port pin. Remove the shorting block from the header (J8) to disconnect the switches from the port
pins. The port pin signal is also routed to pins on the J2 and P1 I/O connectors. See Table 1 for the port pins and
headers corresponding to each switch.
Two touch sensitive (contactless) switches are provided on the target board. The operation of these switches
require appropriate firmware running on the C8051F930 MCU that can sense the state of the switch.
Five power LEDs are provided on the target board to serve as indicators. Each of the two regulators has a red LED
used to indicate the presence of power at the output of the regulator. A red USB Power LED turns on when a USB
cable is plugged into the USB connector P3. One power LED is also added to each of the two primary supply nets
powering the MCU (VDD/DC+ and VBAT). The LEDs connected to the supply nets may be disabled by removing
the shorting blocks from J1 and J5.
Two LEDs are connected to GPIO pins P1.5 and P1.6 for use by application software. See Table 1 for the port pins
and headers corresponding to each LED.
A potentiometer (R15) is also provided on the target board for generating analog signals. Place a shorting block on
J16 to connect the wiper to P0.6/CNVSTR. The header J15 allows the negative terminal of the potentiometer to be
tied to GND or to P1.4. When tied to GND, the potentiometer is always enabled and will draw a measurable
amount of supply current. When tied to P1.4, it only draws current when P1.4 is driving a logic 0 and draws no
current when P1.4 is driving a logic 1.
Table 1. Target Board I/O Descriptions
Description I/O Header(s)
SW1 Reset none
SW2 P0.2 J8[5–6]
SW3 P0.3 J8[7–8]
P2.0 (Touch Sense Switch) P2.0 none
P2.1 (Touch Sense Switch) P2.1 none
Red LED (P1.5) P1.5 J8[1–2]
Yellow LED (P1.6) P1.6 J8[3–4]
Red LED (VDD/DC+) VDD/DC+ Supply Net J5
Red LED (VBAT) VBAT Supply Net J1
Red LED (USB Power) USB VBUS none
Red LED (+1 VD Power) +1 VD Regulator Output none
Red LED (+3 VD Power) +3 VD Regulator Output none
Potentiometer (R15) P0.6/P1.4 J15, J16

C8051F93x/92x
Rev 0.7 17
5.6. Expansion I/O Connector (P1)
The 96-pin Expansion I/O connector P1 provides access to all signal pins of the C8051F930 device (except the C2
debug interface signals). In addition, power supply and ground pins are included. A small through-hole prototyping
area is also provided. See Table 2 for a list of pin descriptions for P1.
Table 2. P1 Pin Descriptions
Row A
Pin # Description Row B Pin # Description Row C Pin # Description
1+3VD 1GND 1 nc
2nc 2nc 2nc
3nc 3nc 3nc
4nc 4nc 4nc
5nc 5nc 5nc
6nc 6nc 6nc
7nc 7nc 7nc
8nc 8nc 8nc
9nc 9nc 9nc
10 nc 10 P0.7/IREF0 10 P0.6/CNVSTR
11 P0.5/RX 11 P0.4/TX 11 P0.3H
12 P0.2H 12 P0.1/AGND 12 P0.0/VREF
13 P1.7/AD7 13 P1.6/AD6 13 P1.5/AD5
14 P1.4/AD4 14 P1.3/AD3 14 P1.2/AD2
15 P1.1/AD1 15 P1.0/AD0 15 A7-Latch
16 A6-Latch 16 A5-Latch 16 A4-Latch
17 A3-Latch 17 A2-Latch 17 A1-Latch
18 A0-Latch 18 P2.3/A11 18 nc
19 nc 19 nc 19 P2.3/A11
20 P2.2/A10 20 P2.1/A9 20 P2.0/A8
21 /WR 21 /RD 21 P0.2H
22 P2.3/A11 22 P2.2/A10 22 P2.1/A9
23 P2.0/A8 23 ALE 23 nc
24 nc 24 nc 24 nc
25 nc 25 GND 25 nc
26 GND 26 nc 26 nc
27 nc 27 nc 27 nc
28 nc 28 VDD/DC+ 28 VBAT
29 nc 29 nc 29 nc
30 nc 30 nc 30 nc
31 nc 31 nc 31 nc
32 nc 32 GND 32 nc

C8051F93x/92x
18 Rev 0.7
5.7. Target Board DEBUG Interface (J9)
The DEBUG connector J9 provides access to the DEBUG (C2) pins of the C8051F930. It is used to connect the
Serial Adapter or the USB Debug Adapter to the target board for in-circuit debugging and Flash programming.
Table 3 shows the
DEBUG pin definitions.
5.8. Serial Interface (J12)
A USB-to-UART bridge circuit (U3) and USB connector (P3) are provided on the target board to facilitate serial
connections to UART0 of the C8051F930. The Silicon Labs CP2103 (U3) USB-to-UART bridge provides data
connectivity between the C8051F930 and the PC via a USB port. The VIO power supply and TX, RX, RTS and
CTS signals of UART0 may be connected to the CP2103 by installing shorting blocks on header J12. The shorting
block positions for connecting each of these signals to the CP2103 are listed in Table 4. To use this interface, the
USB-to-UART device drivers should be installed as described in Section 4.4. "CP210x USB to UART VCP Driver
Installation‚" on page 7.
5.9. Analog I/O (H1)
Several of the C8051F930 target device’s port pins are connected to the H1 terminal block. Refer to Table 5 for the
H1 terminal block connections.
Table 3. DEBUG Connector Pin Descriptions
Pin # Description
1 +3VD(+3.3VDC)
2, 3, 9 GND (Ground)
4 P2.7/C2D
5RST
(Reset)
6P2.7
7RST
/C2CK
8 Not Connected
10 USB Power (+5 VDC from J9)
Table 4. Serial Interface Header (J12) Description
Header Pins UART0 Pin Description
J12[9–10] CP2103_VIO (VDD/DC+)
J12[7–8] TX_MCU (P0.5)
J12[5–6] RX_MCU (P0.4)
J12[3–4] RTS (P0.6)
J12[1–2] CTS (P0.7)
Table 5. H1 Terminal Block Pin Descriptions
Pin # Description
1 P0.6/CNVSTR
2P0.7/IREF0
3 GND (Ground)
4 P0.0/VREF (Voltage Reference)

C8051F93x/92x
Rev 0.7 19
5.10. IREF Connector (J7)
The C8051F930 Target Board also features a current-to-voltage 1 kload resistor that may be connected to the
current reference (IREF0) output that can be enabled on port pin (P0.7). Install a shorting block on J7 to connect
port pin P0.7 of the target device to the load resistor. If enabled by software, the IREF0 signal is then routed to the
J2[8] and H1[2] connectors.
5.11. VREF and AGND Connector (J13, J14)
The C8051F930 Target Board also features 4.7 µF capacitor in parallel with a 0.1 µF that can be connected to
P0.0/VREF when using the Precision Voltage Reference. The capacitors are connected to P0.0/VREF when a
shorting block is installed on J13. Using the Precision Voltage Reference is optional since 'F93x-'F92x devices
have an on-chip High-Speed Voltage Reference.
The shorting block J14 allows P0.1/AGND to be connected to ground. This provides a noise-free ground reference
to the analog-to-digital Converter. The use of this dedicated analog ground is optional.
5.12. C2 Pin Sharing
On the C8051F930, the debug pins C2CK and C2D are shared with the pins RST and P2.7, respectively. The
target board includes the resistors necessary to enable pin sharing which allow the RST and P2.7 pins to be used
normally while simultaneously debugging the device. See Application Note “AN124: Pin Sharing Techniques for the
C2 Interface” at www.silabs.com for more information regarding pin sharing.

C8051F93x/92x
20 Rev 0.7
6. Frequently Asked Questions
1. Should power be turned off when switching between one-cell and two-cell mode?
Yes, power must be turned off by placing SW5 in the OFF position when switching between one-cell and
two-cell mode. Switching between modes while power is on may result in increased power consumption
and possible damage to low voltage transistors.
2. I have placed the MCU in Sleep Mode. Why is the supply current greater than 1 µA?
This can be caused by a number of factors. Check the following:
a. Verify that the USB Debug Adapter is not connected to the device. When connected, it can draw
approximately 2–5 µA from the VDD/DC+ supply net.
b. Verify that the P1.5 and P1.6 LEDs are turned off in software (P1.5 and P1.6 set to logic HIGH).
Alternatively, the P1.5 and P1.6 LEDs can be disabled by removing the corresponding shorting blocks
from J8.
c. Verify that the VDD/DC+ Power LED is disabled (remove shorting block from J5).
d. Verify that the shorting block on J15 does not connect the potentiometer negative terminal to GND,
since this would result in continuous current of ~ 300 µA. The shorting block may be removed, or
configured to enable the potentiometer when P1.4 is set to logic LOW. When the potentiometer enable
is under software control, be sure to set P1.4 to logic HIGH prior to placing the device in Sleep Mode.
e. Verify that J7, J13, and J14 do not have shorting blocks installed.
3. I have been measuring the sleep mode current using the “µA” setting on my multimeter. Why am I
no longer able to connect to the IDE?
When most multimeters are placed in “µA” mode, a large resistance is placed in series with the power
supply. This “current limiting” resistor prevents the MCU from starting up. To measure current during
startup, make sure that the multimeter is configured to its “mA” setting.
Alternatively, a shorting block can be placed on J17 to ensure that the multimeter does not limit current
during startup.
4. Where can I find a schematic of the C8051F930 Target Board?
A target board schematic can be found in the C8051F930-DK User’s Guide which is available on the
Development Tools CD and is installed in the following folder (by default):
C:\SiLabs\MCU\Documentation\UsersGuides
5. Which power LED should I use to determine if the MCU is powered?
The VDD/DC+ LED (DS5) should be used to determine if the MCU is powered. If you have applied power
to the board, but the VDD/DC+ LED is not turning on, check the following:
a. Verify that the correct power source (J10, J11) is selected.
b. Verify that J17 has a shorting block.
c. Verify that SW5 is in the ON position.
d. Verify that J5 has a shorting block installed.
